Automatic Transmission - Special Tools - E38: Other — BMW 7 series E65/E66 (2001-2005)

24 0 120 Attachment for trolley

Note	For removing and installing transmission / Replaced by 24 0 130, March 87
Transmission	4 HP 22
Order number	24 0 120
Attachment for trolley

ATTACHMENT FOR TROLLEY - GENERAL SPECIFICATION

Identifying Take-Up Support For Transmission. Scheme 286

Scheme 286: Identifying Take-Up Support For Transmission

In conjunction with	00 2 030 (not included in minimum kit)
Note	For removal and installation
Transmission	4 HP 22, 4 HP 24
SI number	1 02 87(721)
Order number	24 0 130
Take-up support for transmission

TAKE-UP SUPPORT FOR TRANSMISSION - GENERAL SPECIFICATION

Identifying Pipe Manifold. Scheme 287

Scheme 287: Identifying Pipe Manifold

In conjunction with	13 3 061, 24 0 021, 24 0 022, 13 6 051, 13 6 052, 24 5 190
Note	For pressure gauge 13 3 061 and BMW DIS for measuring oil pressure in transmission
Transmission	A4S 270R, A4S 310R, A5S 310Z, A5S 560Z
Storage location	C3
SI number	1 01 92(469)
Order number	24 0 140
Pipe manifold

PIPE MANIFOLD - GENERAL SPECIFICATION

Identifying Mounting Bracket. Scheme 288

Scheme 288: Identifying Mounting Bracket

In conjunction with	00 1 450
Note	For mounting transmission on assembly stand
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, A4S 270R, A4S 310R, A5S 310Z
Order number	24 0 150
Mounting bracket
Consisting of
2 = 24 0 152	Base frame
3 = 24 0 153	Spindle with rotary handle
6 = 24 0 156	Spindle
Note: With thrust piece, transmission: all
In conjunction with: 00 1 450

MOUNTING BRACKET - GENERAL SPECIFICATION

Identifying Support. Scheme 289

Scheme 289: Identifying Support

In conjunction with	00 2 030 (not included in minimum kit)
Note	For removing and installing transmission
Transmission	A5S 560Z
SI number	1 06 92(509)
Order number	24 0 170
Support
Consisting of
24 0 171	Adjusting screw

SUPPORT - GENERAL SPECIFICATION

Identifying Support. Scheme 290

Scheme 290: Identifying Support

In conjunction with	00 1 450
Note	For mounting transmission on assembly stand
Transmission	A5S 310Z, A5S 325Z, A5S 360R, A5S 440Z, A5S 560Z, GA6 HP26Z
SI number	1 06 92 (509)
Order number	24 0 180
Support
Consisting of
1 = 24 0 181	Base frame
2 = 24 0 182	Pressure spindle with star handle
3 = 24 0 183	Spindle
Note: Replaced by 24 0 184
4 = 24 0 184	Spindle, long (2 x)

SUPPORT - GENERAL SPECIFICATION

Identifying Holding Fixture. Scheme 291

Scheme 291: Identifying Holding Fixture

Note	For output flange of propeller shaft while releasing and tightening slotted nut
Transmission	A5S 560Z
SI number	1 06 92(509)
Order number	24 0 190
Holding fixture

HOLDING FIXTURE - GENERAL SPECIFICATION

Identifying Take-Up Support For Transmission. Scheme 292

Scheme 292: Identifying Take-Up Support For Transmission

In conjunction with	24 5 301 and 00 2 030 (not included in minimum tool kit)
Note	For removal and installation
Transmission	A5S 440Z
SI number	1 08 96(080)
Order number	24 0 250
Take-up support for transmission

TAKE-UP SUPPORT FOR TRANSMISSION - GENERAL SPECIFICATION

Identifying Installation Sleeve. Scheme 293

Scheme 293: Identifying Installation Sleeve

Note	For removing disc pack (4th gear) as well as fitting needle bearing in oil pump housing (A5S 560Z)
Transmission	4 HP 22, 4 HP 24, A5S 560Z
Storage location	A18
Order number	24 1 010
Installation sleeve

INSTALLATION SLEEVE - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 294

Scheme 294: Identifying Impact Bush

Note	For fitting rotary shaft seal for torque converter in oil pump housing
Transmission	3 HP 20, 3 HP 22
Storage location	C29
Order number	24 1 050
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 295

Scheme 295: Identifying Impact Bush

Note	For fitting rotary shaft seal for torque converter in oil pump housing and on output flange
Transmission	3 HP 20, 3 HP 22, A5S 300J, BW 65
Storage location	B29, C29
Order number	24 1 060
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 296

Scheme 296: Identifying Impact Bush

Note	For fitting rotary shaft seal in oil pump housing
Transmission	A5S 325Z
Storage location	B36
SI number	1 03 98(303)
Order number	24 1 070
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Bush (Aluminum). Scheme 297

Scheme 297: Identifying Bush (Aluminum)

In conjunction with	00 5 010
Note	For fitting on input shaft while removing rotary shaft seal from oil pump housing
Transmission	A5S 325Z
Storage location	A36
SI number	1 03 98(303)
Order number	24 1 080
Bush (aluminum)

BUSH (ALUMINUM) - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 298

Scheme 298: Identifying Impact Bush

Note	For installing rotary shaft seal on output flange
Transmission	A5S 390G
SI number	1 08 98(333)
Order number	24 1 090
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 299

Scheme 299: Identifying Impact Bush

Note	For fitting rotary shaft seal for output flange in transmission extension
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 1 100
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Socket With Magnet. Scheme 300

Scheme 300: Identifying Socket With Magnet

Note	For loosening and tightening converter mounting
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location	B19
SI number	1 04 86 (566)
Order number	24 1 110
Socket with magnet

SOCKET WITH MAGNET - GENERAL SPECIFICATION

Identifying Gauge. Scheme 301

Scheme 301: Identifying Gauge

Note	For adjusting position switch in "P" position during assembly / Model year: As from 03/96
Transmission	A4S 270R
SI number	1 07 96(068)
Order number	24 1 120
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Pin Wrench. Scheme 302

Scheme 302: Identifying Pin Wrench

Note	For releasing and tightening slotted nut on output flange
Transmission	A5S 310Z
Storage location	A35
SI number	1 09 90(282)
Order number	24 1 170
Pin wrench

PIN WRENCH - GENERAL SPECIFICATION

Identifying Fixture. Scheme 303

Scheme 303: Identifying Fixture

In conjunction with	24 1 080 (A5S 325Z)
Note	For removing and installing oil pump
Transmission	A5S 310Z, A5S 560Z
Storage location	B18
SI number	1 09 90(282)
Order number	24 1 180
Fixture
Consisting of
1 = 24 1 181	Retaining tube
2 = 24 1 182	Thread spindle
3 = 24 1 183	Retaining ring, inner
Note: (not shown)

FIXTURE - GENERAL SPECIFICATION

Identifying Drift. Scheme 304

Scheme 304: Identifying Drift

In conjunction with	00 5 500
Note	For fitting rotary shaft seal in front section of transmission casing
Transmission	A5S 310Z
Storage location	B28
SI number	1 09 90(282)
Order number	24 1 190
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Installation Sleeve. Scheme 305

Scheme 305: Identifying Installation Sleeve

Note	For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission	A5S 310Z
Storage location	B18
SI number	1 09 90(282)
Order number	24 1 200
Installation sleeve

INSTALLATION SLEEVE - GENERAL SPECIFICATION

Identifying Retaining Plate For Disc Package. Scheme 306

Scheme 306: Identifying Retaining Plate For Disc Package

Note	Not required as from transmission No. 11 2 300
Transmission	A5S 310Z
Storage location	B22
SI number	1 09 90(282)
Order number	24 1 210
Retaining plate for disc package

RETAINING PLATE FOR DISC PACKAGE - GENERAL SPECIFICATION

Identifying Take-Up Support For Drive Flange. Scheme 307

Scheme 307: Identifying Take-Up Support For Drive Flange

In conjunction with	24 1 170 (A5S 310Z), 24 4 110 (A5S 440Z)
Note	When loosening slotted nut
Transmission	A5S 310Z, A5S 440Z
SI number	1 09 90(282)
Order number	24 1 220
Take-up support for drive flange

TAKE-UP SUPPORT FOR DRIVE FLANGE - GENERAL SPECIFICATION

Identifying Pressing Tool. Scheme 308

Scheme 308: Identifying Pressing Tool

Note	For removing and installing piston (cover) on brake Ct
Transmission	A5S 310Z
Storage location	B20
SI number	1 14 93(718)
Order number	24 1 230
Pressing tool

PRESSING TOOL - GENERAL SPECIFICATION

Identifying Measuring Device. Scheme 309

Scheme 309: Identifying Measuring Device

Note	For determining spacers on brake C
Transmission	A5S 310Z
Storage location	B20
SI number	1 14 93(718)
Order number	24 1 240
Measuring device

MEASURING DEVICE - GENERAL SPECIFICATION

Identifying Lifting Gear. Scheme 310

Scheme 310: Identifying Lifting Gear

Note	For removing and installing brake clutch unit D/G incl. sprag wheel
Transmission	A5S 310Z
Storage location	B11, C11
SI number	1 14 93(718)
Order number	24 1 250
Lifting gear

LIFTING GEAR - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 311

Scheme 311: Identifying Removal And Mounting Fixture

Note	For removing and installing cylinder D/E with planetary gear train
Transmission	A5S 560Z
Storage location	C1, C2
SI number	1 01 95(892)
Order number	24 1 260
Removal and mounting fixture
Consisting of
1 = 24 1 261	Handle
2 = 24 1 262	Spindle with knurled nut
3 = 24 1 263	Centering bush

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 312

Scheme 312: Identifying Removal And Mounting Fixture

Note	For removing and installing clutch A/B/C
Transmission	A5S 560Z
Storage location	B14, B15, B3
SI number	1 01 95(892)
Order number	24 1 270
Removal and mounting fixture
Consisting of
1 = 24 1 271	Lifting tube with eye bolt
2 = 24 1 272	Lock pin

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 313

Scheme 313: Identifying Removal And Mounting Fixture

Note	For removing and installing brake clutch F
Transmission	A5S 560Z
Storage location	C20
SI number	1 01 95(892)
Order number	24 1 280
Removal and mounting fixture
Consisting of
1 = 24 1 281	Handle with spindle
2 = 24 1 282	Knurled nut
3 = 24 1 283	Centering handle

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Wedges. Scheme 314

Scheme 314: Identifying Wedges

Note	For fixing disc pack C in position while securing retainer tabs
Transmission	A5S 560Z
Storage location	C17
SI number	1 01 95(892)
Order number	24 1 290
Wedges

WEDGES - GENERAL SPECIFICATION

Identifying Impact Tool. Scheme 315

Scheme 315: Identifying Impact Tool

Note	For securing retainer tabs on disc pack C
Transmission	A5S 560Z
Storage location	C17
SI number	1 01 95(892)
Order number	24 1 300
Impact tool

IMPACT TOOL - GENERAL SPECIFICATION

Identifying Releasing Tool. Scheme 316

Scheme 316: Identifying Releasing Tool

Note	For releasing retainer tabs on disc pack C
Transmission	A5S 560Z
Storage location	C2
SI number	1 01 95(892)
Order number	24 1 310
Releasing tool
Consisting of
1 = 24 1 311	Profile section (slide)
2 = 241 312	Basic body

RELEASING TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 317

Scheme 317: Identifying Tool

Note	For compressing disc spring
Transmission	4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 020
Tool

TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 318

Scheme 318: Identifying Tool

Note	For compressing disc spring
Transmission	3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 030
Tool

TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 319

Scheme 319: Identifying Tool

Note	For compressing disc spring
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 040
Tool

TOOL - GENERAL SPECIFICATION

24 2 050 Extractor grip

Note	For sealing plugs in transmission case lower section / Replaced by 24 0 050
Order number	24 2 050
Extractor grip

EXTRACTOR GRIP - GENERAL SPECIFICATION

Identifying Tensioning Tool. Scheme 320

Scheme 320: Identifying Tensioning Tool

Note	For removing and installing snap ring in front of centering plate of ZF transmissions
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 2 140
Tensioning tool

TENSIONING TOOL - GENERAL SPECIFICATION

Identifying Tool Kit For Removing And Installing Reverse Gear Piston. Scheme 321

Scheme 321: Identifying Tool Kit For Removing And Installing Reverse Gear Piston

Note	For disassembling and assembling transmission for "Sealing intermediate plate" job
Transmission	A4S 270R, A4S 310R
SI number	1 22 97(239)
Order number	24 2 310
Consisting of
Tool kit for removing and installing reverse gear piston
1 = 24 2 311	Pressure plate
Note: For removing and installing spring retainer
2 = 24 2 312	Spindle with pressure plate
Note: Spindle M14x1.5, nut M14, pressure plate and washer / For removing and installing spring retainer
3 = 24 2 313	Guide pin (2)
Note: For fixing gaskets and intermediate plates on intermediate housing
4 = 24 2 314	Slip bush
Note: For removing piston in cylinder of intermediate plate

TOOL KIT FOR REMOVING AND INSTALLING REVERSE GEAR PISTON - GENERAL SPECIFICATION

Identifying Box Spanner. Scheme 322

Scheme 322: Identifying Box Spanner

In conjunction with	24 2 330
Note	For 3/16" socket head cap screw with 1/4" socket for adjusting brake band
Transmission	A4S 270R, A4S 310R
SI number	1 24 97(257)
Order number	24 2 320
Box spanner

BOX SPANNER - GENERAL SPECIFICATION

Identifying Open-Ended Spanner. Scheme 323

Scheme 323: Identifying Open-Ended Spanner

In conjunction with	24 2 320
Note	For adjusting brake band
Transmission	A4S 270R, A4S 310R
SI number	1 24 97(257)
Order number	24 2 330
1/2" open-ended spanner

1/2" OPEN-ENDED SPANNER - GENERAL SPECIFICATION

Identifying Drift. Scheme 324

Scheme 324: Identifying Drift

Note	For fitting radial seal on torque converter
Transmission	GA6 HP26Z, GA6 HP32Z
Storage location	B46
SI number	1 14 01 (766)
Order number	24 2 360
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Gauge. Scheme 325

Scheme 325: Identifying Gauge

Note	For adjusting restrictor piston when installing gearshift unit
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 3 040
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Gauge. Scheme 326

Scheme 326: Identifying Gauge

Note	For aligning hydraulic gearshift unit in transmission
Transmission	3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Order number	24 3 050
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Drive Bush. Scheme 327

Scheme 327: Identifying Drive Bush

Note	For checking smooth movement of oil pump
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A5S 560Z
Storage location	A20
Order number	24 3 140
Drive bush

DRIVE BUSH - GENERAL SPECIFICATION

Identifying Drive Bush. Scheme 328

Scheme 328: Identifying Drive Bush

Note	For checking smooth movement of oil pump
Transmission	3 HP 20, 3 HP 22
Storage location	A20
Order number	24 3 150
Drive bush

DRIVE BUSH - GENERAL SPECIFICATION

Identifying Assembly Grip (2). Scheme 329

Scheme 329: Identifying Assembly Grip (2)

Note	For removing and installing torque converter
Transmission	A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location	C18
Order number	24 4 000
Assembly grip (2)

ASSEMBLY GRIP (2) - GENERAL SPECIFICATION

Identifying Fixture. Scheme 330

Scheme 330: Identifying Fixture

Note	For checking torque converter for leaks
Transmission	3 HP 20, 3 HP 22, 4 HP 22
Order number	24 4 070
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Fixture. Scheme 331

Scheme 331: Identifying Fixture

Note	For firmly holding torque converter in position while removing and installing transmission
Transmission	4 HP 22, 4 HP 24
Storage location	Single
Order number	24 4 080
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Drift. Scheme 332

Scheme 332: Identifying Drift

In conjunction with	00 5 500
Note	For fitting rotary shaft seal on output end
Transmission	A5S 440Z, A5S 560Z
Storage location	B28
SI number	1 06 92(509)
Order number	24 4 090
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Drift. Scheme 333

Scheme 333: Identifying Drift

Note	For fitting rotary shaft seal on drive side (behind converter)
Transmission	A5S 440Z, A5S 560Z
Storage location	C29
SI number	1 06 92(509)
Order number	24 4 100
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Spanner. Scheme 334

Scheme 334: Identifying Spanner

Note	For releasing and tightening slotted nut on output flange
Transmission	A5S 440Z, A5S 560Z
Storage location	A23
SI number	1 06 92(509)
Order number	24 4 110
Spanner

SPANNER - GENERAL SPECIFICATION

Identifying Fixture. Scheme 335

Scheme 335: Identifying Fixture

Note	For firmly holding torque converter in position while removing and installing transmission. Replaced by 24 4 130.
Order number	24 4 120
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Locating Tool. Scheme 336

Scheme 336: Identifying Locating Tool

Note	For firmly holding torque converter in position while removing and installing transmission
Transmission	A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP26Z, GA6 HP32Z
Storage location	A33
SI number	1 05 97(181)
Order number	24 4 130
Locating tool
Consisting of
1 = 24 4 131	Base unit
2 = 24 4 132	Blade
Note: Transmission: A5S 440Z, GA6HP26Z (N62)
3 = 24 4 133	Blade
Note: Transmission: A4S 310R and A5S 390G
4 = 24 4 134	Blade
Note: Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z
5 = 24 4 135	Blade
Note: Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73)
6 = 24 4 136	Counter plate
7 = 24 4 137	Blade
Note: Transmission: A5S 360R

LOCATING TOOL - GENERAL SPECIFICATION

Identifying Drift And Slip Bush. Scheme 337

Scheme 337: Identifying Drift And Slip Bush

Note	For driving in shaft seal on drive shaft.
Transmission	GACVT16Z
Order number	24 4 200
Drift and slip bush
Consisting of
1 = 24 4 201	Drift
2 = 24 4 202	Slip bush

DRIFT AND SLIP BUSH - GENERAL SPECIFICATION

Identifying Tool. Scheme 338

Scheme 338: Identifying Tool

Note	For centering converter bell housing with respect to oil pump during assembly
Transmission	A4S 270R, A4S 310R
Storage location	B2
SI number	1 04 95(906)
Order number	24 5 120
Tool
Consisting of
1 = 24 5 121	Centering bush
2 = 24 5 122	Centering pin (3)

TOOL - GENERAL SPECIFICATION

24 5 140 Centering pin

Note	For transfer plate and gasket to shift unit (2x)
Transmission	A4S 310R
Order number	24 5 140
Centering pin

CENTERING PIN - GENERAL SPECIFICATION

Identifying Centering Pin With Thread (2). Scheme 339

Scheme 339: Identifying Centering Pin With Thread (2)

Note	For centering gearshift unit in transmission during assembly
Transmission	A4S 270R, A4S 310R
Storage location	A2
SI number	1 03 90(184)
Order number	24 5 150
Centering pin with thread (2)

CENTERING PIN WITH THREAD (2) - GENERAL SPECIFICATION

Identifying Centering Pins. Scheme 340

Scheme 340: Identifying Centering Pins

Note	For centering main housing with respect to intermediate and converter housing (2)
Transmission	A4S 270R, A4S 310R
Storage location	A2, B2
SI number	1 03 93(663)
Order number	24 5 160
Centering pins

CENTERING PINS - GENERAL SPECIFICATION

Identifying Adapter. Scheme 341

Scheme 341: Identifying Adapter

In conjunction with	13 3 061, 13 3 067, 24 0 021, 24 0 023, 24 0 140
Note	For pressure gauge 133 061 for checking oil pressure in transmission
Transmission	A4S 270R, A4S 310R
Storage location	C20
SI number	1 03 90(184)
Order number	24 5 190
Adapter

ADAPTER - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 342

Scheme 342: Identifying Impact Bush

Note	For driving in radial seal of selector lever shaft / Replaced by 24 5 360
Transmission	A4S 270R, A4S 310R
SI number	1 03 90(184)
Order number	24 5 200
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Holder. Scheme 343

Scheme 343: Identifying Holder

Note	For loosening and tightening gearshift cable
Transmission	4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 210
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Holder. Scheme 344

Scheme 344: Identifying Holder

Note	For loosening and tightening gearshift cable
Transmission	A5S 300J, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 220
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Assembly Ring. Scheme 345

Scheme 345: Identifying Assembly Ring

Note	For fitting rotary shaft seal on gearshift shaft
Transmission	4 HP 22, 4 HP 24, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 230
Assembly ring

ASSEMBLY RING - GENERAL SPECIFICATION

Identifying Holder. Scheme 346

Scheme 346: Identifying Holder

Note	For releasing and tightening gearshift cable / transmission with position switch
Transmission	A5S 310Z, A5S 560Z
Storage location	B19
SI number	1 06 92(509)
Order number	24 5 240
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Bush. Scheme 347

Scheme 347: Identifying Bush

In conjunction with	24 5 490
Note	For fitting rotary shaft seal on selector shaft
Transmission	A5S 310Z, A5S 560Z
Storage location	B19
SI number	1 02 95(896)
Order number	24 5 250
Bush

BUSH - GENERAL SPECIFICATION

Identifying Extractor Tool. Scheme 348

Scheme 348: Identifying Extractor Tool

Note	For removing rotary shaft seal of selector shaft / transmission with position switch
Transmission	A5S 310Z, A5S 440Z, A5S 560Z
Storage location	B19
SI number	1 02 95 (896)
Order number	24 5 260
Extractor tool
Consisting of
1 = 24 5 261	Insert
2 = 24 5 262	Bushing

EXTRACTOR TOOL - GENERAL SPECIFICATION

Identifying Bush. Scheme 349

Scheme 349: Identifying Bush

In conjunction with	24 5 490
Note	For fitting rotary shaft seal on selector shaft
Transmission	A5S 440Z
Storage location	B18
SI number	1 08 96(080)
Order number	24 5 270
Bush

BUSH - GENERAL SPECIFICATION

Identifying Take-Up Support For Automatic Transmission. Scheme 350

Scheme 350: Identifying Take-Up Support For Automatic Transmission

Note	Miscellaneous: Japan and South Africa only
Transmission	A5S 300J
Order number	24 5 350
Take-up support for automatic transmission

TAKE-UP SUPPORT FOR AUTOMATIC TRANSMISSION - GENERAL SPECIFICATION

Identifying Drift. Scheme 351

Scheme 351: Identifying Drift

In conjunction with	00 5 500
Note	For drive shaft seal.
Transmission	GACVT16Z
Order number	24 5 400
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Slip Sleeve (5). Scheme 352

Scheme 352: Identifying Slip Sleeve (5)

Note	For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission	A5S 310Z, A5S 440Z, A5S 560Z
SI number	1 02 95 (896)
Order number	24 5 490
Slip sleeve (5)

SLIP SLEEVE (5) - GENERAL SPECIFICATION

Identifying Test Cable, 8-Pin. Scheme 353

Scheme 353: Identifying Test Cable, 8-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	4 HP 22, 4 HP 24
Storage location	A 101
SI number	2 03 91(313)
Order number	24 6 000
Test cable, 8-pin

TEST CABLE, 8-PIN - GENERAL SPECIFICATION

Identifying Test Cable, 9-Pin. Scheme 354

Scheme 354: Identifying Test Cable, 9-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	A4S 270R, A4S 310R
Storage location	A 102
SI number	2 03 91(313)
Order number	24 6 010
Test cable, 9-pin

TEST CABLE, 9-PIN - GENERAL SPECIFICATION

Identifying Test Cable, 14-Pin. Scheme 355

Scheme 355: Identifying Test Cable, 14-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	A5S 310Z
Storage location	A 103
SI number	0 02 99 (399)
Order number	24 6 020
Test cable, 14-pin
Consisting of
24 6 029	Operating instructions

TEST CABLE, 14-PIN - GENERAL SPECIFICATION

Automatic Transmission - Special Tools - E38: Other BMW 7 series E65/E66

24 0 120 Attachment for trolley

Identifying Take-Up Support For Transmission. Scheme 286

Identifying Pipe Manifold. Scheme 287

Identifying Mounting Bracket. Scheme 288

Identifying Support. Scheme 289

Identifying Support. Scheme 290

Identifying Holding Fixture. Scheme 291

Identifying Take-Up Support For Transmission. Scheme 292

Identifying Installation Sleeve. Scheme 293

Identifying Impact Bush. Scheme 294

Identifying Impact Bush. Scheme 295

Identifying Impact Bush. Scheme 296

Identifying Bush (Aluminum). Scheme 297

Identifying Impact Bush. Scheme 298

Identifying Impact Bush. Scheme 299

Identifying Socket With Magnet. Scheme 300

Identifying Gauge. Scheme 301

Identifying Pin Wrench. Scheme 302

Identifying Fixture. Scheme 303

Identifying Drift. Scheme 304

Identifying Installation Sleeve. Scheme 305

Identifying Retaining Plate For Disc Package. Scheme 306

Identifying Take-Up Support For Drive Flange. Scheme 307

Identifying Pressing Tool. Scheme 308

Identifying Measuring Device. Scheme 309

Identifying Lifting Gear. Scheme 310

Identifying Removal And Mounting Fixture. Scheme 311

Identifying Removal And Mounting Fixture. Scheme 312

Identifying Removal And Mounting Fixture. Scheme 313

Identifying Wedges. Scheme 314

Identifying Impact Tool. Scheme 315

Identifying Releasing Tool. Scheme 316

Identifying Tool. Scheme 317

Identifying Tool. Scheme 318

Identifying Tool. Scheme 319

24 2 050 Extractor grip

Identifying Tensioning Tool. Scheme 320

Identifying Tool Kit For Removing And Installing Reverse Gear Piston. Scheme 321

Identifying Box Spanner. Scheme 322

Identifying Open-Ended Spanner. Scheme 323

Identifying Drift. Scheme 324

Identifying Gauge. Scheme 325

Identifying Gauge. Scheme 326

Identifying Drive Bush. Scheme 327

Identifying Drive Bush. Scheme 328

Identifying Assembly Grip (2). Scheme 329

Identifying Fixture. Scheme 330

Identifying Fixture. Scheme 331

Identifying Drift. Scheme 332

Identifying Drift. Scheme 333

Identifying Spanner. Scheme 334

Identifying Fixture. Scheme 335

Identifying Locating Tool. Scheme 336

Identifying Drift And Slip Bush. Scheme 337

Identifying Tool. Scheme 338

24 5 140 Centering pin

Identifying Centering Pin With Thread (2). Scheme 339

Identifying Centering Pins. Scheme 340

Identifying Adapter. Scheme 341

Identifying Impact Bush. Scheme 342

Identifying Holder. Scheme 343

Identifying Holder. Scheme 344

Identifying Assembly Ring. Scheme 345

Identifying Holder. Scheme 346

Identifying Bush. Scheme 347

Identifying Extractor Tool. Scheme 348

Identifying Bush. Scheme 349

Identifying Take-Up Support For Automatic Transmission. Scheme 350

Identifying Drift. Scheme 351

Identifying Slip Sleeve (5). Scheme 352

Identifying Test Cable, 8-Pin. Scheme 353

Identifying Test Cable, 9-Pin. Scheme 354

Identifying Test Cable, 14-Pin. Scheme 355

More articles — Automatic Transmission - Special Tools - E38

Login / Signup

Enter the code

You have successfully logged in!
