Wiring diagram: Computer data lines — Computer data lines circuit BMW 6 series F06/F13/F12 facelift
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering 2
- Electronic suspension 2
- Engine performance 3.0l turbo
- Engine performance 4.4l turbo
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 3
- Memory systems 4
- Navigation 7
- Passive restraints
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats 5
- Power top/sunroof 2
- Power windows 2
- Radio 8
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Computer data lines circuit (1 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Computer data lines circuit (2 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Computer data lines circuit (3 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Computer data lines circuit (4 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Computer data lines circuit (5 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Computer data lines circuit (6 of 6) BMW 6 series F06/F13/F12 facelift
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
