11 0 220 Compression test kit
Minimum set: Mechanical tools
Scheme 405
| Note | For all petrol/gasoline and diesel engines. |
|---|---|
| Engine | M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17 |
| SI number | 1 09 92 (558) |
| Order number | 11 0 220 |
| Compression test kit | |
| Consisting of | |
| 16 = 11 0 239 | Adapter |
| NOTE: Engine M67, M67TU | |
| 11 0 221 | Compression recorder for diesel engines |
| 11 0 222 | Test probe |
| NOTE: For compression recorder 11 0 221 and 11 0 160/Engine: M21, M41, M47, M51, M57 | |
| In conjunction with: 11 0 240 | |
| 11 0 223 | Test sheets (100 x) |
| NOTE: For compression recorder for 11 0 221 | |
| 11 0 224 | Compression recorder for petrol/gasoline engines |
| 11 0 226 | Test probe |
| NOTE: For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, S50US, S52US, S62 | |
| In conjunction with: 11 0 240 | |
| 11 0 228 | Rubber taper with fitting |
| NOTE: For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30 | |
| In conjunction with: 11 0 240 | |
| 11 0 229 | Test charts (100 x) |
| NOTE: For compression recorder 11 0 224 | |
| 11 0 231 | Case |
| NOTE: With foam inlay for compression recorder | |
| 11 0 233 | Non-return valve |
| 11 0 234 | Filter 3x3 mm |
| 11 0 235 | Test probe, screw-in |
| NOTE: For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54 | |
| In conjunction with: DIS and DIS pressure sensor | |
| 11 0 236 | Test probe |
| NOTE: For compression recorder 11 0 221 or DIS pressure sensor / engine: M47, M57, M57TU | |
| 11 0 237 | Adapter |
| NOTE: For measuring "absolute compression" at all cylinders. Engine: W17 | |
| In conjunction with: 11 0 221, 11 0 235 or DIS pressure sensor, 11 0 235 | |
| NOTE |
|---|
| Engine M67, M67TU |
| NOTE |
|---|
| For compression recorder 11 0 221 and 11 0 160/Engine: M21, M41, M47, M51, M57 |
| NOTE |
|---|
| For compression recorder for 11 0 221 |
| NOTE |
|---|
| For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, S50US, S52US, S62 |
| NOTE |
|---|
| For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30 |
| NOTE |
|---|
| For compression recorder 11 0 224 |
| NOTE |
|---|
| With foam inlay for compression recorder |
| NOTE |
|---|
| For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54 |
| NOTE |
|---|
| For compression recorder 11 0 221 or DIS pressure sensor / engine: M47, M57, M57TU |
| NOTE |
|---|
| For measuring "absolute compression" at all cylinders. Engine: W17 |
COMPRESSION TEST KIT SPECIFICATION
11 7 390 Complete pressure testing fixture
| Note | For closing off coolant outlet openings when pressure-testing cylinder head for water leaks |
|---|---|
| Engine | M52TU, M54, M56 |
| Order number | 11 7 390 |
| Complete pressure testing fixture | |
| Consisting of | |
| 1 = 11 7 391 | Sealing strip with 7 lugs |
| 2 = 11 7 392 | Sealing strip with 5 lugs |
| 3 = 11 7 393 | Cover plate |
| NOTE: For cylinder head sealing face | |
| 4 = 11 7 394 | Support bracket |
| NOTE: With pressure spindle and mounting screw for 11 7 393 | |
| 5 = 11 7 395 | Screw plug |
| NOTE: With air connection | |
| 6 = 11 7 396 | Cover plate, end face |
| 7 = 11 7 397 | Spindle |
| NOTE: With thrust piece for 11 7 396 | |
| 8 = 11 7 398 | Screw plug, intake side |
| NOTE |
|---|
| For cylinder head sealing face |
| NOTE |
|---|
| With pressure spindle and mounting screw for 11 7 393 |
| NOTE |
|---|
| With air connection |
| NOTE |
|---|
| With thrust piece for 11 7 396 |
COMPLETE PRESSURE TESTING FIXTURE SPECIFICATION
