24 0 010 Fixture
In conjunction with: 00 2 510
Note: For checking axial play of drive shaft
Transmission: 4 HP 22, 4 HP 24, A5S 310Z, A5S 560Z
Storage location: B23
Order number: 24 0 010
Fixture
Consisting of
1 = 240 0 11 Dial gauge holder
2 = 24 0 012 Clamping piece
Scheme 302
24 0 030 Adapter
In conjunction 13 3 061, 24 0 021, 24 0 023 with
Note: For pressure gauge 13 3 061 / For check converter pressure
Transmission: 4 HP 22
Storage location: B23
Order number: 24 0 030
Adapter
Scheme 303
24 0 040 Retaining fixture
Note: For removing and installing disc pack
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C27
Order number: 24 0 040
Retaining fixture
Consisting of
1 = 24 0 041 Disc
2 = 24 0 042 Ring
3 = 24 0 043 Half shells
Scheme 304
24 0 050 Extractor grip
Note: For sealing plug in bottom section of transmission casing
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22 4 HP 24
Storage location: A24
Order number: 24 0 050
Extractor grip
Scheme 305
24 0 070 Adapter
In conjunction with: 13 3 061 (pressure gauge), 24 0 02 24 0 023
Note: For checking pump pressure
Transmission: 4 HP 22, 4 HP 24
Storage location: B23
Order number: 24 0 070
Adapter
Scheme 306
24 0 080 Funnel
Minimum set: Mechanical tools
Note: For filling transmission fluid in transmission
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16
Order number: 24 0 080
Funnel
Scheme 307
24 0 090 Drift
Note: For driving in radial seal in transmission front section / Replaced by 24 0 110, November 96
Transmission: 4 HP 22, 4 HP 24
Order number: 24 0 090
Drift
Scheme 308
24 0 110 Drift
Note: For driving in radial seal in transmission case front section / model year: from 90 and for output flange of S5D 200G S5D 250G transmissions
Series: E87, E90, E91, E92
Transmission: 4 HP 22, 4 HP 24, A5S 310Z, GS6 17BG, S5D 200G, S5D 250G
Storage location: C28
SI number: 1 03 90(184)
Order number: 24 0 110
Drift
Consisting of
24 0 111 Ring disk 1 mm
Note: Transmission: 4 HP 24 - No 160, 4 HP 22 - No. 1 113 936
Scheme 309
24 0 120 Attachment for trolley
Note: For removing and installing transmission Replaced by 24 0 130, March 87
Transmission: 4 HP 22
Order number: 24 0 120
Attachment for trolley
24 0 130 Take-up support for transmission
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For removal and installation
Transmission: 4 HP 22, 4 HP 24
SI number: 1 02 87(721)
Order number: 24 0 130
Take-up support for transmission
Scheme 310
24 0 140 Pipe manifold
Minimum set: Mechanical tools
In conjunction with: 13 3 061, 24 0 021, 24 0 022, 13 6 051, 13 6 052, 24 5 190
Note: For pressure gauge 13 3 061 and BMW for measuring oil pressure in transmission
Transmission: A4S 270R, A4S 310R, A5S 310Z, A5S 560Z
Storage location: C3
SI number: 1 01 92(469)
Order number: 24 0 140
Pipe manifold
Scheme 311
24 0 150 Mounting bracket
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP A4S 270R, A4S 310R, A5S 310Z
Order number: 24 0 150
Mounting bracket
Consisting of
2 = 24 0 152 Baseframe
3 = 24 0 153 Spindle with rotary handle
6 = 24 0 156 Spindle
Note: With thrust piece, transmission
In conjunction with: 00 1 450
Scheme 312
24 0 170 Support
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For removing and installing transmission
Transmission: A5S 560Z
SI number: 1 06 92(509)
Order number: 24 0 170
Support
Consisting of
24 0 171 Adjusting screw
Scheme 313
24 0 180 Support
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand.
Transmission: A5S 310Z, A5S 325Z, A5S 360R, A5S 440Z, A5S 560Z, GA6 HP 19Z, GA6 HP26Z
SI number: 1 06 92 (509)
Order number: 24 0 180
Support
Consisting of
1 = 24 0 181 Baseframe
2 = 24 0 182 Pressure spindle with star handle
4 = 24 0 184 Spindle, long (2 x)
5 = 24 0 185 Adapter
Scheme 314
24 0 190 Holding fixture
Minimum set: Mechanical tools
Note: For output flange of propeller shaft while releasing and tightening slotted nut
Transmission: A5S 310Z, A5S 325Z, A5S 360R, A5S 560Z
SI number: 1 06 92(509)
Order number: 24 0 190
Holding fixture
Scheme 315
24 0 200 Support
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand.
Transmission: A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
SI number: 1 27 06 (328)
Order number: 24 0 200
Support
Consisting of
1 = 24 0 201 Basic body
2 = 24 0 202 Spindle with thrust member
3 = 24 0 203 Spindle with screw
4 = 24 0 204 Sliding piece
5 = 24 0 205 Adapter (long)
6 = 24 0 206 Adapter (medium)
7 = 24 0 207 Adapter (short)
Scheme 316
24 0 250 Take-up support for transmission
In conjunction with: 24 5 301 and 00 2 030 (not included minimum tool kit)
Note: For removing and installing transmission
Transmission: A5S 440Z
SI number: 1 08 96(080)
Order number: 24 0 250
Take-up support for transmission
Scheme 317
24 1 050 Impact bush
Note: For fitting rotary shaft seal for torque converter in oil pump housing
Transmission: 3 HP 20, 3 HP 22
Storage location: C29
Order number: 24 1 050
Impact bush
Scheme 318
24 1 060 Impact bush
Note: For fitting rotary shaft seal for torque converter in oil pump housing and on output flange
Transmission: 3 HP 20, 3 HP 22, A5S 300J, BW 65
Storage location: B29, C29
Order number: 24 1 060
Impact bush
Scheme 319
24 1 070 Impact bush
Minimum set: Mechanical tools
Note: For fitting rotary shaft seal in oil pump housing
Transmission: A5S 325Z
Storage location: B36
SI number: 1 03 98(303)
Order number: 24 1 070
Impact bush
Scheme 320
24 1 080 Bush (aluminium)
Minimum set: Mechanical tools
In conjunction with: 00 5 010
Note: For fitting on input shaft while removing rotary shaft seal from oil pump housing
Transmission: A5S 325Z
Storage location: A36
SI number: 1 03 98(303)
Order number: 24 1 080
Bush (aluminium)
Scheme 321
24 1 090 Impact bush
Note: For installing rotary shaft seal on output flange
Transmission: A5S 390G
SI number: 1 08 98(333)
Order number: 24 1 090
Impact bush
Scheme 322
24 1 100 Impact bush
Note: For fitting rotary shaft seal for output flange in transmission extension
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 1 100
Impact bush
Scheme 323
24 1 110 Socket with magnet
Minimum set: Mechanical tools
Note: For loosening and tightening converter mounting
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 31 0R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP 19Z, GA6 HP26Z, GA6 HP32Z
Storage location: B19
SI number: 1 04 86 (566)
Order number: 24 1 110
Socket with magnet
Scheme 324
24 1 120 Gauge
Note: For adjusting position switch in "P" position during assembly / Model year: As from
Transmission: A4S 270R
SI number: 1 07 96(068)
Order number: 24 1 120
Gauge
Scheme 325
24 1 170 Pin wrench
Minimum set: Mechanical tools
Note: For releasing and tightening slotted nut on output flange
Transmission: A5S 310Z
Storage location: A35
SI number: 1 09 90(282)
Order number: 24 1 170
Pin wrench
Scheme 326
24 1 180 Fixture
In conjunction with: 24 1 080 (A5S 325Z)
Note: For removing and installing oil pump
Transmission: A5S 310Z, A5S 560Z
Storage location: B18
SI number: 1 09 90(282)
Order number: 24 1 180
Fixture
Consisting of
1 = 24 1 181 Retaining tube
2 = 24 1 182 Thread spindle
3 = 24 1 183 Retaining ring, inner
Note: (not shown)
Scheme 327
24 1 190 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For fitting rotary shaft seal in front section of transmission casing
Transmission: A5S 310Z
Storage location: B28
SI number: 1 09 90(282)
Order number: 24 1 190
Drift
Scheme 328
24 1 210 Retaining plate for disc package
Note: Not required as from transmission No. 11 2 300
Transmission: A5S 310Z
Storage location: B22
SI number: 1 09 90(282)
Order number: 24 1 210
Retaining plate for disc package
Scheme 329
24 1 220 Take-up support for drive flange
In conjunction with: 24 1 170 (A5S 310Z), 24 4 110 (A5S 440Z)
Note: When loosening slotted nut
Transmission: A5S 310Z, A5S 440Z
SI number: 1 09 90(282)
Order number: 24 1 220
Take-up support for drive flange
Scheme 330
24 1 230 Pressing tool
Note: For removing and installing piston (cover) on brake Ct
Transmission: A5S 310Z
Storage location: B20
SI number: 1 14 93(718)
Order number: 24 1 230
Pressing tool
Scheme 331
24 1 240 Measuring device
Note: For determining spacers on brake C
Transmission: A5S 310Z
Storage location: B20
SI number: 1 14 93(718)
Order number: 24 1 240
Measuring device
Scheme 332
24 1 250 Lifting gear
Note: For removing and installing brake clutch unit D/G incl. sprag wheel
Transmission: A5S 310Z
Storage location: B11, C11
SI number: 1 14 93(718)
Order number: 24 1 250
Lifting gear
Scheme 333
24 1 290 Wedges
Note: For fixing disc pack C in position while securing retainer tabs
Transmission: A5S 560Z
Storage location: C17
SI number: 1 01 95(892)
Order number: 24 1 290
Wedges
Scheme 334
24 1 300 Impact tool
Note: For securing retainer tabs on disc pack C
Transmission: A5S 560Z
Storage location: C17
SI number: 1 01 95(892)
Order number: 24 1 300
Impact tool
Scheme 335
24 1 310 Releasing tool
Note: For releasing retainer tabs on disc C
Transmission: A5S 560Z
Storage location: C2
SI number: 1 01 95(892)
Order number: 24 1 310
Releasing tool
Consisting of
1 = 24 1 311 Profile section (slide)
2 = 24 1 312 Basic body
Scheme 336
24 1 360 Locating fixture
Note: For securing converter during removal and installation of transmission.
Series: E90, E91
Transmission: GA6 HP26Z
SI number: 1 17 05(212)
Order number: 24 1 360
Locating fixture
Scheme 337
24 1 370 Locating fixture
Note: For securing converter during removal and installation of transmission.
Series: E70, E90, E91, E92
Transmission: GA6 HP19Z
SI number: 1 23 05 (224)
Order number: 24 1 370
Locating fixture
Scheme 338
24 2 020 Tool
Note: For compressing disc spring
Transmission: 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 020
Tool
Scheme 339
24 2 030 Tool
Note: For compressing disc spring
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 030
Tool
24 2 040 Tool
Note: For compressing disc spring
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 040
Tool
24 2 050 Extractor grip
Note: For sealing plugs in transmission case lower section / Replaced by 24 0 050
Order number: 24 2 050
Extractor grip
24 2 140 Tensioning tool
Note: For removing and installing snap ring in front of centring plate of ZF transmissions
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 2 140
Tensioning tool
Scheme 340
24 2 310 Tool kit for removing and installing reverse gear piston
Note: For disassembling and assembling transmission for "Sealing intermediate plate" job
Transmission: A4S 270R, A4S 310R
SI number: 1 22 97(239)
Order number: 24 2 310
Tool kit for removing and installing reverse gear piston
Consisting of
1 = 24 2 311 Pressure plate
Note: For removing and installing spring retainer
2 = 24 2 312 Spindle with pressure plate
Note: Spindle M14x1.5, nut M14, pressure plate and washer / For removing and installing spring retainer
3 = 24 2 313 Guide pin (2)
Note: For fixing gaskets and intermediate plates on intermediate housing
4 = 24 2 314 Slip bush
Note: For removing piston in cylinder intermediate plate
Scheme 341
24 2 320 Box spanner
In conjunction with: 24 2 330
Note: For 3/16" socket head cap screw with socket for adjusting brake band
Transmission: A4S 270R, A4S 310R
SI number: 1 24 97(257)
Order number: 24 2 320
Box spanner
Scheme 342
24 2 330 1/2" open-ended spanner
In conjunction with: 24 2 320
Note: For adjusting brake band
Transmission: A4S 270R, A4S 310R
SI number: 1 24 97(257)
Order number: 24 2 330
1/2" open-ended spanner
Scheme 343
24 2 350 Extractor
Minimum set: Mechanical tools
Note: For extracting radial seal on torque converter and on output flange
Series: E60, E61, E63, E64, E65, E66, E67, E70, E85, E86, E87, E90, E91, E92
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP 32Z
Storage location: A46
SI number: 1 14 01(766)
Order number: 24 2 350
Extractor
Consisting of
1 = 24 2 351 Extractor
2 = 24 2 352 Spindle M12 x 65 with ball head
3 = 24 2 353 Thrust piece
Scheme 344
24 2 370 Drift
Minimum set: Mechanical tools
Note: For fitting radial seal on output flange
Series: E60, E61, E63, E64, E65, E66, E67, E85, E86, E87, E90, E91, E92
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP32
Storage location: A46, B46
SI number: 1 14 01(766)
Order number: 24 2 370
Drift
Scheme 345
24 2 380 Socket bit WAF 34
Minimum set: Mechanical tools
In conjunction with: 23 0 020
Note: Double hexagon for releasing and tightening nut on output flange
Series: E60, E61, E63, E64, E65, E66, E67, E85, E86, E87, E90, E91, E92
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP32
Storage location: B44
SI number: 1 14 01(766)
Order number: 24 2 380
Socket bit WAF 34
Scheme 346
24 2 390 Covering cap
Minimum set: Mechanical tools
Note: For sealing off guide sleeve of transmission connector
Series: E60, E61, E65, E66, E70, E85, E86, E91, E92
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP3
Storage location: C49
SI number: 1 14 01(766)
Order number: 24 2 390
Covering cap
Scheme 347
24 2 400 Drift
Minimum set: Mechanical tools
Note: For driving in shaft seal on torque converter
Series: E61, E85, E86, E87, E90
Transmission: GA6 HP19Z
Storage location: B47
SI number: 1 08 03 (988)
Order number: 24 2 400
Drift
Scheme 348
24 3 040 Gauge
Note: For adjusting restrictor piston when installing gearshift unit
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 3 040
Gauge
Scheme 349
24 3 050 Gauge
Note: For aligning hydraulic gearshift unit in transmission
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Order number: 24 3 050
Gauge
Scheme 350
24 3 140 Drive bush
Note: For checking smooth movement of oil pump
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22 4 HP 24, A5S 560Z
Storage location: A20
Order number: 24 3 140
Drive bush
Scheme 351
24 3 150 Drive bush
Note: For checking smooth movement of pump
Transmission: 3 HP 20, 3 HP 22
Storage location: A20
Order number: 24 3 150
Drive bush
Scheme 352
24 4 070 Fixture
Note: For checking torque converter for leaks
Transmission: 3 HP 20, 3 HP 22, 4 HP 22
Order number: 24 4 070
Fixture
Scheme 353
24 4 080 Fixture
Note: For firmly holding torque converter in position while removing and installing transmission
Transmission: 4 HP 22, 4 HP 24
Storage location: Single
Order number: 24 4 080
Fixture
Scheme 354
24 4 090 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For fitting rotary shaft seal on output end
Transmission: A5S 440Z, A5S 560Z
Storage location: B28
SI number: 1 06 92(509)
Order number: 24 4 090
Drift
Scheme 355
24 4 100 Drift
Minimum set: Mechanical tools
Note: For fitting rotary shaft seal on drive side (behind converter)
Transmission: A5S 440Z, A5S 560Z
Storage location: C29
SI number: 1 06 92(509)
Order number: 24 4 100
Drift
Scheme 356
24 4 110 Spanner
Minimum set: Mechanical tools
Note: For releasing and tightening slotted nut output flange
Transmission: A5S 440Z, A5S 560Z
Storage location: A23
SI number: 1 06 92(509)
Order number: 24 4 110
Spanner
Scheme 357
24 4 120 Fixture
Note: For firmly holding torque converter in position while removing and installing transmission Replaced by 24 4 130.
Order number: 24 4 120
Fixture
Scheme 358
24 4 130 Locating tool
Minimum set: Mechanical tools
Note: For firmly holding torque converter position while removing and installing transmission
Transmission: A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP26Z
Storage location: A33
SI number: 1 05 97(181)
Order number: 24 4 130
Locating tool
Consisting of
1 = 24 4 131 Base unit
2 = 24 4 132 Blade
Note: Transmission: A5S 440Z, GA6HP26Z (N62)
3 = 24 4 133 Blade
Note: Transmission: A4S 310R and 390G
4 = 24 4 134 Blade
Note: Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z
5 = 24 4 135 Blade
Note: Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73)
6 = 24 4 136 Counter plate
7 = 24 4 137 Blade
Note: Transmission: A5S 360R
Scheme 359
24 4 160 Support bracket
Minimum set: Mechanical tools
Note: For securing converter during removal and installation of transmission
Series: E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E87, E90, E92, RR1
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location: A47, C46
SI number: 1 11 02(908)
Order number: 24 4 160
Support bracket
Consisting of
1 = 24 4 161 Basic body
2 = 24 4 162 Shaped section
Note: For converter variant N73
3 = 24 4 163 Shaped section
Note: For converter variant M57TU
4 = 24 4 164 Shaped section
Note: For converter variant M54
5 = 24 4 165 Shaped section
Note: Transmission: GA6 HP 19 in E90
Scheme 360
24 4 200 Drift and slip bush
Minimum set: Mechanical tools
Note: For driving in shaft seal on drive shaft.
Transmission: GACVT16Z
Order number: 24 4 200
Drift and slip bush
Consisting of
1 = 24 4 201 Drift
2 = 24 4 202 Slip bush
Scheme 361
24 4 210 Socket WAF 46
Note: For releasing and tightening down out shaft screw/bolt (bearing side).
Transmission: GACVT16Z
SI number: 1 09 05(188)
Order number: 24 4 210
Socket WAF 46
Scheme 362
24 4 220 Extractor
Note: For removing primary bearing on drive shaft.
Transmission: GACVT16Z
SI number: 1 09 05(188)
Order number: 24 4 220
Extractor
Consisting of
1 = 24 4 221 Basic body
2 = 24 4 222 Claws (2 x)
3 = 24 4 223 Thrust piece
4 = 24 4 224 Ring
Scheme 363
24 4 230 Drift
Note: For driving in primary bearing on drive shaft.
Transmission: GACVT16Z
SI number: 1 09 05(188)
Order number: 24 4 230
Drift
Scheme 364
24 4 280 Extractor
Minimum set: Mechanical tools
Note: For removing shaft seal on shift shaft.
Transmission: GA6F21WA
Storage location: A83
SI number: 1 03 05 (174)
Order number: 24 4 280
Extractor
24 4 290 Drift
Minimum set: Mechanical tools
Note: For removing shaft seal on shift shaft.
Transmission: GA6F21WA
Storage location: C83
SI number: 1 03 05 (174)
Order number: 24 4 290
Drift
24 4 310 Drift
Minimum set: Mechanical tools
Note: For driving in shaft seal on output shaft.
Series: E60, E70, E90, E91
Transmission: GA6 HP19Z, GA6 HP26Z
SI number: 1 04 05 175
Order number: 24 4 310
Drift
Scheme 365
24 5 120 Tool
Note: For centering converter bell housing respect to oil pump during assembly
Transmission: A4S 270R, A4S 310R
Storage location: B2
SI number: 1 04 95(906)
Order number: 24 5 120
Tool
Consisting of
1 = 24 5 121 Centering bush
2 = 24 5 122 Centering pin (3)
Scheme 366
24 5 140 Centering pin
Note: For transfer plate and gasket to shift unit (2 x)
Transmission: A4S 310R
Order number: 24 5 140
Centering pin
24 5 150 Centring pin with thread (2)
Note: For centring gearshift unit in transmission during assembly
Transmission: A4S 270R, A4S 310R
Storage location: A2
SI number: 1 03 90(184)
Order number: 24 5 150
Centring pin with thread (2)
Scheme 367
24 5 160 Centering pins
Note: For centring main housing with respect to intermediate and converter housing (2)
Transmission: A4S 270R, A4S 310R
Storage location: A2, B2
SI number: 1 03 93(663)
Order number: 24 5 160
Centering pins
Scheme 368
24 5 190 Adapter
In conjunction with: 13 3 061, 13 3 067,24 0 021,24 0 02 24 0 140
Note: For pressure gauge 13 3 061 for check oil pressure in transmission
Transmission: A4S 270R, A4S 310R
Storage location: C20
SI number: 1 03 90(184)
Order number: 24 5 190
Adapter
Scheme 369
24 5 200 Impact bush
Note: For driving in radial seal of selector ever shaft / Replaced by 24 5 360
Transmission: A4S 270R, A4S 310R
SI number: 1 03 90(184)
Order number: 24 5 200
Impact bush
Scheme 370
24 5 210 Holder
Note: For loosening and tightening gearshift cable
Transmission: 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 310Z
Storage location: B19
SI number: 1 04 91(372)
Order number: 24 5 210
Holder
Scheme 371
24 5 220 Holder
Note: For loosening and tightening gearshift cable
Transmission: A5S 300J, A5S 310Z
Storage location: B19
SI number: 1 04 91(372)
Order number: 24 5 220
Holder
Scheme 372
24 5 240 Holder
Note: For releasing and tightening gearshift transmission with position switch
Transmission: A5S 310Z, A5S 560Z
Storage location: B19
SI number: 1 06 92(509)
Order number: 24 5 240
Holder
Scheme 373
24 5 250 Bush
Minimum set: Mechanical tools
In conjunction with: 24 5 490
Note: For fitting rotary shaft seal on selector shaft
Transmission: A5S 310Z, A5S 560Z
Storage location: B19
SI number: 1 02 95(896)
Order number: 24 5 250
Bush
Scheme 374
24 5 260 Extractor tool
Minimum set: Mechanical tools
Note: For removing rotary shaft seal of selector shaft / transmission with position switch
Transmission: A5S 310Z, A5S 440Z, A5S 560Z
Storage location: B19
SI number: 1 02 95 (896)
Order number: 24 5 260
Extractor tool
Consisting of
1 = 24 5 261 Insert
2 = 24 5 262 Bushing
Scheme 375
24 5 270 Bush
Minimum set: Mechanical tools
In conjunction with: 24 5 490
Note: For fitting rotary shaft seal on selector shaft
Transmission: A5S 440Z
Storage location: B18
SI number: 1 08 96(080)
Order number: 24 5 270
Bush
Scheme 376
24 5 300 Supports
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For supporting transmission during removal and installation
Series: E60, E61, E65, E66, E87, E90, E91
Transmission: A4S 200R, A4S 270R, A4S 310R, A5S 310Z, A5S 325Z, A5S 360R, A5S 390R, A5S 440Z, GA6 HP19Z, GA6 HP26Z
SI number: 1 03 90(184)
Order number: 24 5 300
Supports
Consisting of
1 = 24 5 301 Base plate
2 = 24 5 302 Support (2 x)
Note: Transmission: A4S 310R
3 = 24 5 303 Mounting pin (4 x)
Note: Transmission: A4S 310Z
24 5 304 Support (2 x)
Note: Transmission: A5S 325Z
24 5 305 Support (2 x)
Note: Transmission: A5S 390G
24 5 306 Mounting
Note: Transmission: GA6HP19Z (6HP19), GA6HP26Z/32Z (6HP26/32)
24 5 307 Take-up support
Note: Transmission: GA6HP19Z (6HP19), GA6HP26Z (6HP26)
In conjunction with: 00 2 030, 24 5 301/306
Scheme 377
24 5 350 Take-up support for automatic transmission
Note: Miscellaneous: Japan and South Africa only
Transmission: A5S 300J
Order number: 24 5 350
Take-up support for automatic transmission
Scheme 378
24 5 360 Fixture
Minimum set: Mechanical tools
Note: For removing and installing selector shaft seal 24 5 361, 24 5 362, 24 5 364 and 24 5 366 for E90
Series: E70, E85, E86, E90, E91
Transmission: A4S 200R, A4S 270R, A4S 310R, A5S 360R, A5S 390R, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location: A22, A46
SI number: 1 14 96(105)
Order number: 24 5 360
Fixture
Consisting of
1 = 24 5 361 Threaded bush
2 = 24 5 362 Union nut
3 = 24 5 363 Bush
Note: For transmission without position switch Transmission: A4S 310R
4 = 24 5 364 Nut
5 = 24 5 365 Slip sleeve (5 x)
Note: Transmission: A4S 310R
6 = 24 5 366 Bush
Note: For driving in radial shaft seal on selector shaft (emergency release Transmission: GA6 HP26Z
Scheme 379
24 5 400 Drift
In conjunction with: 00 5 500
Note: For drive shaft seal.
Transmission: GACVT16Z
Order number: 24 5 400
Drift
Scheme 380
24 5 490 Slip sleeve (5)
Minimum set: Mechanical tools
Note: For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission: A5S 310Z, A5S 440Z, A5S 560Z
SI number: 1 02 95 (896)
Order number: 24 5 490
Slip sleeve (5)
Scheme 381
24 8 100 Adapter
Minimum set: Mechanical tools
Note: For filling automatic transmission
Transmission: GACVT16Z
SI number: 1 05 01(718)
Order number: 24 8 100
Adapter
Scheme 382
24 8 110 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For driving shaft seal onto drive flange
Transmission: GACVT16Z
SI number: 1 02 02 (823)
Order number: 24 8 110
Drift
Scheme 383
24 8 120 Rubber profile
Minimum set: Mechanical tools
Note: For protecting shaft seal in transmission when installing output shafts.
Transmission: GACVT16Z, GS5-65BH, GS6-85BG, 85DG
SI number: 1 02 02 (823)
Order number: 24 8 120
Rubber profile
Scheme 384
24 8 130 Drift
In conjunction with: 00 5 550
Note: For driving in shaft seal on input shaft. Transmission: CVT automatic transmission Replaced by 24 4 200
Transmission: GACVT16Z
SI number: 1 02 02 (823)
Order number: 24 8 130
Drift
