24 31 011 Replacing torque converter flange shaft seal (GA6HP19Z)
Special tools required
- 00 1 450
- 24 0 200
- 24 2 351
- 24 2 352
- 24 2 353
- 24 2 400
Necessary preliminary tasks
- Remove «Automatic Transmission»(ref-258109-S14264880062007071700000).
| IMPORTANT | After completion of work, check Transmission Oil Level. Use only approved Transmission Oil. Failure to comply with this instruction will result in serious damage to the transmission. |
Secure transmission with special tool 24 0 200 to assembly stand 00 1 450.
Remove Torque Converter.
Note. Read and comply with note on Installation Of Transmission Retaining Bridge.
Scheme 212
Attach special tool 24 2 353 to drive shaft (1).
Scheme 213
Screw in special tool 24 2 351 until it is firmly connected with shaft seal.
Screw in special tool 24 2 352 to remove shaft seal.
Scheme 214
Oil sealing lip on shaft seal.
Drive in shaft seal (1) with special tool 24 2 400 as far as it will go.
Scheme 215
24 40 011 Removing and installing/replacing torque converter (GA6HP19Z)
Special tools required
- 00 2 550
- 24 4 000
| IMPORTANT | After completion of work, check Transmission Fluid Level. Use only approved Transmission Fluid. Failure to comply with this instruction will result in serious damage to the transmission. |
Necessary preliminary tasks
- Remove «Automatic Transmission»(ref-258109-S14264880062007071700000)
Screw special tool 24 4 000 into torque converter.
Remove torque converter.
Note. When torque converter is removed, transmission oil flows out.
Scheme 216
Installation
When installing, do not damage shaft seal and bearing.
If the torque converter is not correctly installed, the driver of the pump impeller may be damaged when the transmission is flanged to the engine.
Remove torque converter and set down vertically.
Scheme 217
Installation
Push torque converter through shaft seal onto transmission shaft as far as it will go.
Press torque converter by hand into converter housing and turn in the process. Converter hub opening must snap into place in driver of pump impeller. Torque converter must be felt to slip inwards.
Determine distance between contact surface and surface (1) of tapped hole in torque converter with special tool 00 2 550.
Note. Measured value must be greater than 25 mm.
