Special tools required
- 11 0 070 . See «ENGINE - SPECIAL TOOLS (M44)»(ref-303939) . Disconnect negative battery lead. Remove the ignition coil from the spring strut dome.
- 11 2 150
- 11 2 410 . See «ENGINE - SPECIAL TOOLS (M44)»(ref-303939) .
If necessary, remove drive belt and belt pulley for the air-conditioning compressor.
Remove alternator drive belt.
Attach special tool 11 2 150 in conjunction with special tool 11 2 410.
When releasing and tightening down central bolt, grip special tool 11 2 150 with assistance of a second person.
If it is not possible to grip the tool securely: Remove mounted parts until the special tool 11 2 150 can be supported on the engine carrier without damaging other components.
| CAUTION | Protect engine bracket from damage. |
Insert wood between engine carrier and special tool 11 2 150.
Scheme 152
Unscrew central bolt.
Replace radial seal in lower timing case cover.
Installation
Align vibration damper with groove to featherkey.
Replace central bolt.
Tightening torque see 11 23 5AZ in ENGINE - TORQUE SPECIFICATIONS (M44) .
