DIODE ASSEMBLY
- Place ohmmeter on X100 scale. Connect ohmmeter leads, in turn, between B+ terminal and each of the 3 stator terminals. (Scheme 1) Reverse leads. Ohmmeter should indicate continuity in one direc tion only.
- Connect ohmmeter leads, in turn, between negative plate and each of the 3 stator terminals. Reverse leads. Ohmmeter should indicate continuity in one direction only.
- Connect ohmmeter leads, in turn, between D+ terminal and each of the 3 stator terminals. Reverse leads. Ohmmeter should indicate continuity in one direction only. Replace diode assembly if continuity is not as specified.
Scheme 1
OVERHAUL
For overhaul procedures, see appropriate illustration for exploded view of generator. (Scheme 2)or (Scheme 3).
