Removing sensor
- If the vehicle has automatic headlight vertical range control, mark the installation position of clamp - 7 - on transverse link - 6 - and transfer the marking to the new transverse link.
Note installation position of coupling rod - 4 - in relation to sensor arm.
- Loosen nuts - 5 -.
4 - Coupling rod
5 - Self-locking nut, 4 Nm
Always replace if removed
Hex nut N011 183 12
6 - Lower transverse link
7 - Clamp
Note. When attaching linkage - item1 - to level sensor, use a 9 mm open-ended wrench with dimension - A - to avoid damaging the seal.
The linkage is only attached to the sensor after the new transverse link has been installed.
Scheme 1085
- Dimension A: 4 mm
Tightening torque: 3.5 Nm
