Ball joint, checking Audi TT 8N facelift

Suspension, Wheels, Steering 2 illustrations

Ball joint, checking

Checking axial play

Scheme 927

Scheme 927: Ball joint, checking

Scheme 927: Ball joint, checking

Pull control arm firmly downwards and press back up again.

Checking radial clearance

Scheme 928

Scheme 928

Scheme 928

Press wheel firmly inward and outward.

Note. There should not be any noticeable or visible "play" in either of the two checks. Observe lower ball joint while performing checks. Make allowance for any wheel bearing play or "play" in strut mounting at top. Check rubber boot for damage, replace lower ball joint if necessary.
