General notes
- Switch off the ignition before connecting or disconnecting the battery, otherwise the engine control module may be damaged.
- A voltage of at least 12.7 V is necessary for satisfactory functioning of the electrical components.
- During some of the tests, a malfunction may be recognized and stored by the control module. At the end of all tests and repairs, the fault memory should be checked and, erased.
- If the engine starts and then stops after malfunction search, repair or tests on components, because the immobilizer is blocking the engine control module. The fault memory must then be checked and, if necessary, the control module adapted.
Safety precautions
To prevent injuries to persons and/or damage to the fuel injection and ignition system, observe the following
- Do not touch or disconnect ignition wiring when the engine is running or at starting speed.
- The ignition must be switched off before connecting or disconnecting ignition system wiring. This also applies to high-voltage cables and measuring instrument leads.
- During some of the tests, a malfunction may be recognized and stored by the control module. At the end of all tests and repairs, the fault memory should be checked and, erased.
- Always switch off the ignition before washing the engine.
Technical data
| Engine code | BHE (3.2L/4V/184 kW engine) |
|---|---|
| Idling speed Not adjustable - controlled by idling speed stabilization | 650 to 750 rpm |
| Engine speed limitation by deactivation of injectors | Approx. 6500 rpm |
| Ignition timing determined by control module. Ignition timing cannot be adjusted. | |
| Ignition system | Individual coil system with 6 ignition coils (output stages integrated) connected directly to spark plugs via spark plug connectors |
| Spark plugs | Tightening torque 30 Nm |
| Firing order | 1-5-3-6-2-4 |
TECHNICAL DATA
Ignition system components, removing and installing
Note. The following list refers to items in (Scheme 1).
- Ignition coils with output stages Cylinder 1 ignition coil 1 with output stage -N70- Cylinder 2 ignition coil 2 with output stage -N127- Cylinder 3 ignition coil 3 with output stage -N291- Cylinder 4 ignition coil 4 with output stage -N292- Cylinder 5 ignition coil 5 with output stage -N323- Cylinder 6 ignition coil 6 with output stage -N324
- 4-pin connector For ignition coils with output stage
- Bracket For connector for Knock Sensor 1 -G61
- Bolt, 10 Nm
- 3-pin connector Black With gold-plated contacts
- Knock Sensor (KS) 1 -G61
- Bolt, 20 Nm To ensure correct operation of knock sensor, it is important to adhere to specified tightening torque
- Camshaft adjuster Exhaust side With sender wheel for Camshaft Position sensor 2 -G163- After reinstalling, adjust valve timing See «TIMING CHAIN, COMPONENT OVERVIEW»(ref-200989-S12436479192005102400000) .
- Cover (upper) for camshaft timing chain Removing and installing See «UPPER COVER FOR CAMSHAFT TIMING CHAIN, COMPONENT OVERVIEW»(ref-200989-S18245988532005102400000) .
- Seal Replace
- Camshaft Position (CMP) sensor -G163- For exhaust camshaft
- Bolt, 10 Nm
- 3-pin connector Black With gold-plated contacts Mark before removing
- Camshaft Position (CMP) sensor -G40- For intake camshaft
- Knock Sensor (KS) 2 -G66
- 2-pin connector Black With gold-plated contacts
- Camshaft adjuster Intake side With sender wheel for Camshaft Position sensor - G40- After reinstalling, adjust valve timing See «ENGINE MECHANICAL - 3.2L V6 4V - BHE»(ref-200989) .
- Spark plug Removing and installing, see «SPARK PLUGS, REMOVING AND INSTALLING»(/audi/tt/8n-2003-2006/remont/ignition-system/#ignitionglow-plug-system-32l-v6-4v-bhe) Tighten to 30 Nm
- Valve timing housing For variable valve timing Removing and installing See «ENGINE MECHANICAL - 3.2L V6 4V - BHE»(ref-200989) .
Scheme 1
Scheme 2
- Puller T10095 A
- Assembly tool T10118
Scheme 3
Removing
- Disconnect electrical connectors at ignition coils by releasing tab (arrow) with assembly tool T10118 and pulling connector.
- Attach puller T10095 A to ignition coils as shown in illustration (arrow) and remove ignition coils one at a time.
Scheme 4
Installing
Install in reverse order of removal. Note the following
- Insert ignition coils into holes so that flat edges align with one another (arrows).
Scheme 5
Special tools and equipment required
- Spark plug socket 3122 B
Scheme 6
- Remove ignition coils. See «IGNITION COILS, REMOVING AND INSTALLING»(/audi/tt/8n-2003-2006/remont/ignition-system/#ignitionglow-plug-system-32l-v6-4v-bhe) .
- Remove spark plugs with spark plug socket 3122 B.
Installation is performed in the reverse order of removal.
Note the following
- Install ignition coils. See «IGNITION COILS, REMOVING AND INSTALLING»(/audi/tt/8n-2003-2006/remont/ignition-system/#ignitionglow-plug-system-32l-v6-4v-bhe) .
Tightening torque
| Component | Nm |
|---|---|
| Spark plug in cylinder head | 30 |
TIGHTENING TORQUE: SPARK PLUGS
