Switch console, removing Audi TT 8N рестайлинг

Switch console, removing

Note. Shown from underneath for greater clarity. Instrument panel removed

Scheme 303

1. Remove screws - arrows - (2x).
2. Remove switch console - 1 - with switches.

Scheme 304

1. Use screwdriver to pry out defroster vent - 1 -.
2. When installing, make sure slats are facing side window.
3. Tabs - 2 - (3x) must fully engage.

Scheme 305

1 - Detaching steering column Detaching steering column at top

2 - Removing wiring harness to steering column switch Unfastening wiring harness at steering column

3 - Disconnecting Ground (GND) at steering column Disconnecting Ground (GND) at steering column

4 - Removing relay carrier Removing relay carrier

5 - Unfastening central tube on drivers side Detaching central tube from bodywork (drivers side)

6 - Removing screw in plenum chamber Removing bolt in plenum chamber

7 - Removing brace at steering column Removing brace at steering column

8 - Removing center Ground (GND) point Disconnecting central Ground (GND) point

9 - Removing defroster duct Removing defroster duct

10 - Detaching wiring harness on passengers side Detaching wiring harness on passengers side from central tube

11 - Detaching central tube on passenger side Detaching central tube from bodywork (passenger-side)

12 - Detaching wiring harness for passengers airbag Unplugging connector for passengers airbag
