SIDE TRIM Audi TT 8J facelift

SIDE TRIM

Special tools and workshop equipment required

1. Engine and transmission holder VAS 6095
2. Fixture for seat repair VAS 6136

Scheme 196

1. Bolt Tightening specification 1.2 Nm
2. Side trim (sill side) Removing -- Remove the seat. Refer to «SEAT»(ref-505614-S25023167422012100100000) . -- Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095. -- Attach the front seat to the fixture for seat repair VAS 6136. -- Remove backrest adjustment hand wheel -5-. -- Remove seat height adjustment handle -7-. Refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(ref-505614-S26865758742012100100000) . -- Remove expanding clip -6-, press clamping pin through to the inside. -- Remove mounting bolt -1-. -- Remove side panel -2- at lower edge from retaining bracket on seat. -- Swing side panel upward at front edge. -- Remove side panel to side. -- Pull tab at rear of side panel out under backrest trim. Installation Install in reverse order of removal.
3. Side trim (tunnel side) Removing -- Remove the seat. Refer to «SEAT»(ref-505614-S25023167422012100100000) . -- Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095. -- Attach the front seat to the fixture for seat repair VAS 6136. -- Remove expanding clip -4-, press clamping pin through to the inside. -- Disengage retaining detent at rear side of side panel on tunnel side. -- Remove the trim. Installation Install in reverse order of removal.
4. Expanding clip
5. Hand wheel for backrest adjustment Removing and Installing, refer to «BACKREST ADJUSTMENT HAND WHEEL»(ref-505614-S41136483072012100100000)
6. Expanding clip
7. Seat height adjustment handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(ref-505614-S26865758742012100100000)
