BACKREST LOCK ACTUATING LINK
Special tools and workshop equipment required
Scheme 205
- Torque wrench V.A.G 1410
- Pop rivet pliers VAS 5072
- Drill
- 6.0 mm drill bit
- Engine and transmission holder VAS 6095
- Fixture for seat repair VAS 6136
Removing
Remove the seat. Refer to SEAT .
Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.
Attach the front seat to the fixture for seat repair VAS 6136.
Remove backrest and front seat pan. Refer to FRONT BACKREST AND SEAT PAN .
Remove backrest cover. Refer to BACKREST COVER AND UPHOLSTERY .
Remove the bolts -arrows- from the seat belt guide inner part.
Scheme 206
Remove belt guide inner part -1-.
Scheme 207
Remove cover -1-.
Remove the operating cable mounting bracket -3- on the seat belt guide inner part.
Scheme 208
Remove backrest lock release lever -2-.
Disengage actuating link -1- in direction of -arrow-.
Repeat work steps on opposite side.
Remove backrest cover and backrest frame. Refer to BACKREST COVER .
Scheme 209
Remove screws -3 and 4-.
Drill out the blind rivet -2- on the backrest frame mount -1- with a 6.0 mm drill bit.
Move the backrest frame mount to the side and remove the cable mounting bracket -2- on the backrest frame -3-.
Scheme 210
Disengage actuating link eye -1- at backrest lock release lever -4- by sliding eye forward -arrow- and removing.
Remove actuating link upward from backrest frame.
