Communication (coupe) Audi TT 8J

RADIO SYSTEM

Radio Systems

1. concert
2. symphony

Sound Systems

1. Standard
2. BOSE

General Information

The radio systems are prepared for satellite radio use or Satellite Radio is installed.

The radio have two tuners with phase diversity and each one has an antenna connection (AM/FM1 and FM2).

Besides switching diversity, phase diversity is the second procedure for reducing reception interference.

At least two antennas with amplifier and a radio with two tuners is required.

If the signal received is interrupted, both signals are digitalized and separated in the tuners in the radio so that the disrupted signals are blocked out as much as possible.

If the reception signal is not disrupted, the radio constantly compares which antenna (amplifier) has the strongest reception. This is then transferred.

In this case, the second tuner checks the frequency band in the background for better reception frequencies for the selected station. If a better signal is found, this tuner switches to reception and the other to the background.

Satellite radio for SDARS is installed in luggage compartment.

Communication with other vehicle systems takes place via the Infotainment CAN-Bus and data bus on board diagnostic interface.

Symphony transport mode, activating/deactivating, refer to SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING .

Troubleshooting and diagnosis takes place with Guided Fault Finding using vehicle diagnosis, testing and information system VAS 5051.

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

SOUND SYSTEM

There are three equipment versions.

Sound Systems

1. Base
2. Standard
3. BOSE

The individual speakers are installed in the doors, instrument panel and rear side trim.

ANTENNA SYSTEM

The antenna system includes the antennas inside the rear lid and the roof antenna.

System with phase diversity (radio)

1. Antenna amplifier (AM/FM1/Central Locking System) on the top of the rear lid on the right side
2. Antenna amplifier 4 (digital audio broadcasting) at the top of the rear lid on the left side
3. Antenna amplifier 2 (FM2) at the bottom of the rear lid on the right side
4. Radio, telephone, navigation system antenna (GPS/GSM/Satellite) roof antenna

System with switch diversity (radio/navigation system)

1. Antenna amplifier (AM/FM1/Central Locking System) on the top of the rear lid on the right side
2. Antenna amplifier 4 (digital audio broadcasting/TV3) at the top of the rear lid on the left side
3. Antenna amplifier 2 (FM2/high frequency/intermediate frequency/TV1/TV2) at the bottom of the rear lid on the right side
4. Radio, telephone, navigation system antenna (GPS/GSM/Satellite) roof antenna

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

TELEPHONE SYSTEMS

Mobile phone prep

1. Telephone transceiver
2. Radio, telephone, navigation system antenna/telephone antenna (through MY 2008)
3. Telephone baseplate (through MY 2008)
4. Microphone unit in front roof module

The telephone transceiver is equipped with a Bluetooth Antenna. Using this, all cellular telephones approved by Audi can be operated with the Bluetooth interface with the cellular telephone preparation installed in the vehicle.

It is not possible to connect other devices via Bluetooth, for example headset, laptop, PDA, or similar.

Fault finding is performed via Guided Fault Finding

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

RNS-E NAVIGATION SYSTEM

Description

The RNS-E navigation system is an enhancement of the navigation system II-D. The unit has MMI operation. A DVD is used as the navigation CD.

Screen folds away. DVD drive and two MP3 card readers are located behind.

Beside the navigation system, the RNS-E include a radio, two MP3 card readers and a connection for a CD changer/connection for an external audio source and the satellite radio. The DVD drive can play music CDs.

Error messages on screen ERROR MESSAGES ON SCREEN

Fault finding is performed via Guided Fault Finding, .

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

NAVIGATION SYSTEM RNS-JP4

The JP4 navigation system includes the after market radio/navigation system.

All connections necessary for the navigation unit are present in the vehicle. Sound system and antennas are installed.

Only the navigation unit (RNS) is installed in service.

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

NAVIGATION SYSTEM RNS JP5

The JP5 navigation system includes the after market radio/navigation system.

All connections necessary for the navigation unit are present in the vehicle. The Sound system and the antenna are installed as well as the connections for the microphone unit (in front roof module) and TV card reader.

Only the navigation unit (RNS) is installed in service.

Repairing antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

RNS LOW NAVIGATION SYSTEM

Description

RNS low is the Low variant of the RNS-E.

The unit has MMI operation. A CD is used as the navigation CD.

In addition to the navigation system, RNS Low includes a radio/CD player and connection for a CD changer/external audio source connection and a cellular telephone. The CD drive can play music CDs.

Fault finding is performed via Guided Fault Finding. .

Repairs on antenna wires, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

CD CHANGER

The CD changer is installed in the glove compartment as optional equipment.

It is connected via satellite radio.

Fault finding is performed using radio Guided Fault Finding in . The wiring connection is checked. Malfunction messages result.

IPOD BASEPLATE

The iPod baseplate is installed in the glove compartment instead of the CD changer.

The iPod baseplate connected directly to the radio just like the CD changer.

It is connected via satellite radio.

Fault finding is performed using radio Guided Fault Finding in . The wiring connection is checked. Malfunction messages result.

EXTERNAL AUDIO SOURCE CONNECTION

There are several versions of external audio source connections.

1. AMI (Audi Music Interface) installed inside the glove compartment
2. The AUX IN socket is installed in the center console storage compartment.

Either an AMI or AUX IN socket is installed.

Different external audio sources can be connected to the external audio source connection

1. iPod
2. MP3-Player
3. USB Stick

Suitable adapter cables are needed. Refer to Owner's Manual.

Fault finding is performed via Guided Fault Finding. .

MULTIFUNCTION STEERING WHEEL

Description

Buttons are integrated in the steering wheel for easier operation of the radio, cellular telephone, navigation and CD changer.

With Tiptronic (automatic transmission), additional switches are installed.

The electronics integrated in the multi-function buttons take over signal processing from the Tiptronic buttons/switches and transfer signals via the LIN data bus (single wire bus) to the steering column electronic systems control module. The conversion to CAN BUS (comfort) takes place there.

The individual button blocks and the Tiptronic switch can be replaced separately.

Fault finding is performed via Guided Fault Finding. .

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE

Description

The steering column electronic systems control module is a part of the steering column switch module. The steering column switch module consists of

1. Left and right steering column switch
2. Airbag spiral spring
3. Steering angle sensor
4. Ignition/starter switch
5. Steering column electronic systems control module

The steering column electronic systems control module exchanges data between vehicle control modules (e.g. vehicle electrical system control module) and steering column modules (e.g. steering column switch) and steering wheel modules (e.g. airbag).

In addition, multi-function steering wheel button signals are process and relayed via CAN BUS.

Fault finding is performed via Guided Fault Finding. .

Steering column switch module, removing and installing, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Description and Operation .

Repair to CAN bus lines, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information .

Scheme 1

1. CD Changer -R41
2. Radio Removal Tool T10057
3. iPod Baseplate -R192
4. Front Interior Light -W1- with Microphone Unit (in front roof module) -R164
5. Satellite Radio -R146
6. External Audio Source Connection -R199
7. Screw 1 Nm
8. Radio -R
9. Radio Removal Tool T10057

Scheme 2

1. Radio, Telephone, Navigation System Antenna -R52- (Sat/GPS/GSM) Roof Antenna
2. Rear window antennas
3. Antenna Amplifier 2 -R111- On Lower Right Area of Rear Lid
4. Radio -R- In Upper Center Console
5. Sound Systems
6. External Audio Source Connection -R199- In The Center Console Storage Compartment
7. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
8. Satellite Radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
9. Antenna Splitter -R87- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering (through 10.2006)
10. CAN-BUS (Infotainment)
11. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid

Scheme 3

1. Satellite Antenna -R170- (Sat) On Rear Lid
2. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
3. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
4. Antenna Amplifier -R24- Left Rear Mast Antenna Base
5. Radio -R- In Upper Center Console
6. Sound Systems
7. External Audio Source Connection -R199- In The Center Console Storage Compartment
8. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
9. Satellite radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
10. CAN-BUS (Infotainment)
11. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid

Scheme 4

1. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
2. Front Passenger's Airbag Disabled Indicator Lamp -K145
3. AM/FM1 Connection (White) From Antenna Amplifier -R24
4. FM2 (white) Connection From Antenna Amplifier 2 -R111

Note. Unlisted connector terminals are not assigned.

Scheme 5

2 - Right front speaker (+) (only on base sound system)

3 - Left front speaker (+) (only on base sound system)

6 - Right front speaker (-) (only on base sound system)

7 - Left front speaker (-) (only on base sound system)

1 - Left LF-In from the external audio source connection

2 - Signal ground to CD changer/satellite radio

3 - LF-In ground from the external audio source connection

4 - Permanent positive to CD changer

5 - BOSE coding to ground (only with BOSE)

6 - Data out to the CD changer

7 - Right LF-In from the external audio source connection

8 - Left signal from CD changer/satellite radio

9 -Right signal from CD changer/satellite radio

10 - Positive switched to CD changer

11 - Data in from the CD changer

12 - CLK from the CD changer

1 - Speed signal (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver

7 - K diagnostic (not used)

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

10 - Audio Pilot in/out (not used)

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - LF mute

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive connected with PIN 15 (anti-theft warning system)

Scheme 6

A - Black 8-pin connector (T8n)

B - Black 8-pin connector (T8m)

C - Ter connection (brown) from antenna splitter

D - Sat connection (green) from antenna splitter

Note. Unlisted connector terminals are not assigned.

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD changer/iPod baseplate

4 - Right signal from CD changer/iPod baseplate

5 - Signal ground to radio/navigation system with CD drive control module

6 - Left signal to radio/navigation system with CD drive control module

7 - Right signal to radio/navigation system with CD drive control module

8 - Signal ground from CD changer/iPod baseplate

1 - Terminal 31

2 - Terminal 30

Scheme 7

A - Black 8-pin connector (T8n)

B - Black 8-pin connector (T8m)

C - Sat connection (green) from radio, telephone, navigation system antenna Coupe

Sat connection (green) on the satellite antenna Roadster

Note. Unlisted connector terminals are not assigned.

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD changer/iPod baseplate

4 - Right signal from CD changer/iPod baseplate

5 - Signal ground to radio/navigation system with CD drive control module

6 - Left signal to radio/navigation system with CD drive control module

7 - Right signal to radio/navigation system with CD drive control module

8 - Signal ground from CD changer/iPod baseplate

1 - Terminal 31

2 - Terminal 30

Scheme 8

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
3. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
4. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Radio, Telephone, Navigation System Antenna -R52- Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connections through 10/06, refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Connections from 11/06, refer to «SATELLITE RADIO CONNECTORS, FROM 11/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Removing and installing, activating, refer to «SATELLITE RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__satellite-radio)
8. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
9. Antenna Splitter -R87- Through 10/06 Inside the luggage compartment on the left side under the luggage compartment floor covering Removing and installing, refer to «ANTENNA SPLITTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-splitter)
10. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
11. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-loudspeaker-coupe) - Center speaker -R148- Behind the left rear side trim panel Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
12. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
13. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
14. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
15. Radio -R- In the top of the center console Connectors. Refer to, refer to «RADIO, HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__radio) Symphony transport mode, activating/deactivating, refer to «SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__symphony-transport-mode-activatingdeactivating)
16. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source) refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

Scheme 9

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. Center Mid/High Range Loudspeaker -R158- In the center of the instrument panel Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
3. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
4. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
5. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In left and right rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-speaker-roadster)
6. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Satellite Antenna -R170- On rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connections through 10/06, refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Connections from 11/06, refer to «SATELLITE RADIO CONNECTORS, FROM 11/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Removing and installing, activating, refer to «SATELLITE RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__satellite-radio)
9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
10. Antenna Amplifier -R24- left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
11. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
12. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
13. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
15. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
16. Radio -R- In the top of the center console Connectors, refer to «RADIO, HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__radio) symphony transport mode, activating/deactivating, refer to «SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__symphony-transport-mode-activatingdeactivating)
17. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source) refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

Scheme 10

1 - Speaker connector (T8d) brown

2 - Voltage supply connector (T8c) black

3 - Antenna connection (AM/FM1) for the radio

4 - Antenna amplifier on upper right side of rear lid (Coupe)

Antenna amplifier left rear mast antenna base (Roadster)

5 - Rear window antenna 1 AM/FM1 (Coupe)

Antenna (AM/FM1) mast antenna (Roadster)

6 - left front speaker

7 - right front speaker

SATELLITE RADIO, ENABLING

When using for first time or when replacing satellite radio tuner, it must be enabled (activated) by the provider (XM or Sirius).

The subscription and application for activation can coincide with submission of all necessary data (US postal address, credit card number, radio ID (XM) or SID (Sirius)) to the provider's call center.

Only SIRIUS

SIRIUS sends the activation sequence 6 times within the first hour after apply for the activation. If no successful activation results, another activation sequence must be requested at the SIRIUS call center.

Requirements

1. Customer has subscribed to XM or Sirius
2. Satellite radio is installed and connected
3. radio/navigation system with CD drive control module is adapted/coded accordingly
4. Ignition switched on

Procedure

Switch on radio/navigation system with CD drive control module and select satellite radio reception range.

Attempt to receive free channels in XM (e.g. channel 1) or Sirius band (only channel 184).

Change location.

If free channels can be received clearly, the activation information sent by the provider (XM or Sirius) can also be received clearly.

A poor reception situation can prevent a successful activation even though activation information is being broadcast. In this case, vehicle location must be changed (an activation is also possible while vehicle is moving). There are e.g. workshops, garages, parking buildings, underground garages, fuel filling stations with extensive roofs and all other parking areas with signal shadows must be avoided.

SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING

Transport mode must be activated before sending every symphony radio.

After activation, the internal CD changer drive is in transport position.

After replacing a symphony, transport mode must be deactivated after installation.

Transport mode, activating

symphony is connected and installed.

Press station buttons 3 and 5 and TONE button at the same time.

After about 5 seconds, TRANSPORT appears on the radio display.

Transport mode, deactivating

symphony is connected and installed.

Press CANCEL button.

TRANSPORT display goes out.

Transport mode is deactivated.

Scheme 11

1. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23
2. Screw 3.5 Nm
3. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104
4. Screw 2 Nm
5. Screw 2 Nm
6. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160
7. Clamp
8. Digital Sound System Control Module -J525
9. Screw 3 Nm
10. Nut 5 Nm
11. Digital Sound System Control Module -J525- BOSE
12. Nut 5 Nm
13. Screw 3 Nm
14. Nut 2 Nm
15. Screw 2 Nm
16. Center Speaker -R148
17. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22
18. Instrument panel
19. Screw 1 Nm
20. Instrument panel
21. Center Mid/High Range Loudspeaker -R158

Scheme 12

1. Clamp
2. Digital Sound System Control Module -J525
3. Screw 3 Nm
4. Nut 5 Nm
5. Digital Sound System Control Module -J525- BOSE
6. Nut 5 Nm
7. Screw 3 Nm
8. Screw 2 Nm
9. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160
10. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22
11. Center Mid/High Range Loudspeaker -R158
12. Screw 1 Nm
13. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23
14. Screw 3.5 Nm
15. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104
16. Screw 2 Nm
17. Center speaker -R148
18. Screw 2 Nm

Scheme 13

1 - radio in upper center console

2 - left front treble speaker/right front treble speaker in left and right front of instrument panel

3 - left front bass speaker/right front bass speaker at bottom of doors

Scheme 14

1. Digital Sound System Control Module -J525- behind the luggage compartment left side trim
2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in left and right front of instrument panel
3. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- at bottom of doors
4. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in upper rear side trim
5. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- in rear side trim (Coupe)/in rear wall (Roadster)
6. Center Mid/High Range Speaker -R158- in center instrument panel, front

Scheme 15

1. Digital Sound System Control Module -J525- behind the luggage compartment left side trim
2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in left and right front of instrument panel
3. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- in doors, center
4. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- at bottom of doors
5. Center Mid/High Range Speaker -R158- in center instrument panel, front
6. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in upper rear side trim
7. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- in rear side trim (Coupe)/in rear wall (Roadster)
8. Center Loudspeaker -R148- behind left rear side trim (Coupe)/in center of rear wall (Roadster)
9. Microphone Unit (in front roof module) -R164- in Front Interior Light -W1

Scheme 16

1 - Black 4-pin Multi-pin Harness Connector (T4g)

1 - Microphone 1 to telephone transceiver

2 - Microphone 1 to Telephone transceiver

3 - Microphone 2 to digital sound system control module

4 - Microphone 2 to digital sound system control module

2 - Microphone 1

3 - Microphone 2

STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008

Digital sound system control module

Note. Unlisted connector terminals are not assigned.

Scheme 17

1 - Terminal 30

2 - Terminal 31

3 - Loudspeaker, left front (-)

4 - Loudspeaker, left front (+)

6 - Loudspeaker, left rear (+)

7 - Loudspeaker, left rear (-)

11 - CAN-bus low (Infotainment)

12 - CAN-bus high (Infotainment)

14 - Positive switched from radio/navigation system with CD drive control module, radio/navigation display control module

15 - Loudspeaker, right front (-)

16 - Loudspeaker, right front (+)

18 - Loudspeaker, right rear (-)

19 - Loudspeaker, right rear (+)

20 - Center mid/high range speaker (-)

21 - Center mid/high range speaker (+)

24 - Left rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

25 - Left rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

26 - Left front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

27 - Left front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

29 - Right rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

30 - Right rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

31 - Right front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

32 - Right front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009

Digital sound system control module

Note. Unlisted connector terminals are not assigned.

Scheme 18

1 - Terminal 31

2 - Terminal 30

4 - Loudspeaker, right front (+)

5 - Loudspeaker, left front (+)

7 - Loudspeaker, right rear (-)

8 - Loudspeaker, left rear (+)

10 - Center mid/high range speaker (-)

16 - Loudspeaker, right front (-)

17 - Loudspeaker, left front (-)

19 - Loudspeaker, right rear (+)

20 - Loudspeaker, left rear (-)

22 - Center mid/high range speaker (+)

23 - CAN-Bus Low (Infotainment)

27 - Left rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

28 - Right rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

29 - Left front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

30 - Right front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

31 - CAN-Bus High (Infotainment)

34 - Positive switched from radio/navigation system with CD drive control module, radio/navigation display control module

35 - Left rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

36 - Right rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

37 - Left front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

38 - Right front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

Scheme 19

A - Black 18-pin connector (T18a)

B - Black 32-pin multi-pin harness connector (T32a)

Note. Unlisted connector terminals are not assigned.

Scheme 20

3 - Left front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

4 - Left front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

5 - Left rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

6 - Left rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

11 - Right front signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

12 - Right front signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

13 - Right rear signal (+) from radio/navigation system with CD drive control module, radio/navigation display control module

14 - Right rear signal (-) from radio/navigation system with CD drive control module, radio/navigation display control module

Scheme 21

1 - Terminal 30

2 - Terminal 31

3 - Left front bass speaker (+)

4 - Right front bass speaker (+)

5 - Center loudspeaker (+)

6 - Loudspeaker, right front (+)

7 - Loudspeaker, left front (+)

8 - Center mid/high range speaker (+)

9 - Microphone input (-) from microphone unit (in front roof module)

10 - Microphone input (+) from microphone unit (in front roof module)

11 - Loudspeaker, left rear (-)

12 - Loudspeaker, left rear (+)

13 - Loudspeaker, right rear (-)

14 - Loudspeaker, right rear (+)

15 - Left Front Bass Speaker (-)

16 - Right Front Bass Speaker (-)

17 - Center Loudspeaker (-)

18 - Loudspeaker, right front (-)

19 - Loudspeaker, left front (-)

20 - Center Mid/High Range Speaker (-)

23 - Microphone input (ground shielding) from microphone unit (in front roof module)

27 - CAN-Bus high (Infotainment)

29 - Positive switched from radio/navigation system with CD drive control module, radio/navigation display control module

32 - CAN-Bus Low (Infotainment)

Scheme 22

1. Radio, Telephone, Navigation System Antenna -R52
2. Nut 6 Nm
3. Screw 2 Nm
4. Antenna Amplifier -R24
5. Nut 6 Nm
6. Antenna Amplifier 2 -R111
7. Windshield Antenna Suppression Filter -C18
8. Nut 6 Nm
9. Nut 6 Nm
10. Nut 6 Nm
11. Antenna Amplifier 4 -R113
12. Screw 2 Nm

Scheme 23

1. Radio, Telephone, Navigation System Antenna -R52- GPS/GSM Removing and installing «RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__radio-telephone-navigation-system-antenna) Sat/GPS/GSM (USA only) Removing and installing «RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
2. Antenna Amplifier 4 -R113- Connectors. Refer to «ANTENNA AMPLIFIER/ANTENNA AMPLIFIER 4 CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing «ANTENNA AMPLIFIER AND ANTENNA AMPLIFIER 4»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-amplifier-and-antenna-amplifier-4)
3. Antenna Amplifier -R24- Connectors. Refer to «ANTENNA AMPLIFIER/ANTENNA AMPLIFIER 4 CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing «ANTENNA AMPLIFIER AND ANTENNA AMPLIFIER 4»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-amplifier-and-antenna-amplifier-4)
4. Antenna Amplifier 2 -R111- Connectors. Refer to «ANTENNA AMPLIFIER 2 CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing «ANTENNA AMPLIFIER 2»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-amplifier-2)

Scheme 24

1. A - FM2/ZF connection (yellow) to Radio -R- /Navigation System with CD Drive Control Module -J401- /Radio/Navigation Display Control Module -J503
2. B - AM/FM1 connection (black) from the Antenna Amplifier -R24- (only with the radio/navigation system)
3. C - HF connection (white) to Navigation System with CD Drive Control Module -J401- /Radio/Navigation Display Unit Control Module -J503
4. D - TV1 connection (brown) to TV Tuner -R78
5. E - TV2 connection (green) to TV Tuner -R78
6. F - Connection for window antennas 1 - FM2/TV1 2 - Ground (GND) 3 - FM3/TV2

Scheme 25

1 - Central locking and anti-theft alarm system antenna CLS connection (gray)

2 - AM/FM2 connection (white) to radio/radio preparation/antenna amplifier 2

3 - Window antenna connection (1 - FM1, 2 - CLS, 3 - AM)

1 - Connection TV3 (green) to TV Tuner

2 - DAB connection (black)

3 - Window antenna connection (1 - TV/DAB, 2 - DAB, 3 - TV3)

Scheme 26

1. Nut (through MY 2007) 2 Nm
2. TV Antenna 2 -R56- (through MY 2007)
3. Navigation System Antenna -R50- /Telephone Antenna -R65
4. Screw 2 Nm
5. Antenna Amplifier 2 -R111
6. Screw 2 Nm
7. Radio Antenna 2 -R93
8. Screw 2 Nm
9. Antenna Selection Control Module -J515
10. Screw 2 Nm
11. Antenna -R11- Mast Antenna
12. Antenna Amplifier -R24
13. Nut 4 Nm
14. Grommet
15. Satellite Antenna -R170
16. Nut 6 Nm
17. Cover
18. Screw 4 Nm
19. TV antenna 2 -R56- (from MY 2008)
20. Nut (from MY 2008) 1.5 Nm

Scheme 27

1. TV Antenna 2 -R56- Removing and installing through MY 2007, refer to «TV ANTENNA 2, THROUGH MY 2007»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2-through-my-2007) Removing and installing from MY 2008, refer to «TV ANTENNA 2, FROM MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2-from-my-2008) Removing and installing, USA version, refer to «TV ANTENNA 2»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2)
2. Telephone antenna -R65- Removing and installing, refer to «NAVIGATION SYSTEM ANTENNA/TELEPHONE ANTENNA»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__navigation-system-antennatelephone-antenna)
3. Navigation System Antenna -R50- Removing and installing, refer to «NAVIGATION SYSTEM ANTENNA/TELEPHONE ANTENNA»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__navigation-system-antennatelephone-antenna)
4. Antenna Selection Control Module -J515- Only with RNS-E with TV Connectors. Refer to, refer to «ANTENNA SELECTION CONTROL MODULE CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «ANTENNA SELECTION CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-selection-control-module)
5. Antenna Amplifier 2 -R111- Connectors, refer to «ANTENNA AMPLIFIER 2 CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «ANTENNA AMPLIFIER 2»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Satellite Antenna -R170- (USA only) Removing and installing, refer to «SATELLITE ANTENNA»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__satellite-antenna)
7. Antenna Amplifier -R24- Connectors, refer to «ANTENNA AMPLIFIER CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «ANTENNA AMPLIFIER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__antenna-amplifier)
8. TV Antenna 3 -R57- Removing and installing through MY 2007, refer to «TV ANTENNA 2, THROUGH MY 2007»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2-through-my-2007) Removing and installing from MY 2008, refer to «TV ANTENNA 2, FROM MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2-from-my-2008) Removing and installing, USA version, refer to «TV ANTENNA 2»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tv-antenna-2)

Scheme 28

1 - Grommet with Antenna (AM/FM1) mast antenna

2 - DAB connection (black)

3 - Central locking and anti-theft alarm system antenna CLS connection (gray)

4 - AM/FM1 connection (white) to radio/antenna selection control module/antenna amplifier 2

Scheme 29

1 - Radio Antenna 2 FM2/TV1 rear lid antenna

2 - AM/FM1 connection (black) from the antenna amplifier (only with the radio/navigation system)

3 - IF connection (yellow) from navigation system with CD drive control module, radio/navigation display unit control module (only RNS without TV)

Connection TV1 (green) to TV Tuner

4 - HF connection (white) to navigation system with CD drive control module, radio/navigation display unit control module (only RNS without TV)

FM2 connection (yellow) to radio, antenna selection control module

Scheme 30

1 - AM/FM1 connection (black) from antenna amplifier

2 - HF connection (white) to navigation system with CD drive control module

3 - IF connection (yellow) from navigation system with CD Drive control module

4 - FM2 connection (yellow) from antenna amplifier 2

Scheme 31

1. Front Interior Light -W1- with Microphone Unit (in front roof module) -R164
2. Radio, Telephone, Navigation System Antenna -R52
3. Nut 6 Nm
4. Not Installed
5. Electronic Box Cover
6. Telephone transceiver -R36
7. Electronics Box
8. Screw 2 Nm
9. Base plate
10. Telephone Base plate -R126

Scheme 32

1. Front Interior Light -W1- with Microphone Unit (in front roof module) -R164
2. Electronic Box Cover
3. Telephone Transceiver -R36
4. Electronics Box
5. Telephone Base Plate -R126
6. Base Plate
7. Screw 2 Nm
8. Navigation System Antenna -R50- /Telephone Antenna -R65
9. Screw 2 Nm

Scheme 33

1 - Multi-pin connector, 18-pin (T18b) black, behind glove compartment

2 - Radio, telephone, navigation system antenna (GPS/GSM) coupe

Telephone antenna (GSM) roadster

3 - Microphone unit in front roof module

4 - Radio

5 - Sound Systems

6 - Terminal 15

7 - Terminal 30

8 - Terminal 31

Scheme 34

1. Telephone Baseplate -R126- inside the center console (through MY 2008)
2. Radio -R- /Navigation System with CD Drive Control Module -J401- in top of center console
3. Sound Systems
4. Bluetooth Antenna -R152- at Telephone Transceiver -R36
5. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat
6. Microphone Unit (in front roof module) -R164- in Front Interior Light -W1
7. radio, telephone and navigation system antenna -R52- Roof Antenna (Coupe) Through MY 2008 - Telephone Antenna -R65- Behind The Front Interior Lamp -W1- (Roadster) Through MY 2008

CELLULAR TELEPHONE PREPARATION, CONNECTOR, PRELIMINARY SETUP

Note. Unlisted connector terminals are not assigned.

1 - Terminal 31

4 - NF mute to radio/navigation system with CD drive control module, radio/navigation display control module

7 - NF (-) to radio/navigation system with CD drive control module, radio/navigation display control module

9 - Microphone unit (in front roof module) (-)

10 - Terminal 15

11 - Terminal 30

16 - NF (+) to radio/navigation system with CD drive control module, radio/navigation display control module

18 - Microphone unit (in front roof module) (+)

Scheme 35

A - Bluetooth antenna connection (yellow)

B - Black 54-pin multi-pin harness connector (T54)

Note. Unlisted connector terminals are not assigned.

Scheme 36

1 - Terminal 30

2 - Terminal 31

8 - LF (+) out to radio/navigation system with CD drive control module

9 - LF (-) out to radio/navigation system with CD drive control module

10 - Terminal 31 (screen ground) (not used)

11 - Microphone input (+) from microphone unit (in front roof module)/navigation system with CD drive control module

12 - Microphone input (-) from microphone unit (in front roof module)/navigation system with CD drive control module

16 - LF mute to Navigation System with CD Drive Control Module

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to telephone baseplate

39 - Terminal 31 to telephone baseplate

41 - Terminal 30 to telephone baseplate

42 - Microphone output (+) to telephone baseplate

43 - Microphone output (-) to telephone baseplate

44 - Terminal 31 (screen ground)

45 - LF (+) from telephone baseplate

46 - LF (-) from telephone baseplate

47 - SNDREQ signal from telephone baseplate

49 - Ser-Tx (+) to telephone baseplate

50 - Ser-Tx (-) to telephone baseplate

51 - Ser-Rx (+) from telephone baseplate

52 - Ser-Rx (-) from telephone baseplate

CELLULAR TELEPHONE PREPARATION CONNECTORS, FROM MY 2009

A - Bluetooth antenna connection (yellow)

B - Black 54-pin multi-pin harness connector (T54)

Note. Unlisted connector terminals are not assigned.

1 - Terminal 30

2 - Terminal 31

8 - LF (+) out to radio/navigation system with CD drive control module

9 - LF (-) out to radio/navigation system with CD drive control module

10 - Terminal 31 (screen ground) (not used)

11 - Microphone input (+) from microphone unit (in front roof module)/navigation system with CD drive control module

12 - Microphone input (-) from microphone unit (in front roof module)/navigation system with CD drive control module

16 - LF mute to navigation system with CD drive control module

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW

1 - Black 4-pin multi-pin harness connector (T4g)

1 - Microphone 1 to telephone transceiver

2 - Microphone 1 to telephone transceiver

3 - Microphone 2 to digital sound system control module

4 - Microphone 2 to digital sound system control module

2 - Microphone 1

3 - Microphone 2

TELEPHONE TRANSCEIVER HARNESS CONNECTORS

A - Bluetooth antenna connection (yellow)

B - Black 54-pin multi-pin harness connector (T54)

Note. Unlisted connector terminals are not assigned.

1 - Terminal 30

2 - Terminal 31

3 - Signal cellular telephone ON to telephone amplifier

8 - NF (+) to radio/navigation system with cd drive control module, radio/navigation display control module

9 - NF (-) to radio/navigation system with cd drive control module, radio/navigation display control module

10 - Terminal 31 (screen ground) (not used)

11 - Microphone input (+) from microphone unit (in front roof module)/navigation system with cd drive control module

12 - Microphone input (-) from microphone unit (in front roof module)/navigation system with cd drive control module

16 - NF mute, not used

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to telephone baseplate

39 - Terminal 31 to telephone baseplate

41 - Terminal 30 to telephone baseplate

42 - Microphone output (+) to telephone baseplate

43 - Microphone output (-) to telephone baseplate

44 - Terminal 31 (screen ground)

45 - LF (+) from telephone baseplate

46 - LF (-) from telephone baseplate

47 - SNDREQ signal from telephone baseplate

49 - Ser-Tx (+) to telephone baseplate

50 - Ser-Tx (-) to telephone baseplate

51 - Ser-Rx (+) from telephone baseplate

52 - Ser-Rx (-) from telephone baseplate

Scheme 37

1. CD Changer -R41- In the glove compartment
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center
3. Microphone unit in front roof module -R164- In Front Interior Light -W1- Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
4. Radio, Telephone, Navigation System Antenna -R52- Through MY 2008 Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim
6. Rear Speaker Behind rear side trim
7. Telephone Transceiver -R36- In electronics box under left front seat Connectors through MY 2008, refer to «CELLULAR TELEPHONE PREPARATION CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Connectors from MY 2009, refer to «CELLULAR TELEPHONE PREPARATION CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cellular-telephone-preparation-connectors-from-my) Removing and installing, refer to «TELEPHONE TRANSCEIVER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__telephone-transceiver)
8. Front Speaker In doors
9. Telephone Base plate -R126- Through MY 2008 In center console Removing and installing, refer to «TELEPHONE BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__telephone-baseplate)
10. Radio -R- In the top of the center console

Scheme 38

1. Not Installed
2. CD Changer -R41- In the glove compartment
3. Center Mid/High Range Loudspeaker -R158- In the center of the instrument panel
4. Telephone Antenna -R65- Through MY 2008 Behind front interior light Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Telephone Transceiver -R36- In electronics box under left front seat Connectors through MY 2008, refer to «CELLULAR TELEPHONE PREPARATION CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Connectors from MY 2009, refer to «CELLULAR TELEPHONE PREPARATION CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cellular-telephone-preparation-connectors-from-my) Removing and installing, refer to «TELEPHONE TRANSCEIVER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__telephone-transceiver)
7. Front Speaker In doors
8. Telephone Base plate -R126- Through MY 2008 In center console Removing and installing, refer to «TELEPHONE BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__telephone-baseplate)
9. Radio -R- In the top of the center console

Scheme 39

1. Radio, Telephone, Navigation System Antenna -R52
2. Nut 6 Nm
3. Navigation System with CD Drive Control Module -J401
4. Radio Removal Tool T10057

Scheme 40

1. Navigation System Antenna -R50- /Telephone Antenna -R65
2. Screw 2 Nm
3. Navigation System With CD Drive Control Module -J401
4. Radio Removal Tool T10057

ERROR MESSAGES ON SCREEN

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the navigation system with CD drive control module display.

The following fault messages can be displayed

Indicator in display

This error message appears

1. Navigation DVD cannot be read.
2. DVD is faulty.
3. DVD drive is faulty.

See if drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the vehicle diagnosis, testing and information system to do so.

Indicator in display

This error message appears

1. Drive cannot read DVD data.
2. DVD is faulty.
3. DVD drive is faulty.

See if drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the vehicle diagnosis, testing and information system to do so.

Scheme 41

1. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna
2. Rear Window Antennas
3. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid
4. Antenna Amplifier 2 -R111- On Lower Right Area Of Rear Lid
5. Sound Systems
6. Navigation System with CD Drive Control Module -J401- in Top Of Center Console
7. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
8. Satellite Radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
9. CAN-BUS (Infotainment)
10. External Audio Source Connection -R199- In The Center Console Storage Compartment
11. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat

Scheme 42

1. Satellite antenna -R170- On The Rear Lid
2. Telephone Antenna -R65- Behind Front Interior Light -W1
3. Navigation System Antenna -R50- Behind Front Interior Light -W1
4. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
5. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
6. Antenna Amplifier -R24- Left Rear Mast Antenna Base
7. Antenna Selection Control Module -J515- In Luggage Compartment Under The Luggage Compartment Floor Covering In the center
8. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid
9. External audio source connection -R199- In The Center Console Storage Compartment
10. Navigation System with CD Drive Control Module -J401- In Top Of Center Console
11. Sound Systems
12. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
13. Satellite radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
14. CAN-BUS (Infotainment)
15. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat

Scheme 43

1. GPS connection (blue) from Radio, Telephone, Navigation System Antenna -R52- Coupe - GPS connection (blue) from Navigation System Antenna -R50- Roadster
2. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
3. Front Passenger's Airbag Disabled Indicator Lamp -K145
4. IF Connection (White) To Antenna Amplifier 2 -R111- Coupe - IF Connector (White) To The Antenna Selection Control Module -J515- Roadster
5. HF (white) Connection From Antenna Amplifier 2 -R111- Coupe - HF Connector (White) From The Antenna Selection Control Module -J515- Roadster
6. 32-pin Connector (T32b) From The External Audio Source Connection -R199

Note. Unlisted connector terminals are not assigned.

2 - Right front speaker (+) (not used)

3 - Left front speaker (+) (not used)

6 - Right front speaker (-) (not used)

7 - Left front speaker (-) (not used)

2 - Signal ground to CD changer/satellite radio

3 - Speed signal (not used)

4 - Permanent positive to CD changer

5 - K diagnostic (not used)

6 - Data out to the CD changer

7 - BOSE coding to ground (only with BOSE)

8 - Left signal from CD changer/satellite radio

9 - Right signal from CD changer/satellite radio

10 - Positive switched to CD changer

11 - Data in from the CD changer

12 - CLK from the CD changer

2 - Signal from back-up light switch (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from telephone transciever

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive (not used)

Scheme 44

6 - Right LF-IN from the external audio source connection

21 - LF-IN ground from the external audio source connection

22 - Left LF-IN from the external audio source connection

Scheme 45

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External Audio Source Connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Radio, Telephone, Navigation System Antenna -R52- Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
8. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connectors, refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, activating, refer to «SATELLITE RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__satellite-radio)
9. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
10. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-loudspeaker-coupe)
11. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
12. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
13. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
14. Navigation System with CD Drive Control Module -J401- In the top of the center console Connectors, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE, HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__navigation-system-with-cd-drive-control)

Scheme 46

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
3. Navigation System Antenna -R50- Behind Front Interior Light Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
4. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
5. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In left and right rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-speaker-roadster)
6. Antenna Selection Control Module -J515- Inside the luggage compartment under the luggage compartment floor covering in the center Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Satellite Antenna -R170- On rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
10. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
11. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connectors. Refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, activating, refer to «SATELLITE RADIO»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__satellite-radio)
12. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
13. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
14. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
15. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
16. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
17. Navigation System with CD Drive Control Module -J401- In the top of the center console Connectors, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE, HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__navigation-system-with-cd-drive-control)
18. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

Scheme 47

1. Rear Window Antennas
2. Radio, Telephone, Navigation System Antenna -R52- (GPS/GSM) Roof Antenna
3. GPS Connection (Blue) From Radio, Telephone, Navigation System Antenna -R52
4. 12-pin Black Multi-pin Connector (T12h) From Digital Sound System Control Module -J525
5. Digital Sound System Control Module -J525- Behind The Luggage Compartment Left Side Trim
6. Sound Systems
7. 2-pin Black Multi-pin Voltage Supply Connection (T2l)
8. Black 2-pin Multi-pin CAN BUS (Infotainment) Connection (T2m)
9. TV3/TV4 Connection (Green) From Antenna Amplifier 4 -R113
10. AM/FM1 Connection (White) Antenna Amplifier -R24
11. TV1/TV2 Connection (Brown) From Antenna Amplifier 2 -R111
12. Antenna Amplifier 2 -R111- On Lower Right Area Of Rear Lid
13. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid
14. Antenna Amplifier 4 -R113- On Upper Left Of Rear Lid

Scheme 48

1. Radio Antenna 2 -R93- (FM2/TV1) Behind Right Side Of Rear Lid
2. Antenna (TV2) Right Of Windshield
3. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
4. Antenna (TV3) Left Of Windshield
5. Navigation System Antenna -R50- Behind Front Interior Light -W1
6. GPS Connection (Blue) From Navigation System Antenna -R50
7. 12-pin Black Multi-Pin Connector (T12h) From Digital Sound System Control Module -J525
8. Digital sound system control module -J525- Behind The Luggage Compartment Left Side Trim
9. Sound Systems
10. 2-pin Black Multi-Pin Voltage Supply Connection (T2l)
11. Black 2-pin Multi-pin CAN BUS (Infotainment) Connection (T2m)
12. TV1/TV2 Connection (Brown) From Antenna Amplifier 2 -R111- /TV Antenna 2 -R56
13. AM/FM1 connection (white) from Antenna Amplifier -R24
14. TV3 Connection (Green) From TV Antenna 3 -R57
15. TV Antenna 3 -R57- Behind The Left A-Pillar Trim
16. Antenna Amplifier -R24- Left Rear Mast Antenna Base
17. TV Antenna 2 -R56- Behind The Right A-Pillar Trim
18. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid

SOUND SYSTEM CONNECTORS AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not assigned.

Scheme 49

2 - Right rear signal (+) to digital sound system control module

3 - Right rear signal (-) to digital sound system control module

4 - Positive switched to digital sound system control module

5 - Left rear signal (-) to Digital sound system control module

6 - Left rear signal (+) to digital sound system control module

8 - Right front signal (+) to digital sound system control module

9 - Right front signal (-) to digital sound system control module

11 - Left front signal (-) to digital sound system control module

12 - Left front signal (+) to digital sound system control module

Scheme 50

1 - Terminal 30

2 - Terminal 31

Scheme 51

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

Scheme 52

1 - GPS connection (blue) from radio, telephone, navigation system antenna (Coupe)

GPS connection (blue) from navigation system antenna (Roadster)

2 - AM/FM1 connection (white) antenna amplifier

3 - TV3/TV4 connection (green) from antenna amplifier 4 (Coupe)

TV3 connection (green) from TV antenna 3 (Roadster)

4 - TV1/TV2 connection (brown) antenna amplifier 2 (Coupe)

TV1/TV2 connection (brown) antenna amplifier 2/TV antenna 2 (Roadster)

Scheme 53

1. Left Front Treble Speaker -R20- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Radio, Telephone, Navigation System Antenna -R52- GPS/GSM Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Antenna Amplifier 4 -R113- On upper left of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
9. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
10. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-loudspeaker-coupe)
11. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
12. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
13. Right Front Treble Speaker -R22- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
14. RNS-JP4 Connections/Antenna Connections In the top of the center console Connectors, refer to «ANTENNA CONNECTORS AND CONNECTOR ASSIGNMENTS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) .

Scheme 54

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. TV Antenna 2 -R56- Behind the A-pillar trim on the right side Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Navigation System Antenna -R50- Behind Front Interior Light Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Microphone unit in front roof module -R164- In Front Interior Light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
6. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
7. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-speaker-roadster)
8. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
9. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
10. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
11. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
12. Center Speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
13. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
15. TV Antenna 3 -R57- Behind the A-pillar trim on the left side Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
16. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
17. RNS-JP4 Connections/Antenna Connections In the top of the center console Connectors, refer to «ANTENNA CONNECTORS AND CONNECTOR ASSIGNMENTS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) .
18. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

Scheme 55

1. Rear window antennas
2. Radio, Telephone, Navigation System Antenna -R52- (GPS/GSM) roof antenna
3. Microphone Unit (In Front Roof Module) -R164- in Front Interior Light -W1
4. Black 4-pin Connector
5. GPS Connection (Blue) From Radio, Telephone, Navigation System Antenna -R52
6. Black 12-pin Connector (T12) Digital Sound System Control Module -J525
7. Digital Sound System Control Module -J525- Behind The Luggage Compartment Left Side Trim
8. Sound Systems
9. TV Card Reader -R204- Inside The Glove Compartment With T12
10. Black 12-pin Connector
11. 2-pin Black Multi-pin Voltage Supply Connection (T2l)
12. Black 2-pin Multi-pin CAN BUS (Infotainment) Connection (T2m)
13. TV3/TV4 Connection (Green) From Antenna Amplifier 4 -R113
14. AM/FM1 Connection (White) Antenna Amplifier -R24
15. TV1/TV2 Connection (Brown) From Antenna Amplifier 2 -R111
16. Antenna Amplifier 2 -R111- On Lower Right Area Of Rear Lid
17. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid
18. Antenna Amplifier 4 -R113- On Upper Left Of Rear Lid

Scheme 56

1. FM2/TV 1 Antenna Behind The Rear Lid End Piece On The Right Side
2. TV 1 Antenna On The Right Side Of The Windshield
3. AM/FM1 Rear Mast Antenna On The Left Side
4. Antenna TV3 Left Of Windshield
5. Navigation System Antenna -R50- Behind Front Interior Light -W1
6. Microphone Unit (in front roof module) -R164- In Front Interior Light -W1
7. Black 4-pin Connector
8. GPS Connection (blue) From Navigation System Antenna -R50
9. Black 12-pin Connector (T12) Digital Sound System Control Module -J525
10. Digital Sound System Control Module -J525- Behind The Luggage Compartment Left Side Trim
11. Sound Systems
12. Tv Card Reader -R204- Inside The Glove Compartment With T12
13. Black 12-pin Connector
14. 2-pin Black Multi-pin Voltage Supply Connection (T2l)
15. Black 2-pin Multi-pin CAN BUS (Infotainment) Connection (T2m)
16. TV1/TV2 Connection (Brown) From Antenna Amplifier 2 -R111- /TV Antenna 2 -R56
17. AM/FM1 Connection (White) Antenna Amplifier -R24
18. TV3 Connection (Green) From TV Antenna 3 -R57
19. TV Antenna 3 -R57- Behind The Left A-Pillar Trim
20. Antenna Amplifier -R24- Left Rear Mast Antenna Base
21. TV Antenna 2 -R56- Behind The Right A-Pillar Trim
22. Antenna Amplifier 2 -R111- Behind The Rear Lid End Piece On The Right Side

CONNECTORS AND CONNECTOR ASSIGNMENTS

Note. Unlisted connector terminals are not assigned.

Sound system

2 - Right rear signal (+) to Digital Sound System Control Module

3 - Right rear signal (-) to Digital Sound System Control Module

4 - Positive switched to Digital Sound System Control Module

5 - Left rear signal (-) to Digital Sound System Control Module

6 - Left rear signal (+) to Digital Sound System Control Module

8 - Right front signal (+) to Digital Sound System Control Module

9 - Right front signal (-) to Digital Sound System Control Module

11 - Left front signal (-) to Digital Sound System Control Module

12 - Left front signal (+) to Digital Sound System Control Module

Voltage supply, CAN Bus, TV card reader

1 - Terminal 30

2 - Terminal 31

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

Scheme 57

All pins are connected to the TV card reader.

1 - VDDP

2 - Ground (GND)

3 - VDD

4 - CMDVCC

5 - CLKDIV2

6 - CLKDIV1

7 - OFF

8 - Ground (GND)

9 - Ground (GND)

10 - I/OUC

11 - Ground (GND)

12 - RSTIN

Scheme 58

All pins are connected to the TV card reader.

1 - VDDP

2 - Ground (GND)

3 - VDD

4 - CMDVCC

5 - CLKDIV2

6 - CLKDIV1

7 - OFF

8 - Ground (GND)

9 - Ground (GND)

10 - I/OUC

11 - Ground (GND)

12 - RSTIN

Scheme 59

1 - Telephone microphone (+)

2 - Telephone microphone (-)

1 - GPS connection (blue) from radio, telephone, navigation system antenna (Coupe)

GPS connection (blue) from navigation system antenna (Roadster)

2 - AM/FM1 connection (white) antenna amplifier

3 - TV3/TV4 connection (green) from antenna amplifier 4 (Coupe)

TV3/TV 4 connection (green) from TV antenna 3 (Roadster)

4 - TV1/TV2 connection (brown) antenna amplifier 2 (Coupe)

TV1/TV2 connection (brown) TV antenna 2 (Roadster)

Scheme 60

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External Audio Source Connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Microphone Unit In Front Roof Module -R164- In Front Interior Light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
5. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Radio, Telephone, Navigation System Antenna -R52- GPS/GSM Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Antenna Amplifier 4 -R113- On upper left of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
9. not installed
10. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
11. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
12. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-loudspeaker-coupe)
13. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
15. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
16. RNS-JP5 Connections/Antenna Connections In the top of the center console Connectors, refer to «CONNECTORS AND CONNECTOR ASSIGNMENTS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__connectors-and-connector-assignments) .

ROADSTER COMPONENT LOCATIONS, GENERAL OVERVIEW

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. TV Antenna 2 -R56- Behind the A-pillar trim on the right side Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Navigation System Antenna -R50- Behind front interior light Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
5. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
6. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
7. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-speaker-roadster)
8. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
9. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
10. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
11. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
12. Center Speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
13. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
15. TV Antenna 3 -R57- Behind the A-pillar trim on the left side Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
16. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
17. RNS-JP5 Connections/Antenna Connections In the top of the center console Connectors, refer to «CONNECTORS AND CONNECTOR ASSIGNMENTS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__connectors-and-connector-assignments) .
18. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate -R192- Connectors Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

Scheme 61

1. Radio, Telephone, Navigation System Antenna -R52
2. Nut 6 Nm
3. Radio/Navigation Display Control Module -J503
4. Radio Removal Tool T10057

Scheme 62

1. Navigation System Antenna -R50- /Telephone Antenna -R65
2. Screw 2 Nm
3. Radio/Navigation Display Control Module -J503
4. Radio Removal Tool T10057

Scheme 63

1. Rear Window Antennas
2. Antenna Amplifier 2 -R111- On Lower Right Area Of Rear Lid
3. Sound Systems
4. Radio/Navigation Display Control Module -J503- In Top Of Center Console
5. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
6. CAN-BUS (Infotainment)
7. External audio source connection -R199- In The Center Console Storage Compartment
8. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat
9. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid
10. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna

Scheme 64

1. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
2. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
3. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid
4. Sound Systems
5. Radio/Navigation Display Control Module -J503- In Top Of Center Console
6. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
7. CAN-BUS (Infotainment)
8. External audio source connection -R199- In The Center Console Storage Compartment
9. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat
10. Antenna Amplifier -R24- Left Rear Mast Antenna Base
11. Telephone Antenna -R65- Behind Front Interior Light -W1
12. Navigation System Antenna -R50- Behind Front Interior Light -W1

Scheme 65

1. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
2. Front Passenger's Airbag Disabled Indicator Lamp -K145
3. GPS Connection (Blue) From Radio, Telephone, Navigation System Antenna -R52- Coupe - GPS Connection (Blue) From Navigation System Antenna -R50- Roadster
4. IF Connection (White) To Antenna Amplifier 2 -R111
5. HF (white) Connection From Antenna Amplifier 2 -R111

Note. Unlisted connector terminals are not assigned.

2 - Right front speaker (+) (not used)

3 - Left front speaker (+) (not used)

6 - Right front speaker (-) (not used)

7 - Left front speaker (-) (not used)

1 - Left LF-In from the external audio source connection

2 - Signal ground to CD changer/iPod base plate

3 - LF-In ground from the external audio source connection

4 - Continuous plus to the CD changer/iPod base plate

5 - BOSE coding to ground (only with BOSE)

6 - CD data to CD changer/iPod base plate

7 - Right LF-In from the external audio source connection

8 - Left signal from CD changer/iPod base plate

9 - Right signal from CD changer/iPod base plate

10 - Positive switched to CD changer/iPod base plate

11 - CD data in from the CD changer/iPod base plate

12 - CLK from CD changer/iPod base plate

1 - Speed signal (not used)

2 - Signal from back-up light switch (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver/preliminary setup for cellular telephone package

7 - K diagnostic (not used)

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver/preliminary setup for cellular telephone package

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from preliminary setup for cellular telephone preparation

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive to PIN 15 (anti-theft protection)

Scheme 66

1. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
4. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
5. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
6. Radio, Telephone, Navigation System Antenna -R52- Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
7. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
9. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-treble-speaker)
10. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-loudspeaker-coupe)
11. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
12. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
13. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
14. Radio/Navigation Display Control Module -J503- In the top of the center console Connectors, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__radionavigation-display-control-module)

Scheme 67

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-midhigh-range-speaker)
3. Navigation System Antenna -R50- Behind front interior light Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
4. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__microphone-unit-in-front-roof-module)
5. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
6. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-rear-midlow-range-speaker-roadster)
7. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
8. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__digital-sound-system-control-module-bose)
10. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
11. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__center-loudspeaker-roadster)
12. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-midrange-speaker)
13. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-bass-speaker)
14. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__left-front-treble-speaker)
15. Radio/Navigation Display Control Module -J503- In the top of the center console Connectors, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) . Removing and installing, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__navigation-system-with-cd-drive-control)
16. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - iPod Baseplate In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) - External audio source connection Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__aux-in-external-audio-source-connection) .

CD CHANGER HARNESS CONNECTORS

Note. Unlisted connector terminals are not assigned.

Scheme 68

1 - CD data out to radio/navigation system with CD drive control module, radio/navigation display control module

2 - CLK out to radio/navigation system with CD drive control module, radio/navigation display control module

3 - Terminal 31

4 - Data in from radio/navigation system with CD drive control module, radio/navigation display control module

6 - Permanent positive from radio/navigation system with CD drive control module, radio/navigation display control module

7 - Right signal to radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

8 - Positive switched from radio/navigation system with CD drive control module, radio/navigation display control module

9 - Signal ground from radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

10 - Left signal to radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

IPOD BASEPLATE, CONNECTIONS

Note. Unlisted connector terminals are not assigned.

Scheme 69

1 - CD data out to radio/navigation system with CD drive control module, radio/navigation display control module

2 - CLK out to radio/navigation system with CD drive control module, radio/navigation display control module

3 - Terminal 31

4 - Data in from radio/navigation system with CD drive control module, radio/navigation display control module

6 - Permanent positive from radio/navigation system with CD drive control module, radio/navigation display control module

7 - Right signal to radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

8 - Positive switched from radio/navigation system with CD drive control module, radio/navigation display control module

9 - Signal ground from radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

10 - Left signal to radio/navigation system with CD drive control module, radio/navigation display control module, satellite radio

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI

Note. Unlisted connector terminals are not assigned.

1 - Terminal 31

2 - CAN-Bus Low (Infotainment)

4 - Right NF to radio/navigation system with CD drive control module, radio/navigation display control module

7 - Terminal 30

8 - CAN-Bus High (Infotainment)

9 - Left NF to radio/navigation system with CD drive control module, radio/navigation display control module

10 - NF ground to radio/navigation system with CD drive control module, radio/navigation display control module

AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS

Note. Unlisted connector terminals are not assigned.

Scheme 70

All pins are connected to the radio/navigation system with CD drive control module, radio/navigation display control module.

1 - LF ground

2 - LF left

3 - LF right

4 - Terminal 31

Scheme 71

1. Multifunction Steering Wheel Multi-function buttons, removing and installing, refer to «MULTI-FUNCTION BUTTONS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__multi-function-buttons) Tiptronic Switch, removing and installing, refer to «TIPTRONIC SWITCH»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe__tiptronic-switch)
2. Steering Column Electronic Systems Control Module -J527- On steering column Connectors, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTORS»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe) Removing and installing, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE»(/audi/tt/8j-2006-2010/remont/communication-devices/#communication-coupe)
3. Telephone transceiver -R36- In electronics box under left front seat
4. CAN-Bus (Comfort)
5. Data Bus On Board Diagnostic Interface -J533- behind left front compartment
6. CAN-Bus (Infotainment)
7. Radio -R- In the top of the center console
8. CD Changer -R41- In the glove compartment
9. CAN-Bus (Powertrain)
10. Engine Control Module -J623- In plenum chamber
11. CAN-Bus (Instrument Cluster)
12. Instrument Cluster Control Module -J285- (instrument cluster) In instrument panel
13. LIN Data Bus (Single Wire Bus)

Scheme 72

1. Airbag Spiral Spring
2. Wiper Switch/On-Board Computer
3. Steering Angle Sensor -G85
4. Steering Column Electronic Systems Control Module -J527
5. Black Connector (T20b) On Steering Column Electronic Systems Control Module -J527
6. Ignition/Starter Switch -D
7. Turn Signal Switch/Cruise Control Switch

Scheme 73

A - 4-pin multi-pin connector (T4n) yellow

B - Black 20-pin multi-pin connector (T20b)

Note. Unlisted connector terminals are not assigned.

Scheme 74

11 - CAN-Bus Low (powertrain)

12 - CAN-Bus High (powertrain)

13 - Cruise control locked OFF to Engine Control Module (ECM) -J623

14 - CAN-Bus High (comfort)

15 - CAN-Bus Low (comfort)

16 - Parking lock signal from automatic transmission shift gate

17 - Terminal 15 to vehicle electrical system control module

18 - Terminal 50 to vehicle electrical system control module

19 - Terminal 30

20 - Terminal 31

FASTENER TIGHTENING SPECIFICATIONS

RADIO

Required Special Tools and Equipment

1. Radio Removal Tool T10057

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Activate transport mode in symphony. Refer to SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING .

Switch off all electrical consumers.

Remove the key.

Removing

Insert radio removal tool in release slits on radio until they engage. Points on grip eyes face outward.

Scheme 75

Remove radio from instrument panel with radio removal tool grip eyes.

Release electrical connectors on radio and remove them.

Remove radio removal tool by pressing locking tabs on radio.

Remove front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Installing

Install front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Connect all electrical connectors.

Carefully slide radio into instrument panel and let it engage in mounting frame.

Deactivate transport mode in symphony. Refer to SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING .

FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP

In case of a fault or if radio is replaced, front passenger's airbag disabled indicator lamp must be removed.

Switch off all electrical consumers.

Remove the key.

Removing

Remove radio far enough so rear side can be reached. Refer to RADIO .

Press retaining springs -arrows- at left and right of front passenger's airbag disabled indicator lamp -1-.

Scheme 76

Press front passenger's airbag disabled indicator lamp -1- in -direction of arrow- out of radio frame -2-.

Disconnect electrical connector -1- on front passenger's airbag disabled indicator lamp -2-.

Scheme 77

Installing

Install in reverse order.

SATELLITE RADIO

The satellite radio is clamped into the left luggage compartment insert.

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Switch off all electrical consumers.

Remove the key.

Removing

Open luggage compartment.

Remove the luggage compartment floor covering.

Tip satellite radio -1- in -direction of arrow- out of luggage compartment insert.

Scheme 78

Disconnect electrical connectors -2-, -3- and -4- on satellite radio -1-.

Installing

Install in reverse order.

Enable satellite radio. Refer to SATELLITE RADIO, ENABLING .

DIGITAL SOUND SYSTEM CONTROL MODULE

The digital sound system control module is located behind the left luggage compartment trim panel between the tail lamp assembly and the wheel housing.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the left luggage compartment trim panel. Refer to Removal and Installation .

Remove screws -2-.

Scheme 79

Tip digital sound system control module -1- out of clamp -3- on bracket.

Disconnect electrical connector on digital sound system control module -1-.

Installing

Install in reverse order.

Make sure that digital sound system control module -1- slides into clamp -3- first.

DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)

The digital sound system control module is located behind the left luggage compartment trim panel between the tail lamp assembly and the wheel housing.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the left luggage compartment trim panel. Refer to Removal and Installation .

Loosen nuts -1- and -3- on bracket.

Scheme 80

The digital sound system control module -2- with bracket is only connected at left rear.

Tip digital sound system control module -2- with bracket into luggage compartment.

Disconnect electrical connectors -1- and -2- on digital sound system control module.

Scheme 81

Remove bolts -4- and tip digital sound system control module out of clamps -3-.

Installing

Install in reverse order.

Make sure that digital sound system control module slides into clamp -3- first.

LEFT FRONT BASS SPEAKER

Removal and installation of left front bass speaker and right front bass speaker are the same.

Switch off all electrical consumers.

Remove the key.

Removing

Remove door trim panel. Refer to Removal and Installation .

Disconnect electrical connector -1- on left front bass speaker -3-.

Scheme 82

Remove screws -2-.

Remove left front bass speaker -3- from door.

Installing

Install in reverse order.

LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE

Removal and installation of left rear mid/low range speaker and right rear mid/low range speaker are identical.

Switch off all electrical consumers.

Remove the key.

Removing

Remove side trim. Refer to Removal and Installation .

Disconnect electrical connector -1- on left rear mid/low range speaker -2-.

Scheme 83

Remove screws -3-.

Remove left rear mid/low range speaker -2- from door.

Installing

Install in reverse order.

LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER

Removal and installation of left rear mid/low range speaker and right rear mid/low range speaker are identical.

Switch off all electrical consumers.

Remove the key.

Removing

Remove end panel trim panel. Refer to Removal and Installation .

Disconnect the connector -3- from the left rear midrange speaker -1-.

Scheme 84

Remove screws -2-.

Remove left rear mid/low range speaker -1- from rear wall.

Installing

Install in reverse order.

LEFT FRONT TREBLE SPEAKER

Removal and installation o left front treble speaker and right front treble speaker is the same.

The speakers are clipped into the instrument panel.

Switch off all electrical consumers.

Remove the key.

Removing

First unclip speaker trim.

Unclip left front treble speaker -2- from instrument panel -1-.

Scheme 85

Disconnect electrical connector -3- on left front treble speaker -2-.

Installing

Install in reverse order.

LEFT REAR TREBLE SPEAKER

Removal and installation of left rear treble speaker and right rear treble speaker is identical.

The speakers are clipped into the side trim.

Switch off all electrical consumers.

Remove the key.

Removing

Remove side trim. Refer to Removal and Installation .

Disconnect electrical connector -1- on left rear treble speaker -2-.

Scheme 86

Release retaining clips -arrows- and remove left rear treble speaker -2- from side trim -3-.

Installing

Install in reverse order.

CENTER MID/HIGH RANGE SPEAKER

Switch off all electrical consumers.

Remove the key.

Removing

Unclip cover on front center of instrument panel.

Remove screws -2-.

Scheme 87

Raise center mid/high range loudspeaker -3- from instrument panel -1- and disconnect electrical connector.

Installing

Install in reverse order.

LEFT FRONT MIDRANGE SPEAKER

Removal and installation of left front midrange speaker and right front midrange speaker is the same.

Switch off all electrical consumers.

Remove the key.

Removing

Remove door trim panel. Refer to Removal and Installation .

Disconnect electrical connector -1- on left front midrange speaker -3-.

Scheme 88

Remove nuts -2-.

Remove left front midrange speaker -3- from side panel.

Installing

Install in reverse order.

CENTER LOUDSPEAKER, COUPE

Switch off all electrical consumers.

Remove the key.

Removing

Remove left side trim. Refer to Removal and Installation .

Disconnect electrical connector on center loudspeaker -1-.

Scheme 89

Remove nuts -2-.

Remove bolt -3-.

Remove center loudspeaker -1- from side panel -4-.

Installing

Install in reverse order.

CENTER LOUDSPEAKER, ROADSTER

Switch off all electrical consumers.

Remove the key.

Removing

Remove end panel trim panel. Refer to Removal and Installation .

Remove screws -2-.

Scheme 90

Disconnect electrical connector on center loudspeaker -1-.

Remove center loudspeaker -1- from rear wall.

Installing

Install in reverse order.

MICROPHONE UNIT IN FRONT ROOF MODULE

A maximum of two microphones are installed in the front interior light. They can only be replaced completely.

Switch off all electrical consumers.

Remove the key.

Removing

Remove front interior light. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Disconnect electrical connector -1-.

Scheme 91

Pry microphones -2- and -4- out of front interior light -3- -arrows-.

Installing

Install in reverse order.

ANTENNA AMPLIFIER 2

The antenna amplifier 2 is located on the bottom right of the rear lid.

Switch off all electrical consumers.

Remove the key.

Removing

Remove lower rear lid trim. Refer to Removal and Installation .

Disconnect electrical connectors -2-, -4- and -5- on antenna amplifier 2 -1-.

Scheme 92

Remove nuts -3-.

Remove antenna amplifier 2 -1- from rear lid.

Installing

Install in reverse order.

ANTENNA AMPLIFIER AND ANTENNA AMPLIFIER 4

The antenna amplifier and antenna amplifier 4 are located on the upper right and left of the rear lid.

Removal and installation of antenna amplifier and antenna amplifier 4 is the same.

Switch off all electrical consumers.

Remove the key.

Removing

Remove rear lid trim. Refer to Removal and Installation .

Disconnect electrical connectors -3-, -4- and -5- on antenna amplifier -1-.

Scheme 93

Remove bolt -2- and remove antenna amplifier -1- from rear lid.

Installing

Install in reverse order.

RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA

The antenna wires are connected to the telephone amplifier in the left of the luggage compartment and the right rear lid connector station on the roof frame.

Switch off all electrical consumers.

Remove the key.

Removing

Lower the rear headliner. Refer to Removal and Installation .

Remove the left luggage compartment trim panel. Refer to Removal and Installation .

Disconnect antenna wires on telephone amplifier -1-.

Scheme 94

Disconnect cable tie along antenna wires up to radio, telephone, navigation system antenna -arrows-.

Disconnect connector -1- on right side at right rear lid connector station.

Scheme 95

Disconnect cable ties -arrows- up to radio, telephone, navigation system antenna -2-.

Remove nut -3-.

Remove radio, telephone, navigation system antenna -2- upward from roof.

Installing

Place radio, telephone, navigation system antenna -2- on roof and align it in direction of travel.

Lay antenna wires in opening on antenna base so nut -3- can be turned.

The antenna wires must lie in the nut opening -3-.

Align radio, telephone, navigation system antenna -2- in direction of travel again before tightening the nut -3-.

Perform further installation in reverse order.

The antenna wires are connected to the satellite radio in the left of the luggage compartment and the right rear lid connector station on the roof frame.

Switch off all electrical consumers.

Remove the key.

Removing

Lower rear headliner. Refer to Removal and Installation .

Remove the left luggage compartment trim panel. Refer to Removal and Installation .

Disconnect antenna wire on satellite radio -1-.

Disconnect cable tie along antenna wires up to radio, telephone, navigation system antenna -arrows-.

Disconnect electrical connector -1- on right side at right rear lid connector station.

Disconnect cable ties -arrows- up to radio, telephone, navigation system antenna -2-.

Remove nut -3-.

Remove radio, telephone, navigation system antenna -2- upward from roof.

Installing

Place radio, telephone, navigation system antenna -2- on roof and align it in direction of travel.

Lay antenna wires in opening on antenna base so nut -3- can be turned.

The antenna wires must lie in the nut opening -3-.

Align radio, telephone, navigation system antenna -2- in direction of travel again before tightening the nut -3-.

Perform further installation in reverse order.

WINDSHIELD ANTENNA SUPPRESSION FILTER

The windshield antenna suppression filter is located behind the left side trim between the wheel housing and center loudspeaker.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left side trim. Refer to Removal and Installation .

Remove nuts -3- and -5-.

Scheme 96

Remove wire -2- and -6- from threaded pins.

Remove nut -4-.

Remove windshield antenna suppression filter -1- from threaded pins.

Installing

Install in reverse order.

ANTENNA SPLITTER

The antenna splitter was installed through 10/06.

The antenna splitter is located in the left luggage compartment insert under the satellite radio.

Switch off all electrical consumers.

Remove the key.

Removing

Open luggage compartment.

Remove the luggage compartment floor covering.

Remove satellite radio from luggage compartment insert and lay it aside.

Pry antenna splitter -1- out of luggage compartment insert.

Scheme 97

Disconnect electrical connectors -2- and -3- on antenna splitter -1-.

Installing

Install in reverse order.

ANTENNA AMPLIFIER

The antenna amplifier is in the base of the left rear mast antenna.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the left luggage compartment trim panel. Refer to Removal and Installation .

Remove mast antenna -4-.

Scheme 98

Remove grommet -3- upward.

Remove nut -2-.

Remove antenna amplifier -1- inward from fender and disconnect antenna wiring connections.

Installing

Install in reverse order.

When installing grommet -2-, ensure tab -arrow- in the grommet is above the groove -arrow- on the antenna amplifier -1-.

Scheme 99

The antenna amplifier 2 is located behind the right side of the rear bumper below the right tail lamp.

To remove, rear bumper must be removed.

Switch off all electrical consumers.

Remove the key.

Removing

Remove rear bumper. Refer to Removal and Installation .

Remove bolt -2- on antenna amplifier 2 -1-.

Scheme 100

Disconnect all harness connectors on antenna amplifier 2 -1-.

Remove antenna amplifier 2 -1-.

Radio Antenna 2, removal

Disconnect connector -3- on radio antenna 2 -4-.

Remove bolts -5- on radio antenna 2 -4- and remove antenna.

Installing

Install in reverse order.

TV ANTENNA 2, THROUGH MY 2007

TV antenna 2/TV antenna 3 is located on the left and right A-pillars.

Removal and installation is same for TV antenna 2 and TV antenna 3.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left A-pillar trim. Refer to Removal and Installation .

Remove nut -4-.

Scheme 101

Raise TV antenna 2 -1- from retaining plate and disconnect connectors -2- and -3-.

Installing

Install in reverse order.

TV ANTENNA 2, FROM MY 2008

TV antenna 2 / TV antenna 3 is located on the left and right A-pillars.

Removal and installation is same for TV antenna 2 / TV antenna 3.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the left A-pillar trim. Refer to Removal and Installation .

Remove nut -4-.

Scheme 102

Remove TV antenna 2 -1- from the bracket and disconnect the connectors -2- and -3-.

Installing

Install in reverse order.

ANTENNA SELECTION CONTROL MODULE

The antenna selection control module is located in the front of the luggage compartment on the bottom of the compartment partition.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the luggage compartment floor covering.

Remove foam insert.

Remove bolt -3- on antenna selection control module -4-.

Scheme 103

Disconnect connectors -1- and -2- on antenna selection control module -4- and remove control module.

Installing

Install in reverse order.

NAVIGATION SYSTEM ANTENNA/TELEPHONE ANTENNA

The navigation system antenna/telephone antenna are located behind the front interior light on the roof frame.

The navigation system antenna/telephone antenna cannot be replaced individually.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the roof trim panel. Refer to Removal and Installation .

Remove screws -2- on antenna unit -4-.

Scheme 104

Disconnect connectors -1- and -3- and remove antenna unit -4-.

Installing

Install in reverse order.

SATELLITE ANTENNA

The satellite antenna is located on the rear lid.

Switch off all electrical consumers.

Remove the key.

Removing

Remove satellite antenna cover on bottom side of rear lid.

Disconnect electrical connection -1-.

Scheme 105

Remove nut -2- on satellite antenna -3-.

Remove satellite antenna -3- upward from rear lid.

Installing

Install in reverse order.

TV ANTENNA 2

TV antenna 2 / TV antenna 3 is located on the left and right A-pillars.

Removal and installation is same for TV antenna 2 and TV antenna 3.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left A-pillar trim. Refer to Removal and Installation .

The TV antenna 2 / TV antenna 3 are protected from damage by a cover (metal part). It must be removed first.

Remove screws -1-.

Scheme 106

Remove cover -2- from the A-pillar.

Remove nut -4-.

Raise TV antenna 2 -1- from retaining plate and disconnect connectors -2- and -3-.

Installing

Install in reverse order.

TELEPHONE BASEPLATE

Switch off all electrical consumers.

Remove the key.

Removing

Remove cellular telephone from telephone baseplate and unclip it.

Pry telephone baseplate -1- upward.

Scheme 107

Remove bolt -4- on bottom side of base plate -3-.

Scheme 108

Disconnect electrical connector -2- on telephone baseplate -1-.

Remove telephone baseplate -1- upward.

Installing

Install in reverse order.

TELEPHONE TRANSCEIVER

telephone transceiver is located in the electronics box under left front seat

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Switch off all electrical consumers.

Remove the key.

Removing

Remove left front seat. Refer to Removal and Installation .

Cut open the floor covering. Refer to Removal and Installation .

Unclip cover -1- on electronics box -4- and remove it upward.

Scheme 109

Remove bluetooth antenna -3- from telephone transceiver -2-.

Disconnect electrical connector -5- on telephone transceiver -2-.

Raise telephone transceiver -2- upward out of electronics box -4-.

Installing

Install in reverse order.

Install a carpet frame. Refer to Removal and Installation .

A maximum of two microphones are installed in the front interior light. They can only be replaced completely.

Switch off all electrical consumers.

Remove the key.

Removing

Remove front interior light. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Disconnect electrical connector -1-.

Unclip microphones -2- and -4- from front interior light -3- -arrows-.

Installing

Install in reverse order.

NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE

Special tools and workshop equipment required

1. Radio Removal Tool T10057

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Switch off all electrical consumers.

Remove the key.

Removing

Insert radio removal tool into release slots on navigation system with cd drive control module until they engage. Points on grip eyes face outward.

Scheme 110

Remove the navigation system with cd drive control module from the instrument panel using the grip eyes on the radio removal tool.

Release electrical connectors on navigation system with cd drive control module and remove it.

Remove radio removal tool by pressing locking tabs on navigation system with cd drive control module.

Remove front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Installing

Install front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Connect all electrical connectors.

Slide navigation system with cd drive control module straight into instrument panel until it engages in installation frame.

RADIO/NAVIGATION DISPLAY CONTROL MODULE

Special tools and workshop equipment required

1. Radio Removal Tool T10057

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Switch off all electrical consumers.

Remove the key.

Removing

Place radio removal tool -arrows- in release slits on radio/navigation display control module until they engage. Points on grip eyes face outward.

Scheme 111

Remove radio/navigation display control module from instrument panel using grip eyes on radio removal tool.

Release electrical connectors on radio/navigation display control module and remove it.

Remove radio removal tool by pressing locking tabs on radio/navigation display control module.

Remove front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Installing

Install front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .

Connect all electrical connectors.

Slide radio/navigation display control module straight into instrument panel until it engages in installation frame.

Required Special Tools and Equipment

1. Radio Removal Tool T10057

Switch off all electrical consumers.

Remove the key.

Removing

Open the glove compartment.

If there is a CD still inside the CD changer, remove it.

Insert two clips on radio removal tool in release slits on CD changer until they engage. Points on the grip eyelets of tool face outward.

Scheme 112

Remove CD changer from installation frame using grip eyes on radio removal tool.

Disconnect electrical connector on CD changer.

Remove radio removal tool, push locking tabs on CD changer to do so.

Installing

Connect electrical connector.

Slide CD changer into mounting frame until it engages.

Required Special Tools and Equipment

1. Trim removal wedge 3409

Switch off all electrical consumers.

Remove the key.

Removing

Open the glove compartment.

Remove iPod -1- from iPod baseplate.

Scheme 113

Using trim removal wedge, carefully pry iPod baseplate out of retainer -arrows-.

Remove iPod baseplate from glove compartment and disconnect electrical connector.

Installing

Install in reverse order.

AMI EXTERNAL AUDIO SOURCE CONNECTION

The external audio source connection (AMI) is located inside the glove compartment.

Special tools and workshop equipment required

1. Radio Removal Tool T10057

Switch off all electrical consumers.

Remove the key.

Removing

Open glove compartment.

Insert the two clips of the radio removal tool into the release slits on the external audio source connection until they engage. Points on the grip eyelets of tool face outward.

Scheme 114

Pull external audio source connection out of mounting frame.

Disconnect all connectors on the external audio source connection.

Remove the radio removal tool, push locking tabs on external audio source connection to do so.

Remove the internal control unit

Remove the screw -2- on back side (2 Nm).

Scheme 115

Press the tabs -4- and -5- down and up and remove the control module -5- back from the frame -1-.

Installing

Connect electrical connectors.

Slide the external audio source connection on the mounting frame until it engages.

AUX IN EXTERNAL AUDIO SOURCE CONNECTION

The external audio source connection (AUX IN) is installed inside the center console storage compartment.

Switch off all electrical consumers.

Remove the key.

Removing

Remove the rear center console. Refer to Removal and Installation .

Disconnect the connector -1- on the external audio source connection -2-.

Scheme 116

Remove bolt -4-.

Remove the external audio source connection -2- from the center console -3-.

Installing

Install in reverse order.

MULTI-FUNCTION BUTTONS

Removing

Remove driver's airbag. Refer to Passenger Protection, Airbags, Seat Belts .

Disconnect harness connector -1- at button -2-.

Scheme 117

Slide button -2- out of steering wheel in -direction of arrow-.

Turn the button around.

Disconnect the connector -2- to tiptronic switch from multifunction button -1- and remove button.

Scheme 118

Installing

Install in reverse order.

Removal and installation of left multi-function button is identical.

TIPTRONIC SWITCH

Removing

Remove driver's airbag. Refer to Passenger Protection, Airbags, Seat Belts .

Disconnect trim ring from steering wheel.

Slide multi-function button -2- out of steering wheel in -direction of arrow-.

Rotate multi-function button.

Disconnect the connector -2- on the multifunction button -1-.

Remove the bolts -arrow- (3 Nm) and the Tiptronic switch to the rear.

Scheme 119

Installing

Install in reverse order.

Removal and installation of the left switch is identical.

If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.

Use the Vehicle Diagnosis, Testing and Information System to do so.

Removing

Disconnect battery ground wire. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Observe airbag system safety precautions. Refer to General Safety Precautions .

Remove steering column switch module. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Description and Operation .

Remove bolt -arrow- (2 Nm) below spiral spring.

Scheme 120

The steering column electronic systems control module is secure to steering column module with two spring retainers.

Release springs -1- and -2- with a small screwdriver.

Scheme 121

Remove steering column electronic systems control module downward from steering column module.

Installing

Follow the safety precautions for airbag systems. Refer to General Safety Precautions .

Install in reverse order.

Make sure that all connections have engaged and lines lie in proper guides.

SPECIAL TOOLS

1. Radio Removal Tool T10057

Scheme 122

1. Trim removal wedge 3409

Scheme 123

See also:
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] General Information
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Description and Operation
• Removal and Installation
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Passenger Protection, Airbags, Seat Belts
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation
• General Safety Precautions
• SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING
• ERROR MESSAGES ON SCREEN
• LEFT FRONT TREBLE SPEAKER
• CENTER MID/HIGH RANGE SPEAKER
• FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW
• MICROPHONE UNIT IN FRONT ROOF MODULE
• ANTENNAS OVERVIEW
• SATELLITE RADIO
• STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008
• STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009
• DIGITAL SOUND SYSTEM CONTROL MODULE
• DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)
• ANTENNA SPLITTER
• LEFT REAR TREBLE SPEAKER
• LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE
• CENTER LOUDSPEAKER, ROADSTER
• LEFT FRONT MIDRANGE SPEAKER
• LEFT FRONT BASS SPEAKER
• RADIO
• CD CHANGER HARNESS CONNECTORS
• IPOD BASEPLATE, CONNECTIONS
• EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI
• AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS
• AMI EXTERNAL AUDIO SOURCE CONNECTION
• LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER
• RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA
• ANTENNA AMPLIFIER AND ANTENNA AMPLIFIER 4
• ANTENNA AMPLIFIER 2
• TV ANTENNA 2, THROUGH MY 2007
• TV ANTENNA 2, FROM MY 2008
• TV ANTENNA 2
• NAVIGATION SYSTEM ANTENNA/TELEPHONE ANTENNA
• ANTENNA SELECTION CONTROL MODULE
• SATELLITE ANTENNA
• ANTENNA AMPLIFIER
• CELLULAR TELEPHONE PREPARATION CONNECTORS, FROM MY 2009
• TELEPHONE TRANSCEIVER
• TELEPHONE BASEPLATE
• NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE
• CONNECTORS AND CONNECTOR ASSIGNMENTS
• RADIO/NAVIGATION DISPLAY CONTROL MODULE
• MULTI-FUNCTION BUTTONS
• TIPTRONIC SWITCH
• FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP
• SATELLITE RADIO, ENABLING
