Access/Start Authorization System Audi S8 D3 facelift

Electrical Equipment 4 illustrations ~847 words

Access/Start Authorization System

Observe notes on contact corrosion --> Contact Corrosion .

> Access/Start Authorization System, Component Overview

> Keyless Access Authorization System, Component Overview

> Keyless Access Authorization System Exterior Door Handle, Component Overview

> Front Door Handle Switch, Removing and Installing

> Rear Door Handle Switch, Removing and Installing

> Interior Access/Start Authorization Antenna 1, Removing and Installing

> Access/Start Authorization Control Module, Removing and Installing

> Interior Access/Start Authorization Antenna 2, Removing and Installing

> Interior Access/Start Authorization Antenna 3, Removing and Installing

> Luggage Compartment Access/Start Authorization Antenna, Removing and Installing

> Rear Bumper Access/Start Authorization Antenna, Removing and Installing

Scheme 343

Scheme 343: Access/Start Authorization System, Component Overview
Scheme 343: Access/Start Authorization System, Component Overview

1 - Access/Start Authorization Switch E415

  1. Component location: In instrument panel, drivers side
  2. Removing and installing --> «Access/Start Authorization Switch, Removing and Installing»(ref-289227-S24151845172008062700000)

2 - Access/Start Authorization Button E408 or Driver Identification Control Module J589

  1. Component location: In installation frame for Multimedia Control Head E380
  2. Removing and installing --> «Access/Start Authorization Button or Driver Identification Control Module, Removing and Installing»(ref-289227-S02682979982008062700000)

3 - Access/Start Control Module J518

  1. Component location: Under floor carpet beneath drivers seat
  2. Removing and installing --> «Access/Start Authorization Control Module, Removing and Installing»(ref-289227-S29648581722008062700000)

4 - Steering Column Lock Actuator N360

  1. Removing and installing --> «48 - STEERING»(ref-289219-S07076849872008062700000)

Scheme 344

Scheme 344: Keyless Access Authorization System, Component Overview
Scheme 344: Keyless Access Authorization System, Component Overview

1 - Interior Access/Start Authorization Antenna 1 R138

  1. Component location: Beneath front center console
  2. Removing and installing --> «Interior Access/Start Authorization Antenna 1, Removing and Installing»(ref-289227-S08155968062008062700000)

2 - Passengers side outside door handle

  1. Component overview --> «Keyless Access Authorization System Exterior Door Handle, Component Overview»(ref-289227-S15667483282008062700000)

3 - Interior Access/Start Authorization Antenna 2 R139

  1. Component location: Under floor carpet behind rear center console
  2. Removing and installing --> «Interior Access/Start Authorization Antenna 2, Removing and Installing»(ref-289227-S36353356612008062700000)

4 - Right rear outside door handle

  1. Component overview --> «Keyless Access Authorization System Exterior Door Handle, Component Overview»(ref-289227-S15667483282008062700000)

5 - Interior Access/Start Authorization Antenna 3 R154

  1. Component location: In center armrest at rear
  2. Removing and installing --> «Interior Access/Start Authorization Antenna 3, Removing and Installing»(ref-289227-S15891312872008062700000)

6 - Luggage Compartment Access/Start Authorization Antenna R137

  1. Component location: In luggage compartment, at top, under rear shelf
  2. Removing and installing --> «Luggage Compartment Access/Start Authorization Antenna, Removing and Installing»(ref-289227-S33422256792008062700000)

7 - Access/start authorization antenna (in rear bumper) R136

  1. Component location: On left and right on bumper
  2. Removing and installing --> «Rear Bumper Access/Start Authorization Antenna, Removing and Installing»(ref-289227-S33828145252008062700000)

8 - Rear left outer door handle

  1. Component overview --> «Keyless Access Authorization System Exterior Door Handle, Component Overview»(ref-289227-S15667483282008062700000)

9 - Drivers side outside door handle

  1. Component overview --> «Keyless Access Authorization System Exterior Door Handle, Component Overview»(ref-289227-S15667483282008062700000)

10 - Access/Start Control Module J518

  1. Component location: Under floor carpet beneath drivers seat
  2. Removing and installing --> «Access/Start Authorization Control Module, Removing and Installing»(ref-289227-S29648581722008062700000)

Scheme 345

Scheme 345: Keyless Access Authorization System Exterior Door Handle, Component Overview
Scheme 345: Keyless Access Authorization System Exterior Door Handle, Component Overview

1 - Cover

2 - Access/Start Authorization antennas

  1. Drivers Access/Start Authorization Antenna R134 , Front Passengers Access/Start Authorization Antenna R135
  2. Cannot be replaced separately
  3. Replacing outside door handle --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000)
  4. Rear Access/Start Authorization Antenna (on drivers side) R155 , Rear Access/Start Authorization Antenna (on front passengers side) R156
  1. Cannot be replaced separately
  2. Replacing outside door handle --> «58 - REAR DOORS, WINDOW REGULATORS»(ref-289221-S03652927722008062700000)

3 - Outside door handle switch

  1. Drivers Door Handle Switch F272 , Passengers' Door Handle Switch F273
  2. Removing and installing --> «Front Door Handle Switch, Removing and Installing»(ref-289227-S19286987022008062700000)
  3. Left Rear Door Handle Switch F274 , Right Rear Door Handle Switch F275
  4. Removing and installing --> «Rear Door Handle Switch, Removing and Installing»(ref-289227-S01872030382008062700000)

4 - Mounting bracket

5 - Lock Cylinder

  1. Only drivers side

6 - Outside door handle central locking button

  1. Drivers Outside Door Handle Central Locking Button E369 , Front Passengers Outside Door Handle Central Locking Button E370
  2. Cannot be replaced separately
  3. Replacing outside door handle --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000)
  4. Left Rear Outside Door Handle Central Locking Button E371 , Right Rear Outside Door Handle Central Locking Button E372
  1. Cannot be replaced separately
  2. Replacing outside door handle --> «58 - REAR DOORS, WINDOW REGULATORS»(ref-289221-S03652927722008062700000)

7 - Outside Door Handle Touch Sensor

  1. Drivers Outside Door Handle Touch Sensor G415 , Front Passengers Outside Door Handle Touch Sensor G416
  2. Cannot be replaced separately
  3. Replacing outside door handle --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000)
  4. Right Rear Outside Door handle Touch Sensor G418 , Left Rear Outside Door Handle Touch Sensor G417
  1. Cannot be replaced separately
  2. Replacing outside door handle --> «58 - REAR DOORS, WINDOW REGULATORS»(ref-289221-S03652927722008062700000)

Scheme 346

Scheme 346: Front Door Handle Switch, Removing and Installing
Scheme 346: Front Door Handle Switch, Removing and Installing

Removing

  1. Remove outside door handle --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000) .
  2. Remove mounting bracket --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000) .
  3. Carefully release the retaining clip - 2 - in the - direction of the arrow A - and remove the front door handle switch - 1 - from the bracket - 3 - - arrow B -.

Installing

Install in reverse order of removal, observing the following

  1. Install mounting bracket --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000) .
  2. Install outside door handle --> «57 - FRONT DOORS, CENTRAL LOCKING SYSTEM, WINDOW REGULATORS»(ref-289221-S06726041012008062700000) .
