Final drive unit 01R is allocated to automatic transmission 09E (all wheel drive).
Allocation. Refer to Code letters, ratios, capacities , Technical data
Location on final drive
Scheme 38
Code letters and date of manufacture (arrow -1-)
Final drive 01R (arrow -2-)
Final drive 01R (arrow -2-)
Scheme 39
Code letters and date of manufacture
Scheme 40
| Example | EYC | 27 | 08 | 02 |
|---|---|---|---|---|
| I | I | I | I | |
| I | I | I | I | |
| Code letters | Day | Month | Year (2002) of manufacture |
Additional data depends on manufacture.
Adjustment overview
Note. If repairs have been performed on the final drive it is only necessary to adjust the drive pinion or final drive set if components have been replaced which have a direct effect on the adjustments of the final drive. Refer to the following table to avoid unnecessary adjustments
| To be adjusted | |||
|---|---|---|---|
| Part replaced: ↓ | Ring gear "S1"+"S2" 1) Refer to Ring gear, adjusting | Drive pinion "S3" 1) via deviation "r" Refer to Drive pinion, adjusting | Check backlash Refer to Adjusting backlash |
| Final drive housing | X | X | X |
| Differential housing | X | X | |
| Tapered roller bearing for drive pinion | X | X | |
| Tapered roller bearing for differential | X | X | |
| Final drive set 2) | X | X | X |
| Cover for final drive | X | X | |
1) Shims; installation position. Refer to Position of shims .
2) Drive pinion and ring gear; only replace together.
