Rear Final Drive 0AR: Overview Audi S8 D3 facelift

Identification of rear final drive

Rear Final Drive 0AR is allocated to the following transmissions

1. 6-speed Manual Transmission 02X
2. 6 speed Manual Transmission 0A3
3. Automatic Transmission 09E All Wheel Drive (AWD)
4. Automatic Transmission 09L All Wheel Drive (AWD)

Allocation, Audi A4 2002 >, Cabriolet 2003 > --> Code letters, aggregate allocation, ratios, capacities, Audi A4 2002 >, Cabriolet 2003 >

Allocation, Audi A6 2005 > --> Code letters, aggregate allocation, ratios, capacities, Audi A6 2005 >

Allocation, Audi A8 2003 > --> Code letters, aggregate allocation, ratios, capacities, Audi A8 2004 >

Allocation at rear final drive

Scheme 99

Final Drive 0AR - arrow 1

Identification and date of construction - arrow 2

Final Drive 0AR - arrow

Scheme 100

Code letters and date of manufacture of rear final drive

Scheme 101

Further data can be ignored.

Power transfer, overview

1. Depicted with 6 speed manual transmission 0A3 All Wheel Drive.

Nomenclature

Note. Arrows in direction of travel

Scheme 102

1 - Engine

2 - Clutch

3 - Manual transmission

4 - Input shaft (main shaft)

5 - Front differential

6 - Front pinion shaft (output shaft)

7 - Hollow shaft

8 - Torsen differential

9 - Driveshaft

10 - Rear drive pinion

11 - Rear differential

Ratio

Note. Arrows in direction of travel

I - 1st Gear

II - 2nd Gear

III - 3rd Gear

IV - 4th Gear

V - 5th Gear

VI - 6th Gear

R - Reverse Gear

A1 - Final drive-front

A2 - Rear final drive

Driveshaft, servicing overview

Note. Observe general repair notes --> General Repair Notes . No repair work can be performed on the driveshaft - with the exception of removing and installing and adjustment work. Always store and transport driveshaft fully extended only. Driveshaft can be bent without force up to the center joint stop. A hard bending to the stop may cause damage to the center joint or dust boot. If the driveshaft is only detached at the transmission or from rear final drive, it should be tied up or supported at the shaft end. Driveshaft must also bend without force up to the center joint stop. Mark positions of all parts to each other before removing. Reinstall in identical position otherwise imbalance will be too high which could result in damage to the bearing or in vibration noises. Driveshaft bolts are loosened and tightened with the parking brake engaged. After disconnecting driveshaft from rear final drive, an installed balance washer (thick washer between backing plate and hex socket head bolt) may not be reinstalled. For complaints (noise, vibrations), check intermediate bearing for freedom from tension and radial run-out of driveshaft flange at rear final drive before replacing the driveshaft --> Measure radial play at flange/driveshaft and mark .

Scheme 103

1 - Rear final drive

1. Removing and installing Audi A4, Audi A6 --> «Rear final drive, removing and installing»(ref-289217-S36849510482008062700000)
2. Removing and installing Audi A8 --> «Rear final drive (Audi A8), removing and installing»(ref-289217-S42437064492008062700000)

2 - Gasket

1. Replace
2. Pull off protective foil
3. Remove grease from flange shaft and adhere seal.

3 - Driveshaft

1. Removing and installing Audi A4, Audi A6 --> «Driveshaft (Audi A4 and Cabriolet, Audi A6), removing and installing»(ref-289217-S24907373642008062700000)
2. Removing and installing Audi A8 --> «Driveshaft, removing and installing - Audi A8»(ref-289217-S07578264302008062700000)

4 - Balancing washer

1. Not present on every vehicle
2. If present, this balancing washer must no longer be installed after disconnecting driveshaft from rear final drive.

5 - Socket head bolt, 55 Nm

1. Self-locking
2. Always replace
3. Threaded holes for bolts in drive flanges must always be cleaned. (e.g. using a tap)
4. Loosened and tightened with parking brake engaged.

6 - Backing plate

7 - Intermediate bearing

8 - Hex bolt, 25 Nm

9 - Transmission
