Selector mechanism function unit, removing and installing
Removing
Scheme 335
- Loosen quick-release connectors - 1 - and - 2 - and remove sound insulation.
Scheme 336
- Remove cross member from subframe - arrows -.
| CAUTION | To prevent damage, decoupling element of the front exhaust pipes must never be angled by more than 10 °. |
Scheme 337
- Loosen clamping sleeves - 1 - and - 2 - and slide them forward.
Scheme 338
- Remove bolt - arrow - at left exhaust tract strap.
Scheme 339
- Remove bolt - arrow - at right exhaust tract strap.
Scheme 340
- Remove driveshaft heat shield - A - - arrows -.
Scheme 341
- Remove transmission/front driveshaft connecting bolts - arrows -.
Scheme 342
- Slide driveshaft back to rear final drive and tie up.
| CAUTION | For the following steps, notice: Do not support on transmission oil pan - risk of damage. |
Scheme 343
- Insert a bolt M12x100 - 1 - with attached nut - 2 - in mount behind transmission oil pan.
- Dimension - a - = 13 mm.
- Position Engine and Transmission Holder V.A.G 1383 A plunger on bolt head as shown in illustration.
Scheme 344
- Remove tunnel cross member bolts - arrows -.
Scheme 345
- Slightly lower tunnel cross member with transmission using Engine and Transmission Holder V.A.G 1383 A.
- Dimension - a - = max. 40 mm.
Note. Illustration without right front exhaust pipe, however, it does not have to be removed.
Scheme 346
- Remove four lock washers - 1 -.
Note. Always replace lock washers
- Remove sound insulation - 2 - and slide forward.
Scheme 347
- Unclip mounting frame for selector lever boot - 1 - from center console and lift it upward and off - arrows -.
Scheme 348
- Place selector lever in position "D".
- Through opening - arrow - in shift mechanism, loosen bolt on selector lever cable approx. one turn using Socket T40031.
Note. Only loosen clamping screw, do not remove. Clamping screw is only accessible in selector lever position "D". Selector lever must remain in position "D" while clamping screw is loose.
- Remove front center console - 1 - --> «68 - INTERIOR EQUIPMENT»(/audi/s6/c6-2006-2008/remont/gauges-instrument-panels/#body-interior)
Scheme 349
- Disconnect electrical connectors - 2 - and - 4 -.
- Remove bolts - 1 - , - 3 - , - 5 - and - 6 -.
Note. A second technician is required when detaching shift mechanism function unit below vehicle.
- Press retaining clamps - arrows - inward and lower selector mechanism function unit downward.
Scheme 350
- Remove selector lever cable retaining clip - 1 - sideways.
- Remove shift mechanism function unit downward and simultaneously remove selector lever cable - 2 -.
Installing
Install in reverse order of removal, note the following
Torque specifications --> Selector mechanism, servicing, assembly overview
Note. Lightly grease ball socket of selector lever cable with polycarbamide grease G 052 142 A2 before installing. Do not bend or kink the selector lever cable.
- Install tunnel cross member --> «Tunnel cross member, transmission mount and transmission support, assembly overview»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd) .
- Adjust selector lever cable --> «Selector lever cable, adjusting»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__selector-lever-cable-adjusting) .
- Install driveshaft to transmission --> «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#rear-final-drive-0ar)
- Reconnect exhaust system and ensure it is not under stress --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/s6/c6-2006-2008/remont/cooling-fan/#52l-10-cyl-4v-engine-mechanical-engine-codes-bxa) .
- Install front cross member --> «50 - BODY - FRONT»(/audi/s6/c6-2006-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
- Install front center console --> «68 - INTERIOR EQUIPMENT»(/audi/s6/c6-2006-2008/remont/gauges-instrument-panels/#body-interior) .
Scheme 351
1 - Clamp
- For securing handle to selector lever
- Removing and installing --> «Selector lever handle, removing and installing»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__selector-lever-handle-removing-and-installing)
2 - Trim ring
- Removing and installing --> «Separating selector lever boot from selector lever handle»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__separating-selector-lever-boot-from-selector)
3 - Selector lever handle
- > «Selector lever handle, removing and installing»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__selector-lever-handle-removing-and-installing)
4 - Selector lever boot
- > «Separating selector lever boot from selector lever handle»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__separating-selector-lever-boot-from-selector)
5 - Selector Lever Transmission Range (TR) Position Display Y26
- > «Selector Lever Transmission Range (TR) Position Display Y26 , removing and installing»(/audi/s6/c6-2006-2008/remont/differentials-drive-axles/#6-speed-automatic-transmission-09e-awd__selector-lever-transmission-range-tr-position)
