Interior Trim (Coupe): Overview Audi S5 I facelift

Exterior/interior Trim 28 illustrations ~2915 words

DOOR TRIM OVERVIEW

Note. The illustration shows the driver side door trim.

Scheme 1

Scheme 1: DOOR TRIM OVERVIEW
Scheme 1: DOOR TRIM OVERVIEW
  1. Entry Lamp Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  2. Bolt For armrest Quantity: 9 1.2 Nm
  3. Door Trim Removing and installing, refer to «DOOR TRIM»(ref-520145-S23436116942012123100000) Versions with storage compartment reinforcement The reinforcement must be installed when replacing the door trim. Refer to «DOOR TRIM STORAGE POCKET REINFORCEMENT»(ref-520145-S24286563752012123100000) NOTE: When replacing the door trim panel, a hole for the sleeve -7- must be made in the new panel using the old panel as a sample.
  4. Active/Passive Rear Reflector Vehicles with special equipment
  5. Interior Monitoring Switch -E183- /Alarm System Deactivation Switch -E217- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  6. Clip With seal For door trim Quantity: 8 WARNING: For proper crash sensor (pressure sensor) function, ensure door does not leak. The door trim clips seal the system. Replace the clips if necessary. Follow safety measures when working with front side airbag crash sensors (pressure sensors). Refer to «FRONT SIDE AIRBAG CRASH SENSORS, SAFETY PRECAUTIONS»(ref-520043-S22356198652012123100000) .
  7. Sleeve For the central locking -SAFE- indicator lamp -K133- Driver door only Central locking -SAFE- indicator lamp -K133-, Removing and Installing; refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000) NOTE: When replacing the door trim panel, a hole for the sleeve -7- must be made in the new panel using the old panel as a sample.
  8. Clips Quantity: 4 Press into the door trim
  9. Bolt For inside door release mechanism Quantity: 4 1.2 Nm
  10. Trim Panel Removing and installing, refer to «TRIM MOLDING»(ref-520145-S10103117802012123100000)
  11. Speaker Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(ref-520145-S36845936662012123100000)
  12. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(ref-520145-S30787388352012123100000)
  13. Switch Mount For the rear lid lock cylinder unlock button -F248- Driver door only Removing and installing, refer to «Rear Lid Remote Release Button -E233- SWITCH MOUNT»(ref-520145-S22750725862012123100000)
  14. Rear Lid Lock Cylinder Unlock Button -F248- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Interior Lights, Switches»(ref-520166-S24233765322012123100000)
  15. Speaker Trim For mid range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(ref-520145-S19803339962012123100000)
  16. Bolt For door trim 2.5 Nm
  17. Switch Trim Different versions For the driver interior locking button -E308- /driver memory seat control head -E97- Removing and installing, refer to «SWITCH TRIM»(ref-520145-S24408374562012123100000)
  18. Driver Seat Memory Program Control Head -E97- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  19. Driver Interior Locking Button -E308- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  20. Mirror Adjusting Switch -E43- or Folding Mirror Adjustment Switch -E168- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  21. Power Window Control Head In Driver Door -E512- Front passenger door window regulator switch -E107- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  22. Bolt For door trim 2.5 Nm
  23. Pull Handle With switch mount Removing and installing, refer to «PULL HANDLE WITH SWITCH MOUNT»(ref-520145-S16546425912012123100000)
  24. Armrest Removing and installing, refer to «ARMREST»(ref-520145-S41228662012012123100000)
  25. Bolt For pull handle Quantity: 6 1.2 Nm
  26. Bolt For door trim 2.5 Nm

Scheme 2

Scheme 2
Scheme 2

Tighten the bolts -1, 2, 3 and 5- to 1.3 Nm

Finally, tighten the bolt -4- in the 16 mm hole to 1.3 Nm.

Scheme 3

Scheme 3: INSTRUMENT PANEL OVERVIEW
Scheme 3: INSTRUMENT PANEL OVERVIEW
  1. Center Console Assembly overview, refer to «CENTER CONSOLE OVERVIEW»(ref-520128-S00055316292012123100000) Removing and installing, refer to «CENTER CONSOLE»(ref-520128-S35702320882012123100000)
  2. Driver Side Instrument Panel Cover Assembly overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW»(ref-520128-S17866097422012123100000) Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-520128-S41722069782012123100000)
  3. Trim For steering column switch module Assembly overview, refer to «STEERING COLUMN SWITCH MODULE TRIM OVERVIEW»(ref-520128-S24509341792012123100000) Upper trim, removing and installing «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-520128-S37635119162012123100000) Lower trim, removing and installing «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-520128-S08100018642012123100000)
  4. Central Tube For instrument panel Assembly overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(ref-520145-S11111366302012123100000) Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-520145-S17622673112012123100000)
  5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(ref-520043-S07728518712012123100000) . Assembly overview, refer to «INSTRUMENT PANEL OVERVIEW»(ref-520145-S24796464022012123100000) Removing and installing, refer to «INSTRUMENT PANEL»(ref-520145-S34999297862012123100000)
  6. Glove Compartment Assembly overview, refer to «GLOVE COMPARTMENT OVERVIEW»(ref-520128-S06825610822012123100000) Removing and installing, refer to «GLOVE COMPARTMENT»(ref-520128-S03222408832012123100000)
  7. Front Center Armrest Assembly overview, refer to «FRONT CENTER ARMREST OVERVIEW»(ref-520128-S25214478642012123100000) Removing and installing, refer to «FRONT CENTER ARMREST»(ref-520128-S42044992392012123100000)

Scheme 4

Scheme 4: INSTRUMENT PANEL OVERVIEW
Scheme 4: INSTRUMENT PANEL OVERVIEW
  1. Bolt Quantity: 3 1.5 Nm
  2. Light Switch -E1- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  3. Headlamp Range Control Adjuster -E102- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  4. Bolt Quantity: 6 3 Nm
  5. Mounting Bracket For instrument cluster Removing and installing, refer to «INSTRUMENT CLUSTER MOUNTING FRAME»(ref-520145-S21224657782012123100000)
  6. Left Side Instrument Panel Vent Removing and Installing, refer to «SIDE INSTRUMENT PANEL VENT»(ref-520145-S13594920832012123100000)
  7. Bolt Quantity: 2 3 Nm
  8. Bolt Quantity: 2 3 Nm
  9. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the speaker trim from shearing off.
  10. Mount For speaker Removing and installing, refer to «SPEAKER MOUNT»(ref-520145-S37701547712012123100000)
  11. Mid-Range Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  12. Side Speaker Trim Vehicles with special equipment Removing and installing, refer to «SIDE SPEAKER TRIM»(ref-520145-S02500416982012123100000)
  13. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the defroster vent from shearing off.
  14. Sunlight Photo Sensor -G107- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520155-S05340899682012123100000)
  15. Center Speaker Trim Vehicles with special equipment Removing and installing, refer to «CENTER SPEAKER TRIM»(ref-520145-S01960388242012123100000)
  16. Upper Center Defroster Vent Removing and installing, refer to «TOP CENTER DEFROSTER VENT»(ref-520145-S04050647482012123100000)
  17. Mid-Range Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  18. Upper Side Defroster Vent
  19. Bolt Quantity: 2 3 Nm
  20. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(ref-520043-S07728518712012123100000) . Follow the allocation of the airbag to the instrument panel, Removing and installing, refer to «INSTRUMENT PANEL»(ref-520145-S34999297862012123100000)
  21. Right Side Instrument Panel Vent Removing and Installing, refer to «SIDE INSTRUMENT PANEL VENT»(ref-520145-S13594920832012123100000)
  22. Passenger Airbag WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(ref-520043-S07728518712012123100000) . Follow the allocation of the airbag to the instrument panel. Assembly overview, refer to «PASSENGER AIRBAG OVERVIEW»(ref-520043-S09604799932012123100000) Locking and activating possible with key switch Removing and installing, refer to «FRONT PASSENGER AIRBAG UNIT WITH IGNITERS -N131- / -N132»(ref-520043-S12520410372012123100000)
  23. Nut For the correct tightening specifications, refer to «PASSENGER AIRBAG OVERVIEW»(ref-520043-S09604799932012123100000)
  24. Bolt 3 Nm
  25. MMI Screen Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  26. Cover For MMI screen Removing and installing, refer to «MMI SCREEN»(ref-520145-S35505149382012123100000)
  27. Center Instrument Panel Vent Removing and installing, refer to «CENTER INSTRUMENT PANEL VENT»(ref-520145-S20652337942012123100000)
  28. Radio/Navigation System Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000) Installation frame, removing and installing «RADIO AND NAVIGATION SYSTEM FRAME»(ref-520145-S09239505492012123100000)
  29. Front Information Display Control Head Control Module -J523- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  30. Bolt For the correct tightening specifications, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  31. Climatronic Control Module -J255- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520156-S32785734962012123100000)
  32. Bolt Tightening torque specification, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520042-S16151586192012123100000) .
  33. Bolt 3 Nm
  34. Trim For Access/Start Authorization Switch -E415- Removing and installing, refer to «Access/Start Authorization Switch -E415-, TRIM PANEL»(ref-520145-S02432046952012123100000)
  35. Access/Start Authorization Switch -E415- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520178-S05006081052012123100000)
  36. Instrument Cluster Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520042-S16151586192012123100000)
  37. Light Switch Trim Removing and installing, refer to «LIGHT SWITCH TRIM»(ref-520145-S03445124822012123100000)

Scheme 5

Scheme 5: INSTRUMENT PANEL CENTRAL TUBE OVERVIEW
Scheme 5: INSTRUMENT PANEL CENTRAL TUBE OVERVIEW
  1. Bracket Removing and installing, refer to «MOUNTING BRACKET»(ref-520145-S35407840252012123100000)
  2. Bolt Quantity: 4 20 Nm
  3. Bolt 3.6 Nm
  4. Bolt 20 Nm
  5. Central Tube For instrument panel Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-520145-S17622673112012123100000)
  6. Threaded Pin 20 Nm
  7. Nut Replace 20 Nm
  8. Bracket For the air intake chamber
  9. Bolt Quantity: 2 9 Nm
  10. Bolt Quantity: 2 3.6 Nm
  11. Bolt Quantity: 2 9 Nm
  12. Bracket For the glove compartment
  13. Bolt Quantity: 2 20 Nm
  14. Bolt Quantity: 2 20 Nm
  15. Bolt Quantity: 2 9 Nm
  16. Bracket For the instrument panel cover
  17. Nut Replace 20 Nm
  18. Threaded Pin 20 Nm
  19. Bolt 20 Nm
  20. Bolt Quantity: 2 20 Nm

Scheme 6

Scheme 6: IMPACT ABSORBER, KNEE AIRBAG AND GLOVE COMPARTMENT OVERVIEW
Scheme 6: IMPACT ABSORBER, KNEE AIRBAG AND GLOVE COMPARTMENT OVERVIEW
  1. Bolt Quantity: 2 9 Nm
  2. Left Retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG LEFT BRACKET»(ref-520043-S00630608422012123100000)
  3. Central Tube
  4. Right Retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG RIGHT BRACKET»(ref-520043-S39382738182012123100000)
  5. Bolt Quantity: 2 9 Nm
  6. Bolt Quantity: 2 9 Nm
  7. Bolt 9 Nm
  8. Right Retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(ref-520145-S31407928192012123100000)
  9. Bolt 9 Nm
  10. Left Retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(ref-520145-S31407928192012123100000)
  11. Bolt Quantity: 2 9 Nm
  12. Left Retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG LEFT BRACKET»(ref-520043-S17846757002012123100000)
  13. Grommet Installed on the impact absorber -15
  14. Bolt For the correct tightening specifications, refer to «Steering»(ref-520044-S32948538592012123100000)
  15. Right Shock Absorber Removing and installing, refer to «RIGHT IMPACT ABSORBER»(ref-520145-S21521925152012123100000)
  16. Bolt 9 Nm
  17. Bolt 9 Nm
  18. Left Shock Absorber Removing and installing, refer to «LEFT IMPACT ABSORBER»(ref-520145-S19033564602012123100000)
  19. Bolt Quantity: 2 9 Nm
  20. Bolt Quantity: 2 9 Nm
  21. Right Retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG RIGHT BRACKET»(ref-520043-S04645272842012123100000)

Scheme 7

Scheme 7: A-PILLAR UPPER TRIM OVERVIEW
Scheme 7: A-PILLAR UPPER TRIM OVERVIEW
  1. Clamps Install in the trim Replace if damaged or deformed
  2. Bolt 3.5 Nm Always replace if removed Threaded screw holes must always be cleaned (for example, with thread cutter)
  3. Cover With the "Airbag" symbol Carefully unclip Hangs from trim and cannot be detached
  4. Upper A-Pillar Trim Removing and installing, refer to «A-PILLAR UPPER TRIM»(ref-520145-S34369106902012123100000)

Scheme 8

Scheme 8: A-PILLAR LOWER TRIM OVERVIEW
Scheme 8: A-PILLAR LOWER TRIM OVERVIEW
  1. Clips Install in the trim Replace if damaged or deformed
  2. Hood Release Lever For the cable Driver side only Removing and installing, refer to «CABLE OPERATING LEVER»(ref-520145-S22577312172012123100000)
  3. Bolt 2.5 Nm Driver side only
  4. A-Pillar Lower Trim Removing and installing, refer to «A-PILLAR LOWER TRIM»(ref-520145-S40410843332012123100000)

Scheme 9

Scheme 9: B-PILLAR TRIM OVERVIEW
Scheme 9: B-PILLAR TRIM OVERVIEW
  1. B-Pillar Trim Removing and installing, refer to «B-PILLAR TRIM»(ref-520145-S08525578032012123100000)
  2. Coat Hook
  3. Bolt 1 Nm
  4. B-Pillar Trim Removing and installing, refer to «B-PILLAR TRIM PANEL»(ref-520145-S12593761152012123100000)
  5. Belt Extraction Panel Removing and installing, refer to «BELT EXTRACTION PANEL»(ref-520145-S23822330362012123100000)
  6. Bolt Quantity: 2 4.5 Nm Always replace if removed Threaded screw holes must always be cleaned (for example, with thread cutter)

Scheme 10

Scheme 10: C-PILLAR TRIM OVERVIEW
Scheme 10: C-PILLAR TRIM OVERVIEW
  1. Trim For the sunshade guide Vehicles with special equipment
  2. Clips Quantity: 2 Install in the trim Replace if damaged or deformed
  3. Expanding Clip With the "Airbag" symbol Carefully unclip Hangs from trim and cannot be detached
  4. C-Pillar Trim Vehicles with special equipment Removing and installing, refer to «C-PILLAR TRIM»(ref-520145-S12662349382012123100000)

Scheme 11

Scheme 11: FOOTREST AND FLOOR COVERING OVERVIEW
Scheme 11: FOOTREST AND FLOOR COVERING OVERVIEW
  1. Driver Side Instrument Panel Cover
  2. Clips Insert in the footrest
  3. Footrest The footrest is destroyed during removal and must be replaced. Removing and installing, refer to «FOOTREST»(ref-520145-S16171591642012123100000)
  4. A-Pillar Lower Trim
  5. Carpet One piece Removing and installing, refer to «FLOOR COVERING»(ref-520145-S41328961392012123100000)

Scheme 12

Scheme 12: SIDE TRIM PANEL OVERVIEW
Scheme 12: SIDE TRIM PANEL OVERVIEW
  1. Trim For the mid-range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(ref-520145-S28855703452012123100000)
  2. Trim Panel Removing and installing, refer to «TRIM MOLDING»(ref-520145-S23628001742012123100000)
  3. Clips Quantity: 4 Press into the side trim
  4. Clips Quantity: 8 Insert into the side trim Replace if damaged or deformed
  5. Treble Speaker Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  6. Clip With seal For the side trim Quantity: 3 Replace if damaged
  7. Insulation
  8. Side Trim Removing and installing, refer to «SIDE TRIM»(ref-520145-S16927222042012123100000)
  9. Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(ref-520145-S04920894402012123100000)

Scheme 13

Scheme 13: SILL PANEL OVERVIEW
Scheme 13: SILL PANEL OVERVIEW
  1. Sill Panel Strip Removing and installing, refer to «SILL PANEL»(ref-520145-S33041791522012123100000)
  2. Centering Pin
  3. Clips Quantity: 3 Insert in the sill panel strip Replace if damaged or deformed

Scheme 14

Scheme 14: REAR SHELF OVERVIEW
Scheme 14: REAR SHELF OVERVIEW
  1. Clips Quantity: 4 Insert in the rear shelf Replace if damaged or deformed
  2. Rear Shelf Optional equipment: Without sun shade With sun shade Engaged in the rear window frame Removing and installing, refer to «REAR SHELF»(ref-520145-S36087594602012123100000)
  3. Cover Vehicles with special equipment Removing and installing, refer to «CAP»(ref-520145-S07549324582012123100000)
  4. Bolt Quantity: 4 2 Nm
  5. Speaker Trim Vehicles with special equipment Removing and installing, refer to «SPEAKER TRIM»(ref-520145-S31568772462012123100000)
  6. Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  7. Bolt Quantity: 4 For the correct tightening specifications, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)

Scheme 15

Scheme 15
Scheme 15

Vehicles equipped with an additional fastener: tighten the screw -arrow- with 2 Nm.

Scheme 16

Scheme 16
Scheme 16

Vehicles equipped with an additional fastener: tighten screw -2- for spacer -1- with 2 Nm.

  1. The pin -arrow- must engage the hole on the body.

Scheme 17

Scheme 17: SUN SHADE OVERVIEW
Scheme 17: SUN SHADE OVERVIEW
  1. Bolt Quantity: 4 2 Nm
  2. Front of the Rear Shelf Vehicles with special equipment Removing and installing, refer to «REAR SHELF»(ref-520145-S36087594602012123100000)
  3. Sun Shade Vehicles with special equipment Removing and installing, refer to «SUN SHADE»(ref-520145-S12786800842012123100000)
  4. Bolt Quantity: 4 2.3 Nm
  5. Bolt Quantity: 2 2.3 Nm
  6. Bracket For the guide strip
  7. Guide Strip Removing and installing, refer to «SUN SHADE»(ref-520145-S12786800842012123100000)
  8. Rear Shelf Rear Section Vehicles with special equipment Engaged in the rear window frame Removing and installing, refer to «SUN SHADE»(ref-520145-S12786800842012123100000)
  9. Trim For the rear shelf rear section
  10. Nut Quantity: 5 3 Nm

Scheme 18

Scheme 18: TRIM OVERVIEW
Scheme 18: TRIM OVERVIEW
  1. C-Pillar Trim Assembly overview, refer to «C-PILLAR TRIM OVERVIEW»(ref-520145-S14726272352012123100000) Removing and installing, refer to «C-PILLAR TRIM»(ref-520145-S12662349382012123100000)
  2. Side Trim Assembly overview, refer to «SIDE TRIM PANEL OVERVIEW»(ref-520145-S38076281402012123100000) Removing and installing, refer to «SIDE TRIM»(ref-520145-S16927222042012123100000)
  3. B-Pillar Trim Assembly overview, refer to «B-PILLAR TRIM OVERVIEW»(ref-520145-S19904476162012123100000) Removing and installing, refer to «B-PILLAR TRIM PANEL»(ref-520145-S12593761152012123100000)
  4. Sill Panel Strip Assembly overview, refer to «SILL PANEL OVERVIEW»(ref-520145-S08203718432012123100000) Removing and installing, refer to «SILL PANEL»(ref-520145-S33041791522012123100000)
  5. Upper A-Pillar Trim Assembly overview, refer to «A-PILLAR UPPER TRIM OVERVIEW»(ref-520145-S00513744632012123100000) Removing and installing, refer to «A-PILLAR UPPER TRIM»(ref-520145-S34369106902012123100000)
  6. A-Pillar Lower Trim Assembly overview, refer to «A-PILLAR LOWER TRIM OVERVIEW»(ref-520145-S18786781392012123100000) Removing and installing, refer to «A-PILLAR LOWER TRIM»(ref-520145-S40410843332012123100000)
  7. Footrest/Floor Covering Assembly overview, refer to «FOOTREST AND FLOOR COVERING OVERVIEW»(ref-520145-S42620511552012123100000) Removing and installing «FOOTREST»(ref-520145-S16171591642012123100000) Remove and install the floor covering «FLOOR COVERING»(ref-520145-S41328961392012123100000)
  8. Rear Shelf Versions without sun shade, assembly overview «REAR SHELF OVERVIEW»(ref-520145-S07322660402012123100000) Removing and installing, refer to «REAR SHELF»(ref-520145-S36087594602012123100000)

Scheme 19

Scheme 19: LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW
Scheme 19: LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW
  1. Luggage Compartment Floor Covering Removing and installing, refer to «LUGGAGE COMPARTMENT LINER»(ref-520145-S29619935932012123100000)
  2. Bracket For the luggage compartment floor mat Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR MAT BRACKET»(ref-520145-S27206946052012123100000)
  3. Mounting Bracket For luggage compartment floor covering retainer
  4. Frame For rear panel sill Removing and installing, refer to «REAR PANEL SILL FRAME»(ref-520145-S30137624802012123100000)
  5. Nut For spare wheel mounting When tightening, it must audibly click into place, otherwise, turn some more
  6. Cover For the vehicle tool kit
  7. Vehicle Tool Kit Vehicles with special equipment

Scheme 20

Scheme 20: LUGGAGE COMPARTMENT SIDE TRIM OVERVIEW
Scheme 20: LUGGAGE COMPARTMENT SIDE TRIM OVERVIEW
  1. Clips Quantity: 3 Install in the trim Replace if damaged or deformed
  2. Expanding Clip
  3. Bolt Quantity: 2 6 Nm
  4. Tie-Down Eye Removing and installing, refer to «TIE-DOWNS»(ref-520145-S07188912282012123100000)
  5. Luggage Compartment Side Trim Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(ref-520145-S10239312372012123100000)

Scheme 21

Scheme 21
Scheme 21

Versions with retaining hooks: tighten the screws -arrows- to 1.5 Nm.

Scheme 22

Scheme 22: LUGGAGE COMPARTMENT TRIM OVERVIEW
Scheme 22: LUGGAGE COMPARTMENT TRIM OVERVIEW
  1. Rear Cross Panel Trim Assembly overview, refer to «REAR CROSS PANEL TRIM OVERVIEW»(ref-520145-S29627754772012123100000) Removing and installing, refer to «REAR CROSS PANEL TRIM»(ref-520145-S19725903232012123100000)
  2. Rear Lid Trim Assembly overview, refer to «REAR LID TRIM OVERVIEW»(ref-520145-S41179764422012123100000) Removing and installing, refer to «REAR LID TRIM»(ref-520145-S02239923442012123100000)
  3. Luggage Compartment Side Trim Assembly overview, refer to «LUGGAGE COMPARTMENT SIDE TRIM OVERVIEW»(ref-520145-S40745884992012123100000) Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(ref-520145-S10239312372012123100000)
  4. Luggage Compartment Floor Covering Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW»(ref-520145-S42748657392012123100000) Removing and installing, refer to «LUGGAGE COMPARTMENT LINER»(ref-520145-S29619935932012123100000)
  5. Frame For rear panel sill Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW»(ref-520145-S42748657392012123100000) Removing and installing, refer to «REAR PANEL SILL FRAME»(ref-520145-S30137624802012123100000)

Scheme 23

Scheme 23: REAR CROSS PANEL TRIM OVERVIEW
Scheme 23: REAR CROSS PANEL TRIM OVERVIEW
  1. Rear Cross Panel Trim Removing and installing, refer to «REAR CROSS PANEL TRIM»(ref-520145-S19725903232012123100000)
  2. Clips Quantity: 4 Install in the trim Replace if damaged or deformed

Scheme 24

Scheme 24: REAR LID TRIM OVERVIEW
Scheme 24: REAR LID TRIM OVERVIEW
  1. Trim For rear lid lock Removing and installing, refer to «REAR LID LATCH TRIM PANEL»(ref-520145-S16536342072012123100000)
  2. Trim For the rear lid Removing and installing, refer to «REAR LID TRIM»(ref-520145-S02239923442012123100000)
  3. Stop Strip Clipped into the rear lid
  4. Clips Quantity: 11 Install in the trim Replace if damaged or deformed
  5. Intermediate Piece
  6. Wiring Guide
  7. Bolt 1.8 Nm
  8. Warning Triangle
  9. Bracket For the warning triangle Removing and installing, refer to «WARNING TRIANGLE BRACKET»(ref-520145-S08063976272012123100000)

Scheme 25

Scheme 25: HEADLINER OVERVIEW
Scheme 25: HEADLINER OVERVIEW
  1. Bolt 1.6 Nm
  2. Headliner Optional equipment: Without a sunroof With sunroof Removing and installing, refer to «HEADLINER»(ref-520145-S26062472542012123100000) CAUTION: The headliner bends easily. Replace the headliner if it is bent.
  3. Cover Frame The marking points to the rear of the vehicle
  4. Deformation Elements Versions for specific countries: Self-adhesive On the markings onto the headliner and press firmly
  5. Limiting Strap Replace if damaged
  6. Clamps Insert in the headliner Replace if damaged or deformed
  7. Limiting Strap Replace if damaged
  8. Clamps Quantity: 15 Insert in the headliner Replace if damaged or deformed Release «HEADLINER =>»(ref-520145-S26062472542012123100000)

Scheme 26

Scheme 26
Scheme 26
  1. Installed location: on the left and right sides above the windshield.
  1. Deformation element
  2. Bolt - 3 Nm
  3. Bolt - 3 Nm

Scheme 27

Scheme 27: ROOF TRIM OVERVIEW
Scheme 27: ROOF TRIM OVERVIEW
  1. Interior Light/Front Reading Light Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  2. Sun Visor Assembly overview, refer to «SUN VISORS OVERVIEW»(ref-520145-S02204996682012123100000) Removing and installing, refer to «SUN VISOR»(ref-520145-S15338567882012123100000)
  3. Interior Light/Rear Reading Light Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520166-S39646063012012123100000)
  4. Headliner Optional equipment: Without a sunroof With sunroof Assembly overview, refer to «HEADLINER OVERVIEW»(ref-520145-S17634698712012123100000) Removing and installing, refer to «HEADLINER»(ref-520145-S26062472542012123100000) CAUTION: The headliner bends easily. Replace the headliner if it is bent.

Scheme 28

Scheme 28: SUN VISORS OVERVIEW
Scheme 28: SUN VISORS OVERVIEW
  1. Expanding Cap Clipped into the sun visor
  2. Connector Vehicles with special equipment
  3. Center Bracket For the sun visor Removing and installing, refer to «SUN VISOR CENTER BRACKET»(ref-520145-S08528596032012123100000)
  4. Cover Clipped into the sun visor center bracket
  5. Sun Visor Removing and installing, refer to «SUN VISOR»(ref-520145-S15338567882012123100000)

More articles — Interior Trim (Coupe)
