Interior Trim (Cabriolet): Overview Audi S5 I facelift

DOOR TRIM ASSEMBLY OVERVIEW

Note. The illustration shows the driver side door trim.

Scheme 136

1. Entry Lamp Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
2. Bolt For armrest Quantity: 9 1.2 Nm
3. Door Trim Removing and installing, refer to «DOOR TRIM»(ref-522378-S21557747482013011400000) When replacing the door trim panel, a hole for the sleeve -7- must be made in the new panel using the old panel as a sample.
4. Active/Passive Rear Reflector
5. Passenger Compartment Monitoring Switch -E183- /Alarm System -Off- Switch -E217- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
6. Retaining Clip With seal For door trim Quantity: 8 WARNING: For proper crash sensor (pressure sensor) function, ensure door does not leak. The door trim panel clips seal the system. Replace the clips, if necessary. Follow safety measures when working with front side airbag crash sensors (pressure sensors), refer to «FRONT SIDE AIRBAG CRASH SENSORS SAFETY PRECAUTIONS»(ref-522301-S13746133242013011400000) .
7. Sleeve Driver door only For the central locking -SAFE- indicator lamp -K133- Central locking -SAFE- indicator lamp -K133-, Removing and Installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000) when replacing the door trim panel, a hole for the sleeve must be made in the new panel using the old panel as a sample
8. Clips Quantity: 4 press into the door trim
9. Bolt For inside door release mechanism Quantity: 4 1.2 Nm
10. Trim Panel Removing and installing, refer to «TRIM MOLDING»(ref-522378-S42317841302013011400000)
11. Speaker Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(ref-522378-S27414980522013011400000)
12. Lane Change Assistance Button -E530- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
13. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(ref-522378-S11311070432013011400000)
14. Speaker Trim For mid range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(ref-522378-S02624099102013011400000)
15. Bolt For door trim 2.5 Nm
16. Switch Trim Different versions For the driver interior locking button -E308- /driver seat memory program control head -E97- Removing and installing, refer to «SWITCH TRIM»(ref-522378-S02276522742013011400000)
17. Driver Seat Memory Program Control Head -E97- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
18. Driver Interior Locking Button -E308- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
19. Idle speed variation switch -E43- or mirror (with fold-away function) switch -E168- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
20. Power window control head in driver door -E512- Window Regulator Switch (in RF door) -E107- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
21. Bolt For door trim 2.5 Nm
22. Pull handle With switch mount Removing and installing, refer to «PULL HANDLE WITH SWITCH MOUNT»(ref-522378-S17120037602013011400000)
23. Armrest Removing and installing, refer to «ARMREST»(ref-522378-S04026873802013011400000)
24. Bolt For pull handle Quantity: 6 1.2 Nm
25. Bolt For door trim 2.5 Nm

Scheme 137

1. Center Console Assembly overview, refer to «CENTER CONSOLE ASSEMBLY OVERVIEW»(ref-522367-S24195934402013011400000) Removing and installing, refer to «CENTER CONSOLE»(ref-522367-S27348856052013011400000)
2. Driver side instrument panel cover Assembly overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW»(ref-522367-S26960356962013011400000) Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-522367-S19242479642013011400000)
3. Trim For steering column switch module Assembly overview, refer to «STEERING COLUMN SWITCH MODULE TRIM ASSEMBLY OVERVIEW»(ref-522367-S19309314852013011400000) Upper trim, removing and installing «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-522367-S20097306822013011400000) Lower trim, removing and installing «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-522367-S05868427522013011400000)
4. Central Tube For instrument panel Assembly overview, refer to «INSTRUMENT PANEL CENTRAL TUBE ASSEMBLY OVERVIEW»(ref-522378-S41004480342013011400000) Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-522378-S35885578502013011400000)
5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Assembly overview, refer to «INSTRUMENT PANEL ASSEMBLY OVERVIEW»(ref-522378-S33709824812013011400000) Removing and installing, refer to «INSTRUMENT PANEL»(ref-522378-S27850286942013011400000)
6. Glove compartment Assembly overview, refer to «GLOVE COMPARTMENT ASSEMBLY OVERVIEW»(ref-522367-S10553116422013011400000) Removing and installing, refer to «GLOVE COMPARTMENT»(ref-522367-S08818831782013011400000)
7. Front Center Armrest Assembly overview, refer to «FRONT CENTER ARMREST ASSEMBLY OVERVIEW»(ref-522367-S42178315902013011400000) Removing and installing, refer to «FRONT CENTER ARMREST»(ref-522367-S11333072982013011400000)

Scheme 138

1. Bolt Quantity: 3 1.5 Nm
2. Light Switch -E1- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
3. Headlamp Adjuster -E102- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522393-S11411705592013011400000)
4. Bolt Quantity: 6 3 Nm
5. Mounting Bracket For instrument cluster Removing and installing, refer to «INSTRUMENT CLUSTER MOUNTING FRAME»(ref-522378-S19790845472013011400000)
6. Left Side Instrument Panel Vent Removing and installing, refer to «SIDE INSTRUMENT PANEL VENT»(ref-522378-S35807593452013011400000)
7. Bolt Quantity: 2 3 Nm
8. Bolt Quantity: 2 3 Nm
9. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the speaker trim from shearing off.
10. Mount For speaker Removing and installing, refer to «SPEAKER MOUNT»(ref-522378-S34710890952013011400000)
11. Mid-Range Speaker Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
12. Side Speaker Trim Removing and installing, refer to «SIDE SPEAKER TRIM»(ref-522378-S17383614142013011400000)
13. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the defroster vent from shearing off.
14. Sunlight Photo Sensor -G107- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522391-S30059042062013011400000)
15. Center Speaker Trim Removing and installing, refer to «CENTER SPEAKER TRIM»(ref-522378-S10834886362013011400000)
16. Upper Center Defroster Vent Removing and installing, refer to «TOP CENTER DEFROSTER VENT»(ref-522378-S17725165982013011400000)
17. Mid-Range Speaker Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
18. Upper side defroster vent
19. Bolt Quantity: 2 3 Nm
20. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Follow the allocation of the airbag to the instrument panel. Removing and installing, refer to «INSTRUMENT PANEL»(ref-522378-S27850286942013011400000)
21. Right Side Instrument Panel Vent Removing and installing, refer to «SIDE INSTRUMENT PANEL VENT»(ref-522378-S35807593452013011400000)
22. Passenger Airbag WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Follow the allocation of the airbag to the instrument panel. Assembly overview, refer to «PASSENGER AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S17684066242013011400000) Removing and installing, refer to «Front Passenger Airbag Igniter 1 -N131- /Front Passenger Airbag Igniter 2 -N132»(ref-522301-S33542277082013011400000)
23. Nut Tightening specification «PASSENGER AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S17684066242013011400000)
24. Bolt 3 Nm
25. Mmi Screen Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
26. Cover For MMI screen Removing and installing, refer to «MMI SCREEN»(ref-522378-S42367621562013011400000)
27. Center Instrument Panel Vent Removing and installing, refer to «CENTER INSTRUMENT PANEL VENT»(ref-522378-S18716622422013011400000)
28. Radio/Navigation System Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000) Installation Frame, Removing and Installing «RADIO AND NAVIGATION SYSTEM FRAME»(ref-522378-S42892694302013011400000)
29. Front Information Display Control Head Module -J523- Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
30. Bolt Tightening specification, refer to «Specifications»(ref-522368-S33570978082013011400000)
31. Climatronic Control Module -J255- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522392-S04313248462013011400000)
32. Bolt Tightening specification, refer to «[For engine(s) CAEB, CCBA] Specifications»(ref-522300-S42719821902013011400000) .
33. Bolt 3 Nm
34. Trim For Access/Start Authorization Switch -E415- Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH TRIM PANEL»(ref-522378-S12376191712013011400000)
35. Access/Start Authorization Switch -E415- Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522407-S06691430902013011400000)
36. Instrument Cluster Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522300-S03756685252013011400000)
37. Light Switch Trim Removing and installing, refer to «LIGHT SWITCH TRIM»(ref-522378-S36208934102013011400000)

Scheme 139

1. Bracket Removing and installing, refer to «MOUNTING BRACKET»(ref-522378-S20678260272013011400000)
2. Bolt Quantity: 4 20 Nm
3. Bolt 3.6 Nm
4. Bolt 20 Nm
5. Central Tube For instrument panel Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-522378-S35885578502013011400000)
6. Threaded pin Quantity: 2 20 Nm
7. Nut Quantity: 2 Always replace if removed 20 Nm
8. Bracket For the air intake chamber
9. Bolt Quantity: 2 9 Nm
10. Bracket For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(ref-522378-S34787871022013011400000)
11. Bolt Quantity: 2 9 Nm
12. Bolt Quantity: 2 3.6 Nm
13. Bolt Quantity: 2 9 Nm
14. Bracket For the glove compartment
15. Bolt Quantity: 4 22 Nm
16. Bolt Quantity: 2 9 Nm
17. Bracket For the instrument panel cover
18. Bolt Quantity: 2 20 Nm
19. Bolt 20 Nm

Scheme 140

1. Bolt Quantity: 2 9 Nm
2. Left retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG LEFT BRACKET»(ref-522301-S26637444702013011400000)
3. Central Tube
4. Right retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG RIGHT BRACKET»(ref-522301-S12003163112013011400000)
5. Bolt Quantity: 2 9 Nm
6. Bolt Quantity: 2 9 Nm
7. Bolt 9 Nm
8. Right retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(ref-522378-S34787871022013011400000)
9. Bolt 9 Nm
10. Left retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(ref-522378-S34787871022013011400000)
11. Bolt Quantity: 2 9 Nm
12. Left retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG LEFT BRACKET»(ref-522301-S42256997202013011400000)
13. Grommet Installed on the impact absorber -15
14. Bolt 9 Nm
15. Right shock absorber Removing and installing, refer to «RIGHT IMPACT ABSORBER»(ref-522378-S10456581132013011400000)
16. Bolt 9 Nm
17. Bolt 9 Nm
18. Left shock absorber Removing and installing, refer to «LEFT IMPACT ABSORBER»(ref-522378-S21571954362013011400000)
19. Bolt Quantity: 2 9 Nm
20. Bolt Quantity: 2 9 Nm
21. Right retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG RIGHT BRACKET»(ref-522301-S14359740172013011400000)

Scheme 141

1. Side Trim Assembly overview, refer to «SIDE TRIM ASSEMBLY OVERVIEW»(ref-522378-S25849096632013011400000) Removing and installing, refer to «SIDE TRIM»(ref-522378-S41028868192013011400000)
2. Sill Panel Strip Assembly overview, refer to «SILL PANEL ASSEMBLY OVERVIEW»(ref-522378-S33950180792013011400000) Removing and installing, refer to «SILL PANEL»(ref-522378-S40434780242013011400000)
3. A-Pillar Lower Trim Assembly overview, refer to «LOWER A-PILLAR TRIM ASSEMBLY OVERVIEW»(ref-522378-S03598942882013011400000) Removing and installing, refer to «LOWER A-PILLAR TRIM»(ref-522378-S34222570952013011400000)
4. Footrest Assembly overview, refer to «FOOTREST AND FLOOR COVERING ASSEMBLY OVERVIEW»(ref-522378-S16694738222013011400000) Removing and installing, refer to «FOOTREST»(ref-522378-S38243399232013011400000)
5. Upper A-Pillar Trim Assembly overview, refer to «UPPER A-PILLAR TRIM ASSEMBLY OVERVIEW»(ref-522378-S19831436962013011400000) Removing and installing, refer to «A-PILLAR UPPER TRIM»(ref-522378-S26941008952013011400000)
6. Carpet Assembly overview, refer to «FOOTREST AND FLOOR COVERING ASSEMBLY OVERVIEW»(ref-522378-S16694738222013011400000) Removing and installing, refer to «FLOOR COVERING»(ref-522378-S01114637952013011400000)

Scheme 142

1. Sill Panel Strip Removing and installing, refer to «SILL PANEL»(ref-522378-S40434780242013011400000)
2. Clips Quantity: 3 Insert in the sill panel strip Replace if damaged or deformed

Scheme 143

1. Expanding Clip For the side trim Replace if damaged
2. Trim For the mid-range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(ref-522378-S23995889042013011400000)
3. Side Trim Panel Insert Removing and installing, refer to «SIDE TRIM PANEL INSERT»(ref-522378-S27704568162013011400000)
4. Trim Panel Removing and installing, refer to «TRIM MOLDING»(ref-522378-S28882331222013011400000)
5. Clips Quantity: 4 Press into the side trim
6. Bolt 9 Nm
7. Rear Seat Belt Guide Removing and installing, refer to «REAR BELT GUIDE»(ref-522301-S21286557272013011400000)
8. Adjusting Sleeve Adjustment dimension «SIDE TRIM»(ref-522378-S41028868192013011400000)
9. Bolt 9 Nm
10. Clip With seal For the side trim Quantity: 2 Replace if damaged
11. Bolt 1.5 Nm
12. Bolt 1.5 Nm
13. Treble Speaker Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
14. Front Seat Belt Extraction Panel Removing and installing, refer to «BELT EXTRACTION PANEL»(ref-522378-S25193387812013011400000)
15. Insulation Secured to the side trim panel
16. Clips Quantity: 3 Insert into the side trim Replace if damaged or deformed
17. Side Trim Removing and installing, refer to «SIDE TRIM»(ref-522378-S41028868192013011400000)
18. Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(ref-522378-S41433564382013011400000)

Scheme 144

1. Driver Side Instrument Panel Cover
2. Clips Insert in the footrest
3. Footrest The footrest is destroyed during removal and must be replaced. Removing and installing, refer to «FOOTREST»(ref-522378-S38243399232013011400000)
4. A-Pillar Lower Trim
5. Carpet One piece Removing and installing, refer to «FLOOR COVERING»(ref-522378-S01114637952013011400000)

Scheme 145

1. Upper A-Pillar Trim Removing and installing, refer to «A-PILLAR UPPER TRIM»(ref-522378-S26941008952013011400000)
2. Centering Pins
3. Retaining Tab
4. Clips Quantity: 2 Install inside the roof frame Replace if damaged or deformed
5. Clamps Quantity: 2 Install in the trim Replace if damaged or deformed

Scheme 146

1. Clips Install in the trim Replace if damaged or deformed
2. Clips Install inside the body Replace if damaged or deformed
3. Hood Release Lever For the cable Driver side only Removing and installing, refer to «CABLE OPERATING LEVER»(ref-522378-S39400195692013011400000)
4. Bolt Driver side only 2.5 Nm
5. A-Pillar Lower Trim Removing and installing, refer to «LOWER A-PILLAR TRIM»(ref-522378-S34222570952013011400000)

Scheme 147

1. Rear Convertible Top Compartment Trim Assembly overview, refer to «REAR CONVERTIBLE TOP COMPARTMENT TRIM ASSEMBLY OVERVIEW»(ref-522378-S13640203412013011400000) Removing and installing, refer to «REAR CONVERTIBLE TOP COMPARTMENT TRIM»(ref-522378-S12453148892013011400000)
2. Variable Convertible Top Compartment Enclosure Assembly overview, refer to «VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE ASSEMBLY OVERVIEW»(ref-522378-S38675793112013011400000) Removing and installing, refer to «VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S00805410162013011400000)
3. Front Convertible Top Compartment Trim Assembly overview, refer to «FRONT CONVERTIBLE TOP COMPARTMENT TRIM ASSEMBLY OVERVIEW»(ref-522378-S02900598282013011400000) Removing and installing, refer to «FRONT CONVERTIBLE TOP COMPARTMENT TRIM»(ref-522378-S30473625882013011400000)
4. Convertible Top Compartment Side Trim Panel Assembly overview, refer to «CONVERTIBLE TOP COMPARTMENT SIDE TRIM PANEL ASSEMBLY OVERVIEW»(ref-522378-S26367861202013011400000) Removing and installing, refer to «CONVERTIBLE TOP COMPARTMENT SIDE TRIM»(ref-522378-S35601812952013011400000)

Scheme 148

1. Trim For the variable convertible top compartment enclosure Removing and installing, refer to «TRIM, VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S07636063002013011400000)
2. Bolt 8 Nm
3. Bolt Quantity: 3 8 Nm
4. Left Bracket With left convertible top compartment enclosure motor -V433- Removing and installing, refer to «LEFT MOUNTING PIN, VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S41193851382013011400000)
5. Bolt Quantity: 4 8 Nm
6. Guide Rail For the variable convertible top compartment enclosure Removing and installing, refer to «GUIDE RAIL, VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S06676208952013011400000)
7. Variable Convertible Top Compartment Enclosure Removing and installing, refer to «VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S00805410162013011400000)
8. Switch For the convertible top compartment enclosure Left convertible top compartment enclosure switch -F402- Right convertible top compartment enclosure switch -F403- Removing and installing, refer to «LEFT AND RIGHT CONVERTIBLE TOP COMPARTMENT ENCLOSURE SWITCHES»(ref-522378-S23832038982013011400000)
9. Right Bracket Removing and installing, refer to «RIGHT MOUNTING PIN, VARIABLE CONVERTIBLE TOP COMPARTMENT ENCLOSURE»(ref-522378-S03201944332013011400000)
10. Bolt Quantity: 3 8 Nm

Scheme 149

1. Bracket For the variable convertible top compartment enclosure
2. Spring For the inner release lever Engage in the bracket
3. Inner Release Lever
4. Shaft For the inner release lever
5. Bracket For the convertible top compartment enclosure motor
6. Bolt 1 Nm
7. Locking Washer Replace
8. Insulation Component Removing and installing, refer to «LEFT CONVERTIBLE TOP COMPARTMENT ENCLOSURE MOTOR»(ref-522378-S41770203582013011400000)
9. Cover For the bracket
10. Bolt 1 Nm
11. Locking washer Replace
12. Left Convertible Top Compartment Enclosure Motor -V433- Removing and installing, refer to «LEFT CONVERTIBLE TOP COMPARTMENT ENCLOSURE MOTOR»(ref-522378-S41770203582013011400000)
13. Shaft For the drive wheel
14. Bolt 0.5 Nm
15. Spring For the drive wheel
16. Drive Wheel

Scheme 150

1. Expanding Clip
2. Convertible Top Compartment Side Trim Panel Removing and installing, refer to «CONVERTIBLE TOP COMPARTMENT SIDE TRIM»(ref-522378-S35601812952013011400000)
3. Stop For the convertible top frame
4. Bolt 3 Nm
5. Clip

Scheme 151

1. Expanding Clip Quantity: 9
2. Front Convertible Top Compartment Trim Removing and installing, refer to «FRONT CONVERTIBLE TOP COMPARTMENT TRIM»(ref-522378-S30473625882013011400000)

Scheme 152

1. Expanding Clip Quantity: 4
2. Clips Quantity: 4
3. Rear Convertible Top Compartment Trim Removing and installing, refer to «REAR CONVERTIBLE TOP COMPARTMENT TRIM»(ref-522378-S12453148892013011400000)

Scheme 153

1. Rear Cross Panel Trim Assembly overview, refer to «REAR LID END PANEL TRIM PANEL ASSEMBLY OVERVIEW»(ref-522378-S21800131862013011400000) Removing and installing, refer to «REAR CROSS PANEL TRIM»(ref-522378-S41818852072013011400000)
2. Rear Lid Trim For the engine compartment lid Assembly overview, refer to «REAR LID TRIM ASSEMBLY OVERVIEW»(ref-522378-S03696830092013011400000) Removing and installing, refer to «REAR LID TRIM»(ref-522378-S29707064172013011400000)
3. Luggage Compartment Side Trim Assembly overview, refer to «LUGGAGE COMPARTMENT SIDE TRIM ASSEMBLY OVERVIEW»(ref-522378-S27990380582013011400000) Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(ref-522378-S07747626042013011400000)
4. Front Luggage Compartment Floor Covering Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT ASSEMBLY OVERVIEW»(ref-522378-S23961959032013011400000) Removing and installing, refer to «FRONT LUGGAGE COMPARTMENT COVERING»(ref-522378-S31112283642013011400000)
5. Rear Luggage Compartment Floor Covering Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT ASSEMBLY OVERVIEW»(ref-522378-S23961959032013011400000) Removing and installing, refer to «REAR LUGGAGE COMPARTMENT FLOOR COVERING»(ref-522378-S23623248412013011400000)

Scheme 154

1. Warning Triangle
2. Plugs
3. Trim For the rear lid lock Removing and installing, refer to «REAR LID LATCH TRIM PANEL»(ref-522378-S26174674402013011400000)
4. Stop Strip Quantity: 2 Clipped into the rear lid
5. Expanding Nut Clipped into the rear lid
6. Clips Quantity: 11 Install in the trim Replace if damaged or deformed
7. Rear Lid Trim Removing and installing, refer to «REAR LID TRIM»(ref-522378-S29707064172013011400000)
8. Bolt 1.8 Nm
9. Bracket For the warning triangle Removing and installing, refer to «WARNING TRIANGLE BRACKET»(ref-522378-S00306348802013011400000)
