Communication (Coupe): Overview Audi S5 I facelift

SPEECH INPUT CONTROL MODULE HARNESS CONNECTOR OVERVIEW

Note. Unlisted connector terminals are not used.

Scheme 12

1. Not assigned
2. Not assigned
3. Status
4. Diagnosis
5. Terminal 30
6. Reset signal
7. Power good
8. Power on
9. Terminal 31
10. MOST out
11. Enable
12. MOST in

Scheme 13

1. Telephone Transceiver -R36- Connector Assignment Cell Phone Preparation (CAN), refer to «CAN CELL PHONE PREPARATION CONNECTORS, THROUGH MY 2008»(ref-520129-S31938539842012123100000) . Connector assignment, MMI cell phone preparation through 10.31.2008, refer to «MMI CELL PHONE PREPARATION CONNECTORS, THROUGH 10.2008»(ref-520129-S28280524092012123100000) . Removing and installing, refer to «TELEPHONE TRANSCEIVER -R36»(ref-520129-S36578436472012123100000) .
2. Bluetooth® Antenna -R152
3. Electronics Box
4. Microphone Unit In Front Roof Module -R164- Overview, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE OVERVIEW, THROUGH 10.2008»(ref-520129-S33163572412012123100000) . Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE -R164»(ref-520129-S14184866712012123100000) .
5. Radio, Telephone and Navigation System Antenna -R52- Overview, refer to «ANTENNA SYSTEM»(ref-520129-S09622923662012123100000) .
6. Nut 6 Nm
7. Telephone Base Plate -R126- Removing and installing (cell phone mount), refer to «CELL PHONE CRADLE -R126»(ref-520129-S25622022382012123100000) .
8. Screw 1 Nm

Scheme 14

1. Telephone Transceiver -R36- Connector assignment, CAN from MY 2009, refer to «CAN CELL PHONE PREPARATION CONNECTORS, FROM MY 2009»(ref-520129-S24933075642012123100000) . CAN Bluetooth® Handsfree setup connectors, refer to «CAN BLUETOOTH® CONNECTORS»(ref-520129-S19870975322012123100000) . Removing and installing, refer to «TELEPHONE TRANSCEIVER -R36»(ref-520129-S36578436472012123100000) .
2. Bluetooth® Antenna -R152
3. Electronics Box
4. Microphone Unit In Front Roof Module -R164- Overview, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE OVERVIEW, FROM 11.2008»(ref-520129-S25303591822012123100000) . Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE -R164»(ref-520129-S14184866712012123100000) .
5. Radio, Telephone And Navigation System Antenna -R52- /Roof Antenna -R216- Overview, refer to «ANTENNA SYSTEM»(ref-520129-S09622923662012123100000) .
6. Nut 6 Nm
7. Information Electronics Control Module 1 -J794- For connector assignment, MMI cell phone preparation from 11.03.2008, refer to «MMI CELL PHONE PREPARATION CONNECTORS, FROM 11.2008»(ref-520129-S25249197312012123100000) . MMI Bluetooth® Hands-Free setup connectors, refer to «MMI BLUETOOTH® CONNECTORS»(ref-520129-S08854227782012123100000) . Removing and installing, refer to «INFORMATION ELECTRONICS CONTROL MODULE 1 -J794»(ref-520129-S14926407142012123100000) .
8. Radio Removal Tool T10057

Scheme 15

1. Telephone Baseplate -R126- with Cellular Telephone -R54- through MY 2008
2. Radio -R- in the Instrument Panel
3. Sound Systems
4. Bluetooth® Antenna -R152- at Telephone Transceiver -R36
5. Telephone Transceiver -R36- under the Front Passenger Seat
6. Microphone Unit in Front Roof Module -R164- in Front Interior Light -W1
7. Radio, Telephone and Navigation System Antenna -R52- /Roof Antenna -R216

Scheme 16

1. Telephone Baseplate -R126- with Cellular Phone -R54
2. Front Information Display Control Head -J685- in Center Instrument Panel
3. Front Information Display Control Head Control Module -J523- behind the Instrument Panel
4. Multimedia Control Head -E380- in Center Console
5. Data Bus On Board Diagnostic Interface -J533- behind the Glove Compartment on the left side
6. Instrument Cluster Control Module -J285- in the Instrument Panel
7. Steering Column Electronic Systems Control Module -J527- on Steering Column at Steering Column Switches
8. Multifunction Steering Wheel
9. Microphone Unit in Front Roof Module -R164- in Front Interior Light -W1
10. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim
11. Sound Systems
12. Telephone Transceiver -R36- under the Front Passenger Seat
13. Microphone Unit in Front Roof Module -R164- (Telephone Microphone -R38-) in Front Interior Light -W1
14. Bluetooth® Antenna -R152- at Telephone Transceiver -R36
15. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna

Scheme 17

1. Radio, Telephone and Navigation System Antenna -R52- /Roof Antenna -R216
2. Front Information Display Control Head -J685- in Center Instrument Panel
3. Multimedia Control Head -E380- in the Center Console
4. Information Electronics Control Module 1 -J794- inside the Instrument Panel
5. Microphone Unit in Front Roof Module -R164- (Right Front Microphone -R141-) inside the Front Interior Light -W1
6. Data Bus On Board Diagnostic Interface -J533- behind the Glove Compartment on the left side
7. Steering Column Electronic Systems Control Module -J527- on Steering Column at Steering Column Switches
8. Multifunction Steering Wheel
9. Instrument Cluster Control Module -J285- in the Instrument Panel
10. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim
11. Microphone Unit in Front Roof Module -R164- (Left Front Microphone -R140-) inside the Front Interior Light -W1

Scheme 18

1. Radio -R- in the Instrument Panel
2. Sound Systems
3. Bluetooth® Antenna -R152- at Telephone Transceiver -R36
4. Telephone Transceiver -R36- under the Front Passenger Seat
5. Microphone Unit in Front Roof Module -R164- (Right Front Microphone -R141-) inside the Front Interior Light -W1

Scheme 19

1. Front Information Display Control Head -J685- in Center Instrument Panel
2. Multimedia Control Head -E380- in the Center Console
3. Microphone Unit in Front Roof Module -R164- (Right Front Microphone -R141-) inside the Front Interior Light -W1
4. Information Electronics Control Module 1 -J794- with the Bluetooth® Antenna -R152- inside the instrument panel
5. Data Bus On Board Diagnostic Interface -J533- behind Glove Compartment on the Left Side
6. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim

MICROPHONE UNIT IN FRONT ROOF MODULE OVERVIEW, THROUGH 10.2008

The microphone unit in front roof module -R164- in installed in the front interior light -W1-. Depending on the equipment, there are up to three microphones installed.

Microphone unit in front roof module, removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE -R164 .

One microphone (telephone microphone -R38-) is connected directly with the telephone transceiver -R36-. The other microphones are connected to the digital sound system control module -J525- (from Standard MMI).

Scheme 20

1. Microphone (blue) for the telephone transceiver -R36
2. Radar Interior Monitoring Control Module 1 -G303
3. Microphone (black) for the digital sound system control module (left-hand drive)/telephone transceiver (right-hand drive)
4. Inside microphone -R74- (black) to the digital sound system control module (from the standard sound system)
5. 6-pin connector (T6c)

Scheme 21

1. Telephone microphone -R38- (black)
2. 6-pin connector (T6c), pins 1 and 2: Telephone microphone (black), Pin 3 to 4: Inside microphone -R74- (black), pin 5 to 6: Voice control microphone -R206- (blue)
3. Inside microphone (black)
4. Voice control microphone (blue)

Microphone unit in front roof module, removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE -R164 .

MICROPHONE UNIT IN FRONT ROOF MODULE OVERVIEW, FROM 11.2008

The microphone unit (in front roof module) -R164- in installed in the front interior light -W1-. Depending on the equipment, there are up to three microphones installed.

Microphone unit (in front roof module), removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE -R164 .

One microphone (inside microphone -R74-) is connected directly to the digital sound system control module -J525-. The other microphones are connected to the information electronics control module 1 -J794-.

1. Microphone (blue) for the information electronics control module 1 (MMI)/telephone transceiver -R36- (CAN, left-hand drive vehicles).
2. Radar Interior Monitoring Control Module 1 -G303-.
3. Microphone (black) for the information electronics control module 1 (MMI)/telephone transceiver (CAN, right-hand drive vehicles).
4. Inside microphone -R74- (black) for the digital sound system control module.
5. 6-pin connector (T6c)

1. Left front microphone -R140- (black)
2. 6-pin connector (T6c), pins 1 and 2: Left front microphone (black), Pins 3 and 4: Inside microphone -R74- (black), pins 5 and 6: front right microphone (blue)
3. Inside microphone (black)
4. Right front microphone (blue)

Microphone Unit in front roof module, removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE -R164 .

Scheme 22

A - Connection for Bluetooth® antenna -R152

B - 54-pin connector (T54a)

Note. Unlisted connector terminals are not used.

Scheme 23

1 - Terminal 30

2 - Terminal 31

8 - LF (+) to radio -R

9 - LF (-) to radio

10 - Terminal 31 screening ground (not used)

11 - Microphone input (+) from Microphone unit in front roof module -R164- (telephone microphone)

12 - Microphone input (-) from Microphone unit in front roof module (telephone microphone)

16 - LF mute, not used

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to telephone baseplate -R126

39 - Terminal 31 to telephone base

41 - Terminal 30 to telephone base

42 - Microphone output (+) to telephone base

43 - Microphone output (-) to telephone baseplate -R126

44 - Terminal 31 (screening ground)

45 - LF (+) from telephone baseplate

46 - LF (-) from telephone baseplate

47 -Telephone baseplate -R126- DIAG signal

49 - Ser-Tx (+) to telephone baseplate

50 - Ser-Tx (-) to telephone baseplate

51 - Ser-Rx (+) from telephone baseplate

52 - Ser-Rx (-) from telephone baseplate

GENERAL INFORMATION

After performing service work on the vehicle, it may be necessary to calibrate the rearview camera system. In detail, this is the case after

1. Rear View Camera -R189-, removing and installing
2. Rear View Camera System Control Module -J772-, removing and installing
3. Collision repairs on rear lid
4. Axle alignment
5. Rear axle repairs
