Communication (Cabriolet): Overview Audi S5 I facelift

Communication Devices 5 illustrations ~552 words

SOUND SYSTEMS SCHEMATIC OVERVIEW

Radio (CAN)/MMI Sound System Basic Plus

Scheme 199

Scheme 199: SOUND SYSTEMS SCHEMATIC OVERVIEW
  1. Radio -R- in the Instrument Panel/Behind the Luggage Compartment Left Side Trim
  2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Instrument Panel
  3. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at bottom of Doors
  4. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in Upper Rear Side Trim
  5. Left Rear Mid/Low Range Speaker -R159- /Right Rear Mid/Low Range Speaker -R160- in the rear Side Trim.
  6. CAN bus (Infotainment)/MOST Bus

MMI Sound System Standard

Scheme 200

Scheme 200
  1. Radio -R- behind the Left Luggage Compartment Left Side Trim
  2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Instrument Panel
  3. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at Bottom of Doors
  4. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in Upper Rear Side Trim
  5. Left Rear Mid/Low Range Speaker -R159- /Right Rear Mid/Low Range Speaker -R160- in the Rear Side Trim.
  6. Center Mid/High Range Speaker -R158- In Center Instrument Panel
  7. Subwoofer (on rear shelf) -R157- in the Left Rear Side Trim Panel
  8. MOST Bus

Radio CAN Sound System Standard

Scheme 201

Scheme 201
  1. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim
  2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in the Instrument Panel
  3. Left Front Mid-Bass Speaker -R101- /Right Front Mid-Bass Speaker -R102- at bottom of Doors
  4. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in Upper Rear Side Trim
  5. Left Rear Mid/Low Range Speaker -R159- /Right Rear Mid/Low Range Speaker -R160- in the Rear Side Trim.
  6. Center Mid/High Range Speaker -R158- in Center Instrument Panel
  7. Subwoofer (on rear shelf) -R157- in the Left Rear Side Trim Panel
  8. CAN Bus (Infotainment)

Radio CAN/MMI Sound System Premium Bang and Olufsen

Scheme 202

Scheme 202
  1. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim
  2. Left Front Treble Speaker -R20- /Right Front Treble Speaker -R22- in Mirror Triangle
  3. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- in the Instrument Panel
  4. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- at bottom of Doors
  5. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- in Upper Rear Side Trim
  6. Left Rear Mid-Bass Speaker -R159- /Right Rear Mid-Bass Speaker -R160- in the Rear Side Trim.
  7. Center Mid-Treble Speaker -R158- in Center Instrument Panel
  8. Subwoofer in Rear Shelf -R157- in the Left Rear Side Trim Panel
  9. Microphone Unit in Front Roof Module -R164- (Interior Microphone -R74-) in the Front Interior Lamp -W1
  10. CAN Bus (Infotainment)
  11. MOST Bus

MICROPHONE UNIT IN FRONT ROOF MODULE -R164- OVERVIEW

The microphone unit in front roof module in installed in the front interior lamp -W1-. Up to three microphones may be installed, depending on the equipment.

One microphone (interior microphone -R74-) is connected directly to the digital sound system control module -J525-.

Scheme 203

Scheme 203: MICROPHONE UNIT IN FRONT ROOF MODULE -R164- OVERVIEW

1 - 4-Pin Connector (T4bg)

  1. Left front microphone -R140- to the telephone transceiver -R36- /information electronics control module 1 -J794
  2. Left front microphone to the telephone transceiver/information electronics control module 1
  3. Interior microphone -R74- to the digital sound system control module -J525

2 - Left Front Microphone

3 - Interior Microphone

Microphone unit in front roof module -R164-, Removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE -R164 .
