- Tightening specification see scheme 8
Note. Replace sealing rings and O-rings.
| CAUTION | Risk of contaminating lubricating system and bearing. Cover open parts of the engine. |
| WARNING | Danger of eye injury. Wear protective goggles. |
Remove sealant residue on the upper oil pan and the cylinder block, for example using a rotating plastic brush.
Scheme 31
Clean sealing surfaces, must be free of oil and grease.
Note. Note the expiration date of the sealing compound.
Cut the tube nozzle at the front marking (nozzle diameter approximately 1 mm).
Lay the seals -1- in the groove on the guide frame.
Scheme 32
| CAUTION | The lubrication system could be plugged with excess sealant. Do not apply sealant bead thicker than indicated. |
Apply sealant beads -1 and 2- to the clean sealing surface on the upper oil pan as shown in the illustration.
Scheme 33
- Thickness of sealant beads: 2.5 mm.
Note. Install the upper oil pan within five minutes of applying the sealant.
Position the lower oil pan and tighten the bolts. see scheme 8
Install in reverse order of removal paying attention to the following
Install the oil pump. Refer to OIL PUMP, THROUGH VIN CAU 003 685 , OIL PUMP, FROM VIN CAU 003 686
Install the generator bracket. Refer to RIBBED BELT DRIVE OVERVIEW .
Install the generator. Refer to Removal and Installation .
Install the ribbed belt tensioning damper. Refer to RIBBED BELT TENSIONER .
Install timing chain lower cover. Refer to LOWER TIMING CHAIN COVER .
Scheme 34
Special tools and workshop equipment required
- Oil Pressure Gauge V.A.G 1342 and Adapter V.A.G 1342/14
- Voltage tester V.A.G 1527B
- Connector Test Set V.A.G 1594C
Special tools and workshop equipment required
Scheme 35
Scheme 36
Scheme 37
Scheme 38
- Hose Clamps Up to 25 mm Dia. 3094
- Oil Collecting and Extracting Device V.A.G 1782
- Long Nose Grip Pliers VAS 6226
- Hose Clip Pliers VAS 6362
