Tightening specifications, refer to «FRONT DOOR ASSEMBLY OVERVIEW»(/audi/s5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Note. Do not make any adjustments after installing the door.

Scheme 162: DOOR ARRESTER, REMOVING

Move the door window into the "closed" position.

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the lower speaker REMOVAL AND INSTALLATION .

Remove the door arrester bolt -arrow-.

Remove the door arrester seal -1- on the door opening.

Remove the bolt -arrows- and remove the door arrester -2- inward.

Pull the rubber grommet -1- on the door arrester to the side slightly -A arrows-.

Remove the rubber grommet from the door arrester -2- -arrow B-.

INSTALLING Audi S5 I

INSTALLING
