Scheme 148

1. Bolt 32 Nm
2. Bolt 8 Nm
3. Cover For the door arrester
4. Door arrester Removing and Installing, refer to «FRONT DOOR»(/audi/s5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
5. Bolt 25 Nm
6. Cover Install on the threaded pin.
7. Threaded pin 30 Nm
8. Upper door hinge
9. Bolt 32 Nm
10. Bolt NOTE: The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category. 45 Nm
11. Bolt 8 Nm
12. Seal For the door arrester
13. Bolt 32 Nm
14. Bolt NOTE: The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category. 45 Nm
15. Bolt 32 Nm
16. Bottom door hinge
17. Threaded pin 25 Nm
18. Cover Install on the threaded pin.

Scheme 149

1. Clip for the door seal and inner window shaft strip Cannot be replaced separately.
2. Outer door seal with inside window shaft strip and exterior mirror seal Removing and Installing, refer to «DOOR SEALS»(/audi/s5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-seals) .
3. Door
4. Outer window shaft strip Removing and Installing, refer to «OUTER WINDOW SHAFT STRIP»(/audi/s5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__outer-window-shaft-strip) .
5. Exterior rearview mirror
