# Courtesy lamps circuit

# Courtesy lamps circuit (1 of 5)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (1 of 5). Audi RS3 8V facelift (2017-2021)
Components on the diagram

    # Courtesy lamps circuit (2 of 5)

    Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (2 of 5). Audi RS3 8V facelift (2017-2021)
    Components on the diagram

      # Courtesy lamps circuit (3 of 5)

      Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (3 of 5). Audi RS3 8V facelift (2017-2021)
      Components on the diagram

        # Courtesy lamps circuit (4 of 5)

        Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (4 of 5). Audi RS3 8V facelift (2017-2021)
        Components on the diagram

          # Courtesy lamps circuit (5 of 5)

          Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (5 of 5). Audi RS3 8V facelift (2017-2021)
          Components on the diagram
