Sunroof: Maintenance Audi Q7 4L facelift

WATER DRAIN HOSES, CLEANING

Note. For cleaning, it is recommended that you create your own assisting tool that resembles a speedometer inner cable in size and flexibility and is approximately 8 feet (2300 mm) in length or an equivalent tool.

Scheme 9

1. Front Water Drain Hose Front water drain hoses run into A-pillars and end under wheel housing liners. Cleaning takes place from sunroof frame.
2. Sunroof Frame
3. Rear Water Drain Hose Rear water drain hoses are routed in C-pillars and end in wheel housing above wheel housing liner. Cleaning is performed at lower end of hose.

Scheme 10

After installing sunroof frame, connect water drain hose -2- to connecting piece -1- on frame.

Secure water drain hose with cable ties -3-.

Scheme 11

1. Sunroof Frame
2. Trim -- Position panel -1-. -- Unclip trim at center, moving it to side.
3. Panel 1 Removal: -- Position panel. -- Remove trim -2- sideways from tilting mechanism. -- Remove screws -4- and remove panel upward. CAUTION: Do not move the sunroof when the cover is removed otherwise this will damage, for example, scratch, the wind deflector. Installing: -- Lay panel in installation position on tilting mechanism and lightly install screws -3-. -- Close panel and adjust it according to gap pattern. -- Tighten the front screws first and then the rear screws -4- alternating from side to side. -- Then tighten the center screws to 4.5 Nm. -- Press trim onto tilting mechanisms again. -- Perform an adaptation. Refer to MOTOR ADAPTATION .
4. Screws CAUTION: Pay close attention to the three tightening sequences >>front, rear and center<<. 4.5 Nm

Cover Tightening Sequence -1

Tighten the screws to the tightening specification in sequence 1, 2 and 3 after adjusting.

Scheme 12

1. Sunroof Frame
2. Spacer Discs
3. Bolt 4.5 Nm
4. Panel 2 Removal: NOTE: Before removing panel -2-, panel -3- must be removed. -- After removing panel -3-, guide panel -1- all the way back. NOTE: Push rotary switch beyond comfort setting. -- Remove left and right screws -3- from above. NOTE: There are two spacer discs -2- under attachment points to adjust cover -2- height. Remove these after panel has also be removed so they do not fall into guide channels and disrupt function. -- Run panel 1 into tilted position. -- Remove left and right screws -5- from tilting mechanism rail. NOTE: Small markings are applied to plastic edge of panel that make it easier to find screw positions PANEL . -- Pull trim in slightly and remove screws below. -- Remove panel upward. -- When installing, proceed as follows: CAUTION: Before inserting panel 2, reinsert spacer discs at front attachment points between cover attachment surfaces -2- and sunroof frame. -- Insert panel according to its attachment positions. -- Lightly pull inner seal inward and lightly tighten side screws. -- Insert rear panel 3 and lightly tighten screws. -- Close panel 3. -- Run panel 1 into tilted position. -- Lightly install front screws from above through spacer discs. -- Close panel 1. -- Adjust panel 2 according to gap chart. -- Tighten the screws on the side -5- to 4.5 Nm. -- Run panel 1 into tilted position. -- Tighten front screws to 4.5 Nm. -- Close panel 1 and panel 3 and check adjustment. Refer to GLASS SUNROOF PANEL, ADJUSTING . -- Perform an adaptation on Panels 1 and 3. Refer to MOTOR ADAPTATION .
5. Bolt 4.5 Nm

Panel 2 Spacer Discs

Scheme 13

Distance disc must be inserted between panel 2 and sunroof frame -4- for height adjustment.

Scheme 14

Note. There are small markings on panel edges to make it easier to find panel securing screws.

Lightly pull inner seal back under markings -arrow- and remove screws below.

Note. Inner seal is not shown in illustration.

Scheme 15

1. Sunroof Frame
2. Trim Removal: -- Position panel 3. -- Unclip trim in center and move slightly to side. -- Slide trim back until it can be removed from keyhole-shaped hole. Installing: -- Installation of each trim panel occurs in reverse sequence. This engages trim in panel.
3. Panel 3 Removal: -- Position panel -3-. NOTE: Small markings (3 each) applied to plastic edge of panel that make it easier to find screw positions PANEL . -- For removal, remove side securing screws. -- Remove panel -3- upward. -- Installing: -- Insert cover with tilted tilting mechanism according to attachment points. -- Lightly tighten side screws on panel 3. -- Close cover and check adjustment. Refer to GLASS SUNROOF PANEL, ADJUSTING -- Perform an adaptation -3- on the panel. Refer to MOTOR ADAPTATION . -- Insert side trim panels.
4. Bolt 4.5 Nm

Trim, Removing

Position panel.

Pull trim -1- slightly to side with small hook in center.

Scheme 16

Slide trim panel back slightly and remove it sideways from panel.

Scheme 17

Installing Panel

Scheme 18

When installing, insert the trim into the key hole -arrow- and push it forward.

Press side trim panel into catch on panel.
