TRAILER HITCH SOCKET Audi Q7 4L рестайлинг

Interior Lights, Switches 4 illustrations ~701 words

TRAILER HITCH SOCKET

The following descriptions can be found in DESCRIPTION AND OPERATION and REMOVAL AND INSTALLATION

  1. Trailer Hitch Socket, removing and installing.
  2. Connector assignment on the trailer hitch socket.

Scheme 1

Scheme 1: ACCESS/START AUTHORIZATION SYSTEM OVERVIEW
Scheme 1: ACCESS/START AUTHORIZATION SYSTEM OVERVIEW
  1. Access/Start Authorization Switch -E415- Component location: In instrument panel on the driver side. Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH -E415»(/audi/q7/4l-2009-2015/remont/exterior-lights/#exterior-lights-switches) .
  2. Keyless Access Authorization Antenna Reader -J723- Component location: Behind the luggage compartment side trim panel on the right side. Removing and installing, refer to «KEYLESS ACCESS AUTHORIZATION ANTENNA READER -J723»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__keyless-access-authorization-antenna-reader-j723) .
  3. Access/Start Authorization Button -E408- Component location: Inside the frame for the multimedia control head -E380-. Removing and installing: Vehicles through MY 09, refer to «ACCESS/START AUTHORIZATION BUTTON -E408-, THROUGH MY 09»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__accessstart-authorization-button-e408-through-my) . Vehicles from MY 10, refer to «ACCESS/START AUTHORIZATION BUTTON -E408-, FROM MY 10»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__accessstart-authorization-button-e408-from-my) .
  4. Access/Start Authorization Control Module -J518- With integrated Steering Column Lock Actuator -N360-. Removing and installing, refer to «Removal and Installation»(/audi/q7/4l-2009-2015/remont/manual-power-steering/#steering) .

Scheme 2

Scheme 2: KEYLESS ACCESS SYSTEM OVERVIEW
Scheme 2: KEYLESS ACCESS SYSTEM OVERVIEW
  1. Interior Access/Start Authorization Antenna 1 -R138- Component location: Under center console at the front. Removing and installing, refer to «ACCESS/START AUTHORIZATION ANTENNA 1 IN VEHICLE INTERIOR -R138»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__accessstart-authorization-antenna-1-in-vehicle) .
  2. Front Passenger Exterior Door Handle With the Right front outside door handle touch sensor -G606-. Overview, refer to «KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
  3. Right Access/Start Authorization Antenna -R135- Component location: At rear door trim. Removing and installing, refer to «FRONT PASSENGER ACCESS/START AUTHORIZATION ANTENNA -R135»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__front-passenger-accessstart-authorization-antenna-r135) .
  4. Right Rear Outside Door Handle With the right rear outside door handle touch sensor -G418-. Overview, refer to «KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
  5. Keyless Access Authorization Antenna Reader -J723- Component location: Behind the luggage compartment side trim panel on the right side. Removing and installing, refer to «KEYLESS ACCESS AUTHORIZATION ANTENNA READER -J723»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__keyless-access-authorization-antenna-reader-j723) .
  6. Luggage Compartment Access/Start Authorization Antenna -R137- Component location: On the luggage compartment rear lid end panel on the left side. Removing and installing, refer to «ACCESS/START AUTHORIZATION ANTENNA IN LUGGAGE COMPARTMENT -R137»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__accessstart-authorization-antenna-in-luggage-compartment) .
  7. Rear Left Outer Door Handle Overview, refer to «KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
  8. Left Access/Start Authorization Antenna -R134- Component location: At rear door trim. Removing and installing, refer to «DRIVER ACCESS/START AUTHORIZATION ANTENNA -R134»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__driver-accessstart-authorization-antenna-r134) .
  9. Driver Side Outside Door Handle Overview, refer to «KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches) .

Scheme 3

Scheme 3: KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW
Scheme 3: KEYLESS ACCESS AUTHORIZATION SYSTEM OUTSIDE DOOR HANDLE OVERVIEW
  1. Outside Door Handle Touch Sensor Driver Exterior Door Handle Touch Sensor -G415-, Front Passenger Exterior Door Handle Touch Sensor -G416- Cannot be replaced separately. Replacing outside door handle, refer to «Removal and Installation»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system) . Left Rear Exterior Door Handle Touch Sensor -G417-, Right Rear Exterior Door handle Touch Sensor -G418- Cannot be replaced separately. Replacing outside door handle, refer to «Removal and Installation»(/audi/q7/4l-2009-2015/remont/windows/#rear-doors) .
  2. Electrical Connector
  3. Outside Door Handle Switch Driver Exterior Door Handle Switch -F272-, Front Passenger Exterior Door Handle Switch -F273- Removing and installing, refer to «DRIVER/PASSENGER EXTERIOR DOOR HANDLE SWITCH -F272- / F273»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__driverpassenger-exterior-door-handle-switch-f272) . Left Rear Exterior Door Handle Switch -F274-, Right Rear Exterior Door Handle Switch -275- Removing and installing, refer to «LEFT/RIGHT REAR EXTERIOR DOOR HANDLE SWITCH -F274- / F275»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__leftright-rear-exterior-door-handle-switch) .
  4. Door Lock
  5. Mounting Bracket
  6. Lock Cylinder Only driver's side.
  7. Cover Driver side for lock cylinder. Passenger side closed version. Rear doors closed version.
  8. Outside Door Handle Central Locking Button Driver Exterior Door Handle Central Locking Button -E369-, Front Passenger Exterior Door Handle Central Locking Button -E370-. Cannot be replaced separately. Replacing outside door handle, refer to «Removal and Installation»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system) . Left Rear Exterior Door Handle Central Locking Button -E371-, Right Rear Exterior Door Handle Central Locking Button -E372-. Cannot be replaced separately. Replacing outside door handle, refer to «Removal and Installation»(/audi/q7/4l-2009-2015/remont/windows/#rear-doors) .

Scheme 4

Scheme 4: LANE CHANGE ASSISTANCE OVERVIEW
Scheme 4: LANE CHANGE ASSISTANCE OVERVIEW
  1. Lane Change Assistance Warning Lamp In Driver Exterior Rearview Mirror -K233- Removing and installing, refer to «LANE CHANGE ASSISTANCE WARNING LAMP IN EXTERIOR MIRROR»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__lane-change-assistance-warning-lamp-in) .
  2. Lane Change Assistance Warning Lamp In Front Passenger Exterior Rearview Mirror -K234- Removing and installing, refer to «LANE CHANGE ASSISTANCE WARNING LAMP IN EXTERIOR MIRROR»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__lane-change-assistance-warning-lamp-in) .
  3. Screw 3.5 Nm
  4. Electrical Connector
  5. Screw 3.5 Nm
  6. Lane Change Assistance Control Module -J769
  7. Lane Change Assistance Control Module 2 -J770
  8. Screw 3.5 Nm
  9. Electrical Connector
  10. Screw 3.5 Nm
  11. Lane Change Assistance Button -E530- Removing and installing, refer to «LANE CHANGE ASSISTANCE BUTTON -E530»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__lane-change-assistance-button-e530) .
