STEERING COLUMN ADJUSTMENT SWITCH -E167
Special tools and workshop equipment required
- T8 Screwdriver T40056 A
Removing
Scheme 74
Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.
Remove gap cover -1- in -direction of arrow-.
Remove screws -4- with T40056 A.
Remove screws -7-.
Separate top trim -2- for steering column switches from bottom trim -3- and remove both parts.
Disconnect electrical harness connector at lower trim.
Note. Ignore items -5, 6-. For the sake of illustration, shown with steering wheel removed.
Remove screws -arrows- and remove Steering Column Adjustment Switch -item 1- upward out of lower trim.
Scheme 75
Installing
Install in reverse order of removal, observing the following
Insert top trim piece for steering column switch into catches of bottom trim piece, press together and bolt.
Tightening Specifications
| Component | Nm |
|---|---|
| Steering Column Adjustment Switch to bottom trim | 2.5 |
| Trim for steering column switch | 0.6 |
| Lower trim to steering column | 3.5 |
