General information Audi Q7 4L рестайлинг

Interior Equipment 5 illustrations ~724 words

Scheme 1

Scheme 1: STORAGE COMPARTMENTS AND COVERS ASSEMBLY OVERVIEW
Scheme 1: STORAGE COMPARTMENTS AND COVERS ASSEMBLY OVERVIEW
  1. Center console Assembly Overview, refer to «CENTER CONSOLE ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment) Removing and Installing, refer to «CENTER CONSOLE»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment)
  2. Driver side instrument panel covers Assembly Overview, refer to «INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment) Instrument Panel Cover, Removing and Installing, Lower, Driver Side, refer to «LOWER DRIVER SIDE INSTRUMENT PANEL COVER»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__lower-driver-side-instrument-panel-cover) Instrument Panel cover, Removing and Installing, Upper, Driver Side, Removing and Installing, refer to «UPPER INSTRUMENT COVER, DRIVER SIDE KNEE BAR»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__upper-instrument-cover-driver-side-knee)
  3. Instrument panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION»(/audi/q7/4l-2009-2015/remont/airbag/#passenger-protection-airbags-seat-belts) . Assembly Overview, refer to «INSTRUMENT PANEL COMPONENTS OVERVIEW»(/audi/q7/4l-2009-2015/remont/exteriorinterior-trim/#interior-trim) Removing and Installing, refer to «INSTRUMENT PANEL»(/audi/q7/4l-2009-2015/remont/exteriorinterior-trim/#interior-trim)
  4. Instrument panel central tube Assembly Overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(/audi/q7/4l-2009-2015/remont/exteriorinterior-trim/#interior-trim) Removing and Installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(/audi/q7/4l-2009-2015/remont/exteriorinterior-trim/#interior-trim__instrument-panel-central-tube)
  5. Glove compartment and front passenger side instrument panel cover Assembly Overview, refer to «PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment) Removing and installing the glove compartment, refer to «GLOVE COMPARTMENT»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment) Passenger side instrument panel cover, removing and installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__passenger-side-instrument-panel-cover)
  6. Front center armrest Assembly Overview, refer to «FRONT CENTER ARMREST ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment) Removing and Installing, refer to «FRONT CENTER ARMREST»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__front-center-armrest)

Scheme 2

Scheme 2: INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW
Scheme 2: INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW
  1. Left mount Driver side lower instrument panel cover
  2. Connector, 16-pin - T16- Diagnostic connector
  3. Right mount Driver side lower instrument panel cover Clipped into accelerator pedal module
  4. Bolt Tightening specification - 1.4 Nm
  5. Threaded clip Quantity: 2
  6. Upper instrument panel cover, driver side Iidentified as knee bar Removing and Installing, refer to «UPPER INSTRUMENT COVER, DRIVER SIDE KNEE BAR»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__upper-instrument-cover-driver-side-knee)
  7. Clips Quantity: 2 Before installing the upper instrument panel cover on the driver side, the knee bars must be installed in the cut-outs in the instrument panel Note location «INSTALLATION POSITION»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__installation-position)
  8. Bolt Tightening specification - 1.4 Nm
  9. Footwell light Removing and Installing, refer to «INSTRUMENT PANEL LAMPS AND SWITCHES»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches)
  10. Driver side lower instrument panel cover Removing and Installing, refer to «LOWER DRIVER SIDE INSTRUMENT PANEL COVER»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__lower-driver-side-instrument-panel-cover)

Scheme 3

Scheme 3: DRIVER SIDE KNEE BAR ASSEMBLY OVERVIEW
Scheme 3: DRIVER SIDE KNEE BAR ASSEMBLY OVERVIEW
  1. Bolt 10 Nm
  2. Left knee bar Removing and Installing, refer to «LEFT DRIVER SIDE KNEE BAR»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__left-driver-side-knee-bar)
  3. Central tube
  4. Bolt 10 Nm
  5. Bolt 10 Nm
  6. Right knee bar Removing and Installing, refer to «RIGHT DRIVER SIDE KNEE BAR»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__right-driver-side-knee-bar)
  7. Bolt 10 Nm
  8. Bolt 3 Nm
  9. Knee bar brace Removing and Installing, refer to «DRIVER SIDE KNEE BAR BRACE»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__driver-side-knee-bar-brace)
  10. Bolt 3 Nm

Scheme 4

Scheme 4: PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
Scheme 4: PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
  1. Clips
  2. Cold air vent/cover plate
  3. Hinge pin
  4. Lid dampening mechanism With Glove compartment lamp switch -E26- Removing and Installing, refer to «GLOVE COMPARTMENT COVER BRAKE COMPONENT»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-cover-brake-component)
  5. Rubber stop for instrument panel
  6. Glove compartment unlock motor -V327- Removing and Installing, refer to «GLOVE COMPARTMENT UNLOCK MOTOR V327»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-unlock-motor-v327) Activate the glove compartment cover emergency release «GLOVE COMPARTMENT COVER EMERGENCY RELEASE, ACTIVATING»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-cover-emergency-release-activating)
  7. Bolt Tightening specification - 1 Nm
  8. Cover For the glove compartment unlock motor -V327- With the control cable bracket for the glove compartment cover release Removing and Installing, refer to «GLOVE COMPARTMENT UNLOCK MOTOR V327»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-unlock-motor-v327)
  9. Glove compartment cover release control cable Cannot be replaced separately; replacing, refer to «GLOVE COMPARTMENT LID»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-lid) Adjusting, refer to «GLOVE COMPARTMENT COVER CONTROL CABLE, ADJUSTING»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-cover-control-cable-adjusting)
  10. Glove compartment Removing and Installing, refer to «GLOVE COMPARTMENT»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment)
  11. Compensation disc For the glove compartment hinge
  12. Hinge pin For securing the glove compartment cover Removing and Installing, refer to «GLOVE COMPARTMENT LID»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-lid)
  13. Locking pin mount
  14. Rubber stop For the glove compartment cover
  15. Glove compartment cover Activate the glove compartment cover emergency release «GLOVE COMPARTMENT COVER EMERGENCY RELEASE, ACTIVATING»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-cover-emergency-release-activating) Removing and Installing, refer to «GLOVE COMPARTMENT LID»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__glove-compartment-lid)
  16. Bolt Tightening specification - 1.4 Nm
  17. Glove compartment light Removing and Installing, refer to «GLOVE COMPARTMENT LAMP»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__glove-compartment-lamp)
  18. Front Passenger Airbag -Off- Key Switch -E224- WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION»(/audi/q7/4l-2009-2015/remont/airbag/#passenger-protection-airbags-seat-belts) .
  19. Passenger side instrument panel cover Removing and Installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__passenger-side-instrument-panel-cover)
  20. Footwell light Removing and Installing, refer to «FRONT FOOTWELL LAMP»(/audi/q7/4l-2009-2015/remont/door-locks-anti-theft-systems/#interior-lights-switches__front-footwell-lamp)

Scheme 5

Scheme 5: PASSENGER SIDE KNEE BAR ASSEMBLY OVERVIEW
Scheme 5: PASSENGER SIDE KNEE BAR ASSEMBLY OVERVIEW
  1. Left knee bar Removing and Installing, refer to «KNEE BAR, LEFT PASSENGER SIDE»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__knee-bar-left-passenger-side)
  2. Bolt 10 Nm
  3. Central Tube
  4. Bolt 10 Nm
  5. Right knee bar Removing and Installing, refer to «RIGHT PASSENGER SIDE KNEE BAR»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__right-passenger-side-knee-bar)
  6. Bolt 10 Nm
  7. Bolt 3 Nm
  8. Knee bar brace attach self-adhesive felt strips between A/C unit and knee bar brace Removing and Installing, refer to «PASSENGER SIDE KNEE BAR BRACE»(/audi/q7/4l-2009-2015/remont/seats/#interior-equipment__passenger-side-knee-bar-brace)
  9. Bolt 10 Nm
  10. Bolt 3 Nm
  11. Bolt 10 Nm
