Front Suspension Audi Q5 I

GENERAL REPAIR INFORMATION

When installing waxed components, contact surfaces must be cleaned. Contact surfaces must be free of wax and grease.

Torque specifications for unlubricated bolts and nuts are given.

Always replace self-locking nuts and bolts.

Always replace the bolts and nuts, which are tightened with an additional tightening angle.

Welding or straightening operations are not permitted on load-bearing or wheel-controlling components.

Always avoid the following actions with coil springs: Striking with a hammer, welding beads, applying color identification later.

Do not perform any welding or grinding (separating work) in coil spring or suspension strut area! Cover coil spring or suspension struts if necessary.

When loosening, removing or installing hydraulic, pneumatic or electrical line, always make a sketch or take a picture. Doing so records the original installation locations.

If the cable ties, brackets or mounting elements were removed during the repair procedure, they must be installed at their original location.

Do not let the drive axle hang down. The inner joint could be damaged if it is bent too far.

Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If vehicle does have to be moved, always note the following points

Install an outer joint in place of the drive axle.

Tighten the threaded connection between the drive axle and the wheel hub to 200 Nm.

Bonded rubber bushings can only be turned to a limited extent. Only tighten threaded connections at control arms if vehicle is in curb weight position or control position.

1. Wheel bearing, lifting to curb weight position on vehicles with coil springs, refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .

As a running change in MY 2010, aluminum coupling rods were replaced by plastic coupling rods. It is not permitted to use different coupling rods on an axle.

If the vehicle must still have an axle alignment, every bolt and nut that must be loosened for adjustment must be tightened to the tightening specification. Tighten the bolts and nuts to the specified additional tightening angle after the alignment/adjustment is complete.

CONTACT CORROSION

Contact corrosion can occur when incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fastening elements with a special surface coating are installed.

In addition, rubber and plastic parts and adhesive are of non-conducting materials.

If there are doubts as to whether parts should be reinstalled, install new parts.

Note. Only use genuine Audi replacement parts. They have been checked and are compatible with aluminum. Accessories must be approved by Audi AG. Damage due to contract corrosion is not covered under warranty!

LONGITUDINAL MEMBER THREADS, REPAIRING

It is possible to service the threads of the weld nuts in the longitudinal member depending on certain conditions.

1. Servicing work may only be performed once per thread.
2. If servicing is necessary after this, the nuts must be replaced.
3. Have the thread repair checked by the responsible foreman or next person in charge.
4. Thread insert must be same length as thread in body.
5. Repair any damage to the underbody sealant.

DRIVE AXLE

The wheel bearing must not be under a load while the drive axle threaded connection on the wheel side is loose.

If the bearings are loaded by the vehicle's own weight the wheel bearing will be damaged. This reduces the service life of the wheel bearings. Therefore observe the following

1. Procedure for loosening drive axle to wheel hub threaded connection. Refer to «THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__threaded-connection-between-drive-axle-and) .

Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If vehicle does have to be moved, always note the following points

Install an outer joint in place of the drive axle.

Tighten outer joint to 200 Nm.

Do not let the drive axle hang down. The inner joint could be damaged if it is bent too far.

WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION

Special tools and workshop equipment required

1. Engine/transmission jack V.A.G 1383 A
2. Tensioning strap T10038
3. Wheel hub support T10149

Note. All bolts at suspension parts with bonded rubber bushings must always be tightened in curb weight position (unloaded condition).

Bonded rubber bushings can only be turned to a limited extent.

Parts with bonded rubber bushings must therefore be brought into a position that corresponds to the position in driving mode before being tightened (curb weight position).

Otherwise, the bonded rubber bushing will be stressed resulting in a shortened service life.

By raising appropriate suspension using V.A.G 1383 A and T10149, this position can be simulated on the hoist.

Before starting the work, take measurement -a-, for example, with a tape measure, from the center of the wheel to the lower edge of the wheel housing.

Scheme 1

Note. Measurement must be performed in curb weight position (unloaded condition).

Note measured value. It will be required for tightening bolts/nuts.

Remove the wheel.

Turn the wheel hub until one of the holes for the wheel bolts is on top.

Install T10149 with wheel bolt on wheel hub.

Note. Tightening of the respective bolts/nuts must only occur if dimension -a-, measured before installation between wheel hub center and lower edge of wheel house, has been attained.

Using V.A.G 1383 A, lift wheel bearing housing until dimension -a- is reached.

Scheme 2

Tighten respective bolts/nuts.

Lower wheel bearing housing.

Remove V.A.G 1383 A under vehicle.

Remove T10149.

Scheme 3

1. I - Refer to «SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
2. II - Refer to «ELECTRONIC DAMPING ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
3. III - Refer to «SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
4. IV - Refer to «TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
5. V - Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
6. VI - Refer to «DRIVE AXLE ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .

Scheme 4

1. Subframe Removing and installing, refer to «SUBFRAME»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe) .
2. Bolt 9 Nm
3. Bolt 20 Nm
4. Subframe Shield Installed depending on the engine version. Removing and installing, refer to «SUBFRAME SHIELD»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe-shield) .
5. Bolt 20 Nm
6. Subframe Shield Installed depending on the engine version.
7. Subframe Shield Installed depending on the engine version. Removing and installing, refer to «SUBFRAME SHIELD»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe-shield) .
8. Bolt 9 Nm
9. Bolt 20 Nm
10. Bolt 20 Nm
11. Subframe Shield Installed depending on the engine version.
12. Bolt Tightening specification, refer to «[For engine(s) CAEB] Description and Operation»(ref-515383-S25909791852012120300000) or to «[For engine(s) CALB] Description and Operation»(/audi/q5/i-2008-2012/remont/mechanical/#32l-engine-assembly-engine-codes-calb) .
13. Retaining Plate For the engine mount.
14. Engine Mount Removing and installing, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515383-S00886538612012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/mechanical/#32l-engine-assembly-engine-codes-calb) .
15. Bolt Tightening specification, refer to «[For engine(s) CAEB] Description and Operation»(ref-515383-S25909791852012120300000) or to «[For engine(s) CALB] Description and Operation»(/audi/q5/i-2008-2012/remont/mechanical/#32l-engine-assembly-engine-codes-calb) .
16. Square Nut Always replace if removed.
17. Bolt 115 Nm + 90° turn Always replace if removed. Tightening sequence or procedure for tightening the subframe. Refer to «SUBFRAME»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe) .
18. Stud Replace if damaged.
19. Bolt 115 Nm + 90° turn Always replace if removed. Tightening sequence or procedure for tightening the subframe. Refer to «SUBFRAME»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe) .
20. Bolt Tightening specification, refer to «[For engine(s) CAEB] Description and Operation»(ref-515383-S25909791852012120300000) or to «[For engine(s) CALB] Description and Operation»(/audi/q5/i-2008-2012/remont/mechanical/#32l-engine-assembly-engine-codes-calb) .
21. Bolt 90 Nm + 90° turn Always replace if removed.
22. Subframe Crossbrace Removing and installing, refer to «SUBFRAME CROSSBRACE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__subframe-crossbrace) . CAUTION: The suspension components could be damaged. If the subframe, the steering gear or the subframe crossbrace are not installed correctly, do not rest the vehicle on its wheels. The vehicle must not be supported on the subframe or the subframe crossbrace (e.g. using a floor jack).
23. Shock Absorber Fork
24. Bolt 40 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
25. Coupling Rod There are versions made of aluminum and plastic. A mixed installation is not permitted. Removing and installing, refer to «COUPLING ROD»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__coupling-rod) .
26. Bolt 40 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
27. Nut 25 Nm Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
28. Clamp
29. Rubber Bushing When installing the subframe, the rubber bushing opening must face up. The stabilizer bar and rubber bushing must be free of grease when installing.
30. Stabilizer Bar Removing and installing, refer to «STABILIZER BAR»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__stabilizer-bar) .
31. Nut Always replace if removed.

Scheme 5

1. Charisma Switch Module -E592- Component location: The module is installed in the instrument panel.
2. Electronic Damping Control Module -J250- Removing and installing, refer to «ELECTRONIC DAMPING CONTROL MODULE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__electronic-damping-control-module) . Component location: The module is located behind the right luggage compartment side trim panel. If the module is replaced, then the control position must be reprogrammed. Refer to «CONTROL POSITION, PROGRAMMING USING VAS 5051B»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__control-position-programming-using-vas-5051b) . If the control position was reprogrammed on vehicles with lane assist, the lane assist control module -J759- must be recalibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__lane-assist-calibration-procedure) .
3. Shock Absorber with Right Rear Dampening Adjustment Valve -N339- Removing and installing, refer to «SHOCK ABSORBER»(/audi/q5/i-2008-2012/remont/suspension-rear/#rear-suspension__shock-absorber) .
4. Left Rear Level Control System Sensor -G76- and Right Rear Level Control System Sensor -G77- Removing and installing, refer to «LEVEL CONTROL SYSTEM SENSOR»(/audi/q5/i-2008-2012/remont/suspension-rear/#rear-suspension__level-control-system-sensor) . If the rear level control system sensor were removed and installed or if the linkage was loosened, the control position must be reprogrammed on vehicles with electronically controlled damping. Refer to «CONTROL POSITION, PROGRAMMING USING VAS 5051B»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__control-position-programming-using-vas-5051b) . If the control position was reprogrammed on vehicles with lane assist, the lane assist control module must be recalibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__lane-assist-calibration-procedure) . On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to «[For engine(s) CAEB, CALB] Diagnosis and Testing»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
5. Rear Body Acceleration Sensor -G343- Removing and installing, refer to «REAR BODY ACCELERATION SENSOR»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__rear-body-acceleration-sensor) .
6. Shock Absorber with Left Rear Dampening Adjustment Valve -N338- Removing and installing, refer to «SHOCK ABSORBER»(/audi/q5/i-2008-2012/remont/suspension-rear/#rear-suspension__shock-absorber) .
7. Left Front Body Acceleration Sensor -G341- and Right Front Body Acceleration Sensor -G342- Removing and installing, refer to «FRONT BODY ACCELERATION SENSORS»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__front-body-acceleration-sensors) .
8. Shock Absorber with Left Front Dampening Adjustment Valve -N336- Suspension strut, removal and installation, refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-with-mounting-bracket) . Installing the suspension strut, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) .
9. Left Front Level Control System Sensor -G78- and Right Front Level Control Sensor -G289- Removing and installing, refer to «LEVEL CONTROL SYSTEM SENSOR»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__level-control-system-sensor) . If the front level control system sensor were removed and installed or if the linkage was loosened, the control position must be reprogrammed on vehicles with electronically controlled damping. Refer to «CONTROL POSITION, PROGRAMMING USING VAS 5051B»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__control-position-programming-using-vas-5051b) . If the control position was reprogrammed on vehicles with lane assist, the lane assist control module must be re-calibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__lane-assist-calibration-procedure) . On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to «[For engine(s) CAEB, CALB] Diagnosis and Testing»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
10. Shock Absorber with Right Front Dampening Adjustment Valve -N337- Removal and installation, refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-with-mounting-bracket) . Servicing, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) .

Scheme 6

1. Nut 20 Nm
2. Tower Brace Removing and installing, refer to «TOWER BRACE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__tower-brace) .
3. Nut 2 Nm
4. Bolt 20 Nm
5. Left Additional Reinforcement Removing and installing, refer to «TOWER BRACE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__tower-brace) .
6. Nut 50 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) . Push toward the inside of the vehicle when tightening the control arm.
7. Upper Rear Control Arm Removing and installing, refer to «UPPER CONTROL ARM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__upper-control-arm) .
8. Bolt Always replace if removed.
9. Bolt Always replace if removed.
10. Washer
11. Wheel Bearing Housing
12. Nut 40 Nm Always replace if removed.
13. Upper Front Control Arm Removing and installing, refer to «UPPER CONTROL ARM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__upper-control-arm) .
14. Bolt Always replace if removed.
15. Nut 50 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) . Push toward the inside of the vehicle when tightening the control arm.
16. Nut 90 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
17. Washer
18. Bolt Always replace if removed.
19. Track Control Arm
20. Shock Absorber Fork Removing and installing, refer to «SHOCK ABSORBER FORK»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__shock-absorber-fork) .
21. Bolt 40 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
22. Coupling Rod Note installed position. Refer to «COUPLING ROD»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__coupling-rod) . There are versions made of aluminum and plastic. A mixed installation is not permitted.
23. Bolt 40 Nm + 180° turn Always replace if removed.
24. Nut Always replace if removed.
25. Suspension Strut Removing and installing, refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-with-mounting-bracket) . Servicing, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) . Note different types of suspension versions, see vehicle data plate. Refer to «EXPLANATIONS OF PRODUCTION CONTROL NUMBERS»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__explanations-of-production-control-numbers) . Faulty shock absorbers must be vented and emptied before disposal. Refer to «FRONT GAS-FILLED STRUT, VENTING AND EMPTYING»(/audi/q5/i-2008-2012/remont/manual-power-steering/#general-technical-data-suspension-wheels-steering__front-gas-filled-strut-venting-and-emptying) . Check removed shock absorber. Refer to «SHOCK ABSORBERS, REMOVED, CHECKING»(/audi/q5/i-2008-2012/remont/manual-power-steering/#general-technical-data-suspension-wheels-steering__shock-absorbers-removed-checking) .
26. Right Additional Reinforcement Removing and installing, refer to «TOWER BRACE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__tower-brace) .
27. Bolt 40 Nm + 90° turn Follow tightening sequence. Refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-with-mounting-bracket) . Always replace if removed.

Scheme 7

1. Bolt Always replace if removed.
2. Guide Link Removing and installing, refer to «GUIDE LINK»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__guide-link) . There are conventional and hydraulic bonded rubber bushings. Replacing the standard rubber metal bearing, 65 mm diameter for the guide link, refer to «CONVENTIONAL BONDED RUBBER BUSHING, 65 MM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__conventional-bonded-rubber-bushing-65-mm) . Replacing the hydraulic bonded rubber bushing, 75 mm diameter for the guide link, refer to «HYDRAULIC BONDED RUBBER BUSHING, 75 MM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__hydraulic-bonded-rubber-bushing-75-mm) .
3. Nut 70 Nm + 180° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
4. Wheel Bearing Housing
5. Bolt 40 Nm Always replace if removed.
6. Nut Always replace if removed. There are different versions depending on the vehicle. There are different bolts and tightening specifications. Refer to «TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . After loosening the threaded connection on the guide link on the wheel bearing housing, remove the remaining adhesive from the screw thread.
7. Ball Joint Removing and installing, refer to «BALL JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . There are different versions depending on the vehicle. NOTE: Pay attention to the installed position. Refer to «BALL JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . Install the ball joint up to the contact surface in the wheel bearing housing.
8. Nut There are different versions depending on the vehicle. There are different bolts and tightening specifications. Refer to «TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . Always replace if removed. After loosening the threaded connection on the ball joint on the wheel bearing housing, remove the remaining adhesive from the screw thread.
9. Nut 90 Nm + 90° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
10. Track Control Arm Removing and installing, refer to «TRACK CONTROL ARM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__track-control-arm) . There are different versions depending on the vehicle. Control arm mount, replacing, refer to «TRACK CONTROL ARM MOUNT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__track-control-arm-mount) .
11. Bolt Always replace if removed.
12. Nut 9 Nm
13. Bolt Always replace if removed.
14. Nut 70 Nm + 180° turn Always replace if removed. Must be tightened in the curb weight position. Refer to «WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-lifting-to-curb-weight) .
15. Left Front Level Control System Sensor or Right Front Level Control Sensor The only sensors that may be installed must be the same type. Either completely remove and install or replace. Refer to «LEVEL CONTROL SYSTEM SENSOR»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__level-control-system-sensor) . The sensor lever must point toward the rear. Check the basic setting for the headlamp adjustment after loosening. Refer to «[For engine(s) CAEB, CALB] Diagnosis and Testing»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) . The control position must be "retaught" if the vehicle level sensor has been removed or installed, or if the linkage rod has loosened, in vehicles equipped with electronic damping. Refer to «CONTROL POSITION, PROGRAMMING USING VAS 5051B»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__control-position-programming-using-vas-5051b) . The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__lane-assist-calibration-procedure) .
16. Bolt 20 Nm
17. Shock Absorber Fork

Scheme 8

1. Hex-collar nut -A- M12 special wrench 21 mm

Tightening specification: 145 Nm

1. Hex-combination nut -B- M12 special wrench 18 mm

Tightening specification: 110 Nm

1. Hex-combination nut -B- M12 special wrench 21 mm

Tightening specification: 120 Nm

1. Hex-combination nut -B- M12 special wrench 21 mm

Tightening specification: 140 Nm

Scheme 9

1. Nut 40 Nm Always replace if removed.
2. Upper Front Control Arm
3. Upper Rear Control Arm
4. Bolt Always replace if removed.
5. Washer
6. Wheel Bearing Housing Removing and installing, refer to «WHEEL BEARING HOUSING»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-housing) . There are different versions depending on the vehicle. Distinguishing characteristic. Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . WARNING: When exchanging the wheel bearing housing, make sure the length of the thread on the tie rod end is sufficient (there must be approximately 5 mm extra thread). If this is not the case, then install a new tie rod end with a longer thread pin.
7. Brake Shield
8. Bolt 10 Nm
9. Bolt 200 Nm + 180° turn Replace after each removal. Refer to «DRIVE AXLE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__drive-axle) . Before installing, clean the threads in the CV joint with a tap.
10. Wheel Hub Ejecting and pressing in, refer to «WHEEL BEARING UNIT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
11. Wheel Bearing Ejecting and pressing in, refer to «WHEEL BEARING UNIT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . CAUTION: Avoid contaminating with dirt and damaging the seal when setting down/storing. Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
12. Bolt 40 Nm Always replace if removed.
13. Nut Always replace if removed. There are different versions depending on the vehicle. There are different bolts and tightening specifications. Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . After loosening the threaded connection on the guide link on the wheel bearing housing, remove the remaining adhesive from the screw thread.
14. Control Arm
15. Nut Always replace if removed. There are different versions depending on the vehicle. There are different bolts and tightening specifications. Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . After loosening the threaded connection on the ball joint on the wheel bearing housing, remove the remaining adhesive from the screw thread.
16. Guide Link
17. Tie Rod End There are different versions depending on the vehicle.
18. Nut There are different versions depending on the vehicle. Pay attention to the different nut versions and to the tightening specifications. Refer to «WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . Always replace if removed.
19. Bolt 9 Nm
20. Wheel Speed Sensor
21. Drive Axle
22. Bolt 70 Nm Always replace if removed.
23. Bolts 80 Nm + 90° turn Always replace if removed.

Scheme 10

1. The wheel bearing -1- must always face up.
2. Always set the wheel bearing unit down on the wheel hub -2-.

Scheme 11

1. Hex collar nut -A

Tightening specification: 20 Nm + 90° turn

1. 12-point combi nut -B

Tightening specification: 100 Nm

1. Hex combi nut -C

Tightening specification: 110 Nm

NUT DESIGNS FOR MOUNTING CONTROL ARMS AND GUIDE LINKS

1. Hex-collar nut -A- M12 special wrench 21 mm

Tightening specification: 145 Nm

1. Hex-combination nut -B- M12 special wrench 18 mm

Tightening specification: 110 Nm

1. Hex-combination nut -B- M12 special wrench 21 mm

Tightening specification: 120 Nm

1. Hex-combination nut -B- M12 special wrench 21 mm

Tightening specification: 140 Nm

Scheme 12

1. The wheel bearing housing differs in the thickness of the steering arm -2-.

Scheme 13

1. Clamp Always replace if removed. Tensioning, refer to «LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__large-and-small-clamps-clamping-on) .
2. Protective Boot with Triple Roller Joint Adapter Protective joint boot must fit in groove and on joint contour. Before tightening clamp, briefly raise CV boot to allow pressure to equalize.
3. Clamp Always replace if removed. Tensioning, refer to «LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__large-and-small-clamps-clamping-on) .
4. Securing Ring Always replace if removed. Insert before mounting in ring groove (not visible with joint installed). Before installing CV joint, align sealing ring in center with opening facing upward.
5. Outer CV Joint Replace only as complete unit. Removing, refer to «OUTER CV JOINT WITH DIAMETER 88 MM/100 MM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__outer-cv-joint-with-diameter-88) . Checking, refer to «OUTER CV JOINT, CHECKING»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__outer-cv-joint-checking) . Installing, refer to «OUTER CV JOINT WITH DIAMETER 88 MM/100 MM»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__outer-cv-joint-with-diameter-88) . Greasing, refer to «DRIVE AXLE ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) . When installing joint on axle shaft, splines on axle shaft must be lightly coated with grease used in joint.
6. Bolt 200 Nm + 180° turn Always replace if removed. Before installing, clean the threads in the CV joint with a tap. Follow the sequence when loosening and tightening the threaded connection between the drive axle and the wheel hub. Refer to «THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__threaded-connection-between-drive-axle-and) .
7. Clamp Always replace if removed. Tensioning, refer to «LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__large-and-small-clamps-clamping-on) .
8. CV Boot for Outer CV Joint Check for tears and scuffing. Before tightening clamp, briefly raise CV boot to allow pressure to equalize.
9. Clamp Always replace if removed. Tensioning, refer to «LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__large-and-small-clamps-clamping-on) .
10. Drive Axle Removing and installing, refer to «DRIVE AXLE»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension) .
11. Securing Ring
12. Triple Roller Star The chamfer -arrow- faces the drive axle splines. When installing triple roller star on axle shaft, splines on axle shaft must be lightly coated with grease used in joint.
13. Securing Ring Always replace if removed. Insert in shaft groove.
14. Bolt 70 Nm Always replace if removed.
15. Joint Piece

GREASE QUANTITY AND TYPE

Grease joint when replacing CV boot.

Pack the joint with grease.

Note. Note that the outer and inner joints use different types of grease.

THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING

Special tools and workshop equipment required

1. Angle wrench V.A.G 1756

Loosening

With vehicle still standing on its wheels, loosen bolt a maximum of 90°, otherwise wheel bearing will be pre-damaged.

Lift the vehicle just enough so that the wheels are hanging free.

Operate brake (second mechanic required).

Remove bolt -arrow-.

Scheme 14

Tightening

Replace bolt -arrow-.

Note. Before installing, clean the threads in the CV joint with a tap. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.

Operate brake (second mechanic required).

Tighten bolt to 200 Nm.

Lower the vehicle onto its wheels.

Tighten bolt an additional 180°.

FASTENER TIGHTENING SPECIFICATIONS

CONTROL POSITION, PROGRAMMING USING VAS 5051B

Special tools and workshop equipment required

1. Vehicle diagnosis, testing and information system VAS 5051B with corresponding diagnostic cable.

Connect the VAS 5051B to the vehicle using the appropriate diagnostic cable.

Switch VAS 5051B on.

VAS 5051B is ready to operate when it displays operating modes in button fields.

Switch on ignition.

Requirements

1. The vehicle must be standing on an even surface.
2. The vehicle may not be loaded.
3. The Electronic Damping Control Module -J250- must be coded.
4. The DTC memory may not contain any vehicle level sensor -- DTC memory entries.

Note. If control modules or electric/electronic components were replaced, then the components must be adapted under "Guided Functions".

Touch Guided Functions and the screen.

Then

Select the corresponding program in "Guided Functions".

Follow the prompts on the screen.

Note. If the control position was programmed again on vehicles with lane assist, the directional stabilization assistance control module -J759- with integrated camera must be recalibrated. Refer to LANE ASSIST CALIBRATION PROCEDURE .

OUTER CV JOINT, CHECKING

It is necessary to disassemble the joint whenever replacing the grease or if the ball surfaces show wear or damage.

Disassembling

Mark position of ball hub to ball cage and to housing before disassembling, using electro-writer or grindstone.

Scheme 15

Swing ball hub and ball cage.

Remove balls in sequence.

Turn cage, until two rectangular windows -arrow- contact joint body.

Scheme 16

Lift out cage with hub.

Swing hub segment with smaller pins into rectangular window on cage.

Scheme 17

Fold hub out from cage.

Checking

6 balls for each joint belong to a tolerance group. Check stub axle, hub, cage and balls for small depressions (pitting build-up) and chafing. Excessive circumferential backlash in joint makes itself noticed via tip-in shock, in such cases joint should be replaced. Flattening and running marks of balls are no reason to replace joint.

Assembling

Insert cage with hub into joint body.

Note. Cage must be installed laterally correct.

Press in opposing balls in sequence, during this, previous position of ball hub to ball cage and to joint body must be established again.

Press the grease into the joint body. Refer to DRIVE AXLE ASSEMBLY OVERVIEW .

SUBFRAME

Special tools and workshop equipment required

1. Engine/transmission jack V.A.G 1383 A
2. Tensioning strap T10038
3. Wheel hub support T10149

Removing

Remove wheels.

Remove noise insulation. Refer to Description and Operation .

Remove the left and right wheel housing liner. Refer to Removal and Installation .

Remove the crossbrace. Refer to SUBFRAME CROSSBRACE .

Remove the right and left subframe shield if applicable. Refer to SUBFRAME SHIELD .

Remove the stabilizer bar. Refer to STABILIZER BAR .

Applies to Vehicles with Hydraulic Steering Gear

Remove steering gear. Refer to STEERING GEAR .

Applies to vehicles with Electromechanical Steering Gear

Remove steering gear. Refer to STEERING GEAR .

Continuation for All Vehicles

Remove the level control system sensor, if applicable. Refer to LEVEL CONTROL SYSTEM SENSOR .

Secure the left and right wheel housing liner to the mounting bracket using a T10038 as illustrated.

Scheme 18

Remove the left and right control arms. Refer to TRACK CONTROL ARM .

Support the engine entirely using the engine support bridge. Refer to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CALB] Removal and Installation .

Remove the bolts -1- and nuts -3- and the longitudinal braces -2-.

Scheme 19

Remove the bolt -1-.

Scheme 20

Move the guide link and secure it to the body with wire.

On vehicles with electro-hydraulic engine mounts, disconnect the left electro-hydraulic engine mount solenoid valve -N144- and right electro-hydraulic engine mount solenoid valve -N145- connector -arrow-.

Scheme 21

Depending on the engine version, remove the nut -2- for the electrical wiring bracket on the right side of the vehicle.

Applies to Vehicles with Hydraulic Steering Gear

Scheme 22

Remove the bolt for the power steering line bracket -arrow-.

Continuation for All Vehicles

Scheme 23

Remove the left and right engine mount bolts -1 and 5-.

Move the left and right engine mount retaining plate -2- to the side.

Note. Before lowering the subframe, make sure all the electrical wiring connections have been disconnected and removed.

Note. Mark the installation location of the subframe -A- to -D-, for example, using a felt-tip pen.

Remove the bolts -1- through -8- and remove the subframe.

Scheme 24

Installing

Install in reverse order of removal. Note the following

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

Tightening specifications, refer to SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW .

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Tightening specifications, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

SUBFRAME BOLTING PROCEDURE

Insert the subframe and align according to the markings -A- and -B- made earlier. Tighten bolts -2- and -3- to the specification.

Press the subframe at the markings -C- or -D- and tighten the bolts -5- and -8- to the specification.

Insert the bolts -1-, -4-, -6- and -7- and tighten to the specification.

Tighten the bolts -1- through -8- with an additional turn.

Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position. Wheel bearing, lifting to curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

If the vehicle level sensor was removed and installed on a vehicle with electronically controlled damping or if the linkage was loosened, the control position must be reprogrammed. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

If the control position was reprogrammed on vehicles with lane assist, the lane assist control module -J759- must be re-calibrated. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Tighten wheel. Refer to Specifications .

Axle alignment is required, see Table. Refer to WHEEL ALIGNMENT .

SUBFRAME CROSSBRACE

Removing

Remove noise insulation. Refer to Description and Operation .

Applies to Vehicles with Hydraulic Power Steering

Scheme 25

Remove the power steering line bolt; refer to -1-.

Remove the bolts -arrows- and the crossbrace.

Applies to Vehicles with Electromechanical Power Steering

Scheme 26

Remove the wire on the crossbrace -1- and -2-.

Remove the bolts -arrows- and the crossbrace.

Continuation for All Vehicles

Remove the right and left subframe shield if applicable. Refer to SUBFRAME SHIELD .

Remove the square nut -arrows- from the cast recesses.

Scheme 27

Note. If the vehicle must be moved, the crossbrace must be installed with the old bolts and square nuts and tightened to the specification without any additional turning.

Installing

Install in reverse order of removal. Note the following

1. The square nuts must be inserted into the cast recesses before installing the subframe shields, where applicable.

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

STABILIZER BAR

Removing

Remove noise insulation. Refer to Description and Operation .

Disconnect left and right connectors -2-.

Scheme 28

Remove the left and right nuts -1- and the clamp -3-.

Remove the stabilizer bar.

Installing

Install in reverse order of removal. Note the following

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position. Wheel bearing, lifting to curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

Note. If you replace stabilizer, note chassis version. Stabilizer and mounting must be free of grease. Install the rubber bushing opening in the direction of the subframe contact surface.

Install the nuts -1- but do not tighten them.

Install the left and right threaded connections -2- but do not tighten them.

Wheel bearing, lifting to curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

Tighten connections -1- and -2-.

COUPLING ROD

Note. As a running change in MY 2010, aluminum coupling rods were replaced by plastic coupling rods. It is not permitted to use different coupling rods on an axle.

Removing

Scheme 29

Disconnect connections -1- and -3-.

Remove the coupling rod -2-.

Installing

Install in reverse order of removal. Note the following

Note. Note the installation position of the coupling rod. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position. Wheel bearing, lifting to curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

The bolt -1- for connecting the coupling rod to the stabilizer bar -4- must be attached to the "small" surface -2- of the coupling rod collar and secured with the nut -3-.

Scheme 30

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

Install the threaded connections -1- and -3- but do not tighten them.

Wheel bearing, lifting to curb weight position on vehicles with coil springs, refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

Tighten connections -1- and -3-.

SUBFRAME SHIELD

Removing

Remove the crossbrace. Refer to SUBFRAME CROSSBRACE .

Remove the bolts -arrows-.

Scheme 31

Remove the subframe shield -1-.

Installing

Install in reverse order of removal. Note the following

1. Insert the square nuts into the cast recesses before installing the subframe shield.

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

ELECTRONIC DAMPING CONTROL MODULE

Removing

Scheme 32

Note. The electronic damping control module -J250- is located behind the right luggage compartment side trim panel.

Switch off all electrical consumers.

Remove the ignition key.

Remove the cover from the right luggage compartment storage compartment.

Remove the towing recognition control module -J345- -1- from the control module bracket -2-, where applicable.

Remove the nuts -arrows-, pull the control module bracket -2- off the threaded pins and move it downward.

Open the clamps -A- and -B- and remove the electronic damping control module -1- from the control module bracket -2-.

Scheme 33

Unlock the connector -3- and disconnect it from the electronic damping control module -1-.

Remove the electronic damping control module -1-.

Installing

Installation is the reverse of removal, with special attention to the following

Tightening specification for the nuts, refer to [For engine(s) CAEB, CALB] Description and Operation .

Adapt the electronic damping control module. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

FRONT BODY ACCELERATION SENSORS

Special tools and workshop equipment required

1. Torque wrench V.A.G 1410

Removing

Raise the vehicle.

Release and disconnect the connector -2-.

Scheme 34

Remove the nuts -1- and remove the sensors -4- from the bracket -3-.

Installing

Install in reverse order of removal. Note the following

When installing, always pay attention to the installation position of the sensor.

Install the sensor -4- as illustrated.

Tighten the nuts -1- to 8 Nm.

Tightening specification for the nuts -5- : 5 Nm.

REAR BODY ACCELERATION SENSOR

Special tools and workshop equipment required

1. Torque wrench V.A.G 1410

Removing

Scheme 35

Remove the left rear wheel.

Remove the left rear wheel housing liner. Refer to Removal and Installation .

Release and disconnect the connector -2-.

Remove the bolts -1- and the sensor -3-.

Installing

Install in reverse order of removal. Note the following

When installing, always pay attention to the installation position of the sensor.

Install the sensor -3- as illustrated.

Tighten the bolts -1- to 5 Nm.

SUSPENSION STRUT WITH MOUNTING BRACKET

Special tools and workshop equipment required

1. Spreader 3424
2. Torque wrench V.A.G 1331
3. Torque wrench V.A.G 1332
4. Wheel hub support T10149
5. Engine/transmission jack V.A.G 1383 A

Removing

Remove the wheel.

Remove the additional reinforcement. Refer to TOWER BRACE .

Remove the plenum chamber cover. Refer to Removal and Installation .

Applies to a Vehicle with Electronically Controlled Damping

Scheme 36

Release and remove the connector -3-.

Remove brackets -1- and -2- and expose the wire.

Continuation for All Vehicles

Remove shock absorber fork. Refer to SHOCK ABSORBER FORK .

Remove the nuts -1- and the cover -2-.

Scheme 37

Remove the bolts -arrows- from the flange shaft/transmission.

Scheme 38

Remove the brake line and wires from the bracket on the wheel bearing housing.

Turn the wheel hub until one of the holes for the wheel bolts is on top.

Install T10149 -1- with wheel bolt on wheel hub.

Scheme 39

Support wheel bearing housing over the T10149 -1- with V.A.G 1383 A.

Remove the bolt -1-.

Scheme 40

The slits in the wheel bearing housing must not be widened using a chisel or similar tool!

Remove booth joint pins in the upper control arm -2- from the wheel bearing housing.

Note. Do not lower wheel bearing housing more than necessary.

Remove the bolts -1 through 4- and remove the suspension strut with mounting bracket.

Scheme 41

Installing

Install in reverse order of removal. Note the following

Note. Always observe the tightening sequence for the mounting bracket threaded connection with the suspension strut to the suspension strut tower.

Install and tighten the bolts, on after the other, in the following sequence -1, 2, 3- and -4-.

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

Tightening specifications, refer to SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW .

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Tightening specifications, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

Note. Push the upper control arms down as far as possible while tightening the bolts!

Tighten the threaded connection -1-.

Note. On vehicles with electronically controlled damping, make sure the T-pin -arrow- fits into the groove in the shock absorber fork when being installed.

Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position.

Wheel bearing, lifting to curb weight position on vehicles with coil springs, refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

If the vehicle level sensor was removed and installed on a vehicle with electronically control damping or if the linkage was loosened, the control position must be programmed once again. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

If the control position was reprogrammed on vehicles with lane assist, the lane assist control module -J759- must be re-calibrated. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Tighten wheel. Refer to Specifications .

Axle alignment is required, see Table. Refer to WHEEL ALIGNMENT .

SHOCK ABSORBER FORK

Special tools and workshop equipment required

1. Spreader 3424
2. Torque wrench V.A.G 1331
3. Torque wrench V.A.G 1332
4. Ball joint puller T40010 A

Removing

Remove the wheel.

Remove noise insulation. Refer to Description and Operation .

In vehicles with level control system sensor, unscrew nut -2-.

Scheme 42

Remove the bolt -2-.

Disconnect connections -1- and -3-.

Remove the coupling rod -2-.

Remove the nut -1- from the tie rod end joint pin -2- until it is flush with the joint pin threads. Counterhold when loosening if necessary.

Scheme 43

Note. To protect thread, screw nut on pin a few turns.

Press off track rod ball joint from wheel bearing housing using T40010 A. Remove the nut.

Scheme 44

Remove the bolt -3-.

Separate the threaded connection -1- and guide the control arm out and tilt it forward.

Note. To remove the bolt -1-, turn the steering gear all the way to the left or right depending on the side of the vehicle.

Remove the bolt -1-.

Scheme 45

Insert 3424 into slot of wheel bearing housing.

Scheme 46

Using a ratchet and the 3424, open the wheel bearing housing slot.

Pull the shock absorber fork downward from the shock absorber tube and remove it.

Installing

Install in reverse order of removal. Note the following

Tightening specifications, refer to SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW .

Tightening specifications, refer to TRACK CONTROL ARM .

Note. On vehicles with electronically controlled damping, make sure the T-pin -arrow- fits into the groove in the shock absorber fork when being installed.

Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position.

Wheel bearing, lifting to curb weight position on vehicles with coil springs, refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

If the vehicle level sensor was removed and installed on a vehicle with electronically controlled damping or if the linkage was loosened, the control position must be reprogrammed. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

If the control position was reprogrammed on vehicles with lane assist, the lane assist control module -J759- must be re-calibrated. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Tighten wheel. Refer to Specifications .

Axle alignment is required, see Table. Refer to WHEEL ALIGNMENT .

UPPER CONTROL ARM

Special tools and workshop equipment required

1. Wheel hub support T10149
2. Engine/gearbox jack V.A.G 1383 A

Removing

Remove the wheel.

Turn the wheel hub until one of the holes for the wheel bolts is on top.

Install T10149 -1- with wheel bolt on wheel hub.

Support wheel bearing housing over the T10149 -1- with V.A.G 1383 A.

Remove the bolt -1-.

Remove booth joint pins in the upper control arm -2- from the wheel bearing housing.

Note. Do not lower wheel bearing housing more than necessary.

The slits in the wheel bearing housing must not be widened using a chisel or similar tool!

Remove the nuts -3- and -6-.

Remove the bolts -4- and -5- and remove the upper control arm upward.

Installing

Install in reverse order of removal. Note the following

Tightening specifications, refer to SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW .

Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension screws when vehicle is in curb weight or control position.

Insert the upper control arm and the bolts -4- and -5-.

Install the nuts -3- and -6- and tighten by hand.

Insert both of upper control arm joint pins -2- in the wheel bearing housing and insert the bolt -1-.

Note. Push the upper control arms down as far as possible while tightening the bolts!

Tighten the threaded connection -1-.

Wheel bearing, lifting to curb weight position on vehicles with coil springs, refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION .

Note. The upper control arm must be pressed toward the inside of the vehicle when tightening the nuts -3- and -6-.

Tighten the nuts -3- and -6-.

Tighten wheel. Refer to Specifications .

Axle alignment is required, see Table. Refer to WHEEL ALIGNMENT .

FRONT AND REAR UPPER CONTROL ARM BUSHING

Special tools and workshop equipment required

1. Assembly tool 3301
2. Assembly tool 3348

Note. Control arms must only be clamped in a vise with protective vise jaw lining!

Scheme 47

Scheme 48

A- = ~ 90° +/- 5°

Scheme 49

A- = bearing

Note. Do not use lubricant!

TOWER BRACE

Special tools and workshop equipment required

1. Torque wrench V.A.G 1331

Remove the Tower Brace and Additional Reinforcement

Scheme 50

Remove the nuts -2-, -5- and the right and left bolts -3- and then remove the tower brace -1-.

Remove the Right or Left Additional Reinforcements

Remove the bolt -3- and -6- from the additional reinforcement being removed and then remove the reinforcement -4- or -7-.

Installing

Install in reverse order of removal. Note the following

Tightening specifications, refer to SUSPENSION STRUT WITH BRACKET, SHOCK ABSORBER, UPPER CONTROL ARM AND TOWER BRACE ASSEMBLY OVERVIEW .

TRACK CONTROL ARM

Special tools and workshop equipment required

1. Engine/transmission jack V.A.G 1383 A
2. Ball joint puller T40010 A
3. Ring socket wrench V.A.G 1332/10
4. Ring socket wrench V.A.G 1332/7

Removing

Remove the wheel.

Remove the noise insulation. Refer to Description and Operation .

Remove in vehicles with vehicle level sensor nut -2-.

Disconnect the connectors -3-.

Unscrew the nut -1- from the joint pin -2- on the tie rod end as far as required to make it flush with the threading on the joint pin. Counterhold it if you have to when loosening.

Note. Turn the nut a couple of turns on the pin to protect the threading.

Use the T40010 A to force the tie rod end off of the wheel bearing housing. Next, remove the nut.

Note. Make sure that both lever arms on the puller are parallel to each other when you exert a great deal of force on them; adjust them so that they are parallel, if necessary.

Disconnect the connectors -1-.

Note. To remove the bolt, -1- turn the steering gear completely to the left or right, depending on the side of the vehicle you are on.

Remove the control arm and pivot it to the rear.

Unscrew the nut from the joint pin on the ball joint just far enough to make it flush with the threading on the joint pin. Counterhold it if you have to when loosening.

Use a T40010 A to force the joint pin on the control arm off of the conical seat.

Scheme 51

Note. Make sure that both lever arms on the puller are parallel to each other when you exert a great deal of force on them; adjust them so that they are parallel, if necessary. Make sure not to damage the CV boot when doing this! The wheel bearing housing must be braced against too much rebound, e.g. by using the V.A.G 1383 A, so that the joints on the upper control arm are not damaged.

Remove the nut(s) from the joint pin on the control arm.

Remove the control arm.

Installing

Install in reverse order of removal. Pay attention to the following

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Note. Bonded rubber bushings have a limited range of rotation. Therefore, do not pull the threaded connections on the wheel suspension tightly until the vehicle is positioned in the curb weight or control position. Raise the wheel bearing in curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . The control arm must be depressed toward the inside of the vehicle when tightening the threaded connection -1-.

Remove the remaining adhesive still stuck to the threads on the pin from the control arm.

Perform a headlamp basic setting on vehicles with automatic range control. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

The control position must be "retaught" if the vehicle level sensor has been removed or installed, or if the linkage rod has loosened, in vehicles equipped with electronic damping. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Tighten the front wheels. Refer to Specifications .

Axle alignment required; see table. Refer to WHEEL ALIGNMENT .

TRACK CONTROL ARM MOUNT

Special tools and workshop equipment required

1. Pressure plate VW 402
2. Punch VW 412
3. Subframe support assembling device 3301
4. Subframe support assembling device 3346
5. Subframe support assembling device T10030
6. Assembly paste

Removing and Installing the Control Arm Mounting (On the Wheel Bearing Housing Side)

Note. Hold on to the mounting firmly as you remove and install the control arm.

Removing

Scheme 52

Remove the control arm. Refer to TRACK CONTROL ARM .

Mark the press-in depth on the mount -1- -arrow-.

Note. Use a waterproof felt-tip pen/marker to make the mark.

Lay out the special tools as shown in the illustration.

1. VW 412
2. Thrust piece T10030/1
3. Bearings
4. Control arm
5. Sleeve-press tool 3301/3
6. Bearing race 3301/1
7. VW 402

Remove the mount -3- from the control arm -4-.

Installing

Scheme 53

Transfer the mark you made for the press-in depth from the old to the new mount.

Apply a thin coat of assembly paste on the mount.

Install the mount -3- in the control arm -4-.

Lay out the special tools as shown in the illustration.

1. VW 412
2. Thrust piece T10030/1
3. Bearings
4. Control arm
5. Thrust piece 3346/1
6. Bearing race 3301/1
7. VW 402

Note. Make sure that the mount does not get installed crooked when pressing it in to place.

Install the mount -3- in the control arm -4-.

Pay special attention to the press-in depth mark you made during installation -arrow-.

Check the press-in depth for the mount -1- on the control arm -2-.

Scheme 54

The -a- and -b- dimensions must be the same.

If the -a- and -b- dimensions are different, press on the mount some more -1-.

Install the control arm. Refer to TRACK CONTROL ARM .

Removing and Installing the Control Arm Mounting (On the Subframe Side)

Note. Hold on to the mounting firmly as you remove and install the control arm.

Removing

Scheme 55

Remove the control arm. Refer to TRACK CONTROL ARM .

Mark the press-in depth on the mount -3- -arrow-.

Note. Use a waterproof felt-tip pen/marker to make the mark.

Lay out the special tools as shown in the illustration.

1. VW 412
2. 3346
3. Bearings
4. Control arm
5. Sleeve-press tool 3301/4
6. Bearing race 3301/1
7. VW 402

Remove the mount -3- from the control arm -4-.

Installing

Transfer the mark you made for the press-in depth from the old to the new mount.

Scheme 56

A- = ~ 90° +/- 5°

Apply a thin coat of assembly paste on the mount.

Install the mount -1- in the control arm -2-.

Scheme 57

Lay out the special tools as shown in the illustration.

1. VW 412
2. 3346
3. Bearings
4. Control arm
5. Sleeve-press tool 3301/3
6. Bearing race 3301/1
7. VW 402

Note. Make sure that the mount does not get installed crooked when pressing it in to place.

Install the mount -3- in the control arm -4-.

Pay special attention to the press-in depth mark you made during installation -arrow-.

Check the press-in depth for the mount -1- on the control arm -2-.

Scheme 58

The -a- and -b- dimensions must be the same.

If the -a- and -b- dimensions are different, press on the mount some more -1-.

Install the control arm. Refer to TRACK CONTROL ARM .

Scheme 59

Remove track control arm. Refer to TRACK CONTROL ARM .

Remove the bolt -1-.

Install the washer-or something similar- -2- in the slit for the wheel bearing housing (the washer or whatever you use that is similar must match the slot width exactly).

Scheme 60

Install the bolt -1- up to the contact surface of the washer-or something similar-from the back side.

Widen the slot between the wheel bearing housing by continuing to turn the bolt -1- (half a rotation).

Remove the ball joint from the wheel bearing housing.

Scheme 61

Install in reverse order of removal. Pay attention to the following

Install the control arm -1- up to the contact surface -arrows- in the wheel bearing housing -2-.

Note. Not being able to install the control arm -1- up to the contact surface -arrows- could cause premature damage in the area near the threaded connection on the wheel bearing housing -2-.

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Install the track control arm. Refer to TRACK CONTROL ARM .

Tighten the front wheels. Refer to Specifications .

Axle alignment required; see table. Refer to WHEEL ALIGNMENT .

GUIDE LINK

Note. During MY 2010, guide links with standard rubber bushings were replaced with guide links with a hydraulic bonded rubber bushing. Do not mix and match guide links on one axle. Both guide links must have the same type of bushing.

Special tools and workshop equipment required

1. Engine/transmission jack V.A.G 1383 A
2. Ball joint puller T40010 A

Removing

Remove the wheel.

Remove the noise insulation. Refer to Description and Operation .

Remove the bolts -arrows- and move the subframe shield -1- to the side, where applicable.

Remove the nut from the guide link joint pins enough so it is flush with the joint pin threads. Counterhold the joint pins if necessary.

Turn the nut a couple of turns on the pin to protect the threading.

Scheme 62

Press linkage stub of guide control arm off conical seating using T40010 A.

Note. Make sure not to damage the CV boot when doing this! Make sure that both puller lever arms are parallel to each other when using greatest force.

Disconnect the connectors -1-.

Remove guide link.

Installing

Install in reverse order of removal. Pay attention to the following

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW .

Remove adhesive residue at stub thread of guide control arm.

Note. Bonded rubber bushings have a limited range of rotation. Therefore, do not pull the threaded connections on the wheel suspension tightly until the vehicle is positioned in the curb weight or control position. Raise the wheel bearing in curb weight position on vehicles with coil springs. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . When tightening the threaded connection -1-, the guide link must be pressed toward the inside of the vehicle.

Tighten the front wheels. Refer to Specifications .

Axle alignment required; see table. Refer to WHEEL ALIGNMENT .

CONVENTIONAL BONDED RUBBER BUSHING, 65 MM

Special tools and workshop equipment required

1. Pressure plate VW 402
2. Punch VW 407
3. Press tool 3345
4. Subframe support assembling device 3347/1

Note. Hold the guide link firmly in position while pressing bearing out and in.

Removing

Scheme 63

Remove guide link. Refer to GUIDE LINK .

Mark the press-in depth on the mount -1- -arrow-.

Note. Use a waterproof felt-tip pen/marker to make the mark.

Lay out the special tools as shown in the illustration.

Press bushing -1- out of guide link -2-.

Installing

Scheme 64

Transfer the installation depth marking from the old bearing to the new one -arrow-.

Apply a thin coat of assembly paste on the mount.

Scheme 65

A- = ~ 90° +/- 5°

Insert bearing -1- into guide control arm -2-, observe installation position when doing this.

Lay out the special tools as shown in the illustration.

Note. Make sure that the mount does not get installed crooked when pressing it in to place.

Press bearing -1- into guide control arm -2-.

Pay special attention to the press-in depth mark you made during installation -arrow-.

Check installation position of bearing -1- in guide control arm -2-.

A- = ~ 90° +/- 5°

Check rim offset of bearing -1- in guide control arm -2-.

Scheme 66

The -a- and -b- dimensions must be the same.

If the -a- and -b- dimensions are different, press on the mount some more -1-.

Install guide control arm. Refer to GUIDE LINK .

HYDRAULIC BONDED RUBBER BUSHING, 75 MM

Special tools and workshop equipment required

1. Pressure plate VW 402
2. Punch VW 412
3. Sleeve VW 463/2
4. Sleeve 3144
5. Shop press V.A.G 1290A
6. Installation lubricant -- (1:20 thinned with water).

Removing

Scheme 67

1. The guide link is removed. Refer to «GUIDE LINK»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__guide-link)

Mark the installed position -arrow- on the hydraulic bonded rubber bushing -4-.

Note. Use a waterproof marker.

Order the special tools as illustrated.

1. V.A.G 1290A punch
2. VW 412
3. Sleeve VW 463/2
4. Hydraulic bonded rubber bushing
5. Guide Link
6. 3144
7. VW 402

Remove the hydraulic bonded rubber bushing -4- from the guide link -5-.

Note. Hold the guide link steady when removing/installing the hydraulic bonded rubber bushing.

Installing

Transfer the marking from the old hydraulic bonded rubber bushing to the new one.

Lightly coat the new hydraulic bonded rubber bushing with installation lubricant --.

Scheme 68

The notch -1- is on the steering axle and faces the inside of the guide link.

The arrow -2- faces the inside of the guide link.

Install the hydraulic bonded rubber bushing -4- in the guide link -5- paying close attention to the installed position.

Scheme 69

Order the special tools as illustrated.

1. V.A.G 1290A punch
2. VW 412
3. Sleeve VW 463/2
4. Hydraulic bonded rubber bushing
5. Guide Link
6. 3144
7. VW 402

Note. Do not tilt the hydraulic bonded rubber bushing when installing it.

Install the hydraulic bonded rubber bushing -4- into the guide link -5-.

Pay close attention to the marking -arrow-.

Check the press-in depth -a- of the hydraulic bonded rubber bushing inside the guide link.

Scheme 70

Dimension -a- = 18 mm.

If dimension -a- if not reached, then press the hydraulic bonded rubber bushing again.

Install the guide link. Refer to GUIDE LINK .

LEVEL CONTROL SYSTEM SENSOR

General Information

Vehicles with electronically controlled damping and/or HID headlamps have standard automatic headlamp range control. Refer to [For engine(s) CAEB, CALB] General Information .

To function properly, the electronically controlled damping and automatic headlamp range control system need information about compression travel or rebound travel at the front and rear axles.

For this, the position of the left/right track control arm in relation to the body is transferred via a coupling rod to Left Front Level Control System Sensor -G78- and Right Front Level Control Sensor -G289-. These transmit electrical signals to the electronic damping control module -J250- and/or left/right high-intensity gas discharge lamp control module -J343/344-.

Left/right high-intensity gas discharge lamp control module, servicing, refer to [For engine(s) CAEB, CALB] Removal and Installation .

At the rear axle, these signals are transmitted from the left rear level control system sensor -G76- and right rear level control system sensor -G77- to the electronic damping control module and/or the left/right high-intensity gas discharge lamp control module.

These signals are required for determining vehicle level.

The headlamp range control responds automatically to changes in the vehicle level.

The vehicle level can change in the following situations

1. Trailer Mode.
2. Different load conditions; vehicle empty, vehicle partially or fully loaded.

Note. Programming the control position and checking the headlamp basic setting is always necessary in vehicles with electronically controlled damping if

1. The track control arm has been removed and reinstalled or replaced.
2. The subframe was replaced.
3. Installation work has been performed on the level control system sensor.
4. The level control system sensor has been replaced.
5. The threaded connection for coupling rod of level control system sensor was loosened at track control arm.

Headlamp basic setting, refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

If the vehicle has electronically controlled damping, then the control position must be programmed. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Removing

Remove the nuts -1- and the cover -2-.

Disconnect the harness connector -2-.

Scheme 71

Remove nut -3-.

Remove the bolt -1-.

Remove level control system sensor -4-.

Installing

Install in reverse order of removal. Pay attention to the following

Note. The only sensors that may be installed must be the same type.

Tightening specifications, refer to TRACK CONTROL ARM, BALL JOINT, GUIDE LINK AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .

Guide the retaining hook on the sensor bracket into the subframe.

The sensor lever must point toward the back.

Check the basic setting for the headlamp adjustment after loosening. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

The control position must be "retaught" if the vehicle level sensor -- has been removed or installed, or if the linkage rod has loosened, in vehicles equipped with electronic damping; refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist; refer to LANE ASSIST CALIBRATION PROCEDURE .

WHEEL BEARING HOUSING

Note. Two different wheel bearing housings were installed in production; the difference between the two is the steering arm strength. When exchanging the wheel bearing housing, make sure the length of the thread on the tie rod end is sufficient (there must be approximately 5 mm extra thread). If this is not the case, then install a new tie rod end with a longer thread pin. Distinguishing characteristic, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

Special tools and workshop equipment required

1. Torque wrench V.A.G 1331
2. Torque wrench V.A.G 1332
3. Ring socket wrench V.A.G 1332/10
4. ring socket wrench V.A.G 1332/7

Removing

Loosen the connection between the drive axle and wheel hub. Refer to THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING .

Remove the track control arm. Refer to TRACK CONTROL ARM .

Remove brake line and electrical line bracket from wheel bearing housing.

Remove the front wheel speed sensor --. Refer to Removal and Installation .

Remove brake caliper and secure to body so weight of caliper does not stress or damage brake hose or brake line.

Remove disc brake.

Remove the bolts -arrows- and remove the brake shield -1-.

Scheme 72

Remove the nut from the guide link joint pins enough so it is flush with the joint pin threads. Counterhold it if you have to when loosening.

Note. Turn the nut a couple of turns on the pin to protect the threading.

Press linkage stub of guide control arm off conical seating using T40010 A.

Disconnect the connectors -1-.

Remove booth joint pins in the upper control arm -2- from the wheel bearing housing.

The slits in the wheel bearing housing must not be widened using a chisel or similar tool!

Loosen the wheel bearing housing from the drive axle splines and remove it.

Note. The drive axle must not hang down, otherwise the inner joint will be damaged by overflexing. Secure drive axle to body using wire.

Installing

Install in reverse order of removal. Pay attention to the following

Tightening specifications, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

Slide the wheel bearing housing onto the drive axle splines.

Insert both of upper control arm joint pins -2- in the wheel bearing housing and insert the bolt -1-.

Remove the adhesive residue on the ball joint and guide link stub threads.

Install the guide link on the wheel bearing housing and tighten.

Install the track control arm. Refer to TRACK CONTROL ARM .

Note. Push the upper control arms down as far as possible while tightening the bolts!

Tighten the threaded connection -1-.

Install the brake disc and caliper. Refer to Removal and Installation .

Tighten the drive axle to wheel hub threaded connection. Refer to THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING .

Perform a headlamp basic setting on vehicles with automatic range control. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

The control position must be "retaught" if the vehicle level sensor -- has been removed or installed, or if the linkage rod has loosened, in vehicles equipped with electronic damping. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Tighten the front wheels. Refer to Specifications .

Axle alignment required; see table. Refer to WHEEL ALIGNMENT .

WHEEL BEARING UNIT

Special tools and workshop equipment required

1. Torque wrench V.A.G 1331
2. Torque wrench V.A.G 1332
3. Torque wrench V.A.G 1576

Removing

Remove drive axle. Refer to DRIVE AXLE .

Insert both of upper control arm joint pins -2- in the wheel bearing housing and insert the bolt -1-.

Note. This step is necessary to avoid damage to suspension components when loosening and tightening the cap screws.

Remove brake caliper and secure to body so that the weight of the brake caliper does not stress or damage brake hose or brake line. Refer to Removal and Installation .

Remove disc brake.

Remove the front wheel speed sensor --. Refer to Removal and Installation .

Remove the cap screws -arrows-.

Scheme 73

Remove wheel bearing unit.

The wheel bearing -1- must always face up.

Always set the wheel bearing unit down on the wheel hub -2-.

Service the wheel bearing unit. Refer to WHEEL BEARING UNIT .

Installing

Install in reverse order of removal. Pay attention to the following

Tightening specifications, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

Install the drive axle. Refer to DRIVE AXLE .

Tighten the front wheels. Refer to Specifications .

Perform a headlamp basic setting on vehicles with automatic range control. Refer to [For engine(s) CAEB, CALB] Diagnosis and Testing .

The control position must be "retaught" if the vehicle level sensor -- has been removed or installed, or if the linkage rod has loosened, in vehicles equipped with electronic damping. Refer to CONTROL POSITION, PROGRAMMING USING VAS 5051B .

The directional stabilization assistance control module -J759- must be re-calibrated if the control position has been "retaught" in vehicles equipped with lane assist. Refer to LANE ASSIST CALIBRATION PROCEDURE .

Special tools and workshop equipment required

1. Torque wrench V.A.G 1332
2. Torque wrench V.A.G 1576

Removing

Loosen the connection between the drive axle and wheel hub. Refer to THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING .

Remove the wheel.

Remove the nuts -1- and the cover -2-.

Remove the bolts -arrows- from the flange shaft/transmission.

Remove the drive axle.

Applies to a Vehicle with a Subframe Shield

If there is not enough room available to remove the drive axle, perform the following steps

Remove the bolts -arrows- and move the subframe shield -1- to the side.

Remove the bracket for the brake hose and ABS line from the wheel bearing housing.

Loosen the threaded connection -1- and remove both control arms -2- upward.

The slits in the wheel bearing housing must not be widened using a chisel or similar tool!

Tilt the wheel bearing housing to the side while pulling the drive axle pins out of the wheel hub.

Remove drive axle.

Installing

Install in reverse order of removal. Pay attention to the following

Insert both of upper control arm joint pins -2- in the wheel bearing housing and insert the bolt -1-.

Note. Push the upper control arms down as far as possible while tightening the bolts!

Tighten the threaded connection -1-.

Tightening specifications, refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW

Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW

Tightening specification for drive axle to flange shaft/transmission. Refer to WHEEL BEARING HOUSING AND WHEEL BEARING UNIT ASSEMBLY OVERVIEW .

Install wheel.

Tighten the front wheels. Refer to Specifications .

Tighten the drive axle to wheel hub threaded connection. Refer to THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING .

SUSPENSION STRUT AND MOUNTING BRACKET

Assembly Overview

Scheme 74

1. Nut 50 Nm Always replace if removed.
2. Shock Absorber Mounting
3. Washer
4. Mounting Bracket
5. Upper Spring Support
6. Coil Spring Removing, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) . Installing, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) . Note different types of suspension versions, see vehicle data plate. Refer to «EXPLANATIONS OF PRODUCTION CONTROL NUMBERS»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__explanations-of-production-control-numbers) .
7. Additional Spring
8. Protective Sleeve
9. Protective Cap
10. Lower Spring Support
11. Lower Spring Plate
12. Shock Absorbers Replacing, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__suspension-strut-and-mounting-bracket) . Note different types of suspension versions. Refer to «EXPLANATIONS OF PRODUCTION CONTROL NUMBERS»(/audi/q5/i-2008-2012/remont/wheel-tire-system/#wheels-tires-wheel-alignment__explanations-of-production-control-numbers) . Always release gas and drain malfunctioning shock absorbers before disposal.

The shock absorber combination installed in the vehicle is indicated by the corresponding PR number on the vehicle data plate.

Special tools and workshop equipment required

1. Spring compressor V.A.G 1752/1
2. Spring mounting tool V.A.G 1752/2
3. Spring holder V.A.G 1752/7
4. Knurled bolt from V.A.G 1752/18
5. Rod, extended V.A.G 1752/18-3
6. Clamping jaw V.A.G 1752/19-1
7. Suspension strut adjustment gauge V.A.G 1752/19
8. Shock absorber set T10001/3
9. Shock absorber set T10001/4
10. Shock absorber set T10001/7
11. Shock absorber set T10001/11

Scheme 75

1. V.A.G 1752/1
2. T10001/7
3. T10001/11
4. T10001/3
5. V.A.G 1752/7

Clamp the suspension strut in the vise with the shock absorber fork installed.

Mark the installation location of the mounting bracket to the T-pin on the shock absorber tube. (felt-tip pen)

Pretension coil spring using V.A.G 1752/1 and V.A.G 1752/7 until upper suspension strut is free.

Make sure the coil spring is seated in the spring holder -2- correctly.

Scheme 76

1. V.A.G 1752/1
2. V.A.G 1752/7

Remove the nut from the piston rod using the tools -2-, -3- and -4-.

1. V.A.G 1752/1
2. T10001/7
3. T10001/11
4. T10001/3
5. V.A.G 1752/7

Remove individual components of suspension strut and pre-tensioned coil spring with V.A.G 1752/1.

Scheme 77

Remove the cap -1- and the lower spring support -2-.

Loosen suspension strut -3- using plastic hammer and remove upward.

Drive the spring plate onto the new shock absorber using a plastic hammer.

COIL SPRING, INSTALLING

Install the lower spring support and the cap.

Position the pre-tensioned coil spring on the lower spring support. End of spring coil must rest against stop -arrow- (permissible play maximum 2 mm).

Install mounting bracket with spring washer onto pre-loaded spring so that spring washer makes contact on end of spring coil -arrow- (permissible play maximum 2 mm).

Scheme 78

Position individual suspension strut components.

Tighten the nut using special tools.

Align the marking on the mounting bracket to the T-pin on the shock absorber tube and release the tension in the spring.

Mounting Bracket Installation Position

Scheme 79

Install the V.A.G 1752/2 as shown in the illustration.

1. V.A.G 1752/18-3
2. V.A.G 1752/19
3. V.A.G 1752/2
4. V.A.G 1752/19-1

Tension the suspension strut with spring compressor vertically in the V.A.G 1752/2.

Tension the suspension strut so the pin -1- engages in the V.A.G 1752/19-1 opening -2-.

Scheme 80

When tensioning, make sure the front damping adjustment valve -1- or electrical wiring connection -2- does not sit on the suspension strut mount -3-.

Scheme 81

Disengage the locking lever and set the pointer to the 0° position -arrow-, then tighten the locking lever.

Scheme 82

Adjust the mounting bracket so the V.A.G 1752/19 for the respective side of the vehicle can be bolted to the mounting bracket.

Left Side

Scheme 83

Bolt V.A.G 1752/19 onto mounting bracket -arrows L-.

Right Side

Scheme 84

Bolt V.A.G 1752/19 to mounting bracket -arrows R-.

Release the tension in the V.A.G 1752/1 and remove it.

Note. When releasing the tension, make sure the ends of the spring lie on the spring support stops in the mounting bracket and the lower spring support.

Check adjustment, repeat procedure if necessary.

Permissible deviation: ±2°

Special tools and workshop equipment required

1. Pressure plate VW 401
2. Pressure plate VW 402
3. Punch VW 412
4. Subframe support assembling device T10230
5. Separating device Kukko 15/3 with 17/3

1. Wheel bearing housing removed «WHEEL BEARING UNIT»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension__wheel-bearing-unit)

Wheel Hub, Removing from Wheel Bearing

Scheme 85

Install special tools as shown in illustration.

1. VW 412
2. Sleeve T10230/8 from the T10230
3. Thrust piece T10230/3 from the T10230
4. Wheel bearing unit
5. VW 402
6. VW 401

Press the wheel hub out of the wheel bearing.

Scheme 86

Insert the separating tool between the bearing inner race -1- and the wheel hub -2- and pretension with the spindle.

Note. Use a commercially available separating tool such as the Kukko 15/3 with 17/3.

Install special tools as shown in illustration.

Scheme 87

1. Punch VW 412
2. Sleeve T10230/8 from the T10230
3. Thrust piece T10230/3 from the T10230
4. Kukko 15/3 with 17/3

Press the bearing inner race from the hub.

Pressing Wheel Hub into Wheel Bearing

Scheme 88

Install special tools as shown in illustration.

1. VW 412
2. VW 402
3. Wheel hub
4. Ball bearing
5. VW 401

Note. The reworked surface on the wheel bearing outer race faces down.

Press the wheel hub into the wheel bearing.

Install wheel bearing unit. Refer to WHEEL BEARING UNIT .

PEENED TRIPLE ROLLER JOINT AAR 2600 I OR 3300 I

Special tools and workshop equipment required

1. Pressure plate VW 401
2. Pressure plate VW 402
3. Punch VW 408 A
4. Punch VW 411
5. Tube VW 416 B
6. Thrust pad VW 447 H
7. Hose clamp pliers V.A.G 1275
8. Torque wrench V.A.G 1331
9. Torque wrench V.A.G 1332
10. CV joint boot clamp tool V.A.G 1682
11. Subframe support assembling device T10065
12. Slide hammer - complete set VW 771
13. Assembly device T40018 for triple roller joint AAR 3300 i
14. assembly device T40084 for triple roller joint AAR 2600 i
15. CV joint boot clamp tool 3340

Disassembling

Clamp the drive axle horizontally in the vise with protective covers.

Note. Use vice clamp jaw protectors. Make sure that drive axle is not damaged.

Mark the location of the joint to the drive axle.

Note. If they are not marked and are not installed in their previously installed positions, noises may occur later during driving operation.

Mark the position of the joint protective boot to the joint.

A waterproof felt pen is well-suited for marking.

Scheme 89

Open clamps -arrows-.

Slide back protective boot.

Distinguishing Characteristic of Drive Axle AAR 2600 i to AAR 3300 i

Scheme 90

Determine dimension -A- as shown in illustration.

1. Dimension -A- 74 mm = drive axle AAR 2600 i
2. Dimension -A- 77 mm = drive axle AAR 3300 i

Guide T40018 or T40084 behind joint.

Guide pins -1- must contact joint.

Scheme 91

Bring installation device into contact with joint by turning knurled thumb screws -2-.

Note. Joint must be secured without play in T40018 or T40084. Tighten the screws -2- by hand only.

Screw VW 771 into T40018 or T40084.

Scheme 92

Note. Drive axle AAR 3300 i T40018 is shown in illustration. Use T40084 with drive axle AAR 2600 i.

Remove the joint horizontally using the VW 771.

Leave joint in T40018 or T40084.

Mark installation position of the parts -1- and -2- with lines.

Scheme 93

Note. If they are not marked and are not installed in their previously installed positions, noises may occur later during driving operation. A water-proof felt pen is well-suited for marking.

1 - Drive axle

2 - Triple roller star

Remove grease with lint-free cloth.

Remove securing ring.

Scheme 94

1 - Pliers (commercially available)

Press Triple Roller Star off of Drive Axle

Scheme 95

Use special tool shown in illustration.

1. Subframe support assembling device T10065/1
2. The assembly tool T10065/5 must touch the triple roller star base
3. VW 401
4. VW 408 A
5. VW 402

Note. The T10065/5 must not touch the rollers; move the rollers to the side if necessary.

Remove the protective boot.

Remove the grease on the shaft splines.

Check the roller body and ball cage for wear.

Clean drive axle and housing.

Triple Roller Joint AAR 2600 i or 3300 i, Assembling

Slide on the small clamp with the protective boot and position the protective boot on the drive axle according to the version.

Version with Identification Groove

Scheme 96

Position CV boot in outer groove -arrow B-.

Note. Inner groove -arrow A- must remain visible "identification groove" (for correct installation of CV boot).

Version with Base

Scheme 97

Position protective joint boot between -arrows-.

Tripod Roller Star, Pressing onto Drive Axle

Scheme 98

Note. The chamfer on the triple roller star faces the drive axle. This is used as an assembly aid.

Before installing joint or triple roller star, splines -A- must be lightly coated with grease used in joint.

Place the triple roller star on the shaft according to the marking and drive on to the stop.

Use the assembly tool T10065/6. Make sure it attaches to the bead at the bottom -arrow- in the drive axle.

Scheme 99

Use special tool shown in illustration.

1. Subframe support assembling device T10065/1
2. The assembly tool T10065/6 must attach to the bead at the bottom of the drive axle -arrow-.
3. VW 401
4. VW 416 B
5. VW 447 H
6. VW 411
7. VW 402

The T10065/6 must not touch the roller; move the rollers to the side if necessary.

Press the triple roller joint onto the drive axle.

Install circlip.

Circlip must engage audibly, triple roller star must lie against circlip with no gap.

1 - Pliers (commercially available)

Press 70 grams of joint grease, from repair set, into the reverse side of the triple roller joint.

Lightly grease the roller body.

Note. Make sure roller body does not tilt!

Press the joint over the triple roller star using a plastic hammer.

Scheme 100

Note. Drive axle AAR 3300 i T40018 is shown in illustration.

Press remaining quantity of grease in protective boot.

Slide the protective boot onto the joint.

Make sure the joint protective boot fits correctly on the joint; align the boot if necessary.

Protective joint boot must fit in groove and on joint contour.

Note. It is necessary to let the air out of the joint protective boot when positioning it on the joint. Use a screwdriver to let the air out.

Install clamp.

Note. For a better alignment of multi-point bolts when installing drive axle, clamping sleeve connecting tube -2- must be between joint connecting flanges -1-.

Install the clamps on the triple roller joint. Refer to LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT .

OUTER CV JOINT WITH DIAMETER 88 MM/100 MM

Special tools and workshop equipment required

1. Copper or brass drift

REMOVING

Secure the drive axle in the vise with protective covers.

Open both clamping sleeves and remove protective joint boot from outer joint.

Strike a copper or brass drift -A- on CV joint inner race with a hammer.

Scheme 101

Remove joint and protective joint boot.

INSTALLING

There must be no grease on the boot or on the drive axle where the boot contacts them.

Always replace the circlip -1-.

Slide on the small clamp with the protective boot and position the protective boot on the drive axle according to the version.

Version with Identification Groove

Position CV boot in outer groove -arrow B-.

Inner groove -arrow A- must remain visible "identification groove" (for correct installation of CV boot).

Version with Base

Position protective joint boot between -arrows-.

Add the specified quantity of grease to the inner joint. Refer to DRIVE AXLE ASSEMBLY OVERVIEW .

Before installing the joint, splines -A- must be lightly coated with the grease used in the joint.

Insert sealing ring in groove on shaft.

Slide on CV joint up to sealing ring.

Scheme 102

Align sealing ring at center with opening upward -see arrows-.

Screw old drive axle bolt into joint as shown in the illustration.

Scheme 103

Drive joint onto drive axle with plastic hammer until circlip engages.

Add the specified quantity of grease to the inner joint. Refer to DRIVE AXLE ASSEMBLY OVERVIEW .

Slide the protective boot onto the joint.

Bleed protective joint boot.

Make sure the protective boot is seated on the joint correctly.

Protective joint boot must fit in groove and on joint contour.

Tension clamps on outer joint. Refer to LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT .

LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT

Depending on the version of the clamp, use the following tools

Special tools and workshop equipment required

1. CV joint boot clamp tool 3340
2. CV joint boot clamp tool V.A.G 1682

Mount and tension stainless steel clamps using V.A.G 1682 as illustrated.

Scheme 104

When doing this, make sure that edges of clamping pliers are seated in corners -arrows B- of clamp.

Tighten the clamp by turning the spindle using a torque wrench -C- (do not tilt the pliers).

1. A stainless steel clamp must be used due to the hardness of the CV boot material (compared to rubber). This clamp can only be tensioned using the V.A.G 1682.
2. Tightening specifications: 20 Nm.
3. Use torque wrench with 5 to 50 Nm range (e.g. V.A.G 1331).
4. Make sure the spindle threads on the pliers -A- move freely. Grease with MoS 2 grease if necessary.
5. If the thread is tight e.g. dirty, the required tensioning force for the hose clamp will not be achieved in spite of correct torque specification settings.

Mount and tension the clamp with the retaining tabs using 3340 as illustrated.

Scheme 105

Engage the clamp at the first catch by hand.

Close the clamp using 3340.

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

1. Spring mounting tool V.A.G 1752/2
2. Knurled bolt from V.A.G 1752/18
3. Rod, extended V.A.G 1752/18-3
4. Clamping jaw V.A.G 1752/19-1
5. Suspension strut adjustment gauge V.A.G 1752/19
6. Vehicle diagnosis, testing and information system VAS 5051B with corresponding diagnostic cable
7. Angle wrench V.A.G 1756
8. Torque wrench V.A.G 1410
9. Torque wrench V.A.G 1576
10. Spreader 3424
11. Ball joint puller T40010 A
12. Assembly tool 3301
13. Subframe support assembling device 3346
14. Assembly tool 3348
15. Ring socket wrench V.A.G 1332/10
16. Ring socket wrench V.A.G 1332/7
17. Subframe support assembling device T10030
18. Sleeve VW 463/2
19. Sleeve 3144
20. Shop press V.A.G 1290A
21. CV joint boot clamp tool 3340
22. CV joint boot clamp tool V.A.G 1682
23. Spring compressor V.A.G 1752/1
24. Spring holder V.A.G 1752/7
25. Shock absorber set T10001/3
26. Shock absorber set T10001/4
27. Shock absorber set T10001/7
28. Shock absorber set T10001/11
29. Punch VW 412
30. Subframe support assembling device T10230
31. 3- Separating device Kukko 15/3 with 17/3
32. Slide hammer VW 771
33. Assembly device T40018 for triple roller joint AAR 3300 i
34. Assembly device T40084 for triple roller joint AAR 2600 i

Scheme 132

Special tools and workshop equipment required

1. Engine/transmission jack V.A.G 1383 A
2. Tensioning strap T10038
3. Wheel hub support T10149

Scheme 133

Special tools and workshop equipment required

1. Pressure plate VW 402
2. Punch VW 407
3. Press tool 3345
4. Subframe support assembling device 3347/1

Scheme 134

Special tools and workshop equipment required

1. Pressure plate VW 401
2. Pressure plate VW 402
3. Punch VW 408 A
4. Punch VW 411
5. Tube VW 416 B
6. Thrust pad VW 447 H

Scheme 135

Special tools and workshop equipment required

1. Hose clamp pliers V.A.G 1275
2. Torque wrench V.A.G 1331
3. Torque wrench V.A.G 1332
4. CV joint boot clamp tool V.A.G 1682
5. Subframe support assembling device T10065

See also:
• [For engine(s) CALB] Description and Operation
• LANE ASSIST CALIBRATION PROCEDURE
• SHOCK ABSORBER
• LEVEL CONTROL SYSTEM SENSOR
• [For engine(s) CAEB, CALB] Diagnosis and Testing
• EXPLANATIONS OF PRODUCTION CONTROL NUMBERS
• FRONT GAS-FILLED STRUT, VENTING AND EMPTYING
• SHOCK ABSORBERS, REMOVED, CHECKING
• Description and Operation
• STEERING GEAR
• Specifications
• WHEEL ALIGNMENT
• [For engine(s) CAEB, CALB] Description and Operation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION
• THREADED CONNECTION BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING
• SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD ASSEMBLY OVERVIEW
• SUBFRAME
• SUBFRAME SHIELD
• SUBFRAME CROSSBRACE
• COUPLING ROD
• STABILIZER BAR
• ELECTRONIC DAMPING CONTROL MODULE
• CONTROL POSITION, PROGRAMMING USING VAS 5051B
• REAR BODY ACCELERATION SENSOR
• FRONT BODY ACCELERATION SENSORS
• SUSPENSION STRUT WITH MOUNTING BRACKET
• SUSPENSION STRUT AND MOUNTING BRACKET
• LEVEL CONTROL SYSTEM SENSOR
• TOWER BRACE
• UPPER CONTROL ARM
• SHOCK ABSORBER FORK
• GUIDE LINK
• CONVENTIONAL BONDED RUBBER BUSHING, 65 MM
• HYDRAULIC BONDED RUBBER BUSHING, 75 MM
• TRACK CONTROL ARM
• TRACK CONTROL ARM MOUNT
• WHEEL BEARING HOUSING
• DRIVE AXLE
• LARGE AND SMALL CLAMPS, CLAMPING ON INNER OR OUTER JOINT
• OUTER CV JOINT WITH DIAMETER 88 MM/100 MM
• OUTER CV JOINT, CHECKING
• WHEEL BEARING UNIT
