Backrest Ventilation, Removing and Installing Audi A8 D3 facelift

Body Interior 6 illustrations ~706 words

Backrest Ventilation, Removing and Installing

Note. Rubber guide - 3 - is sewn onto upholstery - 4 -. If rubber guide is malfunctioning, the upholstery must be replaced.

Scheme 412

Scheme 412: Backrest Ventilation, Removing and Installing
Scheme 412: Backrest Ventilation, Removing and Installing

1 - Rivets (2x)

2 - Seat ventilation

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Remove connector - 3 -.
  4. Drill out rivets - 1 - (2x).
  1. Remove seat ventilation - 2 -.
  1. Installing
  1. Install seat ventilation - 2 - in reverse order of removal.

3 - Connector

4 - Upholstery

5 - Rubber guide

Scheme 413

Scheme 413: Rear Seat Angle Adjustment Motors, Removing and Installing
Scheme 413: Rear Seat Angle Adjustment Motors, Removing and Installing

1 - Bolts

2 - Spring washer

3 - Screws (qty. 4)

4 - Connector

5 - Left Rear Seat Angle Adjustment Motor V227 and V228

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Remove connector - 4 -.
  4. Knock bolt - 1 - out using a hammer.
  1. Remove bolts - 3 - (qty. 4).
  2. Remove the seat angle adjustment motor - 5 -.
  1. Installing
  1. Install the seat angle adjustment motor - 5 - in reverse order of removal.
  2. Secure bolt - 1 - with a spring washer - 2 -.

Scheme 414

Scheme 414: Rear Seat Forward/Back Adjustment Motors, Removing and Installing
Scheme 414: Rear Seat Forward/Back Adjustment Motors, Removing and Installing

1 - Bolts

2 - Connector

3 - Left Rear Seat Forward/Back Adjustment Motor V87 and V88

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Remove connector - 2 -.
  4. Knock bolt - 1 - out using a hammer.
  1. Remove bolts - 4 - (qty. 4).
  2. Remove the seat forward/back adjustment motor - 3 -.
  1. Installing
  1. Install the seat forward/back adjustment motor - 3 - in reverse order of removal.
  2. Secure bolt - 1 - with a spring washer - 5 -.

4 - Screws (qty. 4)

5 - Spring washer

Scheme 415

Scheme 415: Upper Backrest Adjustment Motor, Removing and Installing
Scheme 415: Upper Backrest Adjustment Motor, Removing and Installing

1 - Screws, (qty. 2)

  1. Tightening torque 6 Nm.

2 - Connector

3 - Backrest frame

4 - Upper Backrest Adjustment Motor V232

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Unclip harness connector - 2 - from backrest frame and disconnect harness connector.
  4. Remove bolts - 1 - (qty. 2).
  1. Remove Upper Backrest Adjustment Motor - 4 -.
  1. Installing
  1. Install Upper Backrest Adjustment Motor - 4 - in reverse order of removal.

Scheme 416

Scheme 416: Rear Seat Lumbar Forward/Back Motors, with Four-Way Lumbar Support, Removing and Installing
Scheme 416: Rear Seat Lumbar Forward/Back Motors, with Four-Way Lumbar Support, Removing and Installing

1 - Top retainers (2x)

2 - Release

3 - Retainer

4 - Four-way lumbar support

5 - Spring washer

6 - Hook

7 - Bottom retainers (2x)

8 - Left Rear Seat Lumbar Support Forward/Back Adjustment Motor V127 and V128

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Remove connector - 9 -.
  4. Disengage the release cable - 2 - from the bracket - 3 -.
  1. Pry out spring washer - 5 -.
  2. Disengage Bowden cable - 2 - at hook - 6 -.
  3. Disengage top retainer - 1 - (2x) from backrest frame - 10 -.
  4. Disengage bottom retainer - 7 - (2x) from backrest frame - 10 -.
  1. Remove the lumbar support forward/back adjustment motor - 8 - with four-way lumbar support - 4 -.
  1. Installing
  1. Install the lumbar support forward/back adjustment motor - 8 - in reverse order of removal.

9 - Connector

10 - Backrest frame

Scheme 417

Scheme 417: Rear Seat Lumbar Height Adjustment Motors, Removing and Installing
Scheme 417: Rear Seat Lumbar Height Adjustment Motors, Removing and Installing

1 - Release

2 - Retainer

3 - Retaining strip

4 - Left Rear Seat Lumbar Support Height Adjustment Motor V225 and V225

  1. Removing
  1. Remove seat pan --> «Seat Pan, Removing and Installing»(ref-289222-S08334952372008062700000) .
  2. Remove individual rear seat --> «Individual Rear Seat, Removing and Installing»(ref-289222-S19617088712008062700000) .
  3. Remove connector - 5 -.
  4. Disengage the release cable - 1 - from the bracket - 2 -.
  1. Pry out spring washer - 6 -.
  2. Disengage Bowden cable - 1 - at hook - 7 -.
  3. Remove screw - 8 -.
  4. Remove Lumbar Support Height Adjustment Motor - 4 -.
  1. Installing
  1. Install Lumbar Support Height Adjustment Motor - 4 - in reverse order of removal.

5 - Connector

6 - Spring washer

7 - Hook

8 - Screw
