On Board Diagnostic (OBD) - 5 Spd. Automatic Transmission (01l, Awd) Audi A8 D3

Safety precautions

When road testing and using testing and measuring equipment, observe the following

To prevent injury or damage to test and measuring equipment and to electrical and electronic car components, observe the following

1. Always switch the ignition off before connecting or disconnecting test or measuring equipment.
2. During certain tests it can happen that the Transmission Control Module (TCM) recognizes a malfunction which is then stored in memory. It is therefore necessary to check the DTC memory and erase it after all tests and repairs are completed.
3. Always switch the ignition off when connecting or disconnecting the battery, otherwise the TCM may be damaged.

Transmission controls

The automatic transmission is controlled electronically and hydraulically.

The Transmission Control Module (TCM) -J217- for the automatic transmission obtains information from components that have an effect on the shifting. Based on this information the TCM controls the respective solenoid valves in the valve body. The solenoid valves direct the oil pressure created by the ATF oil pump to the respective clutches or brakes.

Malfunction recognition by the TCM

The TCM is equipped with Diagnostic Trouble Code (DTC) memory. Malfunctions that occur in the monitored sensors, components, or wiring are stored in DTC memory, which can be checked using the VAG 1551 or VAG 1552 Scan Tool (ST). If the printer of the VAG 1551 scan tool is switched on, the DTCs will be printed. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

The On Board Diagnostic (OBD) system differentiates between "static" and "sporadic" malfunctions. Static malfunctions are stored until DTC memory is checked and then erased using the VAG 1551 scan tool. If a malfunction that has been stored as "static" no longer exists after the ignition is switched on, it will be converted to "sporadic."

Malfunctions that occur sporadically are identified by the "/SP" designation in the VAG 1551 scan tool display. A sporadic malfunction is automatically erased after 40 engine cold-starts (and subsequent transmission warm-up cycles). A warm-up cycle is recognized when the ATF temperature is below 71° C at start and rises to at least 21° C.

The OBD program can be initiated using the VAG 1551 scan tool in "Rapid data transfer" operating mode 1.

List of OBD functions accessible using the VAG 1551 scan tool, see ON BOARD DIAGNOSTIC (OBD), FUNCTIONS .

TCM backup functions

If one or more components or sensors malfunction, the TCM -J217- activates corresponding substitute functions or backup programs. This ensures that the automatic transmission operates without damage or effect to the operation or quality of the shifting.

If certain malfunctions occur and the TCM is active, the transmission range engaged at that moment is maintained. As soon as the driving situation permits, the TCM activates the "mechanical backup with active control module" mode while ensuring transmission security.

Scheme 112

1. The transmission shifts out of all forward gears into hydraulic 4th gear. The torque converter clutch is unlocked (not applied). All solenoid valves are de-energized.
2. Maximum shift pressure is applied to the power transmitting elements.
3. Reverse gear can be engaged. The shift lock solenoid is active (in "P" and "N").
4. All of the segments of the transmission range selector lever display are lit up completely.
5. The Malfunction Indicator Lamp (MIL) is switched on after 3 Dcy. Check DTC memory (see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) ), and consult DTC table (see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) ).

If the TCM malfunctions (for example, there is a power loss a connector is disconnected) the transmission immediately operates in "mechanical backup with non-active control module" mode.

Mechanical backup with non-active control module

1. The transmission shifts out of all forward gears into hydraulic 4th gear. The torque converter clutch is unlocked (not applied). All solenoid valves are de-energized.
2. Maximum shift pressure is applied to the power-transmitting elements.
3. Reverse gear can be engaged. The shift lock solenoid is active (in "P" and "N").
4. All of the segments of the transmission range selector lever display are dark.
5. The Transmission Control Module (TCM) -J217-is completely inoperative, i.e. it cannot conduct its OBD program.
6. The Malfunction Indicator Lamp (MIL) is switched on when the Engine Control Module (ECM) recognizes the CAN-Bus malfunction (missing data exchange between the ECM and TCM) after 2Dcy. If necessary, check DTC memory of ECM. See «CHECK DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, (SCAN TOOL FUNCTION 02)»(ref-196869-S17091391972005101000000) (1997-99 3.7L and 4.2L), or «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(ref-216437-S08471100802006020800000) (2000-03 4.2L).

Malfunction Indicator Lamp (MIL), function

If emissions-influencing malfunctions are recognized by the TCM, the Malfunction Indicator Lamp (MIL) will be switched on.

Location of the MIL

Scheme 113

Note. When the MIL is switched on, it will either blink or light continuously. In either case, the DTC memory for the TCM must be checked, see ON BOARD DIAGNOSTIC (OBD), CHECKING .

1. MIL flashing : there is a malfunction that could damage the Three Way Catalytic Converter (TWC). In this case, drive only with reduced power.
2. MIL continuously on : there is a malfunction that degrades emissions. Check DTC memory of the Engine Control Module (ECM) or the TCM.
3. If there are driveability problems (e.g. a customer complaint) and the MIL is not on, the MIL functional test must be carried out, since malfunctions that do not immediately switch on the MIL can be stored.

MIL functional check

1. Switch ignition on. The MIL must come on.

If the MIL does not come on when the ignition is switched on (with the engine not running)

1. Check DTC memory. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .
2. If necessary, check wiring per wiring diagram or replace light bulb.
3. Start engine and let idle. The MIL must be switched off after several seconds.

If the MIL is not switched off after the engine is started

1. Check DTC memory. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Conditions for recognition of a driving cycle (Dcy)

A driving cycle (Dcy) is considered complete when the ignition is switched on one time, the engine is started, the engine start is recognized by the control module, and the ignition is switched off again.

Scheme 114

Electrical and electronic components and locations, see ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS .

On Board Diagnostic (OBD), functions

Note. The following modes can be selected by inserting address word 33

Scheme 115

Scheme 116

Electrical and electronic components, locations

The following list pertains to (Scheme 117).

1. Automatic Transmission Control Module (TCM) -J217- Component location, see «REMOVING AND INSTALLING TRANSMISSION CONTROL MODULE (TCM) -J217»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__removing-and-installing-transmission-control-module) Removing and installing, see «REMOVING AND INSTALLING TRANSMISSION CONTROL MODULE (TCM) -J217»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__removing-and-installing-transmission-control-module) Multi-pin connector release, see «DISCONNECTING MULTI-PIN CONNECTOR FROM TCM -J217.»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) Checked via On Board Diagnostic (OBD), see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd)
2. Engine Control Module (ECM) Location: in plenum on right Removing and installing, see «ENGINE CONTROL MODULE (ECM) (WITHOUT METAL ANTI-THEFT HOUSING), REPLACING»(ref-196870-S04786700392005101000000) (1997-99) or «ENGINE CONTROL MODULE (ECM) (WITH METAL ANTI-THEFT HOUSING), REPLACING»(ref-196870-S18377071872005101000000) (1997-99). For 2000-03 4.2L, see «MOTRONIC ENGINE CONTROL MODULE (ECM) -J220- (WITHOUT METAL ANTI -THEFT HOUSING), REPLACING»(/audi/a8/d3-2002-2005/remont/fuel-system/#multiport-fuel-injection-mfi-42l-v8-akb-aux-ays__motronic-engine-control-module-ecm-j220) .
3. Data Link Connector (DLC) Location: in knee bar to left of steering wheel Connecting VAG 1551 (or VAG 1552) Scan Tool (ST), selecting functions, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd)
4. Valve body Location: inside transmission oil pan Removing and installing, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) . Assembly includes solenoid valves -N88-, -N89-, -N90-, -N215-, -N216-, -N217-, -N218- and -N233- Transmission fluid (ATF) temperature sensor -G93-is integrated into internal wiring harness Replacing transmission fluid temperature sensor -G93-, see «TRANSMISSION FLUID TEMPERATURE SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) . Components are electrically checked via OBD.
5. Multi-function -Transmission Range (TR) switch -F125- Location: on left of transmission Replacing, see «TRANSMISSION RANGE SWITCH»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__transmission-range-switch) Checked via OBD, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd)
6. Sensor for transmission RPM -G182- Location: in valve body Replacing, see «TRANSMISSION RPM SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) Checked via OBD, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd)
7. Sender for transmission output RPM -G195- Location: right, outside of differential housing Checked via OBD, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) Supplies transmission output speed (RPM) signal
8. Selector lever mechanism Location: in center console
9. Shift lock solenoid -N110- Location: on right side of selector lever mechanism Can be checked in "Read Measuring Value Block" function 08 (see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) ) and by electrical testing (see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) ). Removing and installing, see «SELECTOR LEVER MECHANISM»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd)
10. Throttle Position (TP) sensor -G69- Location: integrated into throttle valve control module -J338- TP sensor signal is checked by On Board Diagnostic of ECM TP sensor signal is sent via ECM to TCM TP sensor signal can only be checked in "Read Measuring Value Block" function 08. See «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) . If a TP sensor malfunction is detected using OBD program, check OBD program of ECM. See «ON BOARD DIAGNOSTIC (OBD)»(ref-196869-S17596902102005101000000) (1997-99 3.7L and 4.2L), or «ON BOARD DIAGNOSTICS (OBD)»(ref-216437-S25562904152006020800000) (2000-03 4.2L).
11. Cruise control switch -E45- Location: integrated into steering column switch Removing and installing For model years 1997-1999, see «STEERING COLUMN SWITCHES, REMOVING AND INSTALLING»(ref-196898-S33386188672005101000000) . For model years 2000 and up, see «STEERING COLUMN SWITCHES, SERVICING»(/audi/a8/d3-2002-2005/remont/steering-column-switches/#lights-switches-exterior__steering-column-switches-servicing) . Checked by electrical testing. See «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
12. Park/Neutral Position (PNP) relay -J226- Location: relay plate See appropriate System Wiring Diagrams article.
13. Transmission range selector lever display -Y6- Location: in instrument cluster Transmission Range (TR) selector lever display which is completely dark indicates "mechanical backup with non-active control module" mode. See «TCM BACKUP FUNCTIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__tcm-backup-functions) . TR selector lever display which is completely lit up indicates "mechanical backup with active control module" mode. See «TCM BACKUP FUNCTIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__tcm-backup-functions) .
14. Kick down switch -F8- Location: behind spray wall in plenum, integrated into accelerator pedal cable. Replacing: replace accelerator pedal cable and adjust. See «ACCELERATOR PEDAL CABLE, ADJUSTING»(ref-196863-S32795413642005100900000) . Can be checked in "Read Measuring Value Block" function 08 (see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) ), and by electrical testing (see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) ).
15. Brake light switch -F- Location: in pedal cluster Removing and installing, see «BRAKE LIGHT SWITCH, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/anti-locktraction-control/#antilock-brake-system) . Can be checked in "Read Measuring Value Block" function 08 (see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) ), and by electrical testing (see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) ).

Removing and installing Transmission Control Module (TCM) -J217

TCM location: in E-box in right side of plenum

Scheme 117

Scheme 118

1. Switch ignition off.
2. Open E-box in right side of plenum by unscrewing 7 bolts (arrows).
3. Unclip bolt cover to unscrew bolt in upper right-hand section of illustration.
4. Release multi-pin connector lock -2-, then disconnect multi-pin connector from TCM (see «DISCONNECTING MULTI-PIN CONNECTOR FROM TCM -J217.»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) ).
5. Unscrew bolts (arrows) and remove TCM (together with bracket) from E-box.
6. Check container for water penetration and reseal if necessary.

Installing

1. Install in reverse order of removal.
2. Check DTC memory of TCM. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 119

1. Switch ignition off and wait approx. 30 sec.
2. Push lock in direction of arrow to unlatch connector.
3. Disconnect multi-pin connector from top.
4. Install in reverse order of removal.

VAG 1551 Scan Tool (ST), connecting and selecting function

Note. The VAG 1552 scan tool can be used instead of the VAG 1551; however, no printout is possible.

Test requirements

1. Battery Positive Voltage (B+) OK
2. Supply voltage and fuses for respective systems OK See System Wiring Diagrams .
3. Ground (GND) connectors for transmission OK

Scheme 120

1. Check GND connections for corrosion and damage and repair if necessary.
2. Check TCM GND connection per wiring diagram.
3. Check battery GND strap and GND strap between battery and transmission. Selector lever in "P" position Parking brake applied Ignition switched off
4. Remove cover for 16-pin Data Link Connect (DLC), to left of steering column.
5. Connect VAG 1551 (VAG 1552) scan tool to DLC using adapter cable VAG 1551/3. NOTE: If nothing is shown on the display, check the power supply to the DLC. See System Wiring Diagrams . Additional operating instructions can be obtained by pressing the HELP button on VAG 1551 scan tool. Press the --> button to advance through tin program sequence. See VAG 1551 scan tool operating instructions .

Indicated on display

Scheme 121

Operating modes 1 and 2 are displayed alternately

1. Switch ignition on.
2. Operate brake pedal one time.
3. Press PRINT button to switch printer on (indicator light in button comes on).
4. Press button -1- to select "Rapid data transfer" operating mode 1.

Indicated on display

Scheme 122

Note. After address word 33 is inserted and confirmed with the -Q- button, the OBD program can begin. OBD functions, see ON BOARD DIAGNOSTIC (OBD), FUNCTIONS . After address word 00 is inserted and confirmed with the -Q- button, the automatic test sequence can begin (the DTC memory for every system is checked). Stored malfunctions are displayed in sequence and printed out.

Indicated on display

Scheme 123

Operating modes 1 and 2 are displayed alternately.

1. Press button -1- to select "Rapid data transfer" operating mode 1.

Indicated on display

Scheme 124

1. Press buttons -0- and -2- to insert "Transmission Electronics" address word 02.

Indicated on display

Scheme 125

1. Press -Q- button to confirm input.

Indicated on display (control module identification)

Scheme 126

Transmission Control Module (TCM) identification

The TCM identification is dependent on manufacture status (data status). A control module identification may appear which is different than that in this example. For TCM applications, see parts catalog.

TRANSMISSION CONTROL MODULE (TCM) IDENTIFICATION EXAMPLE

If "Control module does not answer" is indicated on display

Scheme 127

A list of the possible malfunction causes can be printed out by pressing the HELP button.

After eliminating possible malfunction causes

1. Again press buttons -0- and -2- to insert "Transmission Electronics" address word 02.

If "Control module does not answer" is again indicated on display

Scheme 128

1. Check power supply by conducting electrical test step 1. See «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. Check wiring connection to DLC. See System Wiring Diagrams .
3. Check DTC table (see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) ) for the following codes: 16987/P0603: Internal Contr.Module (KAM), Error 16989/P0605: Internal Contr.Module ROM Test Error
4. Press --> button.

Indicated on display

Scheme 129

A list of the possible functions can be printed out by pressing the HELP button.

VAG 1551 Scan Tool (ST), overview of available functions

VAG 1551 SCAN TOOL (ST) AVAILABLE FUNCTIONS OVERVIEW

Other functions that are printed out after the HELP button is pressed do not need to be considered.

The VAG 1551 scan tool returns to the "Select function" mode after each function is activated.

Indicated on display

Scheme 130

Code Control Module (scan tool function 07)

1. Connect VAG1551 scan tool, insert "Transmission Electronics" address word 02, and advance through program sequence until "Select function XX" is displayed. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Indicated on display

Scheme 131

1. Press buttons -0- and -7- to select "Code Control Module" function 07.

Note. The Transmission Control Module (TCM) can be successfully coded only with

1. Ignition switched on
2. Gear selector lever in "P" or "N" position
3. Accelerator pedal at Closed Throttle Position (CTP)
4. Vehicle not moving
5. Engine not running

Indicated on display

Scheme 132

1. Press -Q- button to confirm input.

Indicated on display

Scheme 133

1. Input code number according to «CONTROL MODULE CODE NUMBERS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) table. CONTROL MODULE CODE NUMBERS Code Engine Country DSP (2) 00000 invalid coding 00001 All valid engine types All others (1) On 00002 USA On (1) "All others" (all countries except USA/Canada unless otherwise specified) (2) Dynamic Shift Program (DSP)
2. Press -Q- button to confirm input. NOTE: Other codes are not permitted. After coding, DTC memory is automatically erased.
3. Press --> button.

Indicated on display

Scheme 134

1. Press buttons -0- and -1- to select "Check Control Module Versions" function 01, and press -Q- button to confirm.

Indicated on display (example)

Scheme 135

1. Check coding (refer to table).

If indicated on display

Scheme 136

Note. The code that was entered is invalid, or is not recognized by the TCM. If an invalid code has been entered, the TCM will retain the old coding. Only older VAG1551 program cards will display the TCM identification with the old coding after an invalid code has been entered.

If indicated on display

Scheme 137

An attempt has been made to input coding under conditions that do not permit it (for example, transmission drive mode selected).

Diagnostic Trouble Code (DTC) table

Note. The following table contains all possible malfunctions that are recognized by the Transmission Control Module (TCM) -J217- and displayed by the VAG 1551 or VAG 1552 Scan Tool (ST) when the Diagnostic Trouble Code (DTC) memory is checked. The DTC is printed out in the "Rapid data transfer" operating mode only when the printer of the VAG 1551 scan tool is switched on. Example: DTC 17087P0703 (VAG code and P-code). If malfunctions occur occasionally or if the DTC memory was not erased after corrective actions, these malfunctions are indicated as "sporadic" for a specified amount of time. Malfunction recognition by the TCM, see TRANSMISSION CONTROLS . If components are determined to be malfunctioning when the DTC memory is checked, check the wiring to the components for a short circuit and open circuit. See appropriate System Wiring Diagrams . "Dcy " means "driving cycle." Conditions for recognition of a driving cycle (Dcy), see MIL FUNCTIONAL CHECK . Malfunction Indicator Lamp (MIL) function, see MALFUNCTION INDICATOR LAMP (MIL), FUNCTION The "MIL" column in the DTC table indicates the conditions for which the MIL will be switched on. If, for example, "2 Dcy" is indicated, it means that the MIL will be switched on after 2 driving cycles. If "Off" is indicated, the malfunction has no influence on the MIL. If "On" is indicated, the MIL will be switched on immediately when the malfunction occurs.

Scheme 138

1. For Output Diagnostic Test Mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .

Scheme 139

1. For TCM replacement, see «ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-and-electronic-components-locations) .

Scheme 140

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 141

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For multifunction switch F125 replacement, see «TRANSMISSION RANGE SWITCH»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__transmission-range-switch) .

Scheme 142

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For the replacement of transmission fluid temperature sensor -G93-, see «TRANSMISSION FLUID TEMPERATURE SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 143

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
4. For the replacement of transmission fluid temperature sensor -G93-, see «TRANSMISSION FLUID TEMPERATURE SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 144

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
4. For the replacement of transmission fluid temperature sensor -G93-, see «TRANSMISSION FLUID TEMPERATURE SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 145

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
4. For the replacement of transmission fluid temperature sensor -G93-, see «TRANSMISSION FLUID TEMPERATURE SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 146

Scheme 147

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For removal of -G182-, see «TRANSMISSION RPM SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .
4. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
5. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
6. To replace solenoid valves and/or valve body, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 148

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .

Scheme 149

1. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 150

1. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
2. For transmission shift element diagrams and tables, see «TRANSMISSION SHIFT ELEMENTS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 151

1. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
2. For transmission shift element diagrams and tables, see «TRANSMISSION SHIFT ELEMENTS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .
3. For torque converter removal, see «TRANSAXLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#removal-installation-at-01l-awd__transaxle) .

Scheme 152

1. For ATF level checking, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
3. To replace solenoid valves and/or valve body, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 153

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 154

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 155

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 156

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 157

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 158

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For DTM, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__output-diagnostic-test-mode-dtm-function) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 159

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. To replace solenoid valves and/or valve body, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 160

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 161

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 162

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For TCM replacement, see «ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-and-electronic-components-locations) .

Scheme 163

1. For TCM replacement, see «ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-and-electronic-components-locations) .
2. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 164

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For more information regarding Backup Mode, see «TCM BACKUP FUNCTIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__tcm-backup-functions) .

Scheme 165

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For more information regarding Backup Mode, see «TCM BACKUP FUNCTIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__tcm-backup-functions) .

Scheme 166

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 167

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For TCM replacement, see «ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-and-electronic-components-locations) .

Scheme 168

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 169

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 170

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 171

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 172

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Scheme 173

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. For TCM coding, see «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__code-control-module-scan-tool-function) .

Scheme 174

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
3. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 175

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
3. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .
4. For ABS diagnosis, see «ON BOARD DIAGNOSTIC (OBD)»(/audi/a8/d3-2002-2005/remont/warning-system/#on-board-diagnostic-obd-absedlasr) .

Scheme 176

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
3. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 177

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
2. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
3. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 178

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 179

1. For "Read Measuring Value Block", see «READ MEASURING VALUE BLOCK (FUNCTION 08)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__read-measuring-value-block-function-08) .
2. For TCM identification, see «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Scheme 180

Scheme 181

Note. Item 11 in (Scheme 182): the ignition angle is briefly retarded through this TCM signal, depending on speed and engine RPM, during a transmission range change (shift), in order to soften the shift. Item 12 in (Scheme 182): if, while there is a driving malfunction or operating malfunction, a transmission range is engaged by hand with the vehicle parked and the engine at high RPM, the ECM will reduce engine torque instantaneously by shielding the injection signals.

Output Diagnostic Test Mode (DTM) (function 03)

Note. The output DTM can only be carried out when the selector lever is in "P" position, the engine is running, and the vehicle is standing still. The output DTM is discontinued when the engine is started. The function of the solenoid valves 1 -N88-, 2 -N89- and 3 -N90- and the shift lock solenoid -N110- are checked audibly during the output DTM. During the audible check the surrounding noises should be limited, since the clicking noises are very quiet. Pressure control valves 1 -N215-, 2 -N216-, 3 -N217-, 4 -N218- and pressure regulating valve 5 -N233- are triggered by the output DTM. A direct functional check of these components is not possible. However, electrical malfunctions, which occur during this triggering, are eventually stored in the DTC memory through the OBD program. During the output DTM the individual controls are triggered until the --> button is pressed. Only a complete final control diagnosis is possible after the ignition is switched on. To repeat, the ignition must be switched off and switched on again.

DTM TRIGGERING SEQUENCE OUTPUT

1. Connect VAG 1551 scan tool, insert "Transmission Electronics" address word 02, and advance through program sequence to "Select function" mode. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Indicated on display

Scheme 182

1. Press buttons -0- and -3- to select "Output Diagnostic Test Mode" function 03.

Indicated on display

Scheme 183

1. Press -Q- button to confirm input.

Indicated on display

Scheme 184

If the solenoid valve is triggered (clicks)

1. Press --> button to switch to next control.

If the valve is not triggered (does not click)

1. Carry out electrical testing. See «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Note. A malfunction is stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 185

If the solenoid valve is triggered (clicks)

1. Press --> button to switch to next control.

If the valve is not triggered (does not click)

1. Carry out electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Note. A malfunction is stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 186

If the solenoid valve is triggered (clicks)

1. Press --> button to switch to next control.

If the valve is not triggered (does not click)

1. Carry out electrical testing. See «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Note. A malfunction is stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 187

If the solenoid is triggered (clicks)

1. Press --> button to switch to next control.

If the solenoid is not triggered (does not click)

1. Carry out electrical testing. See «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Note. A malfunction is stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The valve is triggered.

Scheme 188

1. Press --> button to switch to next control.

Note. Possible electrical malfunctions are stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The valve is triggered.

Scheme 189

1. Press --> button to switch to next control.

Note. Possible electrical malfunctions are stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The valve is triggered.

Scheme 190

1. Press --> button to switch to next control.

Note. Possible electrical malfunctions are stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The valve is triggered.

Scheme 191

1. Press --> button to switch to next control.

Note. Possible electrical malfunctions are stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The valve is triggered.

Scheme 192

1. Press --> button to switch to next control.

Note. Possible electrical malfunctions are stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display. The activated solenoid valves are triggered (click) in "P" position.

Scheme 193

Note. This need not be taken into consideration.

1. Press -->1 button to switch to next control.

Indicated on display

Scheme 194

1. Press --> button to end output DTM.

Indicated on display

Scheme 195

To repeat the output DTM, the ignition must be switched off and then on again. Then, the "Output Diagnostic Test Mode" function 03 must be selected again.

Requirement

1. DTC memory checked. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

After successful check of DTC memory

Indicated on display

Scheme 196

1. Press buttons -0- and -5- to select "Erase DTC Memory" function 05.

Indicated on display

Scheme 197

1. Press -Q- button to confirm input.

If "DTC Memory is not interrogated" is indicated on display

Scheme 198

Note. DTC memory is not erased if the ignition was switched on between the check of DTC memory and the attempt to erase DTC memory.

1. Adhere to work sequence exactly (i.e. check DTC memory first).

Indicated on display. DTC memory is erased approx. 5 seconds later.

Scheme 199

Note. Wait 1 minute before checking DTC memory again.

If the display indicates

Scheme 200

Or the print-out (with the printer switched on) indicates

The TCM -J217 was not given time for malfunction recognition.

1. Wait 1 minute before checking DTC memory again.
2. After checking and erasing DTC memory, conduct road test and then check DTC memory again. "No DTC recognized" must be indicated.

Read Measuring Value Block (function 08)

1. Connect VAG 1551, insert "Transmission Electronics" address word 02 and advance through program sequence until "Select function XX" is indicated in display. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Indicated on display

Scheme 201

1. Press buttons -0- and -8- to select "Read Measuring Value Block" function 08.

Indicated on display

Scheme 202

1. Press -Q- button to confirm input.

Indicated on display

Scheme 203

1. Input display group number. Display group numbers (Scheme 207)
2. Press -Q- button to confirm input.

4 display fields always appear in the measuring value block (in physical values where necessary). For specifications for values in individual display fields => table, => MEASURING VALUE BLOCK TABLE .

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Note. The actual display is printed out if the printer is switched on.

If the specified values are attained in all display fields

1. Press --> button.

Indicated on display

Scheme 208

Scheme 209

1. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 210

1. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 211

1. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 212

Scheme 213

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing)
2. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 214

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing)
2. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 215

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing)
2. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Note for ATF-temperature

1. A recognized temperature of minus 50° C (122° F) indicates a short circuit to Ground (GND)
2. A recognized temperature of 180° C (356° F) indicates a short circuit to plus (B+) or open circuit.

Scheme 216

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing)
2. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .
3. For selector lever cable adjustment, see «SELECTOR LEVER CABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__selector-lever-cable) .

Scheme 217

Note to intermediate positions

If the selector lever is shifted to the indicated intermediate positions, the scan tool will display "Z1", "Z2", "Z3" or "Z4". The display in the instrument cluster must not show the selected position, only PRND432 without a range being illuminated.

Scheme 218

1. For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table)
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .
3. For selector lever cable adjustment, see «SELECTOR LEVER CABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__selector-lever-cable) .

Note to display field 3 of display group number 004

The input signals for Multi-function Transmission Range (TR) Switch -F125 can be checked at the TCM.

Scheme 219

Scheme 220

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Note to display field 4 of display group number 004

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

1. The engine intervention is only activated during shifting. The engine intervention can only be very briefly activated depending on the driving situation. This means that the relative slow data transmission to the V.A.G 1551 scan tool can neglect this brief engine intervention under certain driving conditions. For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) . For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) . For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) . For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) . For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) To check ATF level, see «CHECKING FLUID LEVEL»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__checking-fluid-level) . For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) For transmission shift elements, see «TRANSMISSION SHIFT ELEMENTS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) . For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table)

Note on Display field 1

The signal of the engine moment is transmitted to the TCM via the CAN-BUS wiring.

Scheme 229

1. For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table)

Scheme 230

1. For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table)

Scheme 231

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing)

Scheme 232

Scheme 233

1. For DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table)

Note to display group number 013

Scheme 234

1. Display field 2 and 4: When replacing the ECM, the display must be the same for the old and the new ECM. If not, the wrong ECM was installed or it was incorrectly coded. For more DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) . For electrical testing, see «ELECTRICAL TESTING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-testing) .

Electrical testing

1. For testing use a Fluke 83 multimeter or equivalent.
2. The specified values are valid for an ambient temperature of 10-40° C (50-104° F).
3. If measured values deviate from specified values, determine the malfunction using the appropriate wiring diagram.
4. If measured values deviate only slightly from specified values, clean the sockets and connectors of the test unit and test leads and repeat the test.
5. Before replacing components, check the respective wiring and connectors. Repeat resistance tests when values are below 10°.
6. To connect test units, use test box VAG 1598/20.
7. The terminal numbers of the connector and the socket numbers of test box VAG 1598/20 must be uniform. See «MULTI-PIN CONNECTOR (88-PIN CONNECTOR) OF TCM -J217- (SOCKET NUMBERS ON VAG 1598/20)»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__multi-pin-connector-88-pin-connector-of-tcm) .

1. Battery Positive Voltage (B+) OK
2. Fuses for Transmission Control Module (TCM) OK
3. Fuses for components to be checked OK
4. Ground (GND) connections OK

1. Check battery GND strap and GND strap between body and transmission.
2. Check GND connectors for TCM.

See appropriate System Wiring Diagrams article.

Testing

1. Conduct steps recommended in DTC table only.
2. Switch ignition off for all test steps, remove multi-pin connector from TCM -J217- (located in right side of plenum, see «ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__electrical-and-electronic-components-locations) ), and connect test box VAG 1598/20 to wiring harness connector.

If measured values deviate from specified values

1. Carry out all corrective actions listed on right side of test table. See «ELECTRICAL TEST TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Multi-pin connector (88-pin connector) of TCM -J217- (socket numbers on VAG 1598/20)

MULTI-PIN CONNECTOR (88-PIN CONNECTOR) OF TCM -J217- (SOCKET NUMBERS ON VAG 1598/20)

Overview of test steps (of 88-pin connector)

Note. Conduct only those test steps recommended in the DTC and measuring value block tables (listed below, according to the component).

TEST STEPS OVERVIEW (88 PIN CONNECTOR)

Scheme 235

Scheme 236

1. For brake light switch information, see «BRAKE LIGHT SWITCH, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/anti-locktraction-control/#antilock-brake-system) .
2. For accelerator pedal cable adjustment, see «ACCELERATOR PEDAL CABLE, ADJUSTING»(ref-196863-S32795413642005100900000) .

Scheme 237

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For multi-function switch information, see «TRANSMISSION RANGE SWITCH»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__transmission-range-switch) .

Scheme 238

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For multi-function switch information, see «TRANSMISSION RANGE SWITCH»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__transmission-range-switch) .

Scheme 239

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For additional DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .

Scheme 240

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For additional DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .
3. For valve body removal and installation, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 241

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For additional DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .
3. For valve body removal and installation, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 242

1. For accelerator pedal cable adjustment, see «ACCELERATOR PEDAL CABLE, ADJUSTING»(ref-196863-S32795413642005100900000) .

Scheme 243

1. For transmission RPM sensor, see «TRANSMISSION RPM SENSOR»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 244

1. For TCM wiring information, see «WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__wiring-harness-between-transmission-control-module) .
2. For additional DTC information, see «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a8/d3-2002-2005/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd__diagnostic-trouble-code-dtc-table) .
3. For valve body removal and installation, see «VALVE BODY»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd) .

Scheme 245

Scheme 246

1. For additional CAN-Bus information (Scheme 182)
2. For further information regarding ECM terminal locations, see «MULTIPORT FUEL INJECTION (MFI) - 3.7L & 4.2L V8 4V (ABZ & AEW)»(ref-196870) (1997-99) or «MULTIPORT FUEL INJECTION (MFI) - 4.2L V8 (AKB, AUX, AYS)»(/audi/a8/d3-2002-2005/remont/fuel-system/#multiport-fuel-injection-mfi-42l-v8-akb-aux-ays).

Scheme 247

1. For multi-function switch information, see «TRANSMISSION RANGE SWITCH»(/audi/a8/d3-2002-2005/remont/automatic-trans/#servicing-at-01l-awd__transmission-range-switch) .

Scheme 248

Disconnecting connector

1. Remove spring-clip lock -2- from harness/multi-function switch connector.

Scheme 249

Wiring harness between Transmission Control Module (TCM) and transmission, checking

Note. This check is to be conducted if either the output Diagnostic Test Mode (DTM) or electrical testing indicates a malfunction in the wiring between the transmission and the Transmission Control Module (TCM) -J217-.

1. Ignition switched off
2. Test box VAG 1598/20 connected to 88-pin transmission wiring harness connector

1. Remove noise insulation.

Scheme 250

Scheme 251

Scheme 252

1. Unlock bayonet lock -4- of 16-pin connector to transmission by turning it (remove bracket -1- for noise insulation if necessary).
2. Check wiring connections for continuity (using multimeter) between terminals of 16-pin connector and sockets of test box VAG 1598. For Specifications see scheme 145

Note. If this test does not result in deviations from specified values, check the wiring harness. For valve body, removing and installing, see VALVE BODY . After a satisfactory test of the wiring harness in the transmission has been conducted, the appropriate solenoid valves must be replaced. For valve body, removing and installing, see VALVE BODY .

Scheme 253

Scheme 254

Scheme 255

1. Remove spring-clip lock -2- from harness/multi-function switch connector.
2. Check wiring connections for continuity (using multimeter) between terminals of 8-pin connector and sockets of test box VAG 1598. Specifications see scheme 148

Transmission diagram for all-wheel drive

The following list pertains to see scheme 149.

1. A = Clutch A
2. B = Clutch B
3. C = Clutch C
4. D = Brake D
5. E = Brake E
6. F = Brake F
7. F1 = Freewheel 1
8. W = Converter clutch
9. Z1 ... Z 3 = Gears for intermediate drive, front; ratios.
10. Z 4, Z5 = Ring gear and pinion set, front; ratios.
11. Z 6, Z 7 = Gears for intermediate drive, rear; ratio.
12. Z 8, Z 9 = Gears for rear differential; ratio.
13. 1 = Driving direction
14. 2 = Front differential
15. 3 = Front axle output
16. 4 = Rear axle drive
17. 5 = Distributor (PAT)
18. 6 = Rear differential
19. a = Output shaft
20. b = Pinion shaft

Shift element positions

Note. Carry out the On Board Diagnostic program (see ON BOARD DIAGNOSTIC (OBD), GENERAL INFORMATION ) before repairing the transmission The following tables show which shifting elements are activated in the individual transmission ranges. If there are complaints regarding the performance of the transmission or recognized malfunctions, this information may be used to determine which shifting elements are not operating properly. Unless otherwise described, the clutch and solenoid logic in the different selector lever positions corresponds to the logic in permanent setting D.

See also:
• MOTRONIC ENGINE CONTROL MODULE (ECM) -J220- (WITHOUT METAL ANTI -THEFT HOUSING), REPLACING
• VALVE BODY
• TRANSMISSION RANGE SWITCH
• STEERING COLUMN SWITCHES, SERVICING
• BRAKE LIGHT SWITCH, REMOVING AND INSTALLING
• CHECKING FLUID LEVEL
• TRANSAXLE
• ON BOARD DIAGNOSTIC (OBD)
• SELECTOR LEVER CABLE
• MULTIPORT FUEL INJECTION (MFI) - 4.2L V8 (AKB, AUX, AYS)
• DIAGNOSTIC TROUBLE CODE (DTC) TABLE
• ON BOARD DIAGNOSTIC (OBD), FUNCTIONS
• ON BOARD DIAGNOSTIC (OBD), CHECKING
• ELECTRICAL AND ELECTRONIC COMPONENTS, LOCATIONS
• REMOVING AND INSTALLING TRANSMISSION CONTROL MODULE (TCM) -J217
• READ MEASURING VALUE BLOCK (FUNCTION 08)
• ELECTRICAL TESTING
• TCM BACKUP FUNCTIONS
• CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)
• OUTPUT DIAGNOSTIC TEST MODE (DTM) (FUNCTION 03)
• TRANSMISSION CONTROLS
• MIL FUNCTIONAL CHECK
• MALFUNCTION INDICATOR LAMP (MIL), FUNCTION
• MULTI-PIN CONNECTOR (88-PIN CONNECTOR) OF TCM -J217- (SOCKET NUMBERS ON VAG 1598/20)
• WIRING HARNESS BETWEEN TRANSMISSION CONTROL MODULE (TCM) AND TRANSMISSION, CHECKING
