Diagnostic Trouble Code (DTC) Memory, checking (function 02) Audi A8 D2 facelift

On Board Diagnostic (OBD) - HVAC, CAN & Defrosters: Diagnosis 5 illustrations ~170 words

Diagnostic Trouble Code (DTC) Memory, checking (function 02)

  1. Connect VAG 1551 Scan Tool, insert address word 08 "AC/Heating Electronics" and move forward in program until "Select function XX" is displayed. See «VAG 1551 ((VAG 1552) SCAN TOOL (ST), CONNECTING AND SELECTING FUNCTIONS»(ref-196890-S19658011992005101000000) .
  2. Switch printer on by pressing the PRINT button (indicator lamp in button comes on).

Indicated on display (function selection)

Scheme 3

Scheme 3
Scheme 3
  1. Press buttons -0- and -2- (function "Check DTC Memory" is entered with 02).

Indicated on display

Scheme 4

Scheme 4
Scheme 4
  1. Press -Q- button to confirm input.

Number of stored DTCs or "No DTC recognized" is displayed

Scheme 5

Scheme 5
Scheme 5
  1. Press => button.

Stored DTCs are displayed and printed one after the other

If "No DTC recognized" is displayed, program returns to the starting position after --> button is pressed.

Scheme 6

Scheme 6
Scheme 6

Indicated on display (function selection)

Scheme 7

Scheme 7
Scheme 7
  1. End output (function 06). See «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, ERASING (FUNCTION 05)»(ref-196890-S22847116632005101000000) .
  2. Switch ignition off and unplug Data Link Connector (DLC).
