Removal
- Unclip cable tunnel cover.
- Remove connector and mark.
- Press inside rear view mirror off the retaining plate by pushing down at a angle clamping springs in base of mirror. (Scheme 7)
Scheme 7
Installation
Note. Cable channel should not be used for turning
When installing mirror, rotate mirror 60-90 degrees, install onto installation point and turn in direction of arrows until locking springs engage. (Scheme 8)
Scheme 8
Removal & Installation
- Switch ignition off.
- Remove mirror lens. See «MIRROR LENS»(ref-150820-S08008822632002112200000).
- Remove screws. (Scheme 9)
- Remove electric adjusting unit.
- Remove cover from electric adjusting unit. (Scheme 10)
- Cut electrical wiring close to soldered connections. (Scheme 11)
Scheme 9
Scheme 10
Scheme 11
Attach electrical wires to plug housing included with replacement parts. (Scheme 12)
- Harness connector wire 1 (Red).
- Harness connector wire 2 (Brown/White).
- Harness connector wire 3 (White). NOTE: Arrow points to chamfer on harness connector housing.To install, reverse removal procedures, See «TORQUE SPECIFICATIONS»(ref-150820-S35373178642002112100000) .
Scheme 12
- Unglue mirror housing.
- Using Pry Lever (82-200), carefully pry out lens at button first, then at top. (Scheme 13)
- Disconnect harness connectors.
Scheme 13
| CAUTION | Safety gloves must be worn when installing the mirror lens. |
- Attach harness connectors.
- Friction finger on mirror lens must also be inserted into friction spring in housing during installation. (Scheme 14)
- Press on mirror lens.
Scheme 14
- Unclip trim from door component carrier. (Scheme 15)
- Remove seal.
- Run door window to lowest position.
- Remove bolt together with washer. (Scheme 16)
- Lift out rear view mirror behind opening seal and the window guide.
- Lift off seal simultaneously.
- Disconnect harness connectors.
- To install, reverse removal procedures. See «TORQUE SPECIFICATIONS»(ref-150820-S35373178642002112100000). NOTE: Align rear view mirror to window guide when installing.
