| CAUTION | Before working on the electrical system: Determine the correct coding for the anti-theft radio. Disconnect the battery Ground (GND) strap. |
Note. After reconnecting the battery be sure to reactivate the radio, clock, power windows and engine according to instructions in the Owner's Manual.
The cruise control, control module is located in the electronics box (E-box) in the plenum.
Note. The following list refers to items in (Scheme 1).
- Actuator with membrane
- Brake vent valve
- Clutch vent valve
- Vacuum hose T-connector
- Vacuum pump
Note. The operating switch is integrated in the turn signal lever. Contact assignment on ignition switch. See TERMINAL ASSIGNMENT FOR WINDSHIELD WIPER SWITCH, HIGH INTENSITY WASHER SYSTEM, HEADLIGHT WASHER SYSTEM AND ON-BOARD COMPUTER . The cruise control, control module is located in the electronics box (E-box) in the plenum.
Scheme 1
- Remove screws for plenum and remove cover.
- Remove cover for E-box (remove 4 screws).
- Remove nut -1- and remove control module upward from E-box.
- Disconnect electrical connector. see scheme 2: Removing Nut And Control Module Upward From E-Box
