Code Control Module (scan tool function 07)

  1. Connect VAG1551 scan tool, insert "Transmission Electronics" address word 02, and advance through program sequence until "Select function XX" is displayed. See «ON BOARD DIAGNOSTIC (OBD), CHECKING»(/audi/a8/d2-1999-2002/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) .

Indicated on display

Scheme 131

Scheme 131
Scheme 131
  1. Press buttons -0- and -7- to select "Code Control Module" function 07.

Note. The Transmission Control Module (TCM) can be successfully coded only with

  1. Ignition switched on
  2. Gear selector lever in "P" or "N" position
  3. Accelerator pedal at Closed Throttle Position (CTP)
  4. Vehicle not moving
  5. Engine not running

Indicated on display

Scheme 132

Scheme 132
Scheme 132
  1. Press -Q- button to confirm input.

Indicated on display

Scheme 133

Scheme 133
Scheme 133
  1. Input code number according to «CONTROL MODULE CODE NUMBERS»(/audi/a8/d2-1999-2002/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01l-awd) table. CONTROL MODULE CODE NUMBERS Code Engine Country DSP (2) 00000 invalid coding 00001 All valid engine types All others (1) On 00002 USA On (1) "All others" (all countries except USA/Canada unless otherwise specified) (2) Dynamic Shift Program (DSP)
  2. Press -Q- button to confirm input. NOTE: Other codes are not permitted. After coding, DTC memory is automatically erased.
  3. Press --> button.

Indicated on display

Scheme 134

Scheme 134
Scheme 134
  1. Press buttons -0- and -1- to select "Check Control Module Versions" function 01, and press -Q- button to confirm.

Indicated on display (example)

Scheme 135

Scheme 135
Scheme 135
  1. Check coding (refer to table).

If indicated on display

Scheme 136

Scheme 136
Scheme 136

Note. The code that was entered is invalid, or is not recognized by the TCM. If an invalid code has been entered, the TCM will retain the old coding. Only older VAG1551 program cards will display the TCM identification with the old coding after an invalid code has been entered.

If indicated on display

Scheme 137

Scheme 137
Scheme 137

An attempt has been made to input coding under conditions that do not permit it (for example, transmission drive mode selected).
