Contact corrosion!

With the extensive use of aluminum construction, corrosion caused by contact between dissimilar metals may result if the wrong fastening components (screws, bolts, nuts, washers, rivets, plugs, grommets, adhesives, etc.) are installed.

For this reason, the manufacturer only installs fastening components that have a special surface coating, recognized by its greenish color, and only uses rubber parts, plastic parts and adhesives that are electrically non-conductive.

These parts, compatible for use with aluminum, are also available as replacement parts.

Use only Genuine Parts!

If there is any doubt about whether the old parts are suitable for re-use, always install new replacement parts.

All accessories must be approved by Audi of America, Inc.

Damage from contact corrosion caused by improper assembly with unsuitable parts is NOT covered under warranty!

Glove box and bracket for glove box, removing and installing

Note. The following list refers to (Scheme 1).

  1. Knee bar For passenger side Removing Open glove box. Remove lock cylinder and glove box push button. See «LOCK CYLINDER AND PUSH BUTTON FOR GLOVE BOX, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) . Remove screws -9-. Remove knee bar trim -2-. Remove screws -10-. Remove kneebar retaining panel -15- from bracket -8-. Disconnect connector for illumination. Remove kneebar. Installing Adjust glove box with adjustment angle -16- and cam -20-. Adjust height at elongated hole at spring nut -19-. Adjust toward front and rear using screw -17-. Perform lateral adjustment by adjusting cam -20-. Loosen screw -21- and adjust cam lever -22- for lateral adjustment. Tighten screw -21-.
  2. Kneebar trim
  3. Support left Remove screws -11-.
  4. Support right Remove screws -12- and -13-.
  5. Retaining bracket Remove screws -14-.
  6. Bracket For knee bar, left Unhook at passenger airbag frame
  7. Bracket For knee bar, right Unhook at passenger airbag frame
  8. Bracket
  9. Bolt 2.5 Nm (22 in. lb.) Qty. 2
  10. Bolt 2.5 Nm (22 in. lb.) 2 parts Qty. 4
  11. Screw 22 Nm (16 ft. lb.) Qty. 2
  12. Screw 22 Nm (16 ft. lb.)
  13. Screw 15 Nm (11 ft. lb.)
  14. Screw 22 Nm (16 ft. lb.) Qty. 2
  15. Retaining panel
  16. Adjustment angle
  17. Bolt 2.5 Nm (22 in. lb.)
  18. Washer
  19. Spring nut
  20. Cam
  21. Bolt 2.5 Nm (22 in. lb.)
  22. Cam lever

Special tools and equipment

  1. Precision mechanic screwdriver; 1.6 x 40 mm

Removing

  1. Remove glove box (see «GLOVE BOX AND BRACKET FOR GLOVE BOX, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__glove-box-and-bracket-for-glove) ) and place in floor outlet.
  2. Turn vehicle key approx. 45° -a-.
  3. Insert precision screwdriver into hole (arrow).
  4. Lock screwdriver into guide tab (arrow).
  5. Press guide tab upward. Lock cylinder is unlocked (if necessary, correct key position slightly).
  6. Pull out lock cylinder with vehicle key inserted. NOTE: Shown in illustration with lock removed.
  7. Loosen screw (arrow) through hole for lock cylinder until retaining bracket slides back.
  8. Remove push button from front.
  9. Turn knurled nut (arrow) for Bowden cable adjustment slightly inward so cable loosens.
  10. Unhook Bowden cable at push button and remove push button.

Installing

Installation is done in reverse order of removal, noting the following

  1. If push button has play or glove box does not close properly, adjust Bowden cable length at knurled nut.

Knee bar and bracket, driver side, removing and installing

Note. The following list refers to see scheme 7.

  1. Knee bar For driver side Removing Remove lower gap cover -6- from below. Pry out left trim -2- and right trim -3- using screwdriver. Remove screws -4- and -5- and remove kneebar.
  2. Trim, left
  3. Trim, right
  4. Screw 2.5 Nm (22 in. lb.) Qty. 3
  5. Screw 2.5 Nm (22 in. lb.) Qty. 2
  6. Gap cover, lower
  7. Support, left Removing instrument cluster See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#instruments__instrument-cluster-removing-and-installing) for up to m.y. 1999 and «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(ref-196902-S39119177702005101000000) for m.y. 2000 on. Control module for ABS, removing See «ANTILOCK BRAKE SYSTEM»(/audi/a8/d2-1994-1999/remont/anti-locktraction-control/#antilock-brake-system) . Remove screws -9-.
  8. Support, right Removing instrument cluster See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#instruments__instrument-cluster-removing-and-installing) for up to m.y. 1999 and «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(ref-196902-S39119177702005101000000) for m.y. 2000 on. Air duct for side air outlet rear, removing and installing. See «REMOVING AND INSTALLING AIR VENT FOR SIDE OUTLET, REAR»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__removing-and-installing-air-vent-for) . Remove screws -10-.
  9. Screw 15 Nm (11 ft. lb.) 2 parts
  10. Screw 15 Nm (11 ft. lb.) 2 parts
  11. Bracket Remove screw -12-.
  12. Screw 2.5 Nm (22 in. lb.)

Removing and installing air vent for side outlet, rear

  1. Remove screw -1-.
  2. Slide air duct -2- out completely in direction of left arrow until air duct unhooks from A/C.
  3. Remove air duct downward in direction of arrow.
  4. Disconnect connector for floor outlet light -3-.
  5. Area -4- is removed on vehicles with manual transmission.

Trim for steering column switch, overview

Note. The following list refers to see scheme 9.

  1. Gap cover, lower
  2. Trim, lower Up to m.y. 06.97
  3. Phillips-head screw 0.6 Nm (5 in.lb.) 2 parts
  4. Trim upper
  5. Switch for steering column adjustment -E167- Only for power adjustable steering column
  6. Phillips-head screw 0.6 Nm (5 in.lb.) For trim, lower, up to m.y. 06.97
  7. Countersunk screw 0.3 Nm (3 in. lb.) 2 parts
  8. Phillips-head screw 0.6 Nm (5 in. lb.) 2 parts
  9. Oval head screw 3 Nm (27 in. lb.) 2 parts Only for mechanically adjustable steering column
  10. Handle for steering column adjustment
  11. Hex socket bolt 2.5 Nm (22 in.lb.)

Trim for steering column switch, removing and installing

  1. Remove bolts (arrows) and remove trim -1-.
  2. Remove airbag unit driver side. See appropriate Air Bag Restraint Systems article in Restraints.
  3. Remove steering wheel. See appropriate Air Bag Restraint Systems article in Restraints.
  4. Remove lower gap cover in direction of arrow.
  5. Remove bolts -1- and remove handle -2- for steering column adjustment. see scheme 12
  6. Remove bolts -7- and -8- and remove lower trim for steering column switch -4-.
  7. If necessary disconnect connector for switch -6- or remove switch. NOTE: In the illustration, trim for steering column switch up to m.y. 06.97 is shown.

Center console, overview

Note. The following list refers to see scheme 13.

  1. Left trim for center console
  2. Hex bolt 2.5 Nm (22 in.lb.)
  3. Phillips-head screw 2.5 Nm (22 in.lb.)
  4. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts
  5. Ashtray
  6. Hex socket bolt 2.5 Nm (22 in.lb.) 4 parts
  7. Instrument cluster, center part Removing and installing. See «INSTRUMENT PANEL (CENTER), ASSEMBLY»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__instrument-panel-center-assembly) .
  8. Hex socket bolt 2.5 Nm (22 in.lb.)
  9. Cover
  10. Locking screw 1 Nm (8 in.lb.) Loosen to adjust parking brake cover
  11. Parking brake lever handle Removing Pry out lock pin at underside. Remove parking brake lever from front
  12. Washer For lock pin
  13. Trim For parking brake After loosening, lock pin is adjustable both longitudinally and in cross direction. See REMOVING . Turn locking screw (item -10-) approx. 2 revolutions to loosen Remove trim from front.
  14. Trim parking brake Insert retaining pin of trim in hole at parking brake lever.
  15. Outlet rear seat area
  16. Trim For outlet rear seat Unclip to remove
  17. Phillips-head screw 1.5 Nm (13 in.lb.) 2 parts
  18. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts
  19. Center console Removing and installing. See «CENTER CONSOLE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-removing-and-installing) .
  20. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts
  21. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts

Center console, removing and installing

  1. Make auxiliary tool for disassembly of outlet.
  2. Bend wire of 3 mm diameter as shown in illustration.
  3. Dimension -x- = 6 mm
  4. Remove speaker mounting for telephone. See «CENTER CONSOLE AND CENTER ARMREST WITH TELEPHONE, INSTALLATION»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-and-center-armrest-with).
  5. Position seats all the way back.
  6. Remove floor left and right cover. See «FLOOR PAD FRONT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-trim__floor-pad-front-removing-and-installing).
  7. Turn accelerator pedal stop 1/4 revolution (90°) further.
  8. Remove screws -1- and -2-.
  9. Remove trim left for center console -3- (to remove, slide trim forward and unhook from back).
  10. Remove screws -2- and -3-. see scheme 16
  11. The front screws -2- can be reached by turning back floor covering.
  12. Remove right-side trim for center console -1-.
  13. To remove, slide trim forward and unhook from back.
  14. Pull up parking brake lever as far as possible.
  15. Pry out lock pin -2- in direction of (arrow -A-). see scheme 17
  16. Remove parking brake lever handle -1- in direction of (arrow -B-).
  17. Pry off cover -1- and loosen lock bolt (arrow) approx. 2 rotations. see scheme 18
  18. Remove trim plate for trim -2- from front.
  19. Remove parking brake trim. Note the retaining tab at the rear/narrow end of the trim.

Vehicles with manual transmission

  1. Remove shift knob and place in 4th gear.

Vehicles with center armrest

  1. Remove center armrest. See «CENTER ARMREST (THROUGH 1999)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) .

Scheme 1

Scheme 1: All vehicles
Scheme 1: All vehicles
  1. Unclip trim -2-. see scheme 20
  2. Remove screws -3-.
  3. Remove rear seat outlet -1-.
  4. Place auxiliary tool -C- in holes of instrument cluster outlets -D-. see scheme 21
  5. Remove instrument cluster outlet, center part out evenly. NOTE: Do not hook auxiliary tool -C- into fins of instrument cluster outlet (the fins could break off).
  6. Remove 5 bolts (arrows). see scheme 22
  7. Remove instrument cluster, center part -1- and disconnect connectors.
  8. Remove bolts -4- left and right.
  9. Press ashtray -1- toward front.
  10. Remove screws -3-.
  11. Using sharp knife, separate, where necessary, adhesive between center console -2- and instrument panel.
  12. Raise rear center console and guide to front over parking brake lever.

Instrument panel (center), assembly

Note. Illustration shows version with Radio-Navigation system.

Note. The following list refers to see scheme 24.

  1. Bracket
  2. Hex socket bolt 2.5 Nm (22 in.lb.) 4 parts
  3. Connecting hose
  4. Phillips-head screw 1.2 Nm (10 in.lb.) 3 parts
  5. Interior temperature sensor fan -V42
  6. Phillips-head screw 1.2 Nm (10 in.lb.) 4 parts
  7. Bracket
  8. A/C control head -E87- For air conditioning
  9. Hex socket bolt 2 Nm (17 in.lb.)
  10. Instrument cluster-center part
  11. Instrument cluster outlet, center Remove using auxiliary tool. See «INSTRUMENT PANEL (CENTER), REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__instrument-panel-center-removing-and-installing) .
  12. Hex socket bolt 2.5 Nm (22 in.lb.)
  13. Switch To remove, press trim from backside
  14. Control module for operating electronics, navigation -J401- Note coding, ask if necessary For removal and installation, see «NAVIGATION CONTROL MODULE WITH CD DRIVE -J401-, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/communication-devices/#radio-telephone-navigation-trip-computer__navigation-control-module-with-cd-drive) or «NAVIGATION SYSTEM IV (BNS 4.0) FROM 01.01»(/audi/a8/d2-1994-1999/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
  15. Trim for instrument cluster, center
  16. Nut Always replace 1.2 Nm (10 in.lb.) Self-locking 4 parts

Instrument panel (center), removing and installing

  1. Make auxiliary tool for disassembly of outlet.
  2. Bend wire of 3 mm diameter as shown in illustration. Dimension -x- = 6 mm
  3. Remove speaker mounting for telephone. See «CENTER CONSOLE AND CENTER ARMREST WITH TELEPHONE, INSTALLATION»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-and-center-armrest-with).
  4. Position seats all the way back.
  5. Remove floor cover left and right. See «FLOOR PAD FRONT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-trim__floor-pad-front-removing-and-installing).
  6. Turn accelerator pedal stop 1/4 revolution (90°) further.
  7. Remove screws -1- and -2-. see scheme 26
  8. Remove left-side trim for center console -3-. To remove, slide trim forward and unhook from back.
  9. Remove screws -2- and -3-. see scheme 27 The front screws -2- can be reached by turning back floor covering.
  10. Remove right-side trim for center console -1-. To remove, slide trim forward and unhook from back.
  11. Place auxiliary tool -C- in holes of instrument cluster outlets -D-.
  12. Remove instrument cluster outlet out center part evenly. NOTE: Do not hook auxiliary tool -C- into fins of instrument cluster outlet (the fins could break off).
  13. Remove 5 bolts (arrows).
  14. Pull instrument cluster, center part -1- out slightly.
  15. Pull off wires and separate connectors.
  16. Remove instrument cluster, center.
  17. Remove control module for operating electronics, navigation -J401-. For removal and installation, see «NAVIGATION CONTROL MODULE WITH CD DRIVE -J401-, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/communication-devices/#radio-telephone-navigation-trip-computer__navigation-control-module-with-cd-drive) or «NAVIGATION SYSTEM IV (BNS 4.0) FROM 01.01»(/audi/a8/d2-1994-1999/remont/communication-devices/#radio-telephone-navigation-trip-computer).

Center armrest, removing and installing

Note. The following list refers to see scheme 30.

  1. Pop rivet 2 parts
  2. Bolt 4 Nm (35 in.lb.) 2 parts
  3. Center console
  4. Center armrest, left To remove, unclip cover -7- and remove screw -8
  5. Spring bracket
  6. Center armrest, right Version for vehicles without telephone installation To remove, unclip cover -7- and remove screw -8- Version for vehicles with telephone installation. See «CENTER CONSOLE AND CENTER ARMREST WITH TELEPHONE, INSTALLATION»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-and-center-armrest-with) .
  7. Cover On spring bracket -5- clipping
  8. Hex socket bolt 22 Nm (16 ft.lb.)
  9. Washer
  10. Bracket for center armrest. To remove, remove bolt -8- and using plastic hammer hit from side onto bracket.
  11. Grommet
  12. Support panel
  13. Mounting For center armrest support
  14. Nut 2 parts 22 Nm (16 ft.lb.)

Center console and center armrest with telephone, installation

Note. The following list refers to see scheme 31.

  1. Mounting plate, short For installation in storage shelf center console
  2. Mounting plate, long For installation in the storage shelf center console
  3. Receiver mounting Only for LU-telephone from AEG
  4. Phillips-head screw 0.8 Nm (7 in.lb.) 2 parts
  5. Phillips-head screw 1.1 Nm (9 in.lb.)
  6. Phillips-head screw 0.8 Nm (7 in.lb.) 2 parts
  7. Telephone
  8. Close-out panel With cable routing
  9. Trim for center console
  10. Grommet
  11. Bracket for center armrest
  12. Spring bracket
  13. Hex socket bolt 22 Nm (16 ft.lb.)
  14. Cover On spring bracket -12
  15. Center armrest 2 parts

Center armrest, retrofitting

Note. The following list refers to see scheme 32.

  1. Remove center console. See «CENTER CONSOLE, OVERVIEW»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-overview) .
  2. Remove trim for center console. See item 10 in «ASHTRAY, STORAGE POCKET, TRIM FOR SHIFT MECHANISM AND CENTER CONSOLE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__ashtray-storage-pocket-trim-for-shift) .
  3. Create cutouts and holes in center console, as shown in the illustration.
  4. Install support panel and mounting for bracket center console. See item 12 in «CENTER ARMREST, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-removing-and-installing) .
  5. Install center armrest. See «CENTER ARMREST, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-removing-and-installing) .

Center armrest, modifications for retrofit

Note. The following list refers to see scheme 32.

  1. Cutout for retrofit center armrest Position cutouts per following dimensions: -a- = 245 mm -b- = 25 mm -c- = 83 mm
  2. Slots for parcel shelf trim assembly Position slots per the following dimensions: -d- = 6 mm -e- = 30 mm -f- = 14 mm -g- = 4 mm -h- = 6 mm
  3. Close-out panel For center armrest without telephone installation
  4. Close-out panel For telephone installation with cable routing
  5. Center console
  6. Parcel shelf

Ashtray, storage pocket, trim for shift mechanism and center console, removing and installing

Note. The following list refers to see scheme 33.

  1. Center console Removing and installing. See «CENTER CONSOLE, OVERVIEW»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-overview) .
  2. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts
  3. Hex socket bolt 2.5 Nm (22 in.lb.) 2 parts
  4. Trim for ashtray To remove close ashtray, remove trim from behind
  5. Ashtray To remove take out center console, see «CENTER CONSOLE, OVERVIEW»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-overview) .
  6. Trim for gearshift mechanism Version for vehicles with automatic transmission Removing Remove trim for center console left and right. Remove two screws -2-. Version for vehicles with manual transmission, see «TRIM FOR GEARSHIFT MECHANISM FOR VEHICLES WITH MANUAL TRANSMISSION»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__trim-for-gearshift-mechanism-for-vehicles) .
  7. Trim for parcel shelf To remove parcel shelf -9- remove and press off trim from hinge side
  8. Phillips-head screw 1.5 Nm (13 in.lb.) 3 parts
  9. Parcel shelf With lid To remove center console, remove trim -10- and trim for gearshift mechanism -6
  10. Trim for center console To remove, take out center console and remove nuts -13
  11. Close out panel To remove, remove center console and trim -10
  12. Carpet
  13. Nut 0.5 Nm (4 in.lb.) 6 parts

Trim for gearshift mechanism for vehicles with manual transmission

  1. Cover frame
  2. Threaded bushing
  3. Sleeve
  4. Threaded bushing
  5. Shift knob NOTE: Cover frame -1- can not be removed without being damaged. If possible, remove boot together with trim for shift mechanism. See item 6 in «ASHTRAY, STORAGE POCKET, TRIM FOR SHIFT MECHANISM AND CENTER CONSOLE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__ashtray-storage-pocket-trim-for-shift) .

Note. The following list refers to see scheme 35.

  1. Armrest Remove cover in center console. See «REMOVING CENTER CONSOLE COVER»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__removing-center-console-cover) . Disconnect harness connector for lighting. See «DISCONNECTING CONNECTOR FOR LIGHTING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__disconnecting-connector-for-lighting) . Remove vent console. See «REMOVING VENT CONSOLE»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__removing-vent-console) . For vehicles with telephone installation, disconnect harness connector. See «DISCONNECTING CONNECTOR FOR TELEPHONE»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__disconnecting-connector-for-telephone) . Pull telephone cable under air shaft through toward front. Remove cover -6-. See «SUPPORT FOOT COVER, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__support-foot-cover-removing-and-installing) . Remove bolt 7- (1x). Remove center armrest -1- with support foot.
  2. Support foot
  3. Grommet
  4. Mount For bracket for center armrest
  5. Center console
  6. Cover Removing. See «SUPPORT FOOT COVER, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__support-foot-cover-removing-and-installing) .
  7. Socket-head bolt, 22 Nm

Disconnecting connector for telephone

  1. Press buttons (arrows) and disconnect connector for telephone -1-.

Removing vent console

  1. Remove trim plate -2-.
  2. Remove bolts -3-.
  3. Remove vent console -1-.
  4. Disconnect harness connector.

Removing center console cover

  1. Pry off cover -1- at cut-out -2-.

Disconnecting connector for lighting

  1. Pull cable out of cut-out.
  2. Disconnect harness connector -1-. For vehicles without telephone, there are two harness connectors -1-.

Support foot cover, removing and installing

  1. Bring armrest -1- into 75° lock position (arrow -A-). see scheme 40
  2. Pull up (arrow -B-) cover -3- first.
  3. Remove cover -3- from support foot -2- toward front (arrow -C-).

Center armrest trim plate, removing and installing

  1. Using flathead screwdriver against pin -2- (6x left and right) lift out inner and outer trim plate beginning at rear.
  2. Remove trim plate -1-.

Center armrest storage compartment, removing and installing

  1. Remove Inner And Outer Trim Plates. See «CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-trim-plate-removing-and) .
  2. Remove bolts -1-.

Storage compartment without lift

  1. Remove stowage compartment -2- in upward direction. see scheme 43
  2. Remove adhesive tape -3-.
  3. Remove lighting -1- from storage compartment.
  1. With cellular phone, remove grommets -1-. see scheme 44
  2. Remove cable -3-. See «CENTER ARMREST CABLE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-cable-removing-and-installing).
  3. For telephone, disconnect connector -2-.

Install in reverse order of removal

Note. After installing storage compartment, pull cable -2- and/or -3- tight. see scheme 44

Storage compartment with Cullmann lift

Note. The following list refers to see scheme 45.

  1. Telephone cable Disconnect telephone cable -1- from socket -3- in storage compartment -2-. Unclip telephone cable -1- from clip -6- on support bracket -4-. Push telephone cable -1- along at support bracket -4- and carefully remove storage compartment -2- in forward direction. Slide telephone connector cable -3- downward out of mounting -5- from storage compartment -2-. Remove storage compartment -2- complete with lift.
  2. Storage compartment
  3. Connector for telephone cable
  4. Support bracket
  5. Mounting on storage compartment
  6. Clip NOTE: After installing telephone cable -1-, pull it tight at support bracket -4-.

Center armrest cable, removing and installing

  1. Remove center armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) .
  2. Remove storage compartment at left and right. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) .
  3. Unclip cable from clip -1-.
  4. Remove center armrest at left and right «CENTER ARMREST WITH CLIP, SEPARATING AT LEFT AND RIGHT»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-with-clip-separating-at) .
  5. Route cable through center armrest.
  1. 2-Cable for left center armrest
  2. 3-Cable for right center armrest
  3. 4-Support foot

Center armrest telephone cable routing, installation

Note. The following list refers to see scheme 47.

  1. Connector First connect connector. Then engage clip.
  2. Cable
  3. Clip Clip telephone cable into clip at 10th coil (+/- 2 coils)

Center armrest lift, removing and installing

  1. Installing: Remove left/righthand trim pieces from center armrest. See «CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-trim-plate-removing-and) . Remove storage compartment. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) .

Note. The following list refers to see scheme 48.

  1. Storage compartment
  2. Arm for lift 4x Remove storage compartment. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) . Press pins -3- through and counter hold arm for lift -2-.
  3. Pin 2x
  4. Lift release
  5. Spring

Center armrest with Cullmann-Lift, removing and installing

  1. Removing
  1. Remove left- and right-side trim pieces from center armrest. See «CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-trim-plate-removing-and) .
  2. Remove storage compartment. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) .

Scheme 2

Scheme 2
Scheme 2
  1. Metal rail Pull metal rail -1- up and remove to side. Pull spring mounting -2- off in downward direction. Remove screws -3- (6x).
  2. Spring mounting
  3. Screws (6x) Installing

Install in reverse order of removal

Note. The spring mounting must be installed on the opposite side from the support bracket.

Center armrest with clip, separating at left and right

Note. Removal procedure for armrest is the same for left and right sides.

Note. The following list refers to see scheme 51.

  1. Center armrest, left
  2. Center armrest, right Remove armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) . Remove storage compartment at left and/or right. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) . Fold left -1- and right -2- center armrest upward. Remove clip -5-. Unclip cable -4-. Refit center armrests to allow for the subsequent operations. Fold armrest to be removed up to 75° latched position. Remove center armrest from support foot -3-.
  3. Support foot
  4. Clip
  5. Clip 2x

Center armrests with bracket and screw, separating at left and right

Note. Removal procedure for armrest is the same for left and right sides.

Note. The following list refers to see scheme 52.

  1. Center armrest, left
  2. Center armrest, right Remove center armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) . Remove storage compartment at left and/or right. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) . Fold left -1- and right -2- center armrest down. Remove screw -5-. Pull -6- out in forward direction. Refit center armrests to allow for the subsequent operations. Fold armrest to be removed up to 75° latched position. Remove center armrest from support foot -3-.
  3. Support foot
  4. Clip
  5. Screw 2x Tightening torque 10.5 Nm
  6. Bracket 2x

Center armrests with screw, separating at left and right

Note. Removal procedure for armrest is the same for left and right sides.

Note. The following list refers to see scheme 53.

  1. Center armrest, left
  2. Center armrest, right Remove center armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) . Remove storage compartment at left and/or right. See «CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-storage-compartment-removing-and) . Fold left -1- and right -2- center armrest down. Remove screw -5-. Refit center armrests to allow for the subsequent operations. Fold armrest to be removed up to 75° latched position. Pull cable out of clip - 4-. Remove center armrest from support foot -3-.
  3. Support foot
  4. Clip
  5. Screw 2x Tightening torque 10.5 Nm

Note. The following list refers to see scheme 54.

  1. Rear center console Remove center console. See «CENTER CONSOLE, OVERVIEW»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-overview) . Install support metal and mount for support foot of center console. Replace covers -5- and -4-. Install center console. See «CENTER CONSOLE, OVERVIEW»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-console-overview) . Install center armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment) .
  2. Cover
  3. Cover with center armrest cut-out
  4. Cover without center armrest cut-out
  5. Cover
  6. Nut, 22 Nm 2x
  7. Mount For support foot of center armrest
  8. Support metal
  9. Pop rivet 2x
  10. Bolt, 4 Nm 2x

Center armrest cover, removing and installing

  1. Starting at bottom, carefully unclip cover -1- in direction of (arrow -A-). see scheme 55
  2. Remove cover -1- in direction of (arrow -B-). NOTE: When installing, ensure that lid is fully engaged so center armrest cover can be properly mounted.
  3. Press cover -1- downward. see scheme 56
  4. Remove cover -1-.

Fitting and removing outer covering of center armrest cover

  1. Removing

Note. When removing arm rest covering, begin at the rear. Remove center armrest cover. See CENTER ARMREST COVER, REMOVING AND INSTALLING . Using flat head screwdriver, remove armrest release/catch device -1- out sideways. Completely remove plastic strip -2-. Unhook clamping strip -3-.

Install in reverse order of removal.

Note. After installing the outer covering, carefully smooth away the folds in the leather using a heat gun.

Lower section of center armrest outer covering, removing and installing

  1. Removing Remove center armrest. See «CENTER ARMREST (FROM 10.98 ON)»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment). Remove left and right side trim pieces of center armrest. See «CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-trim-plate-removing-and). Remove storage compartment. See «CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#interior-equipment__center-armrest-trim-plate-removing-and). NOTE: When removing arm rest covering, begin at the rear. Remove clips -1- (10x) on left and right. see scheme 57 Remove guide -3- for support foot. Remove outer covering -2- from front to rear.

Note. The following list refers to see scheme 57.

  1. Clips (10x)
  2. Outer covering
  3. Support foot guide Installing: NOTE: After fitting the outer covering to the bottom section, carefully smooth away the folds in the leather with a heat gun.
  1. When removing, rotate mirror -1- 60 to 90 ° -arrows B-, until retaining spring releases and remove mirror -arrow A-.
  1. When installing mirror -1-, rotate mirror 60-90°, install onto installation point (arrow -A-) and turn in direction of arrows -B- until locking springs engage.
  1. Unclip cable channel cover -3-. see scheme 60
  2. Remove connector from retainer and disconnect. NOTE: Do not use cable channel -2- to turn mirror.
  3. When removing, rotate mirror -1- 60 to 90 ° -arrows B-, until retaining spring releases and remove mirror - arrow A-.

Note. Cable tunnel -2- should not be used for turning. see scheme 61

  1. When installing mirror -1-, rotate mirror 60-90°, install onto installation point (arrow -A-) and turn in direction of arrows -B- until locking springs engage.

Rearview mirror (roof mounted), removing and installing

Note. The following list refers to see scheme 62.

  1. Rearview mirror Removing Unclip molded headliner cover -7- at front. Disconnect harness connector -4- to rearview mirror. Using a screwdriver on the left side, pry out rearview mirror between base plate -5- and mirror base -3-. Installing: Check whether locking pin -8- is locked before installing. Insert right side of mirror base -3-. Clip in mirror base cover -2- on right side. Press up mirror base cover -2- on left side along with mirror base -3- until locking pin -8- engages.
  2. Mirror base cover
  3. Mirror base
  4. Cable
  5. Ground plate
  6. Molded headliner
  7. Molded headliner cover
  8. Locking pin

Test requirements

  1. Interior rearview mirror installed
  2. Ignition switched on
  3. Reverse gear not engaged

Test procedure

  1. Hold photosensor closed on front side (or tape).
  2. Radiate photosensor on back side using light source (flash light).
  1. The interior rearview mirror must dim within a short time.
  1. Glass-metal-adhesive-set D 000 703 A1
  1. Glass scraper (commercial)
  2. Blade (commercial)

Work procedure

  1. Remove mirror plate from mirror base.
  2. Remove PUR-adhesive material with wire brush from mirror plate.
  3. Grind off spacer knobs from adhesive surface. Sand paper (360/400 grade) on flat surface.
  4. Keep ground surface dirt and grease free.
  5. Scrape PUR-adhesive material and primer up to ceramic layer with glass scraper off of windshield.
  6. Clean adhesive surface with adhesive remover D 002 000 10 or cleaning solution D 009 401 04. CAUTION: Ceramic layer should not be damaged. Scratches are always visible.
  7. Cut nylon mesh weave to exact size of mirror base. NOTE: Hands should be protected (rubber gloves).
  8. Apply adhesive evenly on mirror base.
  9. Place nylon mesh weave on mirror base.
  10. Using tube, dab adhesive on nylon mesh adhesive. From the positioning of the nylon mesh weave onto adhesive until it is pressed on to windshield there are only 30 seconds available.
  11. Press mirror base securely for 15 seconds (not with force) to windshield.
  12. Remove excess adhesive using cloth. NOTE: After 15 minutes the rearview mirror can be installed. CAUTION: Work with adhesive material at room temperature and note safety and use specifications. The complete hardening of material occurs after several hours.
  13. Measurement for interior rearview mirror -a- = 140 mm (upper edge front glass up to center of adhesive plate mirror base).

See also:
• INSTRUMENT CLUSTER, REMOVING AND INSTALLING
• ANTILOCK BRAKE SYSTEM
• FLOOR PAD FRONT, REMOVING AND INSTALLING
• NAVIGATION CONTROL MODULE WITH CD DRIVE -J401-, REMOVING AND INSTALLING
• NAVIGATION SYSTEM IV (BNS 4.0) FROM 01.01
• LOCK CYLINDER AND PUSH BUTTON FOR GLOVE BOX, REMOVING AND INSTALLING
• GLOVE BOX AND BRACKET FOR GLOVE BOX, REMOVING AND INSTALLING
• REMOVING AND INSTALLING AIR VENT FOR SIDE OUTLET, REAR
• INSTRUMENT PANEL (CENTER), ASSEMBLY
• CENTER CONSOLE, REMOVING AND INSTALLING
• CENTER CONSOLE AND CENTER ARMREST WITH TELEPHONE, INSTALLATION
• INSTRUMENT PANEL (CENTER), REMOVING AND INSTALLING
• CENTER CONSOLE, OVERVIEW
• ASHTRAY, STORAGE POCKET, TRIM FOR SHIFT MECHANISM AND CENTER CONSOLE, REMOVING AND INSTALLING
• CENTER ARMREST, REMOVING AND INSTALLING
• TRIM FOR GEARSHIFT MECHANISM FOR VEHICLES WITH MANUAL TRANSMISSION
• REMOVING CENTER CONSOLE COVER
• DISCONNECTING CONNECTOR FOR LIGHTING
• REMOVING VENT CONSOLE
• DISCONNECTING CONNECTOR FOR TELEPHONE
• SUPPORT FOOT COVER, REMOVING AND INSTALLING
• CENTER ARMREST TRIM PLATE, REMOVING AND INSTALLING
• CENTER ARMREST CABLE, REMOVING AND INSTALLING
• CENTER ARMREST STORAGE COMPARTMENT, REMOVING AND INSTALLING
• CENTER ARMREST WITH CLIP, SEPARATING AT LEFT AND RIGHT
• CENTER ARMREST COVER, REMOVING AND INSTALLING

More articles — Accessories & Equipment
