Side marker light bulb, replacing Audi A6 C6 рестайлинг

Side marker light bulb, replacing

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 192

1. Pull lamp socket - 1 - off from housing for side marker lamp.
2. Remove bulb from socket.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb (12V, 5W - orange) into housing, do not touch glass cone with bare hands when doing so.
2. When inserting, make sure markings - 2 - and - 3 - are horizontal.

Scheme 193

Removing

1. Release clip using a screwdriver - arrow A - and remove air inlet grille - 1 - at lower part of bumper cover - arrows B -.
2. Remove front bumper cover --> «63 - BUMPERS»(ref-281388-S27402204812008031100000) .

Scheme 194

1. Remove bolts - 1 - and - 2 -.
2. Release clip - 3 - and remove daytime running lamp - 4 - toward front out of bumper cover - arrow -.

Installing

Installation is performed in reverse order of removal, noting the following

Note. If LEDs are malfunctioning, daytime running lamp must be completely replaced. Install front bumper cover --> 63 - BUMPERS .

Tightening torque
