Engine Coolant Temperature (ECT) Sensor G62 Connector assignment Audi A6 C6 рестайлинг

Electrical Equipment 2 illustrations

Engine Coolant Temperature (ECT) Sensor G62 Connector assignment

Special tools, testers and auxiliary items required

Scheme 107

Scheme 107: Engine Coolant Temperature (ECT) Sensor G62 Connector assignment
Scheme 107: Engine Coolant Temperature (ECT) Sensor G62 Connector assignment
  1. Assembly tool T10118

Preparation

  1. Disconnect electrical harness connector at Engine Coolant Temperature (ECT) Sensor G62 ; procedure
  1. Vehicles with 3.2l FSI engines.
  2. Vehicles with 4.2l MPI engine.
  3. Vehicles with 4.2l FSI engine.
  4. Vehicles with 5.2l FSI engine.

Scheme 108

Scheme 108
Scheme 108

Terminal assignment of the 2-pin harness connector at Engine Coolant Temperature (ECT) Sensor G62

  1. Sensor ground (GND)
  2. Wire connection from Engine Coolant Temperature (ECT) Sensor G62 to engine control module
