Specifications & Procedures: Specifications Audi A6 C5 facelift

Wheel Alignment 4 illustrations

WHEEL ALIGNMENT SPECIFICATIONS

ApplicationPreferred (1)Range (1)
Camber (2)
Standard Suspension (1BA, 1BH, 1BP & 1BC)50'25' To -75'
Sport Suspension (1BE)1° 05'40' To -1° 30'
Rough Terrain Suspension (1BB)35'10' To -1°
Rough Terrain Suspension (1BT)45'20' To -1° 10'
Level Control System (1BG)50'25' To -1° 15'
Toe Per Wheel (Adjustment Value In Start Position)
All Suspension Variations10'8' To 12'
Toe Per Wheel (Control Value In Start Position)
All Suspension Variations10'5' To 15'
Toe Constant Per Wheel (Setting)
All Suspension Variations7'5' To 9'
Toe Constant Per Wheel (Control Value)
All Suspension Variations7'0' To 14'
Toe-out On Turns At 20° (3)
All Suspension Variations1° 30'1° To 2°
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides is 30'. (3) The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides is 30'.
(3)The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.

FRONT AXLE WHEEL ALIGNMENT SPECIFICATIONS (ALL ENGINES - FWD ONLY)

Scheme 1

Scheme 1
ApplicationPreferred (1)Range (1)
Camber (2)
All Suspension Variations1° 30'1° 10' To -1° 50'
Overall Toe (3)
Standard Suspension (1BA, 1BH, 1BP & 1BC)20'10' To 35'
Sport Suspension (1BE)28'18' To 43'
Rough Terrain Suspension (1BB)14'4' To 29'
Rough Terrain Suspension (1BT)17'7' To 32'
Level Control System (1BG)26'16' To 41'
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides is 30'. (3) Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 15'.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides is 30'.
(3)Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 15'.

REAR AXLE WHEEL ALIGNMENT SPECIFICATIONS (ALL ENGINES - FWD ONLY)

ApplicationPreferred (1)Range (1)
Camber (2)
Standard Suspension (1BA, 1BH, 1BP & 1BC)50'25' To -75'
Sport Suspension (1BE)1° 05'40' To -1° 30'
Rough Terrain Suspension (1BB)35'10' To -1°
Rough Terrain Suspension (1BR)40'15' To -1° 5'
Rough Terrain Suspension (1BT & 1BJ)45'20' To -1° 10'
Level Control System (1BG)50'25' To -1° 15'
Toe Per Wheel (Adjustment Value In Start Position)
All Suspension Variations10'8' To 12'
Toe Per Wheel (Control Value In Start Position)
All Suspension Variations10'5' To 15'
Toe Constant Per Wheel (Setting)
All Suspension Variations7'5' To 9'
Toe Constant Per Wheel (Control Value)
All Suspension Variations7'0' To 14'
Toe-out On Turns At 20° (3)
All Suspension Variations1° 30'1° To 2°
(1) All measurements are given in degrees. (2) Maximum difference between sides 30'. (3) The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.
(1)All measurements are given in degrees.
(2)Maximum difference between sides 30'.
(3)The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.

FRONT AXLE WHEEL ALIGNMENT SPECIFICATIONS (AWD VEHICLES - V6 ENGINES)

ApplicationPreferred (1)Range (1)
Camber (2)
Suspension Variation (All Except 1BG)40'10' To -1° 10'
Suspension Variation (1BG Level Control System)1° 10'40' To -1° 40'
Toe Per Wheel (3)
All Suspension Variations8'3' To 13'
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides is 30'. (3) Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 10'.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides is 30'.
(3)Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 10'.

REAR AXLE WHEEL ALIGNMENT SPECIFICATIONS (AWD VEHICLES - V6 ENGINES)

Scheme 2

Scheme 2
ApplicationPreferred (1)Range (1)
Camber (2)
Standard Suspension (1BA & 1BH)1° 25' To -35'
Sport Suspension (1BD & 1BE)1° 05'40' To -1° 30'
Sport Suspension (1BV, 2ME & 2MC)1° 20'55' To -1° 45'
Rough Terrain Suspension (1BR)50'25' To -1° 15'
Level Control System (1BG)35' To -1° 25'
Toe Per Wheel (Adjustment Value In Start Position)
All Suspension Variations10'8' To 12'
Toe Per Wheel (Control Value In Start Position)
All Suspension Variations10'5' To 15'
Toe Constant Per Wheel (Setting)
All Suspension Variations7'5' To 9'
Toe Constant Per Wheel (Control Value)
All Suspension Variations7'0' To 14'
Toe-out On Turns At 20° (3)
All Suspension Variations1° 30'1° To 2°
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides is 30'. (3) The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides is 30'.
(3)The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.

FRONT AXLE WHEEL ALIGNMENT SPECIFICATIONS (AWD VECHICLES - 4.2L V8)

ApplicationPreferred (1)Range (1)
Camber (2)
All Except 1BG Suspensio30' To -1° 30'
1BG Level Control Suspension1° 10'40' To -1° 40'
Toe Per wheel (3)
All Suspension Variations8'3' To 13'
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides 30'. (3) Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) Is +/- 10'.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides 30'.
(3)Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) Is +/- 10'.

REAR AXLE WHEEL ALIGNMENT SPECIFICATIONS (AWD VECHICLES - 4.2L V8)

Scheme 3

Scheme 3
ApplicationPreferred (1)Range (1)
Front Axle
Camber (2)35' To -1° 25'
Toe Per Wheel (Adjustment Value In Start Position)10'8' To 12'
Toe Per Wheel (Control Value In Start Position)10'5' To 15'
Toe Constant Per Wheel (Setting)7'5' To 9'
Toe Constant Per Wheel (Control Value)7'0' To 14'
Toe-out On Turns At 20° (3)1° 25'55' To 1° 55'
Rear Axle
Camber (2)30' To -1° 30'
Toe Per Wheel (4)9'5' To 13'
(1) All measurements are given in degrees (°) and minutes ('). (2) Maximum difference between sides is 30'. (3) The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading. (4) Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 10'.
(1)All measurements are given in degrees (°) and minutes (').
(2)Maximum difference between sides is 30'.
(3)The angle of the outside wheel is less by this amount. Depending on alignment computer being used, this measurement may be indicated as a negative reading.
(4)Maximum permanent deviation from direction of travel in relation to longitudinal axis of vehicle (thrust angle) is +/- 10'.

WHEEL ALIGNMENT SPECIFICATIONS (ALLROAD- 1BY SUSPENSION)

Scheme 4

Scheme 4
