Test conditions for operations with engine running
- No DTCs stored in DTC memory
- Coolant temperature at least 80° C.
- Electrical accessories switched off (coolant fan must not run during the test).
- Air conditioning switched off.
- Vehicles with automatic transmission: Selector lever in position P or N.
Vehicles with control module No. 8E0 909... , go to TEST SEQUENCE .
Operation 4: Adaptation of the kick down function
Note. Only on vehicles with automatic transmission.
Operation 5: Checking operating status of oxygen sensor (O2S) control
- Start engine (for vehicles with manual transmission: press clutch pedal).
Note. If necessary, after the engine starts reselect vehicle system "01 - Engine electronics" and diagnostic function "04 - Basic setting".
Operation 6: Diagnosis of heated oxygen sensor (HO2S) aging before catalytic converter
Display on VAS5051
Scheme 189
- Enter display group
max. input value = 255
- Enter "197" for "display group number 197" in zone -2- and confirm entry by pressing -Q- button.
Display on VAS5051
Scheme 190
- Activate basic setting by pressing -A- button.
- Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2200 RPM.
Test conditions
- Accelerator and brake pedal pressed simultaneously, engine runs at approx. 2200 RPM.
- Check indication in display fields -2- and -4-.
| Display zones | ||||
|---|---|---|---|---|
| 1 | 2 | 3 | 4 | |
| Display group 197: Diagnostic of oxygen sensor aging (Bank 1, Sensor 1 - Bank 2, Sensor 1) | ||||
| Display | X.x | X.x | ||
| Display | Dynamic factor Bank 1, Sensor 1 | Diagnosis status | Dynamic factor Bank 2, Sensor 1 | Diagnosis status |
| Range | Test OFF Test ON B1-S1 OK B1-S1 NOK | Test OFF Test ON B2-S1 OK B2-S1 NOK | ||
| Specif. value | B1-S1 OK | B2-S1 OK | ||
| Note | If "B1-S1 NOK" is displayed: Check DTC memory Diagnostic Trouble Code (DTC) memory, checking and erasing . | If "B2-S1 NOK" is displayed: Check DTC memory Diagnostic Trouble Code (DTC) memory, checking and erasing . | ||
DISPLAY GROUP 197: DIAGNOSTIC OF OXYGEN SENSOR AGING (BANK 1, SENSOR 1 - BANK 2, SENSOR 1)
If specified values "B1-S1 OK" and "B2-S1 OK" are obtained
- Press --> button.
Operation 7: Diagnosis of heated oxygen sensor (HO2S) condition behind catalytic converter
Display on VAS5051
Scheme 191
- Enter display group
- Enter "193" for "display group number 193" in zone -2- and confirm entry by pressing -Q- button.
Display on VAS5051
Scheme 192
- Activate basic setting by pressing -A- button.
- Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2200 RPM.
Operation 10: Diagnosis of heated oxygen sensor (HO2S) aging behind catalytic converter
Display on VAS5051
- Enter display group
- Enter "194" for "display group number 194" in zone -2- and confirm entry by pressing -Q- button.
Display on VAS5051
Scheme 193
- Activate basic setting by pressing -A- button.
- Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2200 RPM.
Operation 13: Read readiness code
- Read readiness code. See «READINESS CODE, READING»(ref-216419-S12295127722006012100000) .
