Seats Frames: Overview Audi A6 C5 facelift

Seats 1 illustration

Seat height adjustment motor versions, overview

  1. Install motor for seat height adjustment after checking seat frame. See «MOUNT FOR SEAT HEIGHT ADJUSTMENT MOTOR AT SEAT FRAME, CHECKING»(ref-196287-S05183271522005100800000) .

Note. The following list refers to see scheme 35.

  1. Old height adjustment motor Characteristic: Wire with connector -6- Gear -5- with 6.2 mm shaft (measurement -B-).
  2. New height adjustment motor Characteristic: Integrated connector -3- Gear -4- with 9.8 mm shaft (measurement -A-).
  3. Integrated connector
  4. Gear
  5. Gear
  6. Connector

Scheme 1

Scheme 1
Scheme 1
