Code Control Module (function 07) Audi A6 C5 facelift

On Board Diagnostic (OBD) - 2001 and Up 6 illustrations ~219 words

Code Control Module (function 07)

Note. The various combination possibilities of the driver information system are adjusted via the coding according to equipment, country version, cylinder count and engine version. The code table lists only those combinations applicable to the Audi A6.

Scheme 86

Scheme 86: Clarification of coding
Scheme 86: Clarification of coding
CodingExplanation
02266Seat belt warning active, country version USA, 6-cylinder, gasoline engine

INSTRUMENT CLUSTER CODE EXAMPLE

  1. Initiate output Diagnostic Test Mode of instrument cluster. See «INSTRUMENT CLUSTER ON BOARD DIAGNOSTIC (OBD), INITIATING»(ref-196304-S19740740292005100900000) .

Display on VAS 5051

Scheme 87

Scheme 87
Scheme 87
  1. Select diagnostic function "07 - Code Control Module" in selection -1-.

Display on VAS 5051

Scheme 88

Scheme 88
Scheme 88
  1. Enter code word Max. input value = 32767
  1. Enter 5-digit coding in button field -2- according to coding table. See «CODING VERSION FOR ADDITIONAL EQUIPMENT»(ref-196304-S03942990102005100900000) . If necessary, insert zeros in front.

Example

Desired input value: 2266

Keypad input: 02266

  1. Press -Q- button to confirm input.

Display on VAS 5051

Scheme 89

Scheme 89
Scheme 89
  1. Coding will be performed
  1. Wait until the next indication appears on display.

Display on VAS 5051

Scheme 90

Scheme 90
Scheme 90
  1. Coding in vehicle system performed
  2. Control module identification with new coding (previous coding in parentheses)
  1. End function "07 - Erase DTC Memory" by pressing <-- button.

Scheme 91

Scheme 91: Coding table
Scheme 91: Coding table

Note. In the previous graphic refer to: Coding version for additional equipment for coding versions ADAPTATION CHANNEL 62-ADAPTATION FOR INFORMATION DATA-BUS for selecting adaptation channel 62 in note
