Notes on exchanging instrument cluster

1. Do not disassemble instrument cluster.
2. When the replacement of a malfunctioning instrument cluster is necessary, follow exchange part procedures.
3. Complete report form and return together with inst. cluster.
4. Use the original packaging from the new cluster when returning modules.
5. The instrument cluster must be coded according to market and equipment versions See «CODE CONTROL MODULE (FUNCTION 07)»(ref-196304-S26400744462005100900000) .
6. The odometer reading must be adapted to the new/exchange instrument cluster using the VAS 5051 tester See «VAS 5051 TESTER, CONNECTING»(ref-196304-S07611429162005100900000) .
7. Anti-theft immobilizer functions supported by the instrument cluster must be adapted to the Engine Control Module (ECM) using the VAS 5051 tester See «ADAPTATION AFTER REPLACING INSTRUMENT CLUSTER»(ref-196304-S18551168802005100900000) .

Additional information

1. Instrument cluster, On Board Diagnostic (OBD) See «INSTRUMENT CLUSTER, ON BOARD DIAGNOSTIC (OBD)»(ref-196304-S23234779942005100900000) .
2. Navigation system functions, On Board Diagnostic (OBD) See «NAVIGATION SYSTEM III (NS-LOW) THROUGH M.Y. 2001, ON BOARD DIAGNOSTIC (OBD)»(ref-196291-S27481228882005100800000) . See «NAVIGATION SYSTEM III (NS-LOW) THROUGH M.Y. 2001»(ref-196292-S26609504442005100800000) .
3. Complaint/symptom based repairs ("Service Fixes)" Check for Technical Bulletins.

Malfunction message "dEF" on trip odometer display

If the control module in the instrument cluster detects a malfunction in its permanent memory, the letters "dEF" will appear on the trip odometer display.

1. If "dEF" is indicated on display, replace instrument cluster. See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(ref-196300-S29162299302005100900000) .

Instrument cluster, removing and installing

Removing

Note. It is not necessary to remove the steering wheel to remove the instrument cluster.

If replacing a malfunctioning instrument cluster with a new one, note odometer reading on existing cluster prior to removal.

1. Determine input values for replacing instrument cluster (i.e.: SRI values etc. where applicable): See «INPUT VALUES FOR REPLACING INSTRUMENT CLUSTER»(ref-196304-S09471942522005100900000) .
2. Adjust steering wheel completely out and downward.
3. Press cover -1- upward at side and then remove cover from instrument panel.
4. Remove Phillips head screws -1-.
5. Pull out instrument cluster toward front.
6. Cut cable ties at rear of instrument cluster.
7. Unclip securing latches of connectors and disconnect connectors.

Installing

Installation is reverse of removal, noting the following

1. Connect electrical harness connectors and affix wiring harness to rear of instrument cluster with cable ties.
2. After installation, perform a function test of the instrument cluster.
3. If the function test is OK, enter the input values for the instrument cluster (i.e.: SRI etc. where applicable): See «INPUT VALUES FOR REPLACING INSTRUMENT CLUSTER»(ref-196304-S09471942522005100900000) .
4. Code instrument cluster according to market and equipment versions using the VAS 5051 tester See «VAS 5051 TESTER, CONNECTING»(ref-196304-S07611429162005100900000) .
5. Adapt odometer reading to new/exchange instrument cluster using the VAS 5051 tester See «VAS 5051 TESTER, CONNECTING»(ref-196304-S07611429162005100900000) .
6. Adapt anti-theft immobilizer functions supported by the instrument cluster to Engine Control Module (ECM) using the VAS 5051 tester See «ADAPTATION AFTER REPLACING INSTRUMENT CLUSTER»(ref-196304-S18551168802005100900000) .

Multi-pin connectors at instrument cluster

Note. All control lamps in instrument cluster are equipped with LEDs. Instrument cluster must be replaced when one control lamp fails.

1. Green 32-pin multi-pin connector
2. Blue 32-pin multi-pin connector
3. Gray 32-pin multi-pin connector
4. Black 4-pin multi-pin connector for remote clock (not connected in US)

Blue 32-pin multi-pin connector

Note. The following list refers to (Scheme 7) and see scheme 5.

1. Terminal 15
2. Brake pad wear
3. Speedometer output 1
4. Not assigned
5. Tank sensor
6. Tank warning OBD 2
7. Terminal 31 (sensor Ground (GND))
8. Coolant temperature
9. Terminal 31 (load Ground (GND))
10. Oil pressure 2 (high)
11. RPM signal
12. A/C shut-off
13. E-Gas/glow plug control
14. Level control
15. Terminal 58d
16. Trailer turn signal
17. High beam
18. Left turn signal
19. Not assigned
20. Terminal 58s
21. Driver door contact
22. Lack of coolant
23. Terminal 30
24. Terminal 31 (load Ground (GND))
25. Consumption signal
26. Right parking light
27. Left parking light
28. Tachometer input
29. Brake
30. S-contact
31. Speedometer output 2
32. ESP/ASR

Green 32-pin multi-pin connector

Note. The following list refers to see scheme 6 and see scheme 7.

1. Not assigned
2. Transponder
3. Not assigned
4. Not assigned
5. W-wire
6. Not assigned
7. Right turn signal
8. External buzzer
9. External gong
10. Airbag
11. Stand-still time output
12. Terminal 61
13. Parking brake/BRAKE
14. CHECK
15. Oil level/oil temperature
16. Not assigned
17. Transponder 2
18. CAN low speed (powertrain) (high +)
19. CAN low speed (powertrain) (low -)
20. CAN low speed (powertrain) (screen)
21. ABS
22. CAN low speed (comfort) (high +)
23. CAN low speed (comfort) (low -)
24. CAN low speed (comfort) (screen)
25. Hood
26. Fuel filler cap
27. Belt buckle
28. K-wire
29. Outside temperature-input
30. Terminal 58d (ext. Dimmer potentiometer)
31. Selector range display
32. Automatic vertical headlight aim control system

Gray 32-pin multi-pin connector

Note. Allocated vertically for VDO version.

Note. The following list refers to see scheme 8 and see scheme 9.

1. Menu selection switch (menu)
2. Menu selection switch (out A)
3. Menu selection switch (out B)
4. Menu selection switch (Ener)
5. CAN high speed display (high +)
6. CAN high speed display (low -)
7. CAN high speed display (screen)
8. Not assigned
9. Not assigned
10. Not assigned
11. Enable
12. Clock
13. Data
14. Brake light
15. Windshield washer fluid level
16. Rear lights/low beams (lamp control)
17. Left board computer
18. Driver information system, right
19. Driver information system, reset
20. Remote input, auxiliary heater
21. Summer / winter switch-over
22. Auxiliary heater on
23. Button branch 1 navigation
24. Button branch 2 navigation
25. Button branch telematic
26. Not assigned
27. Not assigned
28. Not assigned
29. Not assigned
30. Not assigned
31. Not assigned
32. Not assigned

Vehicles with front wheel drive

Sender for fuel gauge is located below the floor cover of the luggage compartment.

1. Unscrew cover for connector flange below the luggage compartment carpet. NOTE: To do so, remove luggage compartment floor on the Avant. See «CARGO AREA FLOOR TRIM AND SUPPORTS (AVANT), REMOVING AND INSTALLING»(ref-196286-S22068532592005100800000) .
2. Carefully disengage and disconnect 4-pin harness connector (arrow).

Scheme 6

Note. Terminal assignment for vehicles with front and all wheel drive is identical.

Vehicles with all wheel drive

For vehicles with all wheel drive, the three senders for fuel gauge are connected in sequence.

1. The central connector for all sensors is located on right below the rear seat bench.
2. Remove rear seat bench. See «SEAT BENCH, REMOVING AND INSTALLING»(ref-196287-S04747218032005100800000) .
3. Unscrew cover for connector flange at right beneath rear seat bench
4. Carefully disengage and disconnect 4-pin harness connector (arrow).

Scheme 7

Note. Terminal assignment for vehicles with front and all wheel drive is identical.

Consumption signal, checking (engine at powertrain CAN-bus)

Note. On some engines, the consumption signal is transferred from the Engine Control Module (ECM) to the instrument cluster via the powertrain CAN-bus. Malfunctions in the communication between Engine Control Module (ECM) and instrument cluster can only be detected via On Board Diagnostic (OBD) (DTC 01312 and 01314).

See INSTRUMENT CLUSTER, ON BOARD DIAGNOSTIC (OBD) .
