ENGINE CODE
Engines are identified by a 3-letter code stamped on engine. On vehicles equipped with engine code AHA, letters and serial number are located on flat surface of cylinder block in front of right cylinder head. The engine code is also included on the vehicle data label. (Scheme 1) On vehicles equipped with engine code ART, letters are located on left side of cylinder block. The engine code is also included on vehicle data label. (Scheme 2)
Scheme 1
Scheme 2
FUSE COLOR IDENTIFICATION
| Fuse Color | Amp Rating |
|---|---|
| Blue | 15 |
| Brown | 7.5 |
| Green | 30 |
| Light Brown | 5 |
| Red | 10 |
| Transparent (White) | 25 |
| Yellow | 20 |
FUSE COLOR/AMP RATING
FUSE PANEL LOCATION
Fuse panel is located behind left side of dashboard. (Scheme 3)
Scheme 3
FUSE PANEL IDENTIFICATION
For fuse position within panel (Scheme 4) For fuse number, amperage rating and circuits protected, see FUSE IDENTIFICATION (FUSE PANEL) table.
Scheme 4
Note. Fuses 23 through 44 may be designated in wiring diagrams with a prefix of 2. For example, fuse No. 29 may be labeled as 229. Fuse No. 43 may be labeled as 243.
| Fuse No. | Amp Rating | Circuits Protected | |
|---|---|---|---|
| 1 (1) | 5 | Washer Nozzle Heaters | |
| 2 (1) | 10 | Emergency Flasher Switch & Relay | |
| 3 | 5 | Glove Compartment Light | |
| 4 | 5 | License Plate Light | |
| 5 | 10 | Outside Temperature Display, Transmission Range Selector Lever Display, Lamp Control Module, A/C Control Head, Air Quality Sensor, Mirror Adjustment, Mirror Fold-Away Function Control Module, Rear Window Shade, Radio, Oil Level Thermal Sensor (2) | |
| 6 | 5 | Central Locking Control Module | |
| 7 | 10 | ABS Control Module, Anti-Slip Control Switch, Brake Pedal Switch (2) | |
| 8 | 5 | Telephone Transceiver Central Locking Control Module (1) | |
| 9 (1) | 10 | Heated Outside Mirrors, Mirror Memory switch | |
| 10 (3) | 5 | Headlight Beam Adjustment Motors, Beam Adjustment Control Module | |
| 11 | N/A | Not Used | |
| 12 (1) | 10 | DLC | |
| 13 | 10 | Brake Light Switch | |
| 14 | 10 | Central Locking Control Module, Door Warning Lights, Passenger Compartment Monitoring Switch, Trunk Lid Release Switch, Memory Program Switch | |
| 15 | 10 | Instrument Cluster, Solar Cell Separation Relay, Transmission Control Module, Selector Lever Light Relay, Mirror Memory Control Module (1) | |
| 16 | N/A | Not Used | |
| 17 | N/A | Not Used | |
| 18 | 10 | High Beam (Right), Headlight High Beam Indicator Light | |
| 19 | 10 | High Beam (Left), Fog Light | |
| 20 | 10 | Lamp Control Module, Headlight Beam Adjusting Motor (Right) (4) | |
| 21 | 10 | Lamp Control Module, Headlight Beam Adjuster (Left) (4) | |
| 22 | 5 | Lamp Control Module, Parking Light (Right) | |
| 23 | 5 | Lamp Control Module, Parking Light (Left) | |
| 24 | 25 | Wiper/Washer Intermittent Relay | |
| 25 | 30 | Fresh Air Blower, Solar Cell Separation Relay, A/C Pressured Switch, A/C Control Head, A/C Clutch Relay | |
| 26 | 30 | A/C Control Head, Rear Window Defogger Switch | |
| 27 | 15 | Rear Window Wiper Motor, Heated Steering Wheel | |
| 28 | 20 | Fuel Pump | |
| 29 | |||
| Engine Code AHA | 30 | Leak Detection Pump, Lambda-Probe Heaters, Camshaft Adjustment (Valve 1 & 2), Intake Manifold Change-Over Valve, Oxygen Sensor Heaters, Secondary Air Injector Solenoid Valve & Pump Relay, EVAP Canister Purge Regulator Valve | |
| Engine Code ART | 30 | Leak Detection Pump, Ignition Coils | |
| 30 | 20 | Power Sunroof Control Module | |
| 31 | |||
| All Vehicles | 15 | Multi-Function Transmission Range Switch, Automatic Day/Night Interior Mirror, Shift Lock Solenoid | |
| Engine Code AHA | 15 | MAF Sensor, DLC, ECM | |
| 32 | |||
| Engine Code AHA | 20 | ECM, Ignition Coils | |
| Engine Code ART | 20 | Cruise Control Switch, Fuel Injectors | |
| 33 | 15 | Cigarette Lighter | |
| 34 | |||
| Engine Code AHA | 15 | Fuel Injectors | |
| Engine Code ART | 25 | MAF Sensor, Lambda Probe Heaters, Oxygen Sensor Heaters, Camshaft Valves, EVAP Canister Purge valve, Secondary Air Injection Solenoid Valve, Electrohydraulic Engine Mount Solenoid Valve (Left & Right), intake Manifold Change-Over Valve, Intake Manifold Turning Valve No. 7 | |
| 35 | N/A | Not Used | |
| 36 | 15 | Fog Light Switch | |
| 37 | 20 | Radio, Right Rear Woofer/Amp, Power Antenna, Telephone Transceiver | |
| 38 | 15 | Central Locking Control Module, Ultra-Sound Sensor Control Module | |
| 39 (1) | 15 | Emergency Flasher Switch | |
| 40 | 25 | Dual Horn Relay | |
| 41 | N/A | Not Used | |
| 42 | N/A | Not Used | |
| 43 | N/A | Not Used | |
| 44 | 30 | Heated Seat Adjuster | |
| (1) Applies to vehicles equipped with engine code AHA only. (2) Applies to vehicles equipped with engine code ART only. (3) Applies to vehicles equipped with high intensity gas discharge lamps only. (4) Applies to vehicles not equipped with high intensity gas discharge lamps. | |||
| (1) | Applies to vehicles equipped with engine code AHA only. |
| (2) | Applies to vehicles equipped with engine code ART only. |
| (3) | Applies to vehicles equipped with high intensity gas discharge lamps only. |
| (4) | Applies to vehicles not equipped with high intensity gas discharge lamps. |
FUSE IDENTIFICATION (FUSE PANEL)
THREE FOLD RELAY PANEL (E-BOX)
For fuse and relay positions within carrier (Scheme 5) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (THREE FOLD RELAY PANEL) table. For fuse number, amperage rating, and circuits protected, see FUSE IDENTIFICATION (THREE FOLD RELAY PANEL) table.
Note. Three fold relay panel is located in electronics box, plenum chamber, in the left rear corner of engine compartment.
Note. Manufacturer does not provide fuse number, amperage rating, or circuits protected for three fold relay panel fuses.
Scheme 5
| Position | Relay No. | Circuit Protected |
|---|---|---|
| 1 | N/A | Not Used |
| 2 | J299 | Secondary Air Injection Pump relay |
| 3 | N/A | Not Used |
RELAY IDENTIFICATION (THREE FOLD RELAY PANEL)
| Position | Fuse No. | Amp Rating | Circuit Protected |
|---|---|---|---|
| 4 | N/A | N/A | Not Used |
| 5 | N/A | N/A | Not Used |
| 6 | N/A | N/A | Not Used |
| 7 (1) | S130 | 40 | Secondary Air Pump |
| 8 | N/A | N/A | Not Used |
| 9 | N/A | N/A | Not Used |
| (1) Applies to vehicles equipped with engine code ART only. | |||
| (1) | Applies to vehicles equipped with engine code ART only. |
FUSE IDENTIFICATION (THREE FOLD RELAY PANEL)
EIGHT FOLD RELAY PANEL
For fuse and relay positions within carrier (Scheme 6) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (EIGHT FOLD RELAY PANEL) table. For fuse number, position number, amperage rating and circuits protected, see FUSE IDENTIFICATION (EIGHT FOLD RELAY PANEL) table.
Note. Eight fold relay panel is located behind trim panel, under driver's side of instrument panel.
Scheme 6
| Position No. | Relay No. | Circuit Protected |
|---|---|---|
| 1 | N/A | Not Used |
| 2 | N/A | Not Used |
| 3 | N/A | Not Used |
| 4 | N/A | Not Used |
| 5 | N/A | Not Used |
| 6 | N/A | Not Used |
| 7 (1) | 40 | Secondary Air Pump |
| 8 | N/A | Not Used |
| (1) Applies to vehicles equipped with engine code AHA from November 1998 and on. | ||
| (1) | Applies to vehicles equipped with engine code AHA from November 1998 and on. |
RELAY IDENTIFICATION (EIGHT FOLD RELAY PANEL)
| Position No. | Fuse No. | Amp Rating | Circuit Protected |
|---|---|---|---|
| 9 | N/A | N/A | Not Used |
| 10 | N/A | N/A | Not Used |
| 11 | N/A | N/A | Not Used |
| 12 | N/A | N/A | Not Used |
| 13 | N/A | N/A | Not Used |
| 14 | S44 | 30 | Power Seat Circuit Breaker (1) |
| 15 | S184 | 20 | Luggage Compartment Socket |
| 16 | S37 | 30 | Power Window Circuit Breaker (Front) |
| 17 | S43 | 30 | Power Window Circuit Breaker (Rear) |
| 18 | S123 | 50 | ABS Control Module |
| 19 | N/A | N/A | Not Used |
| 20 | S42 | 60 | Coolant Fan |
| 21 | S142 | 5 | Coolant Fan Control Module |
| 22 | N/A | N/A | Not Used |
| 23 | N/A | N/A | Not Used |
| 24 | S80 | 30 | Power Seat Circuit Breaker (2) |
FUSE IDENTIFICATION (EIGHT FOLD RELAY PANEL)
THIRTEEN FOLD RELAY PANEL
For fuse and relay position within carrier (Scheme 7) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (THIRTEEN FOLD RELAY PANEL) table. For fuse number, position number, amperage rating and circuits protected, see FUSE IDENTIFICATION (THIRTEEN FOLD RELAY PANEL) table.
Note. Thirteen fold relay panel is located behind trim panel under driver's side of instrument panel.
Scheme 7
| Position No. | Relay No. | Circuit Protected |
|---|---|---|
| 1 | N/A | Not Used |
| 2 | N/A | Not Used |
| 3 | J309 | Solar Cell Separation |
| 4 | J207 | Starting Interlock |
| 5 | J44 | A/C Clutch |
| 6 | J5 | Fog Light |
| 7 | N/A | Not Used |
| 8 | N/A | Not Used |
| 9 | J123 | Lamp Control Module |
| 10 | J123 | Lamp Control Module |
| 11 | J351 | Mirror Fold-Away Function Control Module |
| 12 | J351 | Mirror Fold-Away Function Control Module |
| 13 | J236 | Servotronic Control Module |
RELAY IDENTIFICATION (THIRTEEN FOLD RELAY PANEL)
| Position No. | Fuse No. | Amp Rating | Circuit Protected |
|---|---|---|---|
| 14 | N/A | N/A | Not Used |
| 15 | N/A | N/A | Not Used |
| 16 (1) | A28 | 12 | Fog Light Circuit Breaker |
| 17 (2) | S130 | 40 | Secondary Air Pump |
| 18 | N/A | N/A | Not Used |
| (1) Applies to vehicles produced in Canada only. (2) Applies to vehicles equipped with engine code AHA up to October 1998. | |||
| (1) | Applies to vehicles produced in Canada only. |
| (2) | Applies to vehicles equipped with engine code AHA up to October 1998. |
FUSE IDENTIFICATION (THIRTEEN FOLD RELAY PANEL)
MICRO CENTRAL ELECTRIC PANEL
For relay position within panel (Scheme 8) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (MICRO CENTRAL ELECTRIC PANEL) and RELAY IDENTIFICATION (MICRO CENTRAL ELECTRIC PANEL) tables.
Note. Micro central electric panel is located in driver's side footwell, behind trim panel.
Scheme 8
| Position No. | Relay No. | Circuit Protected |
|---|---|---|
| 1 | J4 | Dual Horn |
| 2 | J59 | Load Reduction |
| 3 | N/A | Not Used |
| 4 | J17 | Fuel Pump |
| 5 | J31 | Wiper/Washer Intermittent |
| 6 | J31 | Wiper/Washer Intermittent |
RELAY IDENTIFICATION (MICRO CENTRAL ELECTRIC PANEL)
| Position No. | Fuse No. | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | N/A | N/A | Not Used |
| B | S100 | 10 | Rear Shade |
| C | N/A | N/A | Not Used |
RELAY IDENTIFICATION (MICRO CENTRAL ELECTRIC PANEL)
