Interior Trim Audi A6 C5

Component locations, overview

The following list pertains to (Scheme 1).

1. Door trim Removing, see «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Hinged pockets Removing, see «HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__hinged-pocket-assembly-removing-and-installing) .
3. Loudspeaker Removing, see «BASS LOUDSPEAKER, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__bass-loudspeaker-removing) .
4. Treble loudspeaker Removing, see «TREBLE LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__treble-loudspeaker-removing-and-installing) .
5. Inner connecting piece
6. Outer connecting piece
7. Inner filler piece
8. Outer filler piece
9. Guide for locking knob
10. Clip locator
11. Insulation Removing and installing, see «FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-insulation-removing-and) .
12. Door warning light Removing, see «DOOR WARNING LIGHT AND FOOTWELL LIGHT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__door-warning-light-and-footwell-light) .
13. Central locking switch (driver's side only) Removing, see «CENTRAL LOCKING SWITCH, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__central-locking-switch-removing) .
14. Interior door handle Removing, see «INTERIOR DOOR HANDLE, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__interior-door-handle-removing) .
15. Trim panel Removing, see «TRIM PANEL IN DOOR TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__trim-panel-in-door-trim-removing) .
16. Foam seal
17. Mount for hinged pockets
18. Window regulator switch unit Driver's side, see «DRIVER'S WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__drivers-window-regulator-switch-removing-and) . Passenger side, see «FRONT PASSENGER WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .

Front door trim, removing and installing

The following list pertains to (Scheme 2).

1. Door trim Remove screws -2- (2x) from door trim -1-. Remove window regulator switch unit -5-. Driver's side, see «DRIVER'S WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__drivers-window-regulator-switch-removing-and) . Passenger side, see «FRONT PASSENGER WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Lift door trim about 20 cm upward and remove from door. Detach Bowden cable for interior door handle, see «DETACHING BOWDEN CABLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-bowden-cable) . Disconnect electrical connectors, see «DISCONNECTING ELECTRICAL CONNECTORS»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__disconnecting-electrical-connectors) . Clip locators -3- (7x) and -4- (2x) must be clipped in place when installing door trim. When installing, press center of door trim onto door.
2. Screws (2x) Tightening torque: 1.5 Nm (13 in lb)
3. Clip locators
4. Clip locators
5. Window regulator switch unit

Detaching Bowden cable

1. Pull Bowden cable -1- out of guide -2- and detach.

Note. When installing, make sure hook -3- is facing upward

Scheme 1

Disconnecting electrical connectors

1. Disconnect connector for central locking switch -1-.
2. Disconnect connector for door warning light and anti-theft alarm -2-.
3. Disconnect connector for loudspeaker -3-.

Driver's window regulator switch, removing and installing

1. Insert screwdriver -1- in hole -2-.
2. Use screwdriver -3- to press retainer -2- in direction of arrow -A-. (Scheme 6)
3. Remove window regulator switch unit -1- in direction of arrow -B-.
4. Press retainer tab -2- and pull off connector -1-.

For vehicles with hole on underside

1. Insert screwdriver -3- in hole.
2. Use screwdriver -3- to press retainer -2- in direction of-arrow A-.
3. Remove window regulator switch unit -1- in direction of-arrow B-.

For vehicles without hole on underside

1. Mask door trim with adhesive tape -4-.
2. Use screwdriver -3- to press retainer -2- in direction of -arrow A-.
3. Remove window regulator switch unit -1- in direction of arrow.

All vehicles

1. Press retainer tab -2- and disconnect connector -1-.

Front door trim insulation, removing and installing

1. Insulation -1- must be installed all around inside door trim.
2. When removing or installing, make sure insulation -1- is not damaged by clip locators or electrical connectors.
3. Wiring cover -2
4. Press on insulation around sealing lip -3-.

Locking knob, adjusting

1. When in "locked" position, locking knob must not project from door trim (distance -a- = 0 to 2 mm below surface).

Wiring in door trim, routing

The following list pertains to (Scheme 13).

1. Wiring to locking knob guide with light for anti-theft alarm.
2. Wiring to central locking switch (driver's side only).
3. Wiring to treble loudspeaker.
4. Wiring to bass loudspeaker.
5. Wiring to door warning lights.

Door warning light and footwell light, removing and installing

1. Use screwdriver to pry out door warning light -1- from underneath and pull outward together with wiring.
2. Disconnect door warning light -1-.
3. Use screwdriver to pry out footwell light -2- from front and pull outward together with wiring.
4. Disconnect footwell light -2-.

Treble loudspeaker, removing and installing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove insulation. See «FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-insulation-removing-and) .
3. Use screwdriver to detach clip -1-.
4. Remove treble loudspeaker -2-.
5. Detach wiring harness from door trim as far as bass loudspeaker.

Bass loudspeaker, removing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove insulation. See «FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-insulation-removing-and) .
3. Remove screws -1- (3x). Tightening torque: 1.5 Nm (13 in lb)
4. Remove bass loudspeaker -2- and disconnect connector.

Hinged pocket assembly, removing and installing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove insulation. See «FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-insulation-removing-and) .
3. Remove screws -1- (6x).

Hinged pocket assembly with memory switch unit and pre-selector/timer for auxiliary heater, overview

The following list pertains to (Scheme 18).

1. Hinged pocket assembly
2. Hinged pocket for auxiliary heater pre-selector/timer
3. Wiring for memory switch unit
4. Trim cap
5. Memory switch unit
6. Wiring for auxiliary heater pre-selector/timer
7. Switch for auxiliary heater pre-selector/timer
8. Auxiliary heater pre-selector/timer
9. Trim panel for auxiliary heater pre-selector/timer

Removing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove hinged pocket assembly. See «HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__hinged-pocket-assembly-removing-and-installing) .
3. Detach wiring -4- from clips -5- (2x).
4. Using a screwdriver, press in retaining lugs -2- (2x) and at the same time push out memory switch unit -1-.
5. Disconnect connector -7- from memory switch unit -1-.

Installing

1. When installing, make sure that wiring -4- is located in guide -6-.

Scheme 2

Trim cap on memory switch unit, removing and installing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove hinged pocket assembly. See «HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__hinged-pocket-assembly-removing-and-installing) .
3. Remove memory switch unit. See «MEMORY SWITCH UNIT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
4. Remove screws -1- (3x). Tightening torque: 1.2 Nm (11 in lb)

1. Open flap for pre-selector/timer.
2. Using a screwdriver -D-, release catches on sides of mount -A-.
3. Carefully lift mount -A- with pre-selector/timer -C- out of flap.
4. Push pre-selector/timer -C- upward out of mount -A-.
5. Detach wire.

Note. Pre-selector/timer -C- is secured in mount -A- with two clips -B-.

1. Install mount -A-.
2. Check position of heater indicator lamp -A-.
3. Plug in connectors.
4. Install pre-selector/timer -C- in mount -A-.

Note. When installing pre-selector/timer, make sure that the wiring does not push the pre-selector/timer out of its mount. The first vehicles equipped with auxiliary heater were equipped with a preselector/timer unit with Part No. index A. If this unit is replaced with a version with Part No. index C, also replace the mount -A- (which is shaped differently). (Scheme 23)

Pre-selector/timer switch, removing and installing

1. Remove pre-selector/timer, see «PRE-SELECTOR/TIMER FOR AUXILIARY HEATER, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim).
2. Using a screwdriver, press back retaining lugs -A-. (Scheme 24)
3. Remove switch -B-.

Note. Switch -B- is closed when the flap is open. The pre-selector/timer is deactivated when the switch is open, which prevents the settings from being altered with the buttons.

Scheme 3

Scheme 4

Scheme 5

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove hinged pocket assembly. See «HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__hinged-pocket-assembly-removing-and-installing) . NOTE: The hinged pockets can be removed separately.
3. Detach spring -1- from guide -2-.
4. Disengage spring -arrow-.
5. Use screwdriver to press pin -1- outward as far as it will go.
6. Use long-nose pliers to pull out pin -1-.
7. Use screwdriver to press pin -1- outward as far as it will go.
8. Use long-nose pliers to pull out pin -1-.
9. Use screwdriver to pry out guide pins -1- on left and right.
10. Remove hinged pocket from mount.

1. When installing, engage gear wheel -1- in gear track -2-.

Scheme 6

Central locking switch, removing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing).
2. Remove insulation. See «FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-insulation-removing-and).
3. Disconnect connector -2-. see scheme 31
4. Detach wiring -4- from door trim.
5. Use screwdriver to press in retainer hooks -3- (2x), and push out central locking switch -1- toward the front.

Scheme 7

1. With door trim installed: Mask door trim with adhesive tape -2- and use screwdriver -3- to pry out trim panel -1-.
2. With door trim removed: Push out trim panel from behind by pressing retaining pins.

Interior door handle, removing

1. Remove door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) .
2. Remove treble loudspeaker. See «TREBLE LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__treble-loudspeaker-removing-and-installing) .
3. Removing central locking switch (driver's side only), see «CENTRAL LOCKING SWITCH, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__central-locking-switch-removing) .
4. Remove screw -1-.
5. Press retainers -2- (2x) and remove interior door handle from the front.

The following list pertains to see scheme 34.

1. Door trim Removing, see «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Hinged pocket Removing, see «HINGED POCKET, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
3. Loudspeaker Removing, see «BASS LOUDSPEAKER, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
4. Treble loudspeaker Removing, see «TREBLE LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
5. Inner connecting piece
6. Outer connecting piece
7. Inner filler piece
8. Outer filler piece
9. Guide for locking knob
10. Clip locator
11. Insulation Removing and installing, see «REAR DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-insulation-removing-and) .
12. Door warning light Removing, see «DOOR WARNING LIGHT AND FOOTWELL LIGHT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
13. Interior door handle Removing, see «INTERIOR DOOR HANDLE, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
14. Trim panel Removing, see «TRIM PANEL IN DOOR TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
15. Foam seal
16. Mount for hinged pockets
17. Window regulator switch unit Removing, see «WINDOW REGULATOR SWITCH UNIT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .

Rear door trim, removing and installing

The following list pertains to see scheme 35.

1. Door trim Remove screws -2- (2x) from door trim -1-. Remove window regulator switch unit -5-. See «WINDOW REGULATOR SWITCH UNIT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Lift door trim about 20 cm upward and remove from door. Detach Bowden cable for interior door handle. See «DETACHING BOWDEN CABLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Disconnect electrical connectors. See «DISCONNECTING ELECTRICAL CONNECTORS»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Clip locators -3- (6x) and -4- (1x) must be clipped in place when installing door trim. When installing, press center of door trim onto door.
2. Screws (2x) Tightening torque: 1.5 Nm (13 in lb)
3. Clip locators
4. Clip locators
5. Window regulator switch unit

1. Pull Bowden cable -1- out of guide -2- and detach.

Note. When installing, make sure hook -3- is facing upward.

Scheme 8

1. Disconnect connector for door warning light -2-.
2. Disconnect connector for loudspeaker -1-.

1. Insert screwdriver -3- in hole.
2. Use screwdriver -3- to press retainer -2- in direction of-arrow A-.
3. Remove window regulator switch unit -1- in direction of-arrow B-.

1. Mask door trim with adhesive tape -4-.
2. Use screwdriver -3- to press retainer -2- in direction of-arrow A-.
3. Remove window regulator switch unit -1- in direction of arrow.

For all vehicles

1. Press retainer tab -2- and disconnect connector -1-.

Rear door trim insulation, removing and installing

1. Insulation -1- must be installed all around inside door trim.
2. When removing or installing, make sure insulation -1- is not damaged by clip locators or electrical connectors.
3. Wiring cover -2-.
4. Press on insulation around sealing lip -3-.

1. When in "locked" position, locking knob must not project from door trim (distance -a- = 0 to 2 mm below surface).

1. Wiring to treble loudspeaker
2. Wiring to bass loudspeaker
3. Wiring to door warning lights
4. Wiring to interior door handle light

1. Use screwdriver to pry out door warning light -1- from underneath and pull outward together with wiring.
2. Disconnect door warning light -1-.
3. Use screwdriver to pry out footwell light -2- from front and pull outward together with wiring.
4. Disconnect footwell light -2-.

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Remove insulation. See «REAR DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-insulation-removing-and) .
3. Remove screws -1- (3x). Tightening torque: 1.5 Nm (13 in lb)
4. Detach bass loudspeaker -2- and disconnect electrical connector(s).

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Remove insulation. See «REAR DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-insulation-removing-and) .
3. Use screwdriver to detach clip -1-.
4. Remove treble loudspeaker -2-.
5. Detach wiring harness from door trim as far as bass loudspeaker.

Trim panel in door trim, removing

With door trim installed

1. Mask door trim with adhesive tape -2- and use screwdriver -3- to pry out trim panel -1-.

With door trim removed

1. Push out trim panel from behind by pressing retaining pins.

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Remove treble loudspeaker. See «TREBLE LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
3. Remove screw -1-.
4. Press retainers -2- (2x) and remove interior door handle from the front.

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Remove insulation. See «REAR DOOR TRIM INSULATION, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-insulation-removing-and) .
3. Remove screws -1- (4x).

Scheme 9

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing).
2. Remove hinged pocket assembly. See «HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim).
3. Detach spring -1- from guide -2-.
4. Detach spring -1- from guide -2-.
5. Use screwdriver to press pin -1- outward as far as it will go.
6. Use long-nose pliers to pull out pin -1-.
7. Use screwdriver to press pin -1- outward as far as it will go.
8. Use long needle-nose pliers to pull out pin -1-.
9. Use screwdriver to pry out guide pins -1- on left and right. see scheme 54
10. Remove hinged pocket from mount. Installing
11. When installing, engage gear wheel -1- in gear track -2-.

1. Remove door trim. See «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
2. Remove trim piece in door panel. See «TRIM PANEL IN DOOR TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .

The following list pertains to see scheme 56.

1. Inner guide strip
2. Caps Pry out inner guide strip -1- before removing caps -2-. see scheme 56
3. U-clips (4x)
4. Rear door panel

1. Remove bolts -2- (3x). see scheme 57
2. Tightening torque: 1.5 Nm (13 in lb)
3. Pull off U-clips -3- (5x). see scheme 57
4. Unhook window shade -1-.

Scheme 10

1. When installing, first slide window shade -1- into direction of -arrow A- and then into direction of -arrow B-. see scheme 57

Retaining hook for window shade, removing and installing

1. 2-Retaining hook
2. 3-Sheet metal screws-1.5 Nm (13 in lb)

Note. Backing plate -1- serves as a spacer and must always be re-installed in the original position.

Scheme 11

The following list pertains to see scheme 59.

1. Glove box Removing, see «GLOVE BOX, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__glove-box-removing-and-installing)
2. Driver's storage compartment Removing, see «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing)
3. Steering column switch Removing, see «REMOVING STEERING COLUMN SWITCH»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-steering-column-switch) .
4. Removing instrument cluster See «INSTRUMENTS - UP TO 2000»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) or «INSTRUMENTS - 2001 AND UP»(ref-196300) .
5. Front section of center console Removing , see «CENTER CONSOLE (FRONT SECTION), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-console-front-section-removing-and)
6. Center section of instrument panel Removing, see «CENTER SECTION OF INSTRUMENT PANEL (VEHICLES WITH "CHORUS" AND "CONCERT" RADIOS), REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment)
7. Reinforcing bracket for center section of instrument panel Removing, see «REMOVING REINFORCING BRACKET»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-reinforcing-bracket) .
8. Instrument panel end trim (left) Removing, see «REMOVING INSTRUMENT PANEL END TRIM (LEFT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-end-trim-left) .
9. Instrument panel end mounting screws (left) Removing, see «REMOVING INSTRUMENT PANEL END TRIM (LEFT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-end-trim-left) .
10. Instrument panel end trim (right) Removing, see «REMOVING INSTRUMENT PANEL END TRIM (RIGHT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-end-trim-right) .
11. Instrument panel end mounting screws (right) Removing, see «REMOVING INSTRUMENT PANEL END TRIM (RIGHT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-end-trim-right) .
12. Instrument panel mounting screws (driver's side) Removing, see «REMOVING INSTRUMENT PANEL MOUNTING SCREWS-DRIVER'S SIDE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-mounting-screws) .
13. Passenger side airbag Detaching, see «REMOVING INSTRUMENT PANEL MOUNTING SCREWS-DRIVER'S SIDE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-instrument-panel-mounting-screws) .
14. Photosensor Removing, see «REMOVING PHOTOSENSOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-photosensor) .
15. Connectors for side vent lighting and temperature sensor Detaching, see «DISCONNECTING CONNECTORS FOR SIDE VENT LIGHTING AND TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__disconnecting-connectors-for-side-vent-lighting) .
16. Connector for center vent lighting Detaching, see «DISCONNECTING CONNECTORS FOR SIDE VENT LIGHTING AND TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__disconnecting-connectors-for-side-vent-lighting) .
17. Trim strip for instrument panel Removing, see «TRIM STRIP FOR INSTRUMENT PANEL, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__trim-strip-for-instrument-panel-removing) .

Instrument panel, removing

Note. Determining the correct coding for the anti-theft radio before removing.

1. Disconnect battery Ground (GND) strap at battery.
2. Remove driver's side airbag unit. See appropriate Air Bag Restraint Systems article.
3. Remove steering wheel. See appropriate Air Bag Restraint Systems article.
4. Remove instrument cluster. See «INSTRUMENTS - UP TO 2000»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) or «INSTRUMENTS - 2001 AND UP»(ref-196300) .
5. Remove driver's storage compartment. See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing) .
6. Remove glove box. See «GLOVE BOX, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__glove-box-removing-and-installing) .
7. Remove rear section of center console. See «CENTER CONSOLE (REAR SECTION), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-console-rear-section-removing-and) .
8. Remove front section of center console. See «CENTER CONSOLE (FRONT SECTION), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-console-front-section-removing-and) .
9. Removing center section of instrument panel (on vehicles with "Chorus" and "Concert" radios). See «CENTER SECTION OF INSTRUMENT PANEL (VEHICLES WITH "CHORUS" AND "CONCERT" RADIOS), REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment) .
10. Removing center section of instrument panel (on vehicles with "Symphony" radio and "radio-navigation system plus". See «CENTER PART OF INSTRUMENT PANEL (VEHICLES WITH "SYMPHONY" RADIOS AND "RADIO-NAVIGATION SYSTEM PLUS"), REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-part-of-instrument-panel-vehicles) .

Removing steering column switch

1. Driver's side airbag unit and steering wheel removed.

1. Pull out steering column and tilt downward as far as it will go.
2. Remove screws -1- (2x). Tightening torque: 2.8 Nm (25.2 in lb)
3. Remove grip -2-.
4. Remove two Phillips-head screws -arrows-. see scheme 61 Tightening torque: 0.6 Nm (5.4 in lb)
5. Remove upper steering column switch trim -1-.

When installing, insert upper section into hooks on lower section, swivel downward and secure with screws.

Scheme 12

1. Remove screws -2- (2x). see scheme 62 Tightening torque: 0.6 Nm (5 in lb)
2. Remove hex socket head bolt -1-. Tightening torque: 0.6 Nm (5 in lb)
3. Remove lower steering column switch trim -3-.
4. Separate connection -1-.
5. Release locking lugs -arrows- and pull coil connector with slip ring off steering column switch. NOTE: The steering must be in the center position (wheels in straight-ahead position) when the coil connector and slip ring are removed and installed.
6. Remove screw -2-. see scheme 63 Tightening torque: 2.8 Nm (25 in lb)
7. Disconnect connectors -3- (2x). see scheme 63
8. Remove steering column switch -4-.

Removing reinforcing bracket

1. Remove screws -1- (5x). Tightening torque: 4 Nm (35 in lb)
2. Remove reinforcing bracket -2-.

Scheme 13

Removing instrument panel end trim (left)

1. Use screwdriver to unclip left-hand instrument panel end trim.

Removing instrument panel end mounting screws (left)

1. Remove screws -1- (3x). Tightening torque: 4 Nm (35 in lb)

Removing instrument panel end trim (right)

1. Use screwdriver to unclip right-hand instrument panel end trim.

Removing instrument panel end mounting screws (right)

1. Remove screws -1- (3x). Tightening torque: 4 Nm (35 in lb)

Removing instrument panel mounting screws - driver's side

1. Remove screws -1- (2x). Tightening torque: 4 Nm (35 in lb)

Detaching passenger side airbag

1. Use screwdriver to lift connector -1- for passenger side airbag unit over retainer tab -2- and pull off connector in direction of arrow -3-.
2. Remove bolts-1-(4x). Tightening torque: 9 Nm (80 in lb)

Removing photosensor

1. Carefully pry off cover -A-.
2. Remove screw -B-.
3. Lift photosensor and secure harness connector with cord or cable tie.
4. Disconnect harness connector.

Disconnecting connectors for side vent lighting and temperature sensor

1. Disconnect connector -1- on left and right for side vent lighting.
2. Disconnect connector -2- for side-vent temperature sensor on left and right by squeezing together retainer tabs -3-.

Disconnecting connector for center vent lighting

1. Disconnect connector -1- for center vent lighting.
2. Pull out instrument panel toward the rear.

Scheme 14

Scheme 15

Scheme 16

1. Extend photosensor by attaching a cord or cable tie.
2. Locate instrument panel and insert extension attached to photosensor.
3. Clip -1- with felt pad -2-.
4. Insert instrument panel into clips -1-, at the same time pressing it down slightly.
5. Press gently to check that instrument panel is installed properly in clips -1-.
6. Install steering column switch but do not tighten mounts.
7. Install lower section of trim -3- for steering column switch.
8. Tighten screws -2- (2x). Tightening torque: 0.6 Nm (5.4 in lb)
9. Install screw -1- but do not tighten.
10. Install self-cancelling ring and slip ring.
11. Install steering wheel.
12. Position steering column switch with lower section of trim at a distance of 3 mm from steering wheel (distance -a-).
13. Tighten clamp -1-. Tightening torque: 2.8 Nm (25 in lb)
14. Tighten socket-head bolt -2-. Tightening torque: 0.6 Nm (5 in lb)
15. Perform remaining installation steps in reverse order of removal.

Trim strip for instrument panel, removing

1. Remove glove box. See «GLOVE BOX, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__glove-box-removing-and-installing) .
2. Using a screwdriver, carefully press out trim strip for instrument panel -1- from the rear.

The following list pertains to see scheme 79.

1. Pedal bracket Removing, see «INSTRUMENT PANEL CENTRAL TUBE, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__instrument-panel-central-tube-removing-and) .
2. Steering column Detaching, see «DETACHING WIRING HARNESS AT STEERING COLUMN»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-wiring-harness-at-steering-column) .
3. Relay carrier Removing, see «REMOVING FUSE CARRIER»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-fuse-carrier) .
4. Fuse carrier Removing, see «REMOVING FUSE CARRIER»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-fuse-carrier) .
5. Wiring harness compartment Detaching, see «REMOVING DEFROSTER DUCT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-defroster-duct) .
6. Central tube on driver's side Detaching, see «DETACHING CENTRAL TUBE FROM BODYWORK (DRIVER'S SIDE)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-central-tube-from-bodywork-drivers) .
7. Connector strip, Removing, see «REMOVING CONNECTOR CONSOLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Engine compartment wiring harness, disconnecting, see «INSTRUMENT PANEL CENTRAL TUBE, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__instrument-panel-central-tube-removing-and) .
8. Acoustic brace Removing With threaded connection at window flange, see «REMOVE ACOUSTIC BRACE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__remove-acoustic-brace) . Alternatively with threaded connection of plenum chamber, see «REMOVE ACOUSTIC BRACE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__remove-acoustic-brace) .
9. Wiring harness to steering column switch Removing, see «DETACHING WIRING HARNESS AT STEERING COLUMN»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-wiring-harness-at-steering-column) .
10. Defroster duct Removing, see «REMOVING DEFROSTER DUCT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-defroster-duct) .
11. Center air duct Removing, see «REMOVING CENTER AIR DUCT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-center-air-duct) .
12. Air conditioner from central tube Detaching, see «REMOVING CENTER AIR DUCT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-center-air-duct) .
13. Central tube on passenger side Detaching, see «DETACHING CENTRAL TUBE FROM BODYWORK (PASSENGER-SIDE)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-central-tube-from-bodywork-passenger-side) .
14. Wiring harness on passenger side Detaching, see «REMOVING CENTER AIR DUCT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-center-air-duct) .
15. Right brace Removing, see «DETACHING LEFT BRACE FOR CENTRAL TUBE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-left-brace-for-central-tube) .
16. Left brace Detaching, see «DETACHING LEFT BRACE FOR CENTRAL TUBE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-left-brace-for-central-tube) .

Instrument panel central tube, removing and installing

1. Remove instrument panel. See «INSTRUMENT PANEL, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__instrument-panel-removing) .

Detaching pedal bracket

1. Remove bolt -1-. Tightening torque: 25 Nm (18 ft lb)

Disconnecting engine compartment wiring harness

1. Remove engine control module

See appropriate Multiport Fuel Injection article.

1. Detach connectors -1- (4x) for connecting engine compartment wiring harness to instrument panel wiring harness.

Remove acoustic brace

1. Vehicles with threaded connection to window flange

1. Remove bolt -2-. see scheme 82 Tightening torque: 9 Nm

Scheme 17

1-Acoustic brace

1. Vehicles with threaded connection of plenum chamber (alternative)
2. Plenum chamber cover removed.

1. Remove windshield wiper motor.

See WINDSHIELD WIPER AND WASHER SYSTEM - UP TO 2000 or WINDSHIELD WIPER AND WASHER SYSTEM - 2001 AND UP .

1. Remove bolt -1-. Tightening torque: 6 Nm

Detaching wiring harness at steering column

1. Unclip wiring harness going to steering column switch at retainers -1- (2x)
2. Cut through cable tie -2-.

Detaching steering column

1. Remove bolts -1- (4x). Tightening torque: 25 Nm (18 ft lb)

Removing fuse carrier

1. Remove bolts -1- (2x). Tightening torque: 4 Nm (35 in lb)
2. Detach fuse carrier inward.

Removing relay carrier

1. Remove bolts -1- (2x) from relay carrier -2-. Tightening torque: 2 Nm (18 in lb)
2. Pull tab -2- on relay carrier downward out of guide -3-.

Removing center air duct

1. Remove screw-1- (2x). Tightening torque: 2 Nm (18 in lb)
2. Remove center air duct.

Detaching passenger-side wiring harness

1. Unfasten cable ties -1- (3x).

Detaching air conditioner from central tube

1. Remove bolts -1- (2x). Tightening torque: 12 Nm (9 ft lb)

Detaching left brace for central tube

1. Remove bolts -1- (2x). Tightening torque: 12 Nm (9 ft lb)

Unbolting right brace

1. Remove bolts -1- (2x). Tightening torque: 12 Nm (9 ft lb)
2. Remove bolts -2- (2x). Tightening torque: 12 Nm (9 ft lb)
3. Remove brace.

Detaching central tube from bodywork (driver's side)

1. Remove nuts -2- (2x). Tightening torque: 40 Nm (30 ft lb)

Detaching central tube from bodywork (passenger-side)

1. Remove nut -2- (1x). Tightening torque: 40 Nm (30 ft lb)

Removing defroster duct

1. Pull out central tube slightly.
2. Pay attention to lock washer -2- when removing screws-1-.
3. Remove screws -1- (2x). Tightening torque: 7 Nm (62 in lb)
4. Remove defroster duct -3-.
5. Cut open cable ties at central tube.

Detaching wiring-harness compartment

1. Pull compartment -1- for fuse-carrier wiring harness out of tongue -2-.

Scheme 18

1. Pull out central tube until screws -1- (2x) can be unfastened. see scheme 96
2. Remove screws -1- (2x).
3. Detach remainder of wiring harness from central tube.
4. Remove central tube from vehicle.

1. Replace cable ties which have been cut open or damaged.

Molded headliner and sun visors (sedan), removing and installing

The following list pertains to see scheme 97.

1. Molded headliner Removing: Remove upper A-pillar trim. See «TRIM PANELS (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Detach wiring harness to molded headliner between A-pillar and instrument panel on left side. Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-removing-and-installing) . Remove upper C/D-pillar trim. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) . Detach connector if interior mirror is of automatic anti-glare type. Remove sun visors -2- Remove holders -3- for sun visors. On models with sunroof, pry out frame trim -6-. Remove cover for molded headliner cut-out and reading lamp. See «COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LAMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__cover-for-molded-headliner-cut-out-and) . On models with sunroof: Remove screws -5- (3x). On models without sunroof: Remove screws -5- (2x) Move gear shift/selector lever as far forward as possible. Tilt backrest of passenger seat as far back as possible. Tilt backrest of driver's seat as far back as possible. A second person is required to support the molded headliner. Detach molded headliner at rear. To detach wiring from molded headliner, get out of the vehicle and carefully lower molded headliner onto seats. Detach wiring harness from molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (SEDAN), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . Remove molded headliner through one of the rear doors. Installing Carefully insert molded headliner through one of the rear doors. Attach wiring harness to molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (SEDAN), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . NOTE: Make sure to follow installation sequence, otherwise roof trim cannot be centered. Attach molded headliner at rear. Clip in holders for sun visors. Clip in frame trim -6- for sunroof. Carry out remainder of installation in reverse order of removal.
2. Sun visor Unclip visor -2- from holder -3-, unclip cap -8- and remove screw -7-.
3. Sun visor holder Press holder for sun visor firmly to one side and pull out.
4. Center sun visor Removing, see «REMOVING CENTER SUN VISOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-center-sun-visor) .
5. Screw Tightening torque: 2.5 Nm (22.5 in lb)
6. Frame trim for sliding roof Pry out at markings -11-.
7. Screw
8. Cap
9. Cover
10. Frame for molded headliner cut-out
11. Markings for prying out frame trim

Cover for molded headliner cut-out and interior lamp, removing and installing

1. Pry out cover panel for molded headliner cut-out -1- at locations -4-.
2. Pry out cover for interior light -3- at locations -5-.

Removing center sun visor

1. Molded headliner removed

1. Cut out frame for molded headliner -1- at screw -2- (line -4-).
2. Remove screw -2-.
3. Carefully open sheet metal bracket -3- and remove center sun visor.

Wiring on back of molded headliner (sedan), routing

The following list pertains to see scheme 100.

1. Back of molded headliner Molded headliner removed (lowered onto seats). Disconnect connector -4-. Disconnect connectors -5-. Disconnect connector -6-. Detach adhesive tape -8-. Unclip wiring ducts -3-. Guide out wiring harness -2- through wiring guide -7-. When installing, secure wiring for sun visors with adhesive tape -8-.
2. Wiring harness
3. Wiring duct (6x)
4. Connector for rear interior light
5. Connectors for sun visor light
6. Connector for interior light
7. Wiring guide
8. Adhesive tape for securing wiring

Note. Removing and installing A-pillar trim for vehicles with and without side curtain airbag is the same.

The following list pertains to see scheme 101.

1. Molded headliner Removing: Remove upper A-pillar trim. See «UPPER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-a-pillar-trim-removing-and-installing) . Detach wiring harness to molded headliner between A-pillar and instrument panel on left side. Remove intermediate piece at B-pillar trim. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) . Remove D-pillar trim. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) . Detach connector if interior mirror is of automatic anti-glare type. Remove sun visors -2-. Remove holders -3- for sun visors. On models with sunroof, pry out frame trim -6-. Remove cover for molded headliner cut-out and reading lamp. See «COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LAMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . On models with sunroof: remove screws -5- (3x). On models without sunroof: Remove screws -5- (2x). Move gear shift/selector lever as far forward as possible. Tilt backrest of passenger seat as far back as possible. Tilt backrest of driver's seat as far back as possible. A second person is required to support the molded headliner. Detach molded headliner at rear. To detach wiring from molded headliner, get out of the vehicle and carefully lower molded headliner onto seats. Detach wiring harness from molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (SEDAN), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . Remove molded headliner through one of the rear doors. Installing Carefully insert molded headliner through one of the rear doors. Attach wiring harness to molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (SEDAN), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . NOTE: Make sure to follow installation sequence, otherwise roof trim cannot be centered. Attach molded headliner at rear. Clip in holders for sun visors. Clip in frame trim -6- for sunroof. Carry out remainder of installation in reverse order of removal.
2. Sun visor Unclip visor -2- from holder -3-, unclip cap -8- and remove screw -7-.
3. Sun visor holder Press holder for sun visor firmly to one side and pull out.
4. Center sun visor Removing, see «REMOVING CENTER SUN VISOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim)
5. Screw Tightening torque: 2.5 Nm (22 in lb)
6. Frame trim for sliding roof Pry out at markings -11-.
7. Screw
8. Cap
9. Cap
10. Frame for molded headliner cut-out
11. Markings for prying out frame trim.

1. Pry out cover panel for molded headliner cut-out -1- at locations -4-.
2. Pry out cover for interior light -3- at locations -5-.

1. Molded headliner removed

1. Cut out frame for molded headliner -1-at screw -2- (line -4-).
2. Remove screw -2-.
3. Carefully open sheet metal bracket -3- and remove center sun visor.

The following list pertains to see scheme 104.

1. Back of molded headliner Molded headliner removed (lowered onto seats). Disconnect connector -4-. Disconnect connectors -5-. Disconnect connector -6-. Detach adhesive tape -8-. Unclip wiring ducts -3-. Guide out wiring harness -2- through wiring guide -7-. When installing, secure wiring for sun visors with adhesive tape -8-.
2. Wiring harness
3. Wiring duct (6x)
4. Connector for rear interior light
5. Connectors for sun visor light
6. Connector for interior light
7. Wiring guide
8. Adhesive tape for securing wiring

USA molded headliner with deformation elements (from calendar week 36.02)

The following list pertains to see scheme 105.

1. Molded headliner Removing molded headliner. See «ROOF TRIM (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Front deformation element
3. Center deformation element
4. Rear deformation element

Scheme 19

Molded headliner and sun visors (Avant), removing and installing

The following list pertains to see scheme 106.

1. Molded headliner Removing: Remove upper A-pillar trim. See «TRIM PANELS (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Detach wiring harness to molded headliner between A-pillar and instrument panel on left side. Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-removing-and-installing) . Remove upper C-pillar trim. See «TRIM PANELS (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove upper D-pillar trim. See «UPPER D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-d-pillar-trim-removing-and-installing) . Remove roof frame trim panel. See «ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim) . Detach connector if interior mirror is of automatic anti-glare type. Remove sun visors -7-. Remove holders -5- for sun visors. On models with sunroof, pry out frame trim panel -4-. Remove cover for molded headliner cut-out and reading lamp. See «REMOVING AND INSTALLING COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LIGHT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-and-installing-cover-for-molded) . On models with sunroof: Remove screws -10-(3x). On models without sunroof: Remove screws -10-(2x). Tilt backrest of passenger seat as far back as possible. Tilt backrest of driver's seat as far back as possible. A second person is required to support the molded headliner. Detach Velcro fasteners at cut-out for rear interior light. See «DETACHING VELCRO FASTENERS»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-velcro-fasteners) . Unclip molded headliner at the rear. To detach wiring from molded headliner, get out of the vehicle and carefully lower molded headliner onto seats. Detach wiring harness from molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (AVANT), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . Remove molded headliner through tailgate. Installing Carefully insert molded headliner through tailgate. Attach wiring harness to molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (AVANT), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wiring-on-back-of-molded-headliner) . NOTE: Make sure to follow installation sequence, otherwise roof trim cannot be centered. Attach molded headliner at rear. Clip in holders for sun visors. Clip in frame trim -4- for sunroof. Carry out remainder of installation in reverse order of removal.
2. Clip (on back of headliner)
3. Markings for prying out frame trim
4. Frame trim for sliding roof Pry out at markings -3-.
5. Sun visor holder Press holder for sun visor firmly to one side and pull out.
6. Cap
7. Sun visor Unclip sun visor -7- from holder -5-, unclip cap -8- and remove screw -9-.
8. Cap
9. Screw
10. Screw Tightening torque: 2.5 Nm (22.5 in lb)
11. Center sun visor Removing, see «REMOVING CENTER SUN VISOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim)
12. Frame for molded headliner cut-out

Removing and installing cover for molded headliner cut-out and interior light

1. Pry out cover panel for molded headliner cut-out -1- at locations -4-.
2. Pry out cover for interior light -3- at locations -5-.

Detaching Velcro fasteners

1. Detach bars -1- (2x) from Velcro fasteners -2- (2x) at cut-out for rear interior light.

1. Molded headliner removed

1. Cut out frame for molded headliner -1-at screw -2- (line -4-).
2. Remove screw -2-.
3. Carefully open sheet metal bracket -3- and remove center sun visor.

Wiring on back of molded headliner (Avant), routing

The following list pertains to see scheme 110.

1. Back of molded headliner Molded headliner removed (lowered onto seats). Disconnect connector -3-. Disconnect connectors -9-. Disconnect connector -2-. Detach adhesive tape -8-. Unclip wiring ducts -5-. Guide out wiring harness -6- through wiring guide -7-. When installing, secure wiring for sun visors with adhesive tape -8-.
2. Connector for interior light
3. Connector for rear interior light
4. Clip
5. Wiring duct (6x)
6. Wiring harness
7. Wiring guide
8. Adhesive tape for securing wiring
9. Connectors for sun visor light

Note. Removing and installing A-pillar trim for vehicles with and without side curtain airbag is the same.

The following list pertains to see scheme 111.

1. Molded headliner Removing: Remove upper A-pillar trim. See «TRIM PANELS (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Detach wiring harness to molded headliner between A-pillar and instrument panel on left side. Remove intermediate piece at B-pillar trim. See «TRIM FOR SIDE CURTAIN AIRBAG (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove roof frame trim. See «ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim) . Remove upper D-pillar trim. See «UPPER D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-d-pillar-trim-removing-and-installing) . Remove roof frame trim. See «ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim) . Detach connector if interior mirror is of automatic anti-glare type. Remove sun visors -7-. Remove holders -5- for sun visors. On models with sunroof, pry out frame trim -4-. Remove cover for molded headliner cut-out and reading lamp. See «REMOVING AND INSTALLING COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LIGHT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . On models with sunroof: Remove screws -10-(3x). On models without sunroof: Remove screws -10-(2x) Tilt backrest of passenger seat as far back as possible. Tilt backrest of driver's seat as far back as possible. A second person is required to support the molded headliner. Detach Velcro fasteners at cut-out for rear interior light. See «DETACHING VELCRO FASTENER»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__detaching-velcro-fastener) . Unclip molded headliner at the rear. To detach wiring from molded headliner, get out of the vehicle and carefully lower molded headliner onto seats. Detach wiring harness from molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (AVANT), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove molded headliner through tailgate. Installing Carefully insert molded headliner through tailgate. Attach wiring harness to molded headliner. See «WIRING ON BACK OF MOLDED HEADLINER (AVANT), ROUTING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . NOTE: Make sure to follow installation sequence, otherwise roof trim cannot be centered. Attach molded headliner at rear. Clip in holders for sun visors. Clip in frame trim -4- for sunroof. Carry out remainder of installation in reverse order of removal.
2. Clip (on back of headliner)
3. Markings for prying out frame trim
4. Frame trim for sliding roof Pry out at markings -3-.
5. Sun visor holder Press holder for sun visor firmly to one side and pull out.
6. Cap
7. Sun visor Unclip sun visor -7- from holder -4-, unclip cap -8-and remove screw -9-.
8. Cap
9. Screw
10. Screw Tightening torque: 2.5 Nm (22 in lb)
11. Center sun visor Removing, see «REMOVING CENTER SUN VISOR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim)
12. Frame for molded headliner cut-out

1. Pry out cover panel for molded headliner cut-out -1- at locations -4-.
2. Pry out cover for interior light -3- at locations -5-.

Detaching Velcro fastener

1. Detach bars -1- (2x) from Velcro fasteners -2- (2x) at cut-out for rear interior light.

1. Molded headliner removed

1. Cut out frame for molded headliner -1- at screw -2- (line -4-).
2. Remove screw -2-.
3. Carefully open sheet metal bracket -3- and remove center sun visor.

The following list pertains to see scheme 115.

1. Back of molded headliner Molded headliner removed (lowered onto seats). Disconnect connector -3-. Disconnect connectors -9-. Disconnect connector -2-. Detach adhesive tape -8-. Unclip wiring ducts -5-. Guide out wiring harness -6- through wiring guide -7-. When installing, secure wiring for sun visors with adhesive tape -8-.
2. Connector for interior light
3. Connector for rear interior light
4. Clip
5. Wiring duct (6x)
6. Wiring harness
7. Wiring guide
8. Adhesive tape for securing wiring
9. Connectors for sun visor light

With sunroof

1. Molded headliner Removing molded headliner. See «ROOF TRIM (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Center deformation element
3. Front deformation element

Without sunroof

1. Molded headliner Removing molded headliner, see «ROOF TRIM (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Front deformation element
3. Center deformation element

Upper A-pillar trim, removing and installing

The following list pertains to see scheme 118.

1. Upper A-pillar trim Removing Pivot down flap -4- on roof grab handle -5- at groove -7-. Roof grab handle can be secured in the 'down' position by opening flap -4-fully. Remove screws -2- (2x) Unclip A-pillar trim -1- starting at the top. Pull out trim and rotate upward. On models with hands-free telephone function, disconnect connector for hands-free unit. Installing Route wiring and connector for hands-free telephone unit from bottom to top. CAUTION: Take care not to damage wiring for hands-free unit when clipping in trim. Insert trim -1- with clips -3- (4x) in mounts -6-. For ease of installation, unclip sun visor and move it to lengthways position. Insert pin -9- in mount -10-. Clip in trim -1- and install door seal over A-pillar trim.
2. Screws (2x)
3. Clips (4x)
4. Flap for roof grab handle
5. Roof grab handle
6. Mounts
7. Groove
8. Seal After installing make sure seal is correctly seated
9. Pin
10. Mount

Lower A-pillar trim, removing and installing

1. Pry out cover -1-.
2. Remove screws -2- (2x). Tightening torque: 2.5 Nm (22 in lb)
3. Pull lower A-pillar trim in direction of -arrow A- until pin -3- can be detached from groove -4-.
4. Pull extension of lower A-pillar trim in direction of -arrow B- out of retainers (2x).

Removing foot rest

1. Remove lower A-pillar trim. See «LOWER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-a-pillar-trim-removing-and-installing) .
2. Remove nut-1-. Tightening torque: 4 Nm (35 in lb)
3. Press foot rest -2- upward and remove.

Removing foot rest support bracket

1. Remove foot rest.
2. Fold back floor covering around foot rest support bracket.
3. Remove nut -4- (2x). Tightening torque: 4 Nm (35 in lb)
4. Remove foot rest support bracket -3-.

Sill panel trim, removing

1. Removing lower A-pillar trim, see «LOWER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-a-pillar-trim-removing-and-installing) .
2. Unclip (3x) sill panel trim -1-at front.
3. Detach sill panel trim -1- from lower B-pillar trim -2- at retainer -5-.
4. Unclip (2x) sill panel trim -1- at rear.
5. Detach sill panel trim -1- from lower B-pillar trim -2- at retainer -4-.
6. Detach sill panel trim -1- from lower B-pillar trim -2- at retainer -3-.

Upper B-pillar trim, removing and installing

The following list pertains to see scheme 122.

1. B-pillar trim Removing Remove outer seat belt attachment point. Unfasten roof grab handle at upper A-pillar trim. See «TRIM PANELS (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim). Unfasten roof grab handle and coat hook at upper C/D-pillar trim. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing). Pull clips -2- on trim -1-out of mounts -4- at the top. Detach retainers -5- upward from lower B-pillar trim -6-. Installing Engage retainers -5- on trim -1-in lower B-pillar trim -6-. NOTE: Do not press height adjustment fitting when installing. Insert actuating button for height adjuster -7- in height adjuster -3- see scheme 123Insert clips -2- (2x) on trim -1-in mounts -4-. Clip on and secure trim. After installing make sure seal is correctly seated NOTE: Check operation after installing trim. Height adjuster must engage audibly in each of the 5 possible positions (including top position). Each time the height adjustment fitting is pressed it should return by itself to the "up" position.
2. Clip
3. Height adjuster
4. Mounts
5. Retainer
6. Lower B-pillar trim
7. Actuating button for height adjuster

Attaching upper B-pillar trim at belt height adjuster

1. Move slide with actuating button -4- (do not press button) downward toward release -1- of height adjuster and at the same time insert pin -2- in mount -3-.

Lower B-pillar trim, removing and installing

The following list pertains to see scheme 124.

1. 1-B-pillar trim Removing NOTE: The outer seat-belt attachment point does not have to be removed when taking out the lower B-pillar trim. Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-removing-and-installing) . Remove sill panel trim. See «SILL PANEL TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__sill-panel-trim-removing) . Use screwdriver to press retainer tabs -4- (2x) outward. Pull up B-pillar trim in direction of arrow until it disengages at belt guide -2-. Disconnect connectors for pushbutton switches for trunk lid and interior monitoring. Installing Insert belt guide -2- from top into retainer -7-. Insert guide pins -3- and retainer tabs -4- into mounts -5- and -6-. After installing make sure seal is correctly seated
2. Belt guide
3. Guide pins
4. Retainer tabs
5. Mounts
6. Mounts
7. Retainer
8. Push-button switch for trunk lid Press retainer tabs and push out switch from behind. Install in position shown.
9. Push-button switch for interior monitoring Press retainer tabs and push out switch from behind. Install in position shown.

Upper C/D-pillar trim, removing and installing

The following list pertains to see scheme 125.

1. C/D-pillar trim Removing Open out coat hook and remove screw -3-. Pivot down flap -11- on roof grab handle -9- at groove -12-. Roof grab handle can be secured in the 'down' position by opening flap -11- fully. Remove screws -2- (2x) Unclip C/D-pillar trim -1-, starting at top. Installing Insert trim -1- in rearshelf mounts. Insert pin -10- on trim -1- in mount -6-. Insert clips -8- (7x) on trim -1- in mounts -5-. Clip trim -1- into place.
2. Screws (2x)
3. Screw (1x)
4. Coat hook
5. Mounts
6. Mount
7. Seal After installing make sure seal is correctly seated
8. Clip (7x)
9. Roof grab handle
10. Pin
11. Flap for roof grab handle
12. Groove

Rear wheel-housing trim, removing and installing

1. Remove sill panel trim. See «SILL PANEL TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__sill-panel-trim-removing) .
2. Remove rear seat bench. See «SEAT BENCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__seat-bench-removing-and-installing) .
3. Remove rear side padding. See «SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__side-padding-for-rear-seat-removing) .
4. Unclip upper C/D-pillar trim around wheel-housing trim.
5. Unclip wheel housing trim -1- at retaining clips -2- (2x).
6. Detach retainer -3- from mount -4-.
7. Guide pin -5-.

Rear shelf (folding backrest), removing and installing

The following list pertains to see scheme 127.

1. Rear shelf Removing Fold down backrest. Unbolt lower attachment points of rear left and right three-point seat belts. Remove rear left and right side padding. See «SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__side-padding-for-rear-seat-removing) . Unclip trim -7- and guide -6- for rear left and right three-point seat belts. Remove upper C/D-pillar trim on left and right. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) . For vehicles with flap in parcel shelf: Open flap -8- beneath high-mount brake light -5-(access via luggage compartment). For all vehicles: Unclip high-mount brake light -5- by unfastening spring -4- (access via luggage compartment). On vehicles with electric sun shade, loosen screws in luggage compartment, see «SCREWS SECURING ELECTRICAL SUN SHADE IN LUGGAGE COMPARTMENT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__screws-securing-electrical-sun-shade-in) . Pull rear shelf -1- forward in direction of arrow and unclip rear shelf -1- at clip -2- (3x). On vehicles with electric sun shade, disconnect connector for sun shade. Remove rear shelf -1- upward and forward. Installing When installing, press down rear shelf -1- slightly until clips -3- (3x) and springs -4- (2x) engage. Engage clips -2- (3x). Perform remaining installation steps in reverse order of removal.
2. Clip (3x)
3. Clip (3x)
4. Spring
5. High-mount brake light
6. Guide
7. Trim
8. Flap

Rear shelf (fixed backrest), removing and installing

The following list pertains to see scheme 128.

1. Rear shelf Removing Unbolt lower attachment points of rear left and right three-point seat belts. Unbolt lower attachment point -8- for center three-point seat belt -9-. Remove backrest. See «FIXED BACKREST, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__fixed-backrest-removing-and-installing) . Unclip trim -7- and guide -6- for rear left and right three-point seat belts. Remove upper C/D-pillar trim on left and right. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) . For vehicles with flap in parcel shelf: Open flap -8- beneath high-mount brake light -5- (access via luggage compartment). For all vehicles: Unclip high-mount brake light -5- by unfastening spring -4- (access via luggage compartment). On vehicles with electric sun shade, loosen screws in luggage compartment. See «SCREWS SECURING ELECTRICAL SUN SHADE IN LUGGAGE COMPARTMENT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__screws-securing-electrical-sun-shade-in) . Pull rear shelf -1- forward in direction of arrow and unclip rear shelf -1- at clip -2- (3x). Unclip trim and guide -10-for center three-point seat belt from the rear. On vehicles with electric sun shade, disconnect connector for sun shade. Remove rear shelf -1- upward and forward. Installing When installing, press down rear shelf -1- slightly until clips -3- (3x) and springs -4- (2x) engage. Engage clips -2- (2x). Perform remaining installation steps in reverse order of removal.
2. Clip (3x)
3. Clip (3x)
4. Spring
5. High-mount brake light
6. Trim
7. Guide
8. Flap
9. Bolt (1x) Tightening torque: 55 Nm (41 ft lb)
10. Webbing
11. Guide

Screws securing electrical sun shade in luggage compartment

1. Loosen screws -1- (3x). Tightening torque: 4 Nm (35 in lb)

Electric sun shade on rear window, removing and installing

The following list pertains to see scheme 130.

Note. Illustration shows back of rear shelf.

1. Rear shelf
2. Electric sun shade Remove rear shelf. With folding backrest, see «REAR SHELF (FOLDING BACKREST), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-shelf-folding-backrest-removing-and) . With fixed backrest, see «REAR SHELF (FIXED BACKREST), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-shelf-fixed-backrest-removing-and) . Take hold of cover plate with wheel -6- on each side, and pull out sun shade approx. 50 mm. Wedge a suitable object between sun shade and rear shelf. Loosen screws -5- (2x). Pull out cover plate with wheel -6- in direction of arrow. Remove nut -4- (8x). Remove sun shade -2
3. Connector
4. Nuts (8x)
5. Screws (2x)
6. Cover plate with wheel

Rear lid trim, removing and installing

The following list pertains to see scheme 131.

1. Rear lid trim
2. Remove hazard warning triangle. Remove screws -4- (2x). Remove bracket for hazard warning triangle -5-. Remove screws -2- (2x). Remove screws -3- (2x). Unclip trunk lid trim -1- from underneath.
3. Screws (2x) Tightening torque: 1.5 Nm (13 in lb)
4. Screws (2x) Tightening torque: 1.5 Nm (13 in lb)
5. Screws (2x) Tightening torque: 1.5 Nm (13 in lb)
6. Bracket for hazard warning triangle

Rear cross panel trim, removing and installing

The following list pertains to see scheme 132.

1. Rear cross panel trim Remove trunk light from rear cross panel trim -1-. Remove screws -2- (2x). Remove screws -3- (4x) from fastening rings -4- on left and right. Unclip rear cross panel trim -1- upward. Guide trunk light through opening. After installing make sure seal is correctly seated
2. Screws (2x) Tightening torque: 2 Nm (18 in lb)
3. Screws (4x) Tightening torque: 4.5 Nm (40 in lb)
4. Fastening rings

Luggage compartment side trim (fixed rear seat)

The following list pertains to see scheme 133.

1. Luggage compartment trim Remove luggage compartment floor covering. Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-cross-panel-trim-removing-and) . Remove screws -7- (2x) for fastening rings -8-. Unclip clips -5- (2x). Unclip clip -3-. Unclip clip -4-. Remove cover -2-. Unclip luggage compartment trim -1- at rear. Pull luggage compartment trim -1- upward out of retaining clips -9- (2x). Pull out luggage compartment trim -1- behind back panel trim.
2. Cover
3. Clip
4. Clip
5. Clips (2x)
6. Mounts
7. Screws (2x) Tightening torque: 4.5 Nm (40 in lb)
8. Fastening rings
9. Retaining clip

Luggage compartment side trim (split rear seat)

The following list pertains to see scheme 134.

1. Luggage compartment trim Remove respective backrest. See «RIGHT (2/3) SECTION OF BACKREST, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__disconnecting-engine-compartment-wiring-harness) . Remove respective side padding. See «SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__side-padding-for-rear-seat-removing) . Remove luggage compartment floor covering. Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-cross-panel-trim-removing-and) . Remove screws -6- (2x) for fastening rings -7-. Unclip clip -3-. Unclip clip -4-. Remove cover -2- Unclip luggage compartment trim -1- at rear from mounts -5- (3x). Pull trim forward to disengage from latch pin.
2. Cover
3. Clip
4. Clip
5. Mounts
6. Screws (2x) Tightening torque: 4.5 Nm (40 in lb)
7. Fastening rings

Back panel trim, removing and installing

The following list pertains to see scheme 135.

1. Back panel trim with ski bag Remove ski bag. Remove luggage compartment floor covering. Remove clips -3- (7x).
2. Back panel trim without ski bag Remove luggage compartment floor covering. Remove clips -3- (7x).
3. Clip

Scheme 20

1. Removing and installing front left/right seat. See «SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__seat-removing-and-installing).
2. Remove rear seat bench. See «SEAT BENCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__seat-bench-removing-and-installing).
3. Remove sill panel trim. See «SILL PANEL TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__sill-panel-trim-removing).
4. Remove rear section of center console. See «CENTER CONSOLE (REAR SECTION), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-console-rear-section-removing-and).
5. Remove front section of center console. See «CENTER CONSOLE (FRONT SECTION), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__center-console-front-section-removing-and).
6. Remove glove box. See «GLOVE BOX, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__glove-box-removing-and-installing).
7. Remove brace on passenger side.
8. Remove bolts -1- (2x). see scheme 136 Tightening torque: 12 Nm (9 ft lb)
9. Remove bolts -2- (2x). see scheme 136 Tightening torque: 12 Nm (9 ft lb)
10. Remove brace.
11. Remove driver's storage compartment. See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing).
12. Unbolt brace on driver's side.
13. Remove bolts -A-, -B- and -C-. see scheme 137
14. Detach wiring harness -D- from brace.
15. To remove floor covering, carefully pull brace away slightly on driver's side and wedge a block of wood or similar between brace and heating unit.
16. Remove lower left and right A-pillar trim. See «LOWER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-a-pillar-trim-removing-and-installing).
17. Remove foot rest. See «FOOT REST AND FOOT REST SUPPORT BRACKET, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim).
18. Unbolt outer seat-belt attachment point.
19. On vehicles with automatic transmission, remove locking cable at lever bracket.
20. See «LOCKING CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01l-awd).
21. Remove air ducts at center console.
22. Remove air ducts at center section of instrument panel.
23. Detach wiring for rear vents at tunnel and attach wiring to instrument panel (or steering wheel).
24. Pull parking brake up as far as it will go.
25. Move gear shift/selector lever as far back as possible.
26. Detach floor covering from seat rail and rear footwell vent.
27. Pull out floor covering beneath lower C-pillar trim.
28. Lift rear section of floor covering over parking brake lever.
29. Pull floor covering over bracket in front of airbag control module.
30. Pull floor covering backward and lift over gear shift/selector lever.
31. Fold floor covering lengthwise and remove through door.

1. Fold new floor covering lengthwise and place in vehicle. NOTE: Floor covering is likely to tear at cut-outs.
2. Push floor covering forward as far as it will go until hole patterns for accelerator pedal stop and foot rest are aligned.
3. Press floor covering under parking brake lever.
4. Carry out remainder of installation in reverse order of removal.

Upper C-pillar trim, removing and installing

The following list pertains to see scheme 138.

1. C-pillar trim Removing On vehicles with children's bench, see «VEHICLES WITH SEAT BELT FOR CHILDREN'S BENCH»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__vehicles-with-seat-belt-for-childrens) . Pull down coat hook -5- and remove screw -4-. Remove screw -3- from front mount -6- for partition grill. Pull down flap -8- on roof grab handle -7- at groove -9-. Roof grab handle can be secured in the 'down' position by opening flap -8- fully. Remove screws -2- (2x). Remove screw -12- from rear mount for partition grill -10-. Remove trim plate for seat belt. See «REMOVING AND INSTALLING TRIM PIECE FOR SEAT BELT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-and-installing-trim-piece-for) . Remove screw -14-. Unclip D-pillar trim -11- from C-pillar trim -1- (2x). Carefully pull away D-pillar trim -11-. Unclip C-pillar trim -1-, working from the top downward. Installing Push C-pillar trim in behind D-pillar trim. Insert clips -13- on trim -1- into mounts. Clip trim -1- into place. Remainder of installation is carried out in reverse order of removal.
2. Screws (2x) Tightening torque: 2.5 Nm (22 in lb)
3. Screw (1x) Tightening torque: 5 Nm (44 in lb)
4. Screw (1x) Tightening torque: 2.5 Nm (22 in lb)
5. Coat hook
6. Front mount for partition grill
7. Roof grab handle
8. Flap for roof grab handle
9. Groove
10. Rear mount for partition grill
11. D-pillar trim
12. Screw (1x) Tightening torque: 5 Nm (44 in lb)
13. Clip
14. Screw (1x) Tightening torque: 2.5 Nm (22 in lb)

Vehicles with seat belt for children's bench

1. Remove bolt -4- at base frame. Tightening torque: 55 Nm (41 ft lb)
2. Compress trim piece -2- at cut-out below seat belt, and pry out trim piece -2- with a screwdriver.
3. After removing C-pillar trim -1-, guide belt -3- out through C-pillar trim -1-.

Removing and installing trim piece for seat belt

1. Using a screwdriver, pry out retaining tabs -2- (2x).
2. Pull out seat belt trim piece -1- in direction of arrow.
3. Guide seat belt out through trim piece -1-.

Upper D-pillar trim, removing and installing

The following list pertains to see scheme 141.

1. D-pillar trim Removing Remove screw -4- from rear mount -5- for partition grill. Remove bolt -3- (1x). Unclip D-pillar trim -1-, working from the top downward. Lift D-pillar trim out of cargo area side trim. Installing Insert D-pillar trim behind cargo area side trim. Insert clips -6- on trim -1- into mounts. Clip trim -1- into place. Remainder of installation is carried out in reverse order of removal.
2. Mount for cargo area cover
3. Screw (1x) Tightening torque: 2.5 Nm (22 in lb)
4. Screw (1x) Tightening torque: 5 Nm (44 in lb)
5. Rear mount for partition grill
6. Clip

Cargo area side trim

The following list pertains to see scheme 142.

1. Cargo area trim Installing Remove cargo area cover. Remove rear bench seat. See «SEAT BENCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__seat-bench-removing-and-installing) . Remove respective side padding. See «SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__side-padding-for-rear-seat-removing) . Detach seat belt from bottom attachment. Remove trim plate for seat belt. See «REMOVING AND INSTALLING TRIM PLATE FOR SEAT BELT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__removing-and-installing-trim-plate-for) . Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove screws -4- (2x) for fastening rings -3-. Remove cover -2-. Remove screw -6- (1x). Remove bolt -7-. Unclip trim at rear. Pull trim slightly toward the front, and disconnect connector for rear electrical socket. Installing Engage cargo area trim behind side window flange. Remainder of installation is carried out in reverse order of removal.
2. Cover
3. Fastening rings
4. Screw (2x) Tightening torque: 4.5 Nm (40 in lb)
5. Mount for cargo area cover
6. Screw (1x) Tightening torque: 2.5 Nm (22 in lb)
7. Screw (1x) Tightening torque: 2.5 Nm (22 in lb)

Removing and installing trim plate for seat belt

1. Using a screwdriver, pry out retaining tabs -2- (2x).
2. Pull out seat belt trim -1- in direction of arrow.
3. Guide seat belt out through trim plate -1-.

Rear electrical socket, removing

1. Remove cargo area side trim, see «CARGO AREA SIDE TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__cargo-area-side-trim) .
2. Disconnect connector -3-.
3. Release retaining tabs -2- and -4- and remove rear electrical socket -1-.

Partition grill, removing and installing

The following list pertains to see scheme 145.

1. Partition grill Removing Fold down both rear backrests. Press partition grill -1- from 1/3 backrest toward 2/3 backrest -4-. Remove partition grill. Installing Install retainer -2- into slot in 2/3 backrest. Lift 2/3 backrest slightly, and at the same time press partition grill -1- toward 1/3 backrest.
2. Retainer
3. Mount
4. 2/3 backrest

Tailgate trim, removing and installing

The following list pertains to see scheme 146.

1. Tailgate trim (bottom section) Removing Remove bolt -3- (1x). Remove screw behind warning triangle. See «SCREW BEHIND WARNING TRIANGLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__screw-behind-warning-triangle) . Pull bottom section of trim -1- away from tailgate slightly. Using a screwdriver, release clips -6- (8x) on bottom section of trim -1-. Push out light -8- from inside. Disconnect connector for light -8-. Installing Locate bottom section of trim -1- at rear window first, and clip into place. Make sure that screw -3- also secures grip molding -4- (shown in inset A).
2. Tailgate trim (top section) Bottom section of trim -1- removed Removing Unclip retainers -7- on both sides. Release clips -6- (7x) on top section of trim -2- by pulling sharply (do not use excessive force). Installing Before installing top section of trim -2-, make sure that rubber buffers -5- (10x) are installed properly. First install top section of trim -2- into place behind side flanges on tailgate. Then clip in top section of trim -2- at the top, and finally at the sides.
3. Screw (1x) Tightening torque: 5 Nm (44 in lb)
4. Grip molding
5. Rubber buffer (10x)
6. Clip
7. Retainer
8. Light

Tailgate trim (sun shade), removing and installing

The following list pertains to see scheme 147.

1. Tailgate trim (bottom section) Removing Remove sun shade. See «SUN SHADE ON TAILGATE (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__sun-shade-on-tailgate-avant-removing) . Remove screws -5- (4x). Remove screw -3- (1x); (2x) in vehicles with children's bench. Remove screw behind warning triangle. See «SCREW BEHIND WARNING TRIANGLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__screw-behind-warning-triangle) . Pry out trim plate -13- with a screwdriver. Pull bottom section of trim -1- away from tailgate slightly. Using a screwdriver, release clips -11- (8x) on bottom section of trim -1-. Push out light -12- from inside. Disconnect connector for light -12-. Installing Locate bottom section of trim -1- at rear window first, and clip into place. Make sure that screw -3- also secures grip molding -4-. Vehicles with children's bench: When installing grip molding, press in operating lever and screw parts together. Check operation after assembly.
2. Tailgate trim (top section) Bottom section of trim -1- removed Removing Remove caps -8- (2x). Remove screws -9- (2x). Remove mounts -10- (2x) for sun shade. Unclip retainers -7- on both sides. Release clips -11- (7x) on top section of trim -2- by pulling sharply (do not use excessive force). Installing Before installing top section of trim -2-, make sure that rubber buffers -6- (10x) are installed properly. Install top section of trim -2- into place behind side flanges on tailgate first. Then clip in top section of trim -2- at the top, and then at the sides.
3. Screw (1x) Tightening torque: 5 Nm (44 in lb) Vehicles with children's bench have two screws -3- instead of one screw: Tightening torque 8 Nm (71 in lb)
4. Grip molding
5. Screws (4x) Tightening torque: 2 Nm (18 in lb)
6. Rubber buffer (10x)
7. Retainers
8. Cap
9. Screws (2x)
10. Mounts (2x)
11. Clip
12. Light
13. Trim cap

Screw behind warning triangle

1. Open flap -1- for warning triangle on tailgate trim -2-.
2. Remove warning triangle.
3. Push Velcro strip -3- clear to the side.
4. Remove screw -4-. Tightening torque: 2.5 Nm (22 in lb)

Sun shade on tailgate (Avant), removing and installing

The following list pertains to see scheme 149.

1. Tailgate trim (bottom section)
2. Sun shade Removing Using a suitable plastic tool -5-, pry out sun shade -2- at the sides. Remove screws -3- (2x). Installing Secure fastening strap -4- with screws -3- (2x). Press sun shade -2- into bottom section of tailgate trim along full length.
3. Screws (2x) Tightening torque: 2.5 Nm (22 in lb)
4. Fastening strap
5. Plastic tool

Roof frame trim

The following list pertains to see scheme 150.

1. Roof frame trim Remove upper D-pillar trim on both sides. See «UPPER D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-d-pillar-trim-removing-and-installing) . Remove screws -2- (2x). Using a screwdriver, release clips -3- (4x) on roof frame trim -1-.
2. Screws (2x) Tightening torque: 2.5 Nm (22 in lb)
3. Clip

1. Remove screws -2- (4x). Tightening torque: 3 Nm (27 in lb)
2. Remove rear cross panel trim -1-.
3. After installing rear cross panel trim, make sure that tailgate seal is positioned over rear cross panel trim.

Spare wheel cover support, removing and installing

1. Remove rear cross panel trim, see «REAR CROSS PANEL TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Remove screws -2- (3x). Tightening torque: 5 Nm (44 in lb)
3. Remove support for spare wheel cover -1-.

Cargo area floor trim and supports (Avant), removing and installing

The following list pertains to see scheme 153.

1. Cargo area floor covering (front) Remove screws -2- (4x) for fastening rings -3-.
2. Screws (2x) Tightening torque: 4.5 Nm (40 in lb)
3. Fastening rings
4. Support for cargo area floor covering (front wheel drive models) Remove front floor covering -1-. Pull out rear floor covering -7- toward the rear. Remove cargo area side trim on one side. See «CARGO AREA SIDE TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__cargo-area-side-trim) . Remove support -4- for floor covering.
5. Support for cargo area floor covering (quattro models) Pull out rear floor covering -7- toward the rear. Detach the two side floor coverings -8- and -6- (left and right). Supports -5- for floor covering are secured with butyl cord. Remove supports -5- for floor covering.
6. Cargo area floor covering (side) Secured with adhesive tape
7. Cargo area floor covering (rear) Pull out toward the rear.
8. Cargo area floor covering (side) Secured with adhesive tape

Cargo area floor trim and supports (vehicles with children's bench), removing and installing

The following list pertains to see scheme 154.

1. Cargo area floor covering Children's bench removed Carefully pry out inserts -2- and -3- with a screwdriver. Remove screws -5- for fastening rings -4-. Remove cargo area floor covering -1-.
2. Insert (large) Pry out carefully with screwdriver. Installed at front left
3. Inserts (small) (2x) Pry out carefully with screwdriver. Installed at left rear and right front
4. Fastening rings
5. Screws (4x) Tightening torque: 4.5 Nm (40 in lb)
6. Cover for spare wheel well
7. Trim for seat belt buckle Unclip and lift out
8. Lining for spare wheel well
9. Cover for spare wheel
10. Support for cargo area floor covering Lift out
11. Base frame Removing, see «CHILDREN'S BENCH BASE FRAME (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__childrens-bench-base-frame-avant-removing) .

Fastening bracket ring

Note. Brackets for the fastening rings are only installed in front-wheel drive models; quattro models have base plate -6-.

The following list pertains to see scheme 155.

1. Fastening bracket tie down
2. Remove screws -5- (4x).
3. Remove eyelets -4-.
4. Remove cargo area floor covering -3-.
5. Remove screws -2- (2x).
6. Screws (2x) Tightening torque: 4.5 Nm (40 in lb)
7. Cargo area floor covering
8. Fastening rings
9. Screws (2x) Tightening torque: 4.5 Nm (40 in lb)
10. Base plate Arrow- points in direction of travel.

A-pillar trim upper section, removing and installing

The following list pertains to see scheme 156.

1. Upper A-pillar trim For vehicles equipped with hands-free microphone, cut-out for microphone must be cut out using workshop tools when installing new part. Mark microphone position on inner side of trim Removing Remove intermediate piece for B-pillar trim (Sedan). See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) or «TRIM FOR SIDE CURTAIN AIRBAG (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Removal sequence when only removing A-pillar trim (e.g. windshield replacement): Remove front grab handle -2-. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) . Remove rear grab handle. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) . For sedan: remove coat hook and bolt under coat hook. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) ; Item no. -6- and -4-. For Avant: remove bolt at attachment hook for separation grill. See «TRIM FOR SIDE CURTAIN AIRBAG (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) , item -6- Remove A-pillar and D-pillar trim and/or roof frame trim from headliner embedding. Press screw-mounted strap of A-pillar trim upward and screw-mounted strap of D-pillar trim downward. Lift screw-mounted strap of A-pillar trim above screw-mounted strap of D-pillar trim. Removal sequence when removing A-pillar trim and D-pillar trim (e.g. replacing headliner, replacing airbag unit): Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-removing-and-installing) . For Avant: remove roof frame trim panel. See «ROOF FRAME TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim-removing) . Remove front grab handle -2-. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) . For all models: Remove metal disk -10- from front cutout of A-pillar trim panel -1- for grab handle using a small screwdriver Using a flat-headed screwdriver, pull out wire cable -9- at metal disc -10- (toward B-pillar, pull hard, about 40 mm) until A-pillar trim -1- disengages audibly. Disengage sun visor at inner catch and fold it parallel to direction of travel toward rear. NOTE: When removing A-pillar trim -1-, touch only sides facing headliner or windshield. Pull out lower A-pillar trim slightly at area of transition to upper A-pillar trim. Pull out trim panel -1- at upper B-pillar. Remove trim -1- from clip -7- by moving back and forth lightly. Unclip A-pillar trim at clips -3- and -4-. Pull out A-pillar trim -1- upward between instrument panel and tension bracket -5-. CAUTION: Always adhere to A-pillar trim installation sequence. Installing Remove clip -7- from A-pillar by pressing together center of clip (always replace clip). Insert new clamp -7- in A-pillar trim -1- and press in retaining clamp -8- (check to be sure it is securely installed). Clamp -7- must be positioned vertically to supporting surface. Tilt clamp -7- to check for secure fit. Clip in metal disc -10- at front cut-out of A-pillar trim -1- for grab handle. Protrusion must be next to clamp -8- (secure using hot glue). Insert A-pillar trim -1- between instrument panel and tension bracket at -5-. See «TENSION BRACKET AT A-PILLAR»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__tension-bracket-at-a-pillar) Position trim at clips. NOTE: When installing A-pillar trim, simply press on sides facing front window and headliner, do not bang or hit. Insert door sealing rubber -1- in lower clip -4- after clipping in trim. Press trim -1- at clip -7- until full engagement. Securely clip A-pillar trim -1- at clips -3- and -4-. CAUTION: Make sure trim is secured properly. Install grab handle. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) .
2. Front grab handle Removing, see «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) .
3. Clip Center (long)
4. Clip Lower (short)
5. Area between instrument panel and tension bracket
6. Bolts (2x) Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
7. Clip Always replace
8. Retaining clip
9. Wire cable
10. Metal disc

Scheme 21

Tension bracket at A-pillar

1. Tension bracket -1- presses A-pillar trim against instrument panel.
2. Be sure not to damage tension bracket -1- when removing and installing A-pillar trim. Disengage cable harness -2- at -3-. To remove, pull out clip -4-.

Intermediate piece at B-pillar and coat hook, removing and installing

The following list pertains to see scheme 158.

1. Intermediate piece Pry off cap -3-. Remove bolt -2-. Pull intermediate piece -1- up and out.
2. Bolt Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
3. Cover
4. Bolt Tightening torque: 3.5 Nm (31 in lb)
5. Self-locking
6. Always replace
7. Always clean threaded holes for bolts (e.g. using a tap)
8. For loose (threaded) inserts, tighten inserts using pliers.
9. Bolt Tightening torque: 2 Nm (18 in lb)
10. Coat hook Open coat hook -6-. Remove bolt -5-. Remove coat hook -6-.
11. Upper D-pillar trim panel
12. Upper A-pillar trim

B-pillar upper trim, removing and installing

The following list pertains to see scheme 159.

1. B-pillar upper trim Removing Remove outer seatbelt anchor. Remove intermediate piece for B-pillar trim. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) . Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-removing-and-installing) . Remove A-pillar trim. See «TRIM FOR SIDE CURTAIN AIRBAG (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove bolt -6-. Remove bolts -4- at brackets, left and right of B-pillar. Carefully press airbag unit -5- upward. Be sure not to damage airbag module with tools when removing. Remove bolt -2-. Remove bolt -3- (1x). Carefully pull out upper B-pillar trim under airbag module -5-. Disconnect harness connector for interior monitoring. See «DISCONNECTING CONNECTOR FOR INTERIOR MONITORING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__disconnecting-connector-for-interior-monitoring) Disengage retaining clips -10- upward, from lower B-pillar trim -9-. Remove 3-point seatbelt -11- from B-pillar trim. CAUTION: Always adhere to B-pillar trim installation sequence. Installing Insert trim -1- with retaining clips -10- in lower B-pillar trim -9-. Guide seatbelt height adjuster switch -12- into height adjuster assembly -8-. See «INSTALLING UPPER B PILLAR TRIM IN BELT HEIGHT ADJUSTER»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__installing-upper-b-pillar-trim-in) NOTE: Do not press switch -4- when installing. Carefully press airbag module -5- upward. Slide B-pillar trim up under airbag module -5-. Be sure not to damage airbag module with tools when installing. Install bolts -2-. Remove bolts -4- at bracket, on left and right of B-pillar. Rest of installation is reverse of removal. After assembling trim, make sure seal is properly installed NOTE: Function check after installing trim: Height adjuster must audibly engage into all five possible positions (even top position). Button must return by itself to upper position after being actuated.
2. Bolt Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
3. Bolt Tightening torque 2.5 Nm (22 in lb)
4. Bolts (2x) Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
5. Side curtain airbag
6. Bolt Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
7. Guide for side curtain airbag
8. Height adjustment
9. Lower B-pillar trim
10. Retaining tab
11. Three-point seatbelt
12. Button for height adjustment

Installing upper B pillar trim in belt height adjuster

1. Guide the slide with button -4- (without pressing) beginning at the top and working downward into release lever -1- of height adjuster while at the same time installing pin -2- into mount -3-.

Disconnecting connector for interior monitoring

1. Disengage connector for interior monitoring -A- by turning. 1 - B-pillar trim

C-pillar upper trim, removing and installing

The following list pertains to see scheme 162.

1. C-pillar upper trim Removing Remove intermediate piece for B-pillar trim. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) . Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-removing-and-installing) . Remove bolts -3- (3x). Remove bolts -5- at brackets, left and right of C-pillar. Carefully press airbag module -4- upward. Remove trim -1- from mounts -6- at retaining clips -2-. CAUTION: Always adhere to C-pillar trim installation sequence. Installing Carefully press airbag module -4- upward. Clip in trim -1- at mounts -6- using retaining clips -2-. CAUTION: Make sure trim is secured properly. Check for proper fit by pulling on upper edge of trim. Install bolts -5-. Install bolts -3-. Rest of installation is reverse of removal.
2. Retaining clip
3. Bolts (3x) Tightening torque: 3.5 Nm (31 in lb)
4. Side curtain airbag
5. Bolts (2x)
6. Mounting holes (2x)

D-pillar trim, removing and installing

The following list pertains to see scheme 163.

1. D-pillar trim Removing Remove appropriate headrest by pressing button at headrest guide hole. Remove intermediate piece for B-pillar trim. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) . Remove coat hook -6-. See «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) . Remove grab handle -2-. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) . Remove metal disk -10- from rear cut-out of D-pillar trim panel -1- for grab handle using a small screwdriver Using a flat-headed screwdriver, pull out wire cable -9- at metal disc -10- (toward B-pillar, pull hard, about 40 mm) until D-pillar trim -1- disengages audibly. NOTE: When removing D-pillar trim -1-, touch only side facing headliner or rear windshield. Remove trim -1- from clip -7- by moving back and forth lightly. Unclip trim from D-pillar -5-. CAUTION: Always adhere to D-pillar trim installation sequence. Installing Remove clip -7- from D-pillar by pressing together center of clip (always replace clip). Insert clamp -7- in D-pillar trim -1- and press in retaining clamp -8- (check to be sure it is securely installed). Clamp -7- must be positioned vertically to supporting surface. Tilt clamp -7- to check for secure fit. Clip in metal disc -10- at front cut-out of D-pillar trim -1- for grab handle. Protrusion must be next to clamp -8- (secure using hot glue). Position trim at clips. Guide D-pillar trim -1- into rubber door seal. Install grab handle -2-. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) . NOTE: When installing D-pillar trim, simply press on sides facing rear windshield or headliner, do not bang or hit. Press trim -1- at clip -7- until full engagement. Securely clip D-pillar trim -1- (3x). CAUTION: Make sure trim is secured properly.
2. Rear grab handle Removing, see «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-for-side-curtain) .
3. Bolts (2x) Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
4. Clip
5. D-pillar
6. Coat hook Removing, see «INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__intermediate-piece-at-b-pillar-and-coat) .
7. Clip Always replace
8. Retaining clip
9. Wire cable
10. Metal disc

Roof grab handle for side curtain airbag trim, removing and installing

1. Open cover -3-.
2. Remove bolts -2- (2x). Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
3. Remove roof grab handle -1-.

Upper A-pillar trim panel, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 165.

1. Upper A-pillar trim Removing Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-panel-removing-and) . Remove front grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Remove sun visor. See «ROOF TRIM (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove bolt at separating point for D-pillar. See «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Unclip upper A-pillar trim -1- at clips -3- and -2-. Pull out upper A-pillar trim -1- upward between instrument panel and tension bracket. WARNING: Always follow installation sequence for A-pillar trim Installing Insert upper A-pillar trim -1- between instrument panel and tension bracket. Position trim at clips. Securely clip upper A-pillar trim -1- at clips -2- and -3-. WARNING: Make sure trim has a proper fit. Thread in bolt with catch strap at separating point for D-pillar. See «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Install front grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Install upper B-pillar trim. See «UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-panel-removing-and) .
2. Clips (2x) Lower (short)
3. Clip Upper (long)
4. Upper B-pillar trim

Upper A-pillar trim panel without head-level airbag, removing and installing (from calendar week 36.02)

Removal of the upper A-pillar trim panel without head-level airbag is the same as in vehicles with head-level airbag without cover and with airbag marking.

The catch strap must be installed as in vehicles with head-level airbag, without bolting in the catch strap. See COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02) .

Remove upper A-pillar trim panel with head-level airbag. See TRIM PANELS FOR HEAD-LEVEL AIRBAG SEDAN (FROM CALENDAR WEEK 36.02) .

Scheme 22

Upper B-pillar trim panel, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 167.

1. B-pillar trim Removing Remove outer seatbelt anchor. Disengage upper B-pillar trim panel -1- at transition to lower B-pillar trim panel. To do so, pull the corners over the lower B-pillar trim panel. NOTE: For better clarity, the A-pillar is depicted without trim in the illustration. Pull upper B-pillar trim panel -1-downward out of guide -6-. Disconnect harness connector for interior monitoring see scheme 171 Press the catch strap -4- through the retaining tab at upper B-pillar trim panel -1-. WARNING: Always follow installation sequence for B-pillar trim Installing Pull the catch strap -4- through the retaining tab at upper B-pillar trim panel -1-. WARNING: The retaining tab must lie between the first and second elevation -3-. Ensure that catch strap -4- is installed securely. The green thread -5- must always face the vehicle interior. Insert button for height adjuster into height adjustment unit. See «DISCONNECTING CONNECTOR FOR INTERIOR MONITORING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) NOTE: Do not press button when installing. Slide upper B-pillar trim panel -1- with catches -2- upward into mounts -6-. Pull upper B-pillar trim panel -1-over lower B-pillar trim. After assembling trim, make sure seal is properly fitted NOTE: Function check after installing trim: Height adjuster must audibly engage into all five possible positions (even top position). Button must return by itself to upper position after being actuated.
2. Retaining tabs
3. Elevation on catch strap
4. Catch strap
5. Green thread
6. Mounts

1. Insert the slide with button -4- (without pressing) beginning at the top and working downward into release lever -1- of height adjustment unit while at the same time installing pin -2- into mounting -3-.

1. Disengage connector for interior monitoring -A- using a turning motion.

1 - B-pillar trim

Scheme 23

Upper C-pillar trim panel, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 170.

1. Upper C-pillar trim Removing Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-removing-and-installing) . Carefully press airbag module upward. Remove bolts -2- (3x). Remove trim panel -1-. WARNING: Always follow installation sequence for upper C-pillar trim: Installing: Carefully press airbag module upward. Press trim panel -1- with guide -3- into mount. Install screws -2-. Rest of installation is reverse order of removal
2. Screws (3x) Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.
3. Guide

D-pillar trim panel, removing and installing (from calendar week 36.02)

Scheme 24

The following list pertains to see scheme 172.

1. D-pillar trim Removing Remove the respective headrest. Remove front and rear grab handles. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Remove coat hook. See «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Remove screw at separating point for A-pillar. See «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Pull out D-pillar trim panel under A-pillar trim panel. See «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Unclip D-pillar trim panel -1- at positions -3- and -4-. Swing D-pillar trim panel -1- inward and pull catch strap -5- through opening at console -4-. Pull out D-pillar trim -1- from parcel shelf at retaining tabs -2-, using light back-and-forth motions. WARNING: Always follow installation sequence for D-pillar trim Installing Insert D-pillar trim -1- with retaining tabs -2- into parcel shelf, using light back-and-forth motions. WARNING: The catch strap -5- must lie above the head-level airbag. Ensure that catch strap -5- is installed securely. WARNING: The green thread -6- on catch strap -5- must face the vehicle interior. Pull catch strap -5- with retaining tab through the mount -4-. Clip in D-pillar trim panel -1- at positions -3- and -4-. Slide in D-pillar trim panel under A-pillar trim panel, see «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Install front and rear grab handles, see «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Install coat hook, see «COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__coat-hook-and-separating-point-at) . Insert D-pillar trim -1- into rubber door seal.
2. Catches (2x).
3. Clip
4. Mount with clip
5. Catch strap Replace after every airbag deployment. Catch strap -5- must stand between positions -A- (vertical, downward) or-B- (horizontal, toward front) after tightening screws -7-.
6. Green thread
7. Screw Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.

Coat hook and separating point at A-/D-pillar (from calendar week 36.02)

The following list pertains to see scheme 173.

1. Upper A-pillar trim Removing Pry off cap -3-. Remove screw -2-. Unclip upper A-pillar trim panel -1- and upper D-pillar trim panel -9- together at clip -12-. Pull out catch strap -10-from upper A-pillar trim panel at -4- Installing Slide catch strap -10- behind clip -12-into upper A-pillar trim panel -1-, at position -4-. WARNING: The green thread -11- must always face the vehicle interior. Securely clip upper A-pillar trim panel -1- and upper D-pillar trim panel -9- together at clip -12-. Securely bolt catch strap -10- with upper A-pillar trim panel -1- to upper D-pillar trim panel -9
2. Screw Tightening torque: 3.5 Nm
3. Concealment cap Always replace cap -3-if catches are faulty. Engage cap -3-in recess.
4. Position for catch strap
5. Screw Tightening torque: 3.5 Nm
6. Coat hook Open coat hook -6-. Remove bolt -5-. Remove coat hook -6
7. Screw Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.
8. Washer
9. Upper D-pillar trim panel
10. Catch strap
11. Green thread
12. Clip

Roof grab handle, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 174.

1. Deformation element
2. Screws (2x) Tightening torque: 3.5 Nm
3. Trim
4. Roof grab handle Open cover -6-. Remove screws -5- (2x). Remove roof grab handle -4-.
5. Screws (2x) Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.
6. Cover

Deformation element for trim panels with head-level airbag, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 175.

1. Deformation element Remove front roof grab handle -4-. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Remove upper A-pillar trim -3-. Remove screws -2- (2x). Disengage deformation element -1- up and out.
2. Screws (2x)
3. Trim
4. Roof grab handle
5. Screws (2x).

The following list pertains to see scheme 176.

1. Intermediate piece Pry off cap -3-. Remove bolt -2-. Pull intermediate piece -1- up and out.
2. Bolt Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
3. Cover Always replace cap -3- if catches are malfunctioning. Engage cap -3- in recess.
4. Coat hook Open coat hook -4-. Remove bolt -5-. Unclip coat hook -4-at catches -7-.
5. Bolt Tightening torque: 2 Nm (18 in lb)
6. Bolt Tightening torque: 5.5 Nm (49 in lb)
7. Locking lugs
8. Roof frame trim
9. Attachment eyelets for separation grill Belongs to roof frame delivery casing
10. Upper A-pillar trim

Roof frame trim, removing

The following list pertains to see scheme 177.

1. Roof frame trim Removing Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove intermediate piece at B-pillar. See «TRIM FOR SIDE CURTAIN AIRBAG (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove roof grab handle -2-. See «ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Open slider on attachment eyelets for separation grill. See «RELEASING ATTACHMENT HOOKS FOR SEPARATION GRILL»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__releasing-attachment-hooks-for-separation-grill) . Remove bolt -4-. Remove bolt -3- (1x). Wedge in a plastic wedge at upper B-pillar trim and upper C-pillar trim, see «WEDGING IN PLASTIC WEDGE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__wedging-in-plastic-wedge) NOTE: When removing roof frame trim -1-, touch only side facing headliner. Pull roof frame trim -1-out of rubber door seal. Pull roof frame trim -1-out under upper B-pillar trim and upper C-pillar trim. Carefully remove roof frame trim -1-. CAUTION: Always adhere to roof trim installation sequence. Installing Carefully guide roof frame trim -1-in under upper B-pillar trim and upper C-pillar trim. NOTE: When installing roof frame trim, press only on side facing headliner, do not bang or hit.
2. Roof grab handle
3. Bolt Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers
4. Bolt Tightening torque: 5.5 Nm (49 in lb)

Wedging in plastic wedge

1. Wedge in a plastic wedge -B- at B-pillar trim -A- and C-pillar trim to push away trim plates.

1. Roof frame trim

Releasing attachment hooks for separation grill

1. Slide on louver -3- in direction of arrow at groove -4-.

1. D-pillar trim
2. Attachment eyelets for separation grill

The following list pertains to see scheme 180.

Note. Removing and installing C-pillar trim item -1- is the same for vehicles with and without side curtain airbag.

1. C-pillar trim Removing Remove D-pillar trim. See «D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove roof frame trim panel. See «ROOF FRAME TRIM, REMOVING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim-removing) . For vehicles with child seat bench. See «WITH SEATBELT FOR CHILD SEAT»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__with-seatbelt-for-child-seat) Remove seatbelt cover. See «SEAT BELT TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__seat-belt-trim-removing-and-installing) Remove bolt -2-. Disengage C-pillar trim at roof frame. See «C-PILLAR TRIM AT ROOF FRAME»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim-at-roof-frame) Unclip trim panel-1- beginning at top.
2. Bolt Tightening torque: 3.5 Nm (31 in lb)
3. Clip

With seatbelt for child seat

1. Remove bolt -4- at foundation frame, tightening torque 55 Nm (41 ft lb)
2. Press trim -2- together at cut-out below safety belt and pry out trim -2- using a screwdriver.
3. After removing C-pillar trim -1-, guide belt -3- through C-pillar trim -1-.

Seat belt trim, removing and installing

1. Using a screwdriver, pry out catches -2- (2x).
2. Pull out seat belt trim -1- in direction of arrow.
3. Remove safety belt from seat belt trim -1-.

C-pillar trim at roof frame

1. Remove bolts -2- (2x). Tightening torque: 3.5 Nm (31 in lb)

1. 1 - C-pillar trim
2. 3 - Side curtain airbag

The following list pertains to see scheme 184.

Note. Removing and installing D-pillar trim -1- is the same for vehicles with and without side curtain airbag.

1. D-pillar trim Removing Open slider on attachment eyelets for separation grill. See «RELEASING ATTACHMENT EYELET FOR PARTITION GRILL»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__releasing-attachment-eyelet-for-partition-grill) . Remove bolt -2-. Remove bolt -3- (1x). NOTE: When removing D-pillar trim -1-, touch only side facing headliner or rear lid. Unclip D-pillar trim -1- at clips -5- (2x), starting at roof panel trim. Remove D-pillar trim upward out of side cargo area trim. Remove D-pillar trim rearward out of roof frame trim. See «D-PILLAR TRIM AT ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-at-roof-frame-trim) . CAUTION: Always adhere to D-pillar trim installation sequence. Installing Insert D-pillar trim -1- in roof frame trim. See «D-PILLAR TRIM AT ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-at-roof-frame-trim) . Insert D-pillar trim behind cargo area trim and to the side. Clip trim -1- into mounts -6- using clips -5-. NOTE: When installing D-pillar trim, simply press on sides facing rear lid or headliner, do not bang or hit. Securely clip trim -1-. CAUTION: Make sure trim is secured properly. Remainder of installation is carried out in reverse order of removal.
2. Screw
3. Screw
4. Bracket for cargo area cover
5. Clip
6. Mounting holes (2x)
7. Catch

Releasing attachment eyelet for partition grill

1. Slide on louver -3- in direction of arrow at groove -4-.

1. D-pillar trim
2. Attachment eyelets for separation grill

D-pillar trim at roof frame trim

1. Pull out catch -7- of D-pillar trim -1- from mount -A- of roof frame trim -B-.

1. Open cover -3-.
2. Remove bolts -2- (2x). Tightening torque: 3.5 Nm (31 in lb) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a tap) For loose (threaded) inserts, tighten inserts using pliers.
3. Remove roof grab handle -1-.

The following list pertains to see scheme 188.

1. Upper A-pillar trim Removing Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove front grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove sun visor. See «ROOF TRIM FOR SIDE CURTAIN AIRBAG (AVANT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove bolt at separating point to roof frame trim. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Unclip upper A-pillar trim -1- at clips -2- and -3-. Pull out upper A-pillar trim -1- upward between instrument panel and tension bracket. WARNING: Always follow installation sequence for A-pillar trim Installing Insert upper A-pillar trim -1- between instrument panel and tension bracket. Position trim at clips. Securely clip upper A-pillar trim -1- at clips -2- and -3-. WARNING: Make sure trim has a proper fit. Thread in bolt at separating point to roof frame trim with catch strap. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Install front grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Install upper B-pillar trim. See «UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Clips (2x) Lower (short)
3. Clip Upper (long)
4. Upper B-pillar trim

Removal of the upper A-pillar trim panel without head-level airbag is the same as in vehicles with head-level airbag without cover and with airbag marking. see scheme 188

The catch strap must be installed as in vehicles with head-level airbag, without bolting in the catch strap. See ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02) .

Remove upper A-pillar trim panel with head-level airbag. See TRIM PANELS FOR HEAD-LEVEL AIRBAG AVANT (FROM CALENDAR WEEK 36.02) .

The following list pertains to see scheme 189.

1. B-pillar trim Removing Remove outer seatbelt anchor. Disengage upper B-pillar trim panel -1- at transition to lower B-pillar trim panel. To do so, pull the corners over the lower B-pillar trim panel. NOTE: For better clarity, the A-pillar is depicted without trim in the illustration. Pull upper B-pillar trim panel -1- downward out of guide -6-. Disconnect harness connector for interior monitoring. See «DISCONNECTING CONNECTOR FOR INTERIOR MONITORING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Press the catch strap -4- through the retaining tab at upper B-pillar trim panel -1-. WARNING: Always follow installation sequence for B-pillar trim Installing Pull the catch strap -4- through the retaining tab at upper B-pillar trim panel -1-. WARNING: The retaining tab must lie between the first and second elevation -3-. Ensure that catch strap -4- is installed securely. WARNING: The green thread -5- must always face the vehicle interior. Insert button for height adjuster into height adjustment unit. See «INSTALLING UPPER B PILLAR TRIM IN BELT HEIGHT ADJUSTER»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . NOTE: Do not press button when installing. Slide upper B-pillar trim panel -1- with catches -2- upward into mounts -6-. Pull upper B-pillar trim panel -1- over lower B-pillar trim. After assembling trim, make sure seal is properly fitted NOTE: Function check after installing trim: Height adjuster must audibly engage into all five possible positions (even top position). NOTE: Button must return by itself to upper position after being actuated.
2. Retaining tabs
3. Elevation on catch strap
4. Catch strap
5. Green thread
6. Mounts

1. Insert the slide with button -4- (without pressing) beginning at the top and working downward into release lever -1- of height adjustment unit while at the same time installing pin -2- into mounting -3-.

1. Disengage connector for interior monitoring -A- using a turning motion.

1. B-pillar trim

Roof frame trim, removing (from calendar week 36.02)

The following list pertains to see scheme 192.

1. Roof frame trim Removing Remove D-pillar trim. See «D-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove attachment eyelets for separation grille at roof frame trim. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove front and rear grab handles. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Loosen upper A-pillar trim. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Pull out roof frame trim under A-pillar trim panel. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Remove screws -4- (1x). Pull roof frame trim -1- out of rubber door seal. Pull out roof frame trim -1- under upper C-pillar trim panel. Carefully remove roof frame trim -1-. WARNING: Always follow installation sequence for roof frame trim Installing Carefully insert roof frame trim -1- under upper C-pillar trim panel. Install attachment eyelets for separation grille at roof frame trim. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Insert roof frame trim with catch strap under A-pillar trim panel. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Thread in bolt at separating point to roof frame trim with catch strap. See «ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__attachment-eyelets-for-separation-grille-and) . Install screw -4- with catch strap -5-. Insert retaining tab of D-pillar trim -6- through the opening on catch strap -5- into roof frame trim -1-. See «D-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Rest of installation is reverse order of removal After assembling trim, make sure seal is properly fitted
2. Roof grab handle
3. Screw Tightening torque: 3.5 Nm
4. Screw Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.
5. Catch strap With opening for retaining tab of D-pillar trim panel -6-.
6. D-pillar trim

The following list pertains to see scheme 193.

1. C-pillar trim Removing Remove D-pillar trim. Aee «D-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) . Remove roof frame trim. See «ROOF FRAME TRIM, REMOVING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim-removing-from-calendar) . Remove side bolster. See «SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__side-padding-for-rear-seat-removing) or non-foldable rear backrest ( «FIXED BACKREST, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/seats/#seats-frames__fixed-backrest-removing-and-installing) ). Remove screw -4-. Remove screws -3- (2x). Remove upper C-pillar trim -1- downward. Installing Slide upper C-pillar trim panel -1- upward. Install screws -3- with washers -2-. Rest of installation is reverse order of removal After assembling trim, make sure seal is properly fitted
2. Washers (2x) Tightening torque: 3.5 Nm
3. Screws (2x) Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers.

The following list pertains to see scheme 194.

1. D-pillar trim Removing Open slider on attachment eyelets for separation grille. See «RELEASING ATTACHMENT EYELET FOR SEPARATION GRILLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__releasing-attachment-eyelet-for-separation-grille) . Remove screw -3-. Unclip D-pillar trim -1- at clips -4- (4x), starting at roof panel trim. Pull D-pillar trim panel -1- upward out of side luggage compartment trim. Remove D-pillar trim panel -1- to the rear out of roof frame trim, see «RELEASING ATTACHMENT EYELET FOR SEPARATION GRILLE»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__releasing-attachment-eyelet-for-separation-grille) . WARNING: Always follow installation sequence for D-pillar trim Installing Insert D-pillar trim into roof frame trim, see «D-PILLAR TRIM TO ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim-to-roof-frame-trim) . Insert D-pillar trim -1- behind side luggage compartment trim. Insert D-pillar trim -1- using clips -4- into mounts -5-. Securely clip D-pillar trim -1-. WARNING: Make sure trim is installed securely. Rest of installation is reverse order of removal
2. Attachment eyelets for separation grill
3. Screw
4. Clip (4x)
5. Mounts (4x)
6. Catch
7. Bracket for cargo area cover.
8. Screw

Releasing attachment eyelet for separation grille

1. Slide on louver -3- in direction of arrow at groove -4-.

1. D-pillar trim
2. Attachment eyelets for separation grill

D-pillar trim to roof frame trim

1. Removing: Pull out catch -6- of D-pillar trim -1- from mount -2- of roof frame trim -4-.
2. Installation: Slide catch -6- through the opening at catch strap -5- into mount -2-.

Attachment eyelets for separation grille and separating point at A-pillar/roof frame (from calendar week 36.02)

The following list pertains to see scheme 197.

1. Upper A-pillar trim Removing Pry off cap -3-. Remove screw -2-. Unclip upper A-pillar trim panel -1- and roof frame trim -11- together at clip -14-. Pull out catch strap -12- from upper A-pillar trim panel -1-, at -4-. Installing Slide catch strap -12- behind clip -14- into upper A-pillar trim panel -1-, at position -4-. WARNING: The green thread -13- must always face the vehicle interior. Securely clip upper A-pillar trim panel -1- and roof frame trim -11- together at clip -14-. Securely bolt catch strap -12- with upper A-pillar trim panel -1- to roof frame trim -11-.
2. Screw Tightening torque: 3.5 Nm
3. Concealment cap Always replace cap -3- if catches are faulty. Engage cap -3- in recess.
4. Position for catch strap
5. Screw Tightening torque: 3.5 Nm
6. Coat hook Open coat hook -6-. Remove bolt -5-. Unclip coat hook -6-.
7. Screw Tightening torque: 3.5 Nm
8. Washer
9. Screw Tightening torque: 3.5 Nm
10. Attachment eyelets for separation grill
11. Roof frame trim
12. Catch strap
13. Green thread
14. Clip

The following list pertains to see scheme 198.

1. Deformation element
2. Screws (2x). Tightening torque: 3.5 Nm
3. Trim
4. Roof grab handle Open cover -6-. Remove screws -5- (2x). Remove roof grab handle -4-.
5. Screws (2x). Tightening torque: 3.5 Nm Self-locking Always replace Always clean threaded holes for screws (e.g. using a thread cutter) For loose (threaded) inserts, tighten inserts using pliers
6. Cover

Deformation element for trim panels, removing and installing (from calendar week 36.02)

The following list pertains to see scheme 199.

1. Deformation element Remove roof grab handle -4-. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle-removing-and-installing) . Remove trim -3-. Remove screws -2- (2x). Disengage deformation element -1- up and out.
2. Screws (2x).
3. Trim
4. Roof grab handle
5. Screws (2x).

See also:
• GLOVE BOX, REMOVING AND INSTALLING
• DRIVER'S STORAGE COMPARTMENT, REMOVING
• INSTRUMENTS - UP TO 2000
• CENTER CONSOLE (FRONT SECTION), REMOVING AND INSTALLING
• CENTER SECTION OF INSTRUMENT PANEL (VEHICLES WITH "CHORUS" AND "CONCERT" RADIOS), REMOVING
• EMERGENCY BATTERY, SWITCHING OFF/ON
• CENTER CONSOLE (REAR SECTION), REMOVING AND INSTALLING
• CENTER PART OF INSTRUMENT PANEL (VEHICLES WITH "SYMPHONY" RADIOS AND "RADIO-NAVIGATION SYSTEM PLUS"), REMOVING
• WINDSHIELD WIPER AND WASHER SYSTEM - UP TO 2000
• SEAT BENCH, REMOVING AND INSTALLING
• SIDE PADDING FOR REAR SEAT, REMOVING AND INSTALLING
• FIXED BACKREST, REMOVING AND INSTALLING
• SEAT, REMOVING AND INSTALLING
• LOCKING CABLE
• CHILDREN'S BENCH BASE FRAME (AVANT), REMOVING AND INSTALLING
• FRONT DOOR TRIM, REMOVING AND INSTALLING
• HINGED POCKET ASSEMBLY, REMOVING AND INSTALLING
• BASS LOUDSPEAKER, REMOVING
• TREBLE LOUDSPEAKER, REMOVING AND INSTALLING
• FRONT DOOR TRIM INSULATION, REMOVING AND INSTALLING
• DOOR WARNING LIGHT AND FOOTWELL LIGHT, REMOVING AND INSTALLING
• CENTRAL LOCKING SWITCH, REMOVING
• INTERIOR DOOR HANDLE, REMOVING
• TRIM PANEL IN DOOR TRIM, REMOVING
• DRIVER'S WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING
• FRONT PASSENGER WINDOW REGULATOR SWITCH, REMOVING AND INSTALLING
• DETACHING BOWDEN CABLE
• DISCONNECTING ELECTRICAL CONNECTORS
• REAR DOOR TRIM, REMOVING AND INSTALLING
• REAR DOOR TRIM INSULATION, REMOVING AND INSTALLING
• REMOVING STEERING COLUMN SWITCH
• REMOVING REINFORCING BRACKET
• REMOVING INSTRUMENT PANEL END TRIM (LEFT)
• REMOVING INSTRUMENT PANEL END TRIM (RIGHT)
• REMOVING INSTRUMENT PANEL MOUNTING SCREWS-DRIVER'S SIDE
• REMOVING PHOTOSENSOR
• DISCONNECTING CONNECTORS FOR SIDE VENT LIGHTING AND TEMPERATURE SENSOR
• TRIM STRIP FOR INSTRUMENT PANEL, REMOVING
• INSTRUMENT PANEL CENTRAL TUBE, REMOVING AND INSTALLING
• DETACHING WIRING HARNESS AT STEERING COLUMN
• REMOVING FUSE CARRIER
• REMOVING DEFROSTER DUCT
• DETACHING CENTRAL TUBE FROM BODYWORK (DRIVER'S SIDE)
• REMOVE ACOUSTIC BRACE
• REMOVING CENTER AIR DUCT
• DETACHING CENTRAL TUBE FROM BODYWORK (PASSENGER-SIDE)
• DETACHING LEFT BRACE FOR CENTRAL TUBE
• INSTRUMENT PANEL, REMOVING
• UPPER B-PILLAR TRIM, REMOVING AND INSTALLING
• UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING
• COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LAMP, REMOVING AND INSTALLING
• WIRING ON BACK OF MOLDED HEADLINER (SEDAN), ROUTING
• REMOVING CENTER SUN VISOR
• UPPER A-PILLAR TRIM, REMOVING AND INSTALLING
• INTERMEDIATE PIECE AT B-PILLAR AND COAT HOOK, REMOVING AND INSTALLING
• UPPER D-PILLAR TRIM, REMOVING AND INSTALLING
• ROOF FRAME TRIM
• REMOVING AND INSTALLING COVER FOR MOLDED HEADLINER CUT-OUT AND INTERIOR LIGHT
• DETACHING VELCRO FASTENERS
• DETACHING VELCRO FASTENER
• LOWER A-PILLAR TRIM, REMOVING AND INSTALLING
• SILL PANEL TRIM, REMOVING
• SCREWS SECURING ELECTRICAL SUN SHADE IN LUGGAGE COMPARTMENT
• REAR SHELF (FOLDING BACKREST), REMOVING AND INSTALLING
• REAR SHELF (FIXED BACKREST), REMOVING AND INSTALLING
• REAR CROSS PANEL TRIM, REMOVING AND INSTALLING
• RIGHT (2/3) SECTION OF BACKREST, REMOVING AND INSTALLING
• VEHICLES WITH SEAT BELT FOR CHILDREN'S BENCH
• REMOVING AND INSTALLING TRIM PIECE FOR SEAT BELT
• REMOVING AND INSTALLING TRIM PLATE FOR SEAT BELT
• CARGO AREA SIDE TRIM
• SCREW BEHIND WARNING TRIANGLE
• SUN SHADE ON TAILGATE (AVANT), REMOVING AND INSTALLING
• ROOF GRAB HANDLE FOR SIDE CURTAIN AIRBAG TRIM, REMOVING AND INSTALLING
• D-PILLAR TRIM, REMOVING AND INSTALLING
• ROOF FRAME TRIM, REMOVING
• TENSION BRACKET AT A-PILLAR
• DISCONNECTING CONNECTOR FOR INTERIOR MONITORING
• INSTALLING UPPER B PILLAR TRIM IN BELT HEIGHT ADJUSTER
• UPPER B-PILLAR TRIM PANEL, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)
• ROOF GRAB HANDLE, REMOVING AND INSTALLING (FROM CALENDAR WEEK 36.02)
• COAT HOOK AND SEPARATING POINT AT A-/D-PILLAR (FROM CALENDAR WEEK 36.02)
• RELEASING ATTACHMENT HOOKS FOR SEPARATION GRILL
• WEDGING IN PLASTIC WEDGE
• WITH SEATBELT FOR CHILD SEAT
• SEAT BELT TRIM, REMOVING AND INSTALLING
• C-PILLAR TRIM AT ROOF FRAME
• RELEASING ATTACHMENT EYELET FOR PARTITION GRILL
• D-PILLAR TRIM AT ROOF FRAME TRIM
• ATTACHMENT EYELETS FOR SEPARATION GRILLE AND SEPARATING POINT AT A-PILLAR/ROOF FRAME (FROM CALENDAR WEEK 36.02)
• ROOF FRAME TRIM, REMOVING (FROM CALENDAR WEEK 36.02)
• RELEASING ATTACHMENT EYELET FOR SEPARATION GRILLE
• D-PILLAR TRIM TO ROOF FRAME TRIM
