On Board Diagnostic (OBD) - Up to 2000 Audi A6 C5

Instrument cluster, On Board Diagnostic (OBD)

1. Determine the correct coding for the anti-theft radio.
2. Disconnect the battery Ground (GND) strap.

Technical features of the instrument cluster

The Audi A6 is equipped with an LCD driver information system.

The Auto Check system monitors the brake system, coolant temperature, fuel level and engine oil pressure.

The driver information system incorporates the following displays

1. Driver information display with radio frequency and telephone data display
2. Ambient temperature display
3. On-board computer display
4. Transmission range selector lever display for automatic transmission

The speedometer contains an LCD display for the odometer, driver information display and Service Reminder Indicator (SRI).

The indicator lamps are integrated in the speedometer and in the tachometer.

The instrument cluster is controlled by a microprocessor and has extensive On Board Diagnostic (OBD) capabilities. If malfunctions occur in any of the system components, corresponding Diagnostic Trouble Codes (DTC) are stored in the DTC memory of the instrument cluster. These can then be identified using the VAG1551 or VAG1552 Scan Tool (ST).

Note. The following adaptation (adjustment) functions can be carried out on the instrument cluster: Adaptation of the fuel gauge sender resistance range Adaptation of the fuel consumption indicator Coding of language versions for the on-board computer and Auto Check system Adaptation of the Service Reminder Indicator (SRI) Adaptation of the odometer after replacement of the instrument cluster

Malfunction message "dEF" on trip recorder display

If the control module in the instrument cluster detects a malfunction in its permanent memory, the letters "dEF" will appear on the trip recorder display.

1. If "dEF" appears on display, replace instrument cluster. See «INSTRUMENTS - UP TO 2000»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) .

Note. When replacing an instrument cluster: The instrument cluster must not be disassembled. All indicator lamps which have conventional bulbs can be replaced individually. See INSTRUMENTS - UP TO 2000 . If necessary, the instrument cluster can be replaced with an exchange unit. A damage report form must be completed and returned together with the faulty instrument cluster. Faulty units must always be returned in original packaging. The odometer and the service reminder indicator on the replacement instrument cluster can be adapted using the VAG1551 scan tool. See ADAPTATION (SCAN TOOL FUNCTION 10) .

Test requirements

1. Fuses OK
2. Coding of instrument cluster checked according to instrument cluster code table. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. VAG1551 Scan Tool (ST) connected
4. Ignition switched on Notes

Note. If the display remains blank, check the voltage supply to the VAG1551 scan tool. Additional operating instructions can be called up with the HELP button. The --> button is used to advance through program sequence. If an incorrect entry is made, press the -C- button to cancel. In "Rapid data transfer" operating mode 1 the "Automatic Test Sequence" (address word 00) can be carried out. This will automatically check the DTC memories of all vehicle control modules which have OBD capabilities.

1. Switch ignition on.
2. Switch printer on by pressing PRINT button (indicator light in button comes on).
3. Press button -1- to select "Rapid data transfer" operating mode 1.

Indicated on display

VAG 1551 Scan Tool Display - Initiating OBD, Instrument Cluster (1 Of 5). Scheme 1

1. Press buttons -1 - and -7- to insert "Instrument Cluster" address word 17.

Indicated on display

VAG 1551 Scan Tool Display - Initiating OBD, Instrument Cluster (2 Of 5). Scheme 2

1. Press -Q- button to confirm input.

Indicated on display (after about 5 seconds)

VAG 1551 Scan Tool Display - Initiating OBD, Instrument Cluster (3 Of 5). Scheme 3

1. 4B0919930B: Part number of instrument cluster
2. C5-KOMBIINSTR.: component designation
3. UN4: manufacturer's code (UN4 = Nippon Seiki, VDO = VDO)
4. D13: software version installed in instrument cluster ("V01" is also possible)
5. Coding 02262: coding of instrument cluster, code table. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
6. WSC 06812: dealership number

Scheme 4

1. If one of these four messages is displayed, carry out troubleshooting procedures. (Scheme 4): VAG 1551 Scan Tool Display - Initiating OBD, Instrument Cluster (4 Of 5)
2. Press --> button to advance through program sequence.

Indicated on display

VAG 1551 Scan Tool Display - Initiating OBD, Instrument Cluster (5 Of 5). Scheme 5

When the HELP button is pressed, a list of possible functions is printed.

On Board Diagnostic (OBD) functions

The following functions are possible

1. 02 - Check DTC Memory. See «CHECK DTC MEMORY (SCAN TOOL FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. 03 - Output Diagnostic Test Mode. See «OUTPUT DIAGNOSTIC TEST MODE (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. 05 - Erase DTC Memory. See «ERASE DTC MEMORY (SCAN TOOL FUNCTION 05)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
4. 06 - End Output. See «END OUTPUT (SCAN TOOL FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
5. 07 - Code Control Module. See «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
6. 08 - Read Measuring Value Block. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
7. 10 - Adaptation. See «ADAPTATION (SCAN TOOL FUNCTION 10)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Instrument cluster

Note. The displayed DTC information is updated only when initiating OBD or with "Erase DTC Memory" function 05.

1. Switch printer on by pressing PRINT button (indicator light in button comes on).

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Instrument Cluster (1 Of 5). Scheme 6

1. Press buttons -0- and -2-to select "Check DTC Memory" function 02.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Instrument Cluster (2 Of 5). Scheme 7

1. Press -Q- button to confirm input.

The number of stored malfunctions appears in the display.

VAG 1551 Scan Tool Display - Check DTC Memory, Instrument Cluster (3 Of 5). Scheme 8

The stored malfunctions are displayed and printed out one after the other.

1. Check print-out against DTC table and repair all malfunctions as necessary. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__diagnostic-trouble-code-dtc-table) .

If "No DTC recognized!" is displayed the program will return to "Select function XX" after the --> button is pressed.

VAG 1551 Scan Tool Display - Check DTC Memory, Instrument Cluster (4 Of 5). Scheme 9

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Instrument Cluster (5 Of 5). Scheme 10

If something else is displayed, see scan tool operating instructions.

End output (function 06). See END OUTPUT (SCAN TOOL FUNCTION 06) .

1. Switch ignition off and disconnect scan tool from Data Link Connector (DLC).

1. The following table lists all malfunctions that can be recognized by the instrument cluster and printed out by the VAG1551 scan tool. The malfunctions are listed in order according to their 5-digit numbers.
2. DTC numbers appear only on the print-out.
3. Before replacing a component shown as faulty, check the wiring and connections to the component as well as the Ground (GND) connections.
4. When the repair has been carried out, the DTC memory must always be checked again and then erased using the VAG1551 scan tool.
5. DTC memory records all static and sporadic malfunctions. If a malfunction occurs and persists for at least 2 seconds, it is identified as a static malfunction.
6. In the case of the ambient temperature display, a malfunction must persist for at least 60 seconds before it is classified as a static malfunction.
7. In the case of the coolant temperature sensor, static malfunctions are those which persist for at least 30 minutes with the engine running.
8. If a malfunction does not occur again it is registered as a sporadic DTC and "/SP" will appear at the right of the scan tool display.
9. When the ignition is switched on, all existing malfunctions are automatically re-classified as sporadic malfunctions and will only register as static malfunctions if they still occur after testing.
10. Sporadic malfunctions which no longer occur after 50 driving cycles are erased automatically. For a driving cycle to be recorded the ignition must be on for at least 5 minutes and a road speed of more than 30 km/h (19 mph) must be attained.

Diagnostic Trouble Code Table - Instrument Cluster (00667, 00771 & 00779). Scheme 11

1. For A/C diagnosis, see «A/C SYSTEM, ON BOARD DIAGNOSTIC (OBD)»(/audi/a6/c5-1997-2001/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac__ac-system-on-board-diagnostic-obd) .

Diagnostic Trouble Code Table - Instrument Cluster (01039 & 65535). Scheme 12

1. To replace instrument cluster, see «INSTRUMENTS - UP TO 2000»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) .

Note. The output Diagnostic Test Mode (DTM) may only be carried out on a stationary vehicle with the engine not running. If a malfunction is found during the output diagnostic test mode, trace the cause and replace the instrument cluster if necessary.

Test sequence

With the output Diagnostic Test Mode (DTM) all the control elements in the instrument cluster (if installed and coded) are activated in sequence.

1. Simultaneous activation of all analog instruments (coolant temperature gauge, tachometer, speedometer, fuel gauge)
2. Activation of seat belt warning lamp
3. Activation of buzzer (chime)
4. Segment test of driver information display and/or LCD display for odometer
5. Test of instrument panel lighting, including dimmer function
6. Coolant excess temperature test

Note. The instrument panel lighting test can only be conducted with illumination switched on. Coolant excess temperature test activates the A/C compressor shut-off.

Initiating output DTM

1. Press buttons -0- and -3- to select "Output Diagnostic Test Mode" function 03.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster. Scheme 13

1. Press -Q- button to confirm input.

This will start the output DTM for the analog instruments (displays)

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Analog Indicator). Scheme 14

The following tests are carried out simultaneously when the -Q- button is pressed

1. Coolant temperature gauge needle moves across the full range of the scale.
2. Tachometer needle moves across the full range of the scale.
3. Speedometer needle moves across the full range of the scale.
4. Fuel gauge needle moves across the full range of the scale.

When the gauge needles have finished moving across the scales the following fixed vales will be indicated

Coolant temperature gauge: 90° C (194° F)

Tachometer: 3000 RPM

Speedometer: 100 km/h (63mph)

Fuel gauge: 1/2

Note. A gauge needle sweep which has been started will be interrupted each time the ignition is switched off and on.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Seat Belt Warning Light). Scheme 15

The seat belt warning light will be activated.

Note. The seat belt warning light is activated using the control module coding, depending on the system design and the equipment installed. Therefore if this control element is not tested, the warning light is not active.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Buzzer Chime). Scheme 16

The buzzer (chime) will be activated and will sound continuously.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Segment Test). Scheme 17

Note. All the display segments on the driver information display and/or the LCD display for the odometer will be activated. All the display segments on the driver information display will light up and one line will remain dark.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Switch And Instrument Lighting). Scheme 18

The dimming of instrument panel lighting is tested.

Note. The instrument panel lighting test can only be conducted with the illumination switched on.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Coolant Excess Temperature Test). Scheme 19

The safety shut-off for the A/C compressor will be activated after about 5 seconds.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (End). Scheme 20

1. Press --> button to terminate output DTM.

This returns the scan tool to the "Select function XX" prompt.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster (Select Function XX). Scheme 21

Note. After erasing DTC memory its contents will automatically be emptied. If DTC memory cannot be erased, check DTC memory again and repair malfunctions.

Requirements

1. DTC memory checked. See «CHECK DTC MEMORY (SCAN TOOL FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. All malfunctions repaired

After DTC memory has been successfully checked

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster (1 Of 5). Scheme 22

1. Press buttons -0- and -5- to select "Erase DTC Memory" function 05.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster (2 Of 5). Scheme 23

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster (3 Of 5). Scheme 24

DTC memory is now erased.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster (4 Of 5). Scheme 25

This message indicates an error in the test sequence.

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster (5 Of 5). Scheme 26

Note. Follow the specified test sequence exactly. First check DTC memory, repair malfunctions if necessary, then erase DTC memory.

1. Press buttons -0- and -6- to select "End Output" function 06.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Instrument Cluster (1 Of 2). Scheme 27

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Instrument Cluster (2 Of 2). Scheme 28

1. Switch ignition off.
2. Disconnect VAG1551 scan tool.

Function 07 is used to code the instrument cluster with the following information

1. Optional equipment
2. Market and language versions
3. Number of cylinders
4. Engine versions

Note. Coding sets the On Board Diagnostics (OBD) language for the Auto Check and driver information systems according to the market/model version, number of cylinders and engine version. The code table lists combinations applicable to the Audi A6 only.

Initiating instrument cluster coding

1. Press buttons -0- and -7- to select "Code Control Module" function 07.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster (1 Of 5). Scheme 29

1. Input code number as per instrument cluster code table. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Example: 02262

Instrument Cluster Input Code Number Table - Except Instrument Cluster With Maintenance Interval Extension. Scheme 30

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster (2 Of 5). Scheme 31

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster (3 Of 5). Scheme 32

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster (4 Of 5). Scheme 33

1. Press buttons -0- and -6- to select "End Output" function 06.

Indicated on display

1. Press -Q- button to confirm input.

Instrument cluster code table

Note. The coding can be modified to allow for various combinations of optional equipment, depending on what is installed on the vehicle. If the vehicle is equipped with more than one item of optional equipment which needs to be coded, the overall coding will be the total of the individual coding numbers.

Instrument Cluster Code Table - Instrument Cluster With Maintenance Interval Extension. Scheme 34

Examples

Seat belt warning active (02) and washer fluid warning system active (04)

1. 02 + 04 = 06

Brake pad wear indicator active (01), seat belt warning system active (02) and washer fluid warning system active (04)

1. 01 + 02 + 04 = 07

Initiating "Read Measuring Value Block" function 08

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster (1 Of 3). Scheme 35

1. Press buttons -0- and -8- to select "Read Measuring Value Block" function 08.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster (2 Of 3). Scheme 36

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster (3 Of 3). Scheme 37

1. Input display group number from «LIST OF DISPLAY GROUPS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Press -Q- button to confirm input.

The VAG1551 scan tool display now indicates the selected display group.

Note. The display will always show the actual values obtained from the sensors. The values which appear on the instrument cluster are modified and may be different. If the actual engine coolant temperature is between 80° C (176° F) and 100° C (212° F), the instrument cluster will always show 90° C (194° F). The display groups shown here are the only ones which can appear for the instrument cluster.

Read Measuring Value Display Groups List - Instrument Cluster. Scheme 38

Read Measuring Value Group 001 - Instrument Cluster. Scheme 39

Read Measuring Value Group 002 - Instrument Cluster. Scheme 40

Read Measuring Value Group 003 - Instrument Cluster. Scheme 41

Read Measuring Value Group 50 - Instrument Cluster. Scheme 42

Function 10 is used to initiate and store the following changes

1. Adaptation of fuel the consumption indicator
2. Coding of language version for the driver information display and Auto Check system
3. Adaptation of the Service Reminder Indicator (SRI)
4. Adaptation of the odometer replacement of the instrument cluster
5. Adaptation of fuel gauge sender resistance range

The individual functions are called up by entering the appropriate adaptation channel numbers listed in the adaptation table. See INITIATING "ADAPTATION" FUNCTION 10 .

ADAPTION FUNCTIONS - INSTRUMENT CLUSTER

Initiating "Adaptation" function 10

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Instrument Cluster (1 Of 2). Scheme 43

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Instrument Cluster (2 Of 2). Scheme 44

1. Insert required adaptation channel number. See «ADAPTION FUNCTIONS - INSTRUMENT CLUSTER»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) table.
2. Press -Q- button to confirm input.

Note. After an adaptation value has been changed, or adaptation in a specific channel has been completed, "Adaptation" function 10 must be selected again in order to select another adaptation channel.

Resetting Service Reminder Indicator (SRI) after a service

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (1 Of 8). Scheme 45

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (2 Of 8). Scheme 46

1. Press buttons -0- and -2- to insert channel number 02.
2. Press -Q- button to confirm input.

Note. The SRI can also be reset without using the VAG1551 or 1552 scan tool. See RESETTING SERVICE REMINDER INDICATOR (SRI) AFTER A SERVICE WITHOUT USING VAG1551/1552 ST . Adaptation channel 02 can only be used on instrument clusters with software versions from D05 onwards. Software version of instrument cluster. See ON BOARD DIAGNOSTIC (OBD) FUNCTIONS .

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (3 Of 8). Scheme 47

The display will indicate which type of service is due.

1 - indicates that oil change service is due

10 - indicates that inspection service is due

11 - indicates that oil change service and inspection service are due

Note. The SRI must be reset using direct input.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (4 Of 8). Scheme 48

The following adaptation values are used to reset an Oil Change Service and/or an Inspection Service

SRI ADAPTATION VALUES

1. Enter appropriate adaptation value using keypad to reset oil change service and/or inspection service as required.

Example: 00000

1. Press button -0- five times to input adaptation value "00000."

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (5 Of 8). Scheme 49

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (6 Of 8). Scheme 50

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (7 Of 8). Scheme 51

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting Service Reminder Indicator After A Service (8 Of 8). Scheme 52

1. Press --> button to complete adaptation.

Adapting fuel consumption indicator

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (1 Of 9). Scheme 53

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (2 Of 9). Scheme 54

1. Press buttons -0- and -3- to insert channel number 03.
2. Press -Q- button to confirm input.

Note. Adaptation is only possible on vehicles with the driver information display. The value entered must be between 85% and 115%. The value must be entered in steps of 5%.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (3 Of 9). Scheme 55

1. Press --> button.

Note. The fuel consumption indicator can only be adapted using direct input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (4 Of 9). Scheme 56

1. Input required adaptation value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Required value: 90%

1. Input "00090" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (5 Of 9). Scheme 57

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (6 Of 9). Scheme 58

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (7 Of 9). Scheme 59

1. Press --> button to complete fuel consumption indicator adaptation.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (8 Of 9). Scheme 60

If an incorrect entry is made the VAG1551 or VAG1552 Scan Tool (ST) will switch to the following display.

VAG 1551 Scan Tool Display - Adapting Fuel Consumption Indicator (9 Of 9). Scheme 61

1. Press --> button.
2. Select "Adaptation" function 10 and adaptation channel number 03 again.
3. Repeat adaptation of fuel consumption indicator.
4. Confirm entry with -Q- button.

Adapting driver information display language version

Note. Adaptation is only possible on vehicles with the driver information display.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Driver Information Display Language Version (1 Of 3). Scheme 62

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Driver Information Display Language Version (2 Of 3). Scheme 63

1. Press buttons -0- and -4- to insert channel number 04.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Driver Information Display Language Version (3 Of 3). Scheme 64

Note. The display will show only the last digit of the 5-digit language version code (e.g. 1 for German). Input of incorrect values will end the adaptation function. "Adaptation" function 10 must be selected again. The code can now be entered either directly or step-by-step using the keypad on the VAG1551 scan tool.

LANGUAGE VERSION CODES

Entering code step-by-step

Button -1- can be used to change down to a lower code value, and button -3- can be used to change up to a higher code value (for example, to change to "2" (00002) for English).

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Step-By-Step (1 Of 3). Scheme 65

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Step-By-Step (2 Of 3). Scheme 66

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Step-By-Step (3 Of 3). Scheme 67

1. Press --> button to complete language version adaptation.

Entering code directly

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (1 Of 6). Scheme 68

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (2 Of 6). Scheme 69

1. Input required 5-digit adaptation value using keypad. See «ENTERING CODE STEP-BY-STEP»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__entering-code-step-by-step) .

Example

1. Input "00002" for English-language code 2.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (3 Of 6). Scheme 70

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (4 Of 6). Scheme 71

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (5 Of 6). Scheme 72

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Entering Language Code Directly (6 Of 6). Scheme 73

1. Press --> button to complete language version adaptation.

Adapting Service Reminder Indicator (SRI), oil change service interval (distance in km)

This function is used to adapt the distance in kilometers until the next oil change service is due.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (1 Of 8). Scheme 74

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (2 Of 8). Scheme 75

1. Press buttons -0- and -5- to insert channel number 05.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (3 Of 8). Scheme 76

The display will show the number of kilometers remaining before the next oil change service is due. In this example, "1" = 1000 km.

Note. Values can only be entered in increments of 1000 km. Therefore, the distance is indicated in units of 1000 km. Even in countries where the speedometers are calibrated in miles, adaptation must be done in metric units. Convert the required distance interval from miles to kilometers to get the required adaptation value. Conversion of miles to kilometers: miles x 1.609 = km. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (4 Of 8). Scheme 77

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Specification: 15000 km

1. Input "00015" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (5 Of 8). Scheme 78

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (6 Of 8). Scheme 79

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (7 Of 8). Scheme 80

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Oil Change Service Interval, Distance In km (8 Of 8). Scheme 81

1. Press --> button to complete adaptation.

Adapting Service Reminder Indicator (SRI), inspection service interval (distance in km)

This function is used to adapt the distance remaining (in kilometers) before the next inspection service is due.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (1 Of 8). Scheme 82

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (2 Of 8). Scheme 83

1. Press buttons -0- and -6- to insert channel number 06.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (3 Of 8). Scheme 84

The display will show the number of kilometers remaining before the next inspection service is due. In this example, "5" = 5000 km.

Note. Values can only be input in increments of 1000 km. Therefore, the distance is indicated in units of 1000 km. Even in countries where the speedometers are calibrated in miles, adaptation must be done in metric units. Convert the required distance interval from miles to kilometers to get the required adaptation value. Conversion of miles to kilometers: miles x 1.609 = km. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (4 Of 8). Scheme 85

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Specification: 30000 km

1. Input "00030" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (5 Of 8). Scheme 86

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (6 Of 8). Scheme 87

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (7 Of 8). Scheme 88

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Distance In km (8 Of 8). Scheme 89

1. Press --> button to complete adaptation.

Adapting Service Reminder Indicator (SRI), inspection service interval (time in days)

This function is used to adapt the number of days remaining until the next inspection service is due.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (1 Of 8). Scheme 90

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (2 Of 8). Scheme 91

1. Press buttons -0- and -7- to select channel number 07.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (3 Of 8). Scheme 92

The display will show the number of days remaining before the next inspection service is due. In this example, "11" = 110 days.

Note. Values can only be entered in increments of 10 days. Therefore, the time is indicated in units of 10 days. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (4 Of 8). Scheme 93

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Specification: 360 days

1. Input "00036" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (5 Of 8). Scheme 94

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (6 Of 8). Scheme 95

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (7 Of 8). Scheme 96

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - SRI, Inspection Service Interval - Time In Days (8 Of 8). Scheme 97

1. Press --> button to complete adaptation.

Adapting odometer display (kilometers, miles)

This function is used to adapt the odometer after the instrument cluster is replaced.

1. The adaptation function can only be carried out on instrument clusters with an odometer reading of not more than 100 km (63 mi).
2. The adaptation function can only be carried out once for each instrument cluster.
3. Only a higher adaptation value can be entered, not a lower one.
4. If an incorrect value is entered and confirmed, it is not possible to change it. If this happens the instrument cluster must be replaced.
5. Even in countries where the speedometers are calibrated in miles, adaptation must be done in metric units. Convert the required distance interval from miles to kilometers to get the required adaptation value.
6. Conversion of miles to kilometers: miles x 1.609 = km.
7. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050.
8. Notes regarding replacement of the instrument cluster. See «REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__replacement-of-instrument-cluster-input-values) .

Selecting function

1. Press -C- button.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (1 Of 13). Scheme 98

1. Press buttons -1- and -1- to select "Login-Procedure" function 11.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (2 Of 13). Scheme 99

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (3 Of 13). Scheme 100

1. Input code number 13861.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (4 Of 13). Scheme 101

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (5 Of 13). Scheme 102

1. Press buttons -1- and -0- to select "Adaptation" function 10.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (6 Of 13). Scheme 103

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (7 Of 13). Scheme 104

1. Press buttons -0- and -9- to select channel number 09.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (8 Of 13). Scheme 105

Note. Only direct input of the values is possible using the VAG1551 scan tool.

1. Press --> button to advance through program sequence.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (9 Of 13). Scheme 106

1. Input adaptation value using keypad.

Example

Number of kilometers = 89627

For 89627 km, input "0 8 9 6 3"

ENTERING INPUT ADAPTATION VALUE 89627 KILOMETERS

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (10 Of 13). Scheme 107

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (11 Of 13). Scheme 108

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (12 Of 13). Scheme 109

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting Odometer Display (Kilometers, Miles) (13 Of 13). Scheme 110

1. Press --> button to complete odometer adaptation.

Adapting Service Reminder Indicator (SRI), after replacing instrument cluster (distance remaining until next oil change service)

This function is used to adapt the distance remaining (in kilometers) before the next oil change service is due, after replacing the instrument cluster.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (1 Of 8). Scheme 111

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (2 Of 8). Scheme 112

1. Press buttons -1 - and -0- to select channel number 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (3 Of 8). Scheme 113

The display will show the number of kilometers remaining before the next oil change service is due. In this example, "1" = 1000km.

Note. Values can only be entered in increments of 1000 km. Therefore, the distance is indicated in units of 1000 km. Even in countries where the speedometers are calibrated in miles, adaptation must be done in metric units. Convert the required distance interval from miles to kilometers to get the required adaptation value. Conversion of miles to kilometers: miles x 1.609 = km. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050. The value entered is then counted backward to 0 km. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (4 Of 8). Scheme 114

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Distance remaining: 1000 km

1. Input "00001" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (5 Of 8). Scheme 115

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (6 Of 8). Scheme 116

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (7 Of 8). Scheme 117

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Oil Change Service) (8 Of 8). Scheme 118

1. Press --> button to complete adaptation.

Adapting Service Reminder Indicator (SRI), after replacing instrument cluster (distance remaining until next inspection service)

This function is used to adapt the distance remaining (in kilometers) before the next inspection service is due, after replacing the instrument cluster.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (1 Of 8). Scheme 119

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (2 Of 8). Scheme 120

1. Press button -1- twice to select channel number 11.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (3 Of 8). Scheme 121

The display will show the number of kilometers remaining before the next inspection service is due. In this example, "5" = 5000 km.

Note. Values can only be Input in increments of 1000 km. Therefore, the distance is indicated in units of 1000 km. Even in countries where the speedometers are calibrated in miles, adaptation must be done in metric units. Convert the required distance interval from miles to kilometers to get the required adaptation value. Conversion of miles to kilometers: miles x 1.609 = km. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050. The value entered is then counted backward to 0 km. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (4 Of 8). Scheme 122

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Remaining distance: 5000 km

1. Input "00005" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (5 Of 8). Scheme 123

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (6 Of 8). Scheme 124

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (7 Of 8). Scheme 125

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Distance Remaining Until Next Inspection Service) (8 Of 8). Scheme 126

1. Press --> button to complete adaptation.

Adapting Service Reminder Indicator (SRI), after replacing instrument cluster (time remaining until next inspection service)

This function is used to adapt the number of days remaining until the next inspection service is due, after replacing the instrument cluster.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (1 Of 8). Scheme 127

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (2 Of 8). Scheme 128

1. Press buttons -1 - and -2- to select channel number 12.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (3 Of 8). Scheme 129

The display will show the number of days remaining before the next inspection service is due. In this example, "11" = 110 days.

Note. Values can only be input in increments of 10 days. Therefore, the time is indicated in units of 10 days. The value entered is then counted backwards to 0 days. Notes regarding replacement of the instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Only direct input of the values is possible using the VAG1551 scan tool. If an incorrect value is input "Adaptation" function 10 is ended and must be initiated again.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (4 Of 8). Scheme 130

1. Input required value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Example

Remaining time: 110 days

1. Input "00011" using keypad.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (5 Of 8). Scheme 131

1. Press -Q- button to confirm input.

Indicated on display

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (7 Of 8). Scheme 132

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adapting SRI, After Replacing Instrument Cluster (Time Remaining Until Next Inspection Service) (8 Of 8). Scheme 133

1. Press --> button to complete adaptation.

Adaptation of fuel gauge sender resistance range

This function is used to adjust the resistance range for the fuel gauge sender in order to compensate for any misalignment of the fuel gauge sender.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (1 Of 8). Scheme 134

1. Press buttons -1- and -0- to select "Adaptation" function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (2 Of 8). Scheme 135

1. Press buttons -3- and -0- to insert channel number 30.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (3 Of 8). Scheme 136

The display will show the adaptation value, for example 128.

Note. "128" is the adaptation value for the standard resistance range for the fuel gauge sender as set by the factory. The resistance value for the fuel gauge sender resistance range can be adjusted by +/- 8 ohm to give an adaptation value between 120 and 136.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (4 Of 8). Scheme 137

Example

1. Input "00132" using keypad.
2. Input adaptation value using keypad on VAG1551 scan tool, filling in initial spaces with "0."

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (5 Of 8). Scheme 138

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (6 Of 8). Scheme 139

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (7 Of 8). Scheme 140

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range (8 Of 8). Scheme 141

1. Press --> to complete fuel gauge sender resistance range adaptation.

Replacement of instrument cluster, input values

Note. It is important to note the following points when replacing the instrument cluster: The instrument cluster must always be coded. Before replacing the instrument cluster, make a note of the values which appear on VAG1551 scan tool in all the adaptation channels for the service reminder indicator. The values noted must be programmed into the new instrument cluster so that it can count down to when the next service is due. Make a note of the display on the odometer and enter it as explained. Even on export versions with speedometers calibrated in miles, the adaptation of the odometer in the service reminder indicator must be made in kilometers. To do this, either convert the adaptation value from miles to kilometers, or enter the adaptation value that was noted from the old instrument cluster. Conversion of miles to kilometers: miles x 1.609 = km. Kilometers are displayed in "Read Measuring Value Block" function 08, display groups 002 and 050.

The following steps must be carried out after replacing the instrument cluster

1. Code instrument cluster. See «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Reset Service Reminder Indicator (SRI) after service. See «RESETTING SERVICE REMINDER INDICATOR (SRI) AFTER A SERVICE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__resetting-service-reminder-indicator-sri-after) . or
3. Adapt distance remaining until next oil change service. See «ADAPTING SERVICE REMINDER INDICATOR (SRI), AFTER REPLACING INSTRUMENT CLUSTER (DISTANCE REMAINING UNTIL NEXT OIL CHANGE SERVICE)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adapting-service-reminder-indicator-sri-after) .
4. Adapt distance remaining until next inspection service. See «ADAPTING SERVICE REMINDER INDICATOR (SRI), AFTER REPLACING INSTRUMENT CLUSTER (DISTANCE REMAINING UNTIL NEXT INSPECTION SERVICE)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adapting-service-reminder-indicator-sri-after) .
5. Adapt time remaining until next inspection service. See «ADAPTING SERVICE REMINDER INDICATOR (SRI), AFTER REPLACING INSTRUMENT CLUSTER (TIME REMAINING UNTIL NEXT INSPECTION SERVICE)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adapting-service-reminder-indicator-sri-after) . and
6. Adapt odometer display. See «ADAPTING ODOMETER DISPLAY (KILOMETERS, MILES)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adapting-odometer-display-kilometers-miles) .

After a service has been carried out the Service Reminder Indicator (SRI) must be reset accordingly.

The SRI can be reset using the adaptation function on the VAG1551 Scan Tool (ST). See ADAPTATION (SCAN TOOL FUNCTION 10) .

The SRI can also be reset using the following procedure

1. Switch ignition off.
2. Press reset button for trip recorder in instrument cluster and, at same time switch ignition on.
3. The message "Service OIL" will appear on the trip recorder display.
4. Pull out clock adjuster knob in instrument cluster and hold in position until message "Service OIL" is cancelled. The trip recorder display will now read "Service - - -".
5. Press trip recorder reset button again to call up next service message. The message "Service INSP" will appear on the trip recorder display.
6. Pull out clock adjuster knob in instrument cluster and hold in position until message "Service INSP" is cancelled. The trip recorder display will now read "Service -".
7. Switch ignition off.

The instrument cluster is equipped with a flexible Service Reminder Indicator (SRI), that is, the instrument cluster evaluates various service requirements of the vehicle based on input quantities such as driveability or oil consumption, (not for USA)

For the standard SRI (with set intervals that could not be influenced by how the vehicle was driven) the service interval was set to 30,000 km or 12 months, and the oil change service was set to 15,000 km.

The maintenance interval extension (MIE) is capable of reproducing the functions of the standard SRI, when the limits are set correctly. The limits are variable however. The MIE is also capable of evaluating the oil temperature sensor. Adaptation channels in the VAG On Board Diagnostic (OBD) make this possible.

In countries where the standard SRE is still used, such as the USA, the following adaptation values must be entered

SRE VALUES WITHOUT MAINTENANCE INTERVAL EXTENSION

The instrument cluster in the Audi A6 Highline comes standard with the driver information system.

The speedometer contains an LCD display for the odometer and trip odometer. The service reminder indicator (SRI) is shown in the center display.

The warning/ indicator lights are integrated in the speedometer and tachometer.

The instrument cluster is controlled by a microprocessor and has extensive On Board Diagnostic (OBD) capabilities. If malfunctions occur in any of the system components, corresponding Diagnostic Trouble Codes (DTC) are stored in the DTC memory of the instrument cluster. These can then be identified using the VAG1551 or VAG1552 Scan Tool (ST).

For details about the instrument cluster, see the owner's manual.

Note. The description in this repair manual only refers to the VAG1551 Scan Tool (ST).

Malfunction message "dEF" on trip odometer display

If the control module in the instrument cluster detects a malfunction in its permanent memory, the letters "dEF" will appear on the trip odometer display.

1. If "dEF" is indicated on display, replace instrument cluster. See «INSTRUMENTS - UP TO 2000»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) .

Notes for replacing instrument cluster

1. Do not disassemble instrument cluster.
2. If necessary, instrument cluster should be replaced through the exchange loop.
3. Fill out a damage report form and return together with faulty instrument cluster.
4. Faulty units must always be returned in original packaging.
5. The odometer and the Service Reminder Indicator (SRI) on the replacement instrument cluster can be adapted using the VAG1551 Scan Tool (ST). See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Additional information

1. Electrical Wiring Diagrams & Component Locations
2. Service tools handbook
3. Parts catalog

Safety Precautions

If special testing equipment is required during test drive, note the following

To reduce the risk of personal injury and/or damage of electric and electronic components, always observe the following

1. Always switch ignition off before connecting or disconnecting test/measurement tools.
2. It is possible that the control module will recognize a malfunction and store a DTC during some tests. After completing all tests and repairs, DTC memory should therefore be checked and erased if necessary.
3. Always switch ignition off before disconnecting or connecting battery. Failure to do so may damage a control module.

Test requirements

1. Check fuse for function according to wiring diagram.
2. Always check coding of instrument cluster according to code table. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. Connect VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
4. Switch on ignition.

Note. If nothing is indicated on display, check voltage supply for VAG 1551 scan tool according to wiring diagram. Additional instructions can be called up via the -HELP-button on the scan tool. The --> -button is used for advancing through the program sequence. An incorrect entry can be canceled using the C- button. Function 00 "Automatic test sequence" can be performed in operating mode 1 "Rapid data transfer". This automatically checks all control modules installed in the vehicle.

1. Switch on ignition.
2. Switch printer on via the print-button (indicator lamp in button lights up).
3. Press button -1- to select "Rapid data transfer" operating mode 1.

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (1 Of 8). Scheme 142

Address word: 17

1. Press buttons -1- and -7-.

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (2 Of 8). Scheme 143

1. Press -Q- button to confirm input.

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (3 Of 8). Scheme 144

Indicated on display after approx. 5 seconds

1. 4B0920980E: Part number of instrument cluster (see also parts catalog)
2. C5 Instrument Cluster: component marking
3. VDO: Manufactured by VDO (M73 : Manufactured by Magneti Marelli)
4. X17: Software version of instrument cluster
5. Coding 02283: Coding of instrument cluster
6. WSC 06812: dealership number

Note. Check code number using coding table. See READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) .

1. Press --> button.

If one of these messages is indicated on the display

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (4 Of 8). Scheme 145

or

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (5 Of 8). Scheme 146

or

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (6 Of 8). Scheme 147

or

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (7 Of 8). Scheme 148

1. Check wiring connections for Data Link Connector (DLC).

Indicated on display

VAG 1551 Scan Tool Display - OBD, Instrument Cluster With Maintenance Interval Extension (8 Of 8). Scheme 149

1. Pressing the -HELP- button will print out an overview of all of the possible functions.

The following functions are possible

1. 02 - Check DTC Memory. See «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__check-dtc-memory) .
2. 03 - Output Diagnostic Test Mode. See «OUTPUT DIAGNOSTIC TEST MODE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__output-diagnostic-test-mode) .
3. 05 - Erase DTC Memory. See «ERASE DTC MEMORY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__erase-dtc-memory) .
4. 06 - End Output. See «END OUTPUT»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__end-output) .
5. 07 - Code Control Module. See «CODE CONTROL MODULE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__code-control-module) .
6. 08 - Read Measuring Value Block. See «MEASURING VALUE BLOCK, READING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
7. 10 - Adaptation. See «ADAPTATION»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation) .

Check DTC Memory

Note. The displayed DTC information is updated only when initiating OBD or with "Erase DTC Memory" function 05.

1. Switch printer on via the print-button (indicator lamp in button lights up).

Indicated on display

VAG 1551 Scan Tool Display - Check DTC MemoryOBD, Instrument Cluster With Maintenance Interval Extension (1 Of 5). Scheme 150

1. Press buttons -0- and -2-. This selects "Check DTC memory," function 02.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC MemoryOBD, Instrument Cluster With Maintenance Interval Extension (2 Of 5). Scheme 151

1. Press -Q- button to confirm input.

VAG 1551 Scan Tool Display - Check DTC MemoryOBD, Instrument Cluster With Maintenance Interval Extension (3 Of 5). Scheme 152

The number of stored malfunctions appears in the display.

The stored malfunctions are displayed and printed out one after the other.

1. Check print-out against DTC table and repair all malfunctions as necessary. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__diagnostic-trouble-code-dtc-table) .

If "No DTC recognized!" is displayed, the program will return to "Select function XX" after the --> - button is pressed.

VAG 1551 Scan Tool Display - Check DTC MemoryOBD, Instrument Cluster With Maintenance Interval Extension (4 Of 5). Scheme 153

Indicated on display

VAG 1551 Scan Tool Display - Check DTC MemoryOBD, Instrument Cluster With Maintenance Interval Extension (5 Of 5). Scheme 154

If something else is displayed, see scan tool operating instructions.

1. End Output (function 06). See «END OUTPUT (SCAN TOOL FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Switch off ignition and disconnect diagnostic connector.

Diagnostic Trouble Code (DTC) table

1. The following table lists all malfunctions that can be recognized by the instrument cluster and printed out by the VAG1551 scan tool. The malfunctions are listed in order according to their 5-digit numbers.
2. DTC numbers appear only on the print-out.
3. Before replacing a component shown as faulty, check the wiring and connections to the component as well as the Ground (GND) connections according to wiring diagram.
4. After repairs and function test of the system, DTC memory must always be checked again using the VAG1551 scan tool and erased.
5. DTC memory records all static and sporadic malfunctions: If a malfunction occurs and persists for at least 2 seconds, it is identified as a static malfunction (outside temperature malfunction at least 60 seconds, coolant temperature sensor only after at least 30 minutes with engine running). If a malfunction does not occur again, it is registered as sporadic. 7SP" will appear at right on scan tool display.
6. When the ignition is switched on, all existing malfunctions are automatically re-classified as sporadic malfunctions and will only register as static malfunctions if they still occur after testing.
7. Sporadic malfunctions which no longer occur during 50 driving cycles (ignition on at least 5 minutes, vehicle speed 30 km/h) are erased automatically.

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (00562, 00667 And 00668). Scheme 155

1. To diagnose A/C system, see «ON BOARD DIAGNOSTIC (OBD)»(/audi/a6/c5-1997-2001/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac) .

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (00771, 00779 And 01039). Scheme 156

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (01300 And 01304). Scheme 157

1. For measuring value block that indicates whether navigation control module supports CAN, see «MEASURING VALUE BLOCK 140»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. For adaptation values, see «EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR INFORMATION DATA-BUS)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (01311). Scheme 158

1. For measuring value block that indicates whether control module supports CAN, see «MEASURING VALUE BLOCK 140»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. For adaptation values, see «EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR INFORMATION DATA-BUS)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. For data exchange, see «DATA EXCHANGE BETWEEN CONTROL MODULES, CHECKING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__data-exchange-between-control-modules-checking) .

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (01312 And 01314). Scheme 159

1. For measuring value block that indicates whether a powertrain control module supports CAN, see «MEASURING VALUE BLOCK 125»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. To select adaptation values, see «EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR POWERTRAIN DATA-BUS)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (01315 And 01320). Scheme 160

1. For measuring value block that indicates whether a powertrain control module supports CAN, see «MEASURING VALUE BLOCK 125»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. To select adaptation values, see «EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR POWERTRAIN DATA-BUS)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Diagnostic Trouble Code Table - Instrument Cluster With Maintenance Interval Extension (01336 And 01402). Scheme 161

1. For measuring value block that indicates whether a comfort system control module supports CAN, see «MEASURING VALUE BLOCK 130»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. To select adaptation values, see «DATA EXCHANGE BETWEEN CONTROL MODULES, CHECKING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__data-exchange-between-control-modules-checking) .

Output Diagnostic Test Mode

1. Output Diagnostic Test Mode is only possible when vehicle is stationary and engine is not running!
2. If malfunctions are found during output Diagnostic Test Mode, determine cause of malfunction and replace instrument cluster if necessary.

During the "output Diagnostic Test Mode" function, all actuators that are installed in the instrument cluster and coded are activated in sequence.

1. There is also a simultaneous parallel sweep through the indicator range of all analog display instruments (Engine Coolant Temperature (ECT) gauge, tachometer, speedometer, fuel gauge)
2. Activation of warning lamps
3. Activation of seat belt warning light
4. Activation of chime
5. Segment test of driver information system, LCD clock/date display, and LCD trip odometer.
6. Test of instrument cluster lighting, including dimmer

Note. Test can only be performed with lights switched on.

Initiating output Diagnostic Test Mode

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Select Function XX). Scheme 162

1. Press buttons -0- and -3-. This selects "output Diagnostic Test Mode (DTM)," function 3.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension. Scheme 163

1. Press -Q- button to confirm input: Output Diagnostic Test Mode for analog displays is initiated immediately.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Analog Indicator). Scheme 164

The following tests are performed simultaneously

1. Sweep of coolant temperature needle through entire display range
2. Sweep of tachometer needle through entire display range
3. Sweep of speedometer needle through entire display range
4. Sweep of fuel gauge needle through entire display range

After sweep of display ranges, the following fixed values are displayed

Engine Coolant Temperature (ECT) gauge: 1/2

Tachometer: 3000 1/min

Speedometer: 62 mph

Fuel gauge: 1/2

Note. Switching ignition on and off will stop any needle sweep that has started.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Controlled Light Test Instrument Cluster). Scheme 165

All lamps are switched on that are activated by the processor.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Seatbelt Warning Light). Scheme 166

Seat belt warning light is activated.

Note. Depending on options/version, the seat belt warning light may be activated by the control module coding, that is, if this actuator test is omitted, the warning light is not active.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Gong). Scheme 167

Chime is activated and sounds the entire time.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Segment Test). Scheme 168

All display points of the driver information display, the LCD clock/date indicator and the LCD trip odometer are activated.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Switch And Instrument Lighting). Scheme 169

Instrument cluster illumination is automatically set twice to bright and dark and then switched to maximum illumination (bright).

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (End). Scheme 170

1. Press --> button to end output Diagnostic Test Mode.

The tester returns to the "Select function" mode.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Instrument Cluster With Maintenance Interval Extension (Select Function XX). Scheme 171

Erase DTC Memory

Note. If DTC memory cannot be erased, check DTC memory again and repair malfunction.

1. DTC memory checked. See «CHECK DTC MEMORY (SCAN TOOL FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. All malfunctions repaired.

After successful DTC memory check

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (1 Of 6). Scheme 172

1. Press buttons -0- and -5-. This selects "Erase DTC memory," function 05.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (2 Of 6). Scheme 173

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (3 Of 6). Scheme 174

DTC memory is erased.

1. Press --> -button.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (4 Of 6). Scheme 175

Note. Test sequence is faulty if message in (Scheme 176) or (Scheme 177) is displayed.

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (5 Of 6). Scheme 176

VAG 1551 Scan Tool Display - Erase DTC Memory, Instrument Cluster With Maintenance Interval Extension (6 Of 6). Scheme 177

Follow test sequence exactly: first check DTC memory, repair malfunction(s) if necessary, then erase.

End Output

Indicated on display

VAG 1551 Scan Tool Display - End Output, Instrument Cluster With Maintenance Interval Extension (1 Of 3). Scheme 178

1. Press buttons -0- and -6-. This selects "End Output," function 06.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Instrument Cluster With Maintenance Interval Extension (2 Of 3). Scheme 179

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Instrument Cluster With Maintenance Interval Extension (3 Of 3). Scheme 180

1. Switch off ignition.
2. Disconnect harness connectors for the VAG1551 scan tool

Code Control Module

Using this function, the instrument cluster can be coded as follows

1. Optional equipment
2. Market and language versions
3. Number of cylinders
4. Engine versions

Note. Coding adjusts the various combination possibilities of the on board computer according to engine type, cylinder count and country version. The code table lists only those combinations applicable to the Audi A6.

Initiating coding

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster With Maintenance Interval Extension (1 Of 5). Scheme 181

1. Press buttons -0- and -7-. This selects "Coding Control Module," function 07.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster With Maintenance Interval Extension (2 Of 5). Scheme 182

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster With Maintenance Interval Extension (3 Of 5). Scheme 183

1. Input code number using coding table. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Example: 02283

02 Optional equipment

2 USA

8 8-cylinder

3 8-cylinder gasoline engine

1. Indicated on display see scheme 186: VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster With Maintenance Interval Extension (4 Of 5)
2. Press -Q- button to confirm input.

Indicated on display after approx. 5 seconds

VAG 1551 Scan Tool Display - Code Control Module, Instrument Cluster With Maintenance Interval Extension (5 Of 5). Scheme 184

1. Press --> button.

Coding Table - Instrument Cluster With Maintenance Interval Extension. Scheme 185

Note. Coding can be modified to allow for various combinations of optional equipment, depending on what is installed in the vehicle. If vehicle is equipped with more than one item of optional equipment and/or transmission variant that needs to be coded, the overall coding will be the total of the individual coding numbers.

Example

1. Larger fuel tank and seatbelt warning active 01 + 02 = 03

Initiating "Read Measuring Value Block"

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster With Maintenance Interval Extension (1 Of 3). Scheme 186

1. Press buttons -0- and -8-. This selects "Read measuring value block," function 08.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster With Maintenance Interval Extension (2 Of 3). Scheme 187

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Instrument Cluster With Maintenance Interval Extension (3 Of 3). Scheme 188

1. Enter display group number from table in «INITIATING "READ MEASURING VALUE BLOCK"»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__initiating-read-measuring-value-block) and press -Q- button to confirm input.

The selected measuring value block is now displayed in standard form.

Display group overview

Read Measuring Value Display Groups 001 To 011 - Instrument Cluster With Maintenance Interval Extension. Scheme 189

Read Measuring Value Display Groups 012 To 015 - Instrument Cluster With Maintenance Interval Extension. Scheme 190

Read Measuring Value Display Groups 050 To 140 - Instrument Cluster With Maintenance Interval Extension. Scheme 191

Note. For an instrument cluster replacement, data from display groups 10... 15 must be printed out. Measuring value blocks 125 and 126 indicate the components that are part of the powertrain data bus. Measuring value block 130 indicates the components that are part of the comfort system data-BUS. Measuring value block 140 indicates the components that are part of the information data-BUS Display will always indicate the actual values obtained from the sensors. The values which appear on the instrument cluster are filtered and may be different. If the actual engine coolant temperature is between 80° C and 700° C, instrument cluster will always show 90° C.

Measuring Value Block 001 - Instrument Cluster With Maintenance Interval Extension. Scheme 192

Measuring Value Block 002 - Instrument Cluster With Maintenance Interval Extension. Scheme 193

Measuring Value Block 003 - Instrument Cluster With Maintenance Interval Extension. Scheme 194

Measuring Value Block 10 - Instrument Cluster With Maintenance Interval Extension. Scheme 195

Note. If the value "128" in display field 2 was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

Measuring Value Block 11 - Instrument Cluster With Maintenance Interval Extension. Scheme 196

Note. If the value "100" in display field 4 was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

Measuring Value Block 12 - Instrument Cluster With Maintenance Interval Extension. Scheme 197

Measuring Value Block 13 - Instrument Cluster With Maintenance Interval Extension. Scheme 198

1. 1) The currently valid specifications can be found in the "Maintenance" book.

Measuring Value Block 14 - Instrument Cluster With Maintenance Interval Extension. Scheme 199

1. 1) The currently valid specifications can be found in the "Maintenance" book.

Measuring Value Block 15 - Instrument Cluster With Maintenance Interval Extension. Scheme 200

1. 1) The currently valid specifications can be found in the "Maintenance" book.

1. Oil quality must be re-adapted after every service.

Measuring Value Block 50 - Instrument Cluster With Maintenance Interval Extension. Scheme 201

Measuring Value Block 125 - Instrument Cluster With Maintenance Interval Extension. Scheme 202

Measuring Value Block 126 - Instrument Cluster With Maintenance Interval Extension. Scheme 203

Measuring Value Block 130 - Instrument Cluster With Maintenance Interval Extension. Scheme 204

Measuring Value Block 140 - Instrument Cluster With Maintenance Interval Extension. Scheme 205

Adaptation

Individual functions are called up by entering the appropriate adaptation channel numbers (listed in the adaptation table under INITIATING "ADAPTATION" FUNCTION 10 ).

Note. Using measuring value blocks 10, 11, 12, 15 and 16, the values that need to be transferred to the new instrument cluster can be read out before replacement. Adaptation channels 42, 43, and 44 (see MEASURING VALUE BLOCK 13 and MEASURING VALUE BLOCK 14 ) must be adapted according to the oil quality (see MEASURING VALUE BLOCK 15 . Adaptation channels 60, 61, and 62 are only needed when the instrument cluster communicates with the corresponding BUS system. MEASURING VALUE BLOCK 125 and MEASURING VALUE BLOCK 126 indicate the components that are part of the powertrain data-BUS. MEASURING VALUE BLOCK 130 indicates the components that are part of the comfort system data-BUS. MEASURING VALUE BLOCK 140 indicates the components that are part of the information data-BUS.

Adaptation table

ADAPTATION TABLE - INSTRUMENT CLUSTER WITH MAINTENANCE INTERVAL EXTENSION

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Instrument Cluster With Maintenance Interval Extension (1 Of 3). Scheme 206

1. Press buttons -1- and -0-. This selects "Adaptation," function 10.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Instrument Cluster With Maintenance Interval Extension (2 Of 3). Scheme 207

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Instrument Cluster With Maintenance Interval Extension (3 Of 3). Scheme 208

1. Enter desired adaptation channel (adaptation table under «INITIATING "ADAPTATION" FUNCTION 10»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) ).
2. Press -Q- button to confirm input.

Note. After changing an adaptation value or ending an adaptation channel, "Adaptation" function 10 must be performed again before selecting another adaptation channel.

Resetting SRI after service

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 209

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 210

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 211

1. Press buttons -0- and -2-.
2. Press -Q- button to confirm input.

Note. The Service Reminder Indicator (SRI) reminds the driver when service is necessary. Indication is in center display. Service reminder appears 1 month or 1200 miles before service limit is reached. Resolution is 100 miles. Example for display: After a total driving distance of 7000 miles, "SERVICE IN 1000 miles" is indicated. The remaining distance to service can be checked via the menu in center display by pressing the clock set button once. When a service event arrives, the text information appears in the center display for 5 seconds when ignition is switched on. It is shown after the note for automatic transmission and a target input for navigation (if applicable). Display: "SERVICE!". The currently valid specifications can be found in the "Maintenance" book. Data version of instrument cluster. See ON BOARD DIAGNOSTIC (OBD) FUNCTIONS . Channels 40, 41, 46, 47 and 48 which display the dynamic value of the service event are set to "0" automatically.

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 212

Indicated on display: Service event is displayed

1 - means service is active, for example "SERVICE!" is displayed in the instrument cluster.

Note. Only reset SRI via direct input.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 213

Service event is reset using the following adaptation values

SRI ADAPTATION VALUE - INSTRUMENT CLUSTER WITH MAINTENANCE INTERVAL EXTENSION

1. Using the keypad enter the appropriate adaptation value (00000) to erase the service.
2. Press -0- button five times.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 214

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 215

0 - means service is reset, that is, after confirming with -Q- button, "SERVICE IN 8000 miles" is displayed in the instrument cluster.

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 216

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Resetting SRI After Service, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 217

1. Press the --> button to complete the reset of the SRI.

Adaptation of fuel consumption display

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (1 Of 12). Scheme 218

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (2 Of 12). Scheme 219

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (3 Of 12). Scheme 220

1. Press buttons -0- and -3-.
2. Press -Q- button to confirm input.

Note. Adaptation only for vehicles with on board computer. Value entered must be between 85% and 115%. Value must be entered in steps of 5%. If the value "100" was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (4 Of 12). Scheme 221

1. Press --> button.

Note. Correction of fuel consumption display is only possible via direct input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (5 Of 12). Scheme 222

1. Input desired correction value using scan tool keypad, filling initial positions with "0".

Example

Desired input value: 90%

Keypad input: 00090

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (6 Of 12). Scheme 223

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (7 Of 12). Scheme 224

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (8 Of 12). Scheme 225

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (9 Of 12). Scheme 226

1. Conclude adaptation of the fuel consumption display by pressing the --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (10 Of 12). Scheme 227

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Consumption, Instrument Cluster With Maintenance Interval Extension (11 Of 12). Scheme 228

1. Press -Q- button to confirm input.

Note. If input is incorrect, tester switches to function mode.

Indicated on display

1. Press --> button.
2. Select "Adaptation" function 10 again and select adaptation channel 03.
3. Perform correction of fuel consumption display again.

Language version of driver information display

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (1 Of 13). Scheme 229

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (2 Of 13). Scheme 230

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (3 Of 13). Scheme 231

1. Press buttons -0- and -4-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (4 Of 13). Scheme 232

Note. Display indicates only the last digit of the five digit language version code, for example, 1 for German. If incorrect value is input "Adaptation" function is terminated and "Adaptation" function 10 must be initiated again. Code can now be entered using the scan tool keypad in steps or via direct input.

Coding table

LANGUAGE VERSION CODING - INSTRUMENT CLUSTER WITH MAINTENANCE INTERVAL EXTENSION

Input in steps

1. Code can be decreased using button 1 and increased using button 3, for example, to 2 for language version English.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (5 Of 13). Scheme 233

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (6 Of 13). Scheme 234

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (7 Of 13). Scheme 235

1. Conclude adaptation of language version by pressing the --> button.

Direct input

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (8 Of 13). Scheme 236

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (9 Of 13). Scheme 237

1. Input desired five digit code ( «ODOMETER DISPLAY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__odometer-display) ) using keypad.

Example

Coding: 2 (English)

Input value: 00002

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (10 Of 13). Scheme 238

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (11 Of 13). Scheme 239

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (12 Of 13). Scheme 240

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Language Version Of Driver Information, Instrument Cluster With Maintenance Interval Extension (13 Of 13). Scheme 241

1. Conclude adaptation of language version by pressing the --> button.

Odometer display

This function is used to adapt the odometer after the instrument cluster is replaced.

Note. Adaptation can only be performed on an instrument cluster with an odometer reading of no more than 62 miles. Adaptation can only be performed once for each instrument cluster. Only higher adaptation values can be entered (more than 62 miles). If an incorrect value is entered and confirmed, it cannot be changed. If this happens, the instrument cluster must be replaced. In countries where speedometers are calibrated in miles, adaptation can be performed in miles. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES .

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (1 Of 13). Scheme 242

1. Press buttons -1- and 1-. This selects "Logon Procedure" function 11.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (2 Of 13). Scheme 243

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (3 Of 13). Scheme 244

1. Input code number 13861.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (4 Of 13). Scheme 245

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (5 Of 13). Scheme 246

1. Press buttons -1- and -0-.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (6 Of 13). Scheme 247

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (7 Of 13). Scheme 248

1. Press buttons -0- and -9-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (8 Of 13). Scheme 249

Note. For the VAG1551 scan tool values can only be input via direct input.

1. Press the --> button to continue program sequence.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (9 Of 13). Scheme 250

1. Input adaptation value using keypad.

Example

Mileage = 89627

0 8 9 6 3

ENTERING INPUT ADAPTATION VALUE 89627 MILEAGE

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (10 Of 13). Scheme 251

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (11 Of 13). Scheme 252

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (12 Of 13). Scheme 253

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Odometer Display, Instrument Cluster With Maintenance Interval Extension (13 Of 13). Scheme 254

1. End adaptation of odometer by pressing the --> button.

Adaptation of auxiliary heater

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 255

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 256

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 257

1. Press buttons 1- and -8-.
2. Press -Q- button to confirm input.

1. Indicated on display: Adaptation value is displayed, for example 0.

VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 258

Note. Adaptation value "0" is input if auxiliary heater is not installed. Adaptation value "1" is input if an auxiliary heater is installed that is independent of engine condition (running or not). Adaptation value "10" is input if an auxiliary heater is installed that switches off when engine is not running.

Scheme 259

Scheme 260

1. Press --> button.
2. Indicated on display (Scheme 259): VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (5 Of 9)
3. Input adaptation value using keypad, filling initial positions with "0," for example 00001.
4. Indicated on display (Scheme 260): VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (6 Of 9)
5. Press -Q- button to confirm input.
6. Indicated on display see scheme 265: VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (7 Of 9)
7. Press -Q- button to confirm input.
8. Indicated on display see scheme 266: VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (8 Of 9)
9. Press -Q- button to confirm input.
10. Indicated on display see scheme 267: VAG 1551 Scan Tool Display - Adaptation Of Auxiliary Heater, Instrument Cluster With Maintenance Interval Extension (9 Of 9)
11. End adaptation of the auxiliary heater by pressing the --> button.

This function is used to adjust the fuel gauge sender resistance range if the fuel gauge display in the instrument cluster does not match the actual amount of fuel in the tank.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 261

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 262

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 263

1. Press buttons 3- and -0-.
2. Press -Q- button to confirm input.

1. Indicated on display: Adaptation value is displayed, for example 128. (Scheme 264): VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (4 Of 9)

Note. "128" is the adaptation value for the standard resistance range for the fuel gauge sender as set by the factory. The resistance value for the fuel gauge sender resistance range can be adjusted by +8 Ohm to give an adaptation value between 120 and 136.. If the value "128" was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

1. Press --> button.
2. Indicated on display (Scheme 265): VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (5 Of 9)
3. Input desired correction value using scan tool keypad, filling initial positions with "0" and watch how the display responds.

Example

Desired input value: 132

Keypad input: 00132

Scheme 264

Scheme 265

Scheme 266

1. Indicated on display (Scheme 266): VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (6 Of 9)
2. Press -Q- button to confirm input.
3. Indicated on display see scheme 274: VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (7 Of 9)
4. Press -Q- button to confirm input.
5. Indicated on display see scheme 275: VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (8 Of 9)
6. Press -Q- button to confirm input.
7. Indicated on display see scheme 276: VAG 1551 Scan Tool Display - Adaptation Of Fuel Gauge Sender Resistance Range, Instrument Cluster With Maintenance Interval Extension (9 Of 9)
8. End adaptation of the fuel gauge sender resistance range by pressing the --> button.

Adaptation of the engine speed threshold

This function is used to adapt the offset value for the engine speed threshold to the dynamic oil pressure warning.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 267

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 268

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 269

1. Press buttons -3- and -5-.
2. Press -Q- button to confirm input.
3. Indicated on display: Adaptation value is displayed, for example 0. (Scheme 270): VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (4 Of 9)

Note. The adaptation value of 0 corresponds to the value set at the factory for the oil pressure warning if the oil pressure drops below 1.2 bar at 1500 rpm. The adaptation can be performed in four steps (0-1000). The adaptation value of "250" changes the engine speed threshold to 1750 rpm. If the value "0" was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

1. Press --> button.
2. Indicated on display (Scheme 271): VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension(5 Of 9)
3. Input adaptation value using keypad, filling initial positions with "0," for example, 00250.
4. Indicated on display (Scheme 272): VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (6 Of 9)
5. Press -Q- button to confirm input.

Scheme 270

Scheme 271

Scheme 272

1. Indicated on display see scheme 283: VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (7 Of 9)
2. Press -Q- button to confirm input.
3. Indicated on display see scheme 284: VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (8 Of 9)
4. Press -Q- button to confirm input.
5. Indicated on display see scheme 285: VAG 1551 Scan Tool Display - Adaptation Of Engine Speed Threshold, Instrument Cluster With Maintenance Interval Extension (9 Of 9)
6. End adaptation of the engine speed threshold by pressing the --> button.

Distance driven since service

This function is used to input the distance in miles since the last service.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 273

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 274

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 275

1. Press buttons -4- and 0-.
2. Press -Q- button to confirm input.

Indicated on display: The display indicates the number of kilometers driven since the last service (here for example, 8 indicates 800 miles)

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 276

Note. Input of current specified value is only possible in units of 100, indication in display also changes by units of 100. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Values can only be input directly using the scan tool keypad. In countries where speedometers are calibrated in miles, adaptation can be performed in miles. If an incorrect value is input, the "Adaptation" function is terminated and must be re-initiated.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 277

1. Input desired value using scan tool keypad, filling initial positions with "0".

Example

Desired input value: for example, 1000 miles

Keypad input: 00010

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 278

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 279

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 280

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Distance Driven Since Service, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 281

1. End adaptation of distance driven since service by pressing the --> button.

Time since service

This function is used to input the time in days since the last service.

Indicated on display

VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 282

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 283

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 284

1. Press buttons -4- and 1-.
2. Press -Q- button to confirm input.
3. Indicated on display: Time in days since last service is displayed (here for example 110 represents 110 days) (Scheme 285): VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (4 Of 9)

Note. Input of the current specified value is only possible in units of one day, indication in display also changes by units of one day. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES . Values can only be input directly using the scan tool keypad. If an incorrect value is input, the "Adaptation" function is terminated and must be re-initiated.

1. Press --> button.
2. Indicated on display (Scheme 286): VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (5 Of 9)
3. Input desired value using scan tool keypad, filling initial positions with "0".

Example

Desired input value: for example 200 days

Keypad input: 00200

Scheme 285

Scheme 286

Scheme 287

1. Indicated on display (Scheme 287): VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (6 Of 9)
2. Press -Q- button to confirm input.
3. Indicated on display see scheme 301: VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (7 Of 9)
4. Press -Q- button to confirm input.
5. Indicated on display see scheme 302: VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (8 Of 9)
6. Press -Q- button to confirm input.
7. Indicated on display see scheme 303: VAG 1551 Scan Tool Display - Time Since Service, Instrument Cluster With Maintenance Interval Extension (9 Of 9)
8. End adaptation of time since service by pressing the --> button.

Minimum mileage

This function is used to set a fixed minimum mileage in the instrument cluster for the SRI.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 288

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 289

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 290

1. Press buttons 4- and -2-.
2. Press -Q- button to confirm input.

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 291

Indicated on display: Factory adjusted value for the minimum mileage (in miles) until next service is displayed (here for example 8 represents 8000 miles)

Note. The currently valid specifications can be found in the "Maintenance" book. Input of current specified value is only possible in units of 1000, indication in display also changes by units of 1000. In countries where speedometers are calibrated in miles, adaptation can be performed in miles. When replacing instrument cluster, this value is already set. Values can only be input directly using the scan tool keypad. If an incorrect value is input, the "Adaptation" function is terminated and must be re-initiated.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 292

1. Input specified value using keypad, filling initial positions with "0".

Specification: 8000

Keypad input: 00008

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 293

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 294

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 295

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Minimum Mileage, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 296

1. End adaptation of the minimum mileage by pressing the --> button.

Maximum mileage

This function is used to set a fixed maximum mileage in the instrument cluster for the SRI.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 297

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 298

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 299

1. Press buttons 4- and 3-.
2. Press -Q- button to confirm input.

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 300

Indicated on display: Factory adjusted value for the maximum mileage (in miles) until next service is indicated (here for example 8 represents 8000 miles)

Note. The adaptation value entered for the relevant engine variant must match the value in the table under MALFUNCTION MESSAGE "DEF" ON TRIP ODOMETER DISPLAY . The currently valid specifications can be found in the "Maintenance" book. Input of current specified value is only possible in units of 1000, indication in display also changes by units of 1000. In countries where speedometers are calibrated in miles, adaptation can be performed in miles. When replacing instrument cluster, this value is already set. Values can only be input directly using the scan tool keypad. If an incorrect value is input, the "Adaptation" function is terminated and must be re-initiated.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 301

1. Input specified value using keypad, filling initial positions with "0".

Input value: for example 8000 miles

Keypad input: 00008

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 302

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 303

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 304

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Mileage, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 305

1. Conclude adaptation of maximum mileage by pressing the --> button.

Maximum time interval

This function is used to set a fixed maximum time in days in the instrument cluster for the SRI.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 306

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 307

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 308

1. Press buttons -4- and 4-.
2. Press -Q- button to confirm input.
3. Indicated on display. The display indicates the maximum time interval in days to the next service (for example, 365 represents 365 days).

Note. The adaptation value input must match the value in the table under MALFUNCTION MESSAGE "DEF" ON TRIP ODOMETER DISPLAY . The currently valid specifications can be found in the "Maintenance" book. Input of the current specified value is only possible in units of one day, indication in display also changes by units of one day. When replacing instrument cluster, this value is already set. Values can only be input directly using the scan tool keypad. If an incorrect value is input, the "Adaptation" function is terminated and must be re-initiated.

1. Press --> button.
2. Indicated on display (Scheme 310): VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (5 Of 9)
3. Input specified value using keypad, filling initial positions with "0".

Input value: for example 365 days

Keypad input: 00365

Scheme 309

Scheme 310

1. Indicated on display see scheme 327: VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (6 Of 9)
2. Press -Q- button to confirm input.
3. Indicated on display see scheme 328: VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (7 Of 9)
4. Press -Q- button to confirm input.
5. Indicated on display see scheme 329: VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (8 Of 9)
6. Press -Q- button to confirm input.
7. Indicated on display see scheme 330: VAG 1551 Scan Tool Display - Maximum Time Interval, Instrument Cluster With Maintenance Interval Extension (9 Of 9)
8. End adaptation of maximum time interval by pressing the --> button.

Adaptation of oil quality

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 311

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 312

1. Press buttons -4- and 5-.
2. Press -Q- button to confirm input.

Note. The oil quality must be adapted after every service. The adaptation value can be set between 1-4. Every value between 1-4 has a corresponding maximum mileage (channel 43) and a maximum time (channel 44). The adaptation value entered for the relevant engine variant must match the value in the table under MALFUNCTION MESSAGE "DEF" ON TRIP ODOMETER DISPLAY . The currently valid specifications can be found in the "Maintenance" book.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 313

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 314

1. Input specified value using keypad, filling initial positions with "0."

Input value: for example, 1 (for US models)

Keypad input: 00001

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 315

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 316

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 317

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Oil Quality, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 318

1. Conclude adaptation of oil quality by pressing the --> button.

Adaptation of total consumption quantity

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 319

1. Press -1- and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 320

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 321

1. Press buttons -4- and -6-.
2. Press -Q- button to confirm input.

Note. Displayed value must be transferred when replacing instrument cluster. The value indicated in liters does not represent actual consumption, but rather a value for the Service Reminder Indicator (SRI) calculated from various engine data.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 322

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 323

1. Input the indicated value of the old instrument cluster into the new instrument cluster using the scan tool keypad, filling initial positions with "0".

Desired input value: 300 liters

Keypad input: 00300

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 324

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 325

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 326

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation Of Total Consumption Quantity, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 327

1. Conclude adaptation of total consumption quantity by pressing the --> button.

Adaptation for powertrain data-BUS

Note. The adaptation values of the table under ADAPTATION FOR COMFORT SYSTEM DATA-BUS are input. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES .

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 328

1. Press -1 - and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 329

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 330

1. Press buttons 6- and -0-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 331

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 332

1. Using the table in «ADAPTATION FOR COMFORT SYSTEM DATA-BUS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-for-comfort-system-data-bus) , input desired value using scan tool keypad, filling initial positions with "0".

for example desired input value: 1033 for manual transmission

Keypad input: 01033

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 333

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 334

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 335

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Powertrain Data-BUS, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 336

1. Conclude adaptation of powertrain data-BUS by pressing the --> button.

Table

EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR POWERTRAIN DATA-BUS)

Installed control modules that participate in the information system data-BUS ( MEASURING VALUE BLOCK 125 and MEASURING VALUE BLOCK 126 ) are added.

Note. The instrument cluster, which supports CAN, is not indicated in the measuring value block, but must be added anyway.

Example: Manual transmission

1. Engine + A/C + instrument cluster = 1 + 8 + 1024 = 1033

Example: Automatic transmission

1. Engine + transmission + A/C + instrument cluster = 1 +2 + 8 + 1024 = 1035

Adaptation for comfort system data-BUS

Note. The adaptation values of the table in ADAPTATION FOR INFORMATION DATA-BUS are input. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES .

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 337

1. Press -1 - and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 338

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 339

1. Press buttons 6- and 1-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 340

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 341

1. Using table in «ADAPTATION FOR INFORMATION DATA-BUS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-for-information-data-bus) , input desired value using scan tool keypad, filling initial positions with "0".

for example desired input value: 768 with tire pressure control

Keypad input: 00768

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 342

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 343

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 344

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Comfort System Data-BUS, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 345

1. Conclude adaptation of comfort system data-BUS by pressing the -->button.

Table

EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR COMFORT SYSTEM DATA-BUS)

Installed control modules that participate in the comfort system data-BUS ( MEASURING VALUE BLOCK 130 (Scheme 204) ) are added.

Note. The instrument cluster, which supports CAN, is not indicated in the measuring value block, but must be added anyway.

Example: Tire pressure control

1. Instrument cluster + tire pressure = 256 + 512 = 768

Adaptation for information data-BUS

Note. The adaptation values of the table in REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES are input. Observe notes when replacing instrument cluster. See REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES .

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (1 Of 9). Scheme 346

1. Press -1 - and -0- and confirm by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (2 Of 9). Scheme 347

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (3 Of 9). Scheme 348

1. Press buttons -6- and -2-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (4 Of 9). Scheme 349

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (5 Of 9). Scheme 350

1. Using table in «REPLACEMENT OF INSTRUMENT CLUSTER, INPUT VALUES»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) , input desired value using scan tool keypad, filling initial positions with "0".

for example desired input value: 5 Navigation system III (NS-Low) with radio (Symphony)

Keypad input: 00005

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (6 Of 9). Scheme 351

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (7 Of 9). Scheme 352

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (8 Of 9). Scheme 353

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation For Information Data-BUS, Instrument Cluster With Maintenance Interval Extension (9 Of 9). Scheme 354

1. Conclude adaptation of information data-BUS by pressing the --> button.

Table

EQUIPMENT ADAPTATION VALUE (ADAPTATION FOR INFORMATION DATA-BUS)

Installed control modules that participate in the information system data-BUS ( MEASURING VALUE BLOCK 140 ) are added.

The following must always be observed when replacing the instrument cluster

Note. Instrument cluster must always be coded. Note the values indicated in measuring value blocks 10... 15 on the VAG1551 scan tool before replacing. Note odometer reading before replacing and input according to instructions. In countries with speedometers calibrated in miles, adaptation of the Service Reminder Indicator (SRI) can be performed in miles.

Perform the following steps after replacing instrument cluster

1. Code Control Module. See «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

and

1. Adaptation of fuel gauge, see «ADAPTATION OF FUEL CONSUMPTION DISPLAY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-of-fuel-consumption-display) (for altered fixed value)
2. Language version of driver information display, see «LANGUAGE VERSION OF DRIVER INFORMATION DISPLAY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__language-version-of-driver-information-display) .
3. Adaptation of auxiliary heater, see «ADAPTATION OF FUEL GAUGE SENDER RESISTANCE RANGE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
4. Adaptation of fuel gauge sender resistance range, see «ADAPTATION OF FUEL GAUGE SENDER RESISTANCE RANGE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) (for altered fixed value)

1. Adaptation for distance driven since service, see «DISTANCE DRIVEN SINCE SERVICE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__distance-driven-since-service) .
2. Adaptation for time since service. See «TIME SINCE SERVICE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__time-since-service) .
3. Adaptation for oil quality. See «ADAPTATION OF OIL QUALITY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-of-oil-quality) .
4. Adaptation for maximum mileage, see «MAXIMUM MILEAGE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__maximum-mileage) .
5. Adaptation for maximum time interval, see «MAXIMUM TIME INTERVAL»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__maximum-time-interval) .
6. Adaptation for total consumption quantity, see «MAXIMUM TIME INTERVAL»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__maximum-time-interval) .
7. Adaptation for powertrain data-BUS. See «ADAPTATION FOR POWERTRAIN DATA-BUS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-for-powertrain-data-bus) .
8. For adaptation for comfort system databus, see «ADAPTATION FOR COMFORT SYSTEM DATA-BUS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-for-comfort-system-data-bus) .
9. For adaptation for information databus, see «ADAPTATION FOR INFORMATION DATA-BUS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__adaptation-for-information-data-bus) . and
10. Enter mileage. See «ODOMETER DISPLAY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__odometer-display) .

Resetting Service Reminder Indicator (SRI) after a service without using VAG1551/1552 ST

The service message must be reset after a service has been performed.

Re-setting the Service Reminder Indicator (SRI) can be performed with the VAG1551 Scantool in the "adaptation" function. See ADAPTATION .

The SRI can also be reset via the following procedure

1. Switch off ignition.
2. Press reset button for trip recorder in instrument cluster and switch on ignition at the same time.

The following appears in display after releasing trip recorder: "SERVICE IN ????MI" or "SERVICE!".

1. Turn adjustment button for clock in instrument cluster to left within 5 seconds until the message is reset to "SERVICE IN ????MI" or "SERVICE!"

The display reads: "SERVICE IN 8000 MI".

1. Switch off ignition.

Note. Channels 40, 41, 46, 47 and 48 which display the dynamic value of the service event are set to "0" automatically. For re-setting without VAG1551/1552, adaptation channels are set to the values shown in SRI ADAPTATION CHANNEL SETTING VALUES table.

SRI ADAPTATION CHANNEL SETTING VALUES

Data exchange between control modules, checking

Note. Data exchange between individual control modules occurs via a bus system. The term "CAN-bus" refers to a system that transports and distributes data. The wire connections between the control modules, via which data is transferred, are referred to as data wires. Data is transferred to the connected control modules serially (one after the other) across the data wires.

Checking bus system

The DTC table indicated that data exchange via the bus should be checked

1. Check to be sure the multi-pin connectors of the control modules are securely connected.
2. Connect the VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. Switch ignition on
4. Switch printer on via the print-button (indicator lamp in button lights up), (indicator lamp in button lights up).
5. Press button 1 to select "Rapid data transfer" operating mode 1.

Indicated on display

VAG 1551 Scan Tool Display - Data Exchange Between Control Modules, Instrument Cluster With Maintenance Interval Extension (1 Of 2). Scheme 355

Note. The address word 00 initiates the automatic test sequence, i.e. it results in a DTC check on all OBD capable systems in the vehicle via rapid data transfer.

When a control module responds with its identification, the display indicates the number of stored errors or indicates "no malfunctions recognized".

DTCs stored in the system are indicated sequence and printed out. Then the VAG1551 scan tool sends the next address word.

If a malfunction involving " ... databus" or " ... no communication" is indicated

Automatic test sequence is over when the following indication appears on the display

VAG 1551 Scan Tool Display - Data Exchange Between Control Modules, Instrument Cluster With Maintenance Interval Extension (2 Of 2). Scheme 356

1. Check whether the correct control module for this vehicle is installed (part number and coding).

If the correct control modules are installed, check the CAN bus system.

Checking a "two-line bus system"

Three or more control modules are communicating across a "two-line bus system".

1. Analyze the DTCs stored in the memories of the control modules.

This analysis will help you locate the cause of the line malfunction.

Example 1

From the DTCs stored in the memories, you have determined that control module 1 is not communicating with control modules 2 and 3.

Checking Two-Line Bus System - Control Module 1 Is Not Communicating With Control Modules 2 And 3. Scheme 357

DTC Memories Table - Control Module 1 Is Not Communicating With Control Modules 2 And 3, Example 1. Scheme 358

1. Switch ignition off.
2. Disconnect the control modules connected across the bus lines and check the bus lines for an open circuit.
3. If you cannot find a malfunction in the bus lines, replace control module 1.

Example 2

From the DTCs stored in the memories, you have determined that control module 2 is not communicating with control modules 1 and 3.

Checking Two-Line Bus System - Control Module 2 Is Not Communicating With Control Modules 1 And 3. Scheme 359

DTC Memories Table - Control Module 2 Is Not Communicating With Control Modules 1 And 3, Example 2. Scheme 360

1. Switch ignition off.
2. Disconnect the control modules connected across the bus lines and check the bus lines for an open circuit.
3. If you cannot find a malfunction in the bus lines, replace control module 2.

Example 3

Using the DTCs stored in the memories, you have determined that none of the control modules are sending or receiving signals.

DTC Memories Table - None Of The Control Modules Are Sending Or Receiving Signals, Example 3. Scheme 361

1. Switch ignition off. see scheme 383: Checking Two-Line Bus System - Short Circuits Between Bus Lines
2. Disconnect the control modules connected across the bus lines and check for short circuits between the bus lines. see scheme 384: Checking Two-Line Bus System - Bus Lines For Short Circuit To B+ Or Ground
3. Check the bus lines for short circuit to B+ or Ground (GND).

If you cannot determine a cause for the malfunction, e.g. "powertrain data-BUS faulty", check whether one of the control modules may be responsible for the DTC.

All control modules that use the CAN-bus are still disconnected. Ignition is switched off.

1. Connect one of the control modules.
2. Connect VAG 1551 scan tool. Switch ignition on, and erase the DTC memory of the control module you just connected. End scan tool output using the "End Output" function 06.
3. Switch ignition off and then on.
4. Leave ignition on for 10 seconds. Then, read the DTC memory of the control module you just connected.
5. If the DTC "powertrain data-BUS faulty" is displayed, replace the control module you just connected.
6. If the DTC "powertrain data-BUS faulty" is not displayed, connect the next control module and repeat the procedure.

1. Electrical Wiring Diagrams
2. Service tools handbook
3. Parts catalog

If special testing equipment is required during test drive, note the following

To reduce the risk of personal injury and/or damage of electric and electronic components, always observe the following

1. Always switch ignition off before connecting or disconnecting test/measurement tools.
2. It is possible that the control module will recognize a malfunction and store a DTC during some tests. After completing all tests and repairs, DTC memory should therefore be checked and erased if necessary.
3. Always switch ignition off before disconnecting or connecting battery. Failure to do so may damage a control module.

Checking cruise control system

1. Connect the VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Select the control module for engine electronics using address word 01.

Note. Except for operating switches, the cruise control system does not have any of its own components. All of its functions are controlled by the Engine Control Module (ECM).

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Cruise Control (1 Of 3). Scheme 362

1. Press buttons -0- and -8-. This selects "Read measuring value block," function 08.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Cruise Control (2 Of 3). Scheme 363

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block, Cruise Control (3 Of 3). Scheme 364

1. Input display group number 066 (engine must be running at idle)
2. Press -Q- button to confirm input.

The selected measuring value block is now displayed in standard form.

Measuring Value Block Display Group Overview - Cruise Control. Scheme 365

Measuring Value Block 66 - Cruise Control. Scheme 366

Indicated on display

VAG 1551 Scan Tool Display - Read Measuring Value Block 66 - Cruise Control. Scheme 367

Check indications in display fields 2 and 4

VAG 1551 Scan Tool Display - Read Measuring Value Block 66 - Cruise Control. Scheme 368

Check of indication in display field 2

TEST CONDITION: DISPLAY FIELD 2

If the specified value in display field 2 for "cruise control system release" (1000) is not obtained

1. Check control module identification of current Engine Control Module (ECM).

See appropriate article in ENGINE PERFORMANCE.

VAG1551 scan tool display indicates control module coding, for example

VAG 1551 Scan Tool Display - Control Module Coding, Example. Scheme 369

1. 4D0907558.. Control module number (see replacement parts program)
2. 4,2l Engine displacement
3. V8/5V Construction style of engine (V engine, 8 cylinder, 5 valves)
4. "G" i.e. no indication Vehicle with or without cruise control
5. 0003 Data version (software version) of control module
6. Coding 6752 Engine Control Module (ECM) coding
7. WSC 6812 Factory identification from VAG1551, with which the last coding was performed

1. If component identification "G" is displayed, cruise control must be activated. See «ACTIVATING CRUISE CONTROL SYSTEM»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__activating-cruise-control-system) .

Only for vehicles with automatic transmission

1. Road test vehicle and exceed 30 km at least once. Do not switch off engine upon completion. Leave selector lever in -2-, -3- or -D-.
2. Engage parking brake.

Note. For vehicles with automatic transmission, the voltage supply for the cruise control switch is not switched on until a speed of above 30 km/h is reached with selector lever in position -2-, -3- or -D-. The voltage supply will then be maintained at idle, as long as a driving mode (aside from -1- or -R-) is selected.

Check of indication in display field 4

VAG 1551 Scan Tool Display - Read Measuring Value Block 66 - Cruise Control. Scheme 370

TEST CONDITION: DISPLAY FIELD 4

If the specified values in display field 4 are not obtained, although switch B is set to "ON" (0011)

1. Connect VAG1598/31 test box to wiring harness for Engine Control Module (ECM). See «WIRE AND COMPONENT TEST USING VAG1598/31 TEST BOX»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__wire-and-component-test-using-vag159831) .

Identifying Cruise Control Switch (A And B). Scheme 371

Activating cruise control system

1. Connect the VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Select the control module for engine electronics using address word 01.

Indicated on display

VAG 1551 Scan Tool Display - Activating Cruise Control System (1 Of 2). Scheme 372

1. Press button -1 - twice for the "Login procedure" function and confirm input by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Activating Cruise Control System (2 Of 2). Scheme 373

1. Press buttons -1-, -1-, -4-, -6- and -3- to select code number 11463. Press -Q- button to confirm input.

Deactivating cruise control system

1. Connect the VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Select the control module for engine electronics using address word 01.

Indicated on display

VAG 1551 Scan Tool Display - Deactivating Cruise Control System (1 Of 2). Scheme 374

1. Press button -1 - twice for the "Login procedure" function and confirm input by pressing the -Q- button.

Indicated on display

VAG 1551 Scan Tool Display - Deactivating Cruise Control System (2 Of 2). Scheme 375

1. Press buttons -1 -, -6-, -1 -, -6- and -7- to select code number 16167. Press -Q- button to confirm input.

Wire and component test using VAG1598/31 test box

Note. VAG1598/31 test box is designed so that it can be simultaneously connected to the wiring harness at the Engine Control Module (ECM) and also to the ECM itself. This is advantageous because electronic engine control remains fully functional (e.g. measurement of signals with engine running) when the test box is attached. Relevant test procedures note whether Engine Control Module (ECM) should also be connected to the test box or not. Use the following for the test: VAG1526 voltage tester or the VAG1715 voltage tester and the VAG1527 diode test lamp. Always use adapter cables from VAG 1594 connector test kit for connecting special tools to the VAG 1598/31 test box. Perform adaptation of Engine Control Module (ECM) to throttle valve control module after reconnecting the Engine Control Module (ECM). See appropriate Multiport Fuel Injection (MFI) article in ENGINE PERFORMANCE.

1. Switch ignition off.
2. Remove cover of protective housing for control modules.
3. Using a screwdriver, carefully pry off retaining bracket (arrow).
4. Then disengage connector from control module and disconnect. see scheme 399: Prying Off ECM Retaining Bracket Using Screwdriver
5. Connect VAG1598/31 test box to connector of wiring harness. Ground (GND) clip at test box (not visible in illustration) must be clipped to battery minus. Relevant test procedures note whether Engine Control Module (ECM) should also be connected to the test box.
6. Perform test as described in relevant repair sequence. see scheme 400: Connecting VAG1598/31 Test Box To Connector Of Wiring Harness
7. Disconnect harness connector at cruise control switch. See «STEERING COLUMN SWITCHES, SERVICING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#lights-switches-exterior-up-to-2000__steering-column-switches-servicing).

Wire connection must be checked for short circuit to B+, Ground (GND) and for open circuit.

1. Check wire connection according to wiring diagram.

1. Repair open circuit or short circuit if necessary.

Cruise control switch must be replaced if wire connection is OK.

General information

When driving in reverse gear, the parking assistance system measures the distance between vehicle rear to an obstruction.

For this reason, four ultra sound sensors are installed in the rear bumper.

The sensors can be controlled in either the combined send/receive mode or in receive mode alone.

The rear sensors are switched off if a trailer hitch is attached and the trailer plug is connected.

Function

The Acoustic Parking System (APS) consists of

1. Control module for parking aid -J446
2. Left rear parking aid sensor -G203
3. Left rear center parking aid sensor -G204
4. Right rear center parking aid sensor -G205
5. Right rear parking aid sensor -G206
6. Warning buzzer for parking -H15

After switching ignition on, a self-test is performed that is completed in less than a second.

The control module is now permanently in operation, however the distance recognition is only activated with shifting into reverse gear.

When the parking assistance is ready, a short signal is sounded, (delay of one second for automatic vehicles due to P-D shift).

If during a self test a malfunction was detected in the system, a continuous tone will sound for 5 seconds.

The distance warning starts while driving in reverse gear from approx. 1.5 m to the obstruction. The warning consists of sound impulses with a duration of 75 ms.

The pauses between chime impulses get shorter as the gap between vehicles gets smaller. For gaps under 25 cm, the chime becomes constant, volume and pitch (frequency) can be adapted using the VAG1551. See ADAPTATION .

Special case: Driving backward along a wall

Note. The following description refers only to the VAG1551 Scan Tool (ST).

1. Electrical Wiring Diagrams & Component Locations
2. Service tools handbook
3. Parts catalog

If special testing equipment is required during test drive, note the following

To reduce the risk of personal injury and/or damage of electric and electronic components, always observe the following

1. Always switch ignition off before connecting or disconnecting test/measurement tools.
2. It is possible that the control module will recognize a malfunction and store a DTC during some tests. After completing all tests and repairs, DTC memory should therefore be checked and erased if necessary.
3. Always switch ignition off before disconnecting or connecting battery. Failure to do so may damage a control module.

1. Check fuse for function according to wiring diagram.

1. Connect the VAS5051 tester or VAG1551 scan tool. See «VAS 5051 VEHICLE DIAGNOSTIC, MEASURING AND INFORMATION SYSTEM OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Note. If nothing is indicated on display, check voltage supply for VAG 1551 scan tool according to wiring diagram. Additional instructions can be called up via the -HELP-button on the scan tool. The --> button is used for advancing through the program sequence. An incorrect entry can be canceled using the C- button. Function 00 "Automatic test sequence" can be performed in operating mode 1 "Rapid data transfer". This automatically checks all control modules installed in the vehicle.

1. Switch on ignition.
2. Switch printer on via the print-button (indicator lamp in button lights up).
3. Press button -1- to select "Rapid data transfer" operating mode 1.

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (1 Of 8). Scheme 376

Address word for Acoustic Parking System (APS): 76

1. Press buttons -7- and -6-.

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (2 Of 8). Scheme 377

1. Press -Q- button to confirm input.

Indicated on display after approx. 5 seconds

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (3 Of 8). Scheme 378

1. 8D0919283: Part number of control module for parking aid (see also parts catalog)
2. D02: Software version of control module for parking aid
3. Coding 01126: Coding of control module for parking aid
4. WSC 06812: dealership number

1. Press --> button.

If one of these messages is indicated on the display

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (4 Of 8). Scheme 379

or

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (5 Of 8). Scheme 380

or

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (6 Of 8). Scheme 381

or

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (7 Of 8). Scheme 382

1. Check wiring connections for Data Link Connector (DLC).

Indicated on display

VAG 1551 Scan Tool Display - Acoustic Parking System On Board Diagnostic (8 Of 8). Scheme 383

1. Pressing the -HELP- button will print out an overview of all of the possible functions.
2. Press the --> button to continue program sequence.

The following functions are possible

1. 01 - Check control module version. See «CHECK CONTROL MODULE VERSIONS»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__check-control-module-versions) .
2. 02 - Check DTC Memory. See «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. 05 - Erase DTC Memory. See «ERASE DTC MEMORY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
4. 06 - End Output. See «END OUTPUT»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
5. 07 - Code Control Module. See «CODE CONTROL MODULE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
6. 08 - Read Measuring Value Block. See «MEASURING VALUE BLOCK, READING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
7. 10 - Adaptation. See «ADAPTATION»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Check Control Module Versions

Indicated on display

VAG 1551 Scan Tool Display - Check Control Module Versions, Acoustic Parking System (1 Of 3). Scheme 384

1. Press buttons -0- and -1-. This selects "Check control module" function 01.

Indicated on display

VAG 1551 Scan Tool Display - Check Control Module Versions, Acoustic Parking System (2 Of 3). Scheme 385

1. Press -Q- button to confirm input.

Indicated on display after approx. 5 seconds

VAG 1551 Scan Tool Display - Check Control Module Versions, Acoustic Parking System (3 Of 3). Scheme 386

1. 8D0919283: Part number of control module for parking aid (see also parts catalog)
2. D02: Software version of control module for parking aid
3. Coding 01126: Coding of control module for parking aid
4. WSC 06812: dealership number

1. Press --> button.

Note. The displayed DTC information is updated only when initiating OBD or with "Erase DTC Memory" function 05.

1. Switch printer on via the print-button (indicator lamp in button lights up).

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Acoustic Parking System (1 Of 5). Scheme 387

1. Press buttons -0- and -2-. This selects "Check DTC memory," function 02.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memor, Acoustic Parking Systemy (2 Of 5). Scheme 388

1. Press -Q- button to confirm input.

The number of stored malfunctions appears in the display.

VAG 1551 Scan Tool Display - Check DTC Memory, Acoustic Parking System (3 Of 5). Scheme 389

The stored malfunctions are displayed and printed out one after the other.

1. Check print-out against DTC table and repair all malfunctions as necessary. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

If "No DTC recognized!" is displayed, the program will return to "Select function XX" after the --> - button is pressed.

VAG 1551 Scan Tool Display - Check DTC Memory, Acoustic Parking System (4 Of 5). Scheme 390

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Acoustic Parking System (5 Of 5). Scheme 391

If something else is displayed, see scan tool operating instructions.

1. End Output (function 06). See «END OUTPUT»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Switch off ignition and disconnect diagnostic connector.

1. The following table lists all malfunctions that can be recognized by the Acoustic Parking System (APS) and printed out by the VAG1551 scan tool. The malfunctions are listed in order according to their 5-digit numbers.
2. DTC numbers appear only on the print-out.
3. Before replacing a component shown as faulty, check the wiring and connections to the component as well as the Ground (GND) connections according to wiring diagram.
4. After repairs and function test of the system, DTC memory must always be checked again using the VAG1551 scan tool and erased.
5. DTC memory records all static and sporadic malfunctions: A malfunction is recognized as being static if it occurs for at least 2 seconds. If the malfunction is no longer recognized after that it is stored as sporadic malfunction. 7SP" will appear at right on scan tool display.
6. When the ignition is switched on, all existing malfunctions are automatically re-classified as sporadic malfunctions and will only register as static malfunctions if they still occur after testing.
7. Sporadic malfunctions which no longer occur during 50 driving cycles (ignition on at least 5 minutes, vehicle speed 30 km/h) are erased automatically.

Diagnostic Trouble Code Table - Acoustic Parking System (01543 And 01545). Scheme 392

Diagnostic Trouble Code Table - Acoustic Parking System (01547 And 01548). Scheme 393

Diagnostic Trouble Code Table - Acoustic Parking System (01546 And 01549). Scheme 394

Diagnostic Trouble Code Table - Acoustic Parking System (01550 And 65535). Scheme 395

Note. If DTC memory cannot be erased, check DTC memory again and repair malfunction.

1. DTC memory checked. See «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. All malfunctions repaired.

After successful DTC memory check

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (1 Of 6). Scheme 396

1. Press buttons -0- and -5-. This selects "Erase DTC memory," function 05.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (2 Of 6). Scheme 397

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (3 Of 6). Scheme 398

DTC memory is erased.

1. Press --> -button.

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (4 Of 6). Scheme 399

Note. Test sequence is faulty if this message is displayed. see scheme 425: VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (5 Of 6) Test sequence is faulty if this message is displayed. see scheme 426: VAG 1551 Scan Tool Display - Erase DTC Memory, Acoustic Parking System (6 Of 6)

Follow test sequence exactly: first check DTC memory, repair malfunction(s) if necessary, then erase.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Acoustic Parking System (1 Of 3). Scheme 400

1. Press buttons -0- and -6-. This selects "End Output," function 06.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Acoustic Parking System (2 Of 3). Scheme 401

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - End Output, Acoustic Parking System (3 Of 3). Scheme 402

1. Switch off ignition.
2. Disconnect harness connectors for the VAG1551 scan tool

Using this function, the control module for parking aid can be coded as follows

1. Transmission type: Manual shifting or automatic
2. Signal for reverse gear engaged With or without acoustic signal that APS is active
3. Chassis type: Sedan or Avant
4. Vehicle type: e.g. Audi A6

Note. Via coding, the universally undifferentiated control module for parking aid -J446- can be specifically adjusted to the demands of the vehicle at hand.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Acoustic Parking System (1 Of 6). Scheme 403

1. Press buttons -0- and -7- to select "Code Control Module" function 07.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Acoustic Parking System (2 Of 6). Scheme 404

1. Press -Q- button to confirm input.

Indicated on display

1. Input code number using coding table. See «MEASURING VALUE BLOCK, READING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Example: 01106

INPUT CODE NUMBER - ACOUSTIC PARKING SYSTEM

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Acoustic Parking System (4 Of 6). Scheme 405

1. Press -Q- button to confirm input.

VAG 1551 Scan Tool Display - Code Control Module, Acoustic Parking System (5 Of 6). Scheme 406

Indicated on display after approx. 5 seconds

1. End coding with the --> button.

Indicated on display

VAG 1551 Scan Tool Display - Code Control Module, Acoustic Parking System (6 Of 6). Scheme 407

Coding Table, Acoustic Parking System. Scheme 408

Indicated on display

VAG 1551 Scan Tool Display - Measuring Value Block, Acoustic Parking System (1 Of 3). Scheme 409

1. Press buttons -0- and -8- to select "Read Measuring Value Block" function 08.

Indicated on display

VAG 1551 Scan Tool Display - Measuring Value Block, Acoustic Parking System (2 Of 3). Scheme 410

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Measuring Value Block, Acoustic Parking System (3 Of 3). Scheme 411

1. Enter display group number (from table in «ADAPTATION»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) ) and press -Q- button to confirm input.

The selected measuring value block is now displayed in standard form.

Measuring Value Block Display Group Overview, Acoustic Parking System. Scheme 412

VAG 1551 Scan Tool Display - Measuring Value Block 001, Acoustic Parking System. Scheme 413

VAG 1551 Scan Tool Display - Measuring Value Block 2, Acoustic Parking System. Scheme 414

VAG 1551 Scan Tool Display - Measuring Value Block 3, Acoustic Parking System. Scheme 415

VAG 1551 Scan Tool Display - Measuring Value Block 4, Acoustic Parking System. Scheme 416

Note. If values that are greater than 4.00 ms are obtained with reverse gear selected, either the ultrasound sensor is faulty or there is an open circuit in the wiring.

Using the adaptation function, the following changes can be made and saved.

1. Volume of warning chime
2. Pitch (frequency) of warning chime

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (1 Of 10). Scheme 417

1. Press buttons -1- and -0- to select "Adaptation" function 10.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (2 Of 10). Scheme 418

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (3 Of 10). Scheme 419

1. Press buttons -0- and -1-.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (4 Of 10). Scheme 420

1. Either adjust adaptation value downward using button -1-, upward using button -3- or press --> button.
2. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (5 Of 10). Scheme 421

1. Now enter the adaptation value by hand (e.g. 00005).

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (6 Of 10). Scheme 422

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (7 Of 10). Scheme 423

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (8 Of 10). Scheme 424

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (9 Of 10). Scheme 425

1. Conclude adaptation of sensitivity by pressing the --> button.

Indicated on display

VAG 1551 Scan Tool Display - Adaptation, Acoustic Parking System (10 Of 10). Scheme 426

ADAPTATION CHANNEL FUNCTION - ACOUSTIC PARKING SYSTEM

The automatic vertical headlight aim control system keeps the low beams at a constant level even if the car is loaded, a situation which would normally change the headlight angle.

There are two vehicle level sensors, one on the front axle and one on the rear axle. These sensors register the vehicle's fore/aft angle of inclination.

The control module processes the vehicle speed signal, evaluates the level sensor signals and turns the headlight beam adjusting motors on when the low beams are on.

The automatic vertical headlight aim control system is required for vehicles with gas discharge (Xenon) headlights.

The automatic vertical headlight aim control system consists of

1. Automatic vertical headlight aim control system control module -J431
2. Left rear level control system sensor -G76
3. Left front level control system sensor -G78
4. Right headlight beam adjusting motor -V48
5. Left headlight beam adjusting motor -V49

When starting the engine, vehicle level is measured and compared to the set point. This signal is sent to the headlight beam adjusting motors which adjust headlight position to this value once, whether or not the low beams are on.

After this single correction, signals to change low beam position will only be sent to the headlight beam adjusting motors with the low beams on.

If a trip is interrupted (vehicle speed less than 1 km/h) and a vehicle position change is recognized due to additional weight (for example, extra people in the car) the headlights will be automatically adjusted to the proper height.

All changes made by the automatic vertical headlight aim control system are due to static operating conditions.

1. Fuse OK (using applicable wiring diagram)
2. VAG1551 Scan Tool (ST) connected

Note. If nothing appears on the display, check the voltage supply to the VAG1551 scan tool according to wiring diagram. Press the HELP button for additional operating instructions. Press the --> button to advance through the program sequence. Press the -C- button to clear an incorrect entry. In "Rapid data transfer" operating mode 1 the "Automatic Test Sequence" (address word 00) can be carried out. This will automatically check the DTC memories of all vehicle control modules which have OBD capabilities.

1. Switch ignition on.
2. Switch printer on by pressing PRINT button (indicator light in button comes on).
3. Press button -1 - to select "Rapid data transfer" operating mode 1.

Indicated on display

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (1 Of 8). Scheme 427

1. Press buttons -5- and -5- to insert "Head lamp vertical aim control system" address word 55.

Indicated on display

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (2 Of 8). Scheme 428

1. Press -Q- button to confirm input.

Indicated on display (after about 5 seconds)

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (3 Of 8). Scheme 429

1. Automatic vertical headlight aim control system control module identification: 4B0907357 (check parts catalog).
2. Software version: DOO
3. Control module coding: 00005
4. WSC 06812: dealer number

1. Press --> button.

1. If one of these four messages displayed in (Scheme 430) - (Scheme 433), carry out troubleshooting procedures.

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (4 Of 8). Scheme 430

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (5 Of 8). Scheme 431

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (6 Of 8). Scheme 432

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (7 Of 8). Scheme 433

Indicated on display

VAG 1551 Scan Tool Display - On Board Diagnostic, Automatic Headlight Aim Control (1998-99) (8 Of 8). Scheme 434

1. Press HELP button to print list of possible functions.
2. Press --> button to continue.

The following functions are possible

1. 02 - Check DTC Memory. See «CHECK DTC MEMORY (SCAN TOOL FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. 03 - Output Diagnostic Test Mode. See «OUTPUT DIAGNOSTIC TEST MODE (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
3. 04 - Basic Setting. See «BASIC SETTING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__basic-setting) .
4. 05 - Erase DTC Memory. See «ERASE DTC MEMORY (SCAN TOOL FUNCTION 05)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
5. 06 - End Output. See «END OUTPUT (SCAN TOOL FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
6. 07 - Code Control Module. See «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
7. 08 - Read Measuring Value Block. See «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

Automatic vertical headlight aim control system

Note. The DTCs indicated are only updated when initiating On Board Diagnostic (OBD) or with "Erasing DTC Memory" function 05.

1. Switch printer on by pressing PRINT button (indicator light in button comes on).

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Automatic Headlight Aim Control (1998-99) (1 Of 5). Scheme 435

1. Press buttons -0- and -2- to select "Check DTC Memory" function 05.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Automatic Headlight Aim Control (1998-99) (2 Of 5). Scheme 436

1. Press -Q- button to confirm input.

The number of stored Diagnostic Trouble Codes (DTCs) is shown on the display.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Automatic Headlight Aim Control (1998-99) (3 Of 5). Scheme 437

Stored DTCs are displayed in sequence and printed out one after another.

1. Repair malfunctions printed out according to DTC Table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .

If "No DTC recognized" is shown on display

VAG 1551 Scan Tool Display - Check DTC Memory, Automatic Headlight Aim Control (1998-99) (4 Of 5). Scheme 438

1. Press --> button to return VAG1551 scan tool to "Select function XX" mode.

Indicated on display

VAG 1551 Scan Tool Display - Check DTC Memory, Automatic Headlight Aim Control (1998-99) (5 Of 5). Scheme 439

If anything else is indicated on display, see scan tool operating instructions.

1. Press buttons -0- and -6- to select "End Output" function 06. See «END OUTPUT (SCAN TOOL FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. Switch ignition off.
3. Disconnect VAG1551 scan tool from DLC.

1. All possible malfunctions recognized by the automatic vertical headlight aim control system and printed out by the VAG1551 Scan Tool (ST) are listed on the following pages according to the 5-digit DTC.
2. The 5-digit DTC numbers are only shown on the printout.
3. Before replacing a component suspected of malfunctioning, check all related wiring connections, harness connections and Ground (GND) connections according to the appropriate wiring diagram.
4. After completing necessary repairs, connect the VAG1551 scan tool, check DTC memory (scan tool function 02) and, if necessary, erase DTC memory (scan tool function 05).
5. DTC memory contains all static and sporadic faults. A malfunction is recognized as static if it exists for at least 2 seconds. If a static malfunction is no longer present after 2 seconds it will be classified as a sporadic malfunction and identified by the letters 7SP" in the lower right of the VAG1551 scan tool display.
6. When the ignition is switched on, all malfunctions present are identified as "sporadic" and are only stored as static malfunctions if they are detected in the next check routine.
7. A sporadic malfunction will be erased if it no longer exists after 50 driving cycles (ignition on for at least 5 minutes, road speed above 30 km/h or 18 mph).

Diagnostic Trouble Code Table (00625, 00774, 00776 And 01537) - Automatic Headlight Aim Control (1998-99). Scheme 440

Diagnostic Trouble Code Table (01538, 01539 And 65535) - Automatic Headlight Aim Control (1998-99). Scheme 441

1. For basic setting, see «BASIC SETTING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000__basic-setting) .

Note. The output Diagnostic Test Mode (DTM) can only be carried out on a stationary vehicle. If a malfunction is found during the output DTM, trace the cause and replace the malfunctioning part.

The following tests are carried out by the output DTM

1. Lowering headlights
2. Raising headlights

1. Low beams switched on

1. Press buttons -0- and -3- to select "Output Diagnostic Test Mode" function 03.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Automatic Headlight Aim Control (1998-99) (1 Of 5). Scheme 442

1. Press -Q- button to confirm input (output DTM for headlight vertical headlight aim control system is started).

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Automatic Headlight Aim Control (1998-99) (2 Of 5). Scheme 443

Headlights will be lowered until sequence is switched ahead or the lowest position is reached.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Automatic Headlight Aim Control (1998-99) (3 Of 5). Scheme 444

Headlights will be raised until sequence is switched ahead or the highest position is reached.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Automatic Headlight Aim Control (1998-99) (4 Of 5). Scheme 445

1. Press --> button.

The scan tool returns to the "Select function XX" mode.

Indicated on display

VAG 1551 Scan Tool Display - Output Diagnostic Test Mode, Automatic Headlight Aim Control (1998-99) (5 Of 5). Scheme 446

After replacing a headlight, axle sensor or the control module basic settings must be initiated.

Test Requirement

1. Vehicle must be loaded to an exactly definable weight.

1. Settle car (push down on car a few times so that shock absorbers and car bounce up and down).

Initiating Basic Setting

1. Press buttons -0- and -4- to select "Basic Setting" function 04.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (1 Of 9). Scheme 447

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (2 Of 9). Scheme 448

1. Press buttons -0-, -0-, and -1- to input Display group number 001.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (3 Of 9). Scheme 449

Headlights are moved into adjustment position.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (4 Of 9). Scheme 450

Headlights are now in adjustment position.

1. Adjust headlights.

Basic setting 1 turns regulation off and "Headlights not adjusted" will be stored in DTC memory.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (5 Of 9). Scheme 451

1. Press buttons -0- and -4- to select "Basic Setting" function 04.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (6 Of 9). Scheme 452

1. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (7 Of 9). Scheme 453

1. Press buttons -0-, -0-, and -2- to input Display group number 002.
2. Press -Q- button to confirm input.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (8 Of 9). Scheme 454

The control module has stored this position as the normal position. "Headlights not adjusted" is erased from DTC memory and regulation is switched back on.

1. Press --> button.

Indicated on display

VAG 1551 Scan Tool Display - Basic Setting, Automatic Headlight Aim Control (1998-99) (9 Of 9). Scheme 455

Note. If DTC memory cannot be erased, check DTC memory again and repair any malfunctions.

1. DTC memory checked. See «CHECK DTC MEMORY (SCAN TOOL FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#on-board-diagnostic-obd-up-to-2000) .
2. All malfunctions repaired

After checking DTC memory

Indicated on display

VAG 1551 Scan Tool Display - Erase DTC Memory, Automatic Headlight Aim Control (1998-99) (1 Of 5). Scheme 456

1. Press buttons -0- and -5- to select "Erase DTC Memory" function 05.
