Radio, Telephone, Navigation, Trip Computer

CAUTION

Before beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch off all electrical consumers. Switch ignition off and remove ignition key. Disconnect negative (-) battery terminal. On vehicles equipped with Audi Telematics by OnStar(R), switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY (BACK-UP) BATTERY, SWITCH ON/OFF, RESET TIME REGISTER . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar(R), switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See EMERGENCY (BACK-UP) BATTERY, SWITCH ON/OFF, RESET TIME REGISTER .

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable standard or optional radio system. Always read the radio owner's manual and review all radio, tape player and CD player/changer functions.

See radio installation instructions.

Note. For detailed instructions (for example, removing and installing trim panels): See TRIM PANELS (SEDAN) and TRIM PANELS (AVANT) . Wherever possible, only genuine Audi parts should be used. Only then can trouble-free installation and optimal reception be guaranteed. All radio systems have anti-theft coding.

To minimize contact corrosion, only use approved fasteners (screws, nuts, bolts, washers etc.).

Where applicable, fasteners may have a special surface coating recognizable by a greenish color.

Coated fasteners must also be stored separately.

Radio systems have extensive On Board Diagnostic (OBD) capabilities.

The radio unit has a Diagnostic Trouble Code (DTC) memory. If a malfunction occurs in one of the components or wires which is monitored by the system, a record of the type of malfunction is stored in DTC memory. See RADIO ON BOARD DIAGNOSTIC (OBD), INITIATING .

The connectors on the factory-installed radio wiring harness are designed for genuine Audi radios.
Radios with different types of connectors must be installed using adapter wires.
When connecting the vehicle speed sensor signal wire (on radios with the GALA function), take particular care to avoid short circuits, which could result in vehicle malfunctions (e.g. in the engine management system).
Vehicle malfunctions may also occur if the vehicle speed sensor signal wire is connected to radios supplied by other manufacturers.
When other radio units are installed it can have an effect on the antenna amplifier, since the original Audi radio units have a remotely driven antenna (the voltage supply of the antenna amplifier is driven via a center wire of the HF cable). Use a remotely driven adaptor. See parts catalog (vendor: Votex).

The wiring set for the CD changer unit is in the vehicle during production. The connecting cable can only be used with original Audi CD changers.

The radio system is disabled (switched-off) when Transport Mode is activated. This is necessary when vehicles are transported over long distances or stored for longer periods of time.

Audi A6 vehicles are initially delivered to dealerships with the radio system in Transport Mode, and must be deactivated before delivery to the customer using OBD program function 10 - Adaptation. See ADAPTATION (FUNCTION 10) .

Note. The following list refers to (Scheme 415).

Radio -R- In center console Removing and installing. See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system") In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier Behind left D-pillar trim Removing and installing. See «ANTENNA AMPLIFIERS - "CONCERT" RADIO (SEDAN) THROUGH M.Y. 2001, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-concert-radio-sedan) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) . Check wiring. See «Checking wiring connection between radio and CD changer»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__checking-wiring-connection-between-radio-and) .
Rear Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to (Scheme 416).

Radio -R- In center console Removing and installing. See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system)" In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna When equipped with radio, telephone and navigation, a combination antenna is used. Removing and installing. See «ROOF ANTENNA (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-avant-removing-and-installing) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) . Check wiring. See «Checking wiring connection between radio and CD changer»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__checking-wiring-connection-between-radio-and) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Rear Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to see scheme 3.

Radio -R- In center console Removing and installing "Concert". See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) . Removing and installing "Symphony". See «"SYMPHONY" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__symphony-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system") In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier -R82- Behind right D-pillar trim (top) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Antenna amplifier -R83- Behind right D-pillar trim (bottom) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Antenna amplifier -R84- Behind left D-pillar trim (top) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Antenna Selection Control Module -J515- Below parcel shelf (left) Removing and installing. See «ANTENNA SELECTION CONTROL MODULE -J515- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-selection-control-module-j515-sedan) .
Antenna amplifier -R84- Behind left D-pillar trim (bottom) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) . Check wiring. See «Checking wiring connection between radio and CD changer»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__checking-wiring-connection-between-radio-and) .
Front Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34- & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to (Scheme 417).

Radio -R- In center console Removing and installing. See «"SYMPHONY" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__symphony-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system") In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier -R82- Behind right D-pillar trim (top) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Satellite Tuner Antenna -R182- On roof Also for Telematics and Navigation Removing and installing. See «SATELLITE TUNER ANTENNA -R172- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier -R83- Behind right D-pillar trim (bottom) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Antenna amplifier -R85- Behind left D-pillar trim (top) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
Antenna amplifier -R84- Behind left D-pillar trim (bottom) Removing and installing. See «ANTENNA AMPLIFIERS -"SYMPHONY" & "CONCERT" RADIOS (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert-radios) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) . Check wiring. See «Checking wiring connection between radio and CD changer»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__checking-wiring-connection-between-radio-and) .
Satellite Radio -R146- In left rear luggage compartment storage under CD changer Removing and installing. See «SATELLITE RADIO -R146- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__satellite-radio-r146-sedan-removing-and) .
Antenna Selection Control Module -J515- Below parcel shelf (left) Removing and installing. See «ANTENNA SELECTION CONTROL MODULE -J515- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-selection-control-module-j515-sedan) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to (Scheme 418).

Radio -R- In center console Removing and installing "Concert". See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) . Removing and installing "Symphony". See «"SYMPHONY" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__symphony-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system") In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier -R82- Behind right rear luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
Antenna Selection Control Module -J515- Next to roof antenna Removing and installing. See «ANTENNA SELECTION CONTROL MODULE -J515- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-selection-control-module-j515-avant) .
Antenna -R11- FM1, AM antennas With radio and telephone system, a combination antenna is used. Removing and installing. See «ROOF ANTENNA (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-avant-removing-and-installing) .
Antenna amplifier -R84- Behind left rear luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) .
Antenna amplifier -R83- Behind left front luggage compartment side trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Rear Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to (Scheme 419).

Radio -R- In center console Removing and installing. See «"SYMPHONY" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__symphony-radio-removing-and-installing) .
Bass Loudspeaker -R100- In right rear luggage compartment behind side trim Removing and installing. See «BASS LOUDSPEAKER -R100- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Amplifier -R12- (only with "BOSE(R) sound system") In right rear luggage compartment behind side trim Removing and installing. See «BOSE(R) AMPLIFIER & LOUDSPEAKER (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna amplifier -R82- Behind right front luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
Antenna amplifier -R83- Behind right rear luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
Antenna Selection Control Module -J515- Next to roof antenna Removing and installing. See «ANTENNA SELECTION CONTROL MODULE -J515- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-selection-control-module-j515-avant) .
Satellite Tuner Antenna -R182- On roof Also for Telematics and Navigation Removing and installing. See «SATELLITE TUNER ANTENNA -R172- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__satellite-tuner-antenna-r172-avant-removing) .
Antenna amplifier -R84- Behind left rear luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
CD Changer Unit -R41- In left rear luggage compartment storage box Removing and installing. See «CD CHANGER UNIT -R41-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__cd-changer-unit-r41-removing-and) .
Satellite Radio -R146- In left rear luggage compartment storage under CD changer Removing and installing. See «SATELLITE RADIO -R146- (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__satellite-radio-r146-avant-removing-and) .
Antenna amplifier -R85- Behind left front luggage compartment trim Removing and installing. See «ANTENNA AMPLIFIERS - "SYMPHONY" & "CONCERT" RADIOS (AVANT) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-amplifiers-symphony-concert) .
Rear Bass Speakers -R15- & -R17- In lower rear door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Rear Midrange Speakers -R34- & -R35- In upper rear door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Bass Speakers -R21- & -R23- In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Note. The following list refers to items in (Scheme 420).

Sedan - rear window antenna with antenna amplifier, Avant - roof antenna with amplifier through m.y. 2001

Sedan - rear window antenna with Diversity-box, Avant - roof antenna with Diversity-box from m.y. 2002
Front treble/mid-range loudspeaker in upper part of front door trim
Front bass loudspeaker in lower part of front door trim
Rear treble/mid-range loudspeaker in upper part of rear door trim
Rear bass loudspeaker in lower part of rear door trim
Bass loudspeaker (subwoofer) in rear of luggage compartment on right-hand side, under side trim
CD changer (optional) in left rear luggage compartment storage box

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to items in (Scheme 421).

1 - Line output - left rear
2 - Line output - right-rear
3 - Line output - Ground (GND)
6 - Switched positive supply for active loudspeakers
7 - CAN-Bus High (Infotainment) from m.y. 2002
8 - Clock signal for radio frequency display in instr. cluster through m.y. 2001
9 - Data signal for radio frequency display in instr. cluster through m.y. 2001
10 - Enable signal for radio frequency display in instr. cluster through m.y. 2001
11 - Steering wheel remote control through m.y. 2001
12 - CAN-Bus Low (Infotainment) from m.y. 2002
13 - Data-in signal for CD display in instrument cluster
14 - Data-out signal for CD display in instrument cluster
15 - Clock signal for CD display in instrument cluster
16 - Battery positive B+ (CD changer)
17 - Switched positive for CD changer
18 - Ground (GND) for CD changer
19 - Line output - left channel (CD changer)
20 - Line output - right (CD changer)

3 - Loudspeaker + right-front
4 - Loudspeaker - right-front
5 - Loudspeaker + left-front
6 - Loudspeaker - left-front

1 - GALA (vehicle speed signal) through m.y. 2001
2 - Telephone muting through m.y. 2001
2 - Anti-theft Ground from m.y. 2002
3 - K, for On Board Diagnostic (OBD) through m.y. 2001
3 - L, for On Board Diagnostic (OBD) from m.y. 2002
4 - Connection for switching on and off via ignition key (S-contact) - terminal 86s through m.y. 2001
5 - Control positive for automatic antenna (only for mirrored glass) through m.y. 2001
6 - Switch illumination (terminal 58s) through m.y. 2001
7 - Battery + (terminal 30)
8 - Ground (GND, terminal 31)

1 - Telephone muting
2 - Terminal 15 (only for navigation) through m.y. 2001
3 - Telephone (NF+) (not when equipped with navigation)
4 - Telephone (NF-) (not when equipped with navigation)
5 - Navigation system (NF +)
6 - Navigation system (NF -)
7 - Navigation system control wire
9 - Display illumination (terminal 58d) through m.y. 2001
10 - CD Ground through m.y. 2001

1 - Sedan - rear window antenna with antenna amplifier, Avant - roof antenna with amplifier through m.y. 2001
1 - Sedan - rear window antenna with Diversity-box, Avant - roof antenna with Diversity-box from m.y. 2002
2 - Hands-free Telephone/Navigation loudspeaker through m.y. 2001
3 - Front treble/mid-range loudspeaker in upper part of front door trim
4 - Front bass loudspeaker in lower part of front door trim
5 - Rear treble/mid-range loudspeaker in upper part of rear door trim
6 - Rear bass loudspeaker in lower part of rear door trim
7 - Bass loudspeaker with BOSE(R) power amplifier in rear of luggage compartment on right-hand side, under side trim
8 - CD changer (optional) in left rear luggage compartment storage box

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to items in (Scheme 426).

Line-output - left-rear
Line-output - right-rear
Line-output - Ground (GND)
Line-output - left-front
Line-output - right-front
Switched positive supply for BOSE(R) amplifier
CAN-Bus High (Infotainment) from m.y. 2002
Clock signal for radio frequency display in instr. cluster through m.y. 2001
Data signal for radio frequency display in instr. cluster through m.y. 2001
Enable signal for radio frequency display in instr. cluster through m.y. 2001
Steering wheel remote control through m.y. 2001
CAN-Bus Low (Infotainment) from m.y. 2002
Data-in signal for CD display in instrument cluster
Data-out signal for CD display in instrument cluster
Clock signal for CD display in instrument cluster
Permanent B+ connection for CD changer
Switched positive supply for CD changer
Ground (GND) connection for CD changer
Line output - left (CD changer)
Line output - right (CD changer)

Scheme 415

3 - Loudspeaker + right-front through m.y. 2001
4 - Loudspeaker - right-front through m.y. 2001
5 - Loudspeaker + left-front through m.y. 2001
6 - Loudspeaker - left-front through m.y. 2001

1 - GALA (vehicle speed signal) through m.y. 2001
1 - BOSE(R) coding from m.y. 2002
2 - Telephone muting
3 - K, for On Board Diagnostic (OBD) through m.y. 2001
3 - L, for On Board Diagnostic (OBD) from m.y. 2002
4 - Connection for switching on and off via ignition key (S-contact) - terminal 86s through m.y. 2001
5 - Control positive for automatic antenna (only for mirrored glass) through m.y. 2001
6 - Switch illumination (terminal 58s) through m.y. 2001
7 - Battery B+ (terminal 30)
8 - Ground (GND) (terminal 31)

Scheme 416

1 - Telephone muting
2 - Terminal 15 (only for navigation) through m.y. 2001
3 - Telephone (NF+) (not when equipped with navigation)
4 - Telephone (NF-) (not when equipped with navigation)
5 - Navigation system (NF +)
6 - Navigation system (NF -)
7 - Navigation system control wire
9 - Display illumination (terminal 58d) through m.y. 2001
10 - CD Ground (GND) through m.y. 2001

Note. The following list refers to see scheme 17.

Rear window antennas
Antenna amplifier (AM/FM4) Behind left D-pillar trim (top)
Antenna amplifier (FM3) Behind left D-pillar trim (bottom)
Antenna amplifier (FM1) Behind right D-pillar trim (top)
Antenna amplifier (FM2) Behind right D-pillar trim (bottom)
Antenna Selection Control Module Below parcel shelf (left)
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass Loudspeaker with amplifier In right rear luggage compartment behind side trim
CD Changer Unit Optional In left rear luggage compartment storage box
Radio -R- "Symphony"

Note. The following list refers to see scheme 18.

Rear window antennas (FM2/FM3) left
Antenna amplifier Behind left rear side trim
Antenna amplifier Behind left rear side trim
Roof antenna with amplifier (AM/FM4)
Side window antenna (FM1) left
Antenna amplifier Behind right rear side trim
Antenna Selection Control Module Next to roof antenna
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass speaker with amplifier In right rear luggage compartment behind side trim.
CD Changer Unit Optional In left rear luggage compartment storage box
Radio -R- "Symphony"

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to items in see scheme 19.

1 - Line output - left rear
2 - Line output - right rear
3 - Line output - Ground (GND)
6 - Switched positive supply for active speaker
7 - CAN-Bus High (Infotainment) from m.y. 2002
8 - Clock-signal through m.y. 2001
9 - Data-signal through m.y. 2001
10 - Enable-signal through m.y. 2001
10 - CD Ground (GND) from m.y. 2002
11 - Remote control steering wheel through m.y. 2001
12 - CAN-Bus Low (Infotainment) from m.y. 2002
13 - CD-Bus data in (CD changer)
14 - CD-Bus data out (CD changer)
15 - CD-clock (CD changer)
16 - Battery positive B+ (CD changer)
17 - CD-switched B+ (CD changer)
18 - CD Ground (GND) (CD changer)
19 - Line output - left (CD changer)
20 - Line output - right (CD changer)

3 - Loudspeaker + right front
4 - Loudspeaker - right front
5 - Loudspeaker + left front
6 - Loudspeaker - left front

1 - Gala (RPM signal) through m.y. 2001
2 - NF-Telephone muting through m.y. 2001
2 - Anti-theft alarm system Ground from m.y. 2002
3 - K, for On Board Diagnostic (OBD) through m.y. 2001
3 - L, for On Board Diagnostic (OBD) from m.y. 2002
4 - Terminal 86s - connection for switching on and off via ignition switch (S-contact) through m.y. 2001
5 - Switched positive for antenna amplifier through m.y. 2001
6 - Illumination (terminal 58d) through m.y. 2001
7 - Battery B+ (terminal 30)
8 - Ground (GND) (terminal 31)

Scheme 417

1 - Telephone muting
2 - Terminal 15 (only for navigation equipment) through m.y. 2001
3 - Telephone (NF+) (not for navigation equipment)
4 - Telephone (NF-) (not for navigation equipment)
5 - Navigation (NF+)
6 - Navigation (NF-)
7 - Navigation control wire
9 - Illumination display (terminal 58d) through m.y. 2001
10 - CD-Ground (GND) through m.y. 2001

Note. The following list refers to see scheme 23.

Rear window antennas
Antenna amplifier (AM/FM4) Behind left D-pillar trim (top)
Antenna amplifier (FM3) Behind left D-pillar trim (bottom)
Antenna amplifier (FM1) Behind right D-pillar trim (top)
Antenna amplifier (FM2) Behind right D-pillar trim (bottom)
Antenna Selection Control Module Below parcel shelf (left)
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Hands-free speaker In left B-pillar trim (only for telephone or navigation) through m.y. 2001
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass Loudspeaker with BOSE(R)amplifier In right rear luggage compartment behind side trim
CD Changer Unit Optional In left rear luggage compartment storage box
Radio -R- "Symphony"

Note. The following list refers to see scheme 24.

Left rear window antennas (FM2/FM3)
Antenna amplifier Behind left rear side trim
Antenna amplifier Behind left rear side trim
Antenna Selection Control Module Next to roof antenna
Roof antenna (AM/FM4) with amplifier
Right rear window antenna (FM1)
Antenna amplifier Behind right rear side trim
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Hands-free speaker in left B-pillar trim (only for telephone or navigation) through m.y. 2001
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass Loudspeaker with BOSE(R) amplifier In right rear luggage compartment behind side trim.
CD Changer Unit Optional In left rear luggage compartment storage box
Radio -R- "Symphony"

Note. The following list refers to see scheme 25.

Rear window antennas
Antenna amplifier (AM/FM4) Behind left D-pillar trim (top)
Antenna amplifier (FM3) Behind left D-pillar trim (bottom)
Antenna amplifier (FM1) Behind right D-pillar trim (top)
Antenna amplifier (FM2) Behind right D-pillar trim (bottom)
Antenna Selection Control Module Below parcel shelf (left)
Radio -R
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass Loudspeaker with BOSE(R) amplifier In right rear luggage compartment behind side trim.
CD Changer Unit In left rear luggage compartment storage box
Satellite Radio
Satellite Tuner Antenna

Note. The following list refers to see scheme 26.

Left rear window antennas (FM3/AM/FM4)
Antenna amplifier Behind left rear side trim
Antenna amplifier Behind left rear side trim
Antenna Selection Control Module Near roof antenna
Right rear window antennas (FM1/FM2)
Antenna amplifier Behind right rear side trim
Antenna amplifier Behind right rear side trim
Front Midrange Speakers In upper front door trim
Front Bass Speakers In lower front door trim
Rear Midrange Speakers In upper rear door trim
Rear Bass Speakers In lower rear door trim
Bass Loudspeaker with BOSE(R) amplifier In right rear luggage compartment behind side trim.
Radio -R
CD Changer Unit In left rear luggage compartment storage box
Satellite Radio
Satellite Tuner Antenna

Note. The following list refers to see scheme 27.

Satellite Radio
Satellite Tuner Antenna
Antenna splitter (GPS)
Control Module for Navigation with CD mechanism
Antenna (rear window or rear side window)
Antenna amplifier
Antenna Selection Control Module
Loudspeaker
Radio
CAN-BUS (Infotainment)
CD Changer Unit
Telephone/Telematic Control Module

Note. The following list refers to see scheme 28.

Antenna connection socket for radio (HF-wire)
ZF-wire
Radio switch block
Black 20-pin multi-pin connection I
Brown 8-pin multi-pin connection II
Black 8-pin multi-pin connection III
Red 10-pin multi-pin connection IV
Anti-theft alarm system Ground (GND) through m.y. 2001
Radio fuse in radio

Note. The following list refers to see scheme 29.

6 - Line output - Ground (GND) (from radio)
7 - Line output - right rear (from radio)
8 - Line output - left rear (from radio)
9 - Line output - right front (from radio)
10 - Line output - left front (from radio)
13 - Battery B+ (terminal 30)
16 - Loudspeaker (-) left front
17 - Loudspeaker (+) left front
18 - Loudspeaker (+) right front
19 - Loudspeaker (-) right front
20 - Loudspeaker (+) left rear
21 - Loudspeaker (-) left rear
22 - Loudspeaker (+) right rear
23 - Loudspeaker (-) right rear
25 - Switched positive

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to see scheme 30.

Multi-pin connection, 8-pin CAN-Bus High (Infotainment) CAN-Bus Low (Infotainment) CD-IN L (CD Changer Unit) CD-IN R (CD Changer Unit) NF - Ground (GND) (Radio) NF - left (Radio) NF - right (Radio) CD Ground (GND) (CD Changer Unit)
Multi-pin connection, 8-pin Terminal 30 (B+) Terminal 31 (GND)
Connection - Satellite Tuner Antenna (brown)
Connection - Satellite Tuner Antenna (green)

Note. The following list refers to see scheme 31.

FM Antenna 1
FM Antenna 2
Auxiliary heater antenna (where applicable)
FM Antenna 3
FM Antenna 4
AM-Antenna

FM antennas 1 through 3 on Avant models are located in both rear side windows, whereby -1- is depicted as the forward antenna and -2- the rearward antenna.

Antenna FM1: right rear window - forward -1
Antenna FM2: left rear window - forward -1
Antenna FM3: left rear window - rearward -2

The roof antenna serves as the AM/FM4 antenna.

On vehicles equipped with Satellite (SDARS) radio preparation, antenna FM4/AM is deleted from roof antenna. SDARS radio/antenna applications as follows

Antenna FM1: right rear window - forward -1
Antenna FM2: right rear window - rearward -2
Antenna FM3: left rear window - rearward -2
AM/FM4 Antenna: left rear window - forward -1

Note. Obtain anti-theft code number for radio before removing.

3344 radio removal tools

Scheme 418: Required special tools, testers and auxiliary equipment

Insert 3344 removal tools into front of radio as shown. Top L = left upper and lower Top R = right upper and lower
Remove radio from instrument panel.
Disconnect electrical connections and antenna wire.

Remove 3344 radio removal tools before installing radio.
Connect electrical connections.
Carefully slide radio into instrument panel and engage in mounting frame.
Activate anti-theft coding. See radio operating instructions.

Note. Determine code number for anti-theft radio before removing.

T10057 radio removal tools

Perform the following work sequence

Insert T10057 radio removal tools into release slots (arrows) as shown until they engage. Top L - left upper and lower Top R - right upper and lower
Pull radio out of instrument panel using grip rings on release tool.
Unlock and disconnect electrical harness connections Remove T10057 radio removal tools before installing radio
Press locking latch arrow- and remove radio release tools toward front.

Connect electrical connections to radio.
Slide radio evenly into instrument panel, until it engages in assembly frame.

The Satellite Radio is located behind the left luggage compartment storage box.

Open left rear luggage compartment storage box.
Remove complete mounting frame including CD changer.
Disconnect electrical connections to CD changer and remove complete frame with units.
Remove nut -arrow- (3 Nm) and remove bracket from mountings -1-.
Disconnect electrical connections to Satellite Radio.
Remove screws -3- (2.5 Nm).
Separate Satellite Radio -1- from bracket -2-.

Install in reverse order of removal.

The Satellite Radio is mounted to the rear of the mounting frame in the left rear luggage compartment storage box.

Open left rear luggage compartment storage box.
Remove complete mounting frame.
Disconnect electrical connections at Satellite Radio.
Remove screws -3- (2.5 Nm).
Separate Satellite Radio -2- from mounting frame -1-.

Install in reverse order of removal.

Remove front/rear door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) and «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
Carefully detach insulation material around bass loudspeaker on back of door trim.
Disconnect electrical connection -2- from loudspeaker.
Remove screws -1- (2 Nm) on loudspeaker and take loudspeaker out of trim.

Install in reverse order of removal.

Remove front/rear door trim. See «FRONT DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__front-door-trim-removing-and-installing) and «REAR DOOR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-removing-and-installing) .
Carefully detach insulation material around treble loudspeaker on back of door trim.
Disengage clip -1- using screwdriver.
Disconnect electrical connection from loudspeaker.
Take loudspeaker -2- out of trim.

Install in reverse order of removal.

Remove right luggage compartment side trim See «LUGGAGE COMPARTMENT SIDE TRIM (FIXED REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-fixed-rear) or «LUGGAGE COMPARTMENT SIDE TRIM (SPLIT REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-split-rear) .
Disconnect electrical connection -1-.
Remove screws -arrows- (5 Nm).
Remove screw -1- (2 Nm) on rear of housing.
Remove screws for cover -2- (2 Nm).
Remove cover.
Disconnect electrical connections -1- and -2-.
Remove screws -arrows- (2.5 Nm).

Install in reverse order of removal.

Remove right luggage compartment side trim See «LUGGAGE COMPARTMENT SIDE TRIM (FIXED REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-fixed-rear) or «LUGGAGE COMPARTMENT SIDE TRIM (SPLIT REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-split-rear) .
Disconnect electrical connections.
Remove screws -1- (5 Nm).

Install in reverse order of removal.

Remove right luggage compartment side trim See «LUGGAGE COMPARTMENT SIDE TRIM (FIXED REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-fixed-rear) or «LUGGAGE COMPARTMENT SIDE TRIM (SPLIT REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-split-rear) .
Disconnect electrical connection -1-.
Disconnect electrical connection -2- on amplifier -3-.
Remove screws (5 Nm) -arrows
Remove amplifier.
Remove Torx(R) bolts (2 Nm) -arrows- on BOSE(R) loudspeaker.
Disconnect electrical connections -1-.
Remove loudspeaker.

Install in reverse order of removal.

Remove right luggage compartment side trim See «LUGGAGE COMPARTMENT SIDE TRIM (FIXED REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-fixed-rear) or «LUGGAGE COMPARTMENT SIDE TRIM (SPLIT REAR SEAT)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-split-rear) .
Disconnect electrical connection.
Remove nuts -1- (5 Nm)
Remove amplifier from bracket.
Remove screws -2- (5 Nm) from loudspeaker.
Disconnect electrical connections.
Remove loudspeaker.

Install in reverse order of removal.

The optional CD changer is located in the left rear luggage compartment storage box.

Open left rear luggage compartment storage box.
Remove screws -A- (3.5 Nm) from retainer -1-.
Disconnect electrical connections from modules and CD changer.
Remove retainer -1-.
Remove screws -2- (2 Nm) and lift CD changer -1- out from retainer.

CAUTION

Do not use fasteners other than the original factory type when installing control modules. Control module damage will result.

Install in reverse order of removal.
Check wiring connections between radio and CD changer after installation. See «Checking wiring connection between radio and CD changer»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__checking-wiring-connection-between-radio-and) .

Switch radio off.
Press and hold MODE button on "Concert" radio, or button No. 4 on "Symphony radio, and at same time switch radio on.
Release MODE/No. 4 button.

Wiring connection OK Indicated on radio display: "CONNECT" and "CD"
Wiring connection not OK

Indicated on radio display: "NO CDC"

Check electrical connections on CD changer.
Repeat wiring check and, if connection has still not been established, check wiring per wiring diagram. See appropriate System Wiring Diagram article.

The antenna amplifier is located behind the left D-pillar trim.

Remove left D-pillar trim See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing).
Disconnect electrical connections -1-, -2-, and -4-. see scheme 52
Remove screws -5- (1.5 Nm) and remove antenna amplifier -3-.

Install in reverse order of removal.

Two antenna amplifiers are located behind both the right and left D-pillar trim.

The following illustrates amplifiers located on the right side. Removing and installing left side antenna amplifiers is identical.

Remove D-pillar trim. See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) .
Remove antenna cable -1- and disconnect electrical connection -3-.
Remove securing bolt -4- (2.4 Nm) and remove antenna amplifier -2-.

Insert turning stop into mounting hole at antenna amplifier, then perform installation in reverse order.

There are two antenna amplifiers below the left luggage compartment side trim and one below the right luggage compartment side trim.

The following illustrates the left side.

Remove left side trim.

See TRIM PANELS (AVANT) .

Each antenna amplifier -1- is directly secured with one screw -4- (2.5 Nm). The other antenna amplifier -1- is secured on a bracket -2- with a screw -4- (2.5 Nm). The bracket is secured with two screws -3- (2.5 Nm).

Scheme 419

Insert turning stop into mounting hole at antenna amplifier, then perform installation in reverse order.

The antenna selection control module is located under the rear parcel shelf trim.

Remove parcel shelf. See «REAR SHELF (FOLDING BACKREST), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-shelf-folding-backrest-removing-and) and «REAR SHELF (FIXED BACKREST), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__rear-shelf-fixed-backrest-removing-and) .
Remove nuts -1- (2 Nm).
Disconnect electrical connection and remove control module.

Install in reverse order of removal.

The antenna selection control module is located under the headliner near the roof antenna.

Remove rear headliner trim See «MOLDED HEADLINER AND SUN VISORS (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__molded-headliner-and-sun-visors-avant) .
Lower headliner at rear See «MOLDED HEADLINER AND SUN VISORS (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__molded-headliner-and-sun-visors-avant) .
Disconnect electrical connections.
Remove screws (2.5 Nm) for bracket -arrows-.
Remove securing screws -1- (2 Nm) for control module for antenna selection and remove control module.

Install in reverse order of removal.

Remove left and right D-pillar trim See «UPPER C/D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-cd-pillar-trim-removing-and-installing) .
Remove both rear interior light modules See «INTERIOR LIGHT, REAR, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/door-locks-anti-theft-systems/#lightsswitches-interior-anti-theft-up-to-2000__interior-light-rear-removing-and-installing) .
Lower headliner at rear See «MOLDED HEADLINER AND SUN VISORS (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__molded-headliner-and-sun-visors-sedan) .
Disconnect antenna cable connections at left and right D pillars.
Loosen antenna cables to antenna.
Remove nut -arrow- (7 Nm).
Remove antenna upwards from roof.

Install in reverse order of removal.

Cables for roof antennas are routed differently. GPS antenna and Satellite tuner antenna cables are routed to modules located in the left rear luggage compartment. The Telematic antenna is connected at the right D-pillar.

Remove rear headliner trim See «ROOF FRAME TRIM»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__roof-frame-trim) .
Remove left and right D-pillar trim See «UPPER D-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-d-pillar-trim-removing-and-installing) .
Remove luggage compartment lights See «LUGGAGE COMPARTMENT LIGHTS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/door-locks-anti-theft-systems/#lightsswitches-interior-anti-theft-up-to-2000__luggage-compartment-lights-removing-and-installing) .
Remove left luggage compartment trim See «CARGO AREA FLOOR TRIM AND SUPPORTS (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__cargo-area-floor-trim-and-supports) .
Partially pull down rear headliner enough to access connections.
Disconnect antenna cable connections at right D-pillar.
Disconnect antenna cable connections at modules.
Loosen antenna cables up to antenna.
Remove nut -arrow- (7 Nm).
Remove antenna upwards from roof.

Install in reverse order of removal.

Note. The following list refers to see scheme 59.

Antenna rod
Antenna base With amplifier for radio operation. With GPS antenna for Navigation
Hex nut M14 with serrated washer Serrated washer is attached to hex nut with plastic ring Apply contact grease to inside of roof in area of serrated washer
Connection for navigation system The navigation connection must be threaded in, and is shorter than the telephone connection.
Connection for telephone system The telephone connection must be connected at wire to telephone system. This connection is shorter than the connection for the radio system.
Connection for radio system The radio connection is connected at wire to radio.

Carefully pry out rear interior light from headliner using screwdriver.
Unbolt antenna -1-.
Unbolt hex nut M14 (3.5 Nm) with serrated washer.
Disconnect electrical connections -4-, -5- and -6-.
Remove antenna foot -2- upward.

Install in reverse order of removal.

CAUTION

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable standard or optional telephone system. Always read the telephone system owner's manual and review all telephone system functions.

Note. The hands-free telephone is optional equipment.

Note. The following list refers to see scheme 61.

Telephone Handset -R37- In center armrest Removing and installing. See «DOCKING STATION/RETAINER (FOR CELLULAR TELEPHONE -R54-), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__docking-stationretainer-for-cellular-telephone-r54) .
Speaker (telephone/navigation) -R39- through m.y. 2001 On BOSE(R) system only In driver's B-pillar trim Removing and installing. See «SPEAKER (TELEPHONE/NAVIGATION) -R39- THROUGH M.Y. 2001 (ONLY WITH BOSE(R) SYSTEM), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Radio -R- In center console. Removing and installing. See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) .
Front Loudspeakers In front door panel trim Removing and installing. See «LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Telephone Transceiver -R36- Sedan: Under rear parcel shelf through m.y. 1998. Removing and installing. See «TELEPHONE TRANSCEIVER -R36- (SEDAN) THROUGH M.Y. 1998, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephone-transceiver-r36-sedan-through-my) . In left rear luggage compartment storage box from m.y. 1999 Removing and installing from m.y. 1999. See «TELEPHONE TRANSCEIVER -R36- (SEDAN AND AVANT) FROM M.Y. 1999, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephone-transceiver-r36-sedan-and-avant) . Avant: In left rear luggage compartment storage box Removing and installing. See «TELEPHONE TRANSCEIVER -R36- (SEDAN AND AVANT) FROM M.Y. 1999, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephone-transceiver-r36-sedan-and-avant) .
Antenna Sedan: Integral with rear window Avant: Roof antenna Removing and installing. See «ROOF ANTENNA (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-avant-removing-and-installing) .
Telephone microphone -R38- In driver's A-pillar through m.y. 1992 Removing and installing. See «TELEPHONE MICROPHONE -R38- THROUGH M.Y. 1999, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) . Integral with front interior light module from m.y. 2000. Removing and installing. See «TELEPHONE MICROPHONE -R38- FROM M.Y. 2000, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephone-microphone-r38-from-my-2000) .

Note. The digital cellular telephone is optional equipment, and is only used in conjunction with telematics system. ("Audi Telematics by OnStar(R). See TELEMATICS .)

Note. The following list refers to see scheme 62.

Docking station/retainer (for cellular telephone -R54-) Removing and installing. See «DOCKING STATION/RETAINER (FOR CELLULAR TELEPHONE -R54-), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__docking-stationretainer-for-cellular-telephone-r54) .
Spiral cord
Radio -R- In instrument panel, center Removing and installing. See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) .
Treble/mid-range or bass loudspeaker In front door panel trim Removing and installing. See «FRONT BASS SPEAKERS -R21- & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Antenna for telephone -R65- In rear bumper Removing and installing. See «ANTENNA FOR TELEPHONE -R65-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-for-telephone-r65-removing-and) .
Telephone/Telematic Control Module -J526- In front passenger's footwell Removing and installing. See «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephonetelematic-control-module-j526-removing-and) .
Telephone microphone -R38- Integral with front interior light module. Removing and installing. See «TELEPHONE MICROPHONE -R38- FROM M.Y. 2000, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephone-microphone-r38-from-my-2000) .

Open center armrest.
Remove cellular telephone -1- from docking station -2- and disconnect cable connection -3-.
Remove retainer with docking station -4- from center armrest and unclip harness connection

See CAR TELEPHONE / MOBILE PHONE LIFT MECHANISM IN CENTER ARMREST, REMOVING AND INSTALLING .

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections.

The Telephone Transceiver is located under the rear parcel shelf.

Open luggage compartment.
Remove screws -arrows- and let transceiver/bracket -1- drop down.
Disconnect electrical connection -2- and separate antenna connection (coupling).

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connection (coupling) must be tight in order to ensure proper reception.

The Telephone Transceiver is located in the left rear luggage compartment storage box on the rear of the CD-changer/control module retainer frame.

Open left rear luggage compartment storage box.
Remove complete retainer frame.
Disconnect electrical connections and remove complete retainer frame with control modules/CD-changer from vehicle.
Transceiver is secured to rear of retainer with spring clips.
Separate antenna connections (coupling) and unclip transceiver -1- from retainer frame.

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connection (coupling) must be tight in order to ensure proper reception.

The Telephone Transceiver is located in the left rear luggage compartment storage box.

Open left rear luggage compartment storage box.
Remove complete retainer frame.
Loosen nut on retainer -1- (2.5 Nm) and pull transceiver out from locating tabs in frame -2-.
Disconnect electrical connections and separate antenna connection (coupling).

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connection (coupling) must be tight in order to ensure proper reception.

Remove driver's A-pillar trim See «UPPER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-a-pillar-trim-removing-and-installing) and «LOWER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-a-pillar-trim-removing-and-installing) .
Separate electrical connection -2- and remove trim -1- together with microphone -4-.
Remove screws -3- and remove microphone -4- from trim -1-.

Install in reverse order of removal.

CAUTION

When reinstalling A-pillar trim, ensure no wires are pinched.

The microphone is integrated into the front interior light module.

Carefully remove interior light module See «FRONT INTERIOR LIGHT, REMOVING AND INSTALLING»(ref-196303-S01428655342005100900000) .
Carefully unclip microphone -1- and disconnect electrical connection.
Depress the four locating tabs locating the microphone in it's mounting -4- and lift-out microphone.

Install in reverse order of removal.

Remove lower B-pillar trim See «UPPER B-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim-removing-and-installing) and «LOWER B-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-b-pillar-trim-removing-and-installing) .
Disconnect electrical connections and remove trim -2-.
Rotate retainer -3- on speaker -1- in direction of -arrow- and remove speaker from housing.

Install in reverse order of removal.

Note. If retrofitting an antenna, always use genuine Audi parts to ensure ease of installation and optimum reception.

Use felt-tipped pen to mark position for antenna hole on left-rear side trim as shown. 88 mm (3.46 in.) 98 mm (3.85 in.) 26 mm (1.02 in.)
Drill hole for antenna and carefully file down edges.
Use suction device to remove any loose metal particles and filings.
Apply anti-corrosion agent and touch up paintwork around hole. See «RAPGARD(R), INSPECTION, REMOVAL AND DISPOSAL»(/audi/a6/c5-1997-2001/remont/procedures/#maintenance__rapgardr-inspection-removal-and-disposal) .
Install antenna.
Install and connect wiring. See appropriate System Wiring Diagram article.

Note. To avoid electrical interference, always make sure that the antenna is properly grounded.

Install toothed washer under Ground connection -1-.

CAUTION

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable Navigation system. Always read the Navigation system owner's manual and review all navigation functions.

All displays appear on the instrument cluster which is connected via the CAN-bus.

All entries are made via buttons on multi-function switch.

The system consists of

Multi-function switch (operating unit)
Instrument cluster (display unit)
Control module for navigation with CD-mechanism (central unit and navigation unit)
Navigation (GPS) antenna

To minimize contact corrosion, only use approved fasteners (screws, nuts, bolts, washers etc.)

Where applicable, fasteners may have a special surface coating recognizable by a greenish color.

Coated fasteners must also be stored separately.

Navigation system III has On Board Diagnostic (OBD) capabilities.

The Navigation control module has a Diagnostic Trouble Code (DTC) memory. If a malfunction occurs in one of the components or wires which is monitored by the system, a record of the type of malfunction is stored in DTC memory. See NAVIGATION SYSTEM III ON BOARD DIAGNOSTIC (OBD), INITIATING .

Note. The following list refers to see scheme 72.

Instrument cluster (display unit)
Function selection switch (operating unit)
Control module for navigation with CD mechanism -J401- (central unit and navigation unit)
Speaker for telephone/navigation -R39- Only vehicles with Bose-sound system
Mid-range/tweeter or bass speakers front (activation via radio/amplifier)
Radio -R
Antenna for navigation (GPS)
Telephone (preparation)

Scheme 420

Note. The following list refers to see scheme 73.

Connecting block with four multi-pin connections and a fuse
Black 20-pin multi-pin connection I
Brown 8-pin multi-pin connection II
Black 8-pin multi-pin connection III
Red 10-pin multi-pin connection IV
Antenna connection GPS; connecting socket for navigation antenna.
Securing bracket for antenna connection

Scheme 421

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to see scheme 74.

2 - CAN-Bus High (Infotainment)
5 - CAN-Bus Low (Infotainment)
13 - NF + (to radio)
14 - NF mute (to radio)
15 - NF - (to radio)
16 - Telephone (NF +) (from telephone)
17 - Tel-active / mute FAW
18 - Tel-NF-screen
19 - Telephone (NF -) (from telephone)

1 - Gala (vehicle speed signal)
2 - Back-up light switch
3 - K - wire, Data Link Connector (DLC)
4 - Terminal 15
7 - Terminal 30 (B+)
8 - Terminal 31 (Ground)

Scheme 422

Note. The following list refers to see scheme 76.

Radio -R- In instrument panel, center Removing and installing. See «"CONCERT" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__concert-radio-removing-and-installing) .
Function selection switch II, in center console -E272- In center console Removing and installing. See «FUNCTION SELECTION SWITCH II -E272-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Display in instrument cluster In instrument panel Removing and installing See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000__instrument-cluster-removing-and-installing) for up to m.y. 1999 and «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) for m.y. 2000 and up.
Antenna for navigation (GPS) -R50-, Antenna for radio/telephone/navigation (GPS) -R52- Sedan: On trunk lid through m.y. 2001 Removing and installing. See «ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- (SEDAN) THROUGH M.Y. 2001, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-for-navigation-system-gps-r50) . Roof antenna from m.y. 2002 Removing and installing. See «ROOF ANTENNA (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-sedan-from-my-2002) . Avant: Roof antenna Removing and installing. See «ROOF ANTENNA (AVANT), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-avant-removing-and-installing) .
Control module for navigation with CD mechanism -J401- In left rear luggage compartment storage box Removing and installing. See «CONTROL MODULE FOR NAVIGATION WITH CD MECHANISM -J401-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__control-module-for-navigation-with-cd) .
Speaker (telephone/navigation) -R39- In B-pillar trim Only for vehicles with Bose-sound system Removing and installing. See «SPEAKER (TELEPHONE/NAVIGATION) -R39- THROUGH M.Y. 2001 (ONLY WITH BOSE(R) SYSTEM), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Bass speaker In lower front door trim Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Mid-range/tweeter In upper front door trim Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .

Function selection switch is located in the center console beside the parking brake lever.

Note. During removal, the function selection switch can only be removed from panel straight upward. During this process, function selection switch may not be tilted or turned, otherwise the catches on bottom side break off.

With two screwdrivers at trim -arrows- carefully lever out function selection switch -1- and remove from panel upward.
Disconnect 4-pin electrical connection at function selection switch.

Install in reverse order of removal.

The antenna is secured on the trunk lid.

First remove trunk lid trim.

See REAR LID TRIM, REMOVING AND INSTALLING .

Note. Before removing antenna, attach a helping wire/rope to end of antenna wire (approx. 1 m in length) and then pull out antenna wire to antenna hole.

Unscrew antenna thread -1- (3.5 Nm) at trunk lid -2-.
Carefully remove antenna wire -1- from left sheet metal opening in trunk lid -2-.
Slide foam trim -3- of electrical connection sideways and separate connection -4-.
Carefully remove antenna upward and pull out antenna wire through antenna hole.

Install in reverse order of removal.

Note. The primed antenna for navigation must be painted in the appropriate vehicle color before installation. For installation, pull new antenna wire into trunk lid with help from the helping wire/rope.

Vehicles from m.y. 2002 equipped with optional navigations and/or telematics systems use a roof-mounted GPS antenna -arrow-.

Scheme 423: Roof antenna (Sedan) from m.y. 2002, removing and installing

Remove rear interior lights. See «REAR INTERIOR LIGHT, REMOVING AND INSTALLING»(ref-196303-S18570452082005100900000) .
Disconnect electrical connections.
Remove nut (3.5 Nm) -arrow- and pull antenna out from opening.

Install in reverse order of removal.

The control module is located in the left rear luggage compartment storage box.

Open left luggage compartment storage box.
Remove screws (3.5 Nm) -arrows- at retainer frame -1-. see scheme 82
Disconnect electrical connections and antenna wire (GPS) on control module for navigation with CD-mechanism and at CD changer.
Remove installation frame -1-.
Remove screws -2- and remove control module for navigation with CD-mechanism -1- from installation frame.

CAUTION

Do not use fasteners other than the original factory type when installing control modules. Control module damage will result.

Install in reverse order of removal.

Installation Notes

The control module for navigation and retainer frame must be installed together in horizontal position and free from vibration to avoid system trouble.
In addition, air circulation must be ensured, meaning that ventilation slots of the control module may not be covered while installing.

CAUTION

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable standard or optional Navigation system. Always read the telephone system owner's manual and review all navigation system functions.

Navigation IV is a further development of previous system "Navigation III".

Dynamic route guidance (Where applicable. See navigation system owner's guide).
Navigation integrated with optional "Audi Telematics by OnStar(R) system.
Compass in Navigation display (where applicable).
Help function (where applicable)

System integrated with vehicle CAN-Bus network.
The dynamic route guidance feature enables local traffic report information to be accessed from either the TMC-function in the radio or telephone (Where applicable. See navigation system owner's guide).

Same as Navigation III. See NAVIGATION SYSTEM III, LAYOUT .

Same as Navigation III. See NAVIGATION SYSTEM III, COMPONENT OVERVIEW .

To minimize contact corrosion, only use approved fasteners (screws, nuts, bolts, washers etc.)

Where applicable, fasteners may have a special surface coating recognizable by a greenish color.

Coated fasteners must also be stored separately.

Navigation system IV has On Board Diagnostic (OBD) capabilities.

CAUTION

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable standard or optional radio and telephone system as they pertain to the multi-function steering wheel. Always read the vehicle/radio owner's manual and review the radio, tape player, CD player/changer and telephone system functions as the pertain to the multi-function steering wheel.

Illuminated function buttons in steering wheel
Steering wheel-incorporated wiring
Steering wheel-incorporated electronics
Vehicle-incorporated control module
Vehicle-incorporated wiring

Function switches/buttons integrated into the multi-function steering wheel allow the driver to safely operate the radio, telephone and Tiptronic controls (models equipped with automatic transmission). In addition, the steering wheel is electrically heated.

Integrated electronics the steering wheel regulate the steering wheel heating, transmission of function switch/button operations to the vehicle CAN-Bus network and dimming (illumination) of the function buttons.

The control module for the multi-function steering wheel controls radio, radio/navigation, telephone, instrument cluster, steering wheel heating and Tiptronic (automatic transmission) functions.

The center display in the instrument cluster shows the currently selected radio channel, and when the telephone is being used, the telephone number being called (from the telephone memory). The display also indicates if either the radio plays a cassette tape (display shows: "TAPE < >", or if the CD changer is in operation (display shows: "CD 02" and the CD track number being played.

The multi-function steering wheel has On Board Diagnostic (OBD) capabilities.

The multi-function steering wheel control module has a Diagnostic Trouble Code (DTC) memory. If a malfunction occurs in one of the components or wires which is monitored by the system, a record of the type of malfunction is stored in DTC memory. See MULTI-FUNCTION STEERING WHEEL ON BOARD DIAGNOSTIC (OBD), INITIATING .

Note. The following list refers to see scheme 84.

Instrument cluster with display In instrument panel
Radio -R- In center instrument panel
CD Changer Unit -R41- (optional) In left rear luggage compartment storage box
Telephone transceiver -R36
Control module for multifunction steering wheel -J453- In 13-position relay carrier below drivers side storage compartment Removing and installing. See «CONTROL MODULE FOR MULTI-FUNCTION STEERING WHEEL -J453-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Multi-function steering wheel With integrated electronics With integrated operation switches Removing and installing. See «MULTI-FUNCTION STEERING WHEEL SWITCHES, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__multi-function-steering-wheel-switches-removing-and) .

Scheme 424

Note. The following list refers to see scheme 85.

CAN-Bus (Infotainment)
Radio -R- In center instrument panel
Control module for multifunction steering wheel -J453- At 13-position relay carrier below drivers side storage compartment Removing and installing. See «CONTROL MODULE FOR MULTI-FUNCTION STEERING WHEEL -J453-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Multi-function steering wheel With integrated electronics with integrated operation switches
Telephone/Telematic Control Module -J526- In front passenger's footwell
Control module for navigation with CD mechanism -J401- In left rear luggage compartment storage box.
Instrument cluster with display In instrument panel

Tiptronic switch (left & right) "+" upshift "-" downshift

Note. The following list refers to items in see scheme 86.

2 - Increase volume
3 - Decrease volume
5 - Radio/Telephone switch
6 - Radio station seek backwards
7 - Radio station seek forwards

Note. The following list refers to items in see scheme 86.

2 - Increase volume
3 - Decrease volume
5 - Radio/Telephone switch
6 - Tape rewind
7 - Tape fast-forward

Note. The following list refers to items in see scheme 86.

2 - Increase volume
3 - Decrease volume
5 - Radio/Telephone switch
6 - CD track back
7 - CD track forward

Note. The following list refers to items in see scheme 86.

2 - Increase hands-free speaker volume
3 - Decrease hands-free speaker volume
4 - Telephone button Answer incoming call Place outgoing call End call (hang-up)
5 - Radio/Telephone switch
6 - Scroll down autodial numbers (alphabetically in telephone memory)
7 - Scroll up autodial numbers (alphabetically in telephone memory)

CAUTION

WARNING

Special safety precautions apply to vehicles equipped with airbags. Refer to appropriate Air Bag Restraint Systems article in Restraints.

Adjust steering wheel as far out and up as possible.
Disconnect battery negative (-) terminal.
Remove airbag unit See appropriate Air Bag Restraint Systems article in Restraints.
Carefully flip airbag unit forward.
Carefully disconnect electrical connector -2-. see scheme 87
Remove screws -1- and -3- (1 Nm).
Remove switch toward front.
Remove switch assembly -4- in direction of -arrow-.

Install in reverse order of removal.

Note. During installation, make sure that connecting wire of connection -2- is in guides and is not pinched.

Adjust steering wheel as far out and up as possible.
Disconnect battery negative (-) terminal.
Remove airbag unit See appropriate Air Bag Restraint Systems article in Restraints.
Carefully flip airbag unit forward.
Carefully disconnect electrical connector -2-. see scheme 88
Remove switches -1- by pressing towards center of steering wheel.
Remove switch assembly -4- in direction of -arrow-.

Install in reverse order of removal.

Note. During installation, make sure that connecting wire of connection -2- is in guides and is not pinched.

Remove driver's side storage compartment See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing) .

Control module for multi-function steering wheel -J453- is stored in a double relay housing and is located in relay sockets -7- and -8- of 13-pin relay carrier above the central electric.

Scheme 425

Remove control module for multi-function steering wheel from relay socket.

Install in reverse order of removal.

CAUTION

Before troubleshooting or servicing, technicians must be familiar with all telematics functions, operating specifics and the particular service plan which the customer subscribes to. Refer to "Audi Telematics by OnStar(R)" Self Study Program (SSP) and "Audi Telematics by OnStar(R) Owner's Manual and/or OnStar(R)" Quick Reference Guide" to become familiar with applicable features and functions.

Telematics is an in-vehicle communication system that uses cellular, internet and Global Positioning System (GPS) technologies to provide the customer with safety, security and convenience services.

GPS is a "constellation" of 24 satellites that orbit the earth and constantly broadcast radio signals. The Telematics/Telephone Control Module receives GPS data, decodes it, and transmits the vehicle's location to the service provider's call center via the national cellular network.

Telematics services for Audi customers are provided by OnStar(R) via a dedicated call center. Service plans may provide route directions and concierge services as well as emergency or vehicle repair services. For details, see Audi Telematics by OnStar(R) Owner's Manual.

During events where the Airbag Control Module processes a crash signal, the vehicle emergency flashers are activated and the doors are unlocked via the respective door control modules. In addition, the telematics system automatically places an emergency call to the OnStar(R) call center.

Telematics hardware includes the driver operated telematics control head (which contains the OnStar(R) control buttons and system status light), microphone, backup loudspeaker, roof mounted GPS/Cellular antenna and Telematics/Telephone Control Module (with supporting software) and related wiring.

An emergency (back-up) battery for the telematics control module is also used in case the vehicle battery goes dead or becomes disconnected due to accident, impact etc.).

All telematics components are factory installed/integrated into the vehicle electrical system.

Telematics system layout. See TELEMATICS SYSTEM, LAYOUT .

Telematics system/component overview. See TELEMATIC SYSTEM, COMPONENT OVERVIEW .

To minimize contact corrosion, only use approved fasteners (screws, nuts, bolts, washers etc.)

Where applicable, fasteners may have a special surface coating recognizable by a greenish color.

Coated fasteners must also be stored separately.

The telematics system has extensive On Board Diagnostic (OBD) capabilities.

The Telematics/Telephone Control Module has a Diagnostic Trouble Code (DTC) memory. If a malfunction occurs in one of the components or wires which is monitored by the system, a record of the type of malfunction is stored in DTC memory. Performing OBD program. See TELEMATICS ON BOARD DIAGNOSTIC (OBD), INITIATING .

The Telematics Control Head is integrated with the front interior light module. The control head contains three separate buttons as well as a system status indicator light (LED).

The OnStar(R) (*) button is used to contact the OnStar(R) call center to request various convenience services. It is also used to initialize/activate the owner's subscription to OnStar(R) services and/or update the customer's account in the event that the Telephone/Telematics Control Module requires replacement.

The Emergency button is used to contact the OnStar(R) call center to request emergency services such as fire department, police etc.

The Communication ("DOT") button is used to end a call to the OnStar(R) call center, place or answer personal calls (in conjunction with the optional digital cellular telephone), or cancel a call if one of the other buttons is accidentally pressed.

Note. Use of certain OnStar(R) services requires a subscriber's Personal Identification Number(s) (PIN).

For complete system operation details. See Audi Telematics by OnStar(R) Owner's Manual.

The system status light is located between the Communication and Emergency buttons. The green light comes on after a self-check routine is performed (approx. 10-15 seconds after ignition is switched on).

Indicated conditions

Green: Indicates system has passed self-test and is ready to place or receive calls. Light remains on even in areas without cellular coverage.
Blinking green: Indicates a call has been initiated or is in progress.
Red: Indicates system has not passed self-test or indicates system malfunction.

Note. System troubleshooting using system status light. See TELEMATICS SYSTEM, TROUBLESHOOTING USING ONSTAR(R) SYSTEM STATUS LIGHT .

An optional digital cellular telephone with specific features integrated into the telematics system is also available.

OnStar(R) and OnStar(R) Personal Calling are activated separately.

Note. Use of certain OnStar(R) services requires a subscriber's Personal Identification Number(s) (PIN).

For complete system operation details. See Audi Telematics by OnStar(R) Owner's Manual.

The following allows technicians to perform an initial evaluation of Telematics system operation status for troubleshooting using the OnStar(R) system status light (and pre-recorded system messages where applicable).

Note. After pressing either the OnStar(R) or Emergency button, a recorded message announces: "connecting to OnStar," followed by progression tones. Normal connection time is 10-15 seconds. However, due to local cellular/GPS conditions, making a connection could take up to three minutes. Be patient.

message "unable to contact OnStar(R)" and disconnect
message "OnStar(R) request ended"
nothing happens
or a cellular message

indicates system cellular reception is affected. Proceed as follows

Relocate vehicle to a more elevated or open area and repeat connection attempts. Depending on the local cellular/GPS traffic conditions, several connection attempts may be necessary (and are normal).
Shortcomings in the vehicle's cellular/GPS antenna system also affects connectivity. Check all cellular/GPS antenna connections, and perform OBD program. See «TELEMATICS ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__telematics-on-board-diagnostic-obd-initiating) . Check for DTCs related to antenna function.
If you are still unable to connect, record the VIN and customer details and call OnStar(R) Customer Care at 1-888-390-4050. Identify yourself to the advisor as an Audi Technician. The advisor will verifiy the customer's OnStar(R) account is active. Further troubleshooting assistance may be given.

indicates system hardware (vehicle portion) is affected. Proceed as follows

Perform OBD program. See «TELEMATICS ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__telematics-on-board-diagnostic-obd-initiating) . Check/perform

DTC memory (function 02)
Output DTM (function 03)
Read Measuring Value Block (function 08)

Note. In the event any of the OnStar(R) control buttons are either inadvertently or deliberately pressed for longer than 15 seconds, the OBD program assumes a button is sticking. The red status light will come on and a DTC loads in memory. Perform OBD program and check DTC memory for DTC 01526 "mechanical malfunction". See TELEMATICS ON BOARD DIAGNOSTIC (OBD), INITIATING . Inform customers accordingly.

The Telematic system is disabled (switched-off) when Transport Mode is activated. This is necessary when vehicles are transported over long distances or stored for longer periods of time.

Audi A6 vehicles are initially delivered to dealerships with the Telematics system in Transport Mode, and must be deactivated before delivery to the customer using OBD program function 10 - Adaptation. See ADAPTATION (FUNCTION 10) .

Note. The following list refers to see scheme 90.

Auxiliary Speaker (telematic) -R91- In right B-pillar
Telephone Microphone -R38- In front interior light module
Radio -R
Loudspeakers (radio system) In front door panels
Instrument cluster
Control module for multifunction steering wheel -J453- In 13-position relay carrier below driver's side storage compartment
Multi-function steering wheel
Telephone/Telematic Control Module -J526- In front passenger's footwell
Control module for navigation with CD mechanism -J401- In left rear luggage compartment storage box
Antenna splitter In left rear luggage compartment storage box
Antenna for navigation (GPS) On roof Integral with telematic antenna
Telematic antenna On roof Integral with GPS antenna
Cellular telephone antenna In rear bumper
Docking station/retainer for optional cellular telephone In center console
Emergency button In Telematic Control Head -E264
OnStar(R) ("On star") button In Telematic Control Head -E264
Communication ("DOT") button In Telematic Control Head -E264
Emergency battery -A16- In front passenger's footwell

GPS antenna connection
42-pin connection
Cellular antenna connection

Note. Terminals which are not listed are vacant/unassigned.

Note. The following list refers to see scheme 92, see scheme 93 and see scheme 94.

1 - Output - horn relay
2 - Output - "lock doors" to central locking control module
3 - Cellular telephone connection - Audio in
4 - Cellular telephone connection - Battery Feedback
5 - Cellular telephone connection - Ground (GND)
6 - Cellular telephone connection - RS 232
7 - Cellular telephone connection - control-Line 1
8 - Cellular telephone connection - shielding Ground (GND)
9 - CAN-Bus High (Infotainment)
10 - Line (+) Output to radio
11 - Auxiliary speaker (+)
12 - Telephone microphone (+)
13 - K-wire, Data Link Connector (DLC)
14 - Terminal 75x
15 - LED "red" (in Telematic Control Head)
16 - LED "green" (in Telematic Control Head)
18 - Ground (GND) (Terminal 31)
19 - Ground (GND) (Terminal 31)
22 - Output - emergency flasher
23 - Output - "unlock doors" to central locking control module
24 - Cellular telephone connection - Audio out
25 - Cellular telephone connection - Audio Ground (GND)
26 - Cellular telephone connection - power supply
27 - Cellular telephone connection - RXD
28 - Cellular telephone connection - control-Line 2
29 - Cellular telephone connection - Hook
30 - CAN-Bus Low (Infotainment)
31 - Line (-) Output to radio
32 - Auxiliary speaker (-)
33 - Telephone microphone (-)
34 - Mute
35 - Input - from Telematic Control Head
36 - Output - to Telematic Control Head (keypad power)
38 - Crash-Signal from airbag control module
39 - Terminal 30 (B+)
40 - Terminal 30 (B+)
41 - Emergency (backup) battery (+)
42 - Emergency (backup) battery (-)

Note. The following list refers to see scheme 95.

Emergency Battery -A16- On Telephone/Telematic Control Module -J526- in front passenger's footwell Removing and installing. See «EMERGENCY BATTERY, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Telephone/Telematic Control Module -J526- In front passenger's footwell Removing and installing. See «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephonetelematic-control-module-j526-removing-and) .
Multi-function steering wheel
Front interior light module with Telematic Control Head -E264- In front headliner Removing and installing. See «TELEMATIC CONTROL HEAD -E264-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telematic-control-head-e264-removing-and) . OnStar(R) ("On star") button System status light (LED) Emergency button Communication ("DOT") button Telephone microphone -R38
Auxiliary speaker (telematic) -R91- In lower right B-pillar trim Removing and installing. See «AUXILIARY SPEAKER (TELEMATIC) -R91-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__auxiliary-speaker-telematic-r91-removing-and) .
Antenna for Navigation System -R50-/Auxiliary Antenna (Telematic) -R90- On roof Removing and installing. See «ROOF ANTENNA (SEDAN) FROM M.Y. 2002, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__roof-antenna-sedan-from-my-2002) .
Antenna Splitter -R87- In left rear luggage compartment storage box Removing and installing. See «ANTENNA SPLITTER -R87- (SEDAN), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-splitter-r87-sedan-removing-and) .
Antenna for telephone -R65- In rear bumper Removing and installing. See «ANTENNA FOR TELEPHONE -R65-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__antenna-for-telephone-r65-removing-and) .
Control module for navigation with CD mechanism -J401- In left rear luggage compartment storage box Removing and installing. See «CONTROL MODULE FOR NAVIGATION WITH CD MECHANISM -J401-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__control-module-for-navigation-with-cd) .
Cellular telephone -R54- Optional equipment (only used in conjunction with telematics system) In center console Telephone system preparation, layout. See «DIGITAL CELLULAR TELEPHONE (PREPARATION) FROM M.Y. 2002, LAYOUT»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__digital-cellular-telephone-preparation-from-my) . Cellular telephone docking station, removing and installing. See «DOCKING STATION/RETAINER (FOR CELLULAR TELEPHONE -R54-), REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__docking-stationretainer-for-cellular-telephone-r54) .
Front Bass Speakers -R21- & -R23- In lower front door panels Removing and installing. See «FRONT BASS SPEAKERS -R21 & -R23-, REAR BASS SPEAKERS -R15- & -R17-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Front Midrange Speakers -R26- & -R27- In upper front door panels Removing and installing. See «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REAR MIDRANGE SPEAKERS -R34 & -R35-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Control module for multifunction steering wheel -J453- On 13-position relay carrier below drivers side storage compartment Removing and installing. See «CONTROL MODULE FOR MULTI-FUNCTION STEERING WHEEL -J453-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer) .
Instrument cluster Removing and installing See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000__instrument-cluster-removing-and-installing) for up to m.y. 1999 and «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/gauges-instrument-panels/#instruments-up-to-2000) for m.y. 2000 and up.
Radio -R- ("Symphony)" In center instrument panel Removing and installing. See «"SYMPHONY" RADIO, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__symphony-radio-removing-and-installing) .

Note. If the Telephone/Telematics Control Module is replaced, the OnStar(R) system needs to be reconfigured. See TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REPLACING AND RECONFIGURING . DO NOT exchange Telephone/Telematic Control Modules between vehicles!. Each module contains specific Station Identification (STID) and Electronic Serial Number (ESN) data unique to the VIN. This data is used by OnStar(R) and National Cellular Telephone Network to identify the vehicle and administer the customer's account.

Switch off emergency battery. See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__emergency-battery-switching-offon) .
Remove right lower A-pillar trim

See LOWER A-PILLAR TRIM, REMOVING AND INSTALLING .

Remove floor mats.
Carefully disconnect electrical and antenna connections.
Remove nuts -3- (5 Nm) and control module -2- from frame -1-.

Install in reverse order of removal.
Switch on emergency battery. See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__emergency-battery-switching-offon) .

Note. Ensure correct seating and fit of electrical connections. Antenna connections (couplings) must be properly aligned and tight to ensure proper reception.

After replacing the Telephone/Telematic Control Module, the OnStar(R) system needs to be reconfigured as described below. Have the VIN and customer details on hand.

Note. DO NOT exchange Telephone/Telematic Control Modules between vehicles!. Each module contains specific Station Identification (STID) and Electronic Serial Number (ESN) data unique to the VIN. This data is used by OnStar(R) and National Cellular Telephone Network to identify the vehicle and administer the customer's account. Failure to reconfigure the control module after replacement will prevent OnStar(R) services and features from functioning, and will result in a customer return for repair. Always replace the emergency (back-up) battery when replacing the Telephone/Telematics Control Module.

Where applicable, carefully record the 8 character Station Identification (STID) number and Electronic Serial Number (ESN) from labels on replacement module.
Remove and replace control module and emergency (back-up) battery. See «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__telephonetelematic-control-module-j526-removing-and) .
Switch on ignition, connect VAG 1551/1552 Scan Tool (ST) and enter address word 75 - "Telematics" ("Emergency call module" may appear on display).
Perform scan tool function 07 - Code Control Module, and enter applicable vehicle/equipment code. See «CODE CONTROL MODULE (FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .
Perform scan tool function 10 - Adaptation, and deactivate "Transport Mode" by entering/storing value "0" in adaptation channel 03. If necessary, refer to detailed procedure. See «TRANSPORT MODE, ACTIVATING/DEACTIVATING»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__transport-mode-activatingdeactivating) .
Reset emergency battery time register by entering/storing value "1" in adaptation channel 08. If necessary, refer to detailed procedure. See «EMERGENCY (BACK-UP) BATTERY, SWITCH ON/OFF, RESET TIME REGISTER»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__emergency-back-up-battery-switch-onoff-reset) .
Erase DTC memory (scan tool function 05). See «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, ERASING (FUNCTION 05)»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .

Perform scan tool function 08 - Read Measuring Value Block.
Read display group 078 and record 8-character ESN. See «DISPLAY GROUP 078»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .
Read display group 079 and record 8-character STID number. See «DISPLAY GROUP 079»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .

End Output (scan tool function 06). See «END OUTPUT (FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .
Switch off ignition and wait a few moments.
Switch on ignition.
Enter address word 75 - "Telematics" ("Emergency call module" may appear on display)
Check DTC memory (scan tool function 02). See «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING (FUNCTION 02)»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) . No DTCs must be present.
Check and confirm the green status indicator light in Telematics Control Head is on.
End Output (scan tool function 06). See «END OUTPUT (FUNCTION 06)»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics) .
Disconnect Scan Tool cable from Data Link Connector (DLC).

Drive vehicle outside to area away from tall buildings, and with no overhead obstructions (trees, bridges, etc.).
Press the blue OnStar(R) ("On star") button. A recorded introduction will be heard.
Press the "On star" button again at any time during the recording (it is not necessary to wait for the recording to finish).
When an OnStar(R) call center advisor answers, identify yourself as an Audi Technician, and that you have replaced the "Vehicle Communications Interface Unit (VCIM)".
Supply advisor with STID number and ESN from new module. Supply the VIN and customer details if necessary. The advisor will guide you through the system reconfiguration and update of the customer's account.
When reconfiguration is complete, end call by pressing the Communications ("DOT") button.
Wait ten minutes and press the "On star" button again to verify system operation. Inform call center advisor you are an Audi Technician performing a quality check after TCM replacement/system reconfiguration.
End call by pressing the Communications ("DOT") button.

Note. Normal connection time is 10-15 seconds. However, depending on local cellular/GPS conditions, making a connection could take up to three minutes. Be patient. If the message: "unable to contact OnStar" is heard, try relocating vehicle to a more elevated or open area and repeat connection attempts. Depending on the local cellular/GPS traffic conditions, several connection attempts may be necessary (and are normal). If the message: "OnStar request ended" is heard, the cellular connection was interrupted before the connection was completed. Wait for a short period of time before repeating connection attempt. If you are still unable to connect, call OnStar(R) Customer Care at 1-888-390-4050. The advisor will verifiy the customer's OnStar(R) account is active.

The antenna splitter is located in the left rear luggage compartment storage box.

Open left rear luggage compartment storage box.
Remove complete retainer frame.
Separate electrical connections to CD changer and remove complete frame with modules from vehicle.
Loosen nut -arrow- (3 Nm) and slide frame out from locating lugs -1-.
Open housing in direction of -arrow-. see scheme 98
Pull splitter out from housing.
Disconnect antenna couplings at splitter.
Loosen screws -1- (1 Nm) and remove housing where necessary.

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connections (couplings) must be properly aligned and tight to ensure proper reception.

The antenna splitter is located in the left rear luggage compartment storage box, on the rear of the retainer frame.

Open left rear luggage compartment storage box.
Remove complete retainer frame.
Open housing in direction of -arrow-.
Pull splitter out from housing.
Disconnect antenna couplings at splitter.
Loosen screws -1- (1 Nm) and remove housing where necessary.

Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connections (couplings) must be properly aligned and tight to ensure proper reception.

The Telematic Control Head is located in the front interior light module.

Remove front interior light module.

See INTERIOR LIGHTS, FRONT, REMOVING AND INSTALLING for up to m.y. 2000 and FRONT INTERIOR LIGHT, REMOVING AND INSTALLING for m.y. 2001 on.

Using a flat-head screwdriver, carefully unclip control head -3- from retainer.
Separate electrical connection -2-.

Scheme 426

Install in reverse order of removal.

The telephone microphone (hands-free microphone) is located in the front interior light module.

Remove front interior light module.

See INTERIOR LIGHTS, FRONT, REMOVING AND INSTALLING for up to m.y. 2000 and FRONT INTERIOR LIGHT, REMOVING AND INSTALLING for m.y. 2001 on.

Using a flat-head screwdriver, carefully unclip microphone -1- from retainer.
Separate electrical connection.

Install in reverse order of removal.

In order to avoid unnecessary discharge of the emergency (back-up) battery, it must always be switched off prior to disconnecting the vehicle battery, and switched back on after the vehicle battery is reconnected.

Switching of emergency battery can be performed using VAS 5051 Vehicle Diagnostic Testing and Information System in mode "Guided Fault finding" or with VAG 1551/1552 Scan Tools (ST) as follows

Switch on ignition, connect VAG 1551/1552 Scan Tool (ST) and enter address word 75 - "Telematics" ("Emergency call module" may appear on display).
Perform scan tool function 10 - Adaptation
Select adaptation channel 08
Press -Q- button to confirm input.
Press --> button.

Switch off emergency battery by entering/storing value "2" in adaptation channel 08. If necessary, refer to detailed procedure. See «EXAMPLE: SWITCH OFF EMERGENCY (BACK-UP) BATTERY»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__example-switch-off-emergency-back-up-battery) .

Switch on emergency battery by entering/storing value "0" in adaptation channel 08. If necessary, refer to detailed procedure. See «EXAMPLE: SWITCH ON EMERGENCY (BACK-UP) BATTERY»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__example-switch-on-emergency-back-up-battery) .

Switch off emergency battery. See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a6/c5-1997-2001/remont/communication-devices/#radio-telephone-navigation-trip-computer__emergency-battery-switching-offon) .
Remove right lower A-pillar trim See «LOWER A-PILLAR TRIM, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim__lower-a-pillar-trim-removing-and-installing) .

Remove floor mats.
Carefully disconnect electrical and antenna connections from Telephone/Telematics Control Module -1-. see scheme 102
Remove nuts -arrows- (4 Nm) and remove frame with installed control module.
Open housing -2-, separate electrical connection and remove battery -3-.

Install in reverse order of removal.

Note. Ensure correct seating of connectors.

Switching of emergency battery can be performed using VAS 5051 Vehicle Diagnostic Testing and Information System in mode "Guided Fault finding" or with VAG 1551/1552 Scan Tools (ST) as follows

Switch on ignition, connect VAG 1551/1552 Scan Tool (ST) and enter address word 75 - "Telematics" ("Emergency call module" may appear on display).
Perform scan tool function 10 - Adaptation
Select adaptation channel 08
Press -Q- button to confirm input.
Press --> button.

Switch on existing emergency battery by entering/storing value "0" in adaptation channel 08. If necessary, refer to detailed procedure. See «EXAMPLE: SWITCH ON EMERGENCY (BACK-UP) BATTERY»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__example-switch-on-emergency-back-up-battery) .

Reset new emergency battery time register by entering/storing value "1" in adaptation channel 08. If necessary, refer to detailed procedure. See «EXAMPLE: RESET EMERGENCY (BACK-UP) BATTERY TIME REGISTER»(/audi/a6/c5-1997-2001/remont/communication-devices/#on-board-diagnostic-obd-radio-navigation-steering-telematics__example-reset-emergency-back-up-battery-time) .

The auxiliary speaker is located in the lower right B-pillar trim.

Remove lower right B-pillar trim.

See LOWER B-PILLAR TRIM, REMOVING AND INSTALLING .

Disconnect electrical connections.
Rotate retainer -1- on speaker -2- in direction of -arrow- and remove speaker from housing.

Install in reverse order of removal.

The antenna for the cellular telephone (used in conjunction with telematics) is located in the rear bumper.

Open left rear luggage compartment storage box.
Separate antenna coupling -arrow-.
Remove rear bumper cover. See «REAR BUMPER, REMOVING, INSTALLING AND ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#bumper) .

Pull antenna -2- out from retainer -1- in direction of -arrow-.

Install in reverse order of removal.

Radio, Telephone, Navigation, Trip Computer Audi A6 C5

General information

Contact Corrosion

On Board Diagnostic (OBD)

Retrofitting of radio systems

CD equipment, retrofitting

Transport Mode, deactivating

"Concert" radio system (Sedan) through m.y. 2001, component overview

"Concert" radio system (Avant) through m.y. 2001, component overview

"Concert" & "Symphony" radio system (Sedan) from m.y. 2002, component overview

Radio systems with Satellite Digital Audio Radio Service (SDARS) (Sedan), component overview

"Concert" & "Symphony" radio system (Avant) from m.y. 2002, component overview

Radio systems with Satellite Digital Audio Radio Service (SDARS) (Avant), component overview

"Concert" radio, layout

"Concert" radio, Multi-pin connection terminal assignments

Multi-pin connection I, 20-pin

Multi-pin connection II, 8-pin, brown

Multi-pin connection III, 8-pin, black

Multi-pin connection IV, 10-pin, red

"Concert" radio with BOSE(R) sound system, layout

"Concert" radio with BOSE(R) sound system, Multi-pin connection terminal assignments

Scheme 415

Scheme 416

"Symphony"radio (Sedan), layout

"Symphony" radio (Avant), layout

"Symphony" radio, Multi-pin connection terminal assignments

20-pin multi-pin connection I

Brown 8-pin multi-pin connection II

Black 8-pin multi-pin connection III

Scheme 417

Red 10-pin multi-pin connection IV

"Symphony" radio with "BOSE(R) sound system" (Sedan), layout

"Symphony" radio with "BOSE(R) sound system" (Avant), layout

Radio system SDARS with "BOSE(R) sound system" (Sedan), layout

Radio system SDARS with "BOSE(R) sound system" (Avant), layout

Communication system with SDARS, layout

Multi-pin connection assignments on "Symphony" radio

Multi-pin connection, 25-pin

Multi-pin connection assignments on Satellite Radio -R146

Rear window antenna (Sedan), connections

Side window antenna (Avant), connections

"Concert" radio, removing and installing

Required special tools, testers and auxiliary equipment

Scheme 418

Removing

Installing

"Symphony" radio, removing and installing

Required special tools and equipment

Satellite Radio -R146- (Sedan), removing and installing

Satellite Radio -R146- (Avant), removing and installing

CD Changer Unit -R41-, removing and installing

Checking wiring connection between radio and CD changer

Antenna amplifiers - "Concert" radio (Sedan) through m.y. 2001, removing and installing

Antenna amplifiers -"Symphony" & "Concert" radios (Sedan) from m.y. 2002, removing and installing

Antenna amplifiers - "Symphony" & "Concert" radios (Avant) from m.y. 2002, removing and installing

Scheme 419

Antenna Selection Control Module -J515- (Sedan), removing and installing

Antenna Selection Control Module -J515- (Avant), removing and installing

Satellite Tuner Antenna -R172- (Avant), removing and installing

Roof antenna (Avant), removing and installing

Hands-free Telephone through m.y. 2001, layout

Digital cellular telephone (preparation) from m.y. 2002, layout

Docking station/retainer (for cellular telephone -R54-), removing and installing

Telephone Transceiver -R36- (Sedan) through m.y. 1998, removing and installing

Telephone Transceiver -R36- (Sedan and Avant) from m.y. 1999, removing and installing

Telephone Transceiver -R36- (Sedan) from m.y. 2000, removing and installing

Telephone microphone -R38- from m.y. 2000, removing and installing

Mast antenna, retrofitting

Navigation system III, layout

Scheme 420

Terminal assignments/harness connectors on Control module for navigation with CD mechanism -J401

Scheme 421

Terminal assignment of multi-pin harness connectors I, II, III, IV on control module for navigation with CD drive -J401

Scheme 422

Navigation system III, component overview

Antenna for navigation system (GPS) -R50- (Sedan) through m.y. 2001, removing and installing

Roof antenna (Sedan) from m.y. 2002, removing and installing

Scheme 423

Control module for navigation with CD mechanism -J401-, removing and installing

Navigation IV - additional equipment features
