Electrical Equipment Audi A6 С6

Battery

The battery is one of the most important electrical components in the vehicle. Trouble-free operation of the battery contributes substantially to customer satisfaction. To ensure a long service life, the battery must be checked, serviced, and cared for according to the explanations in this information.

In addition to its function of starting the vehicle, the battery performs other tasks as a buffer and a source of electrical energy for the vehicles entire electrical system.

Safety precautions

Before beginning work, the technicians must be acquainted with the possible risks when handling batteries.

Warnings and safety measures for lead-acid batteries

When servicing batteries, technicians must be aware of, and observe warnings and safety measures specified in this repair information.

Scheme 1

Explanation of WARNING symbols on batteries

Electrolyte

Eye protection and protective clothing

Danger of explosion

Scheme 2

Note. Do not grease battery terminals. Put the battery terminal clamps on only by hand, without forcing them, to avoid damaging the battery casing. The tightening torque for the cable clamps - arrow - is 7.5 Nm. The tightening torque of the additional clamps on the battery terminal clamps is 7.5 Nm.

Scheme 3

Battery, disconnecting and reconnecting notes

Should service procedures in this Repair Information specify disconnecting and reconnecting battery, please observe following CAUTIONS

Battery, disconnecting and connecting

Work procedure

1. Switch ignition off and remove ignition key.

Sedan

1. Lift and secure luggage compartment floor mat.

Scheme 4

Avant

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

Scheme 5

All

1. Release battery strap - 1 - if present.

Scheme 6

1. Release retaining clips - arrows - using a screwdriver - 2 - and remove ground (GND) terminal cap - 1 -.

Note. Illustration shows molded insert removed.

1. Disconnect Ground (GND) wire - arrow - at battery.
2. To connect, connect terminal clamp of Ground (GND) wire by hand to battery minus pole "-" and tighten nut.

If the battery is re-connected again, the following steps must be performed

1. Activate automatic run-up and run-down of electric window regulators Owners manual.
2. Synchronize secondary and additional keys to ensure remote control operation. To do so, insert key into ignition lock, switch the ignition on and off again and remove key.
3. Check DTC memories of all control modules and erase DTCs "Undervoltage" if necessary.

Note. After re-connecting voltage supply, ESP indicator lamp can only go out after driving several meters.

Tightening torque

Removing

1. Switch ignition off and remove ignition key.

Sedan

1. Lift and secure luggage compartment floor mat.

Avant

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

All

1. Release battery strap - 1 - if present.

1. Release retaining clips - arrows - using a screwdriver - 2 - and remove ground (GND) terminal cap - 1 -.

Note. Illustration shows molded insert removed. Connect the battery charger for battery assistance mode --> Battery assistance mode using battery charger VAS 5095A , VAS 5900 or VAS 5903 .

Scheme 7

1. Remove cover - 4 - above battery positive terminal.
2. Disconnect ground (GND) wire - 5 - and B+ wire - 3 - from battery.
3. Remove hose of central venting system - 6 -.
4. Remove bolt - 2 - at battery retaining bracket - 1 -.

1. Lift battery out of right luggage compartment.

Installing

Note. For optimum operation of Energy Management Control Module J644 , the use of the battery indicated in the Parts Catalog is recommended. Only cycle-proof and leak-proof valve-regulated lead-acid batteries or AGM batteries according to standards "TL82506" (from December 1997) and "VW75073" (from August 2001) must be installed. Batteries from the Audi Parts Program have a bottom strip-adapter for adapting to different grip channels. Whether and how bottom strip-adapter is used, refer to operating instructions for battery.

Scheme 8

1. Insert battery into battery holder so that tab of rear battery holder - arrow - engages into cutout for battery clamping strip - 1 -.

1. Battery must no longer be movable.

1. Tighten battery retaining bracket - 1 - using bolt - 2 -.

Note. The tab at the battery retaining bracket must engage in the recess at the battery clamping strip.

With ignition switched off and electrical components switched off, connect battery in the following sequence

1. First, connect terminal clamp - 3 - of positive wire to battery positive terminal "+" by hand and tighten nut.
2. Connect terminal clamp - 5 - of ground (GND) wire to battery negative terminal "-" by hand and tighten nut.
3. Connect hose - 6 - for central venting system, heed notes --> «Batteries with central gas venting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__batteries-with-central-gas-venting) .
4. Close cover - 4 - above battery positive terminal.

1. Check battery for proper seating after installation --> «Check battery for secure seating»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__check-battery-for-secure-seating) .
2. Stop battery assistance mode at battery charger.

If the battery was not removed and installed in assistance mode, the following steps must be performed after reconnecting the battery

1. Activate automatic run-up and run-down of electric window regulators Owners manual.
2. Synchronize secondary and additional keys to ensure remote control operation. To do so, insert key into ignition lock, switch the ignition on and off again and remove key.
3. Check DTC memories of all control modules and erase DTCs "Undervoltage" if necessary.

Note. After re-connecting voltage supply, ESP indicator lamp can only go out after driving several meters.

If the battery was replaced, Energy Management Control Module J644 must be coded anew.

Tightening torques

Check battery for secure seating

1. Try to wiggle battery back and forth to check for proper installation.

If battery is not securely seated, the following dangers exist

1. Shortened service life due to damage caused by shaking.
2. If the battery is not secured properly normal shock and vibration can damage the battery plates, which results in premature battery failure.
3. The battery casing can be damaged by the fastening clip (this might possibly allow acid to escape from the battery, which would have severe consequences).
4. Poor crash safety.

Batteries with central gas venting

Note. Make sure that venting hose is always connected to the battery. For batteries with hose/tube for central venting system, make sure the hose is not kinked. Only in this case can the battery be vented freely. The latest generation of batteries has a central venting system and a flashback protector in the form of a so-called "frit". Function: Gas produced when charging leaves the battery through a central opening on the top part of the side covering. A flashback protector is also integrated at the same place to prevent the combustible gas in the battery from igniting. The frit consists of a small round fiberglass mat about 15 mm in diameter and 2 mm thick. It works similarly to a valve, i.e. it allows gas produced in the battery to flow out. Do not lubricate battery terminals. Put the battery terminal clamps on only by hand, without forcing them, to avoid damaging the battery casing.

Scheme 9

The "magic eye" - arrow - gives information regarding the acid level and the charge level of the battery. Three different color indications are possible

Note. If the battery is older than 5 years and the color indication of the magic eye is transparent, the battery should be replaced with a new one.

Work procedure

Note. When recharging the battery (but also while driving), air bubbles can form below the "magic eye". These corrupt the color indication of the "magic eye". If batteries are equipped with sealing plugs due to manufacturing conditions, they are covered with a plastic foil. Before performing a visual check, lightly and carefully tap onto "magic eye" using a screwdriver handle; as a result the air bubbles will disappear. Read color indication of the "magic eye" --> Battery with "Magic Eye" .

Visual check of battery

A visual check of the battery should be performed before executing measurements such as open-circuit voltage, electrolyte density or battery load check.

1. Check the following

1. Is the battery housing damaged? Damage to the casing can allow acid to escape from the battery.
2. Are the battery terminals (battery connections) damaged? Because of a damaged battery terminal, contact of the wiring connections is not ensured. This can cause a cable fire and interfere with the function of the electrical system.
3. Are the original battery sealing plugs installed? The sealing plugs must be equipped with an O-ring seal. In case of loss or damage, only original sealing plugs of the same type may be used.

Battery check using diagnostic systems VAS 5051 , VAS 5052 and VAS 5053

Special tools, testers and auxiliary items required

Scheme 10

1. Vehicle Diagnostic, Testing and Information System VAS 5051B with diagnostic cable VAS 5051/5A

Work procedure

1. No charging unit must be connected when checking the battery, and the engine must not be running.
2. Battery temperature must be at least -10 ° C.
3. Diagnostic system temperature must be +5 45 ° C.

1. With ignition switched on, connect Diagnostic Operation System VAS 5051B with diagnostic cable VAS 5051/5A.

Note. If a malfunction indication is displayed Operating instructions of VAS 5051B.

Scheme 11

Display on VAS 5051B

1. Touch Guided Functions button.

Scheme 12

Display on VAS 5051B

1. Enter vehicle identification number by selecting - A - and the appropriate text line - 1 -.

Vehicle Diagnostic, Testing and Information System VAS 5051B will then switch to the next selection level.

1. Follow further instructions on display of VAS 5051B , the following can be displayed

1. Battery is OK.
2. Charge battery.
3. Replace battery.

After battery check

1. Touch Go To button.
2. Select function "Exit".

Display on VAS 5051B

1. Switch off ignition and disconnect diagnostic connector after this indication is displayed.
2. If necessary, charge battery according to --> «Charge battery»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__charge-battery) , or replace battery --> «Battery, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

No load voltage, checking

Note. Measurement of open-circuit voltage for evaluation of battery charge condition should only be considered if battery check cannot be executed using VAS 5051 , VAS 5052 or VAS 5053.

Special tools, testers and auxiliary items required

Scheme 13

1. Portable multimeter V.A.G 1526C

Work procedure

1. Make sure the following is observed, since a proper measurement can otherwise not be ensured.

1. Battery remains installed in vehicle, battery ground (GND) strap must not be disconnected.
2. Open rear lid and adjust lid lock at position "Closed" so that the luggage compartment lamp is not switched on.
3. Lock vehicle with remote control.
4. Battery must not be loaded by electrical components within the next 2 hours before measurement.

1. Battery must not be charged within the next 12 hours before measurement.
2. Battery temperature must be at least -10 ° C.

Vehicles with ground (GND) pin in luggage compartment

Sedan

1. Lift and secure luggage compartment floor mat.

Avant

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

All

1. Release battery strap - 1 - if present.

1. Release retaining clips - arrows - using a screwdriver - 2 - and remove ground (GND) terminal cap - 1 -.

Note. Illustration shows molded insert removed. Remove cover above battery positive terminal.

Vehicles with ground (GND) pin in luggage compartment

1. Open cover - arrow - above battery positive terminal.
2. Connect multimeter V.A.G 1526C to positive terminal "+" and negative terminal "".

Continuation of open-circuit voltage measurement

After a holding time of at least 2 hours

1. Measure voltage between the battery terminals.

1. If meter indicates 12.5 volts or more, battery is in good condition.
2. If battery open-circuit voltage is less than 12.5 volts, battery must be recharged --> «Charge battery»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__charge-battery) .

1. After recharging, a battery check must be performed --> «Battery check using diagnostic systems VAS 5051 , VAS 5052 and VAS 5053»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-check-using-diagnostic-systems-vas) .

Battery, rapid-charging

Note. Battery temperature must be at least 10 ° C. Rapid charging of batteries should only be performed in exceptional circumstances (e.g. boost starting) as rapid charging may cause damage.

Checking electrolyte level - batteries with "magic eye"

1. For batteries with "magic eye" - arrow - , the electrolyte level can be read out via color indication. Three different color indications are possible

Checking electrolyte level - batteries with sealing plug

Maintaining the correct electrolyte level in the battery is an important factor affecting the length of the batterys service life.

1. Batteries with visible minimum and maximum marks require only visual inspection from the outside of the battery to check the electrolyte level.

1. The electrolyte level must be above the min marking but may extend only as far as the max marking.

1. Unthread the sealing plugs on batteries which do not have clearly visible min and max markings or have an opaque housing so that the electrolyte level cannot be checked.
2. Check electrolyte level by visually checking the inside of the battery.

1. The electrolyte level must stop at the inside electrolyte level mark (plastic peg). This corresponds to the exterior max. marking.

If the electrolyte level is too low, a loss of battery capacity (power) occurs due to cell plates drying out. If the cell plates are not surrounded by electrolyte (sulfuric acid-water mixture), the plates, plate straps, and cell connectors will corrode. The corrosion damages battery operation, the battery can no longer be used.

If the electrolyte level in the battery cells is too low, the battery must be replaced.

1. Replacing battery --> «Battery, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Electrolyte specific gravity, measuring - batteries with sealing plugs

Special tools, testers and auxiliary items required

Scheme 14

1. Refractometer T10007 or

Scheme 15

1. Commercially available hydrometer

Note. The electrolyte density test, in combination with the battery load test, provides information about the condition of the battery. The temperature of the battery acid must be at least 10 ° C. The electrolyte density can be checked directly after the battery is charged.

Scheme 16

Work procedure

1. Remove all sealing plugs of battery cells.
2. Dip hydrometer into battery cell and siphon off enough electrolyte until float floats freely in electrolyte.

1. The larger the specified weight of the siphoned battery acid, the higher the float will float.
2. The acid density of the electrolyte can be read off in kg/dm 3 on the hydrometer scale (specified density of the battery acid).

1. Read off measured value at hydrometer and compare to indicated values in the table

Specified acid density must be at least 1.24 kg/dm 3 in moderate climate zones. If the acid density in all battery cells is too low

1. Charge battery and repeat acid density test.

Example 1

Example 2

If specified values are not obtained

1. Replace battery.

Note. The measured values for the acid density for individual battery cells may not deviate more than 0.03 kg/dm 3 from each other, otherwise replace battery.

If specified values are obtained

1. Thread in sealing plugs of battery cells.

Charge battery

Special tools, testers and auxiliary items required

Scheme 17

1. Battery charger VAS 5095A or

Scheme 18

1. Battery charger VAS 5900 or

Scheme 19

1. Battery charging unit VAS 5903

Note. Battery chargers VAS 5095A , VAS 5900 and VAS 5903 charge without current and voltage peaks. Batteries can therefore also be charged when installed. When doing this, heed the safety instructions. The devices provide an assistance mode in which they provide supply for the circuits. When working on the electrical equipment with components temporarily switched on, and for "Guided Fault Finding" , the battery must be charged with a battery charger with assistance mode to prevent damage to the battery.

Work procedure

1. Switch off battery charger.
2. Switch off ignition.

Sedan

1. Lift and secure luggage compartment floor mat.

Avant

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

Scheme 20

Vehicles with ground (GND) pin in luggage compartment

1. Remove cover - 2 - above battery positive terminal.
2. Clamp battery charger pliers - 1 - of positive wire to batterys B+ terminal.
3. Clamp ground (GND) wire pliers - 3 - of battery charger to ground pin - arrow - of Energy Management Control Module J644.

Vehicles with ground (GND) pin in engine compartment

1. Open cover - arrow - above battery positive terminal.
2. Clamp positive wire clamp of battery charger to B+ terminal tap, and clamp ground (GND) wire pliers of battery charger to negative terminal tap.

All

1. Adjust charge current at battery charger according to battery capacity. It should amount to approx. 10 % of the battery capacity. For a 60 Ah-battery, approx. 6 A.
2. Switch on battery charger.
3. Keep lid open while charging.
4. Perform battery test after charging process --> «Charge battery»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__charge-battery) ..

Severely discharged batteries

1. Batteries which have not been used in driving operation for a long time, for example in stored vehicles, discharge themselves.
2. A battery is severely discharged, when the resting voltage has dropped below 11.6 volts. With voltage between 12.2 and 11.6 V, the battery is pre-damaged. Measuring open-circuit voltage --> «No load voltage, checking»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__no-load-voltage-checking) .
3. In severely discharged batteries the electrolyte (a mixture of sulfuric acid and water) consists almost entirely of water, since the proportion of sulfuric acid is strongly reduced. At minus temperatures, the battery can freeze and the casing can crack.
4. Severely discharged batteries can sulfatize, i.e. the complete plate-surfaces of the batteries can harden. The battery acid is not clear, it has a slightly white color.

1. If severely discharged batteries are recharged again shortly after having been severely discharged, the sulfation forms again.
2. If these batteries are not recharged, the plates continue to harden and the charge-retention ability becomes limited. The consequence is reduced battery performance.

Procedure for charging severely discharged batteries, which are sulfatized

Severely discharged batteries which are sulfatized must be charged with a small charge-current as follows

1. Adjust charging current to approx. 5 % of the battery capacity, i.e. for a 60 Ah battery, the charging current is then to approx. 3 Ampere.
2. Charge battery --> «Charge battery»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__charge-battery) . The charge voltage (U max ) may only amount to a max. of 14.4 V (volt).

Note. Severely discharged batteries should never be charged quickly.

Battery assistance mode using battery charger VAS 5095A , VAS 5900 or VAS 5903

1. The battery assistance mode is used, e.g. for battery replacement in the workshop when troubleshooting.
2. In the following, the battery assistance mode is described acting for battery charger VAS 5900.

Special tools, testers and auxiliary items required

1. Battery charger VAS 5095A or

1. Battery charger VAS 5900 or

1. Battery charging unit VAS 5903

Work procedure

1. Switch ignition off and remove ignition key.
2. Switch off all electrical components.
3. Connect power plug of battery charger VAS 5900.

1. The last selected operating mode appears on the display.

1. Press Start/Stop button for approx. 5 seconds.

1. Menu item "charging of severely discharged batteries / assistance mode" is activated.

1. Press button ↑ or ↓ in order to adjust the vehicle electrical system.

Note. If no button is pressed within 5 seconds, the battery charger VAS 5900 switches back to the main menu. Select the battery voltage by pressing the Start/Stop button.

Vehicles with ground (GND) pin in luggage compartment

Sedan

1. Lift and secure luggage compartment floor mat.

Avant

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

1. Remove cover - 2 - above battery positive terminal.
2. Clamp battery charger pliers - 1 - of positive wire to batterys B+ terminal "+".
3. Clamp ground (GND) wire pliers - 3 - of battery charger to ground pin - arrow - of Energy Management Control Module J644.

Vehicles with ground (GND) pin in luggage compartment

1. Open cover - arrow - above battery positive terminal.
2. Clamp positive wire clamp of battery charger to B+ terminal tap "+" , and clamp ground (GND) wire pliers of battery charger to negative terminal tap "".

All

1. The charging clips are checked for connection to correct poles.

1. Confirm charging clips are connected to correct poles via Start/Stop.

1. The battery charger VAS 5900 starts the assistance mode.

The battery can now be removed.

1. Press Start/Stop button to end assistance mode only after replacing the battery.
2. Disconnect power plug.

Battery Switch-Off Relay J655 , removing and installing - vehicles up to approx. 06.2004

If Battery Switch-Off Relay J655 is malfunctioning or was triggered, it must be replaced.

1. Replace Battery Switch-Off Relay J655 --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Battery Interrupt Igniter N253 , removing and installing - vehicles as of approx. 07.2004

If Battery Interrupt Igniter N253 is malfunctioning or was triggered, it must be replaced.

1. Replace Battery Interrupt Igniter N253 --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 21

Removing

Note. All cable ties opened or cut during engine removal must be reinstalled at the same locations during installation. Remove battery --> Battery, removing and installing . Release clasps - arrows - and open flap - 1 -.

Scheme 22

Vehicles up to approx. 06.2004

1. Remove nuts - 1 - and - 3 - from B+ wires.
2. Remove Battery Switch-Off Relay J655 - 2 - from retainer.

Note. Disregard - 4 -.

Scheme 23

Vehicles as of 07.2004

1. Remove nuts - 1 - and - 3 - from B+ wires.
2. Remove Battery Interrupt Igniter N253 - 2 - from retainer.

Note. Disregard - 4 - and - 5 -.

Scheme 24

All

1. Remove nuts - 3 - and - 4 -.
2. Cut cable tie - 1 - and remove retainer - 2 - from body.

Installing

Installation is performed in reverse order of removal, noting the following

Note. During installation, re-install all cable ties at the same locations. Install battery Installing .

Tightening torques

Energy Management Control Module J644 , removing and installing

Removing

Note. While removing and installing, no charger must be connected. If control module is replaced, select "Guided Functions" of respective control module in. With ignition switched off, disconnect battery Ground (GND) wire --> Battery, disconnecting and connecting .

Scheme 25

Vehicles with molded insert

1. If present, remove mounting bolt - 1 -.
2. Remove molded insert from spare wheel well - arrows -.

Scheme 26

All

1. Remove ground pin - 2 - and cap nut - 5 -.
2. Remove Energy Management Control Module J644 - 4 -.
3. Unscrew ground (GND) wire - 1 - to battery from Energy Management Control Module J644.
4. Disconnect electrical harness connector - 3 -.

Scheme 27

1. Press catch - 1 - and rotate retaining bracket in - direction of arrow - to do so.

Installing

When installing, always heed the following sequence, otherwise proper function of Energy Management Control Module J644 cannot be guaranteed.

1. Install ground (GND) wire 1 to battery on Energy Management Control Module J644.
2. Screw Energy Management Control Module J644 4 on to body, tighten ground (GND) pin 2 and cap nut 5 to do so.
3. Connect ground (GND) wire to battery.
4. Connect electrical harness connector 3 to Energy Management Control Module J644.
5. Perform necessary steps after connecting battery.

If Energy Management Control Module J644 was replaced, it must be coded.

Tightening torques

Scheme 28

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove front engine cover - arrows -.

Scheme 29

Note. Mark direction of rotation of ribbed belt using chalk or felt-tip marker before removing. Reversing the direction of rotation of a run-in ribbed belt can destroy the belt. Pivot tensioner in - direction of arrow - to release tension on ribbed belt. Remove ribbed belt from generator pulley. Release tensioner.

Scheme 30

1. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 31

1. Disconnect electrical wires - 1 - and - 2 - from generator.
2. Unscrew bolts - arrows - and remove generator.

Scheme 32

Installing

Installation is performed in reverse order of removal, noting the following

1. Place ribbed belt over belt pulley in the specified sequence.

1. Generator
2. Relay pulley
3. Coolant pump
4. Power-steering pump
5. A/C compressor
6. Ribbed belt tensioner
7. Crankshaft

Note. When installing ribbed belt, be sure that it is seated correctly on belt pulleys. Connect battery. Required actions Battery, disconnecting and connecting . Start engine and check path of belt.

Tightening torques

Vehicles with 4.2l MPI engine

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Drain engine coolant --> 4.2 Liter V8 5V Engine Mechanical, Engine Code(s): BNK - 19 - ENGINE - COOLING SYSTEM .
3. Bring lock carrier into service position --> «50 - BODY - FRONT»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Scheme 33

1. Remove front engine cover - arrow 1 - and - arrows 2 -.

Scheme 34

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

Scheme 35

1. Disconnect vacuum line - 2 -.
2. Disconnect electrical harness connector - 1 - at Mass Air Flow (MAF) Sensor G70.
3. Remove air guide hose, release hose clamp - 3 - and open clips - arrows - to do so.

Scheme 36

1. Open clips - arrows - and remove upper air filter housing.

Scheme 37

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear from Intake Air Switch-Over valve N335.
4. Disconnect hose - 3 - to Secondary Air Injection (AIR) pump.

1. Remove lower air filter housing.

Scheme 38

1. Remove bolt - 2 - and remove bracket.
2. Pull water pipes out of generator.
3. Disconnect electrical wires - 1 - and - 3 - from generator.

Scheme 39

Note. Mark direction of rotation of ribbed belt using chalk or felt-tip marker before removing. Reversing the direction of rotation of a run-in ribbed belt can destroy the belt. Loosen tensioning bolt - arrow - and remove ribbed belt.

Scheme 40

1. Remove bolts - arrows - and remove tensioner roller.

Scheme 41

1. Remove bolts - arrows -.

Note. If generator is stuck in its bracket, screw in mounting bolts again except 2 rotations. Carefully strike on bolt heads using flat side of hammer - doing this loosens sleeves of generator mount. Remove generator.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Secure all hose connections using hose clamps appropriate for the model type Parts Catalog Replace O-rings. Slightly drive back sleeves for retaining bolts in order for easier installation of generator.

Note. Tight sleeves for generator mount must be made smooth-running, otherwise clamping force of sleeve is too little despite correct torque.

Scheme 42

1. Place ribbed belt - 2 - over belt pulleys in the specified sequence.

1 - Generator

3 - Relay pulley

4 - Harmonic balancer

5 - Tensioner roller

Note. When installing ribbed belt, be sure that it is seated correctly on belt pulleys. Install lock carrier with attachments --> 50 - BODY - FRONT . Connect battery. Required actions Battery, disconnecting and connecting . Fill with coolant --> 4.2 Liter V8 5V Engine Mechanical, Engine Code(s): BNK - 19 - ENGINE - COOLING SYSTEM . Start engine and check path of belt.

Tightening torques

Scheme 43

Special tools, testers and auxiliary items required

1. Hose clamps up to 25mm 3094
2. Hose clamp pliers V.A.G 1921
3. Pliers for spring-type clamps VAS 5024 A

Scheme 44

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove quick-release screws - 1 - and - 2 -.
3. Remove pin of expanding clip - arrow - and remove noise insulations.

Scheme 45

1. Remove electrical harness connector - 2 - from bracket and disconnect it.
2. Release clip - arrow - and lay Coolant Fan Control (FC) Control Module J293 - 1 - aside.

Scheme 46

Note. Mark direction of rotation of ribbed belt using chalk or felt-tip marker before removing. Reversing the direction of rotation of a run-in ribbed belt can destroy the belt. Pivot tensioner in - direction of arrow - to release tension on ribbed belt. Remove ribbed belt and release tensioner.

Scheme 47

1. Remove bolts - arrows -.
2. Remove tensioner for ribbed belt from upper part of oil pan.

Scheme 48

1. Clamp coolant hoses - 2 - and - 3 - using hose clamps 3094.

Note. Place a rag under separating point to catch escaping coolant. Disconnect coolant hoses - arrows - from coolant pipes. Disconnect electrical harness connector - 3 - at generator. Remove terminal 30/B+ - 1 -.

Scheme 49

1. Unscrew bolts - arrows - and remove generator.

Note. If generator is stuck in its bracket, screw in mounting bolts again except 2 rotations. Carefully strike on bolt heads using flat side of hammer - doing this loosens sleeves of generator mount.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Secure all hose connections using hose clamps appropriate for the model type Parts Catalog Slightly drive back sleeves for retaining bolts in order for easier installation of generator.

Note. Tight sleeves for generator mount must be made smooth-running, otherwise clamping force of sleeve is too little despite correct torque.

1. Place ribbed belt - 2 - over belt pulleys in the specified sequence.

1 - Generator

3 - Relay pulley

4 - Harmonic balancer

5 - Tensioner roller

Note. When installing ribbed belt, be sure that it is seated correctly on belt pulleys. Install ribbed belt --> 4.2 Liter V8 5V Engine Mechanical, Engine Code(s): BVJ - 13 - ENGINE - CRANKSHAFT, CYLINDER BLOCK . Connect battery. Required actions Battery, disconnecting and connecting . Fill with coolant --> 4.2 Liter V8 5V Engine Mechanical, Engine Code(s): BVJ - 19 - ENGINE - COOLING SYSTEM . Start engine and check path of belt.

Tightening torques

Vehicles with 5.2l FSI engines

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Drain engine coolant --> 5.2 Liter 10-Cyl. 4V Engine Mechanical, Engine Code(s): BXA - «19 - ENGINE - COOLING SYSTEM»(ref-281368-S21687354792008031100000) .
3. Remove radiator --> 5.2 Liter 10-Cyl. 4V Engine Mechanical, Engine Code(s): BXA - «19 - ENGINE - COOLING SYSTEM»(ref-281368-S21687354792008031100000) .

Note. Mark direction of rotation of ribbed belt using chalk or felt-tip marker before removing. Reversing the direction of rotation of a run-in ribbed belt can destroy the belt. Loosen tensioning bolt - arrow - and remove ribbed belt.

1. Remove bolts - arrows -.
2. Remove tensioner for ribbed belt from upper part of oil pan.

Scheme 50

1. Disconnect electrical harness connector - 3 - at generator.
2. Remove terminal 30/B+ - 1 -.

Scheme 51

1. Remove bolts - 3 - and - 4 -.

Note. If generator is stuck in its bracket, screw in mounting bolts again except 2 rotations. Carefully strike on bolt heads using flat side of hammer - doing this loosens threaded sleeves of generator mount. Remove generator. Disconnect coolant hoses - 1 - and - 2 - at generator.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Secure all hose connections using hose clamps appropriate for the model type Parts Catalog Slightly drive back sleeves for retaining bolts in order for easier installation of generator.

Note. Tight sleeves for generator mount must be made smooth-running, otherwise clamping force of sleeve is too little despite correct torque.

1. Place ribbed belt - 2 - over belt pulleys in the specified sequence.

1 - Generator

3 - Relay pulley

4 - Harmonic balancer

5 - Tensioner roller

Note. When installing ribbed belt, be sure that it is seated correctly on belt pulleys. Install radiator --> 5.2 Liter 10-Cyl. 4V Engine Mechanical, Engine Code(s): BXA - 19 - ENGINE - COOLING SYSTEM . Connect battery. Required actions Battery, disconnecting and connecting . Fill with coolant --> 5.2 Liter 10-Cyl. 4V Engine Mechanical, Engine Code(s): BXA - 19 - ENGINE - COOLING SYSTEM . Start engine and check path of belt.

Tightening torques

Scheme 52

1 - Generator

2 - Voltage regulator

1. Removing and installing --> «Voltage regulator, removing and installing - Bosch generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__voltage-regulator-removing-and-installing)
2. Checking carbon brushes --> «Carbon brushes, checking - Bosch generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

3 - 2.5 Nm

4 - Cover

5 - Nut (12 Nm)

6 - Ribbed nut (30 Nm)

7 - 3 Nm

8 - 1.5 Nm

Voltage regulator, removing and installing - Bosch generator

Removing

1. Remove generator

1. 3.2l FSI engines --> «Vehicles with 3.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-32l-fsi-engines) .
2. 4.2l MPI engine --> «Vehicles with 4.2l MPI engine»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-42l-mpi-engine) .
3. 4.2l FSI engine --> «Vehicles with 4.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
4. 5.2l FSI engine --> «Vehicles with 5.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-52l-fsi-engines) .

Scheme 53

1. Remove bolt - 1 - and nuts - 3 - and - 4 -.
2. Remove cover - 2 - at rear side of generator.

Scheme 54

1. Remove bolts - arrows -.
2. Remove voltage regulator.

Installing

1. When installing the voltage regulator, make sure the carbon brushes rest properly on the slip rings.

Rest of installation is performed in the reverse order of removal. Tightening torques --> Bosch generator - component overview .

Scheme 55

Work procedure

1. Remove voltage regulator --> «Voltage regulator, removing and installing - Bosch generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__voltage-regulator-removing-and-installing) .
2. Check carbon brushes for length - a -.

1. Wear limit: - a - = 5 mm.

Scheme 56

1 - Generator

2 - Voltage regulator

1. Removing and installing --> «Voltage regulator, removing and installing - Valeo generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__voltage-regulator-removing-and-installing)
2. Checking carbon brushes --> «Carbon brushes, checking - Valeo generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

3 - Double bolt (2 Nm)

4 - Cover

5 - Protective cap

6 - Hex bolt, (2 Nm)

Voltage regulator, removing and installing - Valeo generator

Removing

1. Remove generator

1. 3.2l FSI engines --> «Vehicles with 3.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-32l-fsi-engines) .
2. 4.2l MPI engine --> «Vehicles with 4.2l MPI engine»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-42l-mpi-engine) .
3. 4.2l FSI engine --> «Vehicles with 4.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
4. 5.2l FSI engine --> «Vehicles with 5.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-52l-fsi-engines) .

Scheme 57

1. Press out cover from threaded pins at rear side of generator - arrows -.

Scheme 58

1. Remove bolts - 1 - and double bolt - 2 -.
2. Remove voltage regulator.

Scheme 59

Installing

1. Press off protective cap - 2 - from voltage regulator - 1 - in - direction of arrow -.
2. When installing the voltage regulator, make sure the carbon brushes rest properly on the slip rings.
3. Attach protective cap with voltage regulator installed.

Rest of installation is performed in the reverse order of removal.

Tightening torque

Scheme 60

Work procedure

1. Remove voltage regulator --> «Voltage regulator, removing and installing - Valeo generator»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__voltage-regulator-removing-and-installing) .
2. Check carbon brushes for length - a -.

1. Wear limit: - a - = 5 mm.

Ribbed belt pulley without overrunning clutch, removing and installing

Special tools, testers and auxiliary items required

Scheme 61

1. Socket 3310
2. Torx T 50 socket

Removing

1. Remove generator

1. 3.2l FSI engines --> «Vehicles with 3.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-32l-fsi-engines) .
2. 4.2l MPI engine --> «Vehicles with 4.2l MPI engine»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-42l-mpi-engine) .
3. 4.2l FSI engine --> «Vehicles with 4.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
4. 5.2l FSI engine --> «Vehicles with 5.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-52l-fsi-engines) .

Scheme 62

1. Press off protective cap from generator pulley.
2. Counterhold mounting nut using socket 3310 and rotate generator shaft clockwise to loosen it.
3. Remove ribbed belt pulley.

Installing

Installation is performed in reverse order of removal, noting the following

1. To tighten, rotate generator shaft clockwise.
2. Clip protective cap onto generator pulley.

Tightening torque

Ribbed belt pulley with overrunning clutch, removing and installing

Special tools, testers and auxiliary items required

Scheme 63

1. Multi-point adapter 3400
2. Torx T 50 socket

Removing

1. Remove generator

1. 3.2l FSI engines --> «Vehicles with 3.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-32l-fsi-engines) .
2. 4.2l MPI engine --> «Vehicles with 4.2l MPI engine»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-42l-mpi-engine) .
3. 4.2l FSI engine --> «Vehicles with 4.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
4. 5.2l FSI engine --> «Vehicles with 5.2l FSI engines»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__vehicles-with-52l-fsi-engines) .

Scheme 64

1. Press off protective cap from generator pulley.
2. Counterhold pulley using multi-tooth adapter 3400 and rotate generator shaft clockwise to loosen it.

Installing

Installation is performed in reverse order of removal, noting the following

1. To tighten, rotate generator shaft clockwise.
2. Clip protective cap onto generator pulley.

Tightening torque

Vehicles with 3.2l FSI engines

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove right front wheel.

Note. Secure brake disc using a wheel bolt. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 65

1. Remove heat shield - arrow - for right drive axle.

Scheme 66

1. Disconnect electrical wires - 3 - and - 4 - on starter.
2. Remove bolts - 1 - and - 2 - and remove starter.

Note. For clarity, the figure depicts engine support as removed.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Replace self-locking nuts. Connect battery. Required actions Battery, disconnecting and connecting .

Tightening torques

Scheme 67

Special tools, testers and auxiliary items required

1. Engine support bridge 10 - 222 A
2. Shackle 10 - 222 A /12
3. Insert pad for front fender T40045

Scheme 68

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove rear engine cover - arrows -.

1. Disconnect vacuum line - 2 -.
2. Disconnect electrical harness connector - 1 - at Mass Air Flow (MAF) Sensor G70.
3. Remove air guide hose, release hose clamp - 3 - and open clips - arrows - to do so.

Scheme 69

1. Secure shackle 10 - 222 A /12 to right rear engine lifting eyelet.

Note. Disregard - 1 -.

Scheme 70

1. Pull off sealing rubber at bolted flanges of fender.
2. To avoid damage to the fender edges when using engine support bridge, insert pad for front fender T40045 on both sides between fender bolt edge and web plate lying beneath - arrows -.

Scheme 71

1. Install engine support bridge 10 - 222 A onto fender bolting edge. Spindle must point toward front.
2. Hook shackle 10 - 222 A /12 into spindle of engine support bridge 10 - 222 A.
3. Carefully attach spindle of engine support bridge.

1. Remove right front wheel.

Note. Secure brake disc using a wheel bolt. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 72

1. Remove heat shield - 1 - for right drive axle.

Scheme 73

1. Remove bolts - 1 - and - 2 - at stabilizer mounts.

Scheme 74

1. Remove nut - 3 -.
2. Remove bolts - 1 - and - 2 - and remove right engine console.

Scheme 75

1. Disconnect electrical harness connector - 1 -.
2. Remove bolts - arrows -.
3. Remove right engine support with engine mount.

Scheme 76

1. Unscrew Ground (GND) wire - 1 -.
2. Disconnect electrical wires - 3 - and - 4 -.
3. Unscrew bolts - 2 - and - 5 - and remove starter.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install engine console and tighten subframe --> «40 - FRONT SUSPENSION»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering)
2. Install stabilizer --> «40 - FRONT SUSPENSION»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .
3. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Tightening torques

Scheme 77

Special tools, testers and auxiliary items required

1. Engine support bridge 10 - 222 A
2. Adapter 10 - 222 A /22
3. Engine Support Basic Set T40091
4. Engine Support Supplement Set T40093

Scheme 78

Removing

Note. All cable ties opened or cut during engine removal must be reinstalled at the same locations during installation. With ignition switched off, disconnect battery Ground (GND) wire --> Battery, disconnecting and connecting . Remove rear engine cover - arrows -.

Scheme 79

1. Remove rubber seal - 1 - and remove plenum chamber cover - 2 -.

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

Scheme 80

1. Lay aside fuel line and line to EVAP canister at air filter housing and air guide pipe.
2. Disconnect electrical harness connector - 1 - at Mass Air Flow (MAF) Sensor G70.
3. Remove air guide pipe from air filter housing, release hose clamp - 5 - and open clips - arrows - to do so.

Note. Disregard - 2, 3 and 4 -.

1. Open clips - arrows - and remove upper air filter housing.

Scheme 81

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear from Exhaust Gas Recirculation (EGR) Cooler Switch-Over Valve N345.
4. Remove air guide hose - 3 - for Secondary Air Injection (AIR) pump, press release buttons to do so.

Scheme 82

1. Secure adapter 10 - 222 A /4 using binder T40091/3 as well as supports T40093/1 and T40093/2 at suspension strut domes.

1. Supports T40093/1 are marked for left and right sides of vehicle.

Scheme 83

1. Assemble other components of engine support bridge 10 - 222 A as depicted in illustration. Set supports T40093/3 on to seams of longitudinal members.
2. Engage hook 10 - 222 A /10 in engine lifting eye.
3. Pre-tension engine slightly using spindles of engine support bridge 10 - 222 A.

1. Remove right front wheel.
2. Remove noise insulations, loosen mounting parts - 1, 2, arrow - to do so.

1. Remove bolts - 1 - and - 2 - for left and right stabilizer mounts.

1. Expose electrical wires at engine mount console.
2. Remove nut - 3 -.
3. Remove bolts - 1 - and - 2 - and remove right engine mount console.

Scheme 84

1. Disconnect electrical harness connector - 1 - at right engine mount.
2. Remove bolts - arrows -.
3. Remove right engine support with engine mount.

Scheme 85

1. Remove bolts - arrows -.
2. Remove heat shields - 1 - and - 2 -.

Note. B+ wire can only be removed after disconnecting electrical harness connector of terminal 50. Unscrew Ground (GND) wire - 1 -. Disconnect electrical wires - 3 - and - 4 -. Unscrew bolts - 2 - and - 5 - and remove starter.

Installing

Installation is performed in reverse order of removal, noting the following

Note. During installation, re-install all cable ties at the same locations. Install right engine mount console --> 40 - FRONT SUSPENSION . Install stabilizer --> 40 - FRONT SUSPENSION . Connect battery. Required actions Battery, disconnecting and connecting .

Tightening torques

Scheme 86

Removing

1. Remove engine --> «10 - ENGINE - ASSEMBLY»(ref-281368-S01918271852008031100000) .
2. Leave engine with transmission installed on the scissor lift platform VAS 6131.
3. Twist spindles of support elements left and right at subframe completely downward.
4. Remove both base plates of attachments for subframe from scissor lift table VAS 6131.

1. Remove attachments.
2. Remove subframe to the side.

Scheme 87

1. Remove bolts - arrows - from After-Run Coolant Pump V51.

Note. The coolant hoses and electrical harness connectors remain connected.

Scheme 88

1. Disconnect electrical harness connector - arrow - at right engine mount.
2. Remove bolts - 1 3 -.
3. Remove engine support with engine mount.

Scheme 89

1. Remove ground (GND) wire - 4 - from starter.
2. Disconnect electrical wires - 2 - and - 3 - from starter.
3. Unscrew bolts - 1 - and - 5 - and remove starter.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install engine --> «10 - ENGINE - ASSEMBLY»(ref-281368-S01918271852008031100000) .

Tightening torques

Instrument cluster

Note. All control lamps in instrument cluster are equipped with LEDs. In case an indicator lamp is malfunctioning, the instrument cluster must be replaced.

Instrument cluster removing and installing

Special tools, testers and auxiliary items required

Scheme 90

1. Trim removal wedge 3409

Scheme 91

1. 2x Hook 3438

Removing

Note. Do not disassemble instrument cluster. If the instrument cluster is replaced with Instrument Cluster Control Module J285 , select "Replace" function of J285 in "Guided Functions". Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this. Switch ignition off and remove ignition key.

Scheme 92

1. Carefully release spring pins - 2 - of decorative panel from instrument panel using trim removal wedge 3409.

Note. The instrument panel vent provides a hole on both sides to engage the hook 3438. Carefully remove the instrument panel at both sides from installation opening using the hook 3438.

If the instrument panel vent cannot be pulled out that way, proceed as follows

1. Position lamellae of instrument panel vent horizontally.
2. Release all clips - arrow - by inserting clockmaker screwdrivers - 1 - and - 3 -.
3. Remove instrument panel vent on both sides out of installation opening using hook 3438 , the clockmaker screwdrivers must remain inserted when doing so.
4. Disconnect electrical harness connectors at instrument panel vent and rotary knob for headlamp range control where present.

Scheme 93

1. Carefully release spring pins - 1 - of decorative panel from instrument panel using trim removal wedge 3409.

Note. The instrument panel vent provides a hole on both sides to engage the hook 3438. Carefully remove the instrument panel at both sides from installation opening using the hook 3438.

If the instrument panel vent cannot be pulled out that way, proceed as follows

1. Position lamellae of instrument panel vent horizontally.
2. Release all clips - arrow - by inserting clockmaker screwdrivers - 2 - and - 3 -.
3. Remove instrument panel vent on both sides out of installation opening using hook 3438 , the clockmaker screwdrivers must remain inserted when doing so.
4. Disconnect electrical harness connectors.

Scheme 94

1. Pry off left cover from instrument panel using a screwdriver - arrow -.

Scheme 95

1. Turn light switch - 3 - to "0" position.
2. Remove spreader pin - 2 - at air guide - 1 - and remove air guide.
3. Reach through opening above instrument panel vent from the side and press light switch out of instrument cluster - arrow -.
4. Disconnect electrical harness connector.

Scheme 96

1. Press cover strip - 1 - at button unit for instrument cluster in - direction of arrow -.
2. Remove cover strip and pull off switch.

Scheme 97

1. Attach hook 3438 in opening - arrow - at button unit.
2. Carefully remove buttons - 1 - from instrument cluster lining.
3. Disconnect electrical harness connector.

Scheme 98

1. Press cover strip - 1 - at button for glove compartment release in - direction of arrow -.
2. Remove cover strip and pull off switch.

Scheme 99

1. Attach hook 3438 in opening - arrow - at button unit.
2. Carefully remove buttons - 1 - from instrument cluster lining.
3. Disconnect electrical harness connector.

Scheme 100

Note. For clarity, the work steps shown in the following illustrations are depicted with steering wheel removed. Release gap cover - 1 - at upper steering column trim - 2 - using a small screwdriver - arrows A and B -.

Scheme 101

1. Remove bolts - arrows -.

Scheme 102

1. Remove bolts - arrows -.
2. Pull instrument cluster lining a bit out of instrument panel.

Scheme 103

1. Disconnect electrical harness connector on instrument cluster, to do so, press catch - 1 - , rotate retainer in - direction of arrow - and disconnect connector.

Scheme 104

1. Release connector lock - 1 - on MMI display - arrow - and swivel upward.
2. Disconnect electrical harness connector - 2 - on MMI display.
3. Remove instrument cluster lining with instrument cluster and MMI display between steering wheel and instrument panel.

Installing

Installation is performed in the reverse order of removal.

Tightening torque

Scheme 105

Gray 32-pin multi-pin connector

1. Not assigned
2. Not assigned
3. CAN Bus Low (to Data Bus On Board Diagnostic Interface J533 )
4. CAN Bus High (to Data Bus On Board Diagnostic Interface J533 )
5. Terminal 31, sensor Ground (GND)
6. Sender for fuel gauge G
7. Fuel Level Sensor 2 G169
8. Button module
9. Outside temperature
10. Not assigned
11. Not assigned
12. Lack of coolant
13. Low washer fluid level
14. Terminal 31
15. Terminal 30
16. Terminal 58s
17. Terminal 58d
18. Oil pressure switch
19. Low brake fluid level
20. Check
21. Not assigned
22. EPB (electro-mechanical parking brake)
23. Radio controlled clock 5 V
24. Radio controlled clock signal
25. Oil level
26. Brake pad
27. External buzzer
28. Wake-up line (to Data Bus On Board Diagnostic Interface J533 )
29. Terminal 31
30. Terminal 31
31. Terminal 30
32. Terminal 30

Fuel level sensors connector assignment

Preparation

1. Disconnect 5-pin electrical harness connector at connector flange or fuel tank; procedure --> «20 - FUEL SUPPLY SYSTEM»(/audi/a6/6-2004-2008/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-codes-bkh) for 3.2 LITER V6 4V GENERIC SCAN TOOL, ENGINE CODE(S): BKH «20 - FUEL SUPPLY»(ref-281373-S42835762992008031100000) for 4.2 LITER V8 4V GENERIC SCAN TOOL, ENGINE CODE(S): BVJ 20 FUEL SUPPLY for 4.2 LITER V8 5V GENERIC SCAN TOOL, ENGINE CODE(S): BNK «20 - FUEL SUPPLY»(ref-281371-S33024851562008031100000) for 5.2 LITER 10-CYL. 4V GENERIC SCAN TOOL, ENGINE CODE(S): BXA .

Scheme 106

Terminal assignment of the 5-pin harness connector at Fuel Level Sensor -G- G - vehicles with front wheel drive

1. B+ activation of electrical fuel pump
2. Wire connection from Fuel Level Sensor -G- G to instrument cluster (fuel gauge)
3. Ground (GND) for fuel level sensor (sensor ground)
4. Not assigned
5. Ground (GND) for electrical fuel pump

Terminal assignment of the 5-pin harness connector at Fuel Level Sensor -G- G and Fuel Level Sensor 2 G169 - vehicles with all-wheel drive

1. B+ activation of electrical fuel pump
2. Wire connection from Fuel Level Sensor -G- G to instrument cluster (fuel gauge)
3. Ground (GND) for fuel level sensor (sensor ground)
4. Wire connection from Fuel Level Sensor 2 G169 to instrument cluster (fuel gauge)
5. Ground (GND) for electrical fuel pump

Engine Coolant Temperature (ECT) Sensor G62 Connector assignment

Special tools, testers and auxiliary items required

Scheme 107

1. Assembly tool T10118

Preparation

1. Disconnect electrical harness connector at Engine Coolant Temperature (ECT) Sensor G62 ; procedure

1. Vehicles with 3.2l FSI engines.
2. Vehicles with 4.2l MPI engine.
3. Vehicles with 4.2l FSI engine.
4. Vehicles with 5.2l FSI engine.

Scheme 108

Terminal assignment of the 2-pin harness connector at Engine Coolant Temperature (ECT) Sensor G62

1. Sensor ground (GND)
2. Wire connection from Engine Coolant Temperature (ECT) Sensor G62 to engine control module

Electrical harness connector at Engine Coolant Temperature (ECT) Sensor G62 , disconnecting - vehicles with 3.2l FSI engines

Work procedure

1. Remove engine cover at front - arrows -.

Scheme 109

1. Disconnect electrical harness connector - 2 - at Engine Coolant Temperature (ECT) Sensor G62.

Note. Disregard - 1 -.

Installation is performed in the reverse order of removal.

Electrical harness connector at Engine Coolant Temperature (ECT) Sensor G62 , disconnecting - vehicles with 4.2l MPI engines

Work procedure

1. Remove rear engine cover - arrows -.

Scheme 110

1. Disconnect electrical harness connector - 1 - at Engine Coolant Temperature (ECT) Sensor G62 using assembly tool T10118.

Note. For clarity, depicted without engine. Disregard - 2 -.

Installation is performed in the reverse order of removal.

Electrical harness connector at Engine Coolant Temperature (ECT) Sensor G62 , disconnecting - vehicles with 4.2l FSI engine

Work procedure

1. Remove rear engine cover - arrows -.

1. Lay aside fuel line and line to EVAP canister at air guide pipe.
2. Remove air guide hose from air filter housing, loosen hose clamp - 4 and 5 - to do so.
3. Lay aside air guide hose with wires - 2 and 3 - connected.

Note. Disregard - 1 and arrows -.

Scheme 111

1. Disconnect electrical harness connector - arrow - at Engine Coolant Temperature (ECT) Sensor G62.

Note. For clarity, depicted without engine.

Installation is performed in the reverse order of removal.

Scheme 112

Work procedure

1. Remove engine cover at front - 1 - and at rear - 2 - - arrows -.

Scheme 113

1. Remove left air guide hose - arrows -.

Scheme 114

1. Remove right air guide hose - arrows -.

Scheme 115

1. Disconnect vacuum hose - 1 - from intake manifold.
2. Unscrew bolts - arrows - and remove air guide.

Scheme 116

1. Disconnect electrical harness connector - 1 - at Engine Coolant Temperature (ECT) Sensor G62.

Note. Disregard - 2 - and - 3 -.

Installation is performed in the reverse order of removal.

Scheme 117

Removing

1. Remove rear bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
2. Remove bolts - arrows -.
3. Remove Radio Frequency Controlled Clock Receiver J489 - 1 - from rear bumper cover.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install rear bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Tightening torque

Scheme 118

Removing

1. Remove rear bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
2. Remove bolts - arrows -.
3. Remove Radio Frequency Controlled Clock Receiver J489 - 1 - from rear bumper cover.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install rear bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Tightening torque

Scheme 119

Removing

1. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
2. Remove bolt - 3 - and remove retaining bracket - 4 -.
3. Remove Garage Door Opener Control Module - 2 - out of bumper cover.
4. Disconnect electrical harness connector - 1 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Tightening torque

Diagnostic interface for CAN-bus J533

General description

Data Bus On Board Diagnostic Interface J533 interlinks the different CAN bus systems in the vehicle.

It transmits data from e.g. the engine control module (drivetrain CAN bus) to the instrument cluster (instrument cluster CAN bus).

Fault finding is performed via "Guided Fault Finding".

Scheme 120

1 - Control module with indicator unit in instrument panel insert J285

1. In instrument cluster

2 - Steering Column Electronic Systems Control Module J527

1. On steering column

3 - Multi-function steering wheel

4 - Front Information Display Control Head J685

1. In instrument panel, center

5 - Multimedia Control Head E380

1. In center console, center

6 - Navigation System Antenna R50

1. With navigation system on MMI Basic Plus
2. Behind rear center roof end trim

7 - Sound systems

8 - Rear window antennas

9 - Antenna amplifier R24

1. Behind left roof end trim

10 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

11 - Diagnostic interface for CAN-bus J533

1. Gateway
2. Behind glove compartment

12 - Media player in position 2 R119

1. In glove compartment

13 - Telephone Transceiver R36

1. Beneath floor carpet in drivers footwell

14 - Digital Sound System Control Module J525

1. With MMI Basic Plus
2. In luggage compartment, left side, behind side trim

15 - Digital radio (DAB) R147

1. In luggage compartment, left side, behind side trim

Scheme 121

1 - Front Information Display Control Head J685

1. In instrument panel, center

2 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

3 - Control module with indicator unit in instrument panel insert J285

1. In instrument cluster

4 - Diagnostic interface for CAN-bus J533

1. Gateway
2. Behind glove compartment

5 - Radio R

1. With Speech Input Control Module J507 , depending on equipment
2. In luggage compartment, left side, behind side trim

6 - Digital radio (DAB) R147

1. In luggage compartment, left side, behind side trim

7 - TV Tuner R78

1. In luggage compartment, left side, behind side trim

8 - Navigation System with CD Drive Control Module J401

1. In luggage compartment, left side, behind side trim

9 - Digital Sound System Control Module J525

1. In luggage compartment, left side, behind side trim

10 - Telephone Transceiver R36

1. Beneath floor carpet in drivers footwell

11 - Multi-function steering wheel

12 - Media player in position 1 R118

1. In glove compartment

13 - Media player in position 2 R119

1. In glove compartment

14 - Steering Column Electronic Systems Control Module J527

1. On steering column

15 - Multimedia Control Head E380

1. In center console, center

Data Bus On Board Diagnostic Interface J533 , removing and installing

Special tools, testers and auxiliary items required

Scheme 122

1. Protective Cap For Cable Connector VAS 6223/9 from Fiber Optic Plier Repair Set VAS 6223

Removing

1. If control module is replaced, select "Guided Functions" of respective control module in.
2. Switch ignition off and remove ignition key.
3. Remove glove compartment --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 123

1. Remove bolts - arrows - and remove Data Bus On Board Diagnostic Interface J533 - 1 -.
2. Disconnect electrical harness connector - 2 -.
3. Disconnect harness connector - 3 - for fiber-optic cable.

Scheme 124

1. Seal open harness connector - 2 - for fiber-optic cable using Protective Cap For Cable Connector VAS 6223/9 - 1 -.

Note. The protective cap prevents soiling or mechanical damage on contact surface of fiber-optic cable, which would otherwise impair signal transmission.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install glove compartment --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Tightening torque

Scheme 125

Connection optical MOST bus (fiber-optic cable) - 1

1. Input
2. Output

26-pin harness connector - 2

1. Battery + (terminal 30)
2. Battery + (terminal 30)
3. Instrument cluster wake up
4. Ring-break diagnostic wire
5. Not assigned
6. CAN bus High (Comfort)
7. Not assigned
8. CAN bus High (drivetrain)
9. CAN bus High (instrument cluster)
10. Not assigned
11. CAN bus High (diagnosis)
12. Not assigned
13. CAN Bus High (to Distance Regulation Control Module J428 )
14. Ground (GND) (terminal 31)
15. Ground (GND) (terminal 31)
16. Terminal 15
17. Not assigned
18. Not assigned
19. CAN bus Low (Comfort)
20. Not assigned
21. CAN bus Low (drivetrain)
22. CAN bus Low (instrument cluster)
23. Not assigned
24. CAN bus Low (diagnosis)
25. Not assigned
26. CAN Bus Low (to Distance Regulation Control Module J428 )

Scheme 126

Removing

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted. With the engine running, bring the windshield wipers to "service position" Operating instructions. Switch off ignition. Lift off wiper arm from front windshield. Compress clip - arrows 1 -. Push wiper blade off wiper arm - arrow 2 -. Remove wiper blade.

Scheme 127

Installing

Installation is performed in reverse order of removal, noting the following

1. Hold wiper blade - 2 - parallel and slide onto wiper arm - 1 - - arrow -. Make sure wiper arm rest completely in guide.
2. Switch ignition on and operate "wipe once" , thus the wipers leave the "service position".

Wiper arms, removing and installing

Removing

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted. Switch the ignition on. Operate "wipe once" and let wiper arms run to end position. Switch ignition off and remove ignition key.

Scheme 128

1. Pry off cover caps on wiper arms using a screwdriver.
2. Loosen nuts - arrows - several rotations.
3. Loosen wiper arms successively by tilting slightly from the wiper arm axle.
4. Remove nuts completely and remove wiper arms.

Note. If the wiper arm cannot be pulled off in this way, use a commercially available puller.

Installing

Installation is performed in reverse order of removal, noting the following

1. Adjust wiper arms --> «Wiper arms, adjusting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__wiper-arms-adjusting) .

Wiper arms, adjusting

Work procedure

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted. Remove wiper arms --> Wiper arms, removing and installing . Switch the ignition on. Operate "wipe once" and let wiper motor run in end position.

Note. Every second time the wiper motor is switched off, it returns the wiper arms to a slightly lower rest position, thus tipping the wiper blade lips the other way. To do so, the wiper motor moves the wiper arms farther down than to rest position and then a bit up again. This lower rest position must not be used to adjust the wiper crank. Only use rest position where wiper arms are rested directly in normal end position. Operate "wipe once" again if necessary. Switch off ignition.

Scheme 129

1. Position wiper arm with wiper blade installed at wiper axles and align wiper blade at windshield as follows

1. Dimension - a - = 10 15 mm.
2. Dimension - b - = 30 40 mm.

Note. The dimensions indicate the gap between the wiper blade tips to black cowl grille at lower edge of windshield. Tighten wiper arm nuts. Switch the ignition on. Operate "wipe once" and let wiper arms run to end position. Switch off ignition. Check adjustment of wiper arms again, correct if necessary.

Tightening torque

Windshield wiper motor with Wiper Motor Control Module J400 , removing and installing

Note. The Wiper Motor Control Module J400 is integrated in the windshield wiper motor.

Removing

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted. If the windshield wiper motor is replaced with Wiper Motor Control Module J400 , select "Path 09 - Electronic central electric / J400 Wiper Motor Control Module, functions / J400 - Replacing" in "Guided Functions".

1. Remove rubber seal - 1 -.
2. Remove plenum chamber cover - 2 -.
3. Remove wiper arms --> «Wiper arms, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__wiper-arms-removing-and-installing) .

Scheme 130

1. Remove bolts - arrows - for cowl grille - 1 - at left and right.
2. Carefully pull cowl grille off locking mechanism on windshield.

Scheme 131

1. Remove bolts - arrows -.
2. Remove E-Box cover in left plenum chamber.

Scheme 132

1. Remove bolts - arrows - and remove wiper frame completely.
2. Disconnect electrical harness connector - 1 -.

Scheme 133

1. Pry off wiper linkage - 1 - from ball head - arrow -.

Scheme 134

1. Remove nut - 2 - and remove crank - 1 - from wiper motor.
2. Remove wiper motor from wiper frame - arrows -.

Scheme 135

Installing

Installation is performed in reverse order of removal, noting the following

1. Bolt wiper motor without crank on to wiper frame - arrows -.
2. Connect electrical harness connector.
3. Switch the ignition on.
4. Perform next program step in "Guided Functions".

Note. The "Replace" function in "Guided Functions" e.g. switches off the alternating park position of the wiper motor. The wiper motor then runs always to the "lower" park position which is the one for adjustment. Operate "wipe once" and let wiper motor run in end position. Switch ignition off and remove ignition key.

Scheme 136

1. Align crank - 1 - toward wiper frame.

1. Dimension - a - = 10.6 ± 0.6 mm.

1. Keep crank in position and hand-tighten nut - 2 - in order to maintain this position.
2. Then, hold crank in position using an open-end wrench and tighten nut.
3. Switch the ignition on.
4. Operate "wipe once" and let wiper motor run in end position.

1. Check if dimension - a - is reached; align again if necessary.
2. Switch ignition off and remove ignition key.
3. Install wiper motor with wiper frame in vehicle, observe the following tightening sequence to do so
4. Hand-tighten center bolt.

1. Tighten outer bolts, then tighten center bolt at wiper frame.

The rest of the installation is performed in reverse order of removal, noting the following

1. Adjust wiper arms --> «Wiper arms, adjusting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__wiper-arms-adjusting) .

Tightening torques

Scheme 137

Removing

1. Remove E-Box in left plenum chamber --> «E-Box in left plenum chamber, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__e-box-in-left-plenum-chamber-removing) .
2. Remove nuts - 3 - and - 4 - from filler neck - 2 -.
3. Pull sealing grommet - 1 - out of body cut-out.
4. Rotate filler hose for filler neck counter-clockwise - arrow A -.

1. Pull filler hose for filler neck out of washer fluid reservoir - arrow B -.

Scheme 138

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert filler hose - 1 - for filler neck into washer fluid reservoir - 4 - - arrow 1 -.
2. Rotate filler hose for filler neck clockwise - arrow 2 -.

Note. Make sure O-ring - 3 - is not crimped when inserted. Press sealing grommet - 2 - into body opening. Install E-Box in left plenum chamber.

Tightening torque

Washer fluid reservoir, removing and installing

Removing

Note. All cable ties opened or cut during engine removal must be reinstalled at the same locations during installation. Remove rubber seal - 1 -. Remove plenum chamber cover - 2 -. Remove wiper arms --> Wiper arms, removing and installing .

1. Remove bolts - arrows - for cowl grille - 1 - at left and right.
2. Carefully pull cowl grille off locking mechanism on windshield.

1. Remove bolts - arrows -.
2. Remove E-Box cover in left plenum chamber.

1. Remove nuts - 3 - and - 4 - from filler neck - 2 -.
2. Pull sealing grommet - 1 - out of body opening.
3. Rotate filler hose for filler neck counter-clockwise - arrow A -.
4. Pull filler hose for filler neck out of washer fluid reservoir - arrow B -.

Scheme 139

1. Remove left front wheel.

Note. Secure brake disc using a wheel bolt. Remove left front wheel housing liner --> 66 - EXTERIOR EQUIPMENT . Disconnect electrical harness connectors - 2 - , - 3 - and - 4 -. Disconnect hose coupling - 1 - by pressing release button. Remove washer fluid line - 5 - at washer fluid pump. Remove nuts and bolts - arrows -. Unhook washer fluid reservoir at threaded pin. Remove washer fluid reservoir downward.

Installing

Installation is performed in reverse order of removal, noting the following

Note. During installation, re-install all cable ties at the same locations. Install washer fluid reservoir and hand-tighten nuts. Insert filler hose - 1 - for filler neck into washer fluid reservoir - 4 - - arrow 1 -. Rotate filler hose for filler neck clockwise - arrow 2 -.

Note. Make sure O-ring - 3 - is not crimped when inserted. Press sealing grommet - 2 - into body opening. Tighten bolt and nuts at washer fluid reservoir. When attaching water hose, make sure it engages audibly in connection of washer fluid pump. Install left front wheel house liner --> 66 - EXTERIOR EQUIPMENT . Adjust wiper arms --> Wiper arms, adjusting .

Tightening torques

Scheme 140

Removing

1. Unclip washer nozzles from bottom of hood - arrow -.

Scheme 141

1. Disconnect washer fluid line - 1 - from unclipped nozzle.
2. Disconnect electrical harness connector - 2 -.

Scheme 142

Installing

Installation is performed in reverse order of removal, noting the following

1. When attaching water hose, make sure it engages audibly in connection of nozzle.
2. Insert nozzle in hood.

1. Oval opening - arrow - for single nozzle must point toward outside of vehicle.

Adjusting spray nozzles

Special tools, testers and auxiliary items required

Scheme 143

1. Windshield Washer Aiming Tool T10127 equipped with needle 3125/5 A

Scheme 144

Setting

Note. The adjustment dimensions indicate the required values for the driving vehicle, i.e. when standing still, the spray nozzles spray in a slightly offset manner. Mark the four points on the windshield using a water soluble marker: Dimension - a - = 255 mm. Dimension - b - = 510 mm. Dimension - c - = 530 mm. Dimension - d - = 430 mm. Locate points from every single nozzle using Windshield Washer Aiming Tool T10127. If the spray area does not correspond to the specifications, the nozzle is contaminated and must be cleaned.

Cleaning the nozzle

1. Remove nozzle --> «Washer nozzles, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
2. Flush nozzle opposite to spray direction using clear water.
3. To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.

If the spray area still does not correspond to the specifications

1. Replace nozzle.

Scheme 145

1 - Connecting pipe

1. For nozzle

2 - Nut (12 Nm)

3 - Spray nozzles

1. Removing and installing --> «Nozzle, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)
2. Adjusting --> «Adjusting spray nozzle»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__adjusting-spray-nozzle)

4 - Cap for rear windshield wiper

5 - Wiper arm

1. Removing and installing --> «Wiper arm, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__wiper-arm-removing-and-installing)

6 - Wiper blade

1. Replace --> «Rear window wiper blades, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

Scheme 146

Removing

1. Lift off wiper arm from front rear window.
2. Release clips - arrows - using a screwdriver and pull wiper blade - 2 - out of wiper arm - 1 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. The wiper blade can only be installed in one position.
2. Wiper blade must audibly engage in wiper arm.

Scheme 147

Removing

1. Carefully expand ends of caps - 3 - and lift off from wiper arm - 1 -.
2. Carefully remove nozzle - 2 - from connecting pipe.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert nozzle so that spray opening faces opening at wiper arm.

Adjusting spray nozzle

Special tools, testers and auxiliary items required

1. Windshield Washer Aiming Tool T10127 equipped with needle 3125/5 A

Scheme 148

Work procedure

1. Adjust nozzles using Windshield Washer Aiming Tool T10127 so that the water jets are sprayed onto the rear window above the wipers at the points shown.

1. Dimension - a - = approx. 122 mm.
2. Dimension - b - = approx. 330 mm.
3. Dimension - c - = approx. 5 mm.

Wiper arm, removing and installing

Removing

1. Switch the ignition on.
2. Activate "rear wipe" and let wiper arm run to end position.
3. Switch ignition off and remove ignition key.

Scheme 149

1. Carefully expand cap - arrows - and remove.

Scheme 150

1. Carefully pull off nozzle - 2 -.
2. Loosen nut - 1 - several rotations.
3. Loosen wiper arm by tilting slightly from the wiper axle.
4. Remove nuts completely and remove wiper arm.

Installing

Installation is performed in reverse order of removal, noting the following

1. Adjust wiper arm --> «Wiper arm, adjusting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Scheme 151

Work procedure

1. Position wiper arm with wiper blade installed at wiper axle and align wiper blade at rear window as follows

1. Dimension - a - = 27 mm.

Note. Dimension is the gap between tip of wiper blade and lower edge of window. Switch the ignition on. Activate "rear wipe" and let wiper arm run to end position. Check adjustment of wiper arm again, correct if necessary.

Tightening torque

Scheme 152

1 - Nut (8 Nm)

2 - Windshield Wiper Motor

1. Removing and installing --> «Removing and installing rear wiper motor»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__removing-and-installing-rear-wiper-motor)

3 - Sealing rubber

4 - Washer fluid hose

Removing and installing rear wiper motor

Removing

1. Remove wiper arm --> «Wiper arm, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__wiper-arm-removing-and-installing) .
2. Remove lower rear lid trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 153

1. Disconnect electrical harness connector - 2 -.
2. Disconnect washer fluid hose - 1 - from connecting pipe of nozzle.
3. Unscrew nuts - arrows - and remove wiper motor.

Installing

Installation is performed in reverse order of removal, noting the following

1. Carefully attach rubber seal in rear window bore.

1. Washer fluid hose must engage audibly into nozzle connection.

1. Switch the ignition on.
2. Activate "rear wipe" and let wiper motor run in end position.
3. Switch off ignition.
4. Install lower rear lid trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

1. Adjust wiper arm --> «Wiper arm, adjusting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Note. The combined washer fluid reservoir for front and rear window washer system is located in engine compartment, left front. Removing and installing --> Washer fluid reservoir, removing and installing .

Spray jets for headlight cleaning system, removing and installing

Special tools, testers and auxiliary items required

Scheme 154

1. Hose clamp pliers V.A.G 1275

Scheme 155

Removing

1. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Note. Protect bumper cover by laying rag underneath and secure nozzle using pliers. At bumper cover, pull cap - 1 - of nozzles upward and carefully unhook securing tabs - arrows 1 -. Swivel cover downward - arrow 2 - and carefully disengage brackets - 2 - and - 3 -.

Scheme 156

1. Disconnect water hose - 1 - from nozzle - 3 -.
2. Unscrew bolts - 2 - and - 4 - and remove nozzle.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Secure all hose connections using hose clamps appropriate for the model type Parts Catalog Install hose clamp using hose clamp pliers V.A.G 1275. Install front bumper cover --> 63 - BUMPERS .

Tightening torque

Adjusting spray jets

Note. Nozzles are supplied preadjusted by the manufacturer and must not be adjusted after installation.

Note. The combined washer fluid reservoir for window washer system and headlamp cleaning system is located between A-pillar and left fender. Removing and installing --> Washer fluid reservoir, removing and installing .

Halogen headlamps, servicing - USA and Canada

Note. If measures are taken which could affect headlamp setting, headlamps are to be re-adjusted.

Scheme 157

1 - Headlamp housing

1. Removing and installing after replacing components at front end --> «Headlamp, removing and installing after replacing components at front end»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__headlamp-removing-and-installing-after-replacing)
2. Removing and installing when reusing current headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__headlamp-removing-and-installing-when-reusing)

2 - Bulb for high beam

1. H1 - 12 V, 55 W
2. W5W, Longlife - white
3. Changing bulb --> «Bulb for high beam, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__bulb-for-high-beam-replacing)

3 - Housing cover

4 - Bulb for low beam

1. H1 - 12 V, 55 W
2. W5W, Longlife - white
3. Changing bulb --> «Low beam bulb, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__low-beam-bulb-replacing)

5 - Lamp holder

1. For light bulb for turn signal

6 - Bulb for turn signal

1. 12 V, 28/7 W
2. Orange
3. Changing bulb --> «Light bulb for turn signal, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

7 - Adjustment nut

1. For adjustment of headlamp to bumper contour

8 - 8 Nm

Headlamp, removing and installing after replacing components at front end

Special tools, testers and auxiliary items required

Scheme 158

1. Adjusting gauge 3371

Scheme 159

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
4. Remove bolts - 1 through 3 -.

1. Remove headlamp toward front.
2. Disconnect electrical harness connector.

Scheme 160

Installing

1. Check adjustment nut - 1 - of adjusting element for smooth running - arrows -.
2. Turn adjustment nut completely downward, but do not tighten.

1. Install headlamp and turn bolts - 1 through 3 - 2 rotations each.

Scheme 161

1. Bring front bumper cover to installation position (do not bolt on).
2. Align dimensions - a through c - of headlamp - 1 - opposite to bumper cover - 2 - and fender - 3 - using adjustment gauge 3371.

1. Dimension - a - = 2.3 mm
2. Dimension - b - = 2 mm
3. Dimension - c - = 1.2 mm.
4. Headlamp must be flush toward outer edge of fender.

1. Lower edge of headlamp must be parallel to upper edge of bumper.

Note. When tightening the bolts, the adjustment nut of the adjusting element turns automatically towards the location point of the headlamp housing and locates it. Tighten bolt - 1 - - do not press bolt when tightening so that adjustment bolt of adjusting element can turn freely. Remove front bumper cover. Tighten bolts - 2 - and - 3 - , align headlamp flush to outer edge of fender while doing so. Install front bumper cover --> 63 - BUMPERS . Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above. Adjust headlamps after installing 405.

Tightening torques

Headlamp, removing and installing when reusing current headlamp

Special tools, testers and auxiliary items required

1. Adjusting gauge 3371

Scheme 162

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
4. Before removing, measure dimension - a - between headlamp - 2 - and spacer - 1 - and note dimension.

Note. When removing mounting bolts, always secure adjustment nuts - 1 - of adjusting elements against turning - arrows -.

1. Remove bolts - 1 through 3 -.
2. Remove headlamp toward front.
3. Disconnect electrical harness connector.

Installing

Note. When installing mounting bolts, always secure adjustment nuts - 1 - of adjusting elements against turning - arrows -.

1. Install headlamp and turn bolts - 1 through 3 - 2 rotations each.

1. Align headlamp - 2 - according to noted dimension - a - toward spacer - 1 -.

1. Bring front bumper cover to installation position (do not bolt on).
2. Align dimensions - a c - of headlamp - 1 - opposite to bumper cover - 2 - and fender - 3 - using adjustment gauge 3371 as follows

1. Dimension - a - = 2.3 mm
2. Dimension - b - = 2 mm
3. Dimension - c - = 1.2 mm.
4. Headlamp must be flush toward outer edge of fender.

1. Lower edge of headlamp must be parallel to upper edge of bumper.

1. Tighten bolt - 1 - - do not press bolt while tightening.
2. Remove front bumper cover.
3. Tighten bolts - 2 - and - 3 - , align headlamp flush to outer edge of fender while doing so.
4. Install front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

1. Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.
2. Adjust headlamps after installing 405.

Tightening torques

Headlamp, adjusting

Current specifications and requirements for headlamp adjustment 405.

Preparations for working on the headlamp

The engine version determines the difficulty of accessibility to the headlamp light bulb. If necessary, additional steps must be performed.

Reservoir for power steering, loosening at bracket

Special tools, testers and auxiliary items required

Scheme 163

1. Old oil collecting and extracting device V.A.G 1782

Scheme 164

Work procedure

1. Extract power steering fluid for power-steering from reservoir using old oil collecting and extracting device V.A.G 1782.

Note. Place a rag under reservoir for power steering to catch escaping hydraulic fluid. Remove bolt - arrow - and lay aside reservoir for power steering with hydraulic hoses connected.

Installation is performed in reverse order of removal, noting the following

1. Fill up power steering fluid and check hydraulic fluid level --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .

Tightening torque

Air filter housing, removing - vehicles with 6-cylinder Gasoline engine

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

1. Remove rear engine cover - arrows -.

Scheme 165

1. Pull check valve - 1 - off from air guide hose.
2. Remove air guide hose, to do so, open clips - arrows - and loosen hose clamp - 2 -.

1. Open clips - arrows - and remove upper air filter housing.

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear.
4. If present, disconnect hose - 3 - secondary air injection pump.

1. Remove lower air filter housing.

Installation is performed in the reverse order of removal.

Air filter housing, removing - vehicles with 4.2l MPI engine

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

Scheme 166

1. Uncover fuel line - 1 - at upper air filter housing.
2. Disconnect electrical harness connector - 2 - at Mass Air Flow (MAF) Sensor G70.
3. Remove air guide hose, to do so remove hose clamp - 3 -.
4. Open clips - arrows - and remove upper air filter housing with mass air flow sensor.

Scheme 167

1. Disconnect vacuum line.
2. Remove pin of expanding clip - 3 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear.
4. Disconnect hose - 1 - to Secondary Air Injection (AIR) pump.

1. Remove lower air filter housing.

Installation is performed in the reverse order of removal.

Air filter housing, removing - vehicles with 4.2l FSI engine

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 and 2 -.

1. Lay aside fuel line and line to EVAP canister at air filter housing and air guide pipe.
2. Disconnect electrical harness connector - 1 - at Mass Air Flow (MAF) Sensor G70.
3. Disconnect vacuum line - 3 - to air duct hose.
4. Lay aside air guide hose with hose for crankshaft housing ventilation - 2 - connected, release hose clamp - 4 - and open clips - arrows - to do so.

Note. Disregard - 5 -.

1. Open clips - arrows - and remove upper air filter housing.

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear from Intake Air Switch-Over valve N335.

Installation is performed in the reverse order of removal.

Scheme 168

Work procedure

1. Remove bolts - arrows - and remove left air guide, unhook hood cable to do so.

Scheme 169

1. Loosen hose clamp - 1 - and remove bolts - 2, 3, 4 -.
2. Remove left upper section of air filter housing.

Scheme 170

1. Disconnect electrical harness connector - arrow - at Mass Air Flow (MAF) Sensor 2 G246.

Scheme 171

1. Pull lower air filter housing off from connection at side.
2. Pivot lower air filter housing upward and out - arrow -.

Installation is performed in the reverse order of removal.

Scheme 172

Work procedure

1. Remove bolts - arrows - and remove right air guide.

Scheme 173

1. Disconnect vacuum hoses - 4 - and - 5 -.
2. Loosen hose clamp - 6 - and remove bolts - 1 3 -.
3. Remove right upper section of air filter housing.

Scheme 174

1. Disconnect electrical harness connector - arrow - at Mass Air Flow (MAF) Sensor G70.

Scheme 175

1. Pull lower air filter housing off from connection at side.
2. Pivot lower air filter housing upward and out - arrow -.

Installation is performed in the reverse order of removal.

Low beam bulb, replacing

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.

Left headlamp - vehicles with 6-cyl. Engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

Scheme 176

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 177

1. Disconnect harness connector - 1 - at low beam bulb.
2. Disengage wire clamp - 3 - and remove bulb - 2 - from housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into housing, do not touch glass cone with bare hands.
2. Secure bulb using wire clamp.
3. Re-connect harness connector and close housing cover.

Bulb for high beam, replacing

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.

Left headlamp - vehicles with 6-cyl. Engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 178

1. Disconnect harness connector - 1 - at high beam bulb.
2. Disengage wire clamp - 3 - and - 4 - and remove bulb - 2 - from housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into housing, do not touch glass cone with bare hands.
2. Secure bulb using wire clamp.
3. Re-connect harness connector and close housing cover.

Scheme 179

Removing

1. Pry off cap - 1 - in front wheel house liner in - direction of arrow -.

Note. On vehicles without cap, the wheel house liner must be loosened in front area --> 66 - EXTERIOR EQUIPMENT .

Scheme 180

1. Turn bulb socket counter-clockwise - arrow - and remove from housing.

Scheme 181

1. Release securing clip in - direction of arrow - and pull light bulb - 1 - out of socket - 2 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into housing, do not touch glass cone with bare hands.
2. Push cap into wheel house liner until it engages noticeably.

Repair set for headlamp housing, installing

Note. Headlight mounting tabs that have broken off can be replaced by installing the repair set. Complete replacement of the headlight is therefore not necessary. Different repair sets are available for the left and the right headlamps Parts Catalog.

Scheme 182

Work procedure

1. Remove headlamp with broken mounting tab --> «Headlamp, removing and installing after replacing components at front end»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__headlamp-removing-and-installing-after-replacing) .
2. Remove remains of broken mounting tab at headlamp housing.
3. Attach mounting tab - 1 - or - 3 - or - 4 - or - 5 - of repair set at headlamp housing and secure tab using bolts - 2 -.

Note. Disregard - 5 -.

Tightening torque

Gas discharge headlamp or gas discharge headlamp with dynamic cornering lamp, servicing - USA and Canada

Note. If measures are taken which could affect headlamp setting, headlamps are to be re-adjusted.

Scheme 183

1 - Headlamp housing

1. On vehicles with Adaptive Front-lighting System (AFS), the adjustment motor is integrated in the headlamp housing and cannot be replaced individually if malfunctioning.
2. Removing and installing after replacing components at front end --> «Headlamp, removing and installing after replacing components at front end»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)
3. Removing and installing when reusing current headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Gasket

1. Replace if damaged

3 - Power output stage

1. Vehicles with AFS only
2. Left Headlamp Power Output Stage J667 or Right Headlamp Power Output Stage J668
3. Removing and installing --> «Left/Right Headlamp Power Output Stage J667 / J668 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__leftright-headlamp-power-output-stage-j667)

4 - 1 Nm

5 - Light bulb

1. 12 V, 21 W
2. P21W, Super longlife
3. Changing bulb --> «Daytime running light bulb, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__daytime-running-light-bulb-replacing)

6 - Headlamp beam adjustment motor

1. Left Headlamp Beam Adjustment Motor V48 and Right Headlamp Beam Adjustment Motor V49
2. Removing and installing --> «Left and Right Headlamp Beam Adjustment Motors V48 / V49 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__left-and-right-headlamp-beam-adjustment)

7 - 1 Nm

8 - Lamp holder

1. For light bulb for daytime running lights

9 - Housing cover

10 - Ignition coil for gas discharge lamp

1. Removing and installing --> «Ignition coil for gas discharge lamp, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__ignition-coil-for-gas-discharge-lamp)

11 - Lamp holder

1. For light bulb for turn signal

12 - Bulb for turn signal

1. 12 V, 28/7 W
2. orange
3. Changing bulb --> «Turn signal indicator bulb, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__turn-signal-indicator-bulb-replacing)

13 - Gas discharge lamp for low beam

1. 35 W, D2S
2. Changing bulb --> «HID lamp, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__hid-lamp-replacing)

14 - Gasket

1. Replace if damaged

15 - Gas discharge lamp control module

1. Left High-intensity Gas Discharge Lamp Control Module J343 and Right High-intensity Gas Discharge Lamp Control Module J344
2. Removing and installing --> «Left/Right High-intensity Gas Discharge Lamp Control Module J343 / J344 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__leftright-high-intensity-gas-discharge-lamp-control)

16 - 1 Nm

17 - Adjustment nut

1. For adjustment of headlamp to bumper contour

18 - 8 Nm

Special tools, testers and auxiliary items required

1. Adjusting gauge 3371

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
4. Remove bolts - 1 3 -.

1. Remove headlamp toward front.
2. Disconnect electrical harness connector.

Installing

1. Check adjustment nut - 1 - of adjusting element for smooth running - arrows -.
2. Turn adjustment nut completely downward, but do not tighten.

1. Install headlamp and turn bolts - 1 3 - 2 rotations each.

1. Bring front bumper cover to installation position (do not bolt on).
2. Align dimensions - a c - of headlamp - 1 - opposite to bumper cover - 2 - and fender - 3 - using adjustment gauge 3371 as follows

1. Dimension - a - = 2.3 mm
2. Dimension - b - = 2 mm
3. Dimension - c - = 1.2 mm.
4. Headlamp must be flush toward outer edge of fender.

1. Lower edge of headlamp must be parallel to upper edge of bumper.

Note. When tightening the bolts, the adjustment nut of the adjusting element turns automatically towards the location point of the headlamp housing and locates it. Tighten bolt - 1 - - do not press bolt when tightening so that adjustment bolt of adjusting element can turn freely. Remove front bumper cover. Tighten bolts - 2 - and - 3 - , align headlamp flush to outer edge of fender while doing so. Install front bumper cover --> 63 - BUMPERS . Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above. Adjust headlamps after installing 405.

Tightening torques

Special tools, testers and auxiliary items required

1. Adjusting gauge 3371

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .
4. Before removing, measure dimension - a - between headlamp - 2 - and spacer - 1 - and note dimension.

Note. When removing mounting bolts, always secure adjustment nuts - 1 - of adjusting elements against turning - arrows -.

1. Remove bolts - 1 3 -.
2. Remove headlamp toward front.
3. Disconnect electrical harness connector.

Installing

Note. When installing mounting bolts, always secure adjustment nuts - 1 - of adjusting elements against turning - arrows -.

1. Install headlamp and turn bolts - 1 3 - 2 rotations each.

1. Align headlamp - 2 - according to noted dimension - a - toward spacer - 1 -.

1. Bring front bumper cover to installation position (do not bolt on).
2. Align dimensions - a c - of headlamp - 1 - opposite to bumper cover - 2 - and fender - 3 - using adjustment gauge 3371 as follows

1. Dimension - a - = 2.3 mm
2. Dimension - b - = 2 mm
3. Dimension - c - = 1.2 mm.
4. Headlamp must be flush toward outer edge of fender.

1. Lower edge of headlamp must be parallel to upper edge of bumper.

1. Tighten bolt - 1 - - do not press bolt while tightening.
2. Remove front bumper cover.
3. Tighten bolts - 2 - and - 3 - , align headlamp flush to outer edge of fender while doing so.
4. Install front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

1. Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.
2. Adjust headlamps after installing 405.

Tightening torques

Adjusting headlamps

Current specifications and requirements for headlamp adjustment 405.

HID headlamp bulb replacement, preparation

Depending on engine version, access to headlamp bulbs could be obstructed. In this case, additional steps must be performed.

Special tools, testers and auxiliary items required

1. Old oil collecting and extracting device V.A.G 1782

Work procedure

1. Extract power steering fluid from reservoir using old oil collecting and extracting device V.A.G 1782.

Note. Place a rag under reservoir for power steering to catch escaping power steering fluid. Remove bolt - arrow - and lay aside reservoir for power steering with hydraulic hoses connected.

Installation is performed in reverse order of removal, noting the following

1. Fill up power steering fluid and check hydraulic fluid level --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .

Tightening torque

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

1. Remove rear engine cover - arrows -.

1. Pull check valve - 1 - off from air guide hose.
2. Remove air guide hose, to do so, open clips - arrows - and loosen hose clamp - 2 -.

1. Open clips - arrows - and remove upper air filter housing.

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear.
4. If present, disconnect hose - 3 - secondary air injection pump.

1. Remove lower air filter housing.

Installation is performed in the reverse order of removal.

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 - and - 2 -.

1. Uncover fuel line - 1 - at upper air filter housing.
2. Disconnect electrical harness connector - 2 - at Mass Air Flow (MAF) Sensor G70.
3. Remove air guide hose, to do so remove hose clamp - 3 -.
4. Open clips - arrows - and remove upper air filter housing with mass air flow sensor.

1. Disconnect vacuum line.
2. Remove pin of expanding clip - 3 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear.
4. Disconnect hose - 1 - to Secondary Air Injection (AIR) pump.

1. Remove lower air filter housing.

Installation is performed in the reverse order of removal.

Work procedure

1. Remove bolts - arrows -.
2. Remove air guides - 1 and 2 -.

1. Lay aside fuel line and line to EVAP canister at air filter housing and air guide pipe.
2. Disconnect electrical harness connector - 1 - at Mass Air Flow (MAF) Sensor G70.
3. Disconnect vacuum line - 3 - to air duct hose.
4. Lay aside air guide hose with hose for crankshaft housing ventilation - 2 - connected, release hose clamp - 4 - and open clips - arrows - to do so.

Note. Disregard - 5 -.

1. Open clips - arrows - and remove upper air filter housing.

1. Disconnect vacuum line - 1 -.
2. Remove pin of expanding clip - 4 -.
3. Remove lower air filter housing and disconnect electrical harness connector - 2 - at rear from Intake Air Switch-Over valve N335.

Installation is performed in the reverse order of removal.

HID lamp, replacing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Left headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 184

1. If present, pivot securing clip - 1 - for electrical harness connector to side.
2. Rotate ignition coil - 2 - for gas discharge lamp counter-clockwise - arrow -.
3. Disconnect harness connector - 3 - at ignition coil for gas discharge lamp.
4. Remove ignition coil for gas discharge lamp.

Scheme 185

1. Disengage wire clamp - 1 -.
2. Pull gas discharge lamp - 2 - out of headlamp housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new gas discharge lamp into housing, do not touch glass cone with bare hands when doing so.

Note. Note installation position: Upper tab at bulb socket must engage at recess for gas discharge lamp. If present, secure gas discharge lamp using wire clamp.

Note. Harness connector must only be connected with ignition coil installed.

Scheme 186

1. Check if recess in housing of ignition coil for gas discharge lamp and recess in pressure ring align completely with each other - arrows -.
2. Attach ignition coil for gas discharge lamp to headlamp and fasten clockwise until stop.

1. Ignition coil must turn freely.
2. Arrow on housing points upward.

1. Connect harness connector.
2. Secure electrical harness connector using securing clip.
3. Close housing lid.
4. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

HID headlamp bulb, disposal

Note. HID headlamp bulbs contain mercury. Faulty HID headlamp bulbs (not covered by new vehicle warranty) may need to be disposed of as hazardous waste. Always heed state/local regulations concerning disposal of hazardous waste.

Daytime running light bulb, replacing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Left headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 187

1. Turn socket counter-clockwise - arrow - and remove from headlamp housing.
2. Remove lamp from socket.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into housing, do not touch glass cone with bare hands.
2. Secure socket by turning clockwise.
3. Close housing lid.
4. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

High/Low Beam Switch-Over Solenoid, removing and installing

The High/Low Beam Switch-Over Solenoid (left: N347 ; right: N348 ) is installed in headlamp housing beneath gas discharge lamp and cannot be replaced individually if malfunctioning.

1. Replace headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Swivel Module Position Sensor and Dynamic Cornering Light Motor, removing and installing

Swivel Module Position Sensor (left: G474 ; right: G475 ) and Dynamic Cornering Light Motor (left: V318 ; right V319 ) is installed in headlamp housing beneath gas discharge lamp and cannot be replaced individually if malfunctioning.

1. Replace headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Turn signal indicator bulb, replacing

Removing

1. Pry off cap - 1 - in front wheel house liner in - direction of arrow -.

Note. On vehicles without cap, the wheel house liner must be loosened in front area --> 66 - EXTERIOR EQUIPMENT .

1. Turn bulb socket counter-clockwise - arrow - and remove from housing.

1. Release securing clip in - direction of arrow - and pull light bulb - 1 - out of socket - 2 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into housing, do not touch glass cone with bare hands.
2. Push cap into wheel house liner until it engages noticeably.

Left and Right Headlamp Beam Adjustment Motors V48 / V49 , removing and installing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Left headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 188

1. Remove bolts - arrows -.
2. By pivoting adjustment motor - 1 - to the side, push ball head of adjustment axle out of ball head mount.
3. Remove headlamp beam adjustment motor out of headlamp housing.
4. Disconnect electrical harness connector - 2 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. First, insert ball head of adjustment axle from the side into ball head mount of reflector, pull reflector toward rear to do so.

Note. Always adjust headlamps after removing, installing or replacing adjustment motors 405. Close housing lid. Connect battery. Required actions Battery, disconnecting and connecting .

Tightening torque

Left/Right High-intensity Gas Discharge Lamp Control Module J343 / J344 , removing and installing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove headlight --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Scheme 189

1. Remove bolts - arrows -.
2. Pull High-intensity Gas Discharge Lamp Control Module off from headlamp housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Check seal between High-intensity Gas Discharge Lamp Control Module and headlamp housing.
2. Install headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
3. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Tightening torque

Left/Right Headlamp Power Output Stage J667 / J668 , removing and installing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .
2. Remove headlight --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Scheme 190

1. Remove bolts - arrows -.
2. Remove headlamp power output stage - 1 - from headlamp housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Check seal between power output stage and headlamp housing.
2. Install headlamp --> «Headlamp, removing and installing when reusing current headlamp»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
3. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Tightening torque

Ignition coil for gas discharge lamp, removing and installing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Left headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove reservoir for power steering.

Right headlamp - vehicles with 6-cyl. Gasoline engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l MPI engine

1. Remove air filter housing.

Right headlamp - vehicles with 4.2l FSI engine

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

1. If present, pivot securing clip - 1 - for electrical harness connector to side.
2. Rotate ignition coil - 2 - for gas discharge lamp counter-clockwise - arrow -.
3. Disconnect harness connector - 3 - at ignition coil for gas discharge lamp.
4. Remove ignition coil for gas discharge lamp.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Harness connector must only be connected with ignition coil installed.

1. Check if recess in housing of ignition coil for gas discharge lamp and recess in pressure ring align completely with each other - arrows -.
2. Attach ignition coil for gas discharge lamp to headlamp and fasten clockwise until stop.

1. Ignition coil must turn freely.
2. Arrow on housing points upward.

1. Connect harness connector.
2. If installed, secure electrical harness connector using securing clip.
3. Close housing lid.
4. Connect battery. Required actions «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Note. Headlight mounting tabs that have broken off can be replaced by installing the repair set. Complete replacement of the headlight is therefore not necessary. Different repair sets are available for the left and the right headlamps Parts Catalog.

Work procedure

1. Remove headlamp with broken mounting tab --> «Headlamp, removing and installing after replacing components at front end»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .
2. Remove remains of broken mounting tab at headlamp housing.
3. Attach mounting tab - 1 - or - 3 - or - 4 - or - 5 - of repair set at headlamp housing and secure tab using bolts - 2 -.

Tightening torque

Side marker lamp, removing and installing

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 191

1. Press clip - 1 - in - direction of arrow - using a screwdriver.
2. Remove side marker lamp - 2 - toward front out of bumper cover.
3. Remove housing for side marker lamp from bulb socket - 3 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. After installing side marker lamp, press clip toward outside of vehicle into bumper cover using a screwdriver.

Side marker light bulb, replacing

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Remove quick-release screws - 1 - and - 2 - and remove front noise insulation.

Scheme 192

1. Pull lamp socket - 1 - off from housing for side marker lamp.
2. Remove bulb from socket.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb (12V, 5W - orange) into housing, do not touch glass cone with bare hands when doing so.
2. When inserting, make sure markings - 2 - and - 3 - are horizontal.

Scheme 193

Removing

1. Release clip using a screwdriver - arrow A - and remove air inlet grille - 1 - at lower part of bumper cover - arrows B -.
2. Remove front bumper cover --> «63 - BUMPERS»(/audi/a6/6-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior) .

Scheme 194

1. Remove bolts - 1 - and - 2 -.
2. Release clip - 3 - and remove daytime running lamp - 4 - toward front out of bumper cover - arrow -.

Installing

Installation is performed in reverse order of removal, noting the following

Note. If LEDs are malfunctioning, daytime running lamp must be completely replaced. Install front bumper cover --> 63 - BUMPERS .

Tightening torque

Fog lamp, removing and installing - Audi A6

Scheme 195

Removing

1. Switch ignition off and remove ignition key.
2. Turn light switch into "0" position.
3. Release clip - arrow A - using a screwdriver and remove air inlet grille - 1 - at lower part of bumper cover - arrows B -.

Scheme 196

1. Remove bolts - 1 - and - 2 -.
2. Rotate fog lamp housing - 3 - counter-clockwise - arrow - on left side, and rotate clockwise on right side.
3. Remove fog lamp housing from bumper cover.
4. Disconnect electrical harness connector.

Installing

Installation is performed in reverse order of removal, noting the following

1. Adjusting fog lights 405.

Tightening torque

Scheme 197

Removing

1. Remove fog lamp --> «Fog lamp, removing and installing - Audi A6»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__fog-lamp-removing-and-installing) .
2. Release securing guides - arrows - at cap - 1 -.

Scheme 198

1. Disconnect electrical harness connector - 2 - at bulb.
2. Disengage wire clamp - 1 - and remove bulb - 3 - from housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb (H7 - 12V, 55W W5W Longlife) into housing, do not touch glass cone with bare hands when doing so.
2. Secure bulb using wire clamp.
3. Reconnect harness connectors and close housing cover.
4. Adjusting fog lights 405.

Fog lamp, removing and installing - Audi S6

The fog lamp is integrated in the headlamp housing and cannot be replaced individually if malfunctioning.

1. Replace headlamp --> «Headlamp, removing and installing after replacing components at front end»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) .

Light bulb for fog lamp, replacing - Audi S6

Removing

Removing

1. With ignition switched off, disconnect battery Ground (GND) wire --> «Battery, disconnecting and connecting»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-connecting) .

Left headlamp

1. Remove air filter housing.

Right headlight

1. Remove air filter housing.

All

1. Release securing guides - arrows - and remove headlamp housing cover.

Scheme 199

1. Disconnect electrical harness connector - 1 - at bulb.
2. Disengage wire clamp - 2 - and remove bulb - 3 - from housing.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb (H7 - 12V, 55W W5W Longlife) into housing, do not touch glass cone with bare hands when doing so.
2. Secure bulb using wire clamp.
3. Reconnect harness connectors and close housing cover.
4. Adjusting fog lights 405.

Fog lamp, adjusting

Current specifications and procedures for adjusting fog lamps 405.

Side turn signal lamp, removing and installing

Removing

1. Switch ignition off and remove ignition key.

Scheme 200

1. Push side turn signal lamp against retaining tab - arrow - in driving direction and carefully remove from fender opening.
2. Remove housing for side turn signals from bulb socket.

Installing

Installation is performed in the reverse order of removal.

Entrance light in exterior mirror, removing and installing

Special tools, testers and auxiliary items required

Scheme 201

1. Pry lever 80 - 200
2. Protective gloves

Scheme 202

Removing

1. Press mirror glass - 1 - out of mirror adjusting unit - arrow - using pry lever 80 - 200.
2. Disconnect electrical harness connectors.

Scheme 203

1. Remove bolts - 1 - and - 3 -.
2. Release clip - arrow a -.
3. Pull housing a little off cover - 2 - - arrows B - and press cover downward at outside - arrow C -.
4. Pull cover off from mirror mount.

1. Disconnect electrical harness connector - 4 -.

Scheme 204

1. Remove bolt - 1 - and disengage entrance light in exterior mirror - 2 - at cover.

Installing

Installation is performed in reverse order of removal, noting the following

Note. If LEDs are malfunctioning, entrance light in exterior mirror must be completely replaced. Attach mirror glass at mirror adjusting unit and press on mirror glass.

Note. Make sure to press only in mirror center.

Tightening torques

Rear lights - Sedan, assembly

Note. Illustration shows basic version of rear light. Depending on market version, LEDs may be used for brake lights and a 21 W halogen bulb may be used for rear fog lamp.

Scheme 205

1 - Housing

1. With High version with LEDs for brake light
2. Removing and installing --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)
3. Align to body contour --> «Rear lights, aligning with body contour»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Light bulb

1. For turn signal light
2. 12 V, 21 W
3. Orange
4. Replace --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

3 - Light bulb

1. 12 V, 21 W
2. Replace --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

4 - Light bulb

1. 12 V, 21 W
2. Replace --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

5 - Bulb carrier

1. Removing and installing --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

6 - Clip nut

7 - Electrical harness connector

8 - Grommet

9 - Spreader pin

10 - 3.5 Nm

11 - Adjustment nut

1. With seal
2. To adjust tail lamp to body contour

12 - Threaded bolts

1. Bolted in side panel

13 - Light bulb

1. 12 V, 21 W
2. Replace --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

14 - Light bulb

1. Back-up lamp, Basis version, drivers and passengers side, as well as USA vehicles: 12 V, 21 W
2. Rear fog lamp, High version, drivers side: 12 V, 21 W Halogen light bulb
3. Back-up lamp, High version, passengers side: 12 V, 21 W
4. Replace --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

15 - Cover

Rear lights / rear light bulb holder, removing and installing

Special tools, testers and auxiliary items required

1. Trim removal wedge 3409

Scheme 206

Removing

1. Turn light switch into "0" position.
2. Remove luggage compartment side trim cover.
3. Remove nut - arrow -.

Scheme 207

1. Pry cover - 2 - off of tail lamp - 1 - using trim removal wedge 3409.

Scheme 208

1. Pry tail lamp - 1 - out of clip nuts from outside using trim removal wedge 3409.
2. Remove tail lamp from body opening.
3. Disconnect electrical harness connector at lamp carrier.

Scheme 209

1. Expand catch bracket - arrows - and remove lamp carrier - 1 - from tail lamp.
2. Remove light bulbs from sockets.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Replace adjusting nut with damaged seal.

Scheme 210

1. Attach tail lamp - 3 - at body cut-out and at cover - 2 -.

Note. Tail lamp must engage in cover guides. Press retaining bolts - 1 - into clip nuts at outside. Press cover onto tail lamp until it engages audibly. Tighten nut.

Tightening torque

Scheme 211

Adjustment in driving direction

1. Screw adjusting nut - 1 - gradually in and out - arrow - with tail lamp removed ( --> «Rear lights / rear light bulb holder, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb) ).

Tightening torque

Scheme 212

1 - Housing

1. Removing and installing --> «Rear lights / rear light bulb holder in rear fenders, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)
2. Align to body contour --> «Rear lights in rear fenders, aligning with body contour»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Bulb for turn signal

1. 12 V, 21 W

3 - 2.5 Nm

1. Insert using locking compound; locking compound Parts Catalog.

4 - Clip nut

5 - Retaining element

1. For aligning housing to body contour --> «Rear lights in rear fenders, aligning with body contour»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

6 - Clip nut

7 - 2.5 Nm

1. Insert using locking compound; locking compound Parts Catalog.

8 - Electrical harness connector

9 - Cap nut (3.5 Nm)

10 - Bulb carrier

1. Removing and installing --> «Rear lights / rear light bulb holder in rear fenders, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb)

11 - Bulb for brake light/backup light

1. 12 V, 21 W
2. Does not apply to vehicles with LEDs

12 - Adjustment nut

1. With seal
2. To adjust tail lamp to body contour

13 - Threaded bolts

1. Bolted in side panel

Rear lights / rear light bulb holder in rear fenders, removing and installing

Removing

1. Turn light switch into "0" position.

Scheme 213

1. Remove luggage compartment side trim cover.
2. Unscrew cap nut - 2 -.
3. Pry tail lamp - 1 - out of clip nuts from outside using trim removal wedge 3409.
4. Remove tail lamp from body opening.

1. Disconnect electrical harness connector at lamp carrier.

Scheme 214

1. Expand catch bracket - arrows - and remove lamp carrier - 1 - from tail lamp.
2. Twist bulbs out of bulb sockets.

Installing

Installation is performed in reverse order of removal, noting the following

Note. Replace adjusting nut with damaged seal. Attach tail lamp at body and press retaining bolts into clip nuts. Tighten cap nut.

Tightening torque

Scheme 215

Adjustment in driving direction

1. Screw adjusting nut - 1 - gradually in and out - arrow - with tail lamp removed ( --> «Rear lights / rear light bulb holder in rear fenders, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb) ).

Scheme 216

Adjustment perpendicular to driving direction

1. With tail lamp removed ( --> «Rear lights / rear light bulb holder in rear fenders, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-rear-light-bulb) ), gradually push in and pull out - arrow - retaining element - 1 - after loosening bolts - 2 - and - 3 -.

Tightening torques

Scheme 217

1 - Housing

1. Removing and installing --> «Rear lights in rear lid, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Light bulb for rear light

1. 12 V, 21 W

3 - Clamp mounting

1. For securing housing at rear lid

4 - Nut (3.5 Nm)

5 - Electrical harness connector

6 - Lamp holder

1. For light bulb for tail light/back-up lamp/rear fog lamp
2. Removing and installing --> «Rear lights in rear lid - bulbs, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-in-rear-lid)

7 - Nut (3.5 Nm)

8 - Clamping bracket

1. For securing bulb socket ad housing at rear lid

9 - Light bulb for rear light/rear fog lamp

1. 12 V, 21 W

10 - Light bulb for back-up lamp

1. 12 V, 16 W

Scheme 218

1 - Housing

1. With LEDs
2. Removing and installing --> «Rear lights in rear lid, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Light bulb for rear fog lamp

1. Halogen 12 V, 21 W

3 - Clamp mounting

1. For securing housing at rear lid

4 - Nut (3.5 Nm)

5 - Electrical harness connector

6 - Lamp holder

1. For light bulb for back-up lamp/rear fog lamp
2. Removing and installing --> «Rear lights in rear lid - bulbs, replacing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-lights-in-rear-lid)

7 - Nut (3.5 Nm)

8 - Clamping bracket

1. For securing bulb socket ad housing at rear lid

9 - Light bulb for back-up lamp

1. 12 V, 16 W

Scheme 219

Removing

1. Turn light switch into "0" position.
2. Open cap - 1 - for warning triangle.
3. Rotate quick-release screw - 2 - counter-clockwise 90 ° and remove cover - 3 - from luggage compartment lining - direction of arrow -.

Scheme 220

1. Disconnect electrical harness connector.
2. Remove bulb socket - 1 - from housing, press catch bracket - 2 - downward - arrow - to do so.

Scheme 221

1. Unscrew nut - 2 - and remove clamping bracket - 1 -.
2. Remove nut - 4 - and remove inner tail lamp - 3 - toward outside.
3. Remove clamp mounting - 5 - from body cut-out.

Scheme 222

Installing

Installation is the reverse of removal, noting the following

Note. Make sure seal between body and tail lamp housing seals properly. Attach clamp mounting - 2 - at inner tail lamp and screw on nut - 3 - loosely. Attach inner tail lamp - 4 - at body cut-out and make sure grip tabs - arrows - of clamp mounting rest against body cut-out. Slide clamp mounting - 1 - onto threaded pin of inner tail lamp and tighten nuts - 3 - and - 5 -.

Note. By tightening nut, clamp mounting wedges with inner interior light and rear lid.

Tightening torques

Rear lights in rear lid - bulbs, replacing

Removing

1. Turn light switch into "0" position.
2. Open cap - 1 - for warning triangle.
3. Rotate quick-release screw - 2 - counter-clockwise 90 ° and remove cover - 3 - from luggage compartment lining - direction of arrow -.

1. Remove bulb socket - 1 - from housing, press catch bracket - 2 - downward - arrow - to do so.

Lamp, Basis version

1. Unscrew light bulb for tail light and rear fog lamp out of socket.

Lamp with LEDs

1. Remove light bulb for rear fog lamp from socket.

All

1. Pull light bulb for back-up lamp out of socket.

Installing

Installation is performed in reverse order of removal, noting the following

1. Insert new bulb into socket, do not touch glass cone with bare hands when doing so.

Tightening torque

Scheme 223

Removing

1. Do not operate brake pedal.
2. Carefully pull roof end trim - 1 - from roof frame - arrows -.

Note. If necessary, pry off roof end trim using pry lever 80 - 200.

Scheme 224

1. Pull release levers - 1 - and - 4 - outward - arrows - at high-mount brake light - 2 -.
2. Disconnect electrical harness connector - 3 - at high-mount brake light.

Note. If LEDs are malfunctioning, high-mount brake light must be completely replaced.

Installing

Installation is performed in the reverse order of removal.

Scheme 225

Removing

1. Do not operate brake pedal.
2. Remove upper rear lid trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
3. Position screwdriver - 2 - in recess at retaining rail - 1 -.
4. Release retaining track of spring tabs toward right by forcefully pressing screwdriver handle toward right - arrow -.

1. Pull high-mount brake light out of lid cut-out.
2. Disconnect electrical harness connector - 1 -.
3. Remove mounting parts for high-mount brake light (4x) from rear lid.

Scheme 226

Installing

Installation is performed in reverse order of removal, noting the following

Note. In case of defective LEDs, the complete high-mount brake light must be replaced. Attach spring clamps - 4 - at housing - 3 - of high-mount brake light so that flat portion - arrow A - aligns at housing with flat portion - arrow B -. Make sure clips of spring clamps are inserted behind guides at housing. Attach retaining track at housing and engage it up to 1st stage. Bar - 1 - of retaining track must align with cut-out - 2 - at lamp housing. Connect electrical harness connector and insert high-mount brake light into lid cut-out until it engages audibly.

Scheme 227

1. Latch retaining track by forcefully pressing screwdriver handle - 1 - toward left - arrow -.

1. Bar - 2 - of retaining track must align with marking - 3 - at lamp housing.
2. Spring clamps are secured by retaining track.

1. Install upper rear lid trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 228

Removing

1. Turn light switch into "0" position.
2. Remove bolt - arrow - in grip piece.

Note. Only the right license plate light is shown in illustration. Lever out bulb carrier from grip piece. Remove bulb (12 V, 5 W) from terminal socket.

Installing

Installation is performed in the reverse order of removal.

Steering column switch module (SCSM)

General description

1. Steering column switch module (SCSM) is composed of return ring with slip ring, Steering Angle Sensor G85 , steering column switch (turn signal switch, wiper switch, cruise control switch) and Steering Column Electronic Systems Control Module J527.
2. Fault finding is performed via "Guided Fault Finding".

Scheme 229

1 - Return spring with slip ring

1. Removing and installing --> «Return spring with slip ring, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__return-spring-with-slip-ring-removing)

2 - Steering Angle Sensor G85

1. Removing and installing --> «Steering Angle Sensor G85 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

3 - Cylinder bolt (0.65 Nm)

4 - Cruise Control Switch E45

1. Removing and installing --> «Cruise Control Switch E45 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__cruise-control-switch-e45-removing)

5 - Cylinder bolt (0.65 Nm)

6 - Turn Signal Switch E2

1. Removing and installing --> «Turn Signal Switch E2 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__turn-signal-switch-e2-removing)

7 - Retaining bracket

8 - Steering Column Electronic Systems Control Module J527

1. Removing and installing --> «Steering Column Electronic Systems Control Module J527 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-electronic-systems-control-module)
2. Connector assignment of Steering Column Electronic Systems Control Module J527 --> «Connector assignment on Steering Column Electronic Systems Control Module J527 - front side»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__connector-assignment-on-steering-column-electronic)

9 - Clamping screw (3 Nm)

10 - Windshield Wiper/Washer Switch E22

1. Removing and installing --> «Windshield Wiper/Washer Switch E22 , removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__windshield-wiperwasher-switch-e22-removing)

11 - Cylinder bolt (0.65 Nm)

Steering Column Switch Module (SCSM), removing and installing

Special tools, testers and auxiliary items required

Scheme 230

1. T8 screwdriver T40056 A

Removing

1. Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

1. Remove airbag unit --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. Remove steering wheel --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .
3. On vehicles with electrically adjustable steering column, remove lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 231

1. Remove bolts - 3 - and - 4 - using T8 screwdriver T40056 A.
2. If present, open mechanical steering column adjustment with handle - 5 -.
3. Remove Torx bolts - 6 -.
4. Disconnect upper trim - 2 - for steering column switch from lower trim - 1 - and remove both sections.

1. If installed, disconnect electrical harness connector at lower trim.

Scheme 232

1. Remove bolt - 2 -.
2. Disconnect electrical harness connectors - 1 - and - 3 -.

1. Disconnect electrical harness connector - 4 -.

Scheme 233

1. Press catch - 1 - in - direction of arrow - until harness connector - 2 - disengages.
2. Carefully pull off steering column switch together with Steering Column Electronic Systems Control Module J527.

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all harness connectors are engaged properly.
2. Insert top trim piece for steering column switch into catches of bottom trim piece, press together and bolt.
3. Install lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
4. Install steering wheel --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .

1. Install airbag unit --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Tightening torques

Return spring with slip ring, removing and installing

Special tools, testers and auxiliary items required

1. T8 screwdriver T40056 A

Removing

1. Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

1. Remove airbag unit --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. Remove steering wheel --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .
3. On vehicles with electrically adjustable steering column, remove lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

1. Remove bolts - 3 - and - 4 - using T8 screwdriver T40056 A.
2. If present, open mechanical steering column adjustment with handle - 5 -.
3. Remove Torx bolts - 6 -.
4. Disconnect upper trim - 2 - for steering column switch from lower trim - 1 - and remove both sections.

1. If installed, disconnect electrical harness connector at lower trim.

Scheme 234

1. Disconnect upper electrical harness connector at return spring with slip ring.
2. Carefully release catch - arrows - and pull return ring with slip ring - 1 - from steering column switch module (SCSM).

Note. Shown in illustration with steering column switch module (SCSM) removed.

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all 3 catches as well as the harness connectors are engaged correctly.
2. Insert top trim piece for steering column switch into catches of bottom trim piece, press together and bolt.
3. Install lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
4. Install steering wheel --> «48 - STEERING»(/audi/a6/6-2004-2008/remont/axle-shafts/#suspension-wheels-steering) .

1. Install airbag unit --> «69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Tightening torques

Scheme 235

Removing

1. Remove return spring with slip ring --> «Return spring with slip ring, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__return-spring-with-slip-ring-removing) .
2. Remove Steering Angle Sensor G85 - 1 - - arrow -.

Installing

Installation is performed in reverse order of removal, noting the following

1. After replacing steering angle sensor G85 , it must be calibrated via "Guided Functions".

Steering Column Electronic Systems Control Module J527 , removing and installing

1. If control module is replaced, select "Guided Functions" of respective control module in.

Scheme 236

Removing

1. Remove Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

1. Carefully release catches - arrows -.
2. Pull return spring with slip ring - 2 - with Steering Angle Sensor G85 - 1 - off from steering column switch module (SCSM).

Scheme 237

1. Remove bolts - arrows -.
2. Remove Steering Column Electronic Systems Control Module J527 - 1 - from steering column switch module.

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all 3 catches as well as the harness connectors are engaged correctly.
2. Install Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

If Steering Column Electronic Systems Control Module J527 was replaced, it must be coded.

Tightening torques

Connector assignment on Steering Column Electronic Systems Control Module J527 - front side

The Steering Column Electronic Systems Control Module J527 is part of the complete system "steering column switch module (SCSM)". It receives its signals e.g. from steering column switch.

Checking Steering Column Electronic Systems Control Module J527.

Scheme 238

A - Cruise control system harness connector

1 - Ground (GND)

2 - Fix

3 - Distance

4 -12 V voltage supply

5 - Resume/touch "Off"

6 - Acceleration/Deceleration

7 - Locked "Off"

B - Turn signal harness connector

1 - Ground (GND)

2 - Radio remote control (special vehicles)

3 - Alarm (special vehicles)

4 - not occupied

5 - Flasher/light change-over

6 - Blinking

C - Harness connector of multi-function steering wheel/Tiptronic/heated steering wheel

7 - Tip- "-"

8 - Multi-function steering wheel "+" - Voltage supply

9 - Multi-function steering wheel data

10 - Tip- "+"

11 - Multi-function steering wheel dimmer

12 - Tiptronic Ground (GND)

13 - Heated steering wheel "+"

14 - Heated steering wheel "-"

D - Steering angle sensor

1 - Light barrier 5

2 - Light barrier 3

3 - Light barrier 1

4 -12 V voltage supply

5 - 5 V voltage supply

6 - Light barrier 6

7 - Light barrier 4

8 - Light barrier 2

9 - Steering angle sensor Ground (GND)

10 - Light barrier 7

E - Signal horn

1 - Horn Ground (GND)

2 - Horn

F - Wiper system

1 - Ground (GND)

2 - Interval-potentiometer

3 - Board computer

4 - not occupied

5 - Washing

6 - Wiping

Scheme 239

16-pin multi-pin connector

1. Terminal 31
2. Terminal 30
3. Powertrain CAN Bus shielding
4. Not assigned
5. Cruise Control System engaged Off
6. Alarm (special vehicles)
7. Radio remote control (special vehicles)
8. CAN Comfort Low
9. CAN Comfort High
10. CAN Powertrain High
11. CAN Powertrain Low
12. Not assigned
13. Terminal 15
14. Not assigned
15. Not assigned
16. Not assigned

Scheme 240

4-pin multi-pin connector

1. Easy Entry
2. Steering column adjustment switch
3. Terminal 31
4. Not assigned

Turn Signal Switch E2 , removing and installing

Removing

1. Remove Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

1. Carefully release catches - arrows -.
2. Pull return spring with slip ring - 2 - with Steering Angle Sensor G85 - 1 - off from steering column switch module (SCSM).

Scheme 241

1. Remove bolts - arrows -.
2. Pull Steering Column Electronic Systems Control Module J527 - 2 - and Windshield Wiper/Washer Switch E22 - 3 - off from steering column switch module (SCSM).
3. Disengage Cruise Control Switch E45 - 1 - from steering column switch module (SCSM).
4. Remove bolt - 5 - and remove retaining bracket - 4 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all 3 catches as well as the harness connectors are engaged correctly.
2. Install Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

Tightening torques

Cruise Control Switch E45 , removing and installing

Removing

1. Remove Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

1. Carefully release catches - arrows -.
2. Pull return spring with slip ring - 2 - with Steering Angle Sensor G85 - 1 - off from steering column switch module (SCSM).

Scheme 242

1. Remove bolts - arrows -.
2. Remove Steering Column Electronic Systems Control Module J527 - 2 - from steering column switch module.
3. Disengage Cruise Control Switch E45 - 1 - from steering column switch module (SCSM).

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all 3 catches as well as the harness connectors are engaged correctly.
2. Install Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

Tightening torques

Windshield Wiper/Washer Switch E22 , removing and installing

Removing

1. Remove Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

1. Carefully release catches - arrows -.
2. Pull return spring with slip ring - 2 - with Steering Angle Sensor G85 - 1 - off from steering column switch module (SCSM).

Scheme 243

1. Remove bolts - 1 - and - 2 -.
2. Remove Windshield Wiper/Washer Switch E22 - 3 - from steering column switch module - arrow -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Make sure that all 3 catches as well as the harness connectors are engaged correctly.
2. Install Steering Column Switch Module (SCSM) --> «Steering Column Switch Module (SCSM), removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__steering-column-switch-module-scsm-removing) .

Tightening torque

Access/Start Authorization Switch E415 , servicing

Note. Reading coil for immobilizer is attached to Access/Start Authorization Switch E415 and cannot be replaced separately. Access/Start Authorization Switch E415 must be replaced if reading coil is faulty.

Access/Start Authorization Switch E415 , removing and installing

Note. If access/start authorization switch is replaced, no adaptation of immobilizer is necessary. Lock in access/start authorization switch is not coded mechanically. Keys must therefore not be replaced when access/start authorization switch is replaced; present keys continue to match.

Special tools, testers and auxiliary items required

1. Trim removal wedge 3409

1. Hook 3438 (2x)

Removing

1. Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

1. Carefully release spring pins - 1 - of decorative panel from instrument panel using trim removal wedge 3409.

Note. The instrument panel vent provides a hole on both sides to engage the hook 3438. Carefully remove the instrument panel at both sides from installation opening using the hook 3438.

If the instrument panel vent cannot be pulled out that way, proceed as follows

1. Position lamellae of instrument panel vent horizontally.
2. Release all clips - arrow - by inserting clockmaker screwdrivers - 2 - and - 3 -.
3. Remove instrument panel vent on both sides out of installation opening using hook 3438 , the screwdrivers must remain inserted when doing so.
4. Disconnect electrical harness connectors.

Scheme 244

1. Remove bolts - arrows -.
2. Remove Access/Start Authorization Switch E415 - 1 - from instrument panel.

Scheme 245

1. Disconnect electrical harness connectors - 1 3 -.

Installing

Installation is performed in the reverse order of removal.

Scheme 246

A - Connector socket

1. Terminal 30
2. Terminal 31
3. Sensor bus
4. Electric steering lock, terminal 15
5. Electric steering lock, terminal 50
6. Switch P

B - Connector socket

1. Illumination Start button
2. Start button, On position
3. Start button, Start position
4. Illumination Stop button
5. Stop button
6. Stop button
7. Brake pedal switch
8. Not assigned

C - Connector socket

To Antenna for remote control

D - Connector socket

1. Terminal 30
2. Electric steering lock (ESL)

Scheme 247

1 - Sensor for parking assistance

1. In front bumper
2. Only for 8-channel parking assistance
3. Removing and installing --> «Front parking aid sensors, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

2 - Parking Aid Button E266

1. Only for 8-channel parking assistance
2. With Parking Aid Switch Illumination L117
3. With integrated Parking Aid Indicator Lamp K136
4. Component location Component location under «Component location Parking Aid Button E266»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

3 - Control module for parking aid J446

Sedan

1. In right rear luggage compartment at wheel house
2. Removing and installing --> «Parking Aid Control Module J446 , removing and installing - Sedan»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

Avant

1. In right rear luggage compartment, in dirt tray
2. Removing and installing --> «Parking Aid Control Module J446 , removing and installing - Avant»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

4 - Sensor for parking assistance

1. In rear bumper
2. Removing and installing --> «Rear parking aid sensors, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

5 - Warning buzzer for parking H15

1. At belt webbing guide

Sedan

1. Removing and installing: Up to model year 2006 --> «Front Parking Aid Warning Buzzer H15 at left belt webbing guide, removing and installing - Sedan up to model year 2006»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment) ; from model year 2007 --> «Rear Parking Aid Warning Buzzer H15 at right belt webbing guide, removing and installing - Sedan as of model year 2007»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment)

Avant

1. Removing and installing --> «Rear Parking Aid Warning Buzzer H15 at right belt webbing guide, removing and installing - Avant»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__rear-parking-aid-warning-buzzer-h15)

6 - Front Parking Aid Warning Buzzer H22

1. Only for 8-channel parking assistance
2. behind storage compartment, drivers side
3. Removing and installing --> «Front Parking Aid Warning Buzzer H22 , removing and installing (8-channel parking aid)»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__front-parking-aid-warning-buzzer-h22)

Scheme 248

1. In switch strip in center console - arrow -.
2. Removing and installing --> «Switches in instrument panel, removing and installing»(/audi/a6/6-2004-2008/remont/cruise-control-systems/#electrical-equipment__switches-in-instrument-panel-removing-and) .

Scheme 249

Removing

1. Remove right luggage compartment side trim cover.
2. Release clip - arrow A - and swivel Parking Aid Control Module J446 - 4 - out of mounting frame - arrow B -.
3. Disconnect electrical harness connectors - 1 3 -.

Note. Shown in illustration from side with trim removed.

Installing

Installation is performed in the reverse order of removal.

Scheme 250

Removing

1. Remove right luggage compartment side trim cover.

Vehicles with car jack bracket

1. Remove car jack from bracket.
2. Remove nuts - 1 - and - 2 - and bolt - 3 -.
3. Remove car jack bracket.

Scheme 251

All

1. Remove towing eye - 1 - from mount for vehicle tool kit - 2 -.

Vehicles without bracket for control modules

1. Remove nut - right arrow -.

All

1. Remove nut - left arrow - and remove mount for vehicle tool kit.

1. Remove luggage compartment storage area floor - 1 - and cover for spare wheel - 2 -.

Scheme 252

1. Push tie-downs - 2 - together in retaining track - 1 - so that they do not rest above bolts.
2. Unscrew bolts - arrow - and remove retaining track.
3. Disengage side luggage compartment trim in lower area --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 253

1. Release clip - arrow - and swivel Parking Aid Control Module J446 - 4 - out of mounting frame.
2. Disconnect electrical harness connectors - 1 3 -.

Installing

Installation is performed in the reverse order of removal.

Tightening torques

Front Parking Aid Warning Buzzer H22 , removing and installing (8-channel parking aid)

Component location: At instrument panel carrier behind storage compartment on drivers side.

Scheme 254

Removing

1. Remove lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. Disconnect electrical harness connector - 2 -.
3. Remove bolts - arrows - and remove Front Parking Aid Warning Buzzer H22 - 1 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install lower instrument panel cover on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 255

Removing

Component location: At belt webbing guide, left rear.

1. Remove C-pillar trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. Pull out Rear Parking Aid Warning Buzzer H15 - 3 - at left belt webbing guide - 1 - in - direction of arrow -.
3. Disconnect electrical harness connector - 2 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install C-pillar trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 256

Removing

Component location: At belt webbing guide, right rear.

1. Remove C-pillar trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. Pull out Rear Parking Aid Warning Buzzer H15 - 2 - at right belt webbing guide - 3 - in - direction of arrow -.
3. Disconnect electrical harness connector - 1 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install C-pillar trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Rear Parking Aid Warning Buzzer H15 at right belt webbing guide, removing and installing - Avant

Removing

1. Remove side trim luggage compartment --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .
2. If necessary, remove insulation mat in area of Rear Parking Aid Warning Buzzer H15.
3. Pull out Rear Parking Aid Warning Buzzer H15 - 2 - at right belt webbing guide - 3 - in - direction of arrow -.
4. Disconnect electrical harness connector - 1 -.

Installing

Installation is performed in reverse order of removal, noting the following

1. Install luggage compartment side trim --> «70 - INTERIOR TRIM»(/audi/a6/6-2004-2008/remont/gauges-instrument-panels/#body-interior) .

Scheme 257

Component location: In bumper - arrows -.

Removing

Inner sensor
